Veris VT7300 Installation Instructions

PIR Ready VT7300 Series

24 Vac Low Voltage Fan Coil Thermostats

For Commercial and Lodging HVAC Applications

(Issue Date: May 19, 2009 – 028-0183_R6)

Product overview

The VT7300 PI thermostat family is specifically designed for fan coil control.
The product features a backlit LCD display with dedicated function menu
buttons for simple operation. Accurate temperature control is achieved due
to the product’s PI proportional control algorithm, which virtually eliminates
temperature offset associated with traditional, differential-based
thermostats.

Models are available for On/Off, 3 point floating and analog 0 to 10 Vdc
control and can control up to three fan speed. Three additional inputs are
also provided for monitoring and / or various advanced functions.

All models feature configurable System and Fan button functions to meet all

VT73x5X Lodging VT73x0X Commercial

possible applications. They all contain an SPST auxiliary switch that can be
used to control lighting or auxiliary reheat.

The thermostats are also compatible with the new Viconics PIR cover accessories. Thermostats equipped with a
PIR cover provide advanced active occupancy logic, which will automatically switch occupancy levels from
Occupied to Stand-By and Unoccupied as required by local activity being present or not. This advanced
occupancy functionality provides advantageous energy savings during occupied hours without sacrificing occupant
comfort. All thermostats can be ordered with or without a factory installed PIR cover ( see ordering notes below ).

The additional following documents are available at: www.viconics.com

• PIR application information and examples, are available on document: APP-PIR-Guide-Exx

• PIR cover installation information is available on document: PIR Cover Installation-Exx

• Information on the LON models (VT73xxX5x00E), is available on document ITG-VT72_73-PIR-LON-Exx

• Information on the BACnet models (VT73xxX5x00B), is available on document ITG-VT72_73-PIR-BAC-Exx

• Information on the Wireless models (VT73xxX5x00W), is available on documents: ITG-VWG-40-BAC-Exx and LIT-VWG-40-SETUP-Exx

Models available

Viconics

Part

Numbers

Application

RH sensor
Market Commercial / Institution Hotels / Lodging

Ordering Information Notes:

- (X) model number represents available communication options: X=none for Stand-alone, X=B for BACnet MS-TP, X=E for Echelon and X=W for Wireless

- Thermostats can be ordered with a factory installed PIR cover. Please use (5500) extension instead of the (5000) only extension.: Ex. VT7300C5500E.

- Thermostats ordered without a PIR cover can be retrofitted with a separate PIR accessory cover afterwards when required

Features and benefits

VT7300A5x00(X)

2 & 4

Pipes

On/Off

No No Yes No No Yes No Yes No Yes

VT7300C5x00(X)

2 & 4 Pipes

Floating & On/Off

VT7350C5x00(X)

VT7305A5x00(X)

2 & 4

Pipes

On/Off

VT7305C5x00(X)

2 & 4 Pipes

Floating & On/Off

VT7355C5x00(X)

VT7300F5x00(X)

Commercial /

Institution

VT7350F5x00(X)

2 & 4 Pipes

Analog 0-10 Vdc

VT7305F5x00(X)

Hotels / Lodging

VT7355F5x00(X)

Features Benefits

• Models available with internal humidity sensing ⇒ Increased occupant comfort through dehumidification

• Advanced occupancy functions ⇒ Through the network or smart local occupancy sensing

• Ready for PIR accessory cover ⇒ Fully integrated advanced occupancy functionality

• 3 configurable inputs ⇒ Adds functionality

• Configurable sequences of operation ⇒ Single model meets more applications

• Configurable fan functions button ⇒ Meets more applications with a single model

• Unique configuration setup utility ⇒ Minimizes parameter tampering

• Multi level lockable keypad ⇒ Tamper proof, no need for thermostat guards

• Auto Fan speed mode

• Available for 24 Vac On/Off, Floating or Analog control ⇒ Meet advanced applications requirements

• Auxiliary output ⇒ Can be used for lighting or reheat

028-0183 R6_LIT-VT7300-PIR-E06.doc www.viconics.com / [e-mail]

⇒ Increased occupant comfort in cooling mode by reducing

humidity and offer less fan noise in all mode of operation

Programmable BI/UI inputs overview

Binary input #1 can be configured for the following
functions:

1. (None): No function will be associated with the
input

2. (Rem NSB): remote NSB timer clock input. The

scheduling will now be set as per the binary input.
It provides low cost setback operation via a dry
contact

• Contact opened = Occupied

• Contact closed = Unoccupied

3. (Motion NO) and (Motion NC): Advanced PIR
occupancy functions using a Normally Open (NO)
or Normally Closed (NC) remote PIR motion
sensor. Occupancy mode is now set as per applied
PIR function and configuration. Application
information and examples, are available on
document: APP-PIR-Guide-Exx. This document will
provide the installers and system designers with
detailed examples on applications, parameter
configuration information, sequence of operation,
troubleshooting and diagnostic help required for the
proper usage of the PIR accessory covers

4. (Window) EMS: Forces the system to disable any
current heating or cooling action by the thermostat.
The mode stays the same and the current setpoints
are the same Occupied setpoints. Only the outputs
are disabled. There is a Door/Window alarm
displayed on the thermostat to indicate to the local
tenant that the door/window needs to be closed for
cooling or heating to resume. Use NC contact.

• Contact opened = System disabled with local

Window alarm

• Contact closed = System enabled

Binary input #2 can be configured for the following
functions:

1. (None): No function will be associated with the

input

2. (Door Dry) Door contact & Motion detector:
This configuration is only functional if binary input
#1 is set to Motion NO or Motion NC or a PIR
accessory cover is used.

With this sequence enabled, the occupancy is now
dictated through those 2 inputs. Any motion
detected will set the zone to occupied status. The
zone will remain permanently in occupied mode
until the door contact switch opens momentarily.
The thermostat will then go in stand-by mode. If
more movements are detected, the occupied mode
will resume. While the door is opened, any
movements detected by the remote PIR sensor or
the PIR accessory cover will be ignored. Use a
Normally Closed contact switching device.

• Contact opened = Door opened

• Contact closed = Door closed

2

3. (RemOVR): temporary occupancy remote override
contact. This function disables the central button
override function on the thermostat. The override
function is now controlled by a manual remote
momentarily closed contact. When configured in
this mode, the input operates in a toggle mode.

It is now possible to toggle between unoccupied &
occupied setpoints for the amount of time set by
parameter (TOccTime) temporary occupancy time.

4. (Filter): a backlit flashing Filter alarm will be
displayed on the thermostat LCD screen when the
input is energized. It can be tied to a differential
pressure switch that monitor filters

• Contact opened = No alarm

• Contact closed = Alarm displayed

5. (Service): a backlit flashing Service alarm will be
displayed on the thermostat LCD screen when the
input is energized. It can be tied in to the AC unit
control card, which provides an alarm in case of
malfunction.

