Chapter 1

Introduction

Thank you for purchasing a Vertical Communications phone. All SBX phones are multifunctional and specifically designed for use with the Vertical SBX system.

This chapter provides you with information that applies to all phone models, and includes:

• How to Use this Guide - see page 1-2

• Getting Help - see page 1-3

• Connecting Your Phone - page 1-4

• 911 Feature - page 1-5

SBX IP 320 Phone User Guide

1-2 How To Use This Guide

Chapter 1: Introduction

How To Use This Guide

This guide provides a comprehensive description of each type of phone and its functionality. Depending upon the type of phone you have (digital or single line/SLT), you will need to review the basic information in the chapters designated for your phone type (see Features” on page 1-2).

SBX Phone Features

It is a good idea to review the information in specific to your SBX phone to familiarize yourself with the basic operation, features, and function.

Note: You may see features available on your phone display that are not

detailed in this document. This is because those features are available to System Administrators only and only detailed in the SBX Features and Operations document.

In addition, it is recommended that if you find a feature on the phone display that is not described in this document, that you do NOT attempt to access the feature, but instead, contact your System Administrator for more information.

Specific Phone Model Information and Features

While general information for SBX phones can be found in Chapters 1 and 2 of this guide, information regarding each type of phone and phone model are covered in chapters 4 through 6.

“Specific Phone Model Information and

If You are Using a Digital Phone

For specific details about using your digital phone, see the chapter as noted below:

• For the 24-Button Digital Phone, see chapter 2.

• For the 8-Button Digital Phone, see chapter 3.

If You are Using a Single Line Phone

For specific details about using an SBX SLT Phone, see chapter 4.

Feature Index

You can also use the Feature Index at the back of this document to find page locations for each feature available on your phone type.

SBX IP 320 Phone User Guide

Getting Help 1-3

Chapter 1: Introduction

Getting Help

If you need information that is not included in this guide, you can get help from either of the following sources:

Your System Administrator

Your first line of support is your System Administrator. This person should be able to provide you with any additional information you may need regarding your phone. For example, the System Administrator can provide you with a list of any pre-programmed buttons depending upon the type of phone you are using.

Vertical Technical Support

If you System Administrator is unavailable, or you have questions that he/she cannot answer your questions, you can

at 1-888-422-2305, Option 4.

contact V ertical Technical Support

SBX IP 320 Phone User Guide

1-4 Connecting Your Phone

Chapter 1: Introduction

Connecting Your Phone

Connecting a Digital Phone

The diagram and information below apply to both the Twenty-four and Eight Button Digital Phones.

A -Connect the telephone cord (curly cord) to the

handset and the other end to the handset jack at the bottom of the telephone.

B -Connect the line cable to the port at the bottom

of telephone and the other end to the wall socket.

C - Connect the Headphone to the headphone jack.

Connecting Your Single Line (SLT) Phone

The connection process for an SLT phone may vary from model to model. You can use the above information as a general guideline. However, if you have any problem or questions getting the connections made properly, contact your System Administrator or refer the manufacturer’s user guide provided with your phone

SBX IP 320 Phone User Guide

911 Feature 1-5

Chapter 1: Introduction

911 Feature

If your System Administrator has pre-programmed it, your phone may have a Flex button designated specifically for 911 calls. If you use this button to place a call to 911 when all lines are busy, an active call is dropped, so that the 91 1 call can be placed.

IMPORTANT: Contact your System Administrator for details about using this

button as it is possible that it has been set up so that you don’t have to use an access code, such as 9, before dialing 911.

To Dial 911

1. Press the designated Flex Button.

If an access code is required as per your System Administrator:

2. Dial 9, then 911 (if the access code is required).

If an access code is NOT required as per your System Administrator:

Dial 911 to place the call.

- If all trunks are busy, the system will drop an in-progress trunk, pause for less than two seconds, then place the 911 call.

Note: Any station user or Attendant who programs a flexible button for 911

ALERT will be alerted of internal stations placing 911 calls. The system can store the sixteen most recent 911 calls.

Calling information includes the time/date of the call, as well as the station number from which the call was placed.

SBX IP 320 Phone User Guide

THIS PAGE INTENTIONALLY LEFT BLANK.

Chapter 2

Using the 24-Button Digital Phone

This chapter describes the specific features of the SBX 24-Button Digital phones. Included in this chapter:

• Using the Basics - see page 2-2

• Customizing Your Phone - see page 2-19

• Using Features and Functions - see page 2-31

SBX IP 320 Phone User Guide

2-2 Using the Basics

1314

Chapter 2: Using the 24-Button Digital Phone

Using the Basics

This section will provide you with basic information including the following:

• What’s on the 24-Button Digital Phone - see below

• Using the Display - see page 2-4

• Making and Answering Outside Calls - page 2-12

• Using the Hold Feature - see page 2-17

• Transferring Calls - see page 2-18

What’s on the 24-Button Digital Phone

SBX IP 320 Phone User Guide

Using the Basics 2-3

Chapter 2: Using the 24-Button Digital Phone

Phone Buttons and Features

Feature Used to...

Headphone Jack speak to a caller when using a headset instead of

Handset answer/make internal or external calls.

Speaker hear the other party during a call without using the

LCD Display display phone status information, dialing directories,

Soft Buttons (3) work in conjunction with fixed and flexible features

Ring LED indicate when the phone is ringing.

Pre-Programmed/ Flexible Buttons (24)

Microphone (MIC) used to speak to a caller when in speaker mode.

SPEED Button access speed dialing, saved number redial, and last

DND Button activate a “do not ring this phone” mode. When DND

TRANS/PGM Button set up a conference call or transfer a call. CALL BACK Button initiate a call back request for another busy station.

Nav Button navigate through (and make selections on) the

VOLUME Button decrease (-) or increase (+) the volume level of the

HOLD/SAVE Button put a call on hold or save the current User

Dialpad dial phone numbers and make entries on the display.

SPEAKER Button toggle between speaker (or headset) mode and

holding the handset.

handset or headset (hands-free mode).

and test message information.

options that appear on the display.

access external line calls, pre-assigned features, or user defined feature code assignments.

number redial. Button is also used to access flexible button programming.

is active, this button is red.

Note: When you make a Forward call setting (other

than forwarding to voice mail), this light will Flash. You can press it to easily cancel those Forward settings.

display/menus.

speaker or handset while on a call.

Programming setting.

handset mode. You can also use this button to exit any menu screen.

Note: The button is red when speakerphone

is active.

SBX IP 320 Phone User Guide

2-4 Using the Basics

STATION 100 (T) DEC 03 08 02:04 pm PICKUP CONF REDIAL-->

Station Number or Name

(See page 2-19.)

Current month, day, and year

Current system time

Options displayed when phone is idle: PICKUP - see page 2-54 CONF - see page 2-39 REDIAL - see page 2-55

Soft buttons used to scroll and make selections on the display (see below).

NOTE: The Nav Button can also be

used to scroll and make selections on the display (see page 2-8).

Current H/T/P Mode setting

(see page 2-25)

Chapter 2: Using the 24-Button Digital Phone

Using the Display

The display provides you with basic information about the current status of your phone (idle, busy, call forwarding). You can also use the display to make some basic programming changes to your station, as well as to make selections for various features. The following display components are described below:

• LCD - see below

• Soft Buttons - see page 2-5

• Nav Button - see page 2-8

Basic information that appears on your display when it is idle is shown below:

SBX IP 320 Phone User Guide

Using the Basics 2-5

BUSY : STA 100 [CALLBK] CAMP(*) OHO(#) MSG CAMP-ON FLASH

Chapter 2: Using the 24-Button Digital Phone

Soft Buttons

The three Soft Buttons are located under the LCD. The function of each button changes, according to call status and progress.

Example: You call a busy extension, the busy status will appear on the

display along with the options available - “ “CAMP-ON” and “FLASH”.

Press the button that corresponds to the function you want to use.

List of Soft Buttons

Below is a list of soft buttons that may appear at various times when you are using the phone.

SOFT BUTTON

ADD

BACK

CALLBK

CAMP-ON

APPEARS... USED...

when are listening to a voice mail message.

on various screens. to return to the previous screen

when you get a busy signal when you have dialed another station or attempted to access an outside line.

when you are listening to a voice mail message from another station.

when you get a busy signal when you have dialed another station within the system.

to add a comment to a message before forwarding it to another station.

(menu). to automatically call back an

extension that is busy or to alert you when an outside line is available.

to call back the station that left the voice mail message.

to automatically call back an extension that is busy (like Callback).

MESSAGE WAIT”,

SBX IP 320 Phone User Guide

(continued on next page)

2-6 Using the Basics

Chapter 2: Using the 24-Button Digital Phone

SOFT BUTTON APPEARS... USED...

CONF

DEL ALL

DEL CUR

DELETE

D-TONE

DROP

ERASE

FLASH

when the phone is idle or when you dial or answer a call.

in the Call Log. to delete all items in the log. in the Call Log. to delete the current item. when you are listening to a

voice mail message. in some of the Forwarding

settings.

in the Monitor/Join feature. to end a call in which you are

in the pre-programmed messages and station speed dial screens.

any time you are off-hook and/or make an error when dialing.

to initiate conference calls between yourself and 2 or more participants.

to delete the current message.

if you need to have these to dial the number (for example to add a dial tone to a number to which you are forwarding calls).

monitoring or have joined another extension’s conversation.

to erase the current entry.

when off-hook to stop the current action and return the dial tone

FWD

JOIN

MONITOR

MSG

MUTE

in some of the Forwarding settings.

when the phone is idle to access the Forward call settings. in the Monitor/Join feature. to a join the conversation that you are

in the Monitor/Join feature. listen in on a conversation between

when you dial a busy extension.

when you are on a call. to prevent the caller at the distant end

on various option screens. to go scroll (right) to the next available

if you need to have these to dial the number (for example to add a flash to a number to which you are forwarding calls).

monitoring.

another extension and a caller without the participants knowing you are listening.

allows you to leave your station number or message at a busy extension.

from hearing anything through your microphone or handset during a call.

setting and/or option

(continued on next page)

SBX IP 320 Phone User Guide

Using the Basics 2-7

Chapter 2: Using the 24-Button Digital Phone

SOFT BUTTON APPEARS... USED...

PAU S E

PICKUP

RECORD

on various option screens. to accept the currently displayed

in some of the Forwarding settings.

when your phone is off-hook. to pick up a call that is ringing at one

in the Call Record screen. to begin recording the current

option or setting. if you need to have these to dial the

number (for example to add a pause to a number to which you are forwarding calls).

of the stations within your PickUp Group.

conversation. Warning: In many localities, it is illegal to record a phone call without first notifying the person or persons being recorded. Contact your System Administrator for information about call recording guidelines.

REDIAL

REPEAT

REWIND

SELECT

SEND

TRANS

when your phone off hook. Redial the last dialed number. when you are listening to

voice mail messages. when you are listening to

voice mail messages. in the call log. to select the currently displayed

when you are using the PhoneBook feature.

during a Meet-Me page. when you are on a call. to transfer the current call to another

to replay the current message from the very beginning.

to rewind the current messages by a few seconds each time you press it.

option. to dial a selected name or number.

when responding to a Meet-Me page.

station.

(continued on next page)

SBX IP 320 Phone User Guide

2-8 Using the Basics

Access Programming Options

Access PhoneBook Options

Use center "OK" button instead of the "OK" soft button, and sometimes the HOLD/SAVE button.

