Verilink QPRI 2921 User Manual

September 1999 P/N 880-503143-001-A1

Copyright Notice

Trademarks

FCC Requirements

its products or services. Verilink’s sole warranty is contained in its product warranty. The end-user documentation is shipped with Verilink’s products and constitutes the sole specifications referred to in the product warranty. Verilink has made reasonable efforts to verify that the information contained herein is accurate, but Verilink assumes no responsibility for its use or for any infringement of patents or other rights of third parties that may r esult. T he customer is sole ly resp onsible fo r veri fying the suitabil ity of Verilink’s products for its use. Specifications are subject to change without notice.

Verilink is a registered trademark of Verilink Corporation. Access System 2000, WANscope, VeriStats, and FrameStart are trademarks of Verilink Corporation.

Any named products herein are trademarks of their respective companies. This equipment has been tested and found to comply within the limits for a Class A

digital device pursuant to Part 15 of the Federal Commun ications Commission (FCC) rules. These limits are designed to provide protection against harmful interference in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the user manual, can cause harmful interference to radio communications.

There is no guarantee that interference will not occur in a particular installation. If this equipment causes harmful interference to radio or television reception—which can be determined by turning the equipment off and on—try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This equipment complies with Part 68 of the FCC Rules. On the rear, side or bottom of the unit is a label that contains the FCC registration number and other information. If requested, provide this information to the telephone company.

• All direct connections to the network lines must be made using standard plugs and jacks (compliant wi th Part 68). The following tables list the applicable registration jack universal order codes (USOCs), facility interface codes (FICs), and service order codes (SOCs). These are required to order service from the telco.

For T1 interfaces:

Port ID REN/SOC FIC USOC

1.544 Mbit/s SF

1.544 Mbit/s SF, B8ZS

1.544 Mbit/s ANSI ESF

1.544 Mbit/s ANSI ESF, B8ZS

For DDS interfaces:

Port ID REN/SOC FIC USOC

56 kbit/s 64 kbit/s

• If the unit appears to be malfunctioning, inform the telco and disconnect it from the network lines until the source of trouble is determined to be your equipment or the telephone line . If your equipment needs repair, it should not be reconnected until it is repaired.

• The unit has been designed to prevent harm to the network. If the telephone company finds that the equipment is exceeding tolerable parameters, it can temporarily disconnect service. In this case, the telephone company will provide you advance notice if possible.

6.0N 04DU9 -BN

6.0N 04DU5 -56

04DU9 -DN 04DU9 -1KN 04DU9 -1SN

04DU5 - 64

RJ-48C jack

RJ-48S jack

Verilink QPRI 2921 Manual

iii

Lithium Battery

• If the telephone company alters its equipment in a manner that can affect the use of this device, it must give you warning so that you have the opportunity to maintain uninterrupted service. You will be advised of your right to file a complaint with the FCC.

• No customer is authorized to repair this equipment, regardless of warranty status. All repair s must be performe d by Ve ril i nk or an auth or ized age nt . It is the responsibility of users requiring service to report the need for service to Verilink or to one of our authorized agents.

The lithium battery referred to in the following notices is contained inside the clock chip.

English

Français

DANGER!

The battery can ex plo de i f inco rre ct ly rep lac ed! Repl ace on ly with th e sam e or equi valent type recommen ded by the manufacturer. Di spos e of used batteries according to the manufacturer’s instructions.

DANGER!

To avoid electrical shock in case of f ailur e , th e power supply must be installed by a professional installer. The terminal labeled with the ground symbol ( ) on the power supply must be connected to a permanent earth ground.

CAUTION!

Interconnecting circuits must comply with the requirements of EN60950:1992/A4:1997 Section 6.2 for telecommunications network voltages (TNV) circuits.

ATTENTION!

Une explosion peut se produire si la batterie est remplacée d’ une façon incorrecte! Remplacez-la seulement avec le même modêle de batterie ou un modèle équivalent selon les recommendations de manufacture. Disposez de les batteries usées selon le s instructions de manufacture.

ATTENTION!

Pour éviter choc électrique en cas de insuccès, la provision de pouvoir doit êtré installé par un installeur professionnel. Le terminal de la provision de pouvoir, marqué du symbol de terre, ( ) doit connecté à un circuit de terre permanent.

PRUDENT!

Les circuit s doi vent êtré i nter conn ectés de mani ère à ce qu e l’ é quipe ment contin ue a êtré en agrément avec “EN60950:1992/A4:1997, Section 6.2, pour les circuits de voltage de liaisons d’ échanges (réseau) par les télécommunications (TNV), ” après les connections de circuits.

Españole

La bateria puede explota r si se reem plaza incorr ec tamente. Reemplace la b a t er ia con el mismo tipo de bateria ó una equivalente recomendada por el manufacturero. Disponga de las baterias de acuerdo con las instrucciones del manufacturero.

ATTENCION!

Para evitar contacto con circuitos que electrocutan, la fuente de alimentación debe ser instalada por un técnico profesional. La terminal de la fuente de alimentación marcada con el símbolo de tierra ( ) debe ser conectada a un circuito de vuelta por tierra permanente.

PELIGRO!

Circuitos que se interconectan a la red de telecomunicaciones deben hacerse de tal manera que cumplan con los requisitos estipulados en las especificaciones “EN60950:1992/ A4:1997 , Secció n 6.2, pa ra los vo ltages de c ircuit os interco nnectado s a la Red de Telecomunicaciones (TNV),” despues de terminar las connecciones entre los circuitos.

iv

Verilink QPRI 2921 User Manual

Deutsch

VORSICHT!

Explosionsgefahr bei unsachgemäßem Ersetzen der Batterie! Batterie gleichen Typs und gleich er Qualität benutzen, wie vom Her s t eller empf ohlen. Ents orgung der Batterie nach Anweisung des Herstellers!

VORSICHT, GEFAHR!

Um keinen Schlag zu erhalten beim Versagen der electrische n Anl a ge, muss der Stromanschluss von ei nem Elektriker vorge nommen werden. Der elektrische Pol, versehen mit dem Erdsymbol ( ) muss am Stromanschluss permanent geerdet sein.

VORSICHT!

Schaltungen, die in den Geräten zusammengeschaltet sind, müssen weiterhin den Vorschriften EN60950:1992/A4:1997, Absatz 6.2 für Telecommunications Netz Spannung (TNV) Schaltkreize entsprechen.

Canadian

Requirements

Safety Precautions

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicabl es aux appareils numériques (de la class A) prescrites dans le Règlement sur le brouill age radi oélect riq ue éd icté par le mi nist ère des Communi ca tion s du Canada.

The Industry Canada label indentifies CS-03 certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. Industry Canada does not guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company’s inside wiring associated with a single line individual service may be extended by means of a certified connector assembly (telephone extension cord). The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

Repairs to certifi ed equipmen t should be made by a n authoriz ed Canad ian maint enance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.

Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.

This equipment is intended to be installed only in a Restricted Access Location that meets the following criteria:

• Access can only be gained by service personnel or users who have been instructed about the reasons for the restrictions applied to the location and about any precautions that must be taken.

• Access can only be gained through the use of a lock and key or other means of security, and is controlled by the authority responsible for the location.

When handling this equipment, follow these basic safety precautions to reduce the risk of electric shock an d in ju ry :

• Follow all warnings and instructions marked on the product and in the manual.

• Unplug the hardware from the wall outlet before cleaning. Do not use liquid

cleaners or aerosol cleaners. Use a cloth slightly dampened with water.

• Do not place this product on an unstable cart, stand, or table. It may fall, causing serious damage to the product.

• Slots and openings in the shelves are provided for ventilation to protect them from overheating. These openings must not be blocked or covered. Never place this product near a radiator or heat register.

Verilink QPRI 2921 Manual

v

Product Warranty

Customer Service

Publications Staff

• This product should be operated only from the type of power source indicated on the marking label and manual. If you are unsure of the type of power supply you are using, consult your dealer or local power company.

• Do not allow anything to rest on the power cord. Do not locate this product where the cord will interfere with the free movement of people.

• Do not overload wall outlets and extension cords, as this can result in fire or electric shock.

• Never push objects of any kind into the shelves. They may touch dangerous voltage points or short out parts that could result in fire or electric shock. Never spill liquid of any kind on this equipment.

• Unplug the equipment from the wall outlet and refer servicing to qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged or frayed.

• If liquid has been spilled into the product.

• If the product has been exposed to rain or water.

• If the product has been dropped or if the cabinet has been damaged.

Verilink’s product warranty covers repair or replacement of all equipment under normal use for a five-year period from date of shipment. Replacement products may be new or reconditioned. Any replaced or repaired product or part has a ninety (90) day warranty or the remainder of the initial warranty period, whichever is longer. Our in-house Repair Center services returns within ten working days.

Verilink offers the following services:

• System Engineers at regional sales office s for network design and planning assistance (800) 837- 4546

• Technical Assistance Center for free 24x7 telephone support during installation, maintenance, and troubleshooting (800) 285-2755 and support@verilink.com

• To return a product, it must be assigned a Return Materials Authorization (RMA) number before sending it to Veril i nk for repa ir (800) 92 6- 0085 , ext. 228 2

• Maintenance contracts and leasing plans (800) 837-4546

• Technical Training on network concepts and Verilink products (800) 282-2755

and training@verilink.com

• Web site (www.verilink.com)

This manual was writt en and illustrated by David Gardner. Contributing Writers and Editors: Dave Fradelis, Marie Metivier, Barbara Termaat, and Steve Rider.

vi

Verilink QPRI 2921 User Manual

Checklist

Use this detachable checklist to guide your installation of the QPRI 2921 f or ISDN capabilities.

When Information Required Notes

Before Ordering ISDN

Check for availability—Call or otherwise access your network service provider (telco)

What applications?

•Data only

What type of equipment will be hooked up? Man ufacturer/Brand Names? Serial/Model Numbers?

•Terminal Adapter (TA)

•Bridge

•Router

•ISDN Telephone How will the equipment be hooked up? Between the telco and the

Verilink equipment? Between the Verilink equipment and your equipment?

ISDN Circuit ID Number ISDN Ordering Code (IOC) (If required by your telco) Service and billing address Your contact na me and number Telco contact name and number

Data only. Notify telco you want the switch configured for DATA ONLY.

No TA supported.

We support RJ-48c connection to telco (Smartjack) interface.

Telco Will Provide

Telco to provide inside wiring and jack? Desired long-distance carrier Delivery of CLID or Station ID (Delivery of Calling Line ID is required) Delivery of DNIS (Delivery of DNIS (Dialed Number Information

Services) required) No NSF is required. Netware Specific Facilities information element is

not required. Multirate Services (Nx64) Multirate services may be required.

Availability confirmation

Estimated pricing Confirmation call

•Due date

• Switch type

• Service profile identifiers (SPIDs)

• Directory numbers Fulfillment package

• Troubleshooting guide

SPIDs may not be applicable.

Verilink QPRI 2921 vii

viii Verilink QPRI 2921

QPRI 2921 Dual-Port ISDN Primary Rate Interface

The QPRI 2921 application module working in conjun ction with an NCM 2000 controller mo dule provides your AS2000 system with critical network backup capability that includes ISDN PRI access.

NOTE:

The QPRI accepts high-speed data from local area networks, host mainframes, and other types of data terminal equipment. The aggregate data rate from terminal equipment can be one of the following:

n

on NFAS configuration

n

on NFAS configuration

The ISDN capabili ty of the QPRI 2921 application module is only accessible through the NCM 2000 Controller Menu.

T1 Timeslots Data Rate

= 1—23 or 1—24 depending

56 kbit/s (up to 1.344 Mbit/s) (n = 1–24)

n ×

64 kbit/s (up to 1.536 Mbit/s) (n = 1–24)

n ×

Applications

In dial-backup mode, the QPRI 2921 provides an altern ate ISDN route when regular T1 lines are unavailable. The QPRI 2921 can also be used to designate a reserve leased T1 as a backup.

Figure 1-1 ISDN Dial-Backup Application

Network

Services

DIDCSU

NCM

DRPI 2922

TAC

DIU

TAC

DIU

TAC

DIU

2000

2912

2010

2130

2010

2130

2010

2130

2010

2130

TAC

2010

ISDN Switched

Network

Verilink QPRI 2921 1-1

QPRI 2921 Dual-Port ISDN Primary Rate Interface

Features

The QPRI 2921 system has the following features:

T1 Digital Transmission Facilities

Advanced Automatic Protection Switching

Dial Backup

Alternate T1

Backup

The QPRI system carries data traffic onto a T1 transmission facility. Each port provides T1 transport bandwidth of n×56 kbit/s or

n×64 kbit/s trunks.

The QPRI system provides Advanced Automatic Protection Switching (AAPS) to alternate T1 lines using three hardware options:

•

QPRI with CIM 2064 (P/N 311-101467-001); four net ports

•

QPRI with CIM 2068 (P/N 311-101500-001); four equipment ports

•

QPRI with CIM 29003 (P /N 311-101501-001); two equipment ports, two net ports

The QPRI system provides an alternate ISDN route for digital data traffic when the regular T1 line is unavailable.

The QPRI system provides an alternate T1 route for digital data traffic when the regular T1 line is unavailable.

Crosspoint Switch

Drop, Insert, and Bypass Mode

Alarm Management

The QPRI system provides flexibility for designing data paths to and from multiple AS2000 T1 modules across the backplane. Incoming and outg oing channels can be set up to send data traffic.

The QPRI supports drop, insert, and bypass functionality via its crosspoint switch. Further, the drop, insert, and bypass configuration helps reduce the number of network (T1) links among different sites.

QPRI alarms are reported to the NCM. These alarms are viewed using the NCM Craft interface, Telnet, SNMP, or Node Manager.

1-2 Verilink QPRI 2921

QPRI 2921 Dual-Port ISDN Primary Rate Interface

Advanced Programmable Architecture

All QPRI system hardware and software components can be independently up gra d ed wit h produ ct options and firmware upgrades. Additional mo dules can be added within a node to increase network channel capacity. CIMs and other modular components can be added, upgraded, or replaced independently.

Node Management

Diagnostics

The NCM provides node management via Cr aft interface, Telnet, SNMP, and Verilink’s Node Manager.

The QPRI provides line (LLB), data port (DPLB), repeater (RLB), and payload (PLB) loopbacks. Test patterns can be used with or without the loopbacks.

System Components

H

ardware

•

components of the QPRI 2921 system include:

NCM 2000 (Version 4. 0 or higher firm ware) with acco mpanying NIM

•

Quad-Port Primary Rate Interface (QPRI) ISDN module

•

Connector interface modules (CIMs):

CIM 2064 (P/N 311-101467-001) CIM 2068 (P/N 311-101500-001) CIM 29003 (P/N 311-101501-001)

•

Universal power supply and shelf

•

System cables (Craft Cable P/N 458-501788-008)

QPRI 2921 Front

Figure 1-2 shows the front panel of the QPRI 2921.

Module

Figure 1-2 Quad-Port ISDN Primary Rate Interface (QPRI 2921) Front Panel

Primary ACP Management port for direct

connection to PC with Node Manager, RJ-45

ACP Management communications port,

QPRI

2921

Craft Port, RJ-11

1

PORT

2

LOCAL

PORT

SYS

3

4

PRI

MANAGEMENT

extends bus to another shelf, RJ-45

EXT

Verilink QPRI 2921 1-3

QPRI 2921 Dual-Port ISDN Primary Rate Interface

LEDs

Management Ports

The QPRI front panel’s System LED (SYS) is green when the module has passed the power-up self-test.

The panel also contains four status LEDs:

•

Two for network port status

•

Two for data port status

Chapter 4 of this manual defines the LEDs and alarms.

Three NCM front panel management ports support management of the local node and allow remote node management.

•

Local—RJ-11 direct connection to the Craft interface via:

•

An ASCII terminal

•

A PC running a terminal emulator

•

Node Manager ASCII Port Access window

The QPRI 2921 also supports access to t he ASCII interface over NCM Telnet sessions via modem dial-up SLIP connections.

•

PRI—Primary Management . Node Manager interface c onnection to the PC COM port.

Type Serial port used for No de Manager access or

ACP bus extension

Connector Interface Modules

Connector RJ-45 (8-pin), RS-232-compliant

•

EXT— Multishelf Management. Extension port for daisychaining multiple AS2000 shelves (ACP-bus modules only).

Type ACP management Connector RJ-45 (8-pin), RS-232-compliant

The PRI and EXT ports can be used interchangeably.

In addition to th e all- n et, a ll-e qui pment , o r 2- n et/2-eq uip ment po rt configurations (RJ-48C), the CIMs also provide the following interfaces:

•

Alarm relay Loss of carrier conditions activate the relay contacts. These

contacts can be wi r e d to e x te r na l ala r m e q u ipment. The connector pins provid e output as a normally open (NO) contact, a normall y closed (NC) contact , and a common (COM) lead contact.

•

External timing source input The 8-pin mini-DIN connecto r receives a clock signal from an

external tim in g de v i ce .

ext

ension port

1-4 Verilink QPRI 2921

Figure 1-3 CIM Configurations

CIM 2064, Four Net Ports (DS1)

QPRI 2921 Dual-Port ISDN Primary Rate Interface

311-101467-001

EXT TIMING

INPUT

ALARM

RELAY

NO COM NC

DS-1

PORT 2

CIM 2068, Four Equipment Ports (DSX-1)

311-101500-001

EXT TIMING

INPUT

ALARM

RELAY

NO COM NC

DSX-1

PORT 2

CIM 29003, Two Equipment Ports, Two Net Ports (DSX-1, DS1)

311-101501-001

EXT TIMING

INPUT

ALARM

RELAY

NO COM NC

DSX-1 DS-1

NET 2

2064

CIM

PORT 1PORT 4 PORT 3

2068

CIM

PORT 1PORT 4 PORT 3

29003

CIM

NET 1CPE CPE 1

NOTE:

Equipment Ports 1 an d 2 require adapter cables to properly interface wit h na tive connectors .

Specifications

Table 1- 1 QPRI General Specifications

Number of Ports Transmission (Line) Rate Line Code Framing Format CPE Impedance Transmission Level Input Level CIMs

Output Level

4 per module)

1.544 Mbit/s, RX: ± 200 ppm; TX: ± 32 B8ZS, AMI ESF, SF 100 Ω ± 5% at 772 KHz test 0 dB

: 3.0 V ± 0.3 V base-to-peak, attenuated by 0 to 27.5 dB

3.0 V ± 0.3 V base-to-peak or DS1 into 100 Ω at 0 dB LBO

Verilink QPRI 2921 1-5

QPRI 2921 Dual-Port ISDN Primary Rate Interface

Output LBO (selectable) Loopbacks

Timing

Table 1-2 CIM Specifications

CIM Modules Name Physical Interface CIM 2064, 2068, 29003

0, 7.5, 15, or 22.5 dB (0 to 3000 feet) Line, Equipment Port, Repeater, Payload Modes: Network, External, and Internal

System port: External T1 (8-pin DIN)

External timing 8-pin DIN Alarm relays Form-C relay Ports RJ-48C

Technical and Regulatory Compliance

This product complies with the following regulatory specifications as they apply to telecommunications equipme nt:

Table 1-3 Standards and Reference Documents

AT&T 54016, AT&T 62411,

AT&T

AT&T TR-NPL-000054, AT&T 4ESS, AT&T 5ESS

ANSI FCC UL

CSA/DOC Bellcore EIA ITU-T (Formerly CCITT) RFC TR

ANSI T1.403 FCC Part 68 UL 1459 Revision 2 DMS 100, and NIS-2 ISDN

5R-Met002343

Q.900 series (I.400 series) regarding ISDN functionality

1-6 Verilink QPRI 2921

Chapter

2

Quick Set-Up

This chapter provides step-by-step procedures as an example for setting up your QPRI 2921 module and creating an ISDN dialbackup circuit .

NOTE:

For ISDN functionality, the QPRI 2921 ASCII interface

accessed from the NCM 2000 module

QPRI 2921 to allow access t o ISDN dial-backup cir cuits or alternate T1 circuits under defined line failure conditions. When installed in a Multi-Line Shelf (MLS), the NCM/QPRI combination provides backup network access for other application modules on the shelf.

NOTE:

Use the following information as a guide for the configuratio n process. Complete descriptions of the various screen options and su ggesti ons fo r the ir ap plic abi lity to your situation are giv en in the following chapter.

must be

. The NCM 2000 uses the

For the most effective and efficient set-up, have all required planning data such as your intended use, network (telco) provider specifications, channel and line requirements, circuit config urations, and other important infor mation handy. For y our conv enience, workshee ts are pr ovided on the following page and the beginning of this manual in addition to those available in the AS2000 Basics Man ual, Chapter 2— Site Planning.

