Verizon Wireless LG Chocolate Touch User Manual

This booklet is made from 60% post-consumer recycled paper.

MMBB0357601(1.0) H

is a trademark of LG. All other

trademarks are the property of their respective owners.

Important Safety Precautions

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.

Violation of the instructions may cause serious injury or death.

●

Never use an unapproved battery since this could damage the

phone and/or battery and could cause the battery to

explode.

●

Never place your phone in a microwave oven as it will cause

the battery to explode.

●

Never store your phone in temperatures less than

-4°F or greater than 122°F.

●

Do not dispose of your battery near fire or with hazardous or

flammable materials.

●

When riding in a car, do not leave your phone or set up the

hands-free kit near the air bag. If wireless equipment is

improperly installed and the air bag is deployed, you may be

seriously injured.

●

Do not use a hand-held phone while driving.

●

Do not use the phone in areas where its use is prohibited.

(For example: aircraft)

Important Safety Precautions

●

Do not expose the battery charger or adapter to direct

sunlight or use it in places with high humidity, such as a

bathroom.

●

Do not use harsh chemicals (such as alcohol, benzene,

thinners, etc.) or detergents to clean your phone. This could

cause a fire.

●

Do not drop, strike, or shake your phone severely. It may

harm the internal circuit boards of the phone.

●

Do not use your phone in high explosive areas as the phone

may generate sparks.

●

Do not damage the power cord by bending, twisting, pulling,

or heating. Do not use the plug if it is loose as it may cause

electric shock or fire.

●

Do not place any heavy items on the power cord. Do not

allow the power cord to be crimped as it may cause electric

shock or fire.

●

t handle the phone with wet hands while it is being

Do no

charged. It may cause an electric shock or seriously damage

your phone.

●

Do not disassemble the phone.

●

Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.

●

Do not hold or let the antenna come in contact with your body during a call.

●

Make sure that no sharp-edged items, such as animal’s teeth or nails, come into contact with the battery. This could cause a fire.

●

Store the battery out of reach of children.

●

Be careful that children do not swallow any parts (such as earphone, connection parts of the phone, etc.) This could cause asphyxiation or suffocation resulting in serious injury or death.

●

Unplug the power cord and charger during lightning storms to avoid electric shock or fire.

●

Only use the batteries and chargers provided by LG. The warranty will not be applied to products provided by other suppliers.

●

Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.

●

Your service provider programs one or more emergency phone numbers, such as 911, that you can call under any circumstances, even when your phone is locked. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

Table of Contents

Important Safety Precautions . . .1

Welcome . . . . . . . . . . . . . . . . . 8

Technical Details . . . . . . . . . . .9

Important Information . . . . . . . . . . . . . . . . .9

Phone Overview . . . . . . . . . . .12

Quick Glance of the Touch Screen and How to Use It . .14

Touch Sensitive Soft Keys . . . . . . . . . . . . .14

Shortcut Menu . . . . . . . . . . .16

Touch Screen Shortcut Menu . . . . . . . . . .16

Entering and Editing

Information . . . . . . . . . . . . . . .18

Text Input . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Menu Tree . . . . . . . . . . . . . . .21

Getting Started with Your

Phone . . . . . . . . . . . . . . . . . . .24

The Battery . . . . . . . . . . . . . . . . . . . . . . . . . .24

Installing the Battery . . . . . . . . . . . . . . . . .24

Removing the Battery . . . . . . . . . . . . . . . .24

Charging the Battery . . . . . . . . . . . . . . . . .24

Charging with USB . . . . . . . . . . . . . . . . . . .25

How to Install a microSD™ Card . . . . . .25

How to Remove a microSD™ Card . . . .25

Battery Temperature Protection . . . . . . .26

Battery Charge Level . . . . . . . . . . . . . . . . . .26

Turning the Phone On and Off . . . . . . . .26

Turning the Phone On . . . . . . . . . . . . . . .26

Turning the Phone Off . . . . . . . . . . . . . . .26

Signal Strength . . . . . . . . . . . . . . . . . . . . . .26

Screen Icons . . . . . . . . . . . . . . . . . . . . . . . . .27

Making Calls . . . . . . . . . . . . . . . . . . . . . . . . .27

Correcting Dialing Mistakes . . . . . . . . . .27

Redialing Calls . . . . . . . . . . . . . . . . . . . . . . .27

Receiving Calls . . . . . . . . . . . . . . . . . . . . . . .27

Menu Tree on the Touch

Screen . . . . . . . . . . . . . . . . . . .28

Menu Access . . . . . . . . . . . . . . .28

Shortcut Menu on the Touch

Screen . . . . . . . . . . . . . . . . . . .29

Touch Screen Shortcut Menu . . . . . . . . . .29

Quick Access to Convenient

Features . . . . . . . . . . . . . . . . .30

Lock Mode . . . . . . . . . . . . . . . . . . . . . . . . . .30

Quick Volume Adjustment . . . . . . . . . . . . .30

Vibrate Mode . . . . . . . . . . . . . . . . . . . . . . . .30

Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . .30

Voice Commands . . . . . . . . . . . . . . . . . . . . .31

Contacts in Your Phone’s

Memory . . . . . . . . . . . . . . . . .32

Storing Basics . . . . . . . . . . . . . . . . . . . . . . . .32

Changing Contact Entries . . . . . . . . . . . . .32

Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . .33

Storing a Number with Pauses . . . . . . . . .33

Deleting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Camera Features . . . . . . . . . .35

