Vermont Casting SR42, SR36, SC42, SC36 User Manual

Download

For use in U.S./Canada Underwriter's Laboratories Report No. MH6018

Majestic Fireplaces® SR/SC Series

™

234567890123456789012

For Models:

SR36 SR42 SC36 SC42

SR/SC Series

Woodburning Fireplace

Homeowner's Installation and Operating Manual

DO NOT DISCARD THIS MANUAL: Retain for future use.

7412948 4/02 Rev. 7

Majestic Fireplaces® SR/SC Series

Safety Information

PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING FIREPLACE. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to

follow these instructions may result in a possible fire hazard and will void the warranty.

Description

The SR/SC Series fireplaces are solid fuel, woodburning premium fireplaces. The SR36/42 are radiant clean-face models and the SC36/42 are circulating models with removable grilles (louvers). Both models

are fully insulated fireplaces.

Precautions

Vermont Castings, Majestic Products fireplaces and component parts have been highly tested and will operate safely when installed in accordance with instructions provided in this manual. Carefully read and understand all instructions before beginning installation.

If you notice any damage to fireplace or component parts, immediately report damage to your Vermont Castings, Majestic Products dealer.

Only use Vermont Castings, Majestic Products components or the warranty will be voided and a fire hazard may be created.

Vermont Castings, Majestic Products warranty will be voided by and Vermont Castings, Majestic Products disclaims any responsibility for the following actions:

• Installation of any damaged fireplace or chimney component;

• Modification of fireplace, chimney assembly or any component parts thereof; (except for

chase flashings as detailed in Vermont Castings, Majestic Products Chimney Top installation instructions).

• Installation other than as instructed by Vermont Castings, Majestic Products; or

• Installation and/or use of any component part not manufactured or approved by Vermont Castings, Majestic Products in combination or assembly with a Vermont Castings, Majestic Products fireplace system, notwithstanding any independent testing laboratory or other third party approval of such component parts or accessory.

Any such action may possibly cause a fire hazard.

Consult local building codes to ensure that you are in compliance before installing the fireplace.

Fireplaces must be vented to the out-of-doors.

Do not obstruct or modify air inlets/outlets in any manner.

Do not install combustible materials on any of the black fireplace surround.

Burn only solid wood fuel or gas logs. Do not install a solid fuel burning insert or other

products not specified for use with this fireplace. These fireplaces are not approved for installation

in mobile homes.

Drafts

The fireplace should not be located in areas that create drafts (ie: frequently opened doors and central heating air inlets/outlets) that hamper the normal flow of air into the fire.

Gas Logs

If you plan to install a gas log, the gas line should be installed before framing the fireplace. The gas line

must be installed by a certified gas line installer.

SR36 / SR42 SC36 / SC42

Listed

UL / ULc127

Standard for Factory Built Fireplaces

Table Of Contents

Safety Information . . . . . . . . . . . . . . . . . . 2

Specifications and Framing. . . . . . . . . . . 3

Parts Identification. . . . . . . . . . . . . . . . . . 5

Chimney Requirements. . . . . . . . . . . . . . 6

Planning Information . . . . . . . . . . . . . . . . 7

Installation . . . . . . . . . . . . . . . . . . . . . . . . 8

Replacement Parts . . . . . . . . . . . . . . . . 19

Accessories. . . . . . . . . . . . . . . . . . . . . . 20

Majestic Fireplaces® SR/SC Series

36"

(914mm)

14⁵⁄₈"

(372mm)

15 ³⁄₈"

(391mm)

9¹⁄₂"

(241mm)

40"

(1016mm)

36⁵⁄₈"

(930mm)

(76mm)

⁵⁄₈"

(16mm)

⁵⁄₈" (16mm)

48¹⁄₂" (1232mm)

¹⁄₂" (13mm)

¹⁄₂"

68¹⁄₂" (1740mm)

8¹⁄₄"

(210mm)

22"

(559mm)

22¹⁄₂"

(572mm)

22" (559mm)

19 ³⁄₄"

(502mm)

21"

(533mm)

40³⁄₄"

(1035mm)

(203mm)

7³⁄₄"

(197mm)

7¹⁄₂"

(191mm)

7¹⁄₂"

(191mm)

Outside Air

Gas Line Access

Electrical Access

Recessed Nailing Flange

11" DIA.

Rough Opening Width 41"

Rough Opening Height

Rough Opening Depth

34¹⁄₂" (876mm)

(1041mm)

⁵⁄₈" (16mm)

¹⁄₂" (13mm)

¹⁄₂"

36"

(914mm)

35¹⁄₄"

(895mm)

40" (1016mm)

⁵⁄₈"

(16mm)

19 ³⁄₄"

(502mm)

1³⁄₄"

(45mm)

35¹⁄₂" (902mm)

21"

(533mm)

7³⁄₄"

(197mm)

7¹⁄₂"

(191mm)

Recessed Nailing Flange

11" DIA.

Rough Opening Width 41"

Rough Opening Height

Rough Opening Depth

Gas Line Access

48¹⁄₂" (1232mm)

34¹⁄₂

" (876mm)

¹⁄₂" (1740mm)

8¹⁄₄"

(210mm)

22"

(559mm)

22¹⁄₂"

(572mm)

22" (559mm)

40³⁄₄"

(1035mm)

14⁵⁄₈"

(372mm)

15 ³⁄₈"

(391mm)

9¹⁄₂"

(241mm)

36⁵⁄₈"

(930mm)

(76mm)

(203mm)

7¹⁄₂"

(191mm)

Outside Air

Gas Line Access

(1041mm)

Electrical Access

SR36 Series Woodburning Fireplace

Fig. 1 SR36 Series specifications and framing.

SC36 Series Woodburning Fireplace — Circulating Model

Fig. 2 SC36 Series specifications and framing.

FP589

FP590

Majestic Fireplaces® SR/SC Series

SR42 Series Woodburning Fireplace

Rough Opening Depth

(572mm)

22¹⁄₂"

(559mm)

(210mm)

22"

Rough Opening Height

(1035mm)

7¹⁄₂"

(191mm)

14⁵⁄₈"

(372mm)

¹⁄₂"

50" (1270mm)

¹⁄₂" (13mm)

36" (914mm)

70¹⁄₂" (1791mm)

36⁵⁄₈"

(930mm)

Outside Air

Gas Line Access

⁵⁄₈" (16mm)

9¹⁄₂"

(241mm)

8¹⁄₄"

40³⁄₄"

26¹⁄₄"

(667mm)

Rough Opening Width 47"

(1067mm)

(1194mm)

42"

11" DIA.

(191mm)

19³⁄₄"

(502mm)

(533mm)

(197mm)

(16mm)

7¹⁄₂"

21"

7³⁄₄"

Recessed

⁵⁄₈"

Nailing Flange

Gas Line Access

(203mm)

15⁵⁄₈"

(397mm)

Fig. 3 SR42 Series specifications and framing.