For information on accessing the QPRI 2921 directly with the Craft/Local port, see the DCSU 2911 User Manual.

Figure 2-1 Hypothetical ISDN Dial-Backup Configuration

ISDN

CO

NCM

QPRI

PRI

NCM

QPRI

Verilink QPRI 2921 2-1

Quick Set- Up

When Information Required Notes

Before Ordering ISDN

Check for availability —Cal l o r oth erw is e access your network service provider (telco)

What application?

• Data only

What type of equipment wi ll b e hooked up? Manufa ctur er/Bran d Names? Serial/M o d el Nu m b ers ?

•Bridge

•Router

•ISDN Telephone How will the equipment be hooked up? Between the telco and

the Verilink equipment? Between the Veri lin k equipment and your equipment?

ISDN Circuit ID Number ISDN Ordering Code (IOC) (If required by your telco) Service and billing address Your contact name an d numb er Telco contact name and number

Should be Data only. Be sure to tell your telco that you want the switch configured for DATA ONLY.

No TA supported.

We support RJ-48c connection to telco (Smartjack) interface.

Telco Will Provide

Telco to provide inside wiring and jack? Desired long-distance carrier Delivery of CLID or Station ID (Delivery of Calling Line ID is

required) Delivery of DNIS (Delivery of DNIS (Dialed Number Information

Services) required) No NSF is required. Netware Specific Facilities information

element is not required. Multirate Services (Nx64) Multirate services may be required. Availability confirmation

Estimated pricing Confirmation call

Due date Switch type Service profile identifiers (SPI D s ), if requir ed . Directory nu m b e rs Fulfillment package Troubleshooting guide

SPIDs may not be applicable

2-2 Verilink QPRI 2921

Getting Started

Quick Set-Up

After the NCM and QPRI modules and their NIM/CIM have been installed in their appropriate shelf/slots (self-test has been successfully completed), connect the Craft Interface Cab l e (P/N 458-501788-008) to the Local port o n the NCM front panel to access the ASCII interface.

Terminal Parameters

Logging On

Bus Compatibility

Terminal parameters: 19.2 kbit/s baud rate, 8 data bits, no parity, one stop-bit, and no flow-control. Make sure that the X-On/X-Off flow control is disabled.

NTER

1. Press

2. Press

If the NCM proper shelf/slot position, you may continue with the configuration tasks.

The default password for the NCM will give the user Access Level 2 permissions. If you need a higher access level, see your NCM 2000 User Manual for more information.

If there is no indication of the QPRI on the “shelf map” on the NCM

Main Menu

the shelf backplane. NCMs are usually sent out with their default bus being the C bus.

Other modules usuall y are sent out wi th the ir defaul t bus be ing the A bus.

E

to display the

NTER

E

to display the NCM

Main Menu

, the modules may be assigned to different busses on

display Figure 2-2 shows the QPRI in the

pSH+>

prompt and type

Main Menu

.

craft

.

Assign the QPRI to the bus on which the NCM resides by accessing the QPRI’s ASCII port direct ly.

1. Connect the Craft Interface Cable directly to the LOCAL port on the QPRI module.

NTER

2. Press

3. From the

4. Once the bus assignment has been made, reboot the

•

E

.

QPRI Main Menu

O) node administration>B) change the ACP bus

reassigned module by either

reset

Using the

Menu

Reseating the module in its slot.

reset

command fr om t h e

resetreset

, option R, or

Verilink QPRI 2921 2-3

, select the following:

Controlle r Adm ini stra tio n

Quick Set- Up

Figure 2-2 NCM Main Menu

Reconnect to the NCM Local port for further operations.

Firmware Version and Date of Release

Node Addre ss

Access Level (1-4)

Menu Heading Area

Node “Map” (Physical Location of Modules)

Module Key

Command List

Active NCM Master Designator

-- VERILINK NCM CONTROLLER : FW Rev 4.15, Dec 13 1997 12:53:30 --

-- VERILINK NCM CONTROLLER : FW Rev 4.15, Dec 13 1997 12:53:30 ---- VERILINK NCM CONTROLLER : FW Rev 4.15, Dec 13 1997 12:53:30 - Site Name: Verilink Test Access Level: 2

Site Name: Verilink Test Access Level: 2

Site Name: Verilink Test Access Level: 2 Site Name: Verilink Test Access Level: 2 Managing at NEAR end node [127.255.255.0] Node ID: 0

Managing at NEAR end node [127.255.255.0] Node ID: 0

Managing at NEAR end node [127.255.255.0] Node ID: 0 Managing at NEAR end node [127.255.255.0] Node ID: 0 <- SLOT ->

<- SLOT ->

<- SLOT -> <- SLOT -> SHELF 1 2 3 4 5 6 7 8 9 10 11 12 13

SHELF 1 2 3 4 5 6 7 8 9 10 11 12 13

SHELF 1 2 3 4 5 6 7 8 9 10 11 12 13 SHELF 1 2 3 4 5 6 7 8 9 10 11 12 13 0 - - - - - - - - - - - - -

0 - - - - - - - - - - - - -

0 - - - - - - - - - - - - - 0 - - - - - - - - - - - - 1 D *N [X]

1 D *N [X]

1 D *N [X] 1 D *N [X] 2 - - - - - - - - - - - - -

2 - - - - - - - - - - - - -

2 - - - - - - - - - - - - - 2 - - - - - - - - - - - - 3 - - - - - - - - - - - - -

3 - - - - - - - - - - - - -

3 - - - - - - - - - - - - - 3 - - - - - - - - - - - - 4 - - - - - - - - - - - - -

4 - - - - - - - - - - - - -

4 - - - - - - - - - - - - - 4 - - - - - - - - - - - - KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM,

KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM,

KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM,KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM, H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, P=QPRI,

H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, P=QPRI,

H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, P=QPRI, H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, P=QPRI, Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI

Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI

Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI S) shelf/slot O) administration

S) shelf/slot O) administration

S) shelf/slot O) administrationS) shelf/slot O) administration C) configuration D) diagnostics

C) configuration D) diagnostics

C) configuration D) diagnosticsC) configuration D) diagnostics P) performance/status A) alarm

P) performance/status A) alarm

P) performance/status A) alarmP) performance/status A) alarm B) circuit manager I) manufacturing info

B) circuit manager I) manufacturing info

B) circuit manager I) manufacturing infoB) circuit manager I) manufacturing info X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [1,1] QPRI >

A [127.255.255.0] [1,1] QPRI >

A [127.255.255.0] [1,1] QPRI >A [127.255.255.0] [1,1] QPRI >

Node Address

Indicator for the type of shelf: M= Multi-line, D = Dual-line

❶

Asterisk indicates that the NCM is the Main Controller in the shelf

❷

Brackets around module letter ( [X] ) indicate current module selected

❸

❶

❷❸

Data (Command) Entry Area

2-4 Verilink QPRI 2921

Network Port Configuration

Quick Set-Up

1. From the NCM ASCII interface

Main Menu

, Figure 2-2, select the QPRI application module using option S, Shelf/Slot. When refreshed, the

Main Menu

will use brackets to enclose the P,

which indicates the QPRI.

2. From the

Main Menu

, select option C, “Configuration”, to start

the configuration task.

Figure 2-3 Configuration Menu

A [127.255.255.0] [0,11] QPRI > x

A [127.255.255.0] [0,11] QPRI > xA [127.255.255.0] [0,11] QPRI > x

-- QPRI CONFIGURATION MENU --

-- QPRI CONFIGURATION MENU ---- QPRI CONFIGURATION MENU -P) T1 port I) ISDN PRI

P) T1 port I) ISDN PRI

P) T1 port I) ISDN PRIP) T1 port I) ISDN PRI X) Exit this screen

X) Exit this screen

X) Exit this screenX) Exit this screen

3. From the

Configuration Menu

, Figure 2-3, select option P to

access the network port configuration menu, Figure 2-4.

Figure 2-4 T1 Port Configuration Menu

-- QPRI T1 PORT CONFIGURATION MENU --

-- QPRI T1 PORT CONFIGURATION MENU ---- QPRI T1 PORT CONFIGURATION MENU --

PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4 PORT 1 PORT 2 PORT 3 PORT 4

In) In Service YES YES YES YES

In) In Service YES YES YES YESIn) In Service YES YES YES YES Fn) Frame Format ESF ESF ESF ESF

Fn) Frame Format ESF ESF ESF ESF

Fn) Frame Format ESF ESF ESF ESFFn) Frame Format ESF ESF ESF ESF Ln) Line Coding B8ZS B8ZS B8ZS B8ZS

Ln) Line Coding B8ZS B8ZS B8ZS B8ZS

Ln) Line Coding B8ZS B8ZS B8ZS B8ZSLn) Line Coding B8ZS B8ZS B8ZS B8ZS Bn) Line Build Out -15db -15db 0-133ft 0-133ft

Bn) Line Build Out -15db -15db 0-133ft 0-133ft

Bn) Line Build Out -15db -15db 0-133ft 0-133ftBn) Line Build Out -15db -15db 0-133ft 0-133ft NDn) Network Density 12.5% 80s 12.5% 80s 12.5% 80s 12.5% 80s

NDn) Network Density 12.5% 80s 12.5% 80s 12.5% 80s 12.5% 80s

NDn) Network Density 12.5% 80s 12.5% 80s 12.5% 80s 12.5% 80sNDn) Network Density 12.5% 80s 12.5% 80s 12.5% 80s 12.5% 80s NLn) Network Initiated Loop YES NO NO NO

NLn) Network Initiated Loop YES NO NO NO

NLn) Network Initiated Loop YES NO NO NONLn) Network Initiated Loop YES NO NO NO An) Alarm Declare Time(sec) 0 0 0 0

An) Alarm Declare Time(sec) 0 0 0 0

An) Alarm Declare Time(sec) 0 0 0 0An) Alarm Declare Time(sec) 0 0 0 0 DLn) FDL Enable YES YES YES YES

DLn) FDL Enable YES YES YES YES

DLn) FDL Enable YES YES YES YESDLn) FDL Enable YES YES YES YES PRM Enable NO NO NO NO

PRM Enable NO NO NO NO

PRM Enable NO NO NO NO PRM Enable NO NO NO NO En) Enable ISDN Disabled Disabled N/A N/A

En) Enable ISDN Disabled Disabled N/A N/A

En) Enable ISDN Disabled Disabled N/A N/AEn) Enable ISDN Disabled Disabled N/A N/A F) FDL configuration

F) FDL configuration

F) FDL configurationF) FDL configuration C) Copy port T) Timing

C) Copy port T) Timing

C) Copy port T) TimingC) Copy port T) Timing X) Exit this screen

X) Exit this screen

X) Exit this screenX) Exit this screen

4. In the numeral 1, the I, then 2,

5. Press F, then 1,

T1 Port Configuration Menu

NTER

E

, then Y, to place Net Port 1 In Service. Press

NTER

E

, then Y, to place Net Port 2 In Service.

NTER

E

, then 2 to select ESF as your frame format for Net Port 1. Press F, then 2, frame format for Net Port 2.

NTER

E

6. Press L, then 1,

, then 2 to select B8ZS as the line coding for Net Port 1. Press L, then 2, the line coding for Net Port 2.

Verilink QPRI 2921 2-5

, press the letter I, then the

NTER

E

, then 2 to select ESF as the

NTER

E

, then 2 to select B8ZS as

Quick Set- Up

NTER

7. Press B, then 1, for Net Port 1 . Press B, then 2,

E

, then 1 to select 0db as the line build out

NTER

E

, then 1 to select 0db as the

line build out for Net Port 2.

NTER

E

8. Press ND, then 1, density for Net Port 1. Press ND, then 2,

, then 1 to select NONE as the network

NTER

E

, then 1 to select

NONE as the network density for Net Port 2.

NTER

9. Press NL, then 1, on Net Port 1. Press NL, then 2,

E

, then Y to allow network initiated loops

NTER

E

, then Y to allow network

initiated loops on Net Port 2.

NTER

10. Press A, then 1,

E

, then 0 if you do not want the alarm

declare time enabled on Net Port 1. Type a number 1 through

127

to indicate the number of seco nds to elapse before

declaring an alarm condi ti on to the system for Net Port 1.

NTER

Press A, then 2,

E

, then 0 if you do not want the alarm

declare time enabled on Net Port 2. Type a number 1 through

127

to indicate the number of seco nds to elapse before

declaring an alarm condi ti on to the system for Net Port 2.

NTER

11. Press DL, then 1, Press DL, then 2,

E

, then Y to enable FDL for Net Port 1.

NTER

E

, then Y to enable FDL for Net Port 2.

NTER

12. Press S, then 1,

E

, then the number 24 to set the signalling channel timeslot for Net Port 1. Press S, then 2, number 24 to set the signalling channel ti meslot fo r Net Port 2.

NTER

E

, then 1 to enable the inba nd for Net Port

NTER

E

, then 2 to enable ISDN for Net Port 2.

FDL Options

13. Press E, then 1,

1. Press E, then 2,

Facility Data Link is an ESF T1 port configuration option. The ESF FDL transmits framing information, error events, and loopback controls. FDL uses 4 kbit/s of bandwidth to transmit data. FDL cannot be used unless the network service provider (telco) has configured the T1 facility for ESF.

1. Press F to access the

Figure 2-5 Configuration Menu (FDL Options)

-- QPRI CONFIGURATION MENU (FDL OPTIONS)--

-- QPRI CONFIGURATION MENU (FDL OPTIONS)---- QPRI CONFIGURATION MENU (FDL OPTIONS)- PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4 PORT 1 PORT 2 PORT 3 PORT 4

Sn) FDL Standard T1.403 T1.403 T1.403 T1.403

Sn) FDL Standard T1.403 T1.403 T1.403 T1.403Sn) FDL Standard T1.403 T1.403 T1.403 T1.403 Mn) FDL Mode TERM TERM TERM TERM

Mn) FDL Mode TERM TERM TERM TERM

Mn) FDL Mode TERM TERM TERM TERMMn) FDL Mode TERM TERM TERM TERM Pn) Poll Mode NO POLL NO POLL NO POLL NO POLL

Pn) Poll Mode NO POLL NO POLL NO POLL NO POLL

Pn) Poll Mode NO POLL NO POLL NO POLL NO POLLPn) Poll Mode NO POLL NO POLL NO POLL NO POLL Cn) PRM C/R bit NONE NONE NONE NONE

Cn) PRM C/R bit NONE NONE NONE NONE

Cn) PRM C/R bit NONE NONE NONE NONECn) PRM C/R bit NONE NONE NONE NONE In) Idle Pattern FLAGS FLAGS FLAGS FLAGS

In) Idle Pattern FLAGS FLAGS FLAGS FLAGS

In) Idle Pattern FLAGS FLAGS FLAGS FLAGSIn) Idle Pattern FLAGS FLAGS FLAGS FLAGS An) Send/Rec LLB BOP YES YES YES YES

An) Send/Rec LLB BOP YES YES YES YES

An) Send/Rec LLB BOP YES YES YES YESAn) Send/Rec LLB BOP YES YES YES YES Bn) Send/Rec PLB BOP YES YES YES YES

Bn) Send/Rec PLB BOP YES YES YES YES

Bn) Send/Rec PLB BOP YES YES YES YESBn) Send/Rec PLB BOP YES YES YES YES X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

Configuration Menu (FDL Options)

NTER

E

, then the

.

2-6 Verilink QPRI 2921

Quick Set-Up

For each port:

NTER

E

2. Press S, then the port number,

, to assign the FDL

Standard to th e p ort. Options available for the FDL Standard are TR54016, T1.403,

or BOTH. This option deter mines how the network service provider examines and resets the ESF registers. Select the TR54016 option if your service provider is AT&T. Select T1.403 if your service provider is any other provider.

3. Press M, then the port number to s ho w op tions for the FDL Mode. Currently, TERM is the only one supported. PASS is NOT supported.

4. Press P, then the port number to show options for the Poll Mode. Your options are PO LL, NO POLL, and UNSOLICT. Th e above display shows that NO POLL has been selected.

5. Press C, then the port number to show options for the PRM C/R bit. Your options are NONE, USER, and TELCO.

6. Press I, then the port number to sho w op ti ons for the Idle Pattern. Options for th is parameter are ALL ONES or FLAGS. The above display shows the FLAGS option.

Timing Options

7. Press A, then the port number for the prompt whether you want to send/receive ANSI BOP LLB.

8. Press B, then the port number for the prompt whet her you want to send/receive ANSI BOP PL B.

1. When the FDL options have been selected, return to the

Configuration Menu Menu (Timing Options)

Figure 2-6 Configuration Menu (Timing Options)

A [127.255.255.0] [0,11] QPRI > t

A [127.255.255.0] [0,11] QPRI > tA [127.255.255.0] [0,11] QPRI > t

-- QPRI CONFIGURATION MENU (TIMING OPTIONS)--

-- QPRI CONFIGURATION MENU (TIMING OPTIONS)---- QPRI CONFIGURATION MENU (TIMING OPTIONS)-Current shelf timing source: Card 11, INTERNAL (TERTIARY)

Current shelf timing source: Card 11, INTERNAL (TERTIARY)

Current shelf timing source: Card 11, INTERNAL (TERTIARY)Current shelf timing source: Card 11, INTERNAL (TERTIARY) Source Slot Number Synchronization Auto Restore

Source Slot Number Synchronization Auto Restore

Source Slot Number Synchronization Auto RestoreSource Slot Number Synchronization Auto Restore PRIMARY PC) 11 PS) INTERNAL PA) NO

PRIMARY PC) 11 PS) INTERNAL PA) NO

PRIMARY PC) 11 PS) INTERNAL PA) NOPRIMARY PC) 11 PS) INTERNAL PA) NO SECONDARY SC) 11 SS) INTERNAL SA) NO

SECONDARY SC) 11 SS) INTERNAL SA) NO

SECONDARY SC) 11 SS) INTERNAL SA) NOSECONDARY SC) 11 SS) INTERNAL SA) NO TERTIARY TC) 11 TS) INTERNAL TA) NO

TERTIARY TC) 11 TS) INTERNAL TA) NO

TERTIARY TC) 11 TS) INTERNAL TA) NOTERTIARY TC) 11 TS) INTERNAL TA) NO R) Receive clock from shelf: YES

R) Receive clock from shelf: YES

R) Receive clock from shelf: YESR) Receive clock from shelf: YES X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

and then select T for the

submenu.

Configuration

2. All primary and dial -backup circuits must use shelf timing to synchronize with each other; therefore, select R, then then refresh the screen by exiting to the

Configuration Menu

and then returning to the screen by

T1 Port

YES

,

Verilink QPRI 2921 2-7

Quick Set- Up

R)

selecting T. When the been selected to be

Options)

menu displays as shown in Figure 2-4.

R)

“Receive clock from shelf” option has

R) R)

YES

Configuration Menu (Timing

, the

3. Use the ISDN network ports as the primary and secondary sources. Use

INTERNAL

as the tertiary source. For example, if the QPRI 2921 is in slot 2, the shelf timing table should look like Figure 2-4. Exit to the

Configuration Menu

.

NOTE:

Ensure that the card used as a ti ming so ur ce is set to Re cei ve Clock From Shelf as well.

ISDN PRI Port Configuration

The ISDN dial-back up circui t uses the NCM 2000 an d the QPR I 2921 to allow access to the ISDN circuit as an alternate T1 circuit under defined line failure conditions. Since the following procedures are for an example which may not be exactly like your configuration requirements, use them only as a guide for you r ow n configur ation.

NOTE:

Figure 2-7 Configuration Menu

From the display the following

Use the ISDN Setup Checklist to help guide you through the ISDN setup process .

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI > A [127.255.255.0] [0,11] QPRI >

-- QPRI CONFIGURATION MENU --

-- QPRI CONFIGURATION MENU ---- QPRI CONFIGURATION MENU -P) T1 port I) ISDN PRI

P) T1 port I) ISDN PRI

P) T1 port I) ISDN PRIP) T1 port I) ISDN PRI X) Exit this screen

X) Exit this screen

X) Exit this screenX) Exit this screen

Configuration Menu

(Figure 4-1) type I for

Configuration Menu

, Figure 2-8.