• Contact opened = No alarm

• Contact closed = Alarm displayed

Universal input #3 can be configured for the
following functions:

1. (None): No function will be associated with the
input

2. (COC/NH) Change over dry contact. Normally
Heat: Used for hot / cold water change over
switching in 2 pipe systems.

• Contact closed = Cold water present

• Contact opened = Hot water present

Only used and valid if system is setup as 2 pipes.
Parameter ( Pipe No ) set as 2 pipes.

3. (COC/NC) Change over dry contact. Normally
Cool: Used for hot / cold water or air change over
switching in 2 pipe systems.

• Contact closed = Hot water present

• Contact opened = Cold water present

Only used and valid if system is setup as 2 pipes.
Parameter ( Pipe No ) set as 2 pipes.

4. (COS) Change over analog sensor: Used for hot
/ cold water or air change over switching in 2 pipe
systems.
Only used and valid if system is setup as 2 pipes.
Parameter ( Pipe No ) set as 2 pipes.

• If temperature is > 77 °F = Hot water present

• If temperature is < 75 °F = Cold water present

5. (SS) Supply air sensor monitoring: Used for
supply air temperature monitoring.
Only used for network reporting of the supply air
temperature. Has no internal function in the
thermostat.

.

Installation

• Remove security screw on the bottom of thermostat cover.

• Open up by pulling on the bottom side of thermostat.

• Remove Assembly and remove wiring terminals from sticker. (Fig. 3)

• Please note the FCC ID and IC label installed in the cover upon

removal of cover for the wireless products.

A) Location:
1- Should not

be installed on an outside wall.
2- Must be installed away from any heat source.
3- Should not be installed near an air discharge grill.
4- Should not be affected by direct sun radiation.
5- Nothing must restrain vertical air circulation to the thermostat.

B) Installation:
1- Swing open the thermostat PCB to the left by pressing the PCB

locking tabs. (Fig. 4)
2- Pull out cables 6” out of the wall.
3- Wall surface must be flat and clean.
4- Insert cable in the central hole of the base.
5- Align the base and mark the location of the two mounting holes

on the wall. Install proper side of base up.
6- Install anchors in the wall.
7- Insert screws in mounting holes on each side of the base.

(Fig. 4)
8- Gently swing back the circuit board on the base and push on it

until the tabs lock it.
10- Strip each wire 1/4 inch.
11- Insert each wire according to wiring diagram.
13- Gently push back into hole excess wring (Fig. 5)
14- Re-Install wiring terminals in correct location. (Fig. 5)
15- Reinstall the cover (top side first) and gently push back extra

wire length into the hole in the wall.
16- Install security screw.

• If replacing an old thermostat, label the wires before
removal of the old thermostat.

• Electronic controls are static sensitive devices.
Discharge yourself properly before manipulation and
installing the thermostat.

• Short circuit or wrong wiring may permanently damage
the thermostat or the equipment.

• Anti-short cycling can be set to 0 minutes for equipment
that posses their own anti cycling timer. Do not use that
value unless the equipment is equipped with such
internal timer. Failure to do so can damage the
equipment.

• All VT7000 series thermostats are to be used only as

operating controls. Whenever a control failure could
lead to personal injury and/or loss of property, it
becomes the responsibility of the user to add safety
devices and/or alarm system to protect against such
catastrophic failures.

Fig.3

Fig.5

3

Location of PCB retaining tabs

Fig.4

Re-install terminal blocks

Thermostat assembly

(VT7300F5000B shown)

Fig.6

V

V

V

V

V

X

X

Terminal identification

iconics Part Numbers

Description / Application 2 & 4 Pipe On/Off 2 & 4 Pipe Floating Description / Application 2 & 4 Pipe Analog

T73xxA5x00(x)

T73xxC5x00(x)

2 & 4 Pipe On/Off

iconics Number

T73xxF5x00(x)

4

Internal Temperature X
Internal Humidity

1- High Fan Speed
2- Medium Fan Speed
3- Low Fan Speed Fan-L Fan-L 3- Low Fan Speed Fan-L
4- 24 V~ Hot 24 V~ Hot 24 V~ Hot 4- 24 V~ Hot 24 V~ Hot
5- 24 V~ Com

6- Aux BO 5
7- Aux BO 5
8- BO 3 Open Heat BO 3 BO 3

9- BO 4 Close Heat
10- BO 1 Open Cool
11- BO 2 Close Cool
12- BI #1 BI 1 BI 1 12- BI #1 BI 1
13- RS RS RS 13- RS RS
14- Scom
15- BI #2
16- UI #3 COS / COC /SS

Fan-H Fan-H
Fan-M Fan-M

24 V~ Com 24 V~ Com

BO 5-Aux BO 5-Aux
BO 5-Aux BO 5-Aux

BO 2 BO 2

Scom Scom

BI 2 BI 2
UI 3 UI 3

Model Dependent

BO 4

BO 1

Internal Temperature
Internal Humidity

1- High Fan Speed
2- Medium Fan Speed

5- 24 V~ Com

6- Aux BO 5
7- Aux BO 5

9- AO 2 Heat
10- AO 1 Cool
Not used Blank Blank

14- Scom
15- BI #2
16- UI #3 COS / COC /SS

Model Dependent

Fan-H
Fan-M

24 V~ Com

BO 5-Aux
BO 5-Aux

AO 2
AO 1

Scom

BI 2
UI 3

Wiring

Power & Fan ( All models )

24 V~ transformer relay pack
3 speed 2 speed Single speed

Fan-H
Fan-M
Fan-L

High

Med

Low

High

Low

High

24 V~ Hot
24 V~ Com

Remote inputs ( All models )

BI 1
RS
Scom

Remote wall sensor

- S3010W1000

- S3020W1000

BI 2
UI 3

Contact

- Door

- Remote Override

- Filter alarm

- service alarm

Contact

- Rem NSB

- Motion

- Window

SS ( supply sensor )

- S1010E1000

- S2000D1000

COS ( changeover sensor )

- S1010E1000

OR

COC/NH

- Normally heat

- Closed contact = cold water

COC/NC

- Normally cool

- Closed contact = heat water

Auxiliary output ( All models )

- Dry contact to end device 24 V~ maximum
#4 24 V~ Hot

#5 24 V~ Com

R

#6
#7

- 24 Vac power to relay
#4 24 V~ Hot
#5 24 V~ Com
#6
#7

R

A

2

2

A

A

Main outputs wiring

VT7300A5x00(x) & VT7305AC5x00(x)

24 V~ Hot
24 V~ Com

BO2

VT7300C5x00(x), VT7305C5x00(x), VT7350C5x00(x) & VT7355C5x00(x)

24 V~ Hot
24 V~ Com

BO1
BO2

VT7300C5x00(x), VT7305C5x00(x), VT7350C5x00(x) & VT7355C5x00(x)

24 V~ Hot
24 V~ Com

BO1
BO2

2 Pipe applications 4 Pipe applications

On-Off control

24 V~ Hot
24 V~ Com

24 Vac

N.C. Heating / Cooling valve

24 Vac

24 Vac
Com

Com

BO3

BO2

24 Vac
Com

Com

24 Vac

24 Vac
Com

Com

24 V~ Hot
24 V~ Com
BO3

if N.O.