Go to previous item (indicated by left arrow: <- - ; see image below)

Go to previous item (indicated by right arrow: - ->; see image below)

STATION 100 (T) APR 01 XX 05:34 pm FWD CONF REDIAL-->

STATION 100 (T) APR 01 XX 05:34 pm <--ICM FLASH

Return to previous item

Go to next item

Chapter 2: Using the 24-Button Digital Phone

Nav Button

This button on the twenty-four button phone allows you to select or scroll through multiple items or options on the display.

Multiple items often are indicated by an arrow (left or right) as shown on the examples below.

Press the navigation key to display subsequent information (as shown above).

SBX IP 320 Phone User Guide

Using the Basics 2-9

1. BASIC PROGRAM

2. ADVANCED PROGRAM

3. SPEED PROGRAM

4. MOBIL EXTENSION PGM

5. CONFERENCE ROOM PGM

6. HOTDESK PGM

Chapter 2: Using the 24-Button Digital Phone

Station Programming Menu Overview

The following shows the menus available for programming features on the 24-Button phone. These menus are shown throughout this chapter when describing the procedures to program specific features and function.

1. Use on the Nav button to scroll through the options.

2. Use the OK soft button to make selections.

SBX IP 320 Phone User Guide

2-10 Using the Basics

Chapter 2: Using the 24-Button Digital Phone

Message Wait and Callback Indicator Lights

The Message Wait light lets you know that a voice mail message is has been left in your mailbox. The Callback light indicates whether or not a Callback request has been placed on your phone (see page diagram shows the location of the Message Wait and Callback lights, and is followed by a description of each of the lights and how they are used.

Also see “Voice Mail” on page 2-62.

Messages

• A new message for the VMIB or external voice mail is defined as a message in the mailbox which has not yet been played to the subscriber.

• A saved message is defined as a message in the mailbox which has been played to the subscriber, but has not been deleted or moved.

• A station message wait request is defined as the MWI request left by another intercom station without a voice message, by pressing the Call Back button when ringing a busy or unanswered station.

2-37). The following

SBX IP 320 Phone User Guide

Using the Basics 2-11

Chapter 2: Using the 24-Button Digital Phone

Fixed, Pre-programmed, & Flex Buttons

The phone described in this guide has both Fixed, Pre-programmed (sometimes also known as Feature), and Flex buttons. These buttons are used to access and perform various tasks and functions. Some may be used in conjunction with other buttons.

• Fixed buttons are those that are permanently labeled on the phone hardware. Such buttons might include SPEAKER, TRANS, HOLD, VOLUME, etc.

• Pre-programmed buttons are those buttons that are pre-progra mmed by your System Administrator. Their names/functions will be on a more temporary-type template that can be replaced if/when the buttons are reprogrammed, etc.

• Flex buttons are also known as "User Programmable" buttons (see “Programming Flex Buttons” on page 2-30). In addition, Flex buttons that are programmed to access the dial tone, are also known as "line buttons".

SBX IP 320 Phone User Guide

2-12 Using the Basics

Chapter 2: Using the 24-Button Digital Phone

Making and Answering Calls

• Internal calls are also known as Intercom calls. These are call s tha t originate or that you make to another station within your phone system.

• External calls are those that originate from or that you make to a source outside your company’s phone system (for example, customers, vendors, etc.).

Making Calls

Dial an Internal Call

1. Lift the handset.

Press SPEAKER*.

Begin dialing from the dialpad.

2. Dial the station number.

Dial an External Call

The following procedure provides the steps to manually dial a call. However, you can also use this method using a speed dial number (see on page 2-56 for details).

1. Lift the handset.

Press SPEAKER*.

Go to Step 2 below.

2. Dial the access code to get to an outside line. NOTE: Outside line (CO) access codes "9" or "88XX". Contact your

System Administrator if you are unsure about what your company access code is.

3. Dial the phone number.

“Speed Dialing”

* For details about using the speaker, (see next

page). For information about using a headset on your phone, see page

SBX IP 320 Phone User Guide

2-15

(continued on next page)

Using the Basics 2-13

Chapter 2: Using the 24-Button Digital Phone

Answering Calls

Aside from using the handset or speakerphone (when available), the operation of the digital phones is quite basic.

Answer an Internal (Intercom) Call

Lift the handset.

Press SPEAKER*.

Answering an External Call

1. Lift the handset or press SPEAKER*.

2. Press the flashing green line (Flex) button.

Using the Speaker

By default, your phone is set to Speaker mode. However, you may have access to changing your phone to the Headset mode. Before you use the speaker to make or answer calls, be sure that it is in the Speaker mode (see page 2-15).

Make a Call

1. Press the line or SPEAKER.

2. Follow the usual process for making calls shown above.

Answer a Call

When the phone is ringing:

1. Press the line or SPEAKER.

End a Call

Press SPEAKER to drop the active call.

* For details about using the speaker, (see below).

For information about using a headset on your phone, see page

SBX IP 320 Phone User Guide

2-15

(continued on next page)

2-14 Using the Basics

Chapter 2: Using the 24-Button Digital Phone

Switch between Handset and Speaker

To switch from Handset to Speaker Mode

While on a call:

1. Press the line or SPEAKER.

2. Place the handset on hook to transition the call from the handset to the speaker mode.

NOTE: If you press line or Speaker and you don’t hear the caller (when

answering a call) or a dial tone (when making a call), check to make sure that the Headset Mode is not on (see "Using the Headset" below).

To Switch from Speaker Mode to Handset

While on a call:

Pick up the handset to remove the call from speaker mode, and continue the conversation.

Adjust Speaker Volume

You can easily adjust the volume of the speaker during a call.

While on a call:

Use the VOLUME down (-) and up (+) to adjust the volume of the caller’s voice.

Hint: This also works for adjusting the volume of the handset.

(continued on next page)

SBX IP 320 Phone User Guide

Using the Basics 2-15

1. BASIC PROGRAM

2. ADVANCED PROGRAM

3. STATION COS PROGRAM

4. SPK/HEADSET PROGRAM BACK OK

SPEAKER MODE SELECT BY NEXT BACK NEXT OK

HEADSET MODE SELECT BY [NEXT] BACK NEXT OK

Chapter 2: Using the 24-Button Digital Phone

Using the Headset (vs. Speaker) Mode

Set the Headset Mode

If you want to use a headset instead of the speaker for handsfree conversations, you will need to switch to the headset mode. In addition, when you want to again use the speaker instead of the headset, you need to change the phone back to speaker mode. You cannot use both the headset and speaker phone at the same time.

1. Use on the Nav Button to access the Programming Menu.

2. Use on the Nav Button to scroll to the ADVANCED

PROGRAM

3. Press the OK soft button to select the

4. Use on the Nav button to scroll through the options.

When you see the SPK/HEADSET PROGRAM option:

5. Press the OK soft button to select the option.

option.

ADVANCED PROGRAM option.

6. Press the NEXT soft button to toggle between the SPEAKER

HEADSET MODEs.

and

7. Press the OK soft button to save the setting.

(continued on next page)

SBX IP 320 Phone User Guide

2-16 Using the Basics

1. BASIC PROGRAM

2. ADVANCED PROGRAM

5. EAR/MIC PROGRAM

BACK OK

Chapter 2: Using the 24-Button Digital Phone

Using the Headset

Once you set the headset mode, you can toggle between the handset and the headset in the same way you toggle between the handset and speaker (see “Switch between Handset and Speaker” on page 2-14).

Press SPEAKER to toggle between using the handset and the headset.

Adjusting the Volume on the Headset

While on a call:

Use the VOLUME down (-) and up (+) to adjust the volume of the caller’s voice.

Using a Headset with a 2.5 mm Headset Jack (Ear/Mic)

If you are using a special headset that has a 2.5mm headset jack, (that is Ear/Mic units) a special setting in addition to the basic Headset Mode setting is required.

Note: Contact your System Administrator to find out if the headset you are

using requires this additional setting.

Follow the steps 1 through 6 for Setting the Headset Mode.

7. Use on the Nav Button to access the Programming Menu.

8. Use on the Nav Button to scroll to the ADVANCED

PROGRAM

9. Press the OK soft button to select the ADVANCED

PROGRAM option.

10. Use on the Nav button to scroll through the options.

When you see the EAR/MIC PROGRAM option:

1 1 . Press the OK soft bu tton to

select the option.

option.

(continued on next page)

SBX IP 320 Phone User Guide

Using the Basics 2-17

EAR/MIC HEADSET > OFF BACK NEXT OK

EAR/MIC HEADSET > ON BACK NEXT OK

Chapter 2: Using the 24-Button Digital Phone

12. Press the NEXT soft button to toggle between the EAR/MIC

OFF and ON.

13. Press the OK soft butt on to save the setting.

Using a Headset with a 2.5mm Jack (Ear/Mic)

See “Using a Headset with a 2.5mm Jack (Ear/Mic)” on page 2-17.

Adjusting the Volume on the Ear/Mic

See “Adjusting the Volume on the Headset” on page 2-16.

Using the Hold Feature

To Put a Call On Hold

Press HOLD/SAVE to place the current call on hol d.

To Retrieve a Call on Hold

Press the flashing red line (Flex) button. NOTE: Calls left on hold for a preset period of time will ringback to the

last extension that placed the call on hold. contact your System Administrator for more information about the ringback time.

SBX IP 320 Phone User Guide

2-18 Using the Basics

19415552222 LINE 08 00:00:03 TRANS CONF MUTE-->

Chapter 2: Using the 24-Button Digital Phone

Transferring Calls

You can perform both screened and unscreened transfer s, as well as direct transfer to a voice mailbox:

• Screened Transfers: Allows you to announce a call to the destination station before completing the transfer.

• Unscreened Transfer: Allows you to complete a transfer without announcing the party to the destination station.

Transfer a Call from Your Station to another Station

While on a call:

1. Press the TRANS soft button or TRANS/PGM to put the current call on hold.

2. Dial the destination target (station or hunt group) to which you want to transfer the call.

To Make a Screened Transfer

3. Wait for the destination target to answer.

4. Announce to the destination target who is calling, then hang up to complete the transfer.

NOTE: If the destination station/hunt group is busy or the user does not

want to accept the call, press the TRANS/PGM to reconnect to the caller.

To Make an Unscreened Transfer

5. Wait for the destination target to ring, then hang up before it is answered to complete the transfer.

NOTE: If the destination station/hunt group is busy, press the TRANS

soft button or TRANS/PGM to reconnect to the caller.

TRANS soft button or

Transfer a Call Directly to Voice Mail

1. Press the TRANS soft button or TRANS/PGM to put the current call on hold.

2. Press the CALLBK soft button.

3. Dial a destination voice mailbox number.

When the voice mail answers:

4. Hang up to complete the transfer.

SBX IP 320 Phone User Guide

Customizing Your Phone 2-19

1. BASIC PROGRAM

2. ADVANCED PROGRAM OK

1. STATION NAME PROGRAM

2. RING PROGRAM BACK OK

Chapter 2: Using the 24-Button Digital Phone

Customizing Your Phone

The following pages provide details about customizing your phone. This includes designating:

• A Station Name - see below

• A Station Greeting for Incoming Calls - see page 2-23

• Ring Types for Incoming Calls - see page 2-24

• The HTP Option for Incoming Calls - see page 2-25

Station Name Programming

You can designate a "name" for your station. This name will appear on your display, as well as the display of any other st ation in your system that you call or that calls you.

1. Use on the Nav Button to access the Programming Menu.

2. Press the OK soft button to select the BASIC PROGRAM option.

3. Make sure the STATION

NAME PROGRAM

selected.

4. Press the OK soft button to select the STATION NAME

PROGRAM

option is

option.