SC42 Series Woodburning Fireplace — Circulating Model

Rough

50" (1270mm)

¹⁄₂" (13mm)

36" (914mm)

50" (1270mm)

¹⁄₂"

Outside Air

Gas Line Access

⁵⁄₈" (16mm)

" (1791mm)

70¹⁄₂

36⁵⁄₈"

(930mm)

9¹⁄₂"

(241mm)

(203mm)

Fig. 4 SC42 Series specifications and framing.

Opening Depth

22¹⁄₂"

(572mm)

15³⁄₈"

(397mm)

(76mm)

Electrical Access

(210mm)

22"

(559mm)

Rough Opening Height

(1035mm)

7¹⁄₂"

(191mm)

14⁵⁄₈"

(372mm)

(76mm)

Electrical Access

8¹⁄₄"

40³⁄₄"

46"

(1168mm)

26¹⁄₄"(667mm)

Rough Opening Width 47"

(1067mm)

38" (965mm) 46" (1168mm)

(1194mm)

42"

11" DIA.

35¹⁄₄"

(895mm)

19³⁄₄"

(502mm)

1³⁄₄"

⁵⁄₈"

(16mm)

7¹⁄ ₂"

(191mm)

21"

(533mm)

7³⁄₄"

(197mm)

FP591

Recessed Nailing Flange

Gas Line Access

FP592

Chase Installation

Insulation methods shown are optional for cold climate, not a requirement for unit operation.

BATT INSULATION (cut out around firestop)

Majestic Fireplaces® SR/SC Series

TERMINATION CAP

STORM COLLAR PAN FLASHING

FIRESTOP

CEILING LEVEL

NAILING FLANGE

GAS LINE ACCESS (both sides)

ELECTRICAL ACCESS

OUTSIDE AIR COVER PLATE

DRAFTSTOP

STANDOFF SURROUND DAMPER CONTROL

GAS LINE KNOCKOUT (both sides)

SCREEN GRATE

FIREBOX

METAL SAFETY STRIPS (1, 2 or 3 pieces)

Fig. 5 Fireplace and chase parts identification.

FP554

Majestic Fireplaces® SR/SC Series

Chimney Requirements - Offset Installations

CHIMNEY FLUE EXIT

CHIMNEY SECTION

ELBOW

RISE

OFFSET

ELBOW

6 FT.

RETURN

ELBOW

OFFSET

HEARTH FLOOR

Example 1 Example 2 Example 3

Notes: G + H cannot exceed 20 feet.

Air Space Clearances: SK8 (2-wall) = 1¹⁄₂" and "S" Series (3-wall) = 2"

OFFSET

ELBOW

Illustration Key

The following safety rules apply to offset installations (letters correspond with illustration above):

A. Height of the chimney is measured from the hearth to the chimney exit.

SR/SC36 SR/SC42 Maximum: 90' 90' Minimum:

Without Elbows 12' 6" 12' 6" With 2 Elbows* 14' 6" 14' 6" With 4 Elbows* 21' 0" 21' 0"

B. Do not use more than 4 elbows per chimney .

Attach the straps of the return (top) elbow to a structural framing member.

The offset (first) elbow of any pair does not have straps.

* In Canada, two (2) SK845 are allowed.

C. The chimney cannot be more than 30˚ (45˚ in Canada) from the vertical plane in any installation*.

D. The maximum length of the angled run of the total chimney system is 20 feet. (G plus H cannot exceed 20 feet.)

E. A chimney support (Model SKCS8) is required every 6 feet of angled run of chimney . Chimney supports are required for every 30 feet and 60 feet (SK8 pipe) or 20 feet and 40 feet (3-wall pipe) of vertical chimney height above the hearth.

Determine the offset distance of your chimney arrangement from the centerline of the fireplace to the centerline of the chimney where it is to pass through the first ceiling.

Note: This offset distance may not be your full offset distance. See Examples 2 and 3.

30˚

RETURN

ELBOW

30˚

SKCS8 SUPPORT

IWF269

OFFSET

RISE

IWF282

30˚ Elbow Offsets

1¹⁄₂'

3' 4'

0000 0 3" 11" 1000 0 8¹⁄₄" 20" 0100 0 11¹⁄₄"25¹⁄₄" 2000 0 13¹⁄₂"29¹⁄₄" 1100 0 16¹⁄₂"34¹⁄₄" 0010 0 20¹⁄₄"40³⁄₄" 2100 0 21³⁄₄"43¹⁄₂" 0001 0 26¹⁄₄"51¹⁄₄" 0110 0 28¹⁄₂"55¹⁄₄" 1001 0 31¹⁄₂"60¹⁄₄” 0101 0 34¹⁄₂"65¹⁄₂" 0020 0 37¹⁄₂"70³⁄₄" 1101 1 41¹⁄₂"77³⁄₄" 0011 1 45" 83³⁄₄" 0120 1 47¹⁄₄"87¹⁄₂" 0002 1 51" 94" 0111 1 53¹⁄₄" 98" 0030 1 56¹⁄₄" 103¹⁄₄" 0102 1 59¹⁄₄" 108¹⁄₂" 0021 1 62¹⁄₄" 113¹⁄₂" 0130 1 64¹⁄₂" 117¹⁄₂" 0012 1 68¹⁄₄" 124" 0121 1 70¹⁄₂" 128" 0003 1 74¹⁄₄" 134¹⁄₂" 01122 78"140³⁄₄" 00312 81" 146" 01032 84"151¹⁄₄" 00222 87"156¹⁄₂" 01312 89¹⁄₄" 160¹⁄₄" 00132 93"166³⁄₄" 01222 95¹⁄₄" 170³⁄₄" 00042 99¹⁄₄" 177³⁄₄" 01132101¹⁄₄" 181³⁄₄" 00322104¹⁄₄" 186¹⁄₄" 01042107¹⁄₄" 191¹⁄₂" 00232110¹⁄₄" 196³⁄₄" 01323 114" 203¹⁄₄" 00143117³⁄₄" 209³⁄₄" 01233 120" 213¹⁄₂" 00053123³⁄₄" 220"

Offset

Chimney

Support

Rise

Fig. 6 Chimney system requirements.

Majestic Fireplaces® SR/SC Series

Planning Information

Preplanning an installation is very important to ensure safety and to save time and money. An installer must predetermine where a fireplace will be set and how the

chimney system will be run.

Mounting The Fireplace

A fireplace may only be mounted on the following surfaces:

1. A flat combustible surface.

2. A raised wooden platform.

3. A concrete block or other solid object placed beneath each of the four (4) corners of the fireplace.

The fireplace must be spaced 1/2 inch from a combustible back wall and 1/2 inch from a combustible

side wall or support. (Fig. 20, Page 14)

Planning The Chimney Run

MODEL SK

2 WALL CHIMNEY

Fig. 7 Installed lengths of chimney sections.