OR

if N.C.
if N.O.
if N.C.

OR

OR

OR

if N.O.
if N.C.

OR

Heating / Cooling valve

24 Vac
Com

BO4
BO1
BO2

Floating control

24 V~ Hot
24 V~ Com
BO3

Heating / Cooling valve

Open
Com
Close

BO4
BO1
BO2

Open
Com
Close

Open
Com
Close

N.O. Heating valve
N.C. Cooling valve

24 Vac

24 Vac
Com

Com

24 Vac

24 Vac
Com

Com

Heating valve

Heating valve
Cooling valve

Cooling valve

Heating valve
Cooling valve

5

Analog control

VT7300F5x00(x), VT7305F5x00(x), VT7350F5x00(x) & VT7355F5x00(x)

24 V~ Hot
24 V~ Com

Heating / Cooling valve

Com
24 Vac

O 1

0-10 Vdc

4 V~ Hot
4 V~ Com

O 2
O 1

Com
24 Vac
0-10 Vdc

Com
24 Vac
0-10 Vdc

Heating valve
Cooling valve

Typical applications

Schematic Wiring Settings

2 pipe system cooling and/or heating: VT7300A5x00(x), VT7300C5x00(x) & VT7305C5x00(x) On / Off N.C. actuator

Normally Closed On/Off

Valve Cooling and/or Heating

3 Speed fan

Room Temperature

Fan-H

Fan-M

Fan-L

UI3 COS

24 V~ Com

24 V~ Hot

BO2 N.C.

24 Vac f an relays

High

Med

Low

Control Thermostat

Mandatory

• Pipe no = 2 pipes

• CntrltT yp = On/Off

• Fan Menu = 0 (L-M-H)

• FL time = as per actuator

If cooling only set::

• SeqOpera = 0 Cooling only
If heating only set::

• SeqOpera = 1 Heating only
If heat / cool auto-changeover with

a local water temperature sensor set:

• SeqOpera = 0 Cooling only

Optional supply water

temper at ure sensor

• UI3 = COS

2 pipe system cooling and/or heating: VT7300C5x00(x) & VT7305C5x00(x) Floating actuator

Modulating Floating

Valve Cooling and/or Heating

3 Speed fan

Room Temperature
Control Thermostat

Fan-H

Fan-M

Fan-L

UI3 COS

24 V~ Com

24 V~ Hot

BO1 Open

BO2 Close

24 Vac f an relays

High

Med

Low

Mandatory

• Pipe no = 2 pipes

• CntrltTyp = Floating

• Fan Menu = 0 (L-M-H)

• FL time = as per actuator

If cooling only set::

• SeqOpera = 0 Cooling only
If heating only set::

• SeqOpera = 1 Heating only
If heat / cool auto-changeover with

a local water temperature sensor set:

• SeqOpera = 0 Cooling only

Optional supply water

temper at ure sensor

• UI3 = COS

6

2 pipe system cooling and/or heating: VT7300F5x00(x) & VT7305F5x00(x) Analog actuator

Modulating Analog

Valve Cooling and/or Heating

3 Speed fan

Room Temperature

Fan-H
Fan-M

Fan-L

UI3 COS
0 V~ Com
24 V~ Hot

AO1

24 Vac f an relays

High

Med

Low

Control Thermostat

0 to 10

Vdc

Mandatory

• Pipe no = 2 pipes

• Fan Menu = 0 (L-M-H)

• RA/DA = as per actuator

If cooling only set::

• SeqOpera = 0 Cooling only
If heating only set::

• SeqOpera = 1 Heating only
If heat / cool auto-changeover with

a local water temperature sensor set:

• SeqOpera = 0 Cooling only

• UI3 = COS

Optional supply water

temper at ure sensor

Schematic Wiring Settings

4 pipe system cooling and heating: VT7300C5x00(x) & VT7305C5x00(x) On / Off N.C. actuators

Normally Closed On/Off

Valve Cooling and Heating

3 Speed fan

Room Temperature
Control Thermostat

Fan-H

Fan-M

Fan-L

24 V~ Com

24 V~ Hot

BO2 Close
BO4 Close

24 Vac f an relays

High

Med

Low

Mandatory

• Pipe no = 4 pipes

• CntrltTyp = On/Off

• Fan Menu = 0 (L-M-H)

• FL time = as per actuator

• SeqOpera = 4 Cool/Heat

CoolingHeating

4 pipe system cooling and heating: VT7300C5x00(x) & VT7305C5x00(x) Floating actuators

Modulating Floating

Valve Cooling and Heating

3 Speed fan

Room Temperature
Control Thermostat

Fan-H

Fan-M

Fan-L

24 V~ Com

24 V~ Hot

BO1 Open

BO2 Close

BO3 Open

BO4 Close

24 Vac f an relays

High

Med

Low

Heating

Mandatory

• Pipe no = 4 pipes

• CntrltTyp = Floating

• Fan Menu = 0 (L-M-H)

• FL time = as per actuator

• SeqOpera = 4 Cool/Heat

Cooling

7

4 pipe system cooling and heating: VT7300F5x00(x) & VT7305F5x00(x) Analog actuators

Modulating Analog

Valve Cooling and Heating

3 Speed fan

Room Temperature
Contro l Thermostat

Fan-H
Fan-M
Fan-L

24 V~ Com

24 V~ Hot

AO1

AO2

24 Vac f an relays

High

Med

Low

0 to 10

Vdc

Heating

0 to 10

Vdc

Cooling

Mandatory

• Pipe no = 4 pipes

• Fan Menu = 0 (L-M-H)

• RA/DA = as per actuator

• SeqOpera = 4 Cool/Heat

2 pipe system cooling or heating with reheat: VT7300C5x00(x) & VT7305C5x00(x) Floating actuator

Modulating Floating

Valve Cooling and/or Heating

3 Speed fan

Electric
Reheat

Room Temperature
Control Thermostat

BO5
BO5

Fan-H
Fan-M

Fan-L

UI3 COS

24 V~ Com

24 V~ Hot

BO1 Open

BO2 Close

High

Med

Low

24 Vac fan re lays

Mandatory

• Pipe no = 2 pipes

• CntrltTyp = Floating

• Fan Menu = 0 (L-M-H)