(continued on next page)

SBX IP 320 Phone User Guide

2-20 Customizing Your Phone

ENTER NAME ( ) BACK OK

JAMES PAUL (T ) DEC 03 08 02:34 pm PICKUP CONF REDIAL-->

Chapter 2: Using the 24-Button Digital Phone

5. Enter the name you want to have appear on the display

“Entering Characters

(see for Display Entries” on page 2-20).

6. Press HOLD/SAVE to save the entry.

- The name will now

appear on your display.

Entering Characters for Display Entries

In addition to using the dialpad to enter numbers on the display, You may need to use it to also enter text when using various features that allow you to enter text on the display (such as Station Name Programming, Pre-selected Messages, Phonebook entries, and Speed Dialing entries).

Use the table below to locate the letter, number, and symbol codes that allow you to enter text on your display.

Example: To enter the name MARY, you would use the dialpad to enter

the number series: 61 (for M), 21 (for A), 73 (for R), and 93 (for Y).

21 = A 22 = B 23 = C 31 = D

72 = Q 73 = R 74 = S 81 = T

00 = 0 10 = 1 20 = 2 30 = 3

32 = E 33 = F 41 = G 42 = H

82 = U 83 = V 91 = W 92 = X

40 = 4 50 = 5 60 = 6 70 = 7

SBX IP 320 Phone User Guide

43 = I 51 = J 52 = K 53 = L

93 = Y 94 = Z

80 = 8 90 = 9

61 = M 62 = N 63 = O 71 = P

13 = .

61 = SPACE 62 = : 63 = ,

Customizing Your Phone 2-21

1. BASIC PROGRAM

2. ADVANCED PROGRAM OK

3. MODE(H/T/P) PROGRAM

4. PASSWORD PROGRAM

BACK OK

> PASSWORD REGISTER SELECT BY [NEXT] BACK NEXT OK

Chapter 2: Using the 24-Button Digital Phone

Setting Your Password

Various options and selections available on your phone require that you enter a password. In order to make the password easy for you to remember, you can create and/or change your password using the procedures below.

IMPORTANT: Contact your System Administrator to find out if there is a

password currently set for your phone. You will need to use that password in order to change or re-set it.

Registering (Creating) Your Password

1. Use on the Nav Button to access the Programming Menu.

2. Press the OK soft button to select the BASIC PROGRAM option.

3. Use on the Nav button to scroll through the options.

When you see the PASSWORD PROGRAM option:

4. Press the OK soft button to select the option.

When you see the PASSWORD REGISTER option:

5. Press the OK soft button to select the PA SS W OR D

6. Use the dialpad to enter the current password (see IMPORTANT note above).

(continued on next page)

SBX IP 320 Phone User Guide

2-22 Customizing Your Phone

ENTER PASSWORD

BACK OK

1. BASIC PROGRAM

2. ADVANCED PROGRAM OK

3. MODE(H/T/P) PROGRAM

4. PASSWORD PROGRAM

BACK OK

> PASSWORD CHANGE SELECT BY [NEXT] BACK NEXT OK

ENTER CURRENT PASSWORD > BACK OK

Chapter 2: Using the 24-Button Digital Phone

7. Press OK.

8. Use the dialpad to enter the new password (3 to 11 digits).

9. Press OK to save your password.

Changing Your Password

1. Use on the Nav Button to access the Programming Menu.

2. Press the OK soft button to select the BASIC PROGRAM option.

3. Use on the Nav button to scroll through the options.

When you see the PASSWORD PROGRAM option:

4. Press the OK soft button to select the option.

5. Press the NEXT soft button to scroll to the PA S SW O R D

CHANGE

When you see the PASSWORD CHANGE option:

6. Press the OK soft button to select the

CHANGE

option.

PA SS W OR D

password.

(continued on next page)

SBX IP 320 Phone User Guide

Customizing Your Phone 2-23

ENTER PASSWORD

BACK OK

Chapter 2: Using the 24-Button Digital Phone

7. Use the dialpad to enter the current password new password (3 to 11 digits)

- See IMPORTANT note on

page 2-21).

8. Press the OK soft button to save your new password.

Recording Your Station Name (Voice Title)

Record or change your name as it will be heard by callers when they dial your extension. If you do not record your own voice title, the system may play a default recording (contact your System Administrator for more information about any default recordings).

1. Lift the handset.

2. Press TRANS/PGM.

3. Press 6.

4. Press 6, then #.

At the prompt/tone:

5. Record your name.

6. Press HOLD/SAVE to complete and save the recording.

Recording Your Station Greeting

You can record the greeting that your callers will here if they reach your voice mail because your phone is busy or because you are away.

Note: This feature applies to in-skin voice mail (VMIB) systems only.

Contact your System Administrator for more information.

1. Press TRANS/PGM.

2. Enter 61.

3. Enter your station number. NOTE: If a greeting already exists, it will be played.

4. Press #.

At the prompt:

5. Begin recording your greeting .

6. Press HOLD/SAVE or SPEAKER to end and save the recording.

- A confirmation tone sounds.

SBX IP 320 Phone User Guide

2-24 Customizing Your Phone

1. BASIC PROGRAM

2. ADVANCED PROGRAM OK

1. STATION NAME PROGRAM

2. RING PROGRAM

BACK OK

1. ICM RING

2. CO RING

BACK OK

RING TYPE : 01 (01-15) SELECT BY [NEXT] BACK NEXT OK

Chapter 2: Using the 24-Button Digital Phone

Setting Ring Types

Use this feature to set different ring types for your incoming intercom calls and external (CO) calls. This allows you to instantly know if you are receiving an intercom call or a call from an outside source.

1. Use on the Nav Button to access the Programming Menu.

2. Press the OK soft button to select the option.

3. Use the on the Nav button to scroll through the options.

When you see the Ring Program option:

4. Press the OK soft button to select the Ring Program option.

5. Use the on the Nav button to toggle between the

ICM (Intercom) and CO

(outside call) options.

BASIC PROGRAM

6. Press the NEXT soft button to scroll through the various ring types.

- As you scroll, the ring types

will sound.

When you hear the ring type you want to use for the currently selected call type (ICM or CO):

7. Press the OK soft button to save the setting.

SBX IP 320 Phone User Guide

Customizing Your Phone 2-25

1. BASIC PROGRAM

2. ADVANCED PROGRAM OK

3. MODE(H/T/P) PROGRAM

4. PASSWORD PROGRAM

BACK OK

TONE MODE SELECT BY [NEXT] BACK NEXT OK

Chapter 2: Using the 24-Button Digital Phone

Setting the HTP Mode

You can set your phone to handle incoming calls in any of the various ways:

• Handsfree Mode- You will hear three bursts of tone and an announcement. Reply handsfree (using the mic and speaker) or lift handset. The calling party can hear any conversation in progress.

• T one Mode (default)- You will hear repeated bursts of intercom ring tone and the HOLD button slow flashes. Lift the handset or press SPEAKER button to answer.

• Private - Y ou will hear three bursts of tone and a one-way announcement. The calling party cannot hear any conversation in progress until you lift the handset or press Speaker to accept the call.

1. Use on the Nav Button to access the Programming Menu.

2. Press the OK soft button to select the option.

3. Use on the Nav button to scroll through the options.

When you see the MODE H/T/P PROGRAM option:

4. Make sure the MODE (H/T/P) PROGRAM option is selected.

5. Press the OK soft button to select the option.

BASIC PROGRAM

6. Press the NEXT soft button to scroll through the various HTP Mode options.

(continued on next page)

SBX IP 320 Phone User Guide

2-26 Customizing Your Phone

PRIVATE MODE SELECT BY [NEXT] BACK NEXT OK

STATION 100 (P) DEC 03 08 08:34 am PICKUP CONF REDIAL

Chapter 2: Using the 24-Button Digital Phone

When you see the HTP Mode you want to use:

7. Press the OK soft button to save the setting.

- The currently selected

setting will appear on the display.

Using Pre-Selected Display Messages

You can set a message on your display that will appear on the display of any other station within your system. These messages will alert the caller as to your status.

Available Pre-selected Messages that are:

•AT HOME

• AT BRANCH OFFICE

• IN A MEETING / RETURN AT TIME XX:XX

• IN OFFICE STASSS

• CALL TO (PHONE NO :)

• OUT OF OFFICE / RETURN UNKNOWN

• OUT OF OFFICE / RETURN AT DATE XX:XX

• OUT OF OFFICE / RETURN AT TIME XX:XX

• ON VACATION / RETURN AT DATE XX:XX

• LUNCH RETURN AT XX:XX

• USER CUSTOM MSG

HINT: To create your own messages using the Character Entry chart

on page 2-20

Note: Contact your System Administrator for more information.

(continued on next page)

SBX IP 320 Phone User Guide

Customizing Your Phone 2-27

1. BASIC PROGRAM

2. ADVANCED PROGRAM

1. WAKE UP PROGRAM

2. PRESELECTED MSG PGM

BACK OK

AT BRANCH OFFICE

BACK OK

OUT OF OFFICE RETURN AT TIME XX:XX BACK OK

Chapter 2: Using the 24-Button Digital Phone

Setting a Pre-Selected Message

1. Use on the Nav Button to access the Programming Menu.

2. Use on the Nav Button to scroll to the ADVANCED

PROGRAM option.

3. Press the OK soft button to select the ADVANCED

PROGRAM

4. Use the on the Nav button to scroll through the options.

When you see the PRESELECTED MSG PGM option:

5. Press the OK soft button to select the option.

6. Use the on the Nav button to scroll through the available messages (as shown on previous page).

When you see the pre-selected message you want to use:

option.

7. Press OK to select it.

(continued on next page)

SBX IP 320 Phone User Guide

2-28 Customizing Your Phone

OUT OF OFFICE RETURN AT TIME XX:XX BACK OK

ENTER TIME 16:30 PRESS OK KEY BACK P.DVU OK

OUT OF OFFICE RETURN AT TIME 04:30 pm PICKUP CONF REDIAL

Chapter 2: Using the 24-Button Digital Phone

If You Select a Message that Requires a Phone Number, Date, or Time Input

8. Use the dialpad to enter phone numbers, dates, and times.

NOTE: For dates, you need

to use two digits for the month and day.

- For times, you need to use

two digits for the hour, and two digits for the minutes. In addition, you must use the 24-mode system.

Example: For 8:30am, you

enter 0830. For 4:30pm you must enter 1630.

Once you have completed the setting:

9. Press the OK soft button to save the setting.

- Once the message has

been selected and time/date/phone numbers entered as needed, it will appear on your display. In addition, the DND LED will flash.

To Cancel an Message

Press DND.

(continued on next page)

SBX IP 320 Phone User Guide

Customizing Your Phone 2-29

Chapter 2: Using the 24-Button Digital Phone

Creating a Custom Message

Contact your System Administrator to see if your phone is allowed to create custom messages.

Follow steps 1 to 6 above to select the User Custom Message option.

7. Enter the message you want to have displayed (see “Entering Characters for Display Entries” on page 2-20).

8. Press the OK soft button to save the message.

SBX IP 320 Phone User Guide

2-30 Customizing Your Phone

Chapter 2: Using the 24-Button Digital Phone

Programming Flex Buttons

If you have access to the Flex Button programming option, you can assign different tasks to any Flex button on your phone (see & Flex Buttons” on page 2-11).

Note: Contact your System Administrator to find out if you have this access.