3D (Three-axis-accelerometer) Rotation . 35

Camera Features . . . . . . . . . . . . . . . . . . . . .36

Video Camera . . . . . . . . . . . . . . . . . . . . . . .38

After recording video . . . . . . . . . . . . . . . . .39

Picture Editing . . . . . . . . . . . . . . . . . . . . . . .39

Video Editing . . . . . . . . . . . . . . . . . . . . . . . .40

My Verizon . . . . . . . . . . . . . . .41

MESSAGING . . . . . . . . . . . . .42

1. New Message . . . . . . . . . . . . .42

1.1 TXT Message . . . . . . . . . . . . . . . . . . . .42

1.2 Picture Message . . . . . . . . . . . . . . . . . .44

1.3 Video Message . . . . . . . . . . . . . . . . . . .45

1.4 Voice Message . . . . . . . . . . . . . . . . . . .46

2. Messages . . . . . . . . . . . . . . . .46

3. Drafts . . . . . . . . . . . . . . . . . . .48

4. Voicemail . . . . . . . . . . . . . . .48

5. Visual Voice Mail . . . . . . . . . .49

6. Mobile IM . . . . . . . . . . . . . . .49

7. Email . . . . . . . . . . . . . . . . . . . .49

8. Chat . . . . . . . . . . . . . . . . . . . .50

9. Social Network Message . . . .50

10. Settings . . . . . . . . . . . . . . . .51

11. Erase Options . . . . . . . . . . . .53

CONTACTS . . . . . . . . . . . . . .54

1. New Contact . . . . . . . . . . . . .54

2. Contact List . . . . . . . . . . . . . .54

3. Backup Assistant . . . . . . . . . .55

4. Favorites . . . . . . . . . . . . . . . . . .55

5. Groups . . . . . . . . . . . . . . . . . . .56

6. Speed Dials . . . . . . . . . . . . . . .56

7. In Case of Emergency(ICE) . .57

8. My Name Card . . . . . . . . . . . .57

RECENT CALLS . . . . . . . . . . . . .58

1. Missed . . . . . . . . . . . . . . . . . .58

2. Received . . . . . . . . . . . . . . . . .58

3. Dialed . . . . . . . . . . . . . . . . . . . .59

4. All . . . . . . . . . . . . . . . . . . . . . . .59

5. View Timers . . . . . . . . . . . . . . .60

MEDIA CENTER . . . . . . . . . . . .61

1. Music & Tones . . . . . . . . . . . .61

1.1 V CAST Music . . . . . . . . . . . . . . . . . . .61

1.2 Get New Ringtones . . . . . . . . . . . . . . .62

1.3 My Ringtones . . . . . . . . . . . . . . . . . . . .62

1.4 My Music . . . . . . . . . . . . . . . . . . . . . . .63

Playing Your Music . . . . . . . . . . . . . . . . . .63

Music Player Controls . . . . . . . . . . . . . . .64

Exit From the Music Player . . . . . . . . . . .66

1.5 My FM Radio . . . . . . . . . . . . . . . . . . . .66

1.6 My Sounds . . . . . . . . . . . . . . . . . . . . . .69

1.7 Sync Music . . . . . . . . . . . . . . . . . . . . . .69

2. Picture & Video . . . . . . . . .71

2.1 V CAST Videos . . . . . . . . . . . . . . . . . . .71

2.2 Get New Pictures . . . . . . . . . . . . . . . . .72

2.3 My Pictures . . . . . . . . . . . . . . . . . . . . . .72

2.4 My Videos . . . . . . . . . . . . . . . . . . . . . . .73

2.5 Take Picture . . . . . . . . . . . . . . . . . . . . . .75

2.6 Record Video . . . . . . . . . . . . . . . . . . . .76

2.7 Online Album . . . . . . . . . . . . . . . . . . . .76

3. Games . . . . . . . . . . . . . . . . . .77

4. Browse & Download . . . . . . .77

5. Extras . . . . . . . . . . . . . . . . . . . .81

6. Info . . . . . . . . . . . . . . . . . . . . . .81

My Music . . . . . . . . . . . . . . . . . .81

Browser . . . . . . . . . . . . . . . . . . .82

Ending a Browser Session . . . . . . . . . . . . .82

Browser Navigating . . . . . . . . . . . . . . . . . . .82

Search . . . . . . . . . . . . . . . . . . . . .87

Table of Contents

Email . . . . . . . . . . . . . . . . . . . . . .88

VZ Navigator . . . . . . . . . . . . . . .88

Tools . . . . . . . . . . . . . . . . . . . . . .89

1. Voice Commands . . . . . . . . .89

1.1.1 Call <Name or Number> . . . . . . . .89

1.1.2 Send Msg to <Name or Number or

Group> . . . . . . . . . . . . . . . . . . . . . .90

1.1.3 Go to <Menu> . . . . . . . . . . . . . . . . .90

1.1.4 Check <Item> . . . . . . . . . . . . . . . . .90

1.1.5 Contacts <Name> . . . . . . . . . . . . .90

1.1.6 Search . . . . . . . . . . . . . . . . . . . . . . .90

1.1.7 Redial . . . . . . . . . . . . . . . . . . . . . . . .90

1.1.8 Play . . . . . . . . . . . . . . . . . . . . . . . . . .90

1.1.9 My Verizon . . . . . . . . . . . . . . . . . . .90

1.1.0 Help . . . . . . . . . . . . . . . . . . . . . . . . .91

2. Calculator . . . . . . . . . . . . . .91

3. Ez Tip Calculator . . . . . . . . .91

4. Calendar . . . . . . . . . . . . . . . .91

5. Alarm Clock . . . . . . . . . . . . .92

6. Stopwatch . . . . . . . . . . . . . .92

7. World Clock . . . . . . . . . . . . .93

8. Notepad . . . . . . . . . . . . . . . .93

9. Drawing Pad . . . . . . . . . . . . .94