• FL time = as per actuator

• SeqOpera = 2 Cool/Reheat

• UI3 = COS

Optional supply water

temperature s ensor

r

Remote sensor accessories

Model no. Description

S3010W1000 Wall mounted temperature sensor
S3020W1000

Wall mounted temperature sensor with override button and

occupancy status LED
S2060A1000 Averaging temperature sensor
S2000D1000 Duct mounted temperature sensor

Remote mount temperature sensors use 10K type 2 NTC thermistors.
Features:

• Each sensor can be configured for various averaging combinations

• Optional occupancy led

• Optional override key

Wiring example of single remote room sensor:

VT7300 Series
Thermostat

Scom

RS

BO 5

24 Vac

Com

BI 2

S3020W1000
Remote wiring 1 sensor

S2=On, S3=On

ScomRSScom

RS

Aux

C
DI

OR

S3010W1000
Remote wiring 1 sensor

S2=On, S3=On

ScomRSScom

RS

FIG.8 – S3020W1000 WALL

MOUNTED SENSOR

Dip switch

ON

setting for:

2

1 senso

1

8

S2-1 = ON
S2-2 = ON

Wiring examples of 2 remote room sensors for averaging applications:

VT7300 Series
Thermostat

Scom

RS

BO 5

24 Vac

Com

BI 2

VT7300 Series
Thermostat

Scom

RS

1 x S3010W1000 and 1 x S3020W1000
Remote wiring 2 sensors

S1=On, S2=Off

ScomRSScom

RS
Aux

C
DI

2 x S3010W1000
Remote wiring 2 sensors

S2=On, S3=Off

ScomRSScom

RS

ScomRSScom

RS

ScomRSScom

RS

Notes for averaging applications:

• S3010W1000 and S3020W1000 can be
mixed matched.

• S3010W1000 and S3020W1000 are to
be wired in parallel.

• Respect the dip switch setting in each
remote sensor.

VT7300 Series
Thermostat

Scom

RS

BO 5

24 Vac

Com

BI 2

Wiring examples of 3 remote room sensors for averaging applications:

VT7300 Series
Thermostat

Scom

RS

BO 5

24 Vac

Com

BI 2

Temperature vs resistance chart for 10 Kohm NTC thermistor (R

2x S3010W1000 and 1 x S3020W1000
Remote wiring 3 sensors

VT7300 Series
Thermostat

S2=Off, S 3 =Off

ScomRSScom

RS

Aux

C

DI

ºC ºF Kohm ºC ºF Kohm ºC ºF Kohm ºC ºF Kohm ºC ºF Kohm

-40 -40 324.3197 -20 -4 94.5149 0 32 32.1910 20 68 12.4601 40 104 5.3467

-35 -31 234.4009 -15 5 71.2430 5 41 25.1119 25 77 10.0000 45 113 4.3881

-30 -22 171.3474 -10 14 54.1988 10 50 19.7390 30 86 8.0694 50 122 3.6202

-25 -13 126.6109 -5 23 41.5956 15 59 15.6286 35 95 6.5499 55 131 3.0016

ScomRSScom

RS

ScomRSScom

RS

Scom

RS

= 10KΩ±3%, B

25°C

2 x S3020W1000
Remote wiring 2 sensors

S2=On, S3=Off

ScomRSScom

RS
Aux

C
DI

ScomRSScom

RS

Aux

Dip switch
setting for:

2 sensors

C
DI

ON

2

1

S2-1 = OFF
S2-2 = ON

3x S3010W1000
Remote wiring 3 sensors

S2=Off, S3= Off

ON

2

1

ScomRSScom

S2-1 = OFF

ScomRSScom

RS

ScomRSScom

RS

Dip switch

setting for:

3 sensors

= 3975K±1.5%)

25/85°C

RS

-

=

Programming and status display instructions
Status display

The thermostat features a two-line, eight-character display. There is a low level backlight level that is always active and
can only be seen at night.

When left unattended, the thermostat has an auto scrolling display that shows the actual status of the system. There is
an option in the configuration menu to lockout the scrolling display and to only present the room temperature and
conditional outdoor temperature to the user. With this option enabled, no local status is given of mode, occupancy and
relative humidity.

Each item is scrolled one by one with the back lighting in low level mode. Pressing any key will cause the back light to
come on to high level. When left unattended for 10 seconds after changes are made, the display will resume automatic
status display scrolling.

To turn on the back light to high level, press any key on the front panel. The back lit display will return to low level when
the thermostat is left unattended for 45 seconds

Sequence of auto-scroll status display:

Room & Humidity System Mode Schedule Status Outdoor Temperature Alarms

x.x °C or °F Sys mode Occupied Outdoor Service
XX % RH Auto x.x °C or°F

If humidity display
enabled

RoomTemp
x.x °C or °F

If humidity display is not
enabled

Sys mode
Cool

Sys mode
heat

Sys mode
off

Stand-By

Unoccup

Override

Network value only

Filter

Window

% RH display is conditional to:
(Humidity display is model and configuration dependent)

• Model with RH sensor built in

• Display function can be enabled with RH display parameter. Displayed range is 10 to 90 % RH

Outdoor air temperature

• Display is only enabled when outdoor air temperature network variable is received.

Occupancy Status

• Occupied, Stand-By, Unoccupied and Override status are displayed on the scrolling display.

Alarms

• If alarms are detected, they will automatically be displayed at the end of the status display scroll.

• During an alarm message display, the backlit screen will light up at the same time as the message and shut off

during the rest of the status display.

• Two alarms maximum can appear at any given time. The priority for the alarms is as follows:

Service
Filter

Window

Three status LED’s on the thermostat cover are used to indicate the status of the fan ( any speed ), a call for heat, or a call for
cooling.

Fan coil models

• When any of the fan speeds are ON,
the FAN LED will illuminate.

• When heating & reheat is ON,
the HEAT LED will illuminate.

• When cooling is ON,
the COOL LED will illuminate.