1. Press TRANS/PGM.

2. Press the flexible button to be programmed.

3. Enter the applicable feature code from the following table.

4. Press HOLD/SAVE to save the setting.

Numbering Plan the 24-button Digital Phone

Account Code PGM + 80 Record Page MSG PGM + 65

Alarm Reset 565 Record User Greeting PGM + 61

Auth. Code Change PGM + 32 Register Station Name PGM + 74

Auth. Code Register PGM + 31 Record User Greeting PGM + 61

Background Music PGM + 73 Register Station Name PGM + 74

Call Log PGM + 57 REDIAL button TRANS + 97

Call Park 601-608 Ring Answer Mode PGM + 12

Camp-On PGM + 85 Ring Type PGM + 11

COS Down PGM + 21 Set Customer MSG PGM + 52

COS Restore PGM + 22 Set Pre-selected MSG PGM + 51

Direct Station Select 100-131 Set Wake-up Time PGM + 41

Erase Page MSG PGM + 67 Speakerphone/Headset PGM + 75

Erase User Greeting PGM + 66 Two way recording PGM + 54

Group Call PickUp PGM + 71 Universal Night Answer 569

H-T-P PGM + 12 Wake-up Disable PGM + 42

Headset Ring Mode PGM + 76 Walking COS PGM + 23

Hunt Group 620-629 Outside Line Access

ICM Hold PGM + 83 Group 801-808

LCD D isplay La nguage PGM + 71 Group access 9

Listen Station Number PGM + 63 Individual Line Access 8801-8812

Listen Station Status PGM + 64 Speed Dial

Listen Time & Date PGM + 62 Station speed dial SPEED + 000-099

LOOP button PGM + 84 System speed dial SPEED + 2000-2449

MPB Version Display PGM + 72 Ring Answer Mode PGM + 12

“Fixed, Pre-programmed,

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-31

1. BASIC PROGRAM

2. ADVANCED PROGRAM

1. WAKE UP PROGRAM

2. PRESELECTED MSG PGM BACK OK

ENTER YOUR WAKEUP TIME HH:MM 10:00 am BACK ERASE OK ENTER YOUR WAKEUP TIME 08:30 10:00 am BACK ERASE OK

Chapter 2: Using the 24-Button Digital Phone

Using Phone Features and Functions

Alarm (Wake Up Program)

You can set up an alarm or reminder on your phone. This feature can be programmed to activate one time or be programmed to repeat daily. If you are on a call when the alarm goes off, a special dial tone will sound.

1. Use on the Nav Button to access the Programming Menu.

2. Use on the Nav Button to scroll to the ADVANCED

PROGRAM

3. Press the OK soft button to select the ADVANCED PROGRAM option.

4. Use the on the Nav button to scroll through the options.

When you see the WAKE UP PROGRAM option:

5. Press the OK soft button to select the option.

option.

6. Use the dialpad to enter the time.

NOTE: Y ou need to use two

digits for the hour, and two digits for the minutes. In addition, you must use the 24-mode system.

Example: For 8:30am, you

enter 0830. for 8:30pm you must enter 2030.

(continued on next page)

SBX IP 320 Phone User Guide

2-32 Using Phone Features and Functions

ENTER YOUR WAKEUP TIME 08:30 10:00 am BACK ERASE OK

STATION 100 (T) FEB 01 08 *10:00 am PICKUP CONF REDIAL

WAKEUP RING FEB 01 08 *08:30 am

Chapter 2: Using the 24-Button Digital Phone

If you only want the alarm to go off for a single time:

7. Press #, otherwise, go to step 8. IMPORTANT: If you do not press #, the alarm will go off at the same time

each day as you have set.

Once you have completed the time alarm time setting:

8. Press the OK soft button to

save the setting.

- Once the alarm has been set, an asterisk (*) will flash next to your system’s current time on the display.

- When the alarm goes off, the tone will sound and the Alarm message will appear on your display:

To Cancel an Alarm

Repeat steps 1 through 4 for setting the alarm.

But... instead of setting a time:

5. Press the ERASE soft button.

6. Press the OK soft button to complete the cancellation.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-33

12345678 LINE 08 00:00:03 RECORD FLASH ACNR-->

Chapter 2: Using the 24-Button Digital Phone

Automatic Called Number Redial

ACNR automatically dials a number until the target answers (see Note below).

While on a call (where no one answered):

1. Use on the Nav Button to set automatic called number redial.

2. Hang up.

Note: The number will be automatically re-dialed until the target destination

answers. However, the number of times and frequency the number is automatically re-dialed is set by your System Administration.

SBX IP 320 Phone User Guide

2-34 Using Phone Features and Functions

1. RECEIVED CALL

2. DIALED CALL OK

123456789 05 FEB 08 BACK OK

Chapter 2: Using the 24-Button Digital Phone

Call Log

The Call Log feature allows you to view a log of the last several incoming and outgoing calls, to and from your station. In addition, any "lost calls" will be included in the list. You can scroll through the list of numbers, then select one of those numbers for redial.

In addition to the phone number, the phone also displays the time and date of each call, as well as any station or system speed dial identifier that may be associated with that number.

Note: A Flex button must be programmed for your phone in order for you to

use this feature (see “Programming Flex Buttons” on page 2-30 for details about programming a Call Log flex button.

The number of calls stored in your call log is defined by your System Administrator. Contact your System Administrator to find out if this feature is available on your phone system for your phone.

Using the Received or Dialed Call List

1. Press the Call Log flex button.

2. Use on the Nav Button to scroll to the call type you want to view.

When you see the list you want to dial:

3. Press the OK soft button to display the first number in the selected list.

4. Use on the Nav Button to scroll through the list of numbers in the list.

Hint: Press the BACK soft

button to return to the previous menu.

When you see a number you want to dial:

5. Press the OK soft button to dial the number.

(continued on next page)

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-35

3. LOST CALL

0123456789 03/10 16:02 CNT :01 BACK SELECT> ANSWER

0123456789 03/10 16:02 CNT :01 BACK SELECT> DELCUR

Chapter 2: Using the 24-Button Digital Phone

Using the Lost Call List

Follow steps 1 and 2 to get the Lost Call option (if you scroll past the first two lists, you will see the third option - Lost Call).

When you see the Lost Call option:

3. Press the OK soft button to display the next first number in the Lost Call list.

4. Use on the Nav Button to scroll through the list of numbers in the list.

Hint: Press the BACK soft button to return to the previous menu.Select

When you see a number you want to dial, delete, save, or edit:

5. Press the ANSWER soft button to dial the currently displayed number.

Press the SELECT soft button to scroll through a list of options.

6. Make a selection from the list of options:

• Press the DEL CUR soft

button to delete the

currently displayed number from the Lost Call

list, then press HOLD/SAVE to confirm the deletion.

(continued on next page)

SBX IP 320 Phone User Guide

2-36 Using Phone Features and Functions

0123456789 03/10 16:02 CNT :01 BACK SELECT> DELALL

ALL CLI DELETE Press HOLD Key BACK SELECT> DEL ALL

0123456789 03/10 16:02 CNT :01 BACK SELECT> SAVE

ENTER SPD BIN NO (000) CLI MSG USED PAU SE FLASH D-TONE

0123456789 03/10 16:02 CNT :01 BACK SELECT> SAVE

ENTER SPD BIN NO (000) CLI MSG USED PAU SE FLASH D-TON E

Chapter 2: Using the 24-Button Digital Phone

• Press the DEL ALL soft

button to delete all numbers from the Lost Call list, then press HOLD/SAVE to confirm the deletion.

• Press the SAVE soft

button to save the

number as a Speed Dial/Bin number, enter

the Speed Bin number you want to associate with this number for future use, then press HOLD/SAVE to store the new number and its bin.

HINT: CLI refers to how

the system identifies a phone number or call information.

- See “Speed Dialing” on page 2-56 for more information about Speed

Dial Numbers/Bins.

• Press the NAME/TEL soft

button to view the name associated with the currently displayed number.

HINT: Use this same

button to toggle between the number and any name associated with it.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-37

CO LINE 001 BUSY QUEUEING ([CALLBK]) CALLBK

Chapter 2: Using the 24-Button Digital Phone

Callback

Callback can be used to call back an internal caller that has left you a message. In addition, if you try to access an outside line (by dialing the access code: usually 9), you can use Callback to alert you when an outside line is freed up for you to use to make an external call.

Note: An external or outside line is also known as a CO Line.

Return a Call from Someone that Left a Message

When you have a message from another station:

1. Pick up the handset or press SPEAKER.

2. Press CALL BACK to directly dial the station from which the message was left.

Use Callback to Notify You When an Outside Line (CO LINE) is Available

When you try to access an outside line that is busy:

1. Press CALLBK.

- A confirmation beep will

sound.

When an outside line becomes available, your phone will ring.

2. Lift the handset or press SPEAKER.

3. Press the flashing line key, then dial 9 to access an outside line.

4. Dial the external phone number.

SBX IP 320 Phone User Guide

2-38 Using Phone Features and Functions

BUSY : STA 105 [CALLBK] CAMP (*) STEP

MSG CAMP-ON FLASH--> CAMP-ON BY STA 105 05 FEB 08 09:51 TRANS CONF MUTE-->

Chapter 2: Using the 24-Button Digital Phone

Camp-On

Camp-On allows you to set your phone to automatically call back a station that is busy.

The Camp-On setting will also be displayed on the busy station’s display. Note: Also see “Setting the HTP Mode” on page 2-25.

When an extension is busy:

1. Press CAMP-ON to set the feature.

- The Camp-On setting will

also appear on the busy station’s display.

When the other extension becomes "un-busy", your phone will ring:

2. Pick up the handset, or press SPEAKER.

- You will hear the other extension ringing, and can continue the call.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-39

CALL TO STA 100 DEC 03 08 08:34 am TRANS CONF MUTE-->

Chapter 2: Using the 24-Button Digital Phone

Conference

You can establish a Conference with up to 15 internal and/or external participants.

IMPORTANT: Your System Administrator may adjust or limit. Contact your

System Administrator for more information as the number of parties allowed on a single conference call may be limited to less than 15.

1. Use the basic steps for placing a call to make the first call in the conference (see page 2-12).

2. Press the CONF soft button to put the current call on hold while you add another participant.

3. Dial the next participant.

4. Press the CONF soft button twice to connect all of the participants.

Repeat steps 2 and 3 to add more participants (up to the maximum allowed by your system).

SBX IP 320 Phone User Guide

2-40 Using Phone Features and Functions

CALL FROM STA 104 DEC 03 08 08:34 am DND

12135559988 LINE 08 00:00:03 RECORD FLASH ACNR--> BUSY : STA 105 [CALLBK] CAMP (*) STEP MSG CAMP-ON FLASH-->

Chapter 2: Using the 24-Button Digital Phone

Do Not Disturb (DND)

Do Not Disturb (DND) prevents your phone from ringing. It also blocks pages and voice calls. Callbacks from calls left on Hold, Park, and Camp-On will still ring your phone.

• Using the Do Not Disturb button, you can enable or disable Do Not Disturb while you are using the phone without interrupting your conversation.

• If you enable Do Not Disturb while your line is ringing, the call is transferred to your Busy Forward destination (see “Flash” on page 2-40), with one exception: if you are a member of a Hunt Group, and you enable Do Not Disturb for a call, the call will continue to ring the other phones in the hunt group.

Press the DND soft button.

Press DND (fixed button).

Flash

The Flash allows you to disconnect the line or exit the current task and access dial tone. It may appear on the display at various points when you are performing tasks and features, or if you make a dialing error. The following provides two examples of how Flash may be available.

Press the FLASH soft button.

Use on the Nav Button to use the Flash feature.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-41

ENTER FORWARD TYPE ( 0 - 9 , # )

Chapter 2: Using the 24-Button Digital Phone

Forward Calls

Use Forward to redirect your calls to another extension or phone number. There are several Call Forward options.

Overview of Forwarding Calls

1. Press SPEAKER.

2. You will hear the dial tone.

3. Press FWD to access the Forward settings.

- The dial tone will stop and the Forward Type selection screen will appear.