SK81 SK818 SK83 SK84

TOTAL

LENGTH

(LT)

11¹⁄₂ 17¹⁄₂ 35¹⁄₂ 47¹⁄₂

Determine how the chimney will be run, length of run and chimney components required to complete the job. (Fig. 6) Never install a chimney below minimum heights.

In planning a chimney system, it is important to know:

1. The height of a chimney is measured from the hearth to the exit point on the termination.

2. A chimney cannot be offset more than 30 degrees from a vertical plane.

3. A chimney may run straight up or it may be necessary to offset it to avoid obstructions.

4. The maximum length of an angled run (total chimney system) is 20 feet.

" " " "

INSTALLED

LENGTH

(L1)

10¹⁄₂

16¹⁄₂

34¹⁄₂

46¹⁄₂

WF288

5. No more than 2 offsets (4 total 30˚ elbows in U.S./or 2 total 45˚ elbows in Canada) per fireplace may be used.

6. A guy wire stabilizer is required for chimneys extending more than 6 feet above a roof line.

The Ten Foot Rule

Major U.S. building codes specify a minimum chimney height above the roof top. The “Ten Foot Rule” is a fire safety rule and not a draft rule. To ensure proper draft, it is recommended that you always meet or exceed the “Ten Foot Rule,” especially when installing a termination on a high pitch roof. (Fig. 8)

The key points of the "Ten Foot Rule" are:

1. If the horizontal distance from the center of the chimney to the peak of the roof is 10 feet or less, the top of the chimney must be at least 2 feet above the peak of the roof, but never less than 3 feet in height above the highest point where it passes through the roof.

2. If a horizontal distance from the center of the chimney to the peak of the roof is more than 10 feet, a chimney height reference point is established that is on the surface of the roof a distance of 10 feet from the center of the chimney in a horizontal plane. The top of the chimney must be at least 2 feet above the reference point, but never less than 3 feet in height above the highest point where it passes

through the roof.

0 TO 10'

2' MIN.

MIN.

REFERENCE POINT

Fig. 8 Ten Foot Rule illustration.

0 TO 10'

2' MIN.

MIN.

AC246

Majestic Fireplaces® SR/SC Series

Chimney Supports

The chimney system is supported by the fireplace for vertical chimney heights less than 30 feet above the hearth. Chimney supports are required if the vertical height exceeds 30 feet with SK8 chimneys or 20 feet with 3-wall chimneys. Locate chimney supports at ceiling holes or other structural framing at 30 foot (SK8) or 20 foot (3-wall) heights. Spacing between chimney supports must not exceed 30 feet(SK8) or 20 foot (3-wall). Use Chimney Support Model SKCS8.

(Note: the SKCS8 can not be mounted directly to the fireplace.) Support provided by elbow straps

fulfills the support requirement only if they are spaced as previously described. (A chimney support is 2¹⁄₂" long when installed.)

Angled chimney runs require a support every six (6) feet in addition to the elbow straps. Chimney supports

are used for this function. (Fig. 9)

Chase Installation

A chase is a vertical box-like structure which encloses the fireplace and/or chimney. Chases are typically built on the outside of the house with fireplace opening cut into the outer wall of a room. (Fig. 5, Page 5)

If you need help in determining fireplace location or how the chimney system should be run, contact your Vermont Castings, Majestic Products dealer for

assistance.

CHIMNEY SUPPORT STRAP

SKCS8

Installation

■ 1. Insulating Fireplace Enclosure

For Cold Climates

If you live in a cold climate, it is not required but highly recommended that you insulate fireplace enclosure to eliminate cold air penetration as much as possible.

Insulate base of fireplace with a non-combustible insulation rated for a minimum of 300 degrees F. Insulating is very important for outside wall installations over a concrete slab. If fireplace is installed on a platform, insulation should be placed on top of the platform before fireplace is set. (Fig. 10)

When a fireplace is installed in a chase or on a outside wall, enclosure should be treated like any outside wall in a home. Insulation should be installed on the inside wall as well as the outside wall(s). In a chase, it is also a good idea to install a firestop at the first ceiling level above the fireplace and enclose the chase with sheeting material. Insulation may then be installed above sheeting material to assure the space around the fireplace is totally protected. (Fig. 5)

When installing the chimney , DO NOT caulk between outer pipe and firestop. It is vital that some air be allowed to flow through this very thin gap.

CAUTION: WHEN INSTALLING A FIREPLACE IN AN INSULATED ENCLOSURE, BE SURE ALL REQUIRED AIR SPACES ARE MAINTAINED. (Fig. 20, Page 14)

Fig. 9 Chimney support installation

FP284

Majestic Fireplaces® SR/SC Series

■ 2. Framing

Framing can be constructed before or after the fireplace is set in place, however, most installers build the frame before setting the fireplace.

Frame fireplace with 2 X 4 lumber or heavier materials. Refer to framing dimensions in Figures 1, 2, 3 or 4 for basic fireplace specifications.

Note: Framing should be positioned to accommodate wall covering and fireplace facing material.

■ 3. Installing Electrical Wire

(for Circulator Models)

If a circulating fireplace is to be installed, run the 120 VAC, 60 Hz wiring to the left side of installation. Wiring must be completed before the fireplace is secured and finish material applied.

Remove the cover plate and electrical knock-out on the lower left side of the fireplace and set aside. Follow the instructions on Page 10 for proper wiring and installation of the EB1.

If the fan kit is not being installed with the fireplace, it is highly recommended that 120 VAC supply be made available since someone may elect to install a blower

at a later date.

Option For Circulating Models Only —

EB1 (Receptacle) Hook-Up

• Wiring should be installed by a certified electrician.

• Turn off circuit breaker before wiring models. Once fireplace is secured, complete wiring the fan

kit. Remove knockout in the center of the back of the EB1 and install listed cable clamps. Feed electrical wire through listed cable clamp leaving approximately six (6) inches of wire exposed through the EB1. Secure listed cable clamp to the wire.

Attach white wire from power source to one (1) wire of receptacle and secure with nut. Attach black wire from power source to the other wire of receptacle and secure with nut.Be sure nuts are secured tightly.

Secure EB1 assembly to inside of electrical box coverplate using two screws. Attach cover to face of the EB1 while being careful to position excess wire completely within the EB1, then attach

coverplate to fireplace.

Install Fan Kit Assembly

HARD FLAT SURFACE

INSULATION

PLATFORM

Fig. 10 Insulating between platform and fireplace.

FP555

Refer to optional Model FK12 fan kit assembly installation instructions for field installation.