Indicates that there is a service alarm as per one of the programmable binary input ( BI2 )
Indicates that the filters are dirty as per one of the programmable binary input ( BI2 )
Indicates that the outside window or door is opened and that the thermostat has cancelled any cooling or
heating action ( BI1 )

Fig.11 – Hotel models °C/°F Fig. 12 Commercial models with Override

9

User interface

• Unoccupied mode Override

An Override can be made on commercial models during an Unoccupied period. If the Override option is enabled in the
lockout configuration pressing the middle override button will resume occupied setpoints for a time specified by
parameter ToccTime

• Local Keypad interface

Is used to toggle between the different system mode available as per sequence and menu selected

System

Pressing repetitively the button will toggle between all the available modes
Available menus are dependent on selected sequence of operation

Is used to toggle between the different fan mode available as per sequence and menu selected

Fan

Pressing repetitively the button will toggle between all the available modes
Available menus are dependent on selected sequence of operation and menu selected for Fan

°C/°F

Override

 Middle key is

• °C / °F for Hotel models

• Override for commercial models

Adjust the setpoints down

Down

 In cooling mode only the cooling setpoint displayed,
 In heating mode only the heating setpoint displayed
 In auto mode, (See below)

Adjust the setpoints up

Up

 In cooling mode only the cooling setpoint displayed,
 In heating mode only the heating setpoint displayed
 In auto mode, (See below)

• Any setpoint change can be permanent or temporary based on configuration parameter (Setpoint Type)

• Any setpoint written through the network, will be permanent and cancel any active temporary setpoints

• Lockouts of access to certain functions is made with configuration parameter (lockout)

• Local Setpoint Adjustment when “Stp Func” = Dual Stp ( Dual Occupied Setpoints Adjustment )

Occupied setpoint adjustments

Auto Mode

Cooling mode Heating mode Off mode

Cool XX.X
°F or °C

Heat XX.X
°F or °C

No access
to setpoint

• Setpoint presented to user is the setpoint from the last action taken by the
thermostat or the one currently in use.

• If the other setpoint is the one desired, then the MODE button is used to
toggle between the current displayed one and the other.

Cool XX.X °F or °C or Heat XX.X °F or °C

Toggle to ( Heat or Cool )with MODE button

• Heat/Cool setpoint toggle with MODE button to be active only in AUTO mode.

• If cooling, heating or off mode is active, function is disabled

• Local Setpoint Adjustment when “Stp Func” = AttchStp (Single Occupied SetpointAdjustment )

Occupied setpoint adjustments

Auto Mode

• Setpoint presented to user is the setpoint from the last action taken by

Cooling mode Heating mode Off mode

Cool XX.X
°F or °C

Heat XX.X
°F or °C

No access to
setpoint

• Unoccupied and Stand-By setpoints adjustments

Setting the stand-by and unoccupied setpoints is done through the network or through configuration setup only.

the thermostat or the one currently in use.

• Both heating and cooling setpoint are changed simultaneously while
respecting the minimum configured deadband

• If the other setpoint is the one desired, then the MODE button is used to
toggle between the current displayed one and the other.

Cool XX.X °F or °C and Heat XX.X °F or °C

Both heating & cooling setpoints are change simultaneously
Toggle to ( Heat or Cool )with MODE button

10

11

• Mode button menu sequence.

- Modes presented to the user are dependent on sequence of operation selected

- Default mode is in bold when sequence of operation parameter is changed

AutoMode set to On = Auto system mode active.

Sequence selected Mode Menu

0 = Cooling only
1 = Heating only
2 = Cooling With Reheat
3 = Heating With Reheat Off - Heat
4 = Cooling / Heating 4 pipes
5 = Cooling / Heating 4 pipes with Reheat

Off - Cool
Off - Heat
Off – Auto – Heat – Cool

Off – Auto – Heat – Cool
Off – Auto – Heat – Cool

AutoMode set to Off = Auto system mode NOT active.

Sequence selected Mode Menu

0 = Cooling only
1 = Heating only
2 = Cooling With Reheat
3 = Heating With Reheat
4 = Cooling / Heating 4 pipes
5 = Cooling / Heating 4 pipes with Reheat

• Available fan button menu sequences.

Fan button menu
configuration
0 Low-Med-High 3 Speed configuration using 3 fan relays ( L-M-H )
1 Low-High 2 Speed configuration using 2 fan relays ( L-H )
2 Low-Med-High-Auto 3 Speed configuration with Auto fan speed mode using 3 fan relays ( L-M-H )
3 Low-High-Auto 2 Speed configuration with Auto fan speed mode using 2 fan relays ( L-H )
4 On-Auto Single Speed configuration. Auto is for Fan on demand / On is On all the time

Menu presented are dependent on model used

and sequence of operation selected

Auto speed fan mode is also offered in heating mode applications; it will not however have any effect on
dehumidification. It will be strictly for noise comfort issues

Auto Speed Fan Mode operation for sequences 2 and 3 is dependent on Auto Fan parameter. When Auto Fan is set to:

• AS ( Default ) = Auto Speed during occupied periods. Fan is always on during occupied periods. Low,

medium and high speeds operate on temperature offset from setpoint.

• AS AD = Auto Speed / Auto Demand during occupied periods.

- Medium and high speeds operate on temperature offset from setpoint.

- Low speed operates on demand and will shut down when no demand is present

Installer configuration parameter menu

Configuration can be done through the network or locally at the thermostat.

• To enter configuration, press and hold the middle button (°C/°F or Override) for 8 seconds

• If a password lockout is active, “Password” is prompted. Enter password value using the “up” and “down” arrows

and press the middle button again to gain access to all configuration properties of the thermostat. A wrong
password entered will prevent local access to the configuration menu.

• Press the same middle button repetitively to scroll between all the available parameters

• Use the up and down key to change the parameter to the desired value.

• To acknowledge and save the new value, press the middle button again.

• The next listed parameter is now displayed

Configuration interface

Fan
°C/°F
Override
Down
Up

Re-starts the configuration parameter list at the beginning
Enters the configuration mode. Press and hold for 8 seconds
Pressing repetitively will scroll all available parameters one by one
Adjust / rotate parameter value down
Adjust / rotate parameter value up

Off - Cool
Off - Heat
Off – Heat – Cool
Off - Heat
Off – Heat – Cool
Off – Heat – Cool

Default value when
sequence toggled

High
High
High
High
Auto

Configuration parameters
Default value
PswrdSet

Configuration parameters menu
access password
Default value = 0

Range is: 0 to 1000
Com Addr

Thermostat networking address
Default value = 254
Range is: 0 to 254

PAN ID

Personal Area Network
Identification
Default value = 0
Range is: 0 to 500

12

Significance and adjustments

This parameter sets a protective access password to prevent unauthorized access
to the configuration menu parameters. A default value of “0” will not prompt a
password or lock the access to the configuration menu.

Range is: 0 to 1000

Conditional parameter to BACnet MS-TP models (VT73xxX5x00B)
Conditional parameter to Wireless models (VT73xxX5x00W)

• For BACnet MS-TP models valid range to use is from 1 to 127. Default value of

254 disables BACnet communication for the thermostat.

• For wireless models valid range is 0 to 254 with a maximum of 30 thermostat

per VWG

Conditional parameter to Wireless models (VT73xxX5x00W)

This parameter will only appear when a wireless network adapter is present. If the
thermostat is installed as a stand-alone unit or with a BACnet or Echelon adapter,
this parameter will not be used or displayed

This parameter (Personal Area Network Identification) is used to link specific
thermostats to a single specific Viconics wireless gateway ( VWG ) For every
thermostat reporting to a gateway ( maximum of 30 thermostats per gateway ), be
sure you set the SAME PAN ID value both at the gateway and the thermostat(s).