10. USB Mass Storage . . . . . . .94

Settings . . . . . . . . . . . . . . . . . . .95

1. My Verizon . . . . . . . . . . . . . . .95

2. Bluetooth Menu . . . . . . . . . .95

2.1 Add New Device . . . . . . . . . . . . . . . . .95

My Device Info . . . . . . . . . . . . . . . . . . .97

2.2 Discovery Mode . . . . . . . . . . . . . . . . . .97

2.3 Supported Profiles . . . . . . . . . . . . . . . .97

3. Sounds Settings . . . . . . . . . .98

3.1 Easy Set-Up . . . . . . . . . . . . . . . . . . . . .98

3.2 Master Volume . . . . . . . . . . . . . . . . . . .98

3.3 Call Sounds . . . . . . . . . . . . . . . . . . . . . .98

3.4 Alert Sounds . . . . . . . . . . . . . . . . . . . . .99

3.5 Button Sounds . . . . . . . . . . . . . . . . . .100

3.6 Digit Dial Readout . . . . . . . . . . . . . .100

3.7 Service Alerts . . . . . . . . . . . . . . . . . . .100

3.8 Power On/Off . . . . . . . . . . . . . . . . . . .101

4. Display Settings . . . . . . . . . .101

4.1 Easy Set-Up . . . . . . . . . . . . . . . . . . . . .101

4.2 Banner . . . . . . . . . . . . . . . . . . . . . . . . .102

4.3 Backlight . . . . . . . . . . . . . . . . . . . . . . .102

4.4 Wallpaper . . . . . . . . . . . . . . . . . . . . . .103

4.5 Charging Screen . . . . . . . . . . . . . . . .103

4.6 Display Themes . . . . . . . . . . . . . . . . .103

4.7 Fonts . . . . . . . . . . . . . . . . . . . . . . . . . .104

4.8 Dial Fonts . . . . . . . . . . . . . . . . . . . . . .104

4.9 Clock Format . . . . . . . . . . . . . . . . . . .104

4.10 Shortcut Bin . . . . . . . . . . . . . . . . . . .105

4.11 Music Handle . . . . . . . . . . . . . . . . . .105

5. Touch Settings . . . . . . . . . .105

6. Phone Settings . . . . . . . . . .106

6.1 Airplane Mode . . . . . . . . . . . . . . . . .106

6.2 Voice Commands . . . . . . . . . . . . . . . .106

6.3 Language . . . . . . . . . . . . . . . . . . . . . . .107

6.4 Location . . . . . . . . . . . . . . . . . . . . . . .107

6.5 Current Country . . . . . . . . . . . . . . .108

6.6 Security . . . . . . . . . . . . . . . . . . . . . . . .108

6.6.1 Edit Codes . . . . . . . . . . . . . . . . . .108

6.6.2 Restrictions . . . . . . . . . . . . . . . . . .109

6.6.3 Phone Lock . . . . . . . . . . . . . . . . . .109

6.6.4 Lock Phone Now . . . . . . . . . . . . . .110

6.6.5 Reset Default . . . . . . . . . . . . . . . . .110

6.6.6 Restore Phone . . . . . . . . . . . . . . . .111

6.7 System Select . . . . . . . . . . . . . . . . . . .111

6.8 NAM Select . . . . . . . . . . . . . . . . . . . . .112

7. Call Settings . . . . . . . . . . . . .112

7. 1 Answer Options . . . . . . . . . . . . . . . . . .112

7. 2 Show Dialpad . . . . . . . . . . . . . . . . . . . .112

7. 3 Auto Retry . . . . . . . . . . . . . . . . . . . . . .113

7. 4 TTY Mode . . . . . . . . . . . . . . . . . . . . . .113

7. 5 One Touch Dial . . . . . . . . . . . . . . . . . .115

7. 6 Voice Privacy . . . . . . . . . . . . . . . . . . . .115

7. 7 DTMF Tones . . . . . . . . . . . . . . . . . . . . .115

7.8 Assisted Dialing . . . . . . . . . . . . . . . . . .115

8. USB Auto Detection . . . . . .116

9. Memory . . . . . . . . . . . . . . . .117

9.1 Save Options . . . . . . . . . . . . . . . . . . . .117

9.2 Phone Memory . . . . . . . . . . . . . . . . . .117

9.3 Card Memory . . . . . . . . . . . . . . . . . . .118

10. Phone Info . . . . . . . . . . . . .118

10.1 My Number . . . . . . . . . . . . . . . . . . . .119

10.2 SW/HW Version . . . . . . . . . . . . . . . .119

10.3 Icon Glossary . . . . . . . . . . . . . . . . . .119

10.4 Software Update . . . . . . . . . . . . . . . .119

11. Set-Up Wizard . . . . . . . . . .120

Safety . . . . . . . . . . . . . . . . . .121

TIA Safety Information . . . . . .121

Exposure to Radio Frequency

Signal . . . . . . . . . . . . . . . . . . . . . . . . .121

Antenna Care . . . . . . . . . . . . . . . . . .121

Phone Operation . . . . . . . . . . . . . . .121

Tips on Efficient Operation . . . . . .122

Driving . . . . . . . . . . . . . . . . . . . . . . . .122

Electronic Devices . . . . . . . . . . . . . .122

Pacemakers . . . . . . . . . . . . . . . . . . . .122

Hearing Aids . . . . . . . . . . . . . . . . . . .123

Other Medical Devices and

Health Care Facilities . . . . . . . . . . .123

Vehicles . . . . . . . . . . . . . . . . . . . . . . .123

Aircraft . . . . . . . . . . . . . . . . . . . . . . . .123

Blasting Areas . . . . . . . . . . . . . . . . .123

Potentially Explosive Atmosphere .123 For Vehicles Equipped with an

Air Bag . . . . . . . . . . . . . . . . . . . . . . .124

Safety Information . . . . . . . . . .124