4. Enter the Forward Type and the destination information as prompted (see "Entering a Destination" below, and “Selecting a Forward Type” on page 2-42).

NOTE: All Forward settings, except Follow-Me, must be made from your

own phone. For some Forward situations, you will be prompted to enter

time, date, and/or password (see“Selecting a Forward Type” on page 2-42 ).

5. Press SPEAKER to exit the Forward menu at any time. NOTE: Once you complete a Forward setting (except the forward to VM

setting), the DND will flash, and the current Forward setting will appear on the display.

Entering a Destination

When entering an Internal Destination (STA/HUNT/VMIB)

Do one of the following:

• Enter 100 to 131 to forward your calls to another station number

(STA).

• Enter 620 to 629 to forward your calls to Hunt Group.

• Enter a voice mailbox number (for either a station or Hunt Group) to

forward calls to voice mail.

(continued on next page)

SBX IP 320 Phone User Guide

2-42 Using Phone Features and Functions

FOLLOW-ME FORWARD ENTER STA/HUNT/#(VMIB)

UNCONDITIONAL FORWARD ENTER STA/HUNT/#(VMIB)

Chapter 2: Using the 24-Button Digital Phone

When Entering an OFF-NET Destination (CO BTN/SPD-B IN)

• Press a flex/line (CO) button for off-net forwarding (optional).

• Enter a station (000 to 099) or system (2000 to 2499) speed bin

number.

Selecting a Forward Type

After you access the Call Forward Option (see steps 1 through 3 in “Overview of Forwarding Calls” on page 2-41):

Select one of the following

0 = FOLLOW-ME FORWARD

From any phone in the system, you can specify an extension to which you want your calls forwarded. Once you enter the destination number, you will be prompted for your password.

Press 0 for FOLLOW-ME FORWARD.

Example: You go to work in

a lab room and want all calls forwarded to that room, but have forgotten to set the forward prior to leaving your office. You can pick up the phone in the lab and set it for the Follow-me forward. All calls to your office phone will then ring in the lab (until you cancel the setting).

1 = UNCONDITIONAL FORWARD

Have your calls forwarded to another destination no matter what your status (for example, on or off hook, busy , DND, no answer, etc.).

Press 1 for UNCONDITIONAL FORWARD, enter the destination extension, then your password.

- A confirmation tone sounds, the DND LED (on your phone) flashes.

(continued on next page)

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-43

BUSY FORWARD ENTER STA/HUNT/#(VMIB)

NO ANS FORWARD ENTER STA/HUNT/#(VMIB)

BUSY/NO ANS FORWARD ENTER STA/HUNT/#(VMIB)

FORWARD TO OFF-_NET ENTER CO BTN/SPD-BIN

Chapter 2: Using the 24-Button Digital Phone

2 = BUSY FORWARD

Have your calls forwarded to another destination when your phone is busy (that is, when you are on another call), or when DND is enabled on your phone.

Press 2 for BUSY FORWARD, then enter the destination extension.

- A confirmation tone will sound, and the DND LED will begin flashing.

3 = NO ANS FORWARD

Have your calls forwarded to another destination when there is no answer at your phone.

Press 3 for NO ANS FORWARD, then enter the destination extension.

- A confirmation tone will sound, and the DND LED will begin flashing.

4 = BUSY/NO ANS FORWARD.

Have your calls forwarded to another destination when your phone is busy, or when DND is enabled on your phone, or when there is no answer.

Press 4 for BUSY/NO ANS FORWARD, then enter the destination extension.

- A confirmation tone will sound, and the DND LED will begin flashing.

5 = (Unconditional) FORWARD TO OFF-NET - Phone Number

Have your calls to forward to an external phone number your home or cell phone) in any situation.

Press 5 for (unconditional) FORWARD TO OFF-NET, then press the CO button (line button) or enter the SPD-BIN (Speed Dial Number) that corresponds to the number to which you want your calls forwarded.

- A confirmation tone will sound, and the DND LED will begin flashing.

(such as

(continued on next page)

SBX IP 320 Phone User Guide

2-44 Using Phone Features and Functions

NO ANS FORWARD TO

OFF-_NET

ENTER CO BTN/SPD-BIN

FORWARD TO OFF-_NET ENTER CO BTN/SPD-BIN

NO ANS FORWARD TO

OFF-_NET

ENTER CO BTN/SPD-BIN

Chapter 2: Using the 24-Button Digital Phone

6 = NO ANS FORWARD TO OFF-NET - Phone Number

Have your calls to forward to an external phone number your home or cell phone) if there is no answer at your phone.

Press 6 for NO ANS FORWARD TO OFF-NET, then press the CO button (line button) or enter the to the number to which you want your calls forwarded (see.

- A confirmation tone will sound, and the DND LED will begin flashing.

(such as

SPD-BIN (Speed Dial Number) that corresponds

7 = Not available 8 =(Unconditional) FORWARD TO OFF-NET - Line Button

Use a Flex/Line button that is programmed to dial a specific outside number to forward calls in any situation.

Press 8, for FORWARD TO OFF-NET, then press the Flex/Line key associated with the number to which you want to forward your calls.

9= NO ANS FORWARD TO OFF-NET - Line Button

Use a Flex/Line button that is programmed to dial a specific outside number to forward calls when there is no answer at your station.

Press 9, NO ANS FORWARD TO OFF-NET, then press the Flex /Lin e key associated with the number to which you want to forward your calls.

# = FORWARD TO VOICE MAIL

- This setting allows you to have your calls forwarded directly to your

own voice mailbox.

NOTE: The other voice mail forward settings allow you to forward calls

Cancel Forward Setting

Press DND.

- The DND LED will stop flashing and the setting will disappear

from the display.

to OTHER voice mailboxes.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-45

1. BASIC PROGRAM

2. ADVANCED PROGRAM OK

5. CONFERENCE ROOM PGM

6. HOTDESK PROGRAM

1. HOTDESK LOG IN

2. HOTDESK LOG OUT OK

Chapter 2: Using the 24-Button Digital Phone

HotDesk

If you are set up with a "HotDesk", it allows you to share a 24-button digital phone with others while maintaining your own settings and log in information. The station used for HotDesk purposes may also be referred to as a "Dummy Station".

Example: For a call center, marketing department people on different shifts

can share a working place with one another.

IMPORTANT: You must log out when you are no longer using the station so

that it will be available to users who share the station with you.

Contact your System Administrator for details about your access to HotDesk, including password information.

To Use HotDesk

From a station designated by your System Administrator for use with the HotDesk feature:

1. Use on the Nav Button to access the Programming Menu.

2. Use the on the Nav button to scroll through the list until you see the

HOTDESK PROGRAM

option.

When you find the HOTDESK option:

3. Press the OK soft button to select it.

4. Use the on the Nav button to scroll between the

options.

To Log In:

5. Make sure the LOG IN option is selected.

(continued on next page)

SBX IP 320 Phone User Guide

2-46 Using Phone Features and Functions

DUMMY STATION 107 ENTER PASSWORD

STATION 131 (T) 01 FEB 08 06:00 am PICKUP CONF REDIAL

1. HOTDESK LOG IN

2. HOTDESK LOG OUT

AGENT LOGOUT WITH NO FORWARD SET ?

Chapter 2: Using the 24-Button Digital Phone

6. Press the OK soft button.

7. Enter the password.

8. Press the OK soft button.

- The station information that corresponds to your HotDesk log in will appear on the display:

To Log Out:

Follow steps 1 to 4 above.

5. Make sure the LOG OUT option is selected.

- Each time you log out, you

will be prompted to enter a Forward setting.

When you see the Forward prompt:

6. Use on the Nav button to scroll through the Forward options:

- NO FORWARD SET

(to set no forward option)

FORWARD TO VMIB

(to forward calls to your own voice mailbox)

FORWARD TO VM XXX

(to forward your calls to a voice mailbox other than your own)

- FORWARD TO SPD2000

- FORWARD TO STA666

(if you want to forward your calls to another user’s station)

When you see the Forward setting you want to use:

7. Press the OK soft button to store the setting and complete the log out.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-47

CALL TO STA 100 DEC 03 08 08:34 am MSG FLASH

BUSY : STA 101 [CALLBK] CAMP (* STEP <--MONITOR

Chapter 2: Using the 24-Button Digital Phone

Leave a Message (MSG)

This is very similar to Camp-On (see page 2-38). You can use this feature to let a busy station know you have called or leave a message on their display.

To Let a Busy Station Know You Called

When you dial another station that is busy:

Press the MSG soft button.

Monitor and/or Join a Conversation (Barge-In)

If you have the correct permissions set in the system, you can use Monitor to listen to a conversation between another extension and one or more other callers (internal or external).When you monitor a conversation, the participants do not know you are doing so. However, once you monitor a call, you can then join the call as a participant. In order to monitor a call, it must already be in process.

To Monitor a Busy Extension

1. Dial the extension you want to monitor.

- Several options will

appear on the display; one of these options is

MONITOR (see example

below).

When the Monitor option appears:

2. Use Nav Button to scroll left to select the MONITOR option.

3. Press LISTEN to "Barge-in" without the participants knowing you are listening.

(continued on next page)

SBX IP 320 Phone User Guide

2-48 Using Phone Features and Functions

MONITOR STA 101

JOIN DROP

MONITOR STA 101

JOIN DROP

14105557771 LINE 08 00:00:03 TRANS CONF MUTE-->

Chapter 2: Using the 24-Button Digital Phone

To Join the conversation

Once you have followed the steps above to monitor a conversation:

4. Press JOIN to participate in the conversation.

To End Monitoring

Once you have followed the steps above to monitor and/or join a conversation:

5. Press DROP to participate in the conversation.

Mute

When you are on a call, you can use the Mute feature to prevent the distant party from hearing anything on your end of the conversation. This function will mute the handset, speaker, or headset.

Example: For example: If you are on a conference call, and don’t want any

noise from your office to interrup t or d ist urb others on the call, you can Mute to keep all noise from your end of the conference from being heard by anyone else on the call.

To Enable Mute

When you are on a call:

Use on the Nav Button to select the Mute option.

To Disable Mute

After you have placed your station on Mute:

Press SPEAKER to allow the distant party (or parties) to hear you again.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-49

Chapter 2: Using the 24-Button Digital Phone

Paging

Pages must be made using the handset. Note: Your station may or may not allow you to page (either internal or

external zone paging). However, even if you cannot initiate a page from your station you may still answer a Meet-Me Page announcement. Contact your System Administrator to find out if you have any paging features available on your phone.

There are 4 ways to initiate a page: External Page, Internal Zone Page, All Call (System) Page, and Meet-Me Page:

External Paging

You can send a page to an external paging and/or amplifier system (such as out in a warehouse or outdoor area).

Internal Zone Paging

Also known as Paging Groups, Internal Zone Paging allows you to page a particular group of phones (such as only those phones in the front office or sales office areas).

Unlike the “External Paging” feature, Internal pages are made through the speaker on each phone.

Each station in your phone system can be part of in any or all zones, or in no zone at all. However, the capability of initiating a page does not rely on whether or not you are part of a Paging Group. In addition, the reverse is true: being a member of a Paging Group does not necessarily mean you can initiate a page (see Note above).

Y our system may also provide a “warning” tone to alert your group that a page is about to be made.

Note: Internal Zone pages are time limited. If the user exceeds the allotted

paging time, the page is automatically disconnected.

All Call (or System) Page

Y ou can send a page to every station within the phone system. A warming tone may be programmed to sound to let users know that a page is about to be made (such as when everyone is being called to a company-wide event or if the receptionist cannot locate a specific user to take an urgent call).

Note: All Call Pages are time limited. If the user exceeds the allotted paging

time, the page is automatically disconnected.