Channel

Channel selection
Default value = 10

Range is: 10 to 26

Get From

Thermostat Get From another
device configuration utility
Default value = 0
Range is: 0 to 254

The default value of 0 is NOT a valid PAN ID. The valid range of available PAN ID
is from 1 to 500

Conditional parameter to Wireless models (VT73xxX5x00W)

This parameter will only appear when a wireless network adapter is present. If the
thermostat is installed as a stand-alone unit or with a BACnet or Echelon adapter,
this parameter will not be used or displayed

This parameter (Channel) is used to link specific thermostats to specific Viconics
wireless gateway(s) ( VWG ) For every thermostat reporting to a gateway (
maximum of 30 thermostats per gateway ), be sure you set the SAME channel
value both at the gateway and the thermostat(s).

Viconics recommends using only the 2 last channels ( 25-2575MHz and 26­2580MHz )

The default value of 10 is NOT a valid channel. The valid range of available
channel is from 11 to 26

Conditional parameter to Wireless models (VT73xxX5x00W)

This parameter / function is not currently supported by the wireless
thermostats.

BI1

Binary input no.1 configuration
Default value = None

BI2

Binary input no.2 configuration
Default value = None

(None): No function will be associated with the input
(Rem NSB): remote NSB timer clock input. The scheduling will now be set as per

the binary input. It provides low cost setback operation via a dry contact
Contact opened = Occupied
Contact closed = Unoccupied

(Motion NO) or (Motion NC): Advanced PIR occupancy functions using a
Normally Open (NO) or Normally Closed (NC) remote PIR motion sensor.
Occupancy mode is now set as per applied PIR function and configuration.
Application information and examples are available on document: APP-PIR-Guide-
Exx. This document will provide the installers and system designers with detailed
examples on applications, parameter configuration information, sequence of
operation, troubleshooting and diagnostic help required for the proper usage of the
PIR accessory covers

(Window) EMS: Forces the system to disable any current heating or cooling action
by the thermostat. The mode stays the same and the current setpoints are the
same Occupied setpoints. Only the outputs are disabled. There is a Door/Window
alarm displayed on the thermostat to indicate to the local tenant that the
door/window needs to be closed for cooling or heating to resume.

* these settings will disable the local override function on the thermostat.

(None): No function will be associated with the input
(Door Dry) Door contact & Motion detector: This configuration is only functional

if binary input #1 is set to Motion NO or Motion NC or a PIR accessory cover is
used.

With this sequence enabled, the occupancy is now dictated through those 2 inputs.
Any motion detected will set the zone to occupied status. The zone will remain
permanently in occupied mode until the door contact switch opens momentarily.
The thermostat will then go in stand-by mode. If more movements are detected,
the occupied mode will resume. While the door is opened, any movements
detected by the remote PIR sensor or the PIR accessory cover will be ignored.
Use a Normally Closed contact switching device.

Contact opened = Door opened

Contact closed = Door closed
(RemOVR): temporary occupancy remote override contact. This function disables
the central button override function on the thermostat. The override function is now
controlled by a manual remote momentarily closed contact. When configured in
this mode, the input operates in a toggle mode.

It is now possible to toggle between unoccupied & occupied setpoints for the
amount of time set by parameter (TOccTime) temporary occupancy time.

(Filter): a backlit flashing Filter alarm will be displayed on the thermostat LCD
screen when the input is energized. It can be tied to a differential pressure switch
that monitor filters

Contact opened = No alarm
Contact closed = Alarm displayed

(Service): a backlit flashing Service alarm will be displayed on the thermostat LCD
screen when the input is energized. It can be tied in to the AC unit control card,
which provides an alarm in case of malfunction.

Contact opened = No alarm
Contact closed = Alarm displayed

13

UI3

Universal input no.3 configuration
Default value = None

(None): No function will be associated with the input
(COC/NH) Change over dry contact. Normally Heat: Used for hot / cold water or

air change over switching in 2 pipe systems.
Contact closed = Cold water or air present
Contact opened = Hot water or air present
Only used and valid if system is setup as 2 pipes. Parameter ( Pipe No ) set as 2
pipes.

(COC/NC) Change over dry contact. Normally Cool: Used for hot / cold water or
air change over switching in 2 pipe systems.
Contact closed = Hot water present
Contact opened = Cold water present
Only used and valid if system is setup as 2 pipes. Parameter (Pipe No ) set as 2
pipes.

(COS) Change over analog sensor: Used for hot / cold water or air change over
switching in 2 pipe systems.
Only used and valid if system is setup as 2 pipes. Parameter (Pipe No ) set as 2
pipes.
If water temperature is > 78 °F = Hot water present
If water temperature is < 75 °F = Cold water present

(SS) Supply air sensor monitoring: Used for supply air temperature monitoring.
Only used for network reporting of the supply air temperature. Has no internal
function in the thermostat.

MenuScro
Menu scroll
Default value = On = Scroll active

AutoMode
Enables Auto menu for Mode

button
Default value = On
C or F
Sets scale of the thermostat
Default value = °F

%RH disp
Local %RH Display

Default value = OFF
Models with Humidity sensor only

Removes the scrolling display and only present the room temperature/humidity to the user.
With this option enabled, no status is given of mode, schedule and outdoor temperature.

On = Scroll active
Off = Scroll not active

Enables Auto function for the mode button
For sequences 2, 4 & 5 only

On = Auto active (Off-Cool-Heat-Auto)
Off = auto not active (Off-Cool-Heat)

°F for Fahrenheit scale
°C for Celsius scale

On hotel models, this sets the default value when the thermostat powers up
RH models only

Enables the display of humidity below the room temperature on the display

ON = Display %RH
OFF = No display of %RH

VT735xX5x00(x) models only

Lockout
Keypad lockout levels
Default value = 0 No lock

Level

0 Yes access Yes access Yes access Yes access
1 Yes access Yes access Yes access No access
2 Yes access No access No access Yes access
3 Yes access No access No access No access
4 No access No access No access Yes access
5 No access No access No access No access

Pipe No

System type installation
Number of pipes
Default is: 4.0 Pipes

Occupied temperature

setpoints

System mode setting Fan mode setting Unoccupied Override

Defines the type of system installed

2.0 Pipes, will limit the number of sequences of operation available from 0 to 3
Will enable heat/cool operation from the same output ( refer to wiring diagram )

4.0 Pipes, can access all the sequences of operation from 0 to 5
Will enable heat/cool operation from different output ( refer to wiring diagram )