ISDN PRI

ISDN PRIISDN PRI

to

Figure 2-8

Configuration Menu

PRI

A [127.255.255.0] [0,11] QPRI > i

A [127.255.255.0] [0,11] QPRI > iA [127.255.255.0] [0,11] QPRI > i

-- QPRI CONFIGURATION MENU --

-- QPRI CONFIGURATION MENU ---- QPRI CONFIGURATION MENU -P) PRI Port Configuration C) PRI Call Profile

P) PRI Port Configuration C) PRI Call Profile

P) PRI Port Configuration C) PRI Call ProfileP) PRI Port Configuration C) PRI Call Profile A) PRI Statistics

A) PRI Statistics

A) PRI StatisticsA) PRI Statistics X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

1. Select P from the PRI

Configuration Menu

Port Configuration Menu

2-8 Verilink QPRI 2921

, Figure 3-3.

to display the

PRI

Figure 2-9 PRI Port Configuration Menu

A [127.255.255.0] [0,11] QPRI > p

A [127.255.255.0] [0,11] QPRI > pA [127.255.255.0] [0,11] QPRI > p

-- QPRI ISDN PORT CONFIGURATION MENU --

-- QPRI ISDN PORT CONFIGURATION MENU ---- QPRI ISDN PORT CONFIGURATION MENU - PORT 1 PORT 2

PORT 1 PORT 2

PORT 1 PORT 2 PORT 1 PORT 2 In) PRI In Service No No

In) PRI In Service No No

In) PRI In Service No NoIn) PRI In Service No No Fn) NFAS Mode No NFAS No NFAS

Fn) NFAS Mode No NFAS No NFAS

Fn) NFAS Mode No NFAS No NFASFn) NFAS Mode No NFAS No NFAS Dn) D-Channel Mode Normal Normal

Dn) D-Channel Mode Normal Normal

Dn) D-Channel Mode Normal NormalDn) D-Channel Mode Normal Normal Bn) D-Channel Bits 8 bits 8 bits

Bn) D-Channel Bits 8 bits 8 bits

Bn) D-Channel Bits 8 bits 8 bitsBn) D-Channel Bits 8 bits 8 bits Sn) Switch Type DMS 100 DMS 100

Sn) Switch Type DMS 100 DMS 100

Sn) Switch Type DMS 100 DMS 100Sn) Switch Type DMS 100 DMS 100 Pn) Own Numbering Plan ISDN-E.164 ISDN-E.164

Pn) Own Numbering Plan ISDN-E.164 ISDN-E.164

Pn) Own Numbering Plan ISDN-E.164 ISDN-E.164Pn) Own Numbering Plan ISDN-E.164 ISDN-E.164 Nn) Own Numbering Type National National

Nn) Own Numbering Type National National

Nn) Own Numbering Type National NationalNn) Own Numbering Type National National En) Security Level No checks No checks

En) Security Level No checks No checks

En) Security Level No checks No checksEn) Security Level No checks No checks Ln) L2 auto establish No No

Ln) L2 auto establish No No

Ln) L2 auto establish No NoLn) L2 auto establish No No X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [0,11] QPRI >>

A [127.255.255.0] [0,11] QPRI >>

A [127.255.255.0] [0,11] QPRI >>A [127.255.255.0] [0,11] QPRI >>

NTER

2. Press I, then 1,

NTER

then 2,

E

, then Y to put Port 1 in service. Press I,

, then Y to put Port 2 in service.

3. For NFAS mode (If you want the increased bandwidth capability from grouping the two lines together):

Quick Set-Up

a. Activate NFAS by pressing F1 for Port 1. Sele ct NFAS. Since NFAS controls the other port as well, there’s no need to

configure both ports. The NFAS configuration will apply to BOTH ports. (Port 1 is then the “controlling” port.)

b. Reboot the module by exiting all the way to the

Menu

, selecting O to display the

Administration Menu

Main

Figure 2-10. The card may also be rebooted by unseating it , then reseating it. (Rebooting is required whenever the NFAS setting is changed.)

Figure 2-10 NCM Controller Administration Menu (QPRI 2921 Card Administration Submenu)

[0.0.0.5] [1,2] QPRI 2921 > o

[0.0.0.5] [1,2] QPRI 2921 > o[0.0.0.5] [1,2] QPRI 2921 > o

-- NCM CONTROLLER ADMINISTRATION MENU --

-- NCM CONTROLLER ADMINISTRATION MENU ---- NCM CONTROLLER ADMINISTRATION MENU -Date/Time/Zone: 3-10-97 13:52:59

Date/Time/Zone: 3-10-97 13:52:59

Date/Time/Zone: 3-10-97 13:52:59Date/Time/Zone: 3-10-97 13:52:59 Node Address: [0.0.0.5]

Node Address: [0.0.0.5]

Node Address: [0.0.0.5]Node Address: [0.0.0.5] Node ID: 1

Node ID: 1

Node ID: 1Node ID: 1 Site Name: TAC-LAB

Site Name: TAC-LAB

Site Name: TAC-LABSite Name: TAC-LAB System Uptime: 4:03:03

System Uptime: 4:03:03

System Uptime: 4:03:03System Uptime: 4:03:03

--- QPRI 2921 -- Card Administration -- [01,02] ---

--- QPRI 2921 -- Card Administration -- [01,02] --- --- QPRI 2921 -- Card Administration -- [01,02] --O) switch over permanent

O) switch over permanent

O) switch over permanentO) switch over permanent Q) query firmware

Q) query firmware

Q) query firmwareQ) query firmware R) reset card

R) reset card

R) reset cardR) reset card Y) switch over once

Y) switch over once

Y) switch over onceY) switch over once U) clear card configuration

U) clear card configuration

U) clear card configurationU) clear card configuration X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen [0.0.0.5] [1,2] QPRI 2921 >

[0.0.0.5] [1,2] QPRI 2921 >

[0.0.0.5] [1,2] QPRI 2921 >[0.0.0.5] [1,2] QPRI 2921 >

,

Verilink QPRI 2921 2-9

Quick Set- Up

e. Select R) “reset card” to reboot the module and

implement NFAS.

NOTE:

If you use ESF /B 8ZS: Do not invert the D Channel Use 8 bits on the D Channe l

If you use SF/AMI: Invert the D Channel Use 7 bits on the D Channe l

4. Set the Switch Type, Own Numbering Plan, and Own Numbering Type according to the parameters your NSP has provided you (use the checksheet provided). The choices shown above are a possible (and recommended) configuration.

5. Set the Security Level according to your particular needs.

6. Set the L2 auto establish to “Yes”. It allows for verification of signal connection.

PRI Call Profile

From the Profile”, to display the

Figure 2-11 PRI Call Profile Configuration Menu

A [127.255.255.0] [0,11] QPRI > c

A [127.255.255.0] [0,11] QPRI > cA [127.255.255.0] [0,11] QPRI > c

-- QPRI CALL PROFILE CONFIGURATION MENU --

-- QPRI CALL PROFILE CONFIGURATION MENU ---- QPRI CALL PROFILE CONFIGURATION MENU --

1) Port 1 Call Profile 2) Port 2 Call Profile

1) Port 1 Call Profile 2) Port 2 Call Profile1) Port 1 Call Profile 2) Port 2 Call Profile X) Exit this screen

X) Exit this screen

X) Exit this screenX) Exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

PRI Configuration Menu

PRI Call Profile Configuration Menu

, Figure 2-8, choose C, “PRI Call

.

Choose the port to configure to display the

Configuration Menu

. No call profile of Port 2 is available when in

NFAS mode.

Figure 2-12 Port 1 PRI Call Profile Configuration Menu (sample)

-- QPRI PORT 1 CALL PROFILE CONFIGURATION MENU --

-- QPRI PORT 1 CALL PROFILE CONFIGURATION MENU ---- QPRI PORT 1 CALL PROFILE CONFIGURATION MENU -Ref Own Number Ext Number Bandwidth Direction Status

Ref Own Number Ext Number Bandwidth Direction Status

Ref Own Number Ext Number Bandwidth Direction StatusRef Own Number Ext Number Bandwidth Direction Status A) Add Call Profile M) Modify Call Profile

A) Add Call Profile M) Modify Call Profile

A) Add Call Profile M) Modify Call ProfileA) Add Call Profile M) Modify Call Profile S) Set Call Action D) Delete Call Profile

S) Set Call Action D) Delete Call Profile

S) Set Call Action D) Delete Call ProfileS) Set Call Action D) Delete Call Profile X) Exit this screen

X) Exit this screen

X) Exit this screenX) Exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

NOTE:

NFAS can have up to 48 call profiles on port 1 only. Without NFAS you can only have up to 24 call profiles per port .

1. Select A to add a call profil e . Each connection th at ne e ds a backup needs a call profile.

2-10 Verilink QPRI 2921

Port n Call Profile

Figure 2-13 PRI Port 1 Add Call Profile Menu

A [127.255.255.0] [0,11] QPRI > a

A [127.255.255.0] [0,11] QPRI > aA [127.255.255.0] [0,11] QPRI > a

-- QPRI PORT 1 ADD CALL PROFILE MENU --

-- QPRI PORT 1 ADD CALL PROFILE MENU ---- QPRI PORT 1 ADD CALL PROFILE MENU -R) Call Profile Ref 0

R) Call Profile Ref 0

R) Call Profile Ref 0R) Call Profile Ref 0 D) Call Direction Deleted

D) Call Direction Deleted

D) Call Direction DeletedD) Call Direction Deleted O) No. of Own Digits 0

O) No. of Own Digits 0

O) No. of Own Digits 0O) No. of Own Digits 0 N) Own Call Number ----

N) Own Call Number ----

N) Own Call Number ----N) Own Call Number ---I) Ext Numbering Plan ISDN-E.164

I) Ext Numbering Plan ISDN-E.164

I) Ext Numbering Plan ISDN-E.164I) Ext Numbering Plan ISDN-E.164 U) Ext Numbering Type International

U) Ext Numbering Type International

U) Ext Numbering Type InternationalU) Ext Numbering Type International C) Ext No. of Digits 0

C) Ext No. of Digits 0

C) Ext No. of Digits 0C) Ext No. of Digits 0 P) Ext Call Number ----

P) Ext Call Number ----

P) Ext Call Number ----P) Ext Call Number ---T) Transfer Mode Unrestricted

T) Transfer Mode Unrestricted

T) Transfer Mode UnrestrictedT) Transfer Mode Unrestricted B) Call Bandwidth B1=64K

B) Call Bandwidth B1=64K

B) Call Bandwidth B1=64KB) Call Bandwidth B1=64K M) MultiRate Count ----

M) MultiRate Count ----

M) MultiRate Count ----M) MultiRate Count ---A) Rate Adaption None

A) Rate Adaption None

A) Rate Adaption NoneA) Rate Adaption None E) Test Call Interval(min.) 0

E) Test Call Interval(min.) 0

E) Test Call Interval(min.) 0E) Test Call Interval(min.) 0 S) Send Call Profile

S) Send Call Profile

S) Send Call ProfileS) Send Call Profile X) Exit Screen

X) Exit Screen

X) Exit ScreenX) Exit Screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

Quick Set-Up

2. R) Call Profile Ref—Select an identifying reference number that is distinct from any previously used IDs for the selected port. (Use the Modify option to change existing call profiles.) You may choose a number from 1 th rough 48 for this reference ID number. If you do not choose a number, the QPRI will select the lowest available reference ID.

3. D) Call Direction—Select whether the call profile is for incoming calls, outgoing calls, or both. “Deleted” invalidates the call profile. “Both” is recommended.

4. O) No. of Own Digits—Number of digits in your phone number. Enter the number of digits in your phone number (1 through

15). If the number is smaller than the length of an existing string associated below, you will be prompted to confirm whether or not you want t o trunc ate the stri ng. If the response to the prompt is Y, the associated string wil be truncated; otherwise, the length will not be accepted.

5. N) Own Call Number—Enter your own phone number (The number from which you are calling). If the entere d str i ng exceeds the associated length as specified above, the string will be truncated.

For outgoing calls, your “Own Call Number” is the CLID (calling line ID) or station ID (SID).

For incoming calls, your “Own Call Number” is the DNIS (dialed number information service).

Talk to your own telephone department or carrier to decide how to assign th e call nu mber.

Verilink QPRI 2921 2-11

Quick Set- Up

6. I) Ext Numbering Plan—A sk your NSP for their external numbering plan. Your choices are “Unknown”, “ISDN-E.164”, “Telephone-E.163”, or “Private”.

7. U) Ext Numbering Type—Ask your NSP for their number type (usually National) . Your choices are “Unknown”, “International”, “National”, or “Local”.

8. C) Ext No. of Digits—The number o f di gi ts in the external phone number (1 through 15). If the number is smaller than the length of an existing string associated below, you will be prompted to confirm whether or not you want to truncate the string. If the response to the prompt is Y, the associated string will be truncated; otherwise, the length will not be accepted.

9. P) Ext Call Number—Enter the external phone number being called (The number you are calling). If the entered string exceeds the associated length as specified above, the string will be truncated. On incoming calls, this number is the CLID or SID. For outgoing calls, this is the dialed number and will be delivered as DNIS at the receiving end.

10. T ) Transfer Mode—If either or both ends of the ISDN circuit have AMI, choose “Restricted” transfer mode and “56K” for the rate adaption. If both ends are B8ZS, choose “Unrestricted” and “None” for the rate adapti on. (Ask your NSP).

11. B) Call Bandwidth—For Multirate ISDN, set “Call Bandwidth” option to “Multirate”. Select the desire d number of multirate channels, up to 24. Otherwise, you have the option of B1=64K.

12. M) Multirate Count—Select the desired number of multirate channels, up to 24.

13. A) Rate Adaption— If either or both ends of the ISDN circuit have AMI, and “Restricted” transfer mode has been selected, choose “56K” for the rate adaption. I f both ends are B8ZS, and “Unrestricted” transfer mode has been selected, choose “None” for the rate adapti on. Rate adaption is diff erent from restricted or unrestricted mode.

14. E) Test Call Interval (mi n.)—Set the interval time for test calls. Choose 0, and this feature is di sa bl e d . DO NOT use test calls.

15. S) Send Call Profile—Select this option to

SET

the parameters you have chosen in the p revious steps. If y ou do not select this option before exiting the

PRI Port n Add Call Pro file Menu

,

the parameters will NOT be set.

16. Repeat this set of procedures for EACH call profile you intend to have.

2-12 Verilink QPRI 2921

Setting Alarm (Backup Trigger) Para mete rs

When normal service is interrupted, errored, or lost, an alarm triggers the backup circuit. Th eref ore, this alarm must be set for the ports you want to monitor/trigger for backup activation.

Quick Set-Up

1. Select A from the

Port Alarm Menu

Main Menu

.

, Figure 2-1, to access the

2. Set the “Card Alarm Reporting” option (A) to “YES”.

Figure 2-14 Net Port Alarm Menu

A [127.255.255.0] [1,2] QPRI > a

A [127.255.255.0] [1,2] QPRI > aA [127.255.255.0] [1,2] QPRI > a

-- QPRI NET PORT ALARM MENU --

-- QPRI NET PORT ALARM MENU ---- QPRI NET PORT ALARM MENU -N) NMS Address 128.0.0.0

N) NMS Address 128.0.0.0

N) NMS Address 128.0.0.0N) NMS Address 128.0.0.0 A) Card Alarm Reporting YES

A) Card Alarm Reporting YES

A) Card Alarm Reporting YESA) Card Alarm Reporting YES C) Configure Thresholds S) Alarm status

C) Configure Thresholds S) Alarm status

C) Configure Thresholds S) Alarm statusC) Configure Thresholds S) Alarm status O) Display Alarm Buffer Tn) Set Default Thresholds

O) Display Alarm Buffer Tn) Set Default Thresholds

O) Display Alarm Buffer Tn) Set Default ThresholdsO) Display Alarm Buffer Tn) Set Default Thresholds X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen

3. Select C to configure thr es h o lds.

Figure 2-15 Net Port Alarm Threshold Configuration Menu

A [127.255.255.0] [0,11] QPRI > c

A [127.255.255.0] [0,11] QPRI > cA [127.255.255.0] [0,11] QPRI > c

-- QPRI NET PORT ALARM THRESHOLD CONFIGURATION MENU --

-- QPRI NET PORT ALARM THRESHOLD CONFIGURATION MENU ---- QPRI NET PORT ALARM THRESHOLD CONFIGURATION MENU - PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4 PORT 1 PORT 2 PORT 3 PORT 4 Pn) Alarm Reporting(NET) YES YES YES YES

Pn) Alarm Reporting(NET) YES YES YES YES

Pn) Alarm Reporting(NET) YES YES YES YESPn) Alarm Reporting(NET) YES YES YES YES Fn) LOF threshold 3 3 3 3

Fn) LOF threshold 3 3 3 3

Fn) LOF threshold 3 3 3 3Fn) LOF threshold 3 3 3 3 LOF interval 3 3 3 3

LOF interval 3 3 3 3

LOF interval 3 3 3 3 LOF interval 3 3 3 3 Ln) LOS threshold 3 3 3 3

Ln) LOS threshold 3 3 3 3

Ln) LOS threshold 3 3 3 3Ln) LOS threshold 3 3 3 3 LOS interval 3 3 3 3

LOS interval 3 3 3 3

LOS interval 3 3 3 3 LOS interval 3 3 3 3 Rn) RAI threshold 1 1 1 1

Rn) RAI threshold 1 1 1 1

Rn) RAI threshold 1 1 1 1Rn) RAI threshold 1 1 1 1 RAI interval 1 1 1 1

RAI interval 1 1 1 1

RAI interval 1 1 1 1 RAI interval 1 1 1 1 An) AIS threshold 1 1 1 1

An) AIS threshold 1 1 1 1

An) AIS threshold 1 1 1 1An) AIS threshold 1 1 1 1 AIS interval 1 1 1 1

AIS interval 1 1 1 1

AIS interval 1 1 1 1 AIS interval 1 1 1 1 Bn) BPV threshold 1 1 1 1

Bn) BPV threshold 1 1 1 1

Bn) BPV threshold 1 1 1 1Bn) BPV threshold 1 1 1 1 BPV interval 1 1 1 1

BPV interval 1 1 1 1

BPV interval 1 1 1 1 BPV interval 1 1 1 1 En) ES 15min threshold 900 900 900 900

En) ES 15min threshold 900 900 900 900

En) ES 15min threshold 900 900 900 900En) ES 15min threshold 900 900 900 900 ES 24hr threshold 86400 86400 86400 86400

ES 24hr threshold 86400 86400 86400 86400

ES 24hr threshold 86400 86400 86400 86400 ES 24hr threshold 86400 86400 86400 86400 Sn) SES 15min threshold 900 900 900 900

Sn) SES 15min threshold 900 900 900 900

Sn) SES 15min threshold 900 900 900 900Sn) SES 15min threshold 900 900 900 900 SES 24hr threshold 86400 86400 86400 86400

SES 24hr threshold 86400 86400 86400 86400

SES 24hr threshold 86400 86400 86400 86400 SES 24hr threshold 86400 86400 86400 86400 In) BER threshold DISABLE DISABLE DISABLE DISABLE

In) BER threshold DISABLE DISABLE DISABLE DISABLE

In) BER threshold DISABLE DISABLE DISABLE DISABLEIn) BER threshold DISABLE DISABLE DISABLE DISABLE X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

Net

4. Enable Net Ports Alarm Reporting (NET) by setting the value Pn to “YES”.

Verilink QPRI 2921 2-13

Quick Set- Up

Building Circuits

Circuit building is a p rimar y f uncti on of th e N CM 2000 . For genera l information on circuit building, refer to the NCM 2000 User Manual. This section provides “Quick Set-up” circuit building information specifically for the QPRI 2921 with material not covered in the NCM 2000 User Manual. For more details on circu it building, refer to the section on circuit building in Chapter 3 of this document.

NOTE:

If you are adding an NCM into a node that has other modules with pre-existing circuits, the circuits must be cleared before using the modules with the NCM or bui lding new circuits with the NCM Circuit Manager.

Build main and backup circuits using the Figure 2-20, by selecting B from the

Figure 2-16 Circuit Manager Menu

A [127.255.255.0] [1,2] QPRI > b

A [127.255.255.0] [1,2] QPRI > bA [127.255.255.0] [1,2] QPRI > b Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 --

Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 --

Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 --Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 - >>>>>> NO CIRCUIT FOUND IN DATABASE <<<<<

>>>>>> NO CIRCUIT FOUND IN DATABASE <<<<<

>>>>>> NO CIRCUIT FOUND IN DATABASE <<<<< >>>>>> NO CIRCUIT FOUND IN DATABASE <<<<< A) add circuit L) search circuit

A) add circuit L) search circuit

A) add circuit L) search circuit A) add circuit L) search circuit D) delete circuit E) edit circuit

D) delete circuit E) edit circuit

D) delete circuit E) edit circuit D) delete circuit E) edit circuit P) prev page I) activate circuit

P) prev page I) activate circuit

P) prev page I) activate circuit P) prev page I) activate circuit N) next page R) deactivate circuit

N) next page R) deactivate circuit

N) next page R) deactivate circuit N) next page R) deactivate circuit X) exit to craft main menu

X) exit to craft main menu

X) exit to craft main menu X) exit to craft main menu A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

Main Menu

When this menu is activ ate d fo r the fir st ti me , an d no cir cu its hav e been built yet, the mesage

NO CIRCUIT FOUND IN DATABASE

display.