■ 4. Chimney Set-up

Since you have already preplanned the chimney run, you should know exactly how the installation is to be accomplished — how much pipe is required, the number of elbows, if any, and type of termination to be used.

CAUTION: REPORT TO YOUR DEALERS ANY PARTS DAMAGED IN SHIPMENT , SPECIFICALLY CHECK THE END CONNECTION OF CHIMNEY SECTIONS AND ELBOWS.

Note: Fireplaces may use Vermont Castings, Majestic Products model SK8, or Model S (three wall) chimney systems. The SR/SC Series Fireplace will accept the SK8 chimney system as is; but a TWABR adapter collar is required when using the Model S (triple wall) chimney system. The installation procedure described in this manual applies only to the SK8 system. Either chimney system may be used, but may not be mixed.

Majestic Fireplaces® SR/SC Series

Straight-Up Chimney Installation

To mark the centerline of the flue, put the fireplace in final position and measure out from the wall: 9¹⁄₄ inches. Mark a spot on the ceiling directly above the fireplace. Draw a line parallel to the back wall through this mark. (Fig. 11)

Using a plumb bob positioned directly over center point of fireplace flue collar, mark the ceiling to estab-

lish the chimney center point. (Fig. 11)

Offset Installation

In order to clear an obstruction, it may be necessary to offset chimney from vertical. This is accomplished by using Majestic elbows. Use the on Page 6 to determine proper offset and parts required.

CHIMNEY CENTERLINE

ACTUAL CENTERPOINT

30˚ Offset Elbow

9¹⁄₄"

table

Each offset requires two (2) elbows. The second elbow is equipped with support straps. It is very important to install the second elbow in each offset as close to the ceiling or support as possible so that the elbow straps can be secured to framing members to help support the weight of the chimney.

Determine offset distance of your chimney arrangement from centerline of fireplace to centerline of chimney where it is to pass through ceiling.

Locate center point of the chimney on ceiling as though a straight up chimney arrangement is to be used. Measure your offset dimension from straight up

chimney center point on ceiling.

Ceiling Chimney Hole/ Possible Obstructions

The size of the hole in ceiling will vary with the angle at which the chimney passes through ceiling.

Drive a nail up through ceiling at marked chimney center point. Go to floor above and see where hole will be cut. Check to see where existing ceiling joists and other possible obstructions are located...i.e. wiring, plumbing etc... If necessary, re-position chim-

ney and/or fireplace to avoid obstructions.

PLUMB LINE

PLUMB BOB IMAGINARY

CENTERPOINT

Fig. 11 Locate centerline of chimney with plumb line.

FP556

Cutting the Hole

Cover fireplace collar opening and cut proper sized chimney hole in chimney. The SK8 pipe allows you to run pipe through a typical 16” on center joist without

cutting joists.

Framing the Ceiling Hole

Frame the ceiling chimney hole as shown in Figure 12. It is good practice to use framing lumber that is the same size as the ceiling joists; this is a requirement at attic level.

EXISTING CEILING JOISTS

CEILING

CHIMNEY HOLE

NEW FRAMING MEMBERS

FP551

Fig. 12 Typical frame for ceiling chimney hole.

Majestic Fireplaces® SR/SC Series

NAIL TOP STANDOFFS

NAIL SIDE-NAILING FLANGES

The following table gives firestop spacer model numbers:

CHIMNEY HOLE SIZE

Angle of Chimney at Ceiling

Size of Chimney

8" Flue

"SK" Series

8" Flue

"S" Series 3-Wall

Fig. 13 Ceiling chimney hole sizes necessary for installing firestop spacer.

Vertical

SKFS2A

14¹⁄₂" x 14¹⁄₂"

FS2A

17¹⁄₂" x 17¹⁄₂"

30˚

SKFS6A

14¹⁄₂" x 25¹⁄₂"

FS6A

17⁷⁄₈" x 29⁵⁄₈"

FP 548

The inside dimension of the frame must be the same as the hole size selected from Figure 13 in order to provide required the 1¹⁄₂ inches of air space between the outside diameter of the chimney and the edges of

the framed ceiling hole.

■ 5. Positioning, Safety Strips,

Securing The Fireplace

Slide fireplace into position. Lift the fireplace front slightly and slide the metal safety

strips under front bottom edge about 1¹⁄₂", allowing the remainder to extend in front of firebox. Overlap strips at least 1/2 inch to provide a positive joint. (Flat safety strips are packed with fireplace.) (Fig. 14)

Note: Safety strips are not required over non-combustible floors where all supports at the base of the fireplace are non-combustible.

Four (4) nailing flanges are supplied with the fireplace (found on the fireplace hearth). To level the box and secure it firmly in place, remove the nailing flanges from the hearth and install at the sides of the fireplace

as shown in Figure 15.

FP549

Fig. 15 Fasten fireplace in position.

METAL SAFETY STRIPS (1, 2 or 3 pieces)

"Z" SAFETY STRIP

(not supplied)

HEARTH EXT.

¹⁄₂" MIN.

1¹⁄₂"

FP557

Fig. 14 Safety strip installation.

OVERLAP

FIREPLACE

PLATFORM

Safety strips are used to ensure that any combustible materials in front of the fireplace are protected even though a non-combustible hearth extension is required.

If fireplace is to be elevated above the floor, a “Z” shaped metal safety strip must be fabricated and used to protect combustible surfaces in front of the fireplace. This “Z” shaped safety strip is not provided but must be fabricated of metal with each horizontal leg at least 1¹⁄₂ inches wide and equal in length to the metals strips provided with the fireplace.

Installing Outside Air Kit

An outside air kit is installed in all SR/SC Series Fireplaces. If desired, or if local codes mandate the use of an air kit, then an AK-MST is required to complete the installation (from air kit to the outdoors). If the outside air kit is to be used, the AK-MST MUST be installed BEFORE the fireplace is enclosed. Refer

to the AK-MST instructions for field installation.

■ 6. Installing The Chimney System

Start by attaching the first chimney section to the collar on top of the fireplace.

Install the pipe as pictured in Figure 16. When you get a good lock, you will hear the pipe clearly snap together. Once sections are snap-locked in place, it is extremely difficult to get them apart. Make sure the

pipe is firmly snapped and locked together as each pipe section is mounted.

When installing elbows, only outer pipe will snap- lock. Middle pipes simply slide into position. Be sure to always attach straps on upper elbow to a structural

framing member. (Fig. 17)

Majestic Fireplaces® SR/SC Series

CHIMNEY SUPPORT STRAP (must be tight)

CEILING HOLE FRAMING

ANGLE FIRESTOP

Continue installing the pipe as required until pipe is installed up through the ceiling. At this point, you must

install a firestop spacer.

Installing the Firestop Spacer

in the Ceiling Hole

A firestop spacer is used to keep pipe spaced properly and required for safety.