Charger and Adapter Safety . . . . .125

Battery Information and Care . . . .125

Explosion, Shock, and Fire

Hazards . . . . . . . . . . . . . . . . . . . . . . .128

General Notice . . . . . . . . . . . . . . . .128

Caution: Avoid potential

hearing loss. . . . . . . . . . . . . .129

FDA Consumer Update . . . . . .131

10 Driver Safety Tips . . . . . . . .139

Consumer Information on

SAR . . . . . . . . . . . . . . . . . . . . . .141

FCC Hearing-Aid Compatibility (HAC) Regulations for

Wireless Devices . . . . . . . . . . . .144

Accessories . . . . . . . . . . . . .147

LIMITED WARRANTY

STATEMENT . . . . . . . . . . . .148

Glossary . . . . . . . . . . . . . . . .151

Terminology . . . . . . . . . . . . . . .151

Acronyms and Abbreviations . .151

Index . . . . . . . . . . . . . . . . . . .153

Welcome

Thank you for choosing the

Chocolate®TOUCH

cellular phone designed to operate with the latest digital mobile communication technology, Code Division Multiple Access (CDMA). Along with the many advanced features of the CDMA system, such as greatly enhanced voice clarity, this compact phone offers:

●

V CAST Music with Rhapsody

●

V CAST Video

●

V CAST Song ID

●

Mobile IM

●

Bing Search

●

VZ Navigator

●

VZW Tones Deluxe

●

Mobile Web Email

●

Visual Voice Mail

●

Corporate Email

●

BackUp Assistant

●

City ID

●

Touch Screen and auto Touch Screen lock.

●

Display themes and Wallpapers for customization.

●

Built-in 3.2 Megapixel digital camera (with video mode).

●

Large, easy-to-read, backlit LCD with status icons.

●

Messaging Voicemail, and caller ID.

●

HTML Browser.

●

Media Center

●

Dolby®Mobile

●

FM Radio

●

Long battery standby and talk time.

●

Easy operation; use Touch Screen to choose menus and answer prompts.

●

Any Key answer, Auto-answer with Handsfree, auto retry, One Touch and Speed Dialing (with 999 memory locations).

●

Bilingual (English and Spanish) capability.

●

Bluetooth®wireless technology.

●

1GB of internal memory for music

NOTE

The Bluetooth®word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.

Technical Details

Important Information

This user’s guide provides important information on the use and operation of your phone. Please read this guide carefully prior to using the phone to be able to use your phone to its greatest advantage and to prevent any accidental damage or misuse. Any unapproved changes or modifications will void your warranty.

Technical Details

The

Chocolate®TOUCH

digital phone that operates on both Code Division Multiple Access (CDMA) frequencies: cellular services at 800 MHz and Personal Communication Services (PCS) at 1.9 GHz.

CDMA technology uses a feature called DSSS (Direct Sequence Spread Spectrum) that enables the phone to keep communication from being crossed and to use one frequency channel by multiple users in the same specific area. This results in a 10-fold capacity

ease when compared with

incr analog mode. In addition, features such as soft/ softer handoff, hard handoff, and dynamic RF power control technologies combine to reduce call interruptions.

The Cellular and PCS CDMA networks consist of MSO (Mobile Switching Office), BSC (Base Station Controller), BTS (Base Station Transmission System), and

is an all

MS (Mobile Station).

1xRTT system receives twice as many subscribers in the wireless section as IS-95. Its battery life is twice as long as IS-95. High-speed data transmission is also possible. EV-DO system is optimized for data service and is much faster than 1xRTT system in applicable area.

The table on the following page lists some major CDMA standards.

FCC RF Exposure Information

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and

ernational standards bodies. The

int design of this phone complies with the FCC guidelines and these international standards.

Bodily Contact During Operation

This device was tested for typical use with the back of the phone kept 0.79 inches (2.0 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79 inches

Technical Details

CDMA

Standard

Basic Air Interface

Network

Service

1x EV-DO

interface

(2.0 cm) m between the user’

Designator Description

TIA/EIA-95A TSB-74 ANSI J-STD-008 TIA/EIA-IS2000

TIA/EIA/IS-634 TIA/EIA/IS-651 TIA/EIA/IS-41-C TIA/EIA/IS-124

TIA/EIA/IS-96-B TIA/EIA/IS-637 TIA/EIA/IS-657 IS-801 TIA/EIA/IS-707-A

TIA/EIA/IS-856

TIA/EIA/IS-878

TIA/EIA/IS-866

TIA/EIA/IS-890

CDMA Dual-Mode Air Interface

14.4kbps radio link protocol and inter-band operations

IS-95 adapted for PCS frequency band CDMA2000 1xRTT Air Interface

MAS-BS PCSC-RS Intersystem operations Non-signaling data comm.