CntrlTyp

Control type for Triac models
Default is: Floating

Defines the type of control output for the type of valves installed

VT7350C10xx, VT7300C10xx, VT7355C10xx and VT7305C10xx only
On/Off is for normally opened or normally closed 24 Vac 2 position valves

Floating is for modulating 3 wires control of 24 Vac floating valves

14

SeqOpera Sequence of
operation

System = 2 Pipes System = 4 Pipes

Default is: Sequence #1
0 = Cooling Only Yes access Yes access
1 = Heating only Yes access Yes access
2 = Cooling With Reheat Yes access Yes access
3 = Heating With Reheat Yes access Yes access
4 = Cooling / Heating 4 pipes No access Yes access
5 = Cooling / Heating 4 pipes with

No access Yes access

Reheat

For single output applications, the system access is also limited if UI3 is configured
for local changeover COS, COC/NC or COC/NC. The current water temperature
detected by the UI3 then limits the system mode available for the local

configuration or network write.
Fan Menu
Mode button menu configuration
Default is: Menu #4

Menu presented are dependent on model used and sequence of operation

selected

Auto Mode operation for sequences 2 and 3 is dependent on Auto Fan parameter
0 = Low-Med-High
1 = Low-High
2 = Low-Med-High-Auto
3 = Low-High-Auto
4 = On-Auto

DHumiLCK
Dehumidification lockout
VT735xX5x00(x) models only
Default value: On = Authorized

3 Speed configuration using 3 fan relays ( L-M-H )

2 Speed configuration using 2 fan relays ( L-H )

3 Speed configuration with Auto fan speed mode using 3 fan relays ( L-M-H )

2 Speed configuration with Auto fan speed mode using 2 fan relays ( L-H )

Single Speed configuration. Auto is for Fan on demand / On is On all the time

Typically toggled through the network.
This variable enables or disables dehumidification based on central network
requirements from the BAS front end

On = Dehumidification Authorized
Off = Dehumidification Not Authorized

%RH set

Dehumidification setpoint
Default is 50 % RH

DehuHyst

Dehumidification Hysterisys
Default is 5 % RH

DehuCool

Maximum Dehumidification
Cooling output
Default is 100 %

Used only if dehumidification sequence is enabled:
Range is: 30-95% RH

VT735xX5x00(x) models only

Humidity control hysterisys. Used only if dehumidification sequence is enabled:
Range is: 2 to 20% RH
VT735xX5x00(x) models only
Maximum cooling valve position when dehumidification is enabled. This can be
used to balance smaller reheat loads installed in regards to the capacity of the
cooling coil.
Range is: 20 to 100 %
VT735xX5x00(x) models only

St-By TM

Stand-by Timer value
Default 0.5 hours

Unocc TM

Unoccupied Timer value
Default 0.0 hours

Time delay between the moment where the PIR cover detected the last movement
in the area and the time which the thermostat stand-by mode and setpoints
become active.
Range is: 0.5 to 24.0 hours in 0.5hr increments
Time delay between the moment where the thermostat toggles to stand-by mode
and the time which the thermostat unoccupied mode and setpoints become active.
The factory value or 0.0 hours: Setting this parameter to its default value of 0.0
hours disables the unoccupied timer. This prevents the thermostat to drift from
stand-by mode to unoccupied mode when PIR functions are used

Range is: 0.0 to 24.0 hours in 0.5hr increments
St-By HT
Stand-by heating setpoint
Default value = 69 °F

The value of this parameter should reside between the occupied and unoccupied

heating setpoints and make sure that the difference between the stand-by and

occupied value can be recovered in a timely fashion when movement is detected

in the zone.

Stand-by heating setpoint range is: 40 to 90 °F ( 4.5 to 32.0 °C )

15

St-By CL
Stand-by cooling setpoint limit
Default value = 78 °F

Unocc HT
Unoccupied heating setpoint
Default value = 62 °F
Unocc CL
Unoccupied cooling setpoint limit
Default value = 80 °F
heat max
Maximum heating setpoint limit
Default value = 90 °F ( 32 °C )
cool min
Minimum cooling setpoint limit
Default value = 54 °F ( 12 °C )

Pband

Proportionnal band setting
Default is : 3

Set Type
Temporary setpoint enable
Default is : Permnent

Enables temporary setpoints
feature to any change of
occupied or unoccupied setpoint.

Spt Func
Local setpoint settings
Default value = Dual Spt

TOccTime
Temporary occupancy time
Default value = 2 hours

The value of this parameter should reside between the occupied and unoccupied
cooling setpoints and make sure that the difference between the stand-by and
occupied value can be recovered in a timely fashion when movement is detected
in the zone.
Stand-by cooling setpoint range is: 54 to 100 °F ( 12.0 to 37.5 °C )

Unoccupied heating setpoint range is:

40 to 90 °F ( 4.5 to 32.0 °C )

Unoccupied cooling setpoint range is:
54 to 100 °F ( 12.0 to 37.5 °C )

Maximum occupied & unoccupied heating setpoint adjustment.
Heating setpoint range is:

40 to 90 °F ( 4.5 to 32.0 °C )

Minimum occupied & unoccupied cooling setpoint adjustment.
Cooling setpoint range is:
54 to 100 °F ( 12.0 to 37.5 °C )
Adjust the proportional band used by the thermostat PI control loop.

Warning. Note that the default value of 3.0 °F ( 1.2 °C ) gives satisfactory
operation in most normal installation cases. The use of a superior proportional
band different than the factory one is normally warranted in applications where the
thermostat location is problematic and leads to unwanted cycling of the unit. A
typical example is a wall mounted unit where the thermostat is installed between
the return and supply air feeds and is directly influenced by the supply air stream
of the unit.

F scale

Value

3 3 F 1.7 C
4 4 F 2.2 C
5 5 F 2.8 C
6 6 F 3.3 C
7 7 F 3.9 C
8 8 F 4.4 C
9 9 F 5.0 C

10 10 F 5.6 C

Pband

C scale

Pband

Temporar: (temporary) Local changes to the heating or cooling setpoints by the

user are temporary. They will remain effective for the duration specified by
ToccTime. Setpoints will revert back to their default value after internal timer
ToccTime expires.
To change setpoints permanently, revert to No this variable or write setpoints
through the network. Any setpoints written through the network will be permanent
ones and saved to EEPROM.
Permnent: (permanent) Any change of occupied or unoccupied setpoints through
the keypad by the user are permanent and saved to & EEPROM
Set the local setpoint interface for the user

Dual Spt ( Dual Occupied Setpoints Adjustment )
AttchSpt ( Single Occupied Setpoint Adjustment )

Temporary occupancy time with occupied mode setpoints when override function
is enabled
When the thermostat is in unoccupied mode, function is enabled with either the
menu or UI2 configured as remote override input.
Range is: 0,1, 2, 3, 4, 5, 6, 7, 8, 9, 10, & up to 24 hours

16

17

deadband
Minimum deadband
Default value = 2.0 °F ( 1.0 °C )
cal RS
Room temperature sensor
calibration
Default value = 0.0 °F or °C
cal RH
Humidity sensor calibration
Default value = 0 %RH

aux cont

Auxiliary contact function &
configuration

Default value = 0 Not Used

Auto Fan

Auto Fan Function
Default value: AS

FL time
For floating models
VT73xxC5x00(x) only
Default value: 1.5 minutes
cph
On/Off devices cycles per hour
For On/Off models & sequences
VT73xxC5x00(x) only
Default value = 4 C.P.H.