Nail the firestop spacer (at each corner) to the framing members of the ceiling hole. Note: A firestop spacer is not required at the roof.

Hole sizes listed in Figure 13 for angled firestop spacers provide minimum required air space to chimney pipe for ceiling thickness up to eight (8) inches. When combined thickness of ceiling material, ceiling joists and flooring material exceeds eight (8) inches, adjustments must be made in framing to assure that

minimum air spaces to chimney are maintained.

Proper Firestop Spacer Installation

Figure 18 shows different installation procedures for both an area that is an attic and an area that

is not

attic. If the area above the ceiling is not an attic, position the

firestop spacer with the flange on the ceiling side and the angled portion extending up into the hole.

If the area above the ceiling is an attic, position the firestop spacer with the flange on the top of the framed hole and the angled portion extending down into the hole.

Firestop spacers are not available for nor are they required on vertical walls.

DO NOT put any sealant around the area where the outer pipe slides through the firestop spacer. If you

seal this area, it may cause a fire hazard.

Canadian Requirements

for Insulation Shield

PIPE SECTION

Fig. 16 Install pipe, listening for the snap-lock to fasten.

SUPPORT STRUCTURE

ELBOW STRAP (must be tight)

ELBOW STRAP

ANGLED STRAP

FP270/271

Fig. 17 Attach straps to a structural framing member.

PIPE RIM

HEM

LANCE

FP558

In Canada, an attic insulation shield is required to prevent attic insulation from contacting the chimney section. Framing dimensions for the chimney hole should measure 14¹⁄₂" x 14¹⁄₂". An attic shield MUST be installed on top of attic joists (above the floor

level). (Fig. 19)

Fig. 18 Installing firestop spacer.

NAILS (4)

FIRESTOP SPACER

JOIST

Ceiling InstallationAttic Installation

JOIST

FIRESTOP SPACER

NAILS (4)

FP593

Install the attic insulation shield with the flanges on its

ATTIC INSULATION SHIELD

BASE FLANGES

ATTIC JOIST

NAILS (4 required)

base extending down into the framing hole. Nail each corner of attic insulation shield to the framing members of the ceiling hole using 8d nails. Attic shields are not

required at the roof.

Continue Installing Pipe to Complete Run

Continue attaching pipe sections to complete system to next level always being careful that the pipe is firmly snapped locked in place before proceeding to next

pipe section.

Chimney Supports

If chimney supports are required, they are installed the same as elbows. Nail chimney support straps to adjacent structural framing, as shown on Figure 9, Page 8. Bend straps as necessary and make sure they are secure so they will support the weight of the chimney. A chimney support is 2¹⁄₂" long when installed. Consider this dimension when determining how many straight chimney sections are needed.

Note: Chimney supports are generally used in long runs in a chase installation.

Additional Ceilings

If you encounter additional ceilings, repeat same steps required for first ceiling installation. See firestop

illustration on Figure 18, Page 12.

Penetrating the Roof

Run pipe to roofline. Since chimney system must be vented to the out-of-doors, you must use an approved Vermont Castings, Majestic Products termination.

If a chase is used, refer to the installation manual provided with the termination cap.

Locate Chimney Centerpoint On Roof

Use same procedure detailed in locating center point of the flue system.

Drive a nail up through roof at the center point. This will determine center point on outside of the roof.

Majestic Fireplaces® SR/SC Series

FP263

Fig. 19 Attic shield installlation (Canadian requirement).

WARNING: DO NOT PACK REQUIRED AIR SPACES WITH INSULATION OR OTHER MATERI-

ALS.

Mark an outline of the roof hole around the center of the point nail. Note: Hole dimensions given in the chimney top installation instructions are horizontal dimensions; therefore, the hole size must be marked on the roof accordingly.

Cover the opening of the installed chimney so debris cannot get into the system.

Cut and frame the hole. It is good practice to use framing lumber that is the same size as the rafters. Install the frame securely because the chimney top and flashing anchored to the frame must be able to

withstand heavy winds.

Install Remainder of Chimney Sections

Since you have already preplanned the height of your termination according to the install pipe to the predetermined height.

Check the chimney top installation instructions for details on how high above the roof top the chimney

sections (all pipes) should extend.

Ten Foot Rule

, continue to

Cut and Frame Roof Hole

Size of roof hole varies with the type of chimney termination installed. Refer to installation instructions provided with Vermont Castings, Majestic Products chimney termination to find correct size of roof hole.

There must be a 1¹⁄₂ inch air space between outermost portion of chimney sections and any adjacent combustible surfaces. (Combustible surfaces include burnable materials such as: ceiling members, joists, flooring,

combustible insulation and roof structures.)

Majestic Fireplaces® SR/SC Series

■ 7. Installing Top Housing

Or Termination

Follow the installation instructions provided with the Vermont Castings, Majestic Products chimney termina-

tion you have selected.

Installing Chimney In a Chase

Refer to Figure 5, Page 5 for an illustration of a typical chase installation.

CAUTION: Treatment of firestop spacers and construction of chase may vary with type of building. These instructions are not a substitute for local building codes. You must check your local building codes to determine specific requirements for your city or state. Note: Other building materials may be required in addition to Vermont Castings, Majestic Products

Firestop Spacers.

Finishing

CAUTION: All joints between the finished wall and the

fireplace surround (top/sides) must be sealed with non-combustible material to prevent cold air leakage into the room. Only non-combustible material may be applied to the facing of the fireplace surround. (Black

painted area) (Fig. 20)

■ 8. Finish Wall

Air Space Clearances

Combustible framing material MUST NOT penetrate AIR SPACE (shaded areas).

1¹⁄₂"

Standoff

¹⁄₂" air space to sides

FRONT VIEW

Wall Shield

SIDE VIEW

Firestop

¹⁄₂" Air Space to Back

¹⁄₂" Air Space to Sides

Finish the wall with material of your choice. Do not

install a combustible mantel shelf less than 12 inches above the grille opening. If a combustible

material is used below a flat mantel shelf, consult your local building codes for minimum clearance from top of fireplace opening to bottom of mantel shelf.

All joints (top, bottom and sides) where wall or decorative facing material meets fireplace surround must be completely sealed with a non-combustible material. (Figs. 21 and 22)

Note: No side wall protection is required for fireplaces installed at 45 degrees to two (2) side walls (corner installation).

Often a decorative surround or vertical portion of the mantel is desired. If this is constructed of any combustible material it must be within the safe zone indicated in Figure 23.

Only noncombustible material may be applied as facing to the black fireplace surround.

Fig. 20 Minimum clearances to combustibles.