Speech CODEC Short Message Service Packet Data Position Determination Service (gpsOne) High Speed Packet Data

CDMA2000 High Rate Packet Data Air Interface

1xEV-DO Inter-Operability Specification for HRPD Access Network Interfaces

Recommended Minimum Performance Standards for HRPD High Rate Packet Data Access Terminal

Test Application Specification(TAS) for High Rate Packet Data Air Interface

ust be maintained

s body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters, and similar accessories containing metallic components should not be used. Avoid the use of accessories that cannot maintain

0.79 inches (2.0 cm) distance between the user’s body and the back of the phone and have not been tested for compliance with

xposure limits.

FCC RF e

Vehicle-Mounted External Antenna

(Optional, if available.)

To satisfy FCC RF exposure requirements, keep 8 inches (20 cm) between the user / bystander and vehicle-mounted the external antenna. For more information about RF exposure, visit the FCC website at www.fcc.gov.

FCC Notice and Cautions

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that causes undesired operation. Any changes or modifications not expressly approved in this user guide could void your warranty for this equipment. Use only the supplied antenna. Use of unauthorized antennas (or modifications to the antenna) could impair call quality, damage the phone, void your warranty and/or violate FCC regulations. Don't use the phone with a damaged antenna. A damaged antenna could cause a minor skin burn. Contact your local dealer for a replacement antenna.

Part 15.21 statement

Changes or modifications that are not expressly approved by the manufactur

er could void the user's

authority to operate the equipment.

Part 15.19 statement

This device and its accessories comply with part15 of FCC rules.

Operation is subject to the following two conditions:

(1) This device & its accessories

may not cause harmful interference.

(2) This device & its accessories

must accept any interference received, including interference that may cause undesired operation.

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to television reception, which can be determined by turning the equipment off and on, the user is encouraged t correct the interference by one or

o try to

more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Phone Overview

1. Earpiece

2. Touch Soft Keys

5. 3.5mm Headset Jack

6. Proximity Sensor

7. Light Sensor

8. Touch Screen

9. Shortcut Menu Touch Key

10. My Music Touch Key

3. SEND Key

4. Clear Key / Voice Command Key

NOTE

SEND Key, CLR / Voice Commands Key, and PWR / END Key are not illuminated when the display is off. Press the Unlock Key, or any other exterior key, to illuminate the display and keys. To unlock the screen and keys, lightly press and slide the icon upwards to reveal the Standby mode Touch Screen and Touch Soft Keys.

1. Earpiece

2. Touch Soft Keys

3. SEND Key

4. Clear K

5. 3.5mm Headset Jack

Lets you hear the caller.

provide easy access to Messages, the phone Dialpad, the Main Menu, the Contact List, and Favorites which easily activate with the touch of your fingertip.

place calls from the Dialpad. From Standby mode, pressing this key will open the All Calls list.

single spaces or characters. Also backs out of menus, one level at a time. While in Standby mode, use for quick access to Voice Command or press and hold to access Voice Recorder.

Touch Keys on this Touchpad

Use to answer incoming calls and to

ey / Voice Command Key

Allows you to plug in an

Deletes

11. PWR/END Key

optional wired headset for convenient, handsfree conversations.

o connect headphones normally used with other

t mp3 players.

6. Proximity Sensor screen during a call if an object (like your head) come accidental k phone cases may engage the sensor. The sensor is disabled when using the Speakerphone, a Bluetooth headset or the headset jack.

7. Light Sensor

brightness of the LCD. This conserves power and extends battery life.

8. Touch Screen messages and indicator icons as well as a wide variety of content you select to view.

The 3.5mm jack also allo

This sensor locks the Touch

s within close proximity, to prevent

eypresses. Please note that some

Detects the amount of light, adjusts

Displays incoming calls,

s y

12. Camera Lens

9. Shortcut Menu Touch Key to a customizable Shortcut Menu.

10. My Music Touch Key

the My Music application.

11. PWR/END Key

and to end a call. Also returns to Standby mode.

12. Camera Lens

recording video. Keep it clean for optimal photo quality.

13. Accessory Charger Port

to the battery charger, or other compatible accessories.

14. Side Volume Keys

Volume in Standby mode* and the Earpiece Volume during a call.

Allows quick access

This shortcut key opens

Use to turn the power on/off

Used for taking pictures and

Connects the phone

Use to adjust the Master

13. Accessory/ Charger Port

14. Side Volume Keys

15. Speakerphone Key

15. Speakerphone Keys deactivate the Speakephone function.

16. Lock/ Unlock Key Touch Screen and keys.

17. My Music Key

music. Download, store and listen to music right from your phone.

18. Camera Key function. Press and hold the Camera Key to record Video.

* Standby mode is when the phone is waiting for

input from you. No menu is displayed and the phone isn’t performing any action. It’s the starting point for all of the instruction steps.