Figure 2-17 Add Circuit Menu

A [127.255.255.0] [1,2] QPRI > a

A [127.255.255.0] [1,2] QPRI > aA [127.255.255.0] [1,2] QPRI > a Add Circuit -- [1,1] NCM 2000 Firmware 4.15 --

Add Circuit -- [1,1] NCM 2000 Firmware 4.15 --

Add Circuit -- [1,1] NCM 2000 Firmware 4.15 --Add Circuit -- [1,1] NCM 2000 Firmware 4.15 - N) Name: -- P) Priority: norm

N) Name: -- P) Priority: norm

N) Name: -- P) Priority: norm N) Name: -- P) Priority: norm T) Type: -- M) Mode: --

T) Type: -- M) Mode: --

T) Type: -- M) Mode: -- T) Type: -- M) Mode: -SP) [-,-] undefined DP) [-,-] undefined

SP) [-,-] undefined DP) [-,-] undefined

SP) [-,-] undefined DP) [-,-] undefinedSP) [-,-] undefined DP) [-,-] undefined SM) --src port chn-- DM) --dst port chn--

SM) --src port chn-- DM) --dst port chn--

SM) --src port chn-- DM) --dst port chn--SM) --src port chn-- DM) --dst port chn- (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<-

U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<-

U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<- U) Bus: -- ->-->>->> Circuit Inactive <<-<<--< S) Setup X) Exit

S) Setup X) Exit

S) Setup X) Exit S) Setup X) Exit A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

Circuit Manager Menu

, Figure 2-1.

will

,

2-14 Verilink QPRI 2921

Figure 2-18 Circuit Manager Menu (With Circuits Added)

Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 --

Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 --Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 - Page : 1

Page : 1

Page : 1 Page : 1 Total: 2 circuits

Total: 2 circuits

Total: 2 circuits Total: 2 circuits Name Type Mode Prio Src Port Dest Port Bus Status

Name Type Mode Prio Src Port Dest Port Bus Status

Name Type Mode Prio Src Port Dest Port Bus Status Name Type Mode Prio Src Port Dest Port Bus Status

------------ ---- ---- ---- ---------------- ---------------- --- ------

------------ ---- ---- ---- ---------------- ---------------- --- ------------------ ---- ---- ---- ---------------- ---------------- --- -----QPRItestC1 prim 64k crit [1, 2] QPRI net 3 [1, 2] QPRI net1 INT Inacti

QPRItestC1 prim 64k crit [1, 2] QPRI net 3 [1, 2] QPRI net1 INT Inacti

QPRItestC1 prim 64k crit [1, 2] QPRI net 3 [1, 2] QPRI net1 INT InactiQPRItestC1 prim 64k crit [1, 2] QPRI net 3 [1, 2] QPRI net1 INT Inacti dialbackup d-bk 64k crit [1, 2] QPRI net 4 [1, 2] QPRI net2 -- Inacti

dialbackup d-bk 64k crit [1, 2] QPRI net 4 [1, 2] QPRI net2 -- Inacti

dialbackup d-bk 64k crit [1, 2] QPRI net 4 [1, 2] QPRI net2 -- Inactidialbackup d-bk 64k crit [1, 2] QPRI net 4 [1, 2] QPRI net2 -- Inacti A) add circuit L) search circuit

A) add circuit L) search circuit

A) add circuit L) search circuit A) add circuit L) search circuit D) delete circuit E) edit circuit

D) delete circuit E) edit circuit

D) delete circuit E) edit circuit D) delete circuit E) edit circuit P) prev page I) activate circuit

P) prev page I) activate circuit

P) prev page I) activate circuit P) prev page I) activate circuit N) next page R) deactivate circuit

N) next page R) deactivate circuit

N) next page R) deactivate circuit N) next page R) deactivate circuit X) exit to craft main menu

X) exit to craft main menu

X) exit to craft main menu X) exit to craft main menu A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

Figure 2-19 Add Circuit Menu

A [127.255.255.0] [1,2] QPRI > a

A [127.255.255.0] [1,2] QPRI > aA [127.255.255.0] [1,2] QPRI > a Add Circuit -- [1,1] NCM 2000 Firmware 4.15 --

Add Circuit -- [1,1] NCM 2000 Firmware 4.15 --

Add Circuit -- [1,1] NCM 2000 Firmware 4.15 --Add Circuit -- [1,1] NCM 2000 Firmware 4.15 - N) Name: -- P) Priority: norm

N) Name: -- P) Priority: norm

N) Name: -- P) Priority: norm N) Name: -- P) Priority: norm T) Type: -- M) Mode: --

T) Type: -- M) Mode: --

T) Type: -- M) Mode: -- T) Type: -- M) Mode: -SP) [-,-] undefined DP) [-,-] undefined

SP) [-,-] undefined DP) [-,-] undefined

SP) [-,-] undefined DP) [-,-] undefinedSP) [-,-] undefined DP) [-,-] undefined SM) --src port chn-- DM) --dst port chn--

SM) --src port chn-- DM) --dst port chn--

SM) --src port chn-- DM) --dst port chn--SM) --src port chn-- DM) --dst port chn- (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<-

U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<-

U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<- U) Bus: -- ->-->>->> Circuit Inactive <<-<<--< S) Setup X) Exit

S) Setup X) Exit

S) Setup X) Exit S) Setup X) Exit A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

Quick Set-Up

Figure 2-20 Circuit Manager Menu

[0.0.0.5] [1,2] QPRI > b

[0.0.0.5] [1,2] QPRI > b[0.0.0.5] [1,2] QPRI > b

Circuit Manager -- [1,1] NCM 2000 Firmware 1.94 --

Circuit Manager -- [1,1] NCM 2000 Firmware 1.94 --Circuit Manager -- [1,1] NCM 2000 Firmware 1.94 - Page : 1

Page : 1

Page : 1 Page : 1 Total: 2 circuits

Total: 2 circuits

Total: 2 circuits Total: 2 circuits Name Type Mode Prio Src Port Dest Port Bus Status

Name Type Mode Prio Src Port Dest Port Bus Status

Name Type Mode Prio Src Port Dest Port Bus Status Name Type Mode Prio Src Port Dest Port Bus Status

------------ ---- ---- ---- ---------------- ---------------- --- ------

------------ ---- ---- ---- ---------------- ---------------- --- ------------------ ---- ---- ---- ---------------- ---------------- --- -----a prim 64k norm [1, 2] QPRI NET1 [1, 2] QPRI NET3 Non Inacti

a prim 64k norm [1, 2] QPRI NET1 [1, 2] QPRI NET3 Non Inacti

a prim 64k norm [1, 2] QPRI NET1 [1, 2] QPRI NET3 Non Inactia prim 64k norm [1, 2] QPRI NET1 [1, 2] QPRI NET3 Non Inacti b d-bkp 64k norm [1, 5] QPRI NET1 [1, 5] QPRI NET4 Non Active

b d-bkp 64k norm [1, 5] QPRI NET1 [1, 5] QPRI NET4 Non Active

b d-bkp 64k norm [1, 5] QPRI NET1 [1, 5] QPRI NET4 Non Activeb d-bkp 64k norm [1, 5] QPRI NET1 [1, 5] QPRI NET4 Non Active A) add circuit L) search circuit

A) add circuit L) search circuit

A) add circuit L) search circuit A) add circuit L) search circuit D) delete circuit E) edit circuit

D) delete circuit E) edit circuit

D) delete circuit E) edit circuit D) delete circuit E) edit circuit P) prev page I) activate circuit

P) prev page I) activate circuit

P) prev page I) activate circuit P) prev page I) activate circuit N) next page R) deactivate circuit

N) next page R) deactivate circuit

N) next page R) deactivate circuit N) next page R) deactivate circuit X) exit to craft main menu

X) exit to craft main menu

X) exit to craft main menu X) exit to craft main menu [0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >[0.0.0.5] [1,2] QPRI >

•

Build T1 to T1 or CPE Port to T1 circuits as the primary circuit.

Verilink QPRI 2921 2-15

Quick Set- Up

•

Port providing backup is the Source port of the primary circuit.

•

Circuit type is “Pri mary” for the main circuit and “Dial Bkup” for the ISDN dial backu p c ircuit. Use “Switched” to manually activate the T1 or ISDN circuit.

•

Set the Call Reference Value to the Call Profile Number defined before (the Call Reference Number is the Call Profile Number).

Activate the Primary Circuit

•

Activate the primary circuit from the by selecting I.

•

Create an error to test the dial backup circuit or set a test call interval from the selecting M from within the

Configuration Menu

PRI Modify Call Profile

Port PRI Call Profile

.

Circuit Manager

Menu accessed by

menu

2-16 Verilink QPRI 2921

When Information Required Notes

Quick Set-Up

Before Ordering ISDN

Check for availability—Ca ll or otherwis e access your network service provider (telco)

What applica tio ns?

•Data only What type of equipment will be hooked up?

Manufacturer/B rand Names? Serial/Model Numbers?

• Terminal Adapter (TA)

•Bridge

•Router

•ISDN Telephone How will the equipment be hooked up? Between the

telco and the Verilink equipment? Between the Verilink equipment and your equipment?

ISDN Circuit ID Number ISDN Ordering Code (IOC) (I f required by your telco) Service and billing address Your contact nam e and nu m ber Telco contact name and number Telco to provide inside wiring and jack?

Should be Dat a only. Tell your telco that you want the switch configured for DATA ONLY.

No TA supported.

Telco Will Provide

Desired long-distance carrier Availability confirmation

Estimated pricing Confirmatio n call

•Due date

• Switch type

• Service profile identifiers (SPIDs)

•Directory numbers Fulfillment package

• Troubleshooting guide

SPIDs may not be applicable.

Verilink QPRI 2921 2-17

Quick Set- Up

2-18 Verilink QPRI 2921

Chapter

3

ISDN Access

ISDN and Routine Management Tasks

Configuring the QPRI 2921 Via the NCM 2000 Craft Interface

For ISDN functionality, the QPRI 2921 Craft interface

accessed from the NCM 2000 module

direct cable connecti on from the NCM 2000 module fro nt panel to an ASCII terminal or PC running a terminal emulator prog ram, or using the NCM 2000’s Telnet capability.

To set up the dial-backup circuit feature, please see Chapter 2, “Creating an ISDN Dial-Backup Circuit”.

The following major functions are available through the Craft interface:

•

T1 port, equipment port, and timing parameter configuration

•

Network and equipment port diagnostics

•

Performance, status, and alarm monitoring

•

Circuit building, editing, and viewing

. This may be done with a

must be

Logging On

In addition to the Craft interface, you can use Verili nk’s Node Manager—a graphical user interface (GUI) management software package—to configure the QPRI module. For mo re information, see the Node Manager for Windows 95 User Manual.

1. To access the NCM/QPR I for the fi rst time vi a the NCM 200 0, at

psH+>

the

psH+>psH+>

NTER

E

psH+>

psH+> psH+>

2. When accessing the NCM/QPRI for the first time, at the

YOUR PASSWORD

YOUR PASSWORDYOUR PASSWORD

Until you change the password, the password. If you have changed the default password, then type the correct password (up to 8 characters, including spaces). The screen will display placeholders ( type the password. After ty pin g th e pass w or d, pr e ss

prompt type

. (Note that the NCM interface will return you to the

prompt after 15 minutes of inactivity at the keyboard.)

prompt, press

craft

(in lowercase letters), then press

NTER

E

.

NTER

E

key is the default

******

************

) as you

NTER

E

.

Verilink QPRI 2921 3-1

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

NCM Main Menu

NOTE:

For more information on NCM security or password assignment, see the NCM 2000 User Manual.

The of the selected node.

NOTE:

In the screen displayed via the

Setting the password on the NCM has no effect on the passwords of the QPRI or other modules in the node . To set the password for the QPRI module, you must access the QPRI module via dire ct connection.

NCM Main Menu

This manual deals with the QPRI module in particular and the NCM module with regard only to how the NCM module interacts with the QPRI module.

•

Slots containing QPRI modules show a rows and columns that designate t he shelf/slot location of the QPRI module.

•

The letter

•

The letter surrounded by br ackets ( of the module that is referenced and modified via submenus of the

•

On initial log in, brackets surround the module being used as the log-in access point.

•

NCM Controller Menu

The move to a desired module in the node.

NNNN

NCM Controller Menu

displays the contents of slots in the shelves

NCM Main Menu

shows the location(s) co ntaining NCM module(s).

[ ]

) designates the location

[ ][ ]

.

option S (shelf/slot) is used to

:

PPPP

at the intersection of

In Figure 3-1, the

PPPP)

by

in slot 2. Using the accessed module indicated by the square brackets ( changed to the QPRI 2921 in slot 2. The asterisk next to the (which designa tes the NCM 2000 module) indicates that the NCM 2000 module is the node mast er.

NOTE:

3-2 Verilink QPRI 2921

Many of the QPRI 2921 ASCII screens accessed via the NCM 2000 will differ significantly from those accessed via the QPRI Local Port.

NCM Main Menu

S) shelf/slot

shows a QPRI 2921 (designated

command, the curren tly

[ ]

) has been

[ ][ ]

NNNN

Figure 3-1 NCM Main Menu

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Firmware Version and Date of Release

Node Addre ss

Access Level (1-4)

Menu Heading Area

Node “Map” (Physical Location of Modules)

Module Key

Command List

Active NCM Master Designator

-- VERILINK NCM CONTROLLER : FW Rev 4.15, Dec 13 1997 12:53:30 --

-- VERILINK NCM CONTROLLER : FW Rev 4.15, Dec 13 1997 12:53:30 ---- VERILINK NCM CONTROLLER : FW Rev 4.15, Dec 13 1997 12:53:30 - Site Name: Verilink Test Access Level: 2

Site Name: Verilink Test Access Level: 2

Site Name: Verilink Test Access Level: 2 Site Name: Verilink Test Access Level: 2 Managing at NEAR end node [127.255.255.0] Node ID: 0

Managing at NEAR end node [127.255.255.0] Node ID: 0

Managing at NEAR end node [127.255.255.0] Node ID: 0 Managing at NEAR end node [127.255.255.0] Node ID: 0 <- SLOT ->

<- SLOT ->

<- SLOT -> <- SLOT -> SHELF 1 2 3 4 5 6 7 8 9 10 11 12 13

SHELF 1 2 3 4 5 6 7 8 9 10 11 12 13

SHELF 1 2 3 4 5 6 7 8 9 10 11 12 13 SHELF 1 2 3 4 5 6 7 8 9 10 11 12 13 0 - - - - - - - - - - - - -

0 - - - - - - - - - - - - -

0 - - - - - - - - - - - - - 0 - - - - - - - - - - - - 1 D *N [X]

1 D *N [X]

1 D *N [X] 1 D *N [X] 2 - - - - - - - - - - - - -

2 - - - - - - - - - - - - -

2 - - - - - - - - - - - - - 2 - - - - - - - - - - - - 3 - - - - - - - - - - - - -

3 - - - - - - - - - - - - -

3 - - - - - - - - - - - - - 3 - - - - - - - - - - - - 4 - - - - - - - - - - - - -

4 - - - - - - - - - - - - -

4 - - - - - - - - - - - - - 4 - - - - - - - - - - - - KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM,

KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM,

KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM,KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM, H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, P=QPRI,

H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, P=QPRI,

H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, P=QPRI, H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, P=QPRI, Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI

Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI

Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI S) shelf/slot O) administration

S) shelf/slot O) administration

S) shelf/slot O) administrationS) shelf/slot O) administration C) configuration D) diagnostics

C) configuration D) diagnostics

C) configuration D) diagnosticsC) configuration D) diagnostics P) performance/status A) alarm

P) performance/status A) alarm

P) performance/status A) alarmP) performance/status A) alarm B) circuit manager I) manufacturing info

B) circuit manager I) manufacturing info

B) circuit manager I) manufacturing infoB) circuit manager I) manufacturing info X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [1,1] QPRI >

A [127.255.255.0] [1,1] QPRI >

A [127.255.255.0] [1,1] QPRI >A [127.255.255.0] [1,1] QPRI >

Node Address

Indicator for the type of shelf: M= Multi-line, D = Dual-line

❶

Asterisk indicates that the NCM is the Main Controller in the shelf

❷

Brackets around module letter ( [X] ) indicate current module selected

❸

❶

❷❸

Data (Command) Entry Area

The node master is the module responsible for:

•

Collecting alarm information for the node.

•

Controlling the relay responsible for reflecting the node’s alarm status. (The relay is activated if any module is in major or critical alarm status. See the NCM 2000 User Manual.)

•

Controlling circuit builder.

Menus and reports are available for the QPRI 2921 via the NCM 2000 by using the S (shelf/slot) option of the

NCM Main Menu

select a QPRI module.

Verilink QPRI 2921 3-3

to

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Shelf and Slot Parameters

To access a QPRI module from the

Main Menu

, enter S to specify

the Shelf/Slot address.

•

If the module slot address is al ready on the current shelf, enter the slot number, then press

•

If the module slot address is on a different shelf, enter the

E

NTER

.

shelf number followed by a comma and then the slot number

1,3

(e.g.,

Table 3-1 Shelf/Slot Designation

Command Description Options

S

Shelf: Use this field to select the shelf containing the QPRI 2921 you want to access.

Slot: Use this field to select the slot containing the QPRI 2921 you want to access.

) then press

E

NTER

.

0–4

1–13 (Multiline) 1–2 (Dual-line)

NCM/QPRI 2921 Main Menu Commands

Once the QPRI module has been selected, the commands pertain to that module. The following commands are available on the

Table 3-2 Main Menu Commands

Main Menu

(Figure 3-1) to manage the QPRI 2921:

Main Menu

Command Description

S O C D

P A

B

I

X

Shelf/slot: Using this command, you can navigate from one card to another, Table 3-1. Administration, Figu re 3-2, Table 3-3. Configuration, Figure 3-3, Table 3-4. Diagnostics, Figure 3-16, Table 3-15. Performance/Status, Figure 3-17, Table 3-16. Alarm—Figure 3- 21,Table 3-19. Circuit manager—F igure 3-25 , Table 3-21. F or more in formati on on this option, see th e

User Manual

Manufacturing Info—Displays hardwa re information for th e appropriate card, Figur e 3-31. Exit—System log-off, Fi gure 3-32.

.

NCM

3-4 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Administration Menu

When the shelf/slot address for the QPRI 2921 is selected from the

NCM Main Menu Main Menu

2921. Command O displays the

Menu’s QPRI 2921 Card Administration Submenu

Figure 3-2 NCM Controller Administration Menu (QPRI 2921 Card Administration Submenu)

-- NCM CONTROLLER ADMINISTRATION MENU --

-- NCM CONTROLLER ADMINISTRATION MENU ---- NCM CONTROLLER ADMINISTRATION MENU -Date/Time/Zone: 05-31-01 17:27:46

Date/Time/Zone: 05-31-01 17:27:46

Date/Time/Zone: 05-31-01 17:27:46Date/Time/Zone: 05-31-01 17:27:46 Node Address: [127.255.255.0]

Node Address: [127.255.255.0]

Node Address: [127.255.255.0]Node Address: [127.255.255.0] Node ID: 20

Node ID: 20

Node ID: 20Node ID: 20 Site Name:

Site Name:

Site Name:Site Name: System Uptime: 17:25:27

System Uptime: 17:25:27

System Uptime: 17:25:27System Uptime: 17:25:27

--- QPRI -- Card Administration -- [01,02] ---

--- QPRI -- Card Administration -- [01,02] --- --- QPRI -- Card Administration -- [01,02] --O) switch over permanent

O) switch over permanent

O) switch over permanentO) switch over permanent Q) query firmware

Q) query firmware

Q) query firmwareQ) query firmware R) reset card

R) reset card

R) reset cardR) reset card Y) switch over once

Y) switch over once

Y) switch over onceY) switch over once I) change site name

I) change site name

I) change site nameI) change site name U) clear card configuration

U) clear card configuration

U) clear card configurationU) clear card configuration X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

and the screen is refreshed by pressing

’s prompt displays the shelf/slot address of the QPRI

NCM Controller Administration

.

E

NTER

, the

Table 3-3 Card Administration Submenu Commands

Command Description Options

O

Q

R Y

I

U

X

Switch over permanent—This option designates the partition A or B firmware version when you reboot the card. Assig n a permanent p artition to boo t from in case of power failure. Before choosing a partition, ensure that a firmware version exists on both partitions using the Query Firmware command below.