0" Clearance to Floor

Hearth Extension

FP559

Side Wall Protection

See mantel drawing for shelf-to-surround dimension

MANTEL SHELF

2 x 4 FINISHED HEADER

Must be sealed with noncombustible material

FIREPLACE FRONT

STANDOFF

FINISHED WALL

SURROUND

STUD

SIDE VIEW

Must be sealed with noncombustible material

FIREPLACE FRONT

FINISHED WALL

2 x 4 STUD

TOP VIEW

¹⁄₂"

Adjacent combustible side walls that are within the minimum dimensions shown in Figure 23 of fireplace opening must be protected with Vermont Castings, Majestic Products Wall Shield Model SP40 or a specifically built wall shield described below.

The special wall shield design described in Figure 20 is an alternate method of adding protection to side walls and can be used in place of the SP40 with the same wall clearances specified for the SP40. Rt must

=1.85 minimum.

Examples of wall shield insulation:

1. Manville - CERAFORM 126, K=.27, 1/2 inches thick

2. Majestic - EH2416, K = .458, 1 inch thick required.

Majestic Fireplaces® SR/SC Series

FP531

Fig. 21 Fireplace surround flush with finished wall.

Fig. 22 Combustible mantle clearances.

1¹⁄₂" Ref.

12"

6" Min.

Combustible materials are permitted within a shaded area shown in Figure 23, page 16 titled Minimum Wall Clearances.

MA81

Majestic Fireplaces® SR/SC Series

■ 9. Hearth Installation

A hearth extension is required to protect a combustible floor in front of the fireplace. Refer to Figure 23 for minimum dimensions and mounting detail.

Note: Hearth Extension must not cover the air inlet opening of a fireplace.

The hearth extension described in Figure 23 must be a durable non-combustible material with a minimum (total) Rt value of 1.09; see Figure 24 for examples. The overall height (above a combustible floor), depth and width must be as indicated, with the extension centered to the fireplace opening.

The top of insulation must be covered with a noncombustible decorative covering or a piece of .018” minimum sheet metal, to protect hearth extension material. (Fig. 23)

Secure the hearth extension to the floor to prevent shifting, using trim molding or other similar means at three (3) outer edges. Seal crack between the fireplace hearth and hearth extension with a non-combustible material. (Figs. 23 and 25)

WARNING: HEARTH EXTENSION MUST BE INSTALLED IN ACCORDANCE WITH FIGURE 23 AND MUST NOT COVER THE BOTTOM FRONT OPENING OF THE CIRCULATING MODEL.

Alternate noncombustible materials may be used providing the (total) thermal resistance (Rt value) of the alternate material employed is greater than or equal to R = 1.09. Thermal resistance (R) or thermal conductivity (K), may be obtained from manufacturer of the material. Factors are related by the formula K = 1/R.

T = given thickness R = thermal resistance for a given thickness (T) K = thermal conductivity

Noncombustible material with a lower R value may be used, provided thickness of material is sufficiently greater to maintain an equivalent (total) thermal

resistance (Rt).

Minimum Wall Clearances

WITH Noncombustible Surround Facing

4" BRICK (Example material)

F**

C**

SIDE WALL

Combustible material permitted within shaded area.

Noncombustible wall shield requires 1" Majestic EH2416

* insulation (minimum R Value = 1.85) between decorative

noncombustible rigid covering and combustible wall. Minimum height and width is 40" x 40".

Dimension/degree of angle will vary depending on thickness

** of noncombustible surround facing.

SR/SC36 16" 12" 48° 41° 18" 14" 7³⁄₄" 16" 48" SR/SC42 20" 12" 42° 35° 18" 14" 11¹⁄₂" 20" 61¹⁄₂"

Fig. 23 Combustible side wall protection and hearth extension dimensions.

FIREBOX

OPENING

A - Min. clearance to combustible perpendicular wall

B - Min. clearance to combustible perpendicular wall when using noncombustible wall shield*

A BCD E F G H J

406mm 305mm 457mm 356mm 197mm 406mm 1219mm 508mm 305mm 457mm 356mm 292mm 508mm 1562mm

WITHOUT Noncombustible Surround Facing

Shaded area starts 1/2" away from edge of unit.

SIDE WALL

Minimum Hearth Extension Dimensions

(for On-Site Construction)

May install noncombustible decorative covering OR .018" min. sheet metal

4" MIN.

COMBUSTIBLE FLOOR

Seal cracks between the fireplace and hearth extension with noncombustible material

MINIMUM INSULATION VALUE "R"

FIREPLACE HEARTH

Safety strips must overlap ¹⁄₂" minimum

FP594

COMMON MATERIALS AND FACTORS

)

WALL COVERING

NONCOMBUSTIBLE DECORATIVE FACING

NONCOMBUSTIBLE DECORATIVE COVERING

Seal all cracks between fireplace surround and wall materials with noncombustible material.

Seal crack between fireplace and hearth extension with noncombustible material.

2x4" HEADER Do not notch at standoffs.

SAFETY STRIPS Must be overlapped ¹⁄₂" minimum.

HEARTH EXTENSION INSULATION

SIDE VIEW

MINIMUM

MATERIAL K*

EH2416

(Majestic Products Company)

0.458

THICKNESS

1.09 0.50 in.**

Majestic Fireplaces® SR/SC Series

Common Brick

R Value is for ¹⁄₂ inch. * Units of K = BTU/SQ FT/HR/˚F/IN ** Thickness of Listed Material

Fig. 24 Hearth extension material factors.

0.10 5.46 in.**

5.0

FP533ADD

Example of Determining Hearth Extension Equivalents

To determine the thickness required for any new material:

NEW required thickness

K of new material (per inch)

K of listed material

er inch

thickness of listed material

Example for Common Brick

T (new) = 5.0/0.458 x 0/50 in. = 5.46 in. (new required thickness).

FP550

Fig. 25 Sealing gaps.

Majestic Fireplaces® SR/SC Series

■ 10. Installing Line For Gas Logs

Vermont Castings, Majestic Products fireplaces are designed to accept a 1/2 inch gas line for installation of an approved gas appliance. (Vermont Castings, Majestic Products manufactures a wide variety of gas logs for use in Vermont Castings, Majestic Products fireplaces.)

Be sure to have the appliance installed in accordance with building codes.

Gas connection may enter from either left or right side of the fireplace.

Locate appropriate gas line in the outer casing of fireplace and remove insulation from gas line tube. (Fig. 26)

From inside the fireplace, locate the knockout on the firebrick -- be sure you are on the appropriate or "gas line" side of the fireplace. Using a flat bladed screwdriver or small chisel and hammer, carefully tap around the knockout until it loosens and falls out.

Install 1/2 inch certified gas pipe through opening. After gas pipe installation is complete, use insulation that was removed from gas line tube to repack space around the pipe. Material should be inserted from outside of the fireplace and packed tightly to totally seal between the pipe and tube.

Note: Gas pipe should not come in contact with any wood structures until it has reached a point at least one (1) inch away from fireplace side.