RA/DA
For Analog models
VT73xxF5x00(x) only
Default value: DA signal
Reheat
Default value: 0 = 15 minute

UI3 dis

Display UI3 value.

Minimum deadband value between the heating and cooling setpoints. If modified,
it will be applied only when any of the setpoints are modified.
Range is: 2, 3, 4 or 5 °F, 1.0 °F increments ( 1.0 to 2.5 °C, 0.5 °C increments )
Offset that can be added/subtracted to actual displayed room temperature
Range is: ± 5.0 °F, 1.0 °F increments ( ± 2.5 °C, 0.5 °C increments )

Offset that can be added/subtracted to actual displayed humidity by ± 15.0 %RH.
Range is : ± 15.0 %RH

0 Aux contact function used for reheat

IF SEQUENCE IS SET TO REHEAT THROUGH NETWORK OR LOCAL

, Ignore

this parameter

The output will directly follow the occupancy of the thermostat
1 Auxiliary NO, Occ or St-By = Contact Closed / Unoccupied = Contact Opened
2 Auxiliary NC, Occ or St-By = Contact Opened / Unoccupied = Contact Closed

Output to follow directly main occupancy and Fan on command

Typically used for 2 position fresh air damper applications.
3 Auxiliary NO, Occ or St-By & Fan On = Contact Closed / Unoccupied & Fan On
or Off = Contact Opened
4 Auxiliary NC, Occ or St-By & Fan On = Contact Opened / Unoccupied & Fan
On or Off = Contact Closed

Output to follow secondary network occupancy command
5 Auxiliary On/Off Control through auxiliary network command. The output can

be commanded through the network for any required auxiliary functions through a
separate & dedicated network variable.

Auto Speed Fan Mode operation for Fan Sequences 2 and 3

AS = Auto Speed during occupied periods. Fan is always on during occupied
periods.

AS AD = Auto Speed / Auto Demand during occupied periods.
Floating actuator timing
Maximum stroke time of floating valve actuator.

Range is: 0.5 to 9.0 minutes in 0.5 minutes increment
Will set the maximum number cycles per hour under normal control operation. It
represents the maximum number of cycles that the equipment will turn ON and
OFF in one hour.
Note that a higher C.P.H will represent a higher accuracy of control at the expense
of wearing mechanical components faster.
Range is: 3, 4, 5, 6,7 & 8 C.P.H.
Reverse acting or Direct acting signal for Analog output signals

DA = Direct acting, 0 to 100 % = 0 to 10 Vdc
RA = Reverse acting, 0 to 100 % = 10 to 0 Vdc

Sets the reheat output time base
Valid only if reheat sequences are enabled

0 = 15 minutes
1 = 10 seconds for Solid state relays

Used as diagnostic / service help to troubleshoot and diagnose sensor operation
Supply or change over temperature when UI3 is configured as an analog input
( SS or COS )

Specifications

Occ, Stand-By and Unocc cooling setpoint range: 12.0 to 37.5 °C ( 54 to 100 °F )

Occ, Stand-By and Unocc heating setpoint range: 4.5 °C to 32 °C ( 40 °F to 90 °F )

Room and outdoor air temperature display range -40 °C to 50 °C ( -40 °F to 122 °F )

Proportional band for room temperature control: Cooling & Heating: 1.8°C ( 3.2°F )

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT
ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

Drawing & Dimensions

Fig.13 – Thermostat dimensions

Thermostat power requirements: 19-30 Vac 50 or 60 Hz; 2 VA Class 2

Operating conditions: 0 °C to 50 °C ( 32 °F to 122 °F )

0% to 95% R.H. non-condensing

Storage conditions: -30 °C to 50 °C ( -22 °F to 122 °F )

0% to 95% R.H. non-condensing

Temperature sensor: Local 10 K NTC thermistor

Temperate sensor resolution: ± 0.1 °C ( ± 0.2 °F )

Temperature control accuracy: ± 0.5 ° C ( ± 0.9 °F ) @ 21 °C ( 70 °F ) typical calibrated

Humidity sensor and calibration: Single point calibrated bulk polymer type sensor

Humidity sensor precision: Reading range from 10-90 % R.H. non-condensing

10 to 20% precision is 10%
20% to 80% precision is 5%
80% to 90% precision is 10%

Humidity sensor stability Less than 1.0 % yearly (typical drift)

Dehumidification setpoint range: 30% to 95% R.H.

Binary inputs: Dry contact across terminal BI1, BI2 & UI3 to Scom

Contact output rating: Fan relay output: 30 Vac, 1 Amp. Maximum, 3 Amp. in-rush

Valve triac output: 30 Vac, 1 Amp. Maximum, 3 Amp. in-rush

Valve analog: 0 to 10 Vdc into 2KΩ resistance min.

Wire gauge 18 gauge maximum, 22 gauge recommended

Dimensions: 4.94” x 3.38” x 1.13”

Approximate shipping weight: 0.75 lb ( 0.34 kg )

Agency Approvals all models:

UL: UL 873 (US) and CSA C22.2 No. 24 (Canada), File E27734
with CCN XAPX (US) and XAPX7 (Canada)
Industry Canada: ICES-003 (Canada)

Agency Approvals all models

FCC: Compliant to CFR 47, Part 15, Subpart B, Class A (US)
CE: EMC Directive 89/336/EEC (Europe Union)
C-Tick: AS/NZS CISPR 22 Compliant (Australia / New Zealand)

Supplier Code Number N10696

Agency Approvals Wireless models

FCC: Compliant to: Part 15, Subpart C

Important Notice

All VT7300 series
controls are for use as
operating controls only

and are not safety
devices. These instruments have
undergone rigorous tests and
verifications prior to shipment to
ensure proper and reliable operation in
the field. Whenever a control failure
could lead to personal injury and/or
loss of property, it becomes the
responsibility of the user / installer /
electrical system designer to
incorporate safety devices ( such as
relays, flow switch, thermal
protections, etc…) and/or alarm
system to protect the entire system
against such catastrophic failures.
Tampering of the devices or miss
application of the device will void
warranty.

18