Query Firmware—Use this option to display the firmware versions and their status for the A and B flashbanks (unless a flashbank is empty).

Reset Card—This option reboots the module. Switch Over Once—Use this option when testing new firmware versions to

change from partition A to B or vice versa. The next time you reboot, the module will use the original partition/flashbank. Though you can use this option for diagnostics, y ou should neverth eless indicate a permanent partiti on to boot from in case of power failure.

Change Site Name—Use this option to specify the site name for the QPRI. Limited to 19 viewable characters. All reports will contain this information which—in case of a problem—will help to identify the module location.

Clear Card Configuration —This option clears the config uration of the car d and returns it to the default settings.

[0.0.0.5] [1,2] QPRI > u

[0.0.0.5] [1,2] QPRI > u[0.0.0.5] [1,2] QPRI > u Clear card configur ation on shelf 1 slot 2 (Y/N) ? y

Clear card configur ation on shelf 1 slot 2 (Y/N) ? y

Clear card configur ation on shelf 1 slot 2 (Y/N) ? yClear card configur ation on shelf 1 slot 2 (Y/N) ? y Card configuration cleared

Card configuration cleared

Card configuration clearedCard configuration cleared

Exit this Screen—Returns you to the Main Menu, Table 3-1.

NOTE: Use with Caution!

1) A

2) B

1) A

2) B

Yes or No (Y/N)

Verilink QPRI 2921 3-5

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Configuration Menu

Typing the command C from

Configuration Menu

. This menu provides access to the menus

used to configure th e T1 port, data port, or ISDN PRI options.

Figure 3-3 Configuration Menu

A [127.255.255.0] [0,11] QPRI > c

A [127.255.255.0] [0,11] QPRI > cA [127.255.255.0] [0,11] QPRI > c

-- QPRI CONFIGURATION MENU --

-- QPRI CONFIGURATION MENU ---- QPRI CONFIGURATION MENU -P) T1 port I) ISDN PRI

P) T1 port I) ISDN PRI

P) T1 port I) ISDN PRIP) T1 port I) ISDN PRI X) Exit this screen

X) Exit this screen

X) Exit this screenX) Exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

Table 3-4 Configuration Menu Commands

Command Description

P

I

X

T1 Port Configuration Menu

T1 port—Displays the Q PRI 2921 T1 Port Configuratio n Menu, Figure 3-4, Tabl e 3-5. ISDN PRI—Displays the PRI Configuration Menu, Figure 3-8, Table 3-9. Exit this Screen—Returns you to the Main Me nu, Table 3-1, Table 3- 2.

To access the

Configuration Menu

T1 Port Configuration Menu

.

To change a port configuration, enter t he command followed by the port number. For example, to remove port 2 from service, In, enter

I2 (n

is a variable that identifies the port number).

Main Menu

displays the

QPRI 2921

, enter P from the

Figure 3-4 QPRI 2921 T1 Port Configuration Menu

A [127.255.255.0] [0,11] QPRI > p

A [127.255.255.0] [0,11] QPRI > pA [127.255.255.0] [0,11] QPRI > p

-- QPRI T1 PORT CONFIGURATION MENU --

-- QPRI T1 PORT CONFIGURATION MENU ---- QPRI T1 PORT CONFIGURATION MENU - PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4 PORT 1 PORT 2 PORT 3 PORT 4 In) In Service YES YES YES YES

In) In Service YES YES YES YES

In) In Service YES YES YES YESIn) In Service YES YES YES YES Fn) Frame Format ESF ESF ESF ESF

Fn) Frame Format ESF ESF ESF ESF

Fn) Frame Format ESF ESF ESF ESFFn) Frame Format ESF ESF ESF ESF Ln) Line Coding B8ZS B8ZS B8ZS B8ZS

Ln) Line Coding B8ZS B8ZS B8ZS B8ZS

Ln) Line Coding B8ZS B8ZS B8ZS B8ZSLn) Line Coding B8ZS B8ZS B8ZS B8ZS Bn) Line Build Out -15db -15db 0-133ft 0-133ft

Bn) Line Build Out -15db -15db 0-133ft 0-133ft

Bn) Line Build Out -15db -15db 0-133ft 0-133ftBn) Line Build Out -15db -15db 0-133ft 0-133ft NDn) Network Density 12.5% 80s 12.5% 80s 12.5% 80s 12.5% 80s

NDn) Network Density 12.5% 80s 12.5% 80s 12.5% 80s 12.5% 80s

NDn) Network Density 12.5% 80s 12.5% 80s 12.5% 80s 12.5% 80sNDn) Network Density 12.5% 80s 12.5% 80s 12.5% 80s 12.5% 80s NLn) Network Initiated Loop YES NO NO NO

NLn) Network Initiated Loop YES NO NO NO

NLn) Network Initiated Loop YES NO NO NONLn) Network Initiated Loop YES NO NO NO An) Alarm Declare Time(sec) 0 0 0 0

An) Alarm Declare Time(sec) 0 0 0 0

An) Alarm Declare Time(sec) 0 0 0 0An) Alarm Declare Time(sec) 0 0 0 0 DLn) FDL Enable YES YES YES YES

DLn) FDL Enable YES YES YES YES

DLn) FDL Enable YES YES YES YESDLn) FDL Enable YES YES YES YES PRM Enable NO NO NO NO

PRM Enable NO NO NO NO

PRM Enable NO NO NO NO PRM Enable NO NO NO NO En) Enable ISDN Disabled Disabled N/A N/A

En) Enable ISDN Disabled Disabled N/A N/A

En) Enable ISDN Disabled Disabled N/A N/AEn) Enable ISDN Disabled Disabled N/A N/A F) FDL configuration

F) FDL configuration

F) FDL configurationF) FDL configuration C) Copy port T) Timing

C) Copy port T) Timing

C) Copy port T) TimingC) Copy port T) Timing X) Exit this screen

X) Exit this screen

X) Exit this screenX) Exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

Following is a brief description of the T1 port configuration parameters:

3-6 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Table 3-5

Command Description Options

T1 Port Configuration Menu Commands

I

n

F

n

L

n

In Service: Use this option to place the port in service. Yes or No

Frame Format: Choose SF (Superframe) or ESF (Extended Superframe Format) as dictated by what your installation supports.

recommended.

SF provides traffic signaling and framing. It is sometimes referred to as D4.

Caution: Setting the framing to SF renders other parameters—such as FDL, below inoperative.

ESF provides cyclic redundancy check, performance monitoring, data checking, and link bits (Facility Data Link, or FDL).

Line Coding: Use this option to choose Alternate Mark Inversion (AMI) or Bipolar Eight-Zero Substitution (B8ZS) as dictated by your T1 facility.

B8ZS is a protocol that replaces eight consecutive Zero bits with two intentional bipolar violations (BPVs) that are not counted as errors by the B8ZS equipment. B8ZS enables each DS0 to transmit at 64 kbit/s with unlimited zeros. This option overrides any selected network density enforcement.

AMI is a T1 signal in which successive Ones (pulses) alternate in polar ity and in which Zeros (spaces) are of zero amplitude. AMI is the original T1 line format that does not support long strings of zeros. Normally, this option is used in conjunction with the network density enforcement option.

Select SF for installations not supporting ESF.

This is the recommended option for ISDN.

ESF is

(Y/N)

1) SF

2) ESF

1) AMI

2) B8ZS

If the T1 facility experien ces pattern sensitiv e errors or constant dribb li ng errors, verify that the un it is not misoptioned for AMI. The intentional errors inserted by B8ZS equipment cannot be decoded by the AM I eq u ipment.

AMI requires use of an ISDN inverted D-channel.

B

n

Line Build Out: Line Build-Out is the signal strength used by the CSU and is calculated by considering the length of the cable connecting the first line repeater and the CSU. It is the db loss inserted to compensate for transmitting levels to first repeaters w hen no network i nterface is in volved. Choose one of the following options:

0 db: if the repeater is between 2000 and 3000 feet from the CSU, or if you are using a network int erface unit (smar t jack) used by most phon e companies.

-7.5 db: if the repeater is between 1000 and 1999 feet from the CSU.

-15 db: if the repeater is between 250 and 999 feet from the CSU.

-22.5 db: if the repeater is between 0 and 249 feet from the CSU.

1) 0 db

2) -7.5 db

3) -15 db

4) -22.5 db

Verilink QPRI 2921 3-7

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Command Description Options

ND

NL

A

DL

Network Density: Use this option to specify the type of network density

n

enforcement to use with PRI line coding. Digital transmissions over public switched telephone network lines cannot support long strings of zeros (repeaters and clocking devices lose synchronization). Therefore, the density algorithms ensure that a minimum pulse density is met to ensure stable system timing.

Choose one of the following if using 64K AMI. Note that these options are ignored with B8ZS line code:

None: does not ins ert a o ne.

Also recommended for ISDN capability.

80 zeros: inserts a one i nto ever y stri ng of more th an 8 0 cons ecuti ve zeros. 15 zeros: inserts a one i nto ever y stri ng of more th an 1 5 cons ecuti ve zeros.

12.5% & 80 zeros: inserts a one into every string of eight or more consecutive zeros when the avera ge d ensity of ones fal l below 12 .5 % or if there are more than 80 consecutive zeros.

TR 62411: inserts a one in to ev ery string of more than 15 consecutive zeros or when there are less than a minimum number of N ones in every window of 8(N+1) data bits (12.5%). N can be any value from 1 to 23. This option is the same as 12.5% + 15 zeros.

Network Initiated Loop: Use this option to specify if you wish to allow your

n

QPRI to be remotely put into a line loopback.

n

Alarm Declare Time (sec): Use this option to indicate how many seconds will elapse before a message regarding a problem is displayed.

FDL Enable/PRM Enable: Facility Data Link (FDL). The ESF Facility Data Link

n

is used to transmit performance registers and controls, error events, and loopback controls. The FDL uses 4 kbit/s of bandwidth to transmit messages. This option only enables or disables the FDL. It only reports if you have the Performance Report Message Command/Response (PRM C/R) bit enabled or dis ab l ed . To ch ange this option’s stat u s or configuration, select the FDL Configurat ion command ( option.

Note: Enabling this option is meaningless for ports in SF mode.

Use this option with B8ZS or a 56K channel.

) and use the Cn (PRM C/R bit)

F

1) NONE

2) 80 zeros

3) 15 zeros

4) 12.5% & 80 zeros

5) TR 62411

Yes or No (Y/N)

0..127 seconds

Yes or No (Y/N)

E

n

S

n

F

T

X

3-8 Verilink QPRI 2921

Enable Inband ISDN: Turns on access to one of the channels in the option fields for inband communication. To receive and tran smit r emote configuration a nd diag nostic infor mation, the channel has to be enabled o n both ends.

This command is used to enable an inband channel or ISDN D-channel, or disable both. An inband channel uses a timeslot (DS0) to send and rec iev e remote configuration and diagnostic information. An ISDN D-channel is used for ISDN call set-up and other messages. Both ends must have the same option selected.

implementing this command.

Inband Timeslot: Select one of the 24 timeslots for inband management before enabling the inband ISDN as described above. ISDN normally uses timeslot 24 for this function.

FDL Configuratio n: Brings up a submenu o f choices. Figure 3-5, Table 3-6. Note: This option and associated submenus are meaningless for ports in SF

mode. Timing: This brings up the Co nfiguration Menu (Timing Op tions), Figure

3-6, Table 3-7. Exit this Screen: Returns you to the Configuration Menu, Figure 3-3, Table

3-4.

Select the Inband Timeslot option below before

1) Inband enable

2) ISDN enable

3) Both disable

1-24

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

When finished configuring the T1 network ports, enter X until you return to the

Configuration Menu

.

FDL Configuration

Submenu

Facility Data Link is an ESF T1 port configuration option. The ESF FDL transmits performance information, error events , an d loopback controls. FDL uses 4 kbit/s of bandwidth to transmit data. To use FDL, ensure that ESF framing format has been selected.

From the

Configuration Submenu

NOTE:

T1 Port Configuration Menu

, choose F to display the

.

This option and associated submenus do not apply for ports in SF mode.

Figure 3-5 Configuration Submenu (FDL Options)

-- QPRI CONFIGURATION MENU (FDL OPTIONS)--

-- QPRI CONFIGURATION MENU (FDL OPTIONS)---- QPRI CONFIGURATION MENU (FDL OPTIONS)- PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4 PORT 1 PORT 2 PORT 3 PORT 4 Sn) FDL Standard T1.403 T1.403 T1.403 T1.403

Sn) FDL Standard T1.403 T1.403 T1.403 T1.403

Sn) FDL Standard T1.403 T1.403 T1.403 T1.403Sn) FDL Standard T1.403 T1.403 T1.403 T1.403 Mn) FDL Mode TERM TERM TERM TERM

Mn) FDL Mode TERM TERM TERM TERM

Mn) FDL Mode TERM TERM TERM TERMMn) FDL Mode TERM TERM TERM TERM Pn) Poll Mode NO POLL NO POLL NO POLL NO POLL

Pn) Poll Mode NO POLL NO POLL NO POLL NO POLL

Pn) Poll Mode NO POLL NO POLL NO POLL NO POLLPn) Poll Mode NO POLL NO POLL NO POLL NO POLL Cn) PRM C/R bit NONE NONE NONE NONE

Cn) PRM C/R bit NONE NONE NONE NONE

Cn) PRM C/R bit NONE NONE NONE NONECn) PRM C/R bit NONE NONE NONE NONE In) Idle Pattern FLAGS FLAGS FLAGS FLAGS

In) Idle Pattern FLAGS FLAGS FLAGS FLAGS

In) Idle Pattern FLAGS FLAGS FLAGS FLAGSIn) Idle Pattern FLAGS FLAGS FLAGS FLAGS An) Send/Rec LLB BOP YES YES YES YES

An) Send/Rec LLB BOP YES YES YES YES

An) Send/Rec LLB BOP YES YES YES YESAn) Send/Rec LLB BOP YES YES YES YES Bn) Send/Rec PLB BOP YES YES YES YES

Bn) Send/Rec PLB BOP YES YES YES YES

Bn) Send/Rec PLB BOP YES YES YES YESBn) Send/Rec PLB BOP YES YES YES YES X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

FDL

Table 3-6 Configuration Submenu (FDL Options) Parameters

Command Description Options

Sn

Mn

Pn

Cn

FDL Standard: Specify the Bell core 54016 standard, the ANSI T1.403 standard, or both.

FDL Mode: Specify TERM (Terminated) to end the FDL transmission at this node. Specify Pass to have the FDL transmission to continue to another

Currently, Pass is not applicable for 2 network ports.

node. Poll Mode: Specify how the FDL will poll for alarms at the far end.

Poll: This has the near-end CSU automatically poll th e far-end CSU for al arms every 4 seconds and report these alarms.

No Poll: This disables alarm polling at both ends. Select this option when the nodes at both ends are connected and both nodes report local alarms.

Unsolicit: This has the far-end automatically send its alarm status (when it detects an LOS) to the near-end. Select this option for far-end CSU circuit element when the near-end CSU is set to Poll.

PRM C/R bit: Performance Report Message Command/Response as defined in the ANSI T1.403 specification.

Specify USER to set the bit to 0, indicating that you are the PRM source terminal. Specify TELCO to set the bit to 1, indicating that the phone company is the PRM source. Phon e com panies usually set it to TELCO; nonphone companies set it to USER. To disable this option, choose NONE.

1) TR54016

2) T1.403

3) BOTH

1) TERM

2) PASS

1) POLL

2) NO POLL

3) UNSOLICIT

1) NONE

2) USER

3) TELCO

Verilink QPRI 2921 3-9

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Command Description Options

In

An

Bn

X

Idle Pattern: Select the idle pattern code for when there is no user data on the net. Depending on your network, select either All-Ones or Flags. The signal is transmitted continuously until a message is sent. Once the message completes transmission, the line reverts to the signal chosen:

All-Ones is a signal on an FDL composed entirely of ones: 11111111. Flags is a signal on an FDL consisti ng of 01111110.

Send/Rec LLB BOP: This option enables the Line Loopback Bit-Oriented Protocol (LLB BOP) to use FDL loopbacks for testing the T1 line.

Send/Rec PLB BOP: This option enables the Payload Loopback Bit-Oriented Protocol (PLB BOP) to use FDL loopbacks for testing the far-end CSU.

Exits the FDL Configuration menu and return to the T1 Port Configuration Menu, Figure 3-4, Table 3-5.

Configuration

Menu (Timing

Options)

1) ALL ONES

2) FLAGS

Yes or No (Y/N)

To access the

T1 Port Configuration Menu

the

Configuration Menu ( Timing Opt ions)

, Figure 3-4.

, enter T from

Use this menu to determine the transmit timing source of the QP R I modules. If the QPRI module derives its timing from another card in the shelf, enter the slot of the module to be the timing source. This includes the option of setting the QPRI as the timing source for the shelf.

Select primary, secondary, and tertiary timing sources. The secondary and tertiary timing sources provide a backu p f o r the primary timing source. The Auto Restore option determines which timing source is used when the primary timing source fails, restores, and then remains viable for a period of 60 seconds.

If the primary source fails, the secondary source becomes the timing source. When the primary source recovers and the Auto Restore option is set to “Yes”, the primary source resumes service as the QPRI module’s timing source. If the Auto Restore option is set to “No”, the secondary source remains the timing source until you manually reconfigure the primary source, or set its Auto Restore option to “Yes”.

NOTE:

For ISDN, the netwo rk ALWAYS supplies a cloc k that MUST be the source.

Figure 3-6 Configuration Menu (Timing Options)

-- QPRI CONFIGURATION MENU (TIMING OPTIONS)--

-- QPRI CONFIGURATION MENU (TIMING OPTIONS)---- QPRI CONFIGURATION MENU (TIMING OPTIONS)-Current card timing source: INTERNAL (PRIMARY)

Current card timing source: INTERNAL (PRIMARY)

Current card timing source: INTERNAL (PRIMARY)Current card timing source: INTERNAL (PRIMARY) Source

Source Synchronization Auto Restore

SourceSource PRIMARY

PRIMARY PS) NET1

PRIMARYPRIMARY SECONDARY

SECONDARY SS) NET2

SECONDARYSECONDARY TERTIARY

TERTIARY TS) INTERNAL

TERTIARYTERTIARY R) Receive clock from shelf: NO

R) Receive clock from shelf: NO

R) Receive clock from shelf: NOR) Receive clock from shelf: NO X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen [1,2] QPRI >

[1,2] QPRI >

[1,2] QPRI >[1,2] QPRI >

Synchronization Auto Restore

Synchronization Auto RestoreSynchronization Auto Restore PS) NET1 PA) YES

PS) NET1PS) NET1 SS) NET2 SA) YES

SS) NET2SS) NET2 TS) INTERNAL TA) NO

TS) INTERNALTS) INTERNAL

PA) YES

PA) YES PA) YES SA) YES

SA) YES SA) YES TA) NO

TA) NO TA) NO

3-10 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

For ISDN, you must provide shelf timing derived from the ISDN PRI span. All cards with dial-backup must use shelf timing. Set the secondary timing source for the second ISDN port, if used (otherwise set it to internal). The following options are valid if you specified “No” to “Receive Clock from Shelf”:

Table 3-7

Command Description Options

PS

SS

Configuration Menu (Timing Options)

Primary Synchronization: Choose one of the following as your primary source for clock synchr onization.

Net 1: Use this option to synchronize timing to Net Port 1. Net 2: Use this option to synchronize timing to Net Port 2. External: Use this option if you want to use an external clock as your timing

source. Internal: Use this option if you want to use the internal clock as your timing

source. Net 3: Use this option to synchronize timing to the Net Port 3 signal. Net 4: Use this option to synchronize timing to the Net Port 4 signal.

Secondary Synchronization: Use this option to specify an alternate source of timing for synchronization. If the pri mary source is unavailable, this source will be used.

Net 1: Use this option to synchronize timing to Net Port 1. Net 2: Use this option to synchronize timing to Net Port 2. External: Use this option if you want to use an external clock as your timing

source. Internal: Use this option if you want to use the internal clock as your timing

source. Net 3: Use this option to synchronize timing to the Net Port 3 signal. Net 4: Use this option to synchronize timing to the Net Port 4 signal.

1) NET 1

2) NET 2

3) EXTERNAL

4) INTERNAL

5) NET 3

6) NET 4

1) NET 1

2) NET 2

3) EXTERNAL

4) INTERNAL

5) NET 3

6) NET 4

TS

PA

SA

Tertiary Synchronization: Use this option to specify an alternate source of timing for synchronization. If the primary and secondary sources are unavailable, this sourc e will be used.