NOTE: When installing an ANSI Z21.11.2 ventless

appliance the finishing material used for the mantel must be rated at 250°F or greater.

BTU input of a gas appliance installed in fireplace should be rated less than 100,000 BTU/Hr.

Gas pipe installation is intended for connection to a decorative gas appliance only when (1.) incorporating an automatic shutoff device and (2.) complying with the Standard for Decorative Gas Appliances for Installation in Vented Fireplaces (ANSI Z21.60) or CSA draft requirements for Gas-Fired Log Lighters for Woodburning Fireplaces (Draft No. 4, August 1993).

Decorative gas appliance should be installed in accordance with the National Fuel Gas Code, ANSI

Z223.1 (latest edition).

HOLE IN OUTER CASING

GAS LINE TUBE

CERAMIC KNOCKOUT

HOLE IN OUTER CASING

Fig. 26 Gas line access.

CAUTION: WHEN USING DECORATIVE GAS APPLIANCE, FLUE DAMPER MUST BE SET IN FULLY OPEN POSITION. IF YOU HAVE GLASS DOORS ON THE FIREPLACE, THEY MUST ALSO BE FULLY

OPENED.

WARNING: DO NOT OPERATE AN UNVENTED GAS LOG SET IN THIS FIREPLACE WITH THE CHIMNEY REMOVED.

WARNING: WHEN INSTALLING AN UNVENTEDAS LOG SET, THE MAJESTIC MODEL AH3244BK OR AH3244PB 4" ADJUSTABLE HOOD MUST BE USED.

FIREPLACE TOP VIEW

SUPPLY LINE

REPACK INSULATION

CERAMIC KNOCKOUT (Both sides)

FP560

If installing an unvented gas log set, refer to statement below:

Only unvented gas logsets which have been found to comply with the Standard for Unvented Room Heaters, ANSI Z21.11.2, are to be installed in this fireplace.

Majestic Fireplaces® SR/SC Series

948

Vermont Castings, Majestic Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice.

SR/SC36/42 Series

SR/SC36 SR/SC42

Item/Model Number Part Number Part Number

1. Damper Weld Assembly RP199 RP199

2. Damper Bracket 3030176 3030176

3. Screen Rod Assembly 3030126 3032112

4. Screen* 7554338 7554340

5. Screen Pulls 5584139 5584139 6a. Firebrick - Hearth 3041103 3034105 6b. Firebrick - Rear 3030102 3034104 6c. Firebrick - Right Side 3041105 3034103 6d. Firebrick - Left Side 3041104 3034102

7. Top Brick Retainers*** 3030172 3030172

8. Screen Clips** 7512135 7512135

9. Hearth Pan Cover Plate (SC Only) 3031104 3031104

10. Outer Collar Assembly (SK8 Chimney) 3030143 3030143

11. Nailing Flange** 2253161 2253161

12. Top Grille Assembly (SC Only) 3041143 3035131

13. Bottom Grille Assembly (SC Only) 0056034 3035130

14. Basket Grate 3041130 3041130

15. O.S.A. Assy. 20003076 20003076

*Two (2) required per fireplace

** Four (4) required per fireplace

*** Three (3) required per fireplace

Majestic Fireplaces® SR/SC Series

Accessories

The following accessories for this appliance are available from your local Vermont Castings, Majestic Products distributor. Should you need additional information beyond what your distributor can furnish, contact: Vermont Castings, Majestic Products, 410 Admiral Blvd., Mississauga, Ontario, Canada L5T 2N6, Attn: Technical Services.

CAUTION: This fireplace and chimney assembly is a highly engineered system, and, as such, must be operated only with Vermont Castings, Majestic Products approved components. If you use an unapproved component to make any modifications, you may create a possible fire hazard and will void the Vermont Castings, Majestic Products warranty. In addition, such action may void the coverage provided by the owner’s insurance.

Model NumberDescriptionAccessory

Glass Door — Standard Bi-Fold door set Brushed Brass finish 36GDKBB (SR/C36)

42GDKBB (SR/C42)

Black finish 36GDKBK (SR/C36)

42GDKBK (SR/C42)

Polished Brass finish 36GDKDB (SR/C36)

42GDKDB (SR/C42)

Pewter finish 36GDKS (SR/SC36)

42GDKS (SR/SC42) Fan Kit Provides forced air flow FK12 Variable Speed Control Provides speed adjustment of fans SCVS Outside Air Termination Completes connection from air kit to out-of-doors AK-MST Chimney Adapter Converts fireplace to 3-wall system TWABR Hearth Extension Insulation Provides hearth extension floor protection EH2416 Grate SR/SC36/42 Holds firewood in firebox RSBG36 Hearth Patch Compound Patch cracks in hearth HPC-1

Contact your Vermont Castings, Majestic Products distributor or dealer for finishing Marble and Mantels, available in a wide selection of styles.

Majestic Fireplaces® SR/SC Series

Chimney Components

U.S.

Model NumberDescriptionComponent

Round Top Termination Top used to terminate chimney at roof. RLTSK8

(Flashing not included.)

Round Top Termination - Top used to terminate chimney at chase. RLTSK8L Extended (Flashing not included.)

Flashing Metal finishing required around Contemporary 8-6-12 with 8" flue:

Termination to prevent rain leakage. 0-6/12 pitch

8-12-12 with 8" flue: 6/12-12/12 pitch

Square Termination Top housing of simulated brick pattern S20B (R, T, W) Housing available in red, tan or white. Appropriate Must also include:

adapter required. Flashing included. PLTSK8 or SLTSK8

Adapter Kit Unites Square Termination with chimney CF8CA

pipe (required).

Housing Extensions Extends Square Termination on steep 202036

pitched roofs.

Square Chase Termination Housing used to terminate chimney through CT100

a chase top. Appropriate adapter required. (Flashing not included.)

Adapter Kit Unites Square Chase Termination with chimney CTSK

pipe (required).

Chase Top Housing Low profile pyramid-style chimney cap used to PLTSK8

terminate chimney through a chase. Includes adapter. (Flashing not included.)

Chase Top Housing Square chimney cap used to terminate chimney SLTSK8

through a chase. Terra Cotta Masonry . Includes adapter. (Flashing not included.)

SK8 Chimney Sections Pipe used to build 8" (SK8) flue systems. SK81 (1' Long)

SK818 (1¹⁄₂' Long) SK83 (3' Long) SK84 (4' Long)

SK8 Chimney Elbows Elbow used to create an offset in an 8" SK830-2

chimney system. Only 30˚ elbows available. Packaged 2 per carton (offset and return).

Firestop Required at each floor level of chimney SKFS2A —

installation. (Plus attic on multi-story installation.) (8" straight flue)

SKFS6A — (8" 30˚ inclined flue)

Chimney Support Used to support chimney for each of: 30' vertical SKCS8

height and 6' of angled chimney run.