16. Lock/ Unlock Key

17. My Music Key

18. Camera Key

Press to activate or

Press to lock or unlock the

Use for quick access to your

Use for quick access to Camera

Quick Glance of the Touch Screen and How to Use It

Touch Sensitive Soft Keys

(,,,,)

1. Make sure your hands are clean and dry. Remove moisture from the surface of your hands. Don't use the touch keys in a humid environment.

2. Touch screen is sensitive to your light touch. You don't need to press it forcefully to use it. Protect your phone from severe impact because touch screen sensors may become damaged from harsh use.

3. Use the tip of your finger to touch the center of a touch key. If you touch off-center it may activate the nearby function instead.

4. The touch feedback level can be adjusted to your preference.

5. When both the LCD screen and backlight are off, all keys are deactivated. Press the Unlock Key ( ) twice to turn on and unlock the Touch Screen.

6. The Proximity Sensor protects against accidental key presses during phone calls by locking the screen.

7. Keep metal and other conductive material away from the surface of touch screen because contact may cause electronic interference.

How to Unlock

Touch the icon and slide up to unlock the screen.

Press the Unlock Key on

the side of your phone. Press twice if the backlight is off.

Calibrating the Touch Screen

Calibration allows the phone to recognize the accuracy of your touch.

1. Unlock the Touch Screen by sliding the Slide icon up or press the Unlock Key ( ) on the right side of your phone. Then, touch the Menu Touch Soft Key .

2. Touch the

3. Touch

Settings

icon .

Touch Settings

4. Place your finger on the Touch Screen and apply gentle upward pressure to scroll the list up, then touch

Calibration

5. Touch the target each time it appears.

6. After setting calibration, touch

Check calibration without check

●

If you touch

Save

Check calibration

touch each target as it appears again. The screen will display a purple dot to indicate the location of your touch. If you are satisfied with your accuracy, touch

Ye s

to save, or touch

to try again.

●

Touch

Save without check

to save without viewing your touch accuracy.

Shortcut Menu

Touch Screen Shortcut Menu

The Touch Screen Shortcut Menu allows instant access to menus and phone features with the quick touch of your fingertip. To use the Shortcut Menu:

1. Unlock the Touch Screen by sliding the Slide icon up or press the Unlock Key ( ) on the right side of your phone.

2. Touch the Shortcut Menu icon .

3. Touch the My Media tab to access, and/or manage, shortcuts to your

favorite Media files (including pictures, videos, and music).

4. To close the Shortcut Menu, press the Clear or PWR/END Key.

Touch Soft Keys

s: Displays

Message

the Messages menu.

Menu: Displa

ys the Main Menu.

Phone: Displays the Dialpad Touch

Keys so you can make a call. Dial manually using the numeric keys or easily from your Recent Calls, Contacts, or Voice Dial.

Contacts:

Displays your Contact List.

Favorites: Displays

your favorite contacts.

When you touch the Phone Touch Soft Key the following Dialpad is displayed:

Touch and hold this

Touch Key to call your

voice mail box.

Touch this Touch Key to

dial using Voice

Command.

Touch this Touch Key to view

the recent call history.

Touch this Touch Key to display your Contact List to view or call a Contact.

Touch and hold this Touch Key to toggle your phone between Vibrate Mode and Normal Mode.

Touch this Touch Key to delete digits entered one by one. Hold down to delete the entire entry.

Entering and Editing Information

Text Input

You can enter information using the Touch Screen keypad. There are special key functions to help you with text entry.

Text Input While Composing a TXT Message

1. Unlock the Touch Screen by sliding the Slide icon up or press the Unlock Key ( ) on the right side of your phone.

2. Touch the Message Touch Soft Key

3. Touch .

4. Select

TXT Message

5. Touch the Text Field to begin entering text. A touch keypad will popup.

6. To access Text Input options, press the Text Options Touch Key . The options are:

Insert Quick Text/ Save As Draft/ Add/ Format Text/ Priority Level/ Callback#/ Save Quick Text/ Cancel Message

Text Entry Options.

Insert Quick Text/ Save As Draft/ Add/ Format Text/ Priority Level/ Callback#/ Save Quick Text/ Cancel Message

Touch to exit text input mode.

Touch to change text input modes.

Handwriting/Keypad Toggle Key.

When entering text, besides "typing" the text with Touch Keys, you also have the option to write with your fingertip. The Touch Screen interprets your movements into characters.

1. Touch a text field, then touch the manual writing icon on the right side of the display.

2. Use your fingertip to write each character you want. You must write in the box that appears in the lower half of the screen. If the Touch Screen does not display the character you intended, press the Clear/Voice Commands Key to delete characters, and try again.

For instructions on how to better use the handwriting function, see the next page.

TIP

When you "write" on the Touch Screen, the int

erpreted movements will be displayed. Gaps in lines may indicate that you need to press slightly harder for more constant contact with the Touch Screen.

NOTE

The handwriting option may not be available for all text entry fields.

Handwriting Recognition Field

Changing Input Method

To change from "writing" to "typing": In the hand-writing screen, touch the Keypad icon on the righthand side.

After creating a message, touch to send the message.

SEND

Entering and Editing Information

The following tables may help in understanding how the Touch Screen interprets movements into characters.

Writing in Upper-Case

Writing in Lower-Case

Note that you must touch the All Caps Touch

Key to write in upper-case letters.

Note that you must touch the Numbers

Touch Key to write in numbers.