Net 1: Use this option to synchronize timing to Net Port 1. Net 2: Use this option to synchronize timing to Net Port 2. External: Use this option if you want to use an external clock as your timing

source. Internal: Use this option if you want to use the internal clock as your timing

source. Net 3: Use this option to synchronize timing to the Net Port 3 signal. Net 4: Use this option to synchronize timing to the Net Port 4 signal.

Primary Auto Restore: Indicate automatically if the clock in the node fail s. Otherwi s e, choose No. Setting up auto restore returns timing to a higher priority source after a failure. If you have not set up auto restore to the primary source, but you have indicated a secondary source, after rebooting the module uses the latter source to restore timing to the module or shelf.

Secondary Auto Restore: Indicate preference automatically if the clock in the n ode fails . Otherwise, choose No. Specifying a s eco ndar y s our ce f or c lo cking is usef ul if pow er fail s and c aus es failure of the primary automatic restore source. Restoring from a secondary source may take up to 60 seconds.

Yes

to resynchronize to your c lock preferenc e

Yes

to resynchronize to your clock

1) NET 1

2) NET 2

3) EXTERNAL

4) INTERNAL

5) NET 3

6) NET 4

Yes or No (Y/N)

Verilink QPRI 2921 3-11

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Command Description Options

TA

R

X

Tertiary Auto Restore: Indicate automatically if the clock in the node fails. Otherwise, choose No. Specifying a tertiary source for cloc kin g is usef ul when power loss results in fail ure of the primary and secondary sources for automatic restore. Restoring from a tertiary source may take up to 90 seconds.

Receive Clock from Shelf: Use this option to indicate the DPRI receives the timing signal from another module in the shelf or from an on-board timing source.

Note: Changing this option will change the Configuration Menu (Timing Options) display the next time it is refreshed

Exit the Timing Options screen and return to the T1 Port Configuration Menu, Figure 3-4, Table 3-5.

Yes

to resynchronize to your clock pr eference

, Figure 3-6 and Figure 3-7.

If you enable “Receive Clock from Shelf” (which is what you should do if you plan on using the module’s ISDN and dial-backup features) the following options display:

Figure 3-7 Configuration Menu (Timing Options) for Receive Clock from Shelf Option

-- QPRI CONFIGURATION MENU (TIMING OPTIONS)--

-- QPRI CONFIGURATION MENU (TIMING OPTIONS)---- QPRI CONFIGURATION MENU (TIMING OPTIONS)-Current shelf timing source: Card 2, INTERNAL (PRIMARY)

Current shelf timing source: Card 2, INTERNAL (PRIMARY)

Current shelf timing source: Card 2, INTERNAL (PRIMARY)Current shelf timing source: Card 2, INTERNAL (PRIMARY) Source

Source Slot Number

SourceSource PRIMARY

PRIMARY PC) 2

PRIMARYPRIMARY SECONDARY

SECONDARY SC) 2

SECONDARYSECONDARY TERTIARY

TERTIARY TC) 2

TERTIARYTERTIARY R) Receive clock from shelf: YES

R) Receive clock from shelf: YES

R) Receive clock from shelf: YESR) Receive clock from shelf: YES X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen [1,2] QPRI >

[1,2] QPRI >

[1,2] QPRI >[1,2] QPRI >

Slot Number Synchronization

Slot NumberSlot Number PC) 2 PS) NET1

PC) 2PC) 2 SC) 2 SS) NET2

SC) 2SC) 2 TC) 2 TS) INTERNAL

TC) 2TC) 2

Synchronization Auto Restore

Synchronization Synchronization PS) NET1 PA) YES

PS) NET1 PS) NET1 SS) NET2 SA) YES

SS) NET2 SS) NET2 TS) INTERNAL TA) NO

TS) INTERNAL TS) INTERNAL

Additional parameters because Receive Clock From Shelf Option selected is YES.

Auto Restore

Auto Restore Auto Restore

PA) YES

PA) YES PA) YES SA) YES

SA) YES SA) YES TA) NO

TA) NO TA) NO

Yes or No (Y/N)

Following is a brief description of the additional timing parameters shown for “Yes” for the “Receive Clock from Shelf” timing option:

Table 3-8

Command Description Options

PC

SC

TC

Configuration Menu (Timing Options), Receive Clock From Shelf

Primary Module Slot Number: This option selects the module providing the primary timing source.

Secondary Module Slot Number: This option selects the module providing the secondary timing source.

Tertiary Module Slot Number: This option selects the module providing the tertiary timing source.

R

X

Receive Clock from Shelf: This option selects whether the DPRI will receive its timing signal from another module in the shelf, or from an on-board timing source.

Note: Changing this option will change the appearance of the Configuration Menu (Timing Options) the next time it is displayed, Figure 3-6 and Figure 3-7.

Exit the Timing Options menu and return to the T1 Port Configuration Menu, Figure 3-4, Table 3-5.

Enter module (slot) number

Yes or No (Y/N)

3-12 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Recommended settings for timing when the QPRI 2921 is being used for ISDN dial-backup are:

Source Synchronization Auto Restore

Primary PRI Slot Net 1 YES Secondary PRI Slot Net 2 YES Tertiary PRI Slot Internal NO

When finished configuring the timing options, enter X until you return to the

Main Menu

.

ISDN PRI Configuration Menu

To access the

Configuration Menu

•

Use the PRI port configuration option to assign ISDN-specific

PRI Configuration Menu

, Figure 3-3.

parameters and ISDN network parameters.

•

Configure call profiles to define the routing characteristics for incoming and outgoing phone calls.

•

Configure the incoming and outgoing call numbers to be used for ISDN security checks.

•

Examine the 15-minute and 24 -hour performance characteristics for the ISDN PRI framing, protocol, and call setups.

Figure 3-8 PRI Configuration Menu

A [127.255.255.0] [1,2] QPRI >i

A [127.255.255.0] [1,2] QPRI >iA [127.255.255.0] [1,2] QPRI >i

-- QPRI CONFIGURATION MENU --

-- QPRI CONFIGURATION MENU ---- QPRI CONFIGURATION MENU -P) PRI Port Configuration C) PRI Call Profile

P) PRI Port Configuration C) PRI Call Profile

P) PRI Port Configuration C) PRI Call ProfileP) PRI Port Configuration C) PRI Call Profile A) PRI Statistics

A) PRI Statistics

A) PRI StatisticsA) PRI Statistics X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

Table 3-9

Command Description

PRI Configuration Menu Commands

, enter I from the

P C A

X

PRI Port Configur ation—Displays the PRI Port Configurat ion Menu, Figure 3-9, Table 3-10. PRI Call Profile—Dis p la y s the PRI Ca ll Profile Configurat ion Menu, Figure 3-10, Tab le 3- 1 1. PRI Statistics—Displays the PRI Performance/Statis tics Menu, Figure 3-13, Tab le 3-14. Exit to the Configurat ion Menu, Figure 3-3, Table 3-4.

PRI Port

Configuration

Menu

To access the from the

PRI Port Configuration Menu

PRI Configuration Menu

, Figure 3-9, enter P

, Figure 3-8. Use this menu to

configure the characteristics of the specified port for PRI handling.

Verilink QPRI 2921 3-13

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Figure 3-9 PRI Port Configuration Menu

[0.0.0.5] [1,2] QPRI > p

[0.0.0.5] [1,2] QPRI > p[0.0.0.5] [1,2] QPRI > p

-- QPRI 2921 PRI PORT CONFIGURATION MENU --

-- QPRI 2921 PRI PORT CONFIGURATION MENU ---- QPRI 2921 PRI PORT CONFIGURATION MENU - PORT 1 PORT 2

PORT 1 PORT 2

PORT 1 PORT 2 PORT 1 PORT 2 In) PRI In Service No No

In) PRI In Service No No

In) PRI In Service No NoIn) PRI In Service No No Fn) NFAS Mode No NFAS No NFAS

Fn) NFAS Mode No NFAS No NFAS

Fn) NFAS Mode No NFAS No NFASFn) NFAS Mode No NFAS No NFAS Dn) D-Channel Mode Normal Normal

Dn) D-Channel Mode Normal Normal

Dn) D-Channel Mode Normal NormalDn) D-Channel Mode Normal Normal Bn) D-Channel Bits 8 bits 8 bits

Bn) D-Channel Bits 8 bits 8 bits

Bn) D-Channel Bits 8 bits 8 bitsBn) D-Channel Bits 8 bits 8 bits Sn) Switch Type DMS 100 DMS 100

Sn) Switch Type DMS 100 DMS 100

Sn) Switch Type DMS 100 DMS 100Sn) Switch Type DMS 100 DMS 100 Pn) Own Numbering Plan ISDN-E.164 ISDN-E.164

Pn) Own Numbering Plan ISDN-E.164 ISDN-E.164

Pn) Own Numbering Plan ISDN-E.164 ISDN-E.164Pn) Own Numbering Plan ISDN-E.164 ISDN-E.164 Nn) Own Numbering Type National National

Nn) Own Numbering Type National National

Nn) Own Numbering Type National NationalNn) Own Numbering Type National National En) Security Level No checks No checks

En) Security Level No checks No checks

En) Security Level No checks No checksEn) Security Level No checks No checks Ln) L2 auto establish No No

Ln) L2 auto establish No No

Ln) L2 auto establish No NoLn) L2 auto establish No No X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen [0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >[0.0.0.5] [1,2] QPRI >

Table 3-10

Command Description Options

In

Fn

Dn

Bn

Sn

PRI Port Configuration Menu Commands

PRI In Service—ISDN stack on or off. Yes or No

NFAS Mode—Non-Facil ities Associated Signal ling. Only available on Po rt 1. Makes both T1 channels mapable from the Port 1 D-channel. D-channel of Port 1 would provide call control for both PRI ports formi ng 47B+D.

Note: This feature must be ordered with your ISDN service.

To activate NFAS Mode: Use T1 Port Configuration Menu, Figure 3-4, to put T1 Ports 1 and 2 out of

service. Deactivate both ISDN stacks—Port 1 and Port 2. Select NFAS on Port 1 via the PRI Port Configuration Menu (command F1). Reboot the module (You will be prompted to ensure that you really want to

do this). Put Ports 1 and 2 back into service via the T1 Port Configuration Menu. Reactivate the ISDN stacks on

D-Channel Mode—The D-channel bit pattern can be inverted.

D-channel if AMI is selected in the T1 Port Configuration Menu, Figure 3-4.

For B8ZS select “Normal”

D-Channel Bits—Signallin g bit sel ecti on. If using AMI, select “7 bits”. For B8ZS, select “8 bits”.

Switch Type—Enter the type of switch used by your ISDN carrier. There are other options which are not supported.

Port 1 ONLY

.

(only allowed on Port 1).

Use Inverted

(Y/N)

1) No NFAS

2) NFAS

1) Normal

2) Inverted

1) 8 bits

2) 7 bits

3) 6 bits

4) exit

1) unspecified

2) AT&T 4ESS

3) AT&T 5ESS

4) DMS-100

5) NI-2

3-14 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Command Description Options

Pn

Nn

En

Ln

Own Numbering Plan—Enter the numbering plan recommended by your ISDN carrier and according to your co rporate network plan.

ISDN-E.164 is typically Cla ss 4, Europe. Telephony-E.163 is typical ly C lass 5, U.S.

U.S. Recommended Plans: < 7 digits—Private 7 digits—Private or Telephony 10 digits—Private, Telephony, or ISDN-E.164 >10 digits—ISDN-E. 164

Own Numbering Type—Enter the type of numbering used by your ISDN carrier and according to your network requirements.

U.S. Recomme nd ed Ty p es : < 7 digits—Unknown or Local 7 digits—Local 10 digits—National > 10 digits—International

Security Level—If se curity is enab led, any number table wil l be rejected. For this version of firmw a re, use “No Checks”.

L2 Auto Establish—Counts on ISDN CO switch to activate layer two.

is “No”

layer 2 (link layer).

. If set to “Yes”, the QPRI module will continually try to establish

NOT

found in the security

Normal

1) Unknown

2) ISDN-E.164

3) TelephonyE.163

4) Private

1) Unknown

2) International

3) National

4) Local

1) No checks

2) Check own

3) Check remote

4) Check own and remote

Yes or No (Y/N)

X

PRI Call Profile

Configuration

Exit to the PRI Configuration Menu, Figure 3-8, Table 3-9.

An ISDN Call Profile defines the network layer information required to build ISDN backup calls. Each circuit build that requires an ISDN

Menu

backup circuit must have a call profile reference assigned to it. To access the

enter C from the

PRI Call Profile Configuration Menu

PRI Configuration Menu

port associated with the call profiles to be changed.

Figure 3-10 PRI Call Profile Configuration Menu

[[0.0.0.5] [1,2] QPRI > c

[[0.0.0.5] [1,2] QPRI > c[[0.0.0.5] [1,2] QPRI > c

-- QPRI CALL PROFILE CONFIGURATION MENU --

-- QPRI CALL PROFILE CONFIGURATION MENU ---- QPRI CALL PROFILE CONFIGURATION MENU --

1) Port 1 Call Profile 2) Port 2 Call Profile

1) Port 1 Call Profile 2) Port 2 Call Profile1) Port 1 Call Profile 2) Port 2 Call Profile X) Exit this screen

X) Exit this screen

X) Exit this screenX) Exit this screen [0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >[0.0.0.5] [1,2] QPRI >

Table 3-11 PRI Call Profile Configuration Menu Parameters

Command Description

1

2 X

Port 1 Call Profile—Displays the Port 1 PRI Call Profile Configuration Menu, Figure 3-11, Table 3-12.

Port 2 Call Profile—Displays the Port 2 PRI Call Profile Configuration Menu. Exit to the PRI Port Confi guration Menu, Figure 3-9, Table 3-10.

, Figure 3-10,

, Figure 3-8. Select the

Verilink QPRI 2921 3-15

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Port n PRI Call

Profile

Configuration

Menu

Figure 3-11 Port 1 PRI Call Profile Configuration Menu (sample)

-- QPRI PORT 1 CALL PROFILE CONFIGURATION MENU --

-- QPRI PORT 1 CALL PROFILE CONFIGURATION MENU -- -- QPRI PORT 1 CALL PROFILE CONFIGURATION MENU -Ref Own Number Ext Number Bandwidth Direction Status

Ref Own Number Ext Number Bandwidth Direction Status

Ref Own Number Ext Number Bandwidth Direction StatusRef Own Number Ext Number Bandwidth Direction Status A) Add Call Profile M) Modify Call Profile

A) Add Call Profile M) Modify Call Profile

A) Add Call Profile M) Modify Call ProfileA) Add Call Profile M) Modify Call Profile S) Set Call Action D) Delete Call Profile

S) Set Call Action D) Delete Call Profile

S) Set Call Action D) Delete Call ProfileS) Set Call Action D) Delete Call Profile X) Exit this screen

X) Exit this screen

X) Exit this screenX) Exit this screen [0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >[0.0.0.5] [1,2] QPRI >

Table 3-12

Command Description

M

Port n PRI Call Profile Configuration Menu Commands

A

Add Call Profile—Displays the PRI Port 1 Add Call Profile Menu, Figure 3-12, Table 3-13. Modify Call Profile—Prompts for selection of a call profile to be edited,

Port n Enter Call Ref ID (0-0):

Port n Enter Call Ref ID (0-0):Port n Enter Call Ref ID (0-0):

then displays the Modify Call Profile Menu. Modify the Call Profile items by selecting the appropriate keys. WARNING: After making changes, remember to select the option,

S) Send Call Profile

S) Send Call Profile S) Send Call Profile

or the changes will not be set up.

From the selecting 1 or 2 will display a

Menu

Port 1.

PRI Call Profile Configuration Menu

Port PRI Call Profile Configuratio n

for that particular port. The example below shows that for

, Figure 3-10,

S

D

X

Set Call Action—Prompts for selection of a call profile to define the profile to be set up or taken down.

Port n Enter Call Action Ref ID (0-MAX):

Port n Enter Call Action Ref ID (0-MAX):Port n Enter Call Action Ref ID (0-MAX): Port n -- Set Call Action:

Port n -- Set Call Action:

Port n -- Set Call Action:Port n -- Set Call Action:

1) Setup Call 2) Take Down Call 3) Exit

1) Setup Call 2) Take Down Call 3) Exit1) Setup Call 2) Take Down Call 3) Exit

Delete Call Profile—Prompts for selection of a call profile ID for the call profile to be deleted.

Port n -- Disable entry number (0-0):

Port n -- Disable entry number (0-0):Port n -- Disable entry number (0-0):

CAUTION:

call profiles. If you cha nge your min d about d eleting a call prof ile, ente r a non-n umeric value at the prompt or enter a carriage return .

CAUTION:

Exit to the PRI Call Profile Configuration Menu, Figure 3-10, Table 3-11.

The prompt says "disable", but the result is deletion of the entry from the list of

No confirmation prompt will be displayed when a requested profile is deleted.

PRI Port n Add Call Profile Menu

To add a new call profile to the list of existing call profiles for the previously selected port, select A in the

Configuration Menu

. Select the appropriate key for each

parameter. The minimal information required to create a call profile is:

•

Reference ID

•

Direction (incoming/outgoing/both)

•

Number of Own Digits

•

Own Call Number

Port n PRI Call Profile

3-16 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

•

Extension Number of Digits

•

Extension Call Number

NOTE:

Acceptance of the call profile does not imply the completeness of the information required to describe your configuration.

NOTE:

After defining a call profile , selec t optio n S, Send Call Profile, or the profile will not be saved/create d.

Figure 3-12 PRI Port 1 Add Call Profile Menu

[0.0.0.5] [1,2] QPRI > a

[0.0.0.5] [1,2] QPRI > a[0.0.0.5] [1,2] QPRI > a

-- QPRI 2921 PRI PORT 1 ADD CALL PROFILE MENU --

-- QPRI 2921 PRI PORT 1 ADD CALL PROFILE MENU ---- QPRI 2921 PRI PORT 1 ADD CALL PROFILE MENU -R) Call Profile Ref 0

R) Call Profile Ref 0

R) Call Profile Ref 0R) Call Profile Ref 0 D) Call Direction Deleted

D) Call Direction Deleted

D) Call Direction DeletedD) Call Direction Deleted O) No. of Own Digits 0

O) No. of Own Digits 0

O) No. of Own Digits 0O) No. of Own Digits 0 N) Own Call Number ----

N) Own Call Number ----

N) Own Call Number ----N) Own Call Number ---I) Ext Numbering Plan ISDN-E.164

I) Ext Numbering Plan ISDN-E.164

I) Ext Numbering Plan ISDN-E.164I) Ext Numbering Plan ISDN-E.164 U) Ext Numbering Type International

U) Ext Numbering Type International

U) Ext Numbering Type InternationalU) Ext Numbering Type International C) Ext No. of Digits 0

C) Ext No. of Digits 0

C) Ext No. of Digits 0C) Ext No. of Digits 0 P) Ext Call Number ----

P) Ext Call Number ----

P) Ext Call Number ----P) Ext Call Number ---T) Transfer Mode Unrestricted

T) Transfer Mode Unrestricted

T) Transfer Mode UnrestrictedT) Transfer Mode Unrestricted B) Call Bandwidth B1=64K

B) Call Bandwidth B1=64K

B) Call Bandwidth B1=64KB) Call Bandwidth B1=64K M) MultiRate Count ----

M) MultiRate Count ----

M) MultiRate Count ----M) MultiRate Count ---A) Rate Adaption None

A) Rate Adaption None

A) Rate Adaption NoneA) Rate Adaption None E) Test Call Interval(min.) 0

E) Test Call Interval(min.) 0

E) Test Call Interval(min.) 0E) Test Call Interval(min.) 0 S) Send Call Profile

S) Send Call Profile

S) Send Call ProfileS) Send Call Profile X) Exit Screen

X) Exit Screen

X) Exit ScreenX) Exit Screen [0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >[0.0.0.5] [1,2] QPRI >

Table 3-13

Command Description Options

D

O

N

PRI Port n Add Call Profile Menu Commands

R

Call Profile Ref—Selec t a refe ren ce ID tha t is dis tinct from previously used IDs for the selected port. (Use the modify option to change existing call profiles.)

Call Direction—Select whether the call profile is for incoming calls, outgoing calls, or both. “D elete” i nvalidate s the ca ll profi le. We re commend using the “Delete Call Profile” command in the Call Profile Configuration Menu.

No. of Own Digits—Enter the number of digits in your phone number. Note: If the number is smaller than the length of an existing string associated below, you will be prompted to confirm whether or not you want to truncate the string. If the response to the prompt is Y, the associated string will be truncated; otherwise, the length will not be accepted.