(continued on next page)

SBX IP 320 Phone User Guide

2-50 Using Phone Features and Functions

Chapter 2: Using the 24-Button Digital Phone

Meet-Me Page

One user can initiate a page directed at another (specific) user. The user that is paged can then respond from any station, and be directly connected to the paging party for a private conversation (such as when a user is not in their own office and needs to reach another user).

Note: The paged user has a specific amount of time to respond before the

Meet-Me page times out.

Also see “Programming Flex Buttons” on page 2-30 for details about programming a Meet-Me Page Flex button.

Sending a Page

1. Lift the handset.

2. Enter the appropriate paging code.

ACCESS CODE ITEM

501-510 Internal Page Zones 506-510 Conference page zones 543 Internal All Call Page 544 Meet Me Page 545 External Page Zone 549 All Call Page (Internal & External)

3. Make your announcement. Hint: If your system uses a warning tone you will have to wait until

AFTER the tone sounds before you make your announcement.

4. Hang up.

(continued on next page)

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-51

PAGE F R OM S TA 10 3 DEC 03 08 08:34 am MEET ME

Chapter 2: Using the 24-Button Digital Phone

Respond to a Meet-me Page

1. Lift the handset.

2. Dial 544 (Meet-me Page code).

In case of Nomad IP

Dial 544, then press the SEND soft button.

-OR

If a Meet-Me soft button appears on your display:

Press the MEET ME soft button (to respond without having to complete step 3).

3. Press HOLD/SAVE to establish connection with the paging party.

- The page feature returns to

the idle status.

SBX IP 320 Phone User Guide

2-52 Using Phone Features and Functions

Chapter 2: Using the 24-Button Digital Phone

Parking

There are two ways that Park can be set up on your system. Contact your Administrator to find out if you have the following.

• System Park

• Park and Page

System Park

You can place a call in a “parking slots” available on the SBX system for retrieval from another phone.

Example: A call may come in for someone in your group. However, that

person is somewhere else in the building. You can park the call, then page the person with the parking location/slot number. That person can then retrieve the call from any phone in the system by dialing the park location you provided.

Note: Contact your System Administrator for details about the available

parking slots, and/or if you are unsure if this feature is available on your phone.

To Park a Call

While on an active call:

1. Press TRANS/PGM, then dial the Park location/slot number (601through 608).

2. Hang up. Hint: Remember the location at which the call is parked as you need it

to retrieve the call.

To Retrieve a Parked Call at Any Station

1. Lift the handset, or press SPEAKER.

2. Dial the Park location/slot number to be connected with the caller. Note: The time a call can remain parked is limited. If parked call

exceeds this time limit, the call will ring back at the station that parked the call. If the call is still not retrieved it will route to the Automated Attendant, then it will be disconnected if not retrieved from there.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-53

Chapter 2: Using the 24-Button Digital Phone

Park and Page

This feature allows a caller reaching a mailbox to select an option to be placed into a system park state (see above), then have the mailbox user paged.

IMPORTANT: Contact your System Administrator to find out if this feature is

available on your station and/or phone system. If it is available on your station, you will need to record your mailbox greeting to let the caller know he/she has the option to page you.

Note: Y ou will need to create a recording in your mailbox to let callers know

that this option is available to them.

Example: For example: "I am currently away from my desk, if you would like

to have me paged, please press 8. Otherwise, please leave a message and I will return your call as soon as possible. (please press 8 to page me)."

How the Caller Sends a Page

When the caller reaches your mailbox and hears your pre-recorded (see IMPORTANT note above) messa ge with the page option:.

• If the caller decides to have you paged (by pressing 8), the call is placed in the first available Park location/slot number.

• Once the call is parked, the system then accesses the All Call Page code (see page 2-49) and broadcasts over all stations: "Call for [subscriber] in

location XXX"

• The system then hangs up, but the call remains parked for a designated length of time. This time is set by your System Administrator.

To Retrieve a Parked Call at Any Station

If/when you hear a page for you for a parked call:

1. Lift the handset, or press SPEAKER.

2. Dial the Park location/slot number to be connected with the caller. NOTE: The time a call can remain parked is limited. If a parked call

waiting for a page retrieval exceeds this time limit, the call will route to the Automated Attendant, then it will be disconnected if not retrieved from there.

SBX IP 320 Phone User Guide

2-54 Using Phone Features and Functions

1. DIAL BY ICM NAME

2. DIAL BY STA SPD NAME OK

3. DIAL BY SYS SPD NAME

1: JOE (105) 2: MARY (107) BACK SEND

CALL TO JOE 01 FEB 08 06:00 am MSG FLASH

19145552323 LINE 008 00:00:03 TRANS CONF MUTE

Chapter 2: Using the 24-Button Digital Phone

Phone Book/Dial by Name

You can use this feature to easily find and dial numbers that are stored in the system and on your phone: Dial by Intercom (ICM) name, Station (ST A) name, or by System (SYS) name.

Note: Also see “Programming Station Speed Dial Numbers/Bins” on

page 2-57.

Using the Phonebook for Dialing

1. Use on the Nav Button to access the Phonebook.

2. Use on the Nav button to scroll through the "Dial by..." lists.

3. Press the OK soft button to select the list you want to use.

4. Use on the Nav button to scroll through the names in the selected list.

When you find the number you want to dial:

5. Be sure that the appropriate number is selected.

6. Press the SEND soft button to dial the selected name (number).

- If you are dialing an

intercom number (another station in your system) using the ICM (Intercom) dial lists, the dialed number will appear on the display.

- If you are dialing an outside

call using the Station or System Speed dial lists, the dialed number will appear on the display.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-55

STATION 100 (T) DEC 03 08 08:34 am PICKUP CONF REDIAL

Chapter 2: Using the 24-Button Digital Phone

PickUp

You can pick up a call on any extension within your call PickUp group. Note: You must be part of a PickUp Group in order to pick up calls to that

group. Contact your System Administrator to find out if you are a member of a PickUp Group, and if so, which group.

To Pick Up a Call to Your Group

When a station within your group is ringing:

1. Lift your handset or press SPEAKER.

2. Press the PICKUP soft button to accept the call at your station.

Redial (Last Number)

The last number dialed on an external call is automatically saved by the phone as Last Number Redial (or in the Call Log - see on page 2-19).

To dial the last number dialed.

1. Press the REDIAL soft button.

- The last dialed number

appears on the display.

“Station Name Programming”

(continued on next page)

SBX IP 320 Phone User Guide

2-56 Using Phone Features and Functions

> 1234567 DEC 03 08 05:35 pm BACK DELETE OK

SPD_NO LAST(*)SAVE(#) DIAL_BY_NAME([SPEED]) SPEED

Chapter 2: Using the 24-Button Digital Phone

Once you confirm that this is the number you want to call:

2. Press the OK soft button to call the number listed.

If this is not the number you want to dial:

Use down on the Nav

Button to view scroll through other recently dialed numbers.

When the number you want to dial appears:

Go back to step 2 above.

Speed Dialing

Speed Dials can be programmed to dial directly to another person’s phone number (for external calls) or extension (for internal calls. Your System Administrator may have speed dial numbers programmed for use by anyone in the system (known as System Speed Dial Numbers). However, you may also be able to set up your own list of speed dial numbers for your own use (known as Station Speed Dial Numbers).

Note: Speed Dial Numbers are also known as Speed Bins, and may be

designated as follows:

• Station Speed Bins: 000 to 099

• System Speed Bins: 2000 to 2499

Using System and Station Speed Dial Numbers

From an idle phone:

1. Press SPEED.

2. Enter the speed dial number (in the format as shown above).

Press 6 to dial the last speed dial number used.

Press the SPEED soft button to search available speed dial numbers (both system and station) by name.

(continued on next page)

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-57

1. DIAL BY ICM NAME

2. DIAL BY STA SPD NAME OK

1. BASIC PROGRAM

2. ADVANCED PROGRAM

3. SPEED PROGRAM

5. MOBILE EXTENSION PGM OK

Chapter 2: Using the 24-Button Digital Phone

To Dial by Speed Name

Once you have pressed the SPEED soft button as shown above:

3. Use on the Nav Button to scroll between DIAL BY STA SPD

NAME or DIAL BY SYS SPD NAME option.

4. Press the OK soft button to select the "DIAL BY..." option you want to use.

Hint: Follow the steps

shown in Book/Dial by Name” on page 2-54 for details about finding and dialing a speed dial number by name.

“Phone

Programming Station Speed Dial Numbers/Bins

While your System Administrator can program System Speed Dial Numbers/Bins (those that anyone in the system can use), you can create your own list of speed dial numbers. These are known as Station Speed Dial Numbers or Bins.

1. Use on the Nav Button to access the Programming Menu.

2. Use on the Nav button to scroll through the options.

When you find the SPEED PROGRAM option:

3. Press the OK soft button to select it.

(continued on next page)

SBX IP 320 Phone User Guide

2-58 Using Phone Features and Functions

> ENTER SPD BIN NO(000) BACK

>5552323 ENTER CO-BTN/DIGIT (007) BACK DELETE

> ENTER NAME (SPD 007) BACK OK

>ABC COMPANY ENTER NAME (SPD 007) BACK OK

Chapter 2: Using the 24-Button Digital Phone

4. Enter the three-digit speed dial BIN number (for example, 007).

- This is the number that will

be associated with the actual phone number to be dialed.

5. Enter the number that you want to have dialed when the designated BIN number is selected.

- You can press DELETE to

delete the BIN number without saving it.

6. Press the OK soft button to store the phone number.

7. Enter a name for the speed dial number (see “Entering Characters for Display Entries” on page 2-20).

8. Press the OK soft button to complete the entry and store the name and number.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-59

12135556767 LINE 08 00:00:03 RECORD FLASH ACNR-->

Chapter 2: Using the 24-Button Digital Phone

Two-Way Recording (optional)

Note: It is likely that only certain phones within your phone system have the

rights to the use of this feature.

This feature records the currently active call and saves it as a .wav file to a voice mailbox. The maximum length of a recording equals the maximum length of a voice mail message. The Record button has to be programmed as a Flex button (PGM + 54 -see

WARNING! In many localities, it is illegal to record a phone call without first

notifying the person or persons being recorded. Contact your System Administrator for information about call recording guidelines.

To Record the Current Conversation

While on a call:

1. Notify the person or people with whom you are that you are about to record the call (see Warning above).

2. Press the Record Flex button.

“Programming Flex Buttons” on page 2-30).

speaking

SBX IP 320 Phone User Guide

2-60 Using Phone Features and Functions

STATION 100 (T )

DEC 03 08 02:04 pm [1] RING

[2] COS / SMS SERVICE

[3] AUTH / MOBILE-EXT [4] TIME / CONF-ROOM

[5] MESSAGE [6] ANNOUNCEMENT

[7] SUPPLEMENTARY [*] SYSTEM

Chapter 2: Using the 24-Button Digital Phone

User Programming

There are several additional items which can be programmed for your specific station. Some items can be programmed using the procedure below as well as

page 2-19. However, certain features must be programmed using only

using the menus below.

Hint: Review the Menu map shown in Appendix A for the location

of each feature and its options.

To Access and Navigate In User Programming

From your idle station:

1. Press TRANS/PGM to display the first screen in User Programming.

2. Use the VOLUME down and up buttons to scroll through the various options in the menus.

Hint: Review the Menu

map in Appendix A to find out which menu item to select on each screen.

When you see an item/feature that you want to program:

3. Press the number that corresponds to the number next to the feature name.

Example: To set Ring Type on your phone, press 1.

Repeat steps 2 and 3 to complete the settings you want to make.