Note that you must touch the Symbols

Touch Key to write in symbols.

Menu Tree

My V

erizon

My V

erizon

ssaging

MeMessaging

1. New Message

1. TXT Message

2. Picture Message

3. Video Message

4. Voice Message

2. Messages*

3. Drafts

4. Voicemail

5. Visual Voice Mail

6. Mobile IM

7. Email

8. Chat

9. Social Network Message

10. Settings

1. Messages View

2. Entry Mode

3. Text Entry Settings

4. Auto Save Sent

5. Auto Erase Inbox

6. Message Font Size

7. TXT Auto View

8. TXT Auto Scroll

9. Multimedia Auto Receive

10. Quick Text

11. Voicemail#

12. Callback#

13. Signature

14. Delivery Receipt

11. Erase Options

ont

actss

CCont

act

1. New Contact

2. Contact List

3. Backup Assistant

4. Favorites

5. Groups

6. Speed Dials

7. In Case of Emergency

8. My Name Card

ecent Calls

RRecent Calls

1. Missed

2. Received

3. Dialed

4. All

5. View Timers

Media C

enterer

Media C

ent

1. Music & Tones

1. V CAST Music | Rhapsody

2. Get New Ringtones

3. My Ringtones

4. My Music

5. My FM Radio

6. My Sounds

7. Sync Music

2. Picture & Video

1. V CAST Videos

2. Get New Pictures

3. My Pictures

4. My Videos

5. Take Picture

6. Record Video

7. Online Album

3. Games

1. Get New

Applications

2. Rock Band

3. The Sims 3

4. Browser

5. Browse & Download

* The submenu options Messages vary and depend on the Message View settings.

Menu Tree

1. Get New Applications

2. City ID

3. Bing

4. VZ Navigator

5. Visual Voice Mail

6. Mobile Email

7. Corporate Email

8. Backup Assistant

6. Extras

1. Get New Applications

7. Info

1. Memory

2. Music Memory

3. View Log

4. Help

5. About

My Music

1. Play All

2. Shop

3. Sync

4. FM Radio

5. All Songs

6. Playlists

7. Artists

8. Genres

9. Albums

10. Manage My Music

11. Music Settings

12. Music Alerts

ser

BrBroowwser

Searchch

Sear

1. Mobile Email

2. Corporate Email

3. Mobile Web Mail

VZ Na

vigattoror

VZ Na

viga

ools

TTools

1. Voice Commands

2. Calculator

3. Ez Tip Calculator

4. Calendar

5. Alarm Clock

6. Stopwatch

7. World Clock

8. Notepad

9. Drawing Pad

10. USB Mass Storage

tings

SeSetttings

1. My Verizon

2. Bluetooth Menu

3. Sounds Settings

1. Easy Set-up

2. Master Volume

3. Call Sounds

1. Call Ringtone

2. Call Vibrate

3. Caller ID Readout

4. Alert Sounds

1. TXT Message

2. Multimedia Message

3. Voicemail

4. Emergency Tone

5. Missed Call

5. Button Sounds

6. Digit Dial Readout

7. Service Alerts

1. ERI

2. Minute Beep

3. Call Connect

4. Charge Complete

8. Power On/Off

1. Power On Sound

2. Power On Vibrate

3. Power Off Sound

4. Power Off Vibrate

4. Display Settings

1. Easy Set-up

2. Banner

1. Personal Banner

2. ERI Banner

3. Backlight

4. Wallpaper

1. My Pictures

2. My Videos

3. Fun Animations

5. Charging Screen

6. Display Themes

7. Fonts

8. Dial Fonts

9. Clock Format

10. Shortcut Bin

11. Music Handle

5. Touch Settings

1. Auto Lock

2. Vibrate Type

3. Vibrate Level

4. Vibrate Effect

5. Sound

6. Calibration

6. Phone Settings

1. Airplane Mode

2. Voice Commands

1. Confirm Choices

2. Sensitivity

3. Adapt Voice

4. Prompt Mode

5. Audio Playback

6. Prompt Timeout

7. CLR Key

Activation

8. Info

3. Language

4. Location

5. Current Country

6. Security

1. Edit Codes

2. Restrictions

3. Phone Lock

4. Lock Phone Now

5. Reset Default

6. Restore Phone

7. System Select

8. NAM Select

7. Call Settings

1. Answer Options

2. Show Dialpad

3. Auto Retry

4. TTY Mode

5. One Touch Dial

6. Voice Privacy

7. DTMF Tones

8. Assisted Dialing

8. USB Auto Detection

9. Memory

1. Save Options

2. Phone Memory

3. Card Memory

10. Phone Info

1. My Number

2. SW/HW Version

3. Icon Glossary

4. Software Update

11. Set-up Wizard

Getting Started with Your Phone

The Battery

NOTE

It is important to fully charge the battery before initial use of the phone.

The phone comes with a rechargeable battery. The battery charge level is shown at the top of the LCD screen.

Installing the Battery

To install the battery, insert the edge with the battery contacts into the opening on the back of the phone. Push the battery down until it clicks into place, then attach the back cover.

Removing the Battery

Turn power off and slide the back cover down to remove it. Use the fingertip cutout at the edge of the battery to lift the edge of the battery to remove it.

and a USB data cable which connect together to charge your phone. To charge your phone:

NOTICE

Please use only an approved charging accessory to charge your LG phone. Improper handling of the charging port, as well as the use of an incompatible charger, may cause damage to your phone and void the warranty.