Own Call Number—Enter your calling phone number. On incoming calls, this number equals “DNIS”. On outgoing calls, this number is delivered as “CLID” or “Station ID”. Note: If the entered string exceeds the associated length above, the string will be truncated.

1 through 48

1) Delete

2) Incoming

3) Outgoing

4) Both 1 through 15

Phone number of string length specified above.

Verilink QPRI 2921 3-17

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Command Description Options

I

U

C

P

T

B

Ext. Numbering Plan 1) Unknown

2) ISDN-E1.64

3) TelephonyE-

1.63

4) Private

Ext. Numbering Type 1) Unknown

2) International

3) National

4) Local

Ext. Number of Digits—Enter the number of digits in the extension phone number. Note: If the number is smaller than the length of an existing string associated below, you will be pr ompted to confirm whether or not you want to truncate the string. If the response to the prompt is Y, the associated string will be truncated; otherwise, the length will not be accepted.

Ext. Call Number—Enter the extension phone number. On incoming calls this number is the “CLID” or “Station ID”. On outgoing calls, this number is the “DNIS”. Note: If the entered string exceeds the associated length above , the string will be truncated.

Transfer Mode—Specify “restricted” for 56 Kbit/s transfer rate. Select if AMI facilities are being used. “Unrestricted” is for 64 Kbit/s (B8ZS) or 56 Kbit/s.

Call Bandwidth—Use this option to determine the bandwidth for the ISDN backup circuit.

1) B1 = 64 K

2) H0 = 6 x 64 K

3) H11 = 24 x 64 K (European, or in US—NFAS mode only.)

4) H12 = 30 x 64 K (European only)

5) Multirate = n x 64 K

1 through 15

Phone number of string length specified above.

1) restricted

2) unrestricted

1) B1

2) H0

3) H11

4) H12

5) Multirate

M

A

E

S

X

MultiRate Count—Produces bandwidth of n x 64 or n x 56 depending on the adopted rate. Enter this value only if call bandwidth is multirate.

Note: Options 8 and 9 should not be selected for T1 units—they are for E1 only.

Option 7 is for European (E1) or in US—NFAS mode only.

Rate Adaption—If you have unrestricted transfer mode (B8ZS) but the farend is restricted (A MI), th en s pecif y 56 K r ate a dapti on. T his w ill d epe nd on your application.

Test Call Interval (min.)—For testin g only . This o ptio n caus es the se lect ed call profile to be set up and taken down repeatedly at the intervals specified (zero disables testing).

Send Call Profile—

menu.

Until this option is selected, the menu is only a work sheet and the

configurati o n is Exit to the PRI Configuration Menu, Figure 3-8, Table 3-9.

PRI Performance /

Statistics Menu

Select this to save your call profile before exiting the

NOT

stored.

To access the

Configuration Menu

PRI Performance/St atistics Menu

, Figure 3-8. The prompt options identify the

types of performance characteristics.

1) 2

2) 4

3) 6

4) 8

5) 12

6) 23

7) 24

8) 30 (European only)

9) 31 (European only)

1) none (same as 64K)

2) 56K 0 through 255

, select A at the

PRI

3-18 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Figure 3-13 PRI Performance/Statistics Menu

A [127.255.255.0] [1,2] QPRI > a

A [127.255.255.0] [1,2] QPRI > aA [127.255.255.0] [1,2] QPRI > a

-- QPRI PERFORMANCE/STATISTICS MENU --

-- QPRI PERFORMANCE/STATISTICS MENU ---- QPRI PERFORMANCE/STATISTICS MENU -Cn) Get Current Interval Dn) Get 24 hr. Interval

Cn) Get Current Interval Dn) Get 24 hr. Interval

Cn) Get Current Interval Dn) Get 24 hr. IntervalCn) Get Current Interval Dn) Get 24 hr. Interval Rn) Reset Interval X) Exit this screen

Rn) Reset Interval X) Exit this screen

Rn) Reset Interval X) Exit this screenRn) Reset Interval X) Exit this screen A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

Table 3-14

Command Description

C

D

R

n

X

PRI Performance/Statistics Menu Parameters

n

Get Current Interval—Displays the Port n PRI 15-Minute Performance Data, Figure 3-14. Press Enter to exit this screen.

Get 24 hr. Interval—Displays the Port n 24-Hour Performance Data Menu, Figure 3-15. Choose an option from this menu to view the related performance summary for the previous 24 hours.

Reset Interval—Resets the performance data counters for the specified port. Exit to the PRI Call Profile Configuration Menu, Figure 3-10, Table 3-11.

Performance data displayed in the following two screens is defined as follows:

•

INFOs rcvd/ x mi t d—Any ISDN Lay e r 2 i nformation mes s a g e s received or transmitted.

•

CRC errs recvd—CRC errors in Layer 2 packet.

•

Invld frames rcvd—Invalid frames received—Information message with incorrect header that the link layer cannot decode.

•

Frame aborts rcvd—Frame aborts received—Information message that started with a good frame, but did not end properly.

•

DISCs rcvd/xmitd—Disconnect message received or transmitted.

•

FRMR rcvd/xmitd—Frame error (invalid frame) received or transmitted.

•

L3 protocol errors—Invalid Layer 3 information elements.

•

Unsupported msgs rcvd—Unsupported messages received— Layer 3 messages which cannot be decoded because they are not supported by the module.

Verilink QPRI 2921 3-19

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Figure 3-14 Port 1 PRI 15 Minute Performance Data

---- Port 1 15 MINUTE PERFORMANCE DATA ---- 05-30-01 21:57:05

---- Port 1 15 MINUTE PERFORMANCE DATA ---- 05-30-01 21:57:05---- Port 1 15 MINUTE PERFORMANCE DATA ---- 05-30-01 21:57:05 Site Name: Verilink Test Shelf: 1 Slot: 2

Site Name: Verilink Test Shelf: 1 Slot: 2

Site Name: Verilink Test Shelf: 1 Slot: 2Site Name: Verilink Test Shelf: 1 Slot: 2 Seconds in current interval: 0

Seconds in current interval: 0

Seconds in current interval: 0Seconds in current interval: 0 Layer 2 Performance Data

Layer 2 Performance Data

Layer 2 Performance Data Layer 2 Performance Data INFOs rcvd : 0 INFOs xmitd : 0

INFOs rcvd : 0 INFOs xmitd : 0

INFOs rcvd : 0 INFOs xmitd : 0 INFOs rcvd : 0 INFOs xmitd : 0 CRC errs rcvd : 0 Invld frames rcvd : 0

CRC errs rcvd : 0 Invld frames rcvd : 0

CRC errs rcvd : 0 Invld frames rcvd : 0 CRC errs rcvd : 0 Invld frames rcvd : 0 Frame aborts rcvd : 0 DISCs rcvd : 0

Frame aborts rcvd : 0 DISCs rcvd : 0

Frame aborts rcvd : 0 DISCs rcvd : 0 Frame aborts rcvd : 0 DISCs rcvd : 0 DISCs xmitd : 0 FRMR rcvd : 0

DISCs xmitd : 0 FRMR rcvd : 0

DISCs xmitd : 0 FRMR rcvd : 0 DISCs xmitd : 0 FRMR rcvd : 0 FRMR xmitd : 0

FRMR xmitd : 0

FRMR xmitd : 0 FRMR xmitd : 0 Layer 3 Performance Data

Layer 3 Performance Data

Layer 3 Performance Data Layer 3 Performance Data L3 protocol errors : 0

L3 protocol errors : 0

L3 protocol errors : 0 L3 protocol errors : 0 Call Performance Data

Call Performance Data

Call Performance Data Call Performance Data Call setups sent : 0 Call setups sent & failed: 0

Call setups sent : 0 Call setups sent & failed: 0

Call setups sent : 0 Call setups sent & failed: 0 Call setups sent : 0 Call setups sent & failed: 0 Call setups received : 0 Call setups received & failed: 0

Call setups received : 0 Call setups received & failed: 0

Call setups received : 0 Call setups received & failed: 0 Call setups received : 0 Call setups received & failed: 0 Unsupported msgs rcvd : 0 Test call setups sent & failed: 0

Unsupported msgs rcvd : 0 Test call setups sent & failed: 0

Unsupported msgs rcvd : 0 Test call setups sent & failed: 0 Unsupported msgs rcvd : 0 Test call setups sent & failed: 0 Press enter to continue

Press enter to continue

Press enter to continuePress enter to continue

When the options presented in the following menu are chosen, they display a screen which shows the previous 24-hour performance segmented into 96 15-minute intervals. The number of instances that the particular parameter has occurred during each particul ar 15-minute interval displays.

Figure 3-15 Port 1 24 Hour Performance Data Menu

-- PORT 1 24 Hour Performance Data Menu --

-- PORT 1 24 Hour Performance Data Menu ---- PORT 1 24 Hour Performance Data Menu -Layer 2 statistics options:

Layer 2 statistics options:

Layer 2 statistics options:Layer 2 statistics options:

1) INFOs rcvd 2) INFOs xmitd

1) INFOs rcvd 2) INFOs xmitd 1) INFOs rcvd 2) INFOs xmitd

3) CRC errs rcvd 4) Invld frames rcvd

3) CRC errs rcvd 4) Invld frames rcvd 3) CRC errs rcvd 4) Invld frames rcvd

5) Frame aborts rcvd 6) DISCs rcvd

5) Frame aborts rcvd 6) DISCs rcvd 5) Frame aborts rcvd 6) DISCs rcvd

7) DISCs xmitd 8) FRMR rcvd

7) DISCs xmitd 8) FRMR rcvd 7) DISCs xmitd 8) FRMR rcvd

9) FRMR xmitd

9) FRMR xmitd 9) FRMR xmitd Layer 3 statistics options:

Layer 3 statistics options:

Layer 3 statistics options:Layer 3 statistics options:

10) L3 protocol errors

10) L3 protocol errors 10) L3 protocol errors Call Statistics options:

Call Statistics options:

Call Statistics options:Call Statistics options:

11) Call setups sent 12) Call setups sent & failed

11) Call setups sent 12) Call setups sent & failed 11) Call setups sent 12) Call setups sent & failed

13) Call setups received 14) Call setups received & failed

13) Call setups received 14) Call setups received & failed 13) Call setups received 14) Call setups received & failed

15) Unsupported msgs rcvd 16) Test call setups sent & failed

15) Unsupported msgs rcvd 16) Test call setups sent & failed 15) Unsupported msgs rcvd 16) Test call setups sent & failed X) exit this screen

X) exit this screen

X) exit this screen X) exit this screen A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

Diagnostics Menu

The

Main Menu

, Figure 3-1, enter D to access the Figure 3-16. Use this menu to activate or deactivate loopbacks, and send test patterns.

is used to troubleshoot the ports. From the

Diagnost ics Menu

,

3-20 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Figure 3-16 Diagnostics Menu

-- QPRI DIAGNOSTICS MENU --

-- QPRI DIAGNOSTICS MENU ---- QPRI DIAGNOSTICS MENU - PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4 PORT 1 PORT 2 PORT 3 PORT 4 Loop type NONE NONE NONE NONE

Loop type NONE NONE NONE NONE

Loop type NONE NONE NONE NONELoop type NONE NONE NONE NONE Test Pattern NONE NONE NONE NONE

Test Pattern NONE NONE NONE NONE

Test Pattern NONE NONE NONE NONETest Pattern NONE NONE NONE NONE Test Error Counter 0 0 0 0

Test Error Counter 0 0 0 0

Test Error Counter 0 0 0 0Test Error Counter 0 0 0 0 Ln) Line Loop Pn) Payload Loop

Ln) Line Loop Pn) Payload Loop

Ln) Line Loop Pn) Payload LoopLn) Line Loop Pn) Payload Loop Rn) Local Loop Tn) Test Pattern

Rn) Local Loop Tn) Test Pattern

Rn) Local Loop Tn) Test PatternRn) Local Loop Tn) Test Pattern An) Send LLB BOP Bn) Send PLB BOP

An) Send LLB BOP Bn) Send PLB BOP

An) Send LLB BOP Bn) Send PLB BOPAn) Send LLB BOP Bn) Send PLB BOP En) Reset Test Counter X) exit this screen

En) Reset Test Counter X) exit this screen

En) Reset Test Counter X) exit this screenEn) Reset Test Counter X) exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

NOTE:

If the loopback does not activate, use the Port Configuration menu to verify that the port is in service.

Table 3-15

Command Description Options

L

P

R

QPRI Diagnostics Menu Commands

n

Line Loopback (LLB): This option tests the network line from the far-end node. With Line Loopbacks, incoming signals are looped around and sent back toward the netw ork. The service provider or f ar-end node admini strator can then determine if the network line is good.

n

Payload Loopback (PLB): This option tests the QPRI from the far-end node. In this case, the data goes through the network line and the QPRI framer before it is looped back toward the network.

n

Local Loopback (RLB): This option tests all of the QPRI. Also known as a Repeater Loopback, the data sent from the data equipment passes thro ugh the QPRI up to the network interface and back to the equipment without passing through the network line.

CPE

QPRI Framer

1) DEACTIVATE

2) ACTIVATE

T1

1) DEACTIVATE

2) ACTIVATE

T1

1) DEACTIVATE

2) ACTIVATE

CPE T1

QPRI Framer

Verilink QPRI 2921 3-21

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Command Description Options

T

n

Test Pattern: None: This option indicates that no test pattern will be used. 3 in 24: 3-in-24 Onrs test pattern which consists of three pulses in every 24-

bit sequence (10001000 10000000 00000000). This stress test is useful for testing circuits und er extremely low d ensity conditio ns. This is mos tly useful for T1 AMI.

QRSS: Quasi-Random Signal Sequence that limits the signal to a maximum of 15 zeros that can be transmitted sequentially. These signals contain a medley of 20-bit words (except for more than 15 consecutive 0s). It repeats

1) NONE

2) 3/24

3) QRSS

20

-1

4) 2

5) 1/8

15

-1

6) 2

7) ALL 0’S

8) 55 OCTET (Daly)

9) ALL 1’S

every 1,048,575 bits. Also, it contai ns high density sequences and low density sequences, and sequen ces that chan g e f ro m l o w density to hig h density and vice versa (as defined by ANSI T1.403).

20

-1: Tests circuits for equalization and timing. It is the same as QRSS, but

2 without the 15 zeros restriction.

1/8: This pattern tests the ability of a circuit to support a pattern having the minimum ones density (containing 7 zeros indicating empty pulses and 1 pulse-1000000). It helps discover a timing recovery problem. This is mostly useful for T1 AMI.

15

-1: This pattern tests circuits for equalization and timing using an

2 alternate pattern for jitter testing. The pattern repeats every 32,757 bits.

All 0s: This pattern is composed entirely of framed zeros (00000000). It should only be used in conjunction with B8ZS (a clear channel) for end-toend testing. This is mostly useful for T1 B8ZS.

55 Octet: The Daly 55 octet pattern tests circuits for line card and timing recovery. By rapidl y transition ing from a lo ng seque nce of low de nsity octets to high density octets, the circuit is stress tested. Following is a binary representation of the 55 Octet stress pattern:

1000000010000000100000001000000010000000 10000000 00000001100000001000000010000 000 1000000010000000100000001100000010000000 1000000010000000100000001110000010000000 10000000 10000000100000001010101010101 010 1010101010101010010101010101010101010101 0101010110000000100000001000000010000000 1000000010000000111111111111111111111111 1111111111111111111111110000000110000000 0000000110000000000000011000000000000001 1000000000000001100000000000000110000000

All 1s: This pattern is composed entirely of framed ones (11111111). It stresses circuits by maximizing power consumption.

A

n

Send Line Loopback Bit-Oriented Protocol (LLB BOP): This option uses FDL loopbacks to test the T1 from the near-end toward the far-end.

B

n

Send Payload Loopback Bit-Oriented Protocol (PLB BOP): This option uses FDL loopbacks to test the CSU at the far-end circuit from the near-end.

E

n

Reset Test Counter: This option resets the test counter to 0. The counter is

1) DEACTIVATE

2) ACTIVATE

1) DEACTIVATE

2) ACTIVATE

automatically reset when changing patterns.

X

Exit the T1 Port Diagnostics Menu—Returns the screen to the Diagnostics Menu, Figure 3-16, Table 3-15.

When finished configuring the T1 port diagnostics parameters, enter X to return to the

3-22 Verilink QPRI 2921

Diagnostics Menu

.

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

NOTE:

To do an LLB BOP or a PLB BOP to the far-end, set the far-end “Network Initi ated Loop” option to “Yes.”

Performance / Status Menu

Use the condition of the network ports. The parameters in this menu provide counts for the various problems occuring in a given period of time. Performance info rmation is logged in 15 minute i ntervals over a 24 hour period.

To access the

Menu

Figure 3-17 Performance/Status Menu

A [127.255.255.0] [0,11] QPRI > p

A [127.255.255.0] [0,11] QPRI > pA [127.255.255.0] [0,11] QPRI > p

-- QPRI PERFORMANCE/STATUS MENU --

-- QPRI PERFORMANCE/STATUS MENU ---- QPRI PERFORMANCE/STATUS MENU - PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4 PORT 1 PORT 2 PORT 3 PORT 4 LOS YES YES NO NO

LOS YES YES NO NO

LOS YES YES NO NOLOS YES YES NO NO LOF NO NO NO NO

LOF NO NO NO NO

LOF NO NO NO NOLOF NO NO NO NO AIS Rx/Tx NO/NO NO/NO NO/NO NO/NO

AIS Rx/Tx NO/NO NO/NO NO/NO NO/NO

AIS Rx/Tx NO/NO NO/NO NO/NO NO/NOAIS Rx/Tx NO/NO NO/NO NO/NO NO/NO RAI Rx/Tx NO/YES NO/YES NO/NO NO/NO

RAI Rx/Tx NO/YES NO/YES NO/NO NO/NO

RAI Rx/Tx NO/YES NO/YES NO/NO NO/NORAI Rx/Tx NO/YES NO/YES NO/NO NO/NO SLIP NO NO NO NO

SLIP NO NO NO NO

SLIP NO NO NO NOSLIP NO NO NO NO CRC6 NO NO NO NO

CRC6 NO NO NO NO

CRC6 NO NO NO NOCRC6 NO NO NO NO BER NO NO NO NO

BER NO NO NO NO

BER NO NO NO NOBER NO NO NO NO CGA YES YES NO NO

CGA YES YES NO NO

CGA YES YES NO NOCGA YES YES NO NO P) display performance data T) threshold status

P) display performance data T) threshold status

P) display performance data T) threshold statusP) display performance data T) threshold status C) display counters X) exit this screen

C) display counters X) exit this screen

C) display counters X) exit this screenC) display counters X) exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

Performance/Status Menu

, Figure 3-1.

to monitor the func ti oning and

, enter P from the

Main

Use the

Performance/Status Menu

to monitor the following

functions:

•

LOS—Loss of Signal. A major alarm indicating no receive pulses at all. May be caused by disconnected or miswired network cable. Supercedes all other alarms: Ignore other alarms and troubleshoot this condition firs t.

•

LOF—Loss of Frame. (No frame synchronization)

•

AIS—Alarm Indication Signal. Unframed all-ones. Red Alarm.

•

RAI—Remote Alarm Indication. Yellow Alarm.

•

SLIP—Indicates variations in clock rate.

•

CRC-6—Cyclic Redundancy Check. Method for detecting biterrors. Used in ESF and ISDN.

•

BER—Bit Error Rate.

•

CGA—Carrier Group Alarm

Verilink QPRI 2921 3-23

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Table 3-16

Command Description

Performa nce/ Status Menu Comma nds

P

T

C

Display performance data—Displays the totals for the more common errors and alarms, and provides a menu for more detailed, 15-minute incremented, 24-hour time-period buffer records. Figure 3- 18, Table 3-17.

Threshold status—Displays the Net Port Alarm Threshold Status Menu, Figure 3-19. Display counters—displays the Counter Menu, Figure 3-20, Table 3-18.

Counts the number of BPV, FE, ESF, and CRC errors: Bipolar Violations (BPV): A violation of the T1 bipolar alternate mark inversion transmission

pattern in which consecutive ONEs (pulses) are erroneously transmitted as pulses of like polarities. Bipolar viol ati o ns norma ll y ind ic ate trans mi ssio n errors.

Frame Bit Error (FE): The number of whole seconds in which a framing bit error has been received.

Extended Superframe Format (ESF): This is the AT&T T1 framing standard that provides frame synchronizatio n, cyclic redundanc y check, data checking, a nd link bits. Th is counter is only available in ESF mode.