Majestic Fireplaces® SR/SC Series

(Chimney Components con't.)

Canada

Model NumberDescriptionComponent

Chimney Collar Enclosure Installs on the "over the chimney collar" of the CCE-SK

fireplace; provides outside air to assist in cooling the chimney system.

Attic Insulation Shield Used to prevent insulation from coming in AIS-SK

contact with the chimney system.

SK8 Chimney Sections Used to build chimney systems exposed above SK818CAN (1¹⁄₂' Long)

roof. SK84CAN (4' Long)

45˚ Chimney Elbows Provides 45˚ offset and return. For Canadian SK845/2

installations only . For use with SK8 chimney only. (Maximum use of 2, or 1 pair.)

Majestic Fireplaces® SR/SC Series

™

LIMITED WARRANTY & 30 YEAR PROTECTION PLAN

For MAJESTIC FIREPLACES® PRE-ENGINEERED Fireplace Systems

Vermont Castings, Majestic Products warrants its MAJESTIC FIREPLACES® Pre-Engineered Fireplace (“Fireplace”) and Vermont Castings, Majestic Products supplied firegrate, glass doors, outside air system, fan motor, and liners to be free from defects in material or workmanship, as follows:

A. Fireplace and Chimney Components: (exclusive of Vermont Castings, Majestic Products-supplied firegrate, glass doors, outside air system, fan motor, and liners all of which are covered by separate warranties under paragraphs B through D below): At its option for a period of thirty (30) years from the date the Fireplace is installed, Vermont Castings, Majestic Products either will pay to the consumer the then current wholesale price of such defective part; or,

(1) For a period of five (5) years from the date the Fireplace is installed, Vermont Castings, Majestic Products, at its option, will repair or replace any defective part without charge.

(2) Thereafter, through the 10th year after the date the Fireplace is installed, if replacement parts are available, Vermont Castings, Majestic Products will provide a replacement for any defective part without charge for the part itself. The consumer must pay for everything else other than the part.

(3) Thereafter, through the 30th year after the date the Fireplace is installed, if replacement parts are available, Vermont Castings, Majestic Products will provide a replacement for any defective part at a cost to the consumer of Vermont Castings, Majestic Products then current list price, FOB Vermont Castings, Majestic Products factory.

B. Firegrate, Glass Doors, Outside Air System:

For a period of 90 days from the date the Fireplace is installed The Vermont Castings, Majestic Products Company, at its option, will provide a replacement for any defective part, without charge for the part itself, FOB Vermont Castings, Majestic Products factory, (The consumer must pay for everything else other than the part,) or pay to the consumer the then current wholesale price of such defective part.

C. Fan Motor:

(1) For a period of one (1) year from the date the Fireplace is installed, Vermont Castings, Majestic Products, at its option, will repair or replace any defective part without charge, or pay to the consumer the then current wholesale price of such defective part.

(2) Thereafter, through the 30th year after the date the Fireplace is installed Vermont Castings, Majestic Products, at its option, if replacement parts are available, will provide a replacement for any defective part at a cost to the consumer of Vermont Castings, Majestic Products then current list price, FOB Vermont Castings, Majestic Products factory, or pay to the consumer the then current wholesale price of such defective part.

D. Liners (Refractory or Metal):

(1) For a period of two (2) years from the date the Fireplace is installed, Vermont Castings, Majestic Products, at its option, will repair or replace any defective part without charge, or pay to the consumer the then current wholesale price of such defective part.

This warranty is subject to the following conditions and limitations:

(1) This warranty is extended only to a Fireplace installed in the continental United States, the state of Alaska and Canada; only if and so long as the Fireplace is installed according to the installation instructions furnished with the Fireplace, and operated at all times under normal conditions, use and service according to the operative instructions furnished with the Fireplace, and only if and so long as the Fireplace is not removed from its original installation.

(2) This warranty is non-transferrable, and is made to the original owner, provided that the purchase was made through an authorized supplier of the Company.

(3) The sole and exclusive remedies for breach of any warranties hereunder shall be for the repair, replacement or provision of a replacement part at Vermont Castings, Majestic Products then current list price, FOB Vermont Castings, Majestic Products factory, for any defective part as specified in paragraphs A through D, or the payment to the consumer of the then current wholesale price of such defective part.

(4)Vermont Castings, Majestic Products shall not be liable for damage from any smoking of a MAJESTIC FIREPLACES PreEngineered Fireplace System related to environmental geographic conditions (such as, for example, nearby structures or roof peaks, trees, hills, or mountains), inadequate ventilation, or negative air pressure in the place where the Fireplace system is installed, related to any mechanical system (such as, for example, furnaces, fans, air conditioners, clothes dryers, etc.)

(5) Except as otherwise expressly specified in paragraphs A through D, NONE OF THESE WARRANTIES COVER, AND VERMONT CASTINGS, MAJESTIC PRODUCTS SHALL NOT BE RESPONSIBLE FOR, ANY CONSTRUCTION, INSTALLATION, LABOR, TRANSPORTATION OR OTHER COSTS OR EXPENSES ARISING FROM A DEFECTIVE PART, ITS REPAIR OR REPLACEMENT OR OTHERWISE, NOR SHALL VERMONT CASTINGS, MAJESTIC PRODUCTS IN ANY EVENT BE RESPONSIBLE FOR ANY INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES EXCEPT TO THE EXTENT REQUIRED BY LAW. Some states do not allow the exclusion or limitation of incidental or consequential damages, so this exclusion or limitation may not apply to you.

NO IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL REMAIN IN EFFECT AFTER THE EXPIRATION OF THE WARRANTIES SET FORTH IN PARAGRAPHS A THROUGH D. Some states do not allow limitations on how long an implied warranty lasts, so this limitation may not apply to you.

In order to obtain performance of any of the above warranty obligations write to Vermont Castings, Majestic Products at this address:

Vermont Castings, Majestic Products 410 Admiral Blvd. Mississauga, Ontario, Canada L5T 2N6 Attention: Director of Warranty Services

Since local building requirements may vary greatly throughout the country, users of Vermont Castings, Majestic Products products should determine in advance whether there are any building code restrictions on the use of a specific product. VERMONT CASTINGS, MAJESTIC PRODUCTS MAKES NO REPRESENTATION OR WARRANTY REGARDING, AND SHALL NOT BE RESPONSIBLE FOR, ANY BUILDING CODE COMPLIANCE.

The foregoing warranties give you specific legal rights and you may also have other rights which vary from state to state.

Majestic Fireplaces® SR/SC Series

Ver mont Castings, Majestic Products

410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777

www.majesticproducts.com • www.vermontcastings.com

Vermont Casting SR42, SR36, SC42, SC36 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