Note: Contact your System Administrator if you have any questions

regarding the programming of your station.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-61

CAMP-ON BY STA 105 05 FEB 08 09:51 TRANS CONF MUTE-->

VOICE OVER STA 101 05 FEB 08 09:51 TRANS CONF MUTE-->

Chapter 2: Using the 24-Button Digital Phone

Voice Over

This feature allows you, while on a current call, to simultaneously accept an "announcement" from a station that has camped-on to your extension

“Camp-On” on page 2-38). You can converse with the camped on station

(see without your distant party hearing. You can also toggle between the camped on station and your caller. However, the camped on user and your caller cannot speak to each other.

Example: You have asked a co-worker to find some information that you

need to provide to a current caller. Once your co-worker has found the information he can camp on to your busy station.

At that point, you can accept the Voice Over and speak to your co-worker without your caller hearing. You can then switch back and forth between your co-worker and your caller to gather and deliver information.

To Accept a Voice Over Call

While on a call, you hear the Camp-On tone, and see the Camp-On notification on your display:

1. Press HOLD/SAVE to put your current caller on hold and speak to the camped-on user.

2. Press HOLD/SAVE again to put the camped on user on hold and reconnect to your original caller.

Hint: You can use Hold/Save to toggle back and forth between

these two calls.

SBX IP 320 Phone User Guide

2-62 Using Phone Features and Functions

Chapter 2: Using the 24-Button Digital Phone

Voice Mail

When you have a new voice mail message, your Message Wait Lamp (see

“Message Wait and Callback Indicator Lights” on page 2-10) will be lit.

page

Hint: Also see “Setting Your Password” on page 2-21, and “Recording Your

Station Name (Voice Title)", as well as “Recording Your Station Greeting” on page 2-23.

Listen to Messages

New messages will be played first. Any saved messages can be accessed after the new messages have been played.

At the prompt:

1. Press 1 to play the first new message.

2. Press 2 or the NEXT soft button to play the next message.

Press the REPEAT soft button to play the message again.

Press 3 or the DELETE soft button to delete the current message.

Press 4 to delete all messages.

Press 6 to return to the previous menu.

Use additional mailbox options to:

• ADD, REWIND, or CALLBK (see page 2-63)

• Reply to a Message (see page 2-63)

• Forward a Message (see page 2-63)

(continued on next page)

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-63

Chapter 2: Using the 24-Button Digital Phone

Use Add, Rewind, or CallBack Options

While listening to the current message:

Use on the Nav Button to display another set of options for the current message.Press the ADD soft button if you are replying to a message and want to add a comment first.

NOTE: See "Forward a Message" below.

Press the REWIND soft button to rewind the message by a few seconds.

- Each time you press REWIND, the message will rewind another few

seconds.

Press the CALLBK soft button to immediately dial the station that left the current message.

Reply to a Message

You can reply directly to an email left by another station within your phone system. The reply will be in the form of leaving a reply message in the caller’s mailbox.

While listening to the message (see steps above for listening to messages):

1. Press #5 to dial the station that left the message.

At the prompt:

2. Record your reply.

Forward a Message

You can forward a message to another voice mailbox within the system.

While listening to a message:

1. Press #6 to forward the message.

2. Enter the destination voice mailbox. Hint: If you do not want to add your own comment, when you hear the

prompt "The message has been forwarded", you can hang up or press 2 to listen to the next message.

(continued on next page)

SBX IP 320 Phone User Guide

2-64 Using Phone Features and Functions

Chapter 2: Using the 24-Button Digital Phone

To add your comment to the message

You can add your own comment to the message being forwarded:

Example: "Please respond to the following message that was accidentally

left in my mailbox.").

3. Press the ADD soft button if you want to include a comment along with the message.

At the prompt:

4. Record your comment.

At the prompt:

5. Hang up.

Press 2 to listen to the next message.

Checking Voice Mailbox from Outside the Office

1. Call Main Number.

When you hear the Auto Attendant greeting:

2. Press 7.

At the prompt:

3. Enter your station number.

4. Enter your password, then press #.

5. Follow the prompts to listen to (and manage) your messages.

(continued on next page)

SBX IP 320 Phone User Guide

Using Phone Features and Functions 2-65

Chapter 2: Using the 24-Button Digital Phone

Mailbox Buttons

This feature allows you to assign Flex buttons (see page “Programming Flex Buttons” on page 2-30) as Voice Mail "buttons" to represent other voice mailboxes within your phone system. Y ou can access your own st ation's voice mailbox to check a new or saved message or program mailbox buttons for other mailboxes. You can then use those buttons to check for messages or transfer a caller directly to a mailbox via the use of this button.

Programming a Mailbox Button

1. Press TRANS/PGM, then press the flex button you want to program.

2. Press TRANS/PGM again.

3. Enter 47, then enter the number of the mailbox to be associated with the selected Flex button.

4. Press HOLD/SAVE to save the setting. Repeat the steps above for each mailbox button you want to program.

Using a Mailbox Button

When a new message is left for a mailbox, the mailbox button LED flashes at the rate of 1 flash per 1000 ms.

To Check Messages

When you see a flashing LED next to a mailbox button:

Press the mailbox button next to the flashing LED to access the mailbox.

To Transfer a Caller Directly to a Mailbox

While on a call:

Press the pre-programmed mailbox button to transfer the caller directly to that programmed mailbox.

SBX IP 320 Phone User Guide

THIS PAGE INTENTIONALLY LEFT BLANK.

Chapter 3

Using the 8-Button Digital Phone

This chapter describes the specific features of the SBX 24-Button Digital phones. Included in this chapter:

• Using the Basics - see page 3-2

• Using Features and Functions - see page 3-8

SBX IP 320 Phone User Guide

3-2 Using the Basics

Chapter 3: Using the 8-Button Digital Phone

Using the Basics

This section will provide you with basic information including following:

• What’s on the 8-Button Digital Phone - see below

• Using the Display - see page 3-4

• Making and Answering Outside Calls - page 3-6

What’s on the 8-Button Digital Phone

SBX IP 320 Phone User Guide

Using the Basics 3-3

Chapter 3: Using the 8-Button Digital Phone

Phone Buttons and Features

Feature Used to...

1 Headphone Jack speak to a caller when using a headset instead of

Handset answer or place an internal or external call.

LCD Display display phone status information, dialing directories,

Speaker hear the other party during a call without using the

MSG LED indicate new voice mail messages are waiting.

Pre-Programmed/ Flexible Buttons (8)

TRANS/PGM Button set up a conference call or transfer a call. It is also

SPEED Button access speed dialing, saved number redial, and last

Microphone (MIC) used to speak to a caller when in speaker mode.

VOLUME Button decrease (-) or increase (+) the volume of the speaker

HOLD/SAVE Button put a call on hold or save the current User

SPEAKER Button toggle between speaker (or headset) mode and hand-

Dialpad dial phone numbers and make entries on the display.

holding the handset.

and test message information.

handset or headset (hands-free mode).

access external line calls, pre-assigned features, or user defined feature code assignments.

Note: These include Flex Button 1: DND and Flex

Button 2: CALL BACK.

used to access User Programming features.

number redial. Button is also used to access flexible button programming.

or handset while on a call. This button is also used to scroll up and down in the User Programming menus.

Programming setting.

set mode. You can also use this button to exit any menu screen.

Note: The button is red when speakerphone

is active.

SBX IP 320 Phone User Guide

3-4 Using the Basics

STATION 100 (T)

DEC 03 08 02:04 pm

Station Number or Name

(See page 2-9.)

Current month, day, and year

Current system time

Current H/T/P Mode setting

(see page 2-25)

Chapter 3: Using the 8-Button Digital Phone

Using the Display

Basic information that appears on your display when it is idle is shown below:

Message Waiting and Call Back Indicator Lights

The Message Wait light lets you know that a voice mail message is has been left in your mailbox. The Call Back light indicates whether or not a Call Back request has been placed on your phone (see page diagram shows the location of the Message Wait and Call Back lights, and is followed by a description of each of the lights and how they are used

2-37). The following

(continued on next page)

SBX IP 320 Phone User Guide

Using the Basics 3-5

Chapter 3: Using the 8-Button Digital Phone

A new message for the VMIB or external voice mail is defined as a message in the mailbox which has not yet been played to the subscriber.

A saved message is defined as a message in the mailbox which has been played to the subscriber, but has not been deleted or moved.

A station message wait request is defined as the MWI request left by another intercom station without a voice message, by pressing the Call Back button when ringing a busy or unanswered station.

Fixed, Pre-programmed, & Flex Buttons

This 8-Button phone has Fixed, Pre-programmed (sometimes also known as Feature), and Flex buttons. These buttons are used to access and perform various tasks and functions. Some may be used in conjunction with other buttons.

• Fixed buttons are those that are permanently labeled on the phone hardware. Such buttons might include SPEAKER, TRANS, HOLD, VOLUME, etc.

• Pre-programmed buttons are those buttons that are pre-programmed by your System Administrator. Their names/functions will be on a more temporary-type template that can be replaced if/when the buttons are reprogrammed, etc.

SBX IP 320 Phone User Guide

3-6 Using the Basics

Chapter 3: Using the 8-Button Digital Phone

Making and Answering Calls

• Internal calls are also known as Intercom calls. These are call s tha t originate or that you make to another station within your phone system.

• External calls are those that originate from or that you make to a source outside your company’s phone system (for example, customers, vendors, etc.).

Making Calls

Dial an Internal Call

1. Lift the handset.

Press SPEAKER*.

Begin dialing from the dialpad.

2. Dial the station number.

Dial an External Call

The following procedure provides the steps to manually dial a call. However, you can also use this method using a speed dial number (see on page 2-56 for details).

1. Lift the handset.

Press SPEAKER*.

Go to Step 2 below.

2. Dial the access code to get to an outside line. NOTE: Outside line (CO) access codes "9" or "88XX". Contact your

System Administrator if you are unsure about what your company access code is.

3. Dial the phone number.

“Speed Dialing”

(continued on next page)

SBX IP 320 Phone User Guide

Using the Basics 3-7

Chapter 3: Using the 8-Button Digital Phone

Answering Calls

Aside from using the handset or speakerphone (when available), the operation of the digital phones is quite basic.

Answer an Internal (Intercom) Call

Lift the handset.

Press SPEAKER*.

Answering an External Call

1. Lift the handset or press SPEAKER*.

2. Press the flashing green line (Flex) button.

Using the Speaker

• For details about using the speaker, see page 2-13.

Using the Hold Feature

• For Details about putting calls on hold, see page 2-17.

Transferring Calls

• For Details about transferring calls, see page 2-18.

SBX IP 320 Phone User Guide

3-8 Customizing Your Phone

Chapter 3: Using the 8-Button Digital Phone

Customizing Your Phone

The following provides details about customizing your phone. This includes: Recording Your Station Name (Voice Title) - see below

Setting/Changing Your Station Password

IMPORTANT: Contact your System Administrator to find out if there is a

password currently set for your phone. You will need to use that password in order to change or re-set it.

1. Press TRANS/PGM.

2. Press 3.

3. Press 2.

4. Enter the current password. Hint: If this is the first time a password is being set up for this mailbox,

the default password is your 3-digit extension number. If this default does not work, contact your System Administrator for assistance.

5. Press #.

6. Enter the new password (up to 4 digits).

7. Press HOLD/SAVE to store the new setting.

Recording Your Station Name (Voice Title)

1. Lift the handset.

2. Press TRANS/PGM.

3. Press 6.

4. Press 6, then #.

At the prompt/tone:

5. Record your name.

6. Press HOLD/SAVE to complete and save the recording.

SBX IP 320 Phone User Guide

Customizing Your Phone 3-9

Chapter 3: Using the 8-Button Digital Phone

Record Your Station Greeting

You can record the greeting that your callers will here if they reach your voice mail because your phone is busy or because you are away.