1. Connect the USB data cable into the cableless wall adapter, as shown below.

Cableless Wall Adapter

Gently uncover the phone's accessory/ charging port. Then plug the USB data cable (as shown in the next image) into the accessory/ charger port and the other end into an electrical outlet.

Charging the Battery

Your

Chocolate®TOUCH

comes with a cableless wall adapter

device

NOTICE

Please make sure that the 'B' side is facing up before inserting a charger or data cable into the charger port of your phone.

3. The charge time varies depending upon the battery level.

Charging with USB

You can use your computer to charge your phone. To be able to charge with the USB cable, you may need to have the necessary USB Driver installed on your PC first. Connect one end of the USB cable to the charging accessory port on your phone and the other end to a bus-powered USB port on your PC.

NOTE

Low-powered USB ports are not supported, such as the USB port on your keyboard or buspowered USB hub.

How to Install a microSDTMCard

2. Insert the microSD

card (purchased separately) with the logos facing up. Push in until it clicks into the slot. Please note that if you insert the card in the wrong direction, it may damage your phone or your card.

How to Remove a microSD

Card

1. Gently push the card in, this will release the exposed edge of the

microSD

2. Remove the microSD the slot and replace the cover.

card to eject it.

card from

microSDTMslot

1. Remove the back cover and locate the microSD

slot on

the left side.

NOTE

• Do not attempt to remove the

card while reading or writing

microSD to the card.

• Users wishing to transfer or download music onto a MicroSD phone (through either MTP Sync or Over the Air) should format the MicroSD handset before using it through (Menu -> Settings -> Memory -> Card Memory ->

card inserted into this

card on this

Getting Started with Your Phone

Format). Warning: Formatting the MicroSD card will erase all contents on the card. In the event the MicroSD phone without first formatting it, the phone will display “License acquisition failed” during OTA downloading or MTP Sync. Song files downloaded or otherwise purchased from third party providers and stored on a MicroSD be protected or encrypted by such provider and cannot be played on this device.

card is used on this

card inserted into this device may

Battery Temperature Protection

Though extremely rare, if the battery becomes overheated, the phone will automatically turn off. When you turn the phone back on, a message pops up alerting you that the phone was powered off for your safety.

Battery Charge Level

You can find the battery charge level at the top right of the LCD screen. When the charge level becomes low, the battery sensor sounds a warning tone, blinks the battery icon, and displays a warning message. As the charge level approaches empty, the phone automatically switches off without saving.

Turning the Phone On and Off

Turning the Phone On

1. Install a charged battery or

connect the phone to an external power source.

2. Press the PWR/END Key

for a few seconds until the Touch Screen lights up.

Turning the Phone Off

1. Unlock the Touch Screen by sliding

the Slide icon up to unlock or press the Unlock Key ( ) on the right side of your phone.

Press and hold the PWR/END

off.

Signal Strength

Call quality depends on the signal strength in your area. You can tell how much signal strength you have by the number of bars next to the signal strength icon: the more bars, the stronger the signal. If you’re having problems with signal quality, move to an open area or, when inside a building, try moving near a window.

Key until the display turns

Screen Icons

When the phone is on, the top line of the LCD screen displays phone status icons. To view what they mean:

1. Unlock the Touch Screen by sliding the Slide icon up to unlock or press the Unlock Key ( ) on the right side of your phone and touch the Menu Touch Soft Key .

2. Touch the Settings icon .

3. Scroll the list up, then touch

Phone Info

4. Touch

Icon Glossary

Making Calls

1. Unlock the Touch Screen by sliding the Slide icon up to unlock or press the Unlock Key ( ) on the right side of your phone.

2. Touch the Phone Touch Soft Key

, to display the dialpad you can use to dial. Enter the phone number you want to call.

NOTE

You can search your Contact List

ACTS

CONT

( ) or Recent Calls ( ) and select a number to

RECENT

call instead of manually dialing.

3. Press the SEND Key or touch the Call touch key to place the call.

4. Press the PWR/END Key

CALL

or touch the End touch key

END

to end the call.

Correcting Dialing Mistakes

If you make a mistake while dialing a number, touch the Clear touch

CLR

key once to erase the last digit entered, or hold the Clear touch key down for at least 2 seconds to delete all digits.

Redialing Calls

With the Touch Screen unlocked, press the SEND Key once to view a list of all of your recent calls. The last 270 calls (90 Received, 90 missed and 90 Dialed) are stored in the call history list. Touch the Dial touch key next to any of the entries to place a call to that number.

You can also press the SEND Key twice to redial the last number you dialed, received or missed in the call history.

Receiving Calls

1. When the phone rings and/or vibrates, unlock the Touch Screen by sliding the Slide icon

up, then touch the Answer touch key , or press the SEND Key.

2. Press the PWR/END Key to end the call.

Answer

Menu Tree on the Touch Screen

Menu Access

The Menu Touch Soft Key provides access to twelve phone

menus. To access the main menus, unlock first by pressing the unlock

key ( ) on the right side of your phone or sliding the Slide icon

up. Touch the Menu Touch Soft Key at the bottom of the screen

to open the main menus. To go back to Standby mode, touch the

Home touch key or press the Clear Key at the bottom

center of your phone.

The main menus are displayed as shown below. Touch any of the menu icons with your fingertip to go to that menu.

+ 302 hidden pages