Note: This feature applies to in-skin voice mail (VMIB) systems only.

Contact your System Administrator for more information.

1. Press TRANS/PGM.

2. Enter 61.

3. Enter your station number. NOTE: If a greeting already exists, it will be played.

4. Press #.

At the prompt:

5. Begin recording your greeting .

6. Press HOLD/SAVE or SPEAKER to end and save the recording.

- A confirmation tone sounds.

SBX IP 320 Phone User Guide

3-10 Using Phone Features and Functions

Chapter 3: Using the 8-Button Digital Phone

Using Phone Features and Functions

Call Wait (Camp-On)

Camp-On allows you to set your phone to automatically call back a station that is busy.

After receiving station busy tone:

1. Press 6.

- A Camp-on tone sounds.

When the other extension becomes "un-busy", your phone will ring:

2. Pick up the handset, or press SPEAKER.

- You will hear the other extension ringing and can continue the call.

Flexible Button Programming

Use the procedure and Numbering Plan code shown in the section “Programming Flex Buttons” on page 2-30.

Mailbox Buttons

In the idle state on any digital or IP phone (including Soft Phone), all pre-programmed flex buttons assigned as mailbox buttons will flash red when there is an un-played (new) message in the assigned mailbox.

Note: See “Checking Voice Mailbox from Outside the Office” on page 2-64

for more information about Mailbox Buttons and Voice Mail.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 3-11

Chapter 3: Using the 8-Button Digital Phone

PickUp

Extension

You can pick up a call ringing on a specific extension in your area.

To Pick Up an Incoming Call on a Specific Extension:

1. Lift your handset or press SPEAKER.

2. Press 7.

3. Enter the extension number of the ringing station to be automatically connected to the caller.

Group

You can pick up a call on any extension within your call PickUp group. Note: You must be part of a PickUp Group in order to pick up calls to that

group. Contact your System Administrator to find out if you are a member of a PickUp Group, and if so, which group.

To Pick Up a Call to Your Group

When a station within your group is ringing:

1. Lift your handset or press SPEAKER.

2. Dial 566 to automatically connect to the caller.

Redial (Last Number)

The last number dialed on an external call is automatically saved by the phone as Last Number Redial.

To Dial the Last Number Dialed

1. Lift the handset or press SPEAKER.

AND/OR

2. Enter 552.

Press SPEED, then press 6.

3. Press the HOLD/SAVE.

SBX IP 320 Phone User Guide

3-12 Using Phone Features and Functions

Chapter 3: Using the 8-Button Digital Phone

Speed Dial Numbers

Note: Speed Dial Numbers are also known as Speed Bins, and may be

designated as follows:

• Station Speed Bins: 000 to 099

• System Speed Bins: 2000 to 2499

Using Speed Dial Numbers

From an idle phone:

1. Press SPEED.

2. Enter the speed dial bin number assigned to the destination you want to call.

- Your call will be dialed.

Programming Station Speed Dial Numbers/Bins

From an idle phone:

1. Press the TRANS/PGM, then SPEED.

2. Enter the appropriate speed bin number (range = 000-099).

3. Enter number you wish to associate with this Speed Dial Number (that is the destination phone number).

4. Press HOLD/SAVE to store the number.

5. Enter the name associated to the number (see “Entering Characters for Display Entries” on page 2-20)

6. Press HOLD/SAVE to store the name with the destination number.

- A confirmation tone will sound.

SBX IP 320 Phone User Guide

Using Phone Features and Functions 3-13

STATION 100 (T ) DEC 03 08 02:04 pm

[1] RING [2] COS / SMS SERVICE

[3] AUTH / MOBILE-EXT [4] TIME / CONF-ROOM

[5] MESSAGE [6] ANNOUNCEMENT

[7] SUPPLEMENTARY [*] SYSTEM

Chapter 3: Using the 8-Button Digital Phone

User Programming

There are several items which can be programmed for your specific station. Review the Menu map shown in Appendix A for the location of each feature and its options.

To Access and Navigate In User Programming

From your idle station:

1. Press TRANS/PGM to display the first screen in User Programming.

2. Use the VOLUME down and up buttons to scroll through the various options in the menus.

Hint: Review the Menu

Map in Appendix A to find out which menu item to select on each screen.

When you see an item/feature that you want to program:

3. Press the number that corresponds to the number next to the feature name.

Example: To set Ring Type on your phone, press 1.

Repeat steps 2 and 3 to complete the settings you want to make.

Note: Contact your System Administrator if you have any questions

regarding the programming of your station.

SBX IP 320 Phone User Guide

3-14 Using Phone Features and Functions

Chapter 3: Using the 8-Button Digital Phone

Voice Mail

When you have a new voice mail message, your Message Wait Lamp (see

“Message Waiting and Call Back Indicator Lights” on page 3-4) will be lit.

page

Hint: Also see “Customizing Your Phone” on page 3-8 for information about

setting/changing your password, as well as recording a voice title and voice mail greeting.

Checking Your Voice Mailbox when You Are in the Office

If your CALL BACK button LED is flashing:

1. Press CALL BACK.

At the prompt:

2. Enter your password.

3. Press # to play the first message.

4. Follow the prompts to manage your messages.

Checking Voice Mailbox from Outside the Office

1. Call the main company phone number.

When you hear the Auto Attendant greeting:

2. Press 7.

At the prompt:

3. Enter your station number.

4. Enter your password, then press #.

5. Follow the prompts to listen to (and manage) your messages.

Recording a Message in another User’s Voice Mailbox

1. Dial another station.

While the phone is ringing:

2. Press CALL BACK.

At the tone:

3. Record your message.

SBX IP 320 Phone User Guide

Chapter 4

Using a Single Line Telephone (SLT)

This chapter describes the features available on a Single Line T elephone (SLT) when used on the SBX phone system. Included in this chapter:

• Using the Basics - see page 4-2

• Customizing Your Phone - see page 4-4

• Using Features and Functions - see page 4-8

SBX IP 320 Phone User Guide

4-2 Using the Basics

Chapter 4: Using a Single Line Telephone (SLT)

Using the Basics

The following procedures provide you with the basic information you need to make, answer, and transfer calls, as well as put calls on hold. You’ll also find out how to use the Message Wait feature.

Note: It is recommended that you also review the manufacturer’s user guide

Making and Answering Calls

• Internal calls are also known as Intercom calls. These are call s tha t

• External calls are those that originate from or that you make to a source

Make an Internal (Intercom) Call

Make an External Call

that was provided with your telephone. In addition, you may want to consult your System Administrator for any specific details regarding how your phone works with the SBX phone system.

originate or that you make to another station within your phone system. outside your company’s phone system (for example, customers,

vendors, etc.).

1. Lift the handset.

2. Dial the intercom number.

1. Lift the handset.

2. Dial 9 to access a CO line. Note: In the following countries, dial 0 to access a CO line: Finland,

Brazil, Norway, Netherlands, Belgium, Denmark, Spain, and Italy).

3. Dial the number you want to call.

Making Calls Using CO Access

Contact your System Administrator for more information regarding CO Group and Individual Access calls.

External Calls via CO (Outside Line) Group Access

1. Lift the handset.

2. Dial 8 and a CO group number (01-24).

3. Dial the number you want to call.

External Calls via CO Individual Access

1. Lift the handset.

2. Dial 88 and a CO line number (01-12).

3. Dial the number you want to call.

SBX IP 320 Phone User Guide

Using the Basics 4-3

Chapter 4: Using a Single Line Telephone (SLT)

Using Hold

Place an External Call on Hold

While connected to an external call:

1. Press the hook-switch.

2. Dial 560.

Retrieve a Held Outside Call

1. Lift handset.

2. Dial 8 # and CO line number (01-12).

If you don’t remember the held CO number:

Dial 86.

Transferring Calls

You can perform both screened and unscreened transfer s, as well as direct transfer to a voice mailbox:

• Screened Transfers: Allows you to announce a call to the destination station before completing the transfer.

• Unscreened Transfer: Allows you to complete a transfer without announcing the party to the destination station.

To Transfer a Call

While on a call:

1. Press the hook-switch.

2. Dial the destination target (station or hunt group) to which you want to transfer the call.

Make a Screened Transfer

3. Wait for the destination target to answer.

4. Tell the destination target who is calling, then hang up to complete the transfer.

Note: If the destination station/hunt group is busy or the user does not

want to accept the call, press the

Trans/PGM to reconnect to the caller.

Make an Unscreened Transfer

5. Wait for the destination target to ring, then hang up before it is answered to complete the transfer.

TRANS soft button or

SBX IP 320 Phone User Guide

4-4 Customizing Your Phone

Chapter 4: Using a Single Line Telephone (SLT)

Message Waiting

1. Lift the handset.

2. Dial the target extension number.

3. Press the hook-switch.

4. Dial 556.

5. Hang up.

Customizing Your Phone

Programming Your Station Name

You can designate a "name" for your station. This name will appear on your display, as well as the display of any other st ation in your system that you call or that calls you.

1. Lift the handset.

2. Enter 563, then 74.

3. Enter your name using the table shown on “Entering Characters for Display Entries” on page 2-20).

4. Press the hook-switch.

When you hear the (confirmation) tone:

5. Hang up.

Recording Voice Announcements

Date & Time Prompt

1. Lift the handset.

2. Dial 563.

After the confirmation tone sounds:

3. Enter 62.

- The date & time prompt plays (e.g., "Date is March, 20th and

Time is 00:00.")

SBX IP 320 Phone User Guide

(continued on next page)

Vertical SBX IP 320 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

REVISION HISTORY

Contents

How To Use This Guide

SBX Phone Features

Specific Phone Model Information and Features

If You are Using a Digital Phone

If You are Using a Single Line Phone

Feature Index

Getting Help

Your System Administrator

Vertical Technical Support

Connecting Your Phone

Connecting a Digital Phone

Connecting Your Single Line (SLT) Phone

911 Feature

Using the Basics

What’s on the 24-Button Digital Phone

Phone Buttons and Features

Using the Display

Soft Buttons

Nav Button

Station Programming Menu Overview

Message Wait and Callback Indicator Lights

Messages

Fixed, Pre-programmed, & Flex Buttons

Making and Answering Calls

Making Calls

Answering Calls

Using the Speaker

Using the Headset (vs. Speaker) Mode

Using a Headset with a 2.5 mm Headset Jack (Ear/Mic)

Using the Hold Feature

Transferring Calls

Transfer a Call from Your Station to another Station

Transfer a Call Directly to Voice Mail

Customizing Your Phone

Station Name Programming

Entering Characters for Display Entries

Setting Your Password

Registering (Creating) Your Password

Changing Your Password

Recording Your Station Name (Voice Title)

Recording Your Station Greeting

Setting Ring Types

Setting the HTP Mode

Using Pre-Selected Display Messages

Setting a Pre-Selected Message

Creating a Custom Message

Programming Flex Buttons

Using Phone Features and Functions

Alarm (Wake Up Program)

Automatic Called Number Redial

Call Log

Using the Received or Dialed Call List

Using the Lost Call List

Callback

Camp-On

Conference

Do Not Disturb (DND)

Flash

Forward Calls

Overview of Forwarding Calls

Selecting a Forward Type

Cancel Forward Setting

HotDesk

Leave a Message (MSG)

Monitor and/or Join a Conversation (Barge-In)

Mute

Paging

Sending a Page

Respond to a Meet-me Page

Parking

System Park

Park and Page

Phone Book/Dial by Name

Using the Phonebook for Dialing