Cyclic Redundancy Check (CRC): An error-checking algorithm performed on data transmissions. On a frame-by-frame basis, a numerical value is derived from the data in the bit stream at o ne end of transmission. When each frame reac hes the receive end, the cyclic redundancy check is calculated again and compared with the value generated by the transmit-side data. Discrepancies can indicate one or more transmission errors. This counter is only available in ESF mode.

Options are: Rn—Reset counters, which resets the counter for the indicated port number. X—Exit this screen, which returns you to the Performance/Status Menu.

.

X

Exit the Performance/Status Menu—Returns to the Main Menu, Figure 3-1, Table 3-2.

Performance / Status Menu (24hr T1 Performance Data Summary)

Select P for “display performance data” from the

Performance/Status Menu

, Figure 3-17, to access the

Performance/Status Menu (24hr T1 Performance Data Summary)

, Figure 3-18.

3-24 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Figure 3-18 Performance/Status Menu (24hr T1 Performance Data Summary)

[0.0.0.5] [1,2] QPRI > p

[0.0.0.5] [1,2] QPRI > p[0.0.0.5] [1,2] QPRI > p

-- QPRI 2921 PERFORMANCE/STATUS MENU --

-- QPRI 2921 PERFORMANCE/STATUS MENU ---- QPRI 2921 PERFORMANCE/STATUS MENU -24hr T1 Performance Data Summary

24hr T1 Performance Data Summary

24hr T1 Performance Data Summary24hr T1 Performance Data Summary ES BES SES UAS LOF LOSS AISS

ES BES SES UAS LOF LOSS AISS

ES BES SES UAS LOF LOSS AISS ES BES SES UAS LOF LOSS AISS PORT 1 0 0 1 81342 81340 0 68284

PORT 1 0 0 1 81342 81340 0 68284

PORT 1 0 0 1 81342 81340 0 68284PORT 1 0 0 1 81342 81340 0 68284 PORT 2 0 0 0 81361 81359 81361 0

PORT 2 0 0 0 81361 81359 81361 0

PORT 2 0 0 0 81361 81359 81361 0PORT 2 0 0 0 81361 81359 81361 0 En) Errored Seconds Un) Unavailable Seconds

En) Errored Seconds Un) Unavailable Seconds

En) Errored Seconds Un) Unavailable SecondsEn) Errored Seconds Un) Unavailable Seconds Bn) Bursty Seconds Sn) Severely Errored Seconds

Bn) Bursty Seconds Sn) Severely Errored Seconds

Bn) Bursty Seconds Sn) Severely Errored SecondsBn) Bursty Seconds Sn) Severely Errored Seconds Ln) LOS Seconds Fn) SEF Seconds

Ln) LOS Seconds Fn) SEF Seconds

Ln) LOS Seconds Fn) SEF SecondsLn) LOS Seconds Fn) SEF Seconds Dn) LOF Seconds On) OOF Seconds

Dn) LOF Seconds On) OOF Seconds

Dn) LOF Seconds On) OOF SecondsDn) LOF Seconds On) OOF Seconds An) AIS Seconds Cn) Controlled Slip Seconds

An) AIS Seconds Cn) Controlled Slip Seconds

An) AIS Seconds Cn) Controlled Slip SecondsAn) AIS Seconds Cn) Controlled Slip Seconds Mn) Loss of Frame Counts Zn) AIS/SEF Seconds

Mn) Loss of Frame Counts Zn) AIS/SEF Seconds

Mn) Loss of Frame Counts Zn) AIS/SEF SecondsMn) Loss of Frame Counts Zn) AIS/SEF Seconds Qn) Errored Seconds Type A Hn) Frame Errors

Qn) Errored Seconds Type A Hn) Frame Errors

Qn) Errored Seconds Type A Hn) Frame ErrorsQn) Errored Seconds Type A Hn) Frame Errors Jn) Degraded Minutes In) Error Free Seconds

Jn) Degraded Minutes In) Error Free Seconds

Jn) Degraded Minutes In) Error Free SecondsJn) Degraded Minutes In) Error Free Seconds Rn) Reset Registers X) exit this screen

Rn) Reset Registers X) exit this screen

Rn) Reset Registers X) exit this screenRn) Reset Registers X) exit this screen [0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >

[0.0.0.5] [1,2] QPRI >[0.0.0.5] [1,2] QPRI >

Table 3-17

Command Description

E U

B

S

L

F

D

O

Performance/Status Menu (24hr T1 Performance Data Summary) Commands

n

Errored Seconds (ES): A second with one or more AIS, LOS, or LOF defects. Unavailable Seconds (UAS): Co un t ed fo r every second in which an Una vailable Signal St ate

n

occurs with the onset of 10 contiguous SES errors. It is also defined as the number of seconds a service is unavailab l e due to a Lo ss of Fra me ( L OF ) co ndition. The UAS condition is stop ped when the failure condition clears.

Bursty Seconds (BES): A second having between 2 and 319 CRC-6 (Cyclical Redundancy Check error events.

Severely Errored Seconds (SES): This error counts one second intervals with an AIS or CRC error.

Loss of Signal (LOS) Seconds: A second during which the QPRI is in a Loss of Signal state. LOS is declared upon detecting 175 consecutive zeros, it is cleared with the receipt of the next 1 bit.

Severely Errored Framing (SE F) Se conds: Those seconds in which two or more fr aming bit errors occur withi n a 3-m illis econd p eriod . In ESF mod e, this inte rval may o r may n ot co inci de with an ESF multiframe.

Loss-of-Frame (LOF) Seconds: An LOF alarm is declared when a 3-second interval of

n

continuous Out-Of-Frame (O OF) or Loss-Of-Signal (LOS) state is dete cted. If at least 10 seconds elapse without an LOS or LOF error, the LOF alarm is cleared.

Out-of-Frame (OOF) Seconds: A condition when any three of four consecutive frame bits

n

received from the T1 line are incorrect.

A

C

Alarm Indication Signal (AIS) Seconds: A count of one-second intervals containing one or more

n

AIS defects. AIS is an unframed All-Ones bit pattern that indicates an alarm condition exists upstream in a circuit leading to the downstream equipment. This is also called an All-Ones Keep-Alive or Blue Alarm Signal. An AIS defect is declared when there are 3 or fewer zeros in 512 bit times and there is an LOF defect. It is cleared when there are 3 or more zeros in two frames or the LOF defect no longer exists.

Controlled Slip Seconds: This error indicates that in a one second interval one or more slip

n

events occurred. An accurate count of controlled slips that occur can only be made at the terminating network element where the slips take place.

The current version of the firmware does not support this feature.

Verilink QPRI 2921 3-25

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Command Description

M

Z

n

Q

H

J

n

I

n

R

n

X

Loss of Frame Counts: An accumulation of the number of times a Loss-Of-Frame alarm is

n

declared. AIS/SEF Seconds: Displays information on the AIS and SEF erro rs.

AIS: An unframed All-Ones bit pattern that indicates that an alarm condition exists upstream in a circuit leading to the downstream equipment. Th is is also calle d an All-Ones Ke ep-Alive or Blue Alarm Signal.

SEF: The seconds in which two or more framing bit errors occur within a 3-millisecond period. In ESF mode, this interval may or may not coincide with an ESF multiframe.

Errored Seconds Type A: This error occurs when one Code Violation Path (CV-P) error and no

n

AIS defects occur in a second. Controlled Slips are not included in this parameter. Frame Bit Error (FE): An error in the received framing bit pattern and the number of whole

n

seconds that a framing bit error has occurred. Degraded Minutes (DM): This error occurs when the Bit Error Rate (BER) threshold of 10

exceeded in a 60 second p eri od. Error Free Seconds: A second with no detected error s.

Reset Registers: Use this option to clear out all counts and reset all registers to zero for a particular port.

Exit this screen—Exits the Performance/Status Menu (24hr T1 Performance Data Summary) and returns to the Performance/Status Menu, Figure 3-17.

-6

is

When one of these options is selected, the previous 24 hour data is displayed in 15 minute increments for a total of 96 blocks of time.

NTER

E

Press

to exit these screens.

Net Port Alarm Threshold Status Menu

Enter T from the

Net Port Alarm Threshold Status Menu

the screen shows the threshold intervals set in the

Threshold Configuration Menu

Performance/Status Menu

, Figure 3-22.

, Figure 3-17, to access , Figure 3-19. This

Net Port Alarm

It also displays the counts for each type of alarm. When the alar m count exceeds its threshold value set in the

Threshold Configuration Menu

, a “Y” displays after the count.

Net Port Alarm

3-26 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Figure 3-19 Net Port Alarm Threshold Status Menu

A [127.255.255.0] [0,11] QPRI > t

A [127.255.255.0] [0,11] QPRI > tA [127.255.255.0] [0,11] QPRI > t

-- QPRI NET PORT ALARM THRESHOLD STATUS MENU --

-- QPRI NET PORT ALARM THRESHOLD STATUS MENU ---- QPRI NET PORT ALARM THRESHOLD STATUS MENU - PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4

PORT 1 PORT 2 PORT 3 PORT 4 PORT 1 PORT 2 PORT 3 PORT 4 LOF counts(exceeded) 2(N) 2(N) 0(N) 0(N)

LOF counts(exceeded) 2(N) 2(N) 0(N) 0(N)

LOF counts(exceeded) 2(N) 2(N) 0(N) 0(N)LOF counts(exceeded) 2(N) 2(N) 0(N) 0(N) interval 2 2 2 2

interval 2 2 2 2

interval 2 2 2 2 interval 2 2 2 2 LOS counts(exceeded) 2(N) 2(N) 0(N) 0(N)

LOS counts(exceeded) 2(N) 2(N) 0(N) 0(N)

LOS counts(exceeded) 2(N) 2(N) 0(N) 0(N)LOS counts(exceeded) 2(N) 2(N) 0(N) 0(N) interval 2 2 2 2

interval 2 2 2 2

interval 2 2 2 2 interval 2 2 2 2 RAI counts(exceeded) 0(N) 0(N) 0(N) 0(N)

RAI counts(exceeded) 0(N) 0(N) 0(N) 0(N)

RAI counts(exceeded) 0(N) 0(N) 0(N) 0(N)RAI counts(exceeded) 0(N) 0(N) 0(N) 0(N) interval 1 1 1 1

interval 1 1 1 1

interval 1 1 1 1 interval 1 1 1 1 AIS counts(exceeded) 0(N) 0(N) 0(N) 0(N)

AIS counts(exceeded) 0(N) 0(N) 0(N) 0(N)

AIS counts(exceeded) 0(N) 0(N) 0(N) 0(N)AIS counts(exceeded) 0(N) 0(N) 0(N) 0(N) interval 1 1 1 1

interval 1 1 1 1

interval 1 1 1 1 interval 1 1 1 1 BPV counts(exceeded) 0(N) 0(N) 0(N) 0(N)

BPV counts(exceeded) 0(N) 0(N) 0(N) 0(N)

BPV counts(exceeded) 0(N) 0(N) 0(N) 0(N)BPV counts(exceeded) 0(N) 0(N) 0(N) 0(N) interval 1 1 1 1

interval 1 1 1 1

interval 1 1 1 1 interval 1 1 1 1 ES 15min counts(exceeded) 0(N) 0(N) 0(N) 0(N)

ES 15min counts(exceeded) 0(N) 0(N) 0(N) 0(N)

ES 15min counts(exceeded) 0(N) 0(N) 0(N) 0(N)ES 15min counts(exceeded) 0(N) 0(N) 0(N) 0(N) ES 24hr counts(exceeded) 0(N) 0(N) 0(N) 0(N)

ES 24hr counts(exceeded) 0(N) 0(N) 0(N) 0(N)

ES 24hr counts(exceeded) 0(N) 0(N) 0(N) 0(N)ES 24hr counts(exceeded) 0(N) 0(N) 0(N) 0(N) SES 15min counts(exceeded) 0(N) 0(N) 0(N) 0(N)

SES 15min counts(exceeded) 0(N) 0(N) 0(N) 0(N)

SES 15min counts(exceeded) 0(N) 0(N) 0(N) 0(N)SES 15min counts(exceeded) 0(N) 0(N) 0(N) 0(N) SES 24hr counts(exceeded) 0(N) 0(N) 0(N) 0(N)

SES 24hr counts(exceeded) 0(N) 0(N) 0(N) 0(N)

SES 24hr counts(exceeded) 0(N) 0(N) 0(N) 0(N)SES 24hr counts(exceeded) 0(N) 0(N) 0(N) 0(N) Press enter to continue

Press enter to continue

Press enter to continuePress enter to continue

Counter Menu

Enter C from the

Counter Menu

the

Performance/Status Menu

. These counts are continuous until reset using

the Rn option.

Figure 3-20 Counter Menu

A [127.255.255.0] [0,11] QPRI > c

A [127.255.255.0] [0,11] QPRI > cA [127.255.255.0] [0,11] QPRI > c

-- QPRI COUNTER MENU --

-- QPRI COUNTER MENU ---- QPRI COUNTER MENU - BPV FE ESF CRC

BPV FE ESF CRC

BPV FE ESF CRC BPV FE ESF CRC PORT 1 0 0 65535 0

PORT 1 0 0 65535 0

PORT 1 0 0 65535 0PORT 1 0 0 65535 0 PORT 2 0 0 65535 0

PORT 2 0 0 65535 0

PORT 2 0 0 65535 0PORT 2 0 0 65535 0 PORT 3 255 255 2 0

PORT 3 255 255 2 0

PORT 3 255 255 2 0PORT 3 255 255 2 0 PORT 4 255 255 0 0

PORT 4 255 255 0 0

PORT 4 255 255 0 0PORT 4 255 255 0 0 Rn) Reset counters X) exit this screen

Rn) Reset counters X) exit this screen

Rn) Reset counters X) exit this screenRn) Reset counters X) exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

Table 3-18

Command Description

R

Counter Menu Commands

n

X

Reset Counters: Returns the values of the BPV, FE, ESF, and CRC counters to zero or N/A. Exit this screen—Returns to the Performance/Status Menu, Figure 3-17, Table 3-16.

, Figure 3-17, to access

Verilink QPRI 2921 3-27

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Net Port Alarm Menu

To access the

Net Port Alarm Menu

Figure 3-1. Use this menu to set alarm threshold values, monitor alarm status, and set other alarm parameters. All monito red conditions are also reflected by LED states.

Figure 3-21 Net Port Alarm Menu

A [127.255.255.0] [0,11] QPRI > a

A [127.255.255.0] [0,11] QPRI > aA [127.255.255.0] [0,11] QPRI > a

-- QPRI NET PORT ALARM MENU --

-- QPRI NET PORT ALARM MENU ---- QPRI NET PORT ALARM MENU -N) NMS Address 128.0.0.0

N) NMS Address 128.0.0.0

N) NMS Address 128.0.0.0N) NMS Address 128.0.0.0 A) Card Alarm Reporting NO

A) Card Alarm Reporting NO

A) Card Alarm Reporting NOA) Card Alarm Reporting NO C) Configure Thresholds S) Alarm status

C) Configure Thresholds S) Alarm status

C) Configure Thresholds S) Alarm statusC) Configure Thresholds S) Alarm status O) Display Alarm Buffer Tn) Set Default Thresholds

O) Display Alarm Buffer Tn) Set Default Thresholds

O) Display Alarm Buffer Tn) Set Default ThresholdsO) Display Alarm Buffer Tn) Set Default Thresholds X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >

A [127.255.255.0] [0,11] QPRI >A [127.255.255.0] [0,11] QPRI >

Table 3-19

Command Description

Net Port Alarm Menu Commands

N

A C

Network Management System (NMS) Address: This option sets the ACP address (which is the address of the PC that will receive the alarms). Though this address is significant for Node Manager, it is not important for the ASCII interface.

Card Alarm Reporting: This option enables or disables the module from sending alarms. Configure Threshol ds: To disable any or all alarm conditions, enter a threshold val ue of 0.

To enable a condition, specify any non-zero threshold value. Figure 3-22, Table 3-20.

, enter

A

from the

Main Menu

,

S

O

Tn

X

Alarm Status: Displays the Net Port Alarm Threshold Status Menu which shows the counts and intervals of the LOF, LOS, RAI, AIS , BPV, ES , and SE S registers. Figure 3-23.

Display Alarm Buffer: Displays the Alarm Buffer. These are the alarms which have been stored in the database.

Set Default Thresholds—Resets the module and loads the factory default threshold settings. Exit this screen—Returns you to the Main Menu, Figure 3-1.

Net Port Alarm Threshold Configuration Menu

Performance/Status Menu

The thresholds, while the

Menu

enables setting custom alarm thresholds and intervals in

Net Port Alarm Threshold Configuration

reflects the industry T1 stan dard

addition to the above standards. To view and modify the ala rm thresholds, enter C from the

Port Alarm Menu

to display the

Configuration Menu

. Use this menu to set the monitoring interval

Net Port Alarm Threshold

Net

and the alarm threshold for errored seconds within the m on itoring interval.

3-28 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

For example, if the LOF interval is set to 100 seconds, and the LOF threshold is set to 5 seconds, then an alarm is sent if more than 5 errored seconds occur during a 100-second interval. The erro red count resets to zero at the end of the interval, unless there is an alarm condition, and the first second of the next interval is also errored. The alarm s tate continues until a new i nterval contains no errors in the first second.

Figure 3-22 Net Port Alarm Threshold Configuration Menu

-- QPRI NET PORT ALARM THRESHOLD CONFIGURATION MENU --

-- QPRI NET PORT ALARM THRESHOLD CONFIGURATION MENU ---- QPRI NET PORT ALARM THRESHOLD CONFIGURATION MENU - PORT 1 PORT 2

PORT 1 PORT 2

PORT 1 PORT 2 PORT 1 PORT 2 Pn) Alarm Reporting(NET) NO NO

Pn) Alarm Reporting(NET) NO NO

Pn) Alarm Reporting(NET) NO NOPn) Alarm Reporting(NET) NO NO Fn) LOF threshold 3 3

Fn) LOF threshold 3 3

Fn) LOF threshold 3 3Fn) LOF threshold 3 3 LOF interval 3 3

LOF interval 3 3

LOF interval 3 3 LOF interval 3 3 Ln) LOS threshold 3 3

Ln) LOS threshold 3 3

Ln) LOS threshold 3 3Ln) LOS threshold 3 3 LOS interval 3 3

LOS interval 3 3

LOS interval 3 3 LOS interval 3 3 Rn) RAI threshold 1 1

Rn) RAI threshold 1 1

Rn) RAI threshold 1 1Rn) RAI threshold 1 1 RAI interval 1 1

RAI interval 1 1

RAI interval 1 1 RAI interval 1 1 An) AIS threshold 1 1

An) AIS threshold 1 1

An) AIS threshold 1 1An) AIS threshold 1 1 AIS interval 1 1

AIS interval 1 1

AIS interval 1 1 AIS interval 1 1 Bn) BPV threshold 1 1

Bn) BPV threshold 1 1

Bn) BPV threshold 1 1Bn) BPV threshold 1 1 BPV interval 1 1

BPV interval 1 1

BPV interval 1 1 BPV interval 1 1 En) ES 15min threshold 900 900

En) ES 15min threshold 900 900

En) ES 15min threshold 900 900En) ES 15min threshold 900 900 ES 24hr threshold 86400 86400

ES 24hr threshold 86400 86400

ES 24hr threshold 86400 86400 ES 24hr threshold 86400 86400 Sn) SES 15min threshold 900 900

Sn) SES 15min threshold 900 900

Sn) SES 15min threshold 900 900Sn) SES 15min threshold 900 900 SES 24hr threshold 86400 86400

SES 24hr threshold 86400 86400

SES 24hr threshold 86400 86400 SES 24hr threshold 86400 86400 In) BER threshold DISABLE DISABLE

In) BER threshold DISABLE DISABLE

In) BER threshold DISABLE DISABLEIn) BER threshold DISABLE DISABLE X) exit this screen

X) exit this screen

X) exit this screenX) exit this screen

NOTE:

To disable any or al l alarm conditions, enter a threshold value of 0. To enable a condition, specify any non-ze ro threshold value. The interval must be g reater than or equal to the threshold value.

Verilink QPRI 2921 3-29

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Table 3-20

Command Description Options

P

F

L

R

A

Net Port Alarm Threshold Configuration Menu Commands

Alarm Reporting (NET): Enabling alarm reporting, indicates alarms for each

n

network port. These alarms are declared to the ASCII interface as well as the Node Manager. If this option is set to No, alarm messages are not reported. The LEDs remain amber or red in an alarm condition. Set this option to No while configuring the node; then set to

For any of the Advanced Automatic Protection Switching features—dial backup or other backup options—this parameter MUST be set to Yes.

Loss-of-Frame (LOF) Threshold/LOF Interval: Use this option to indicate an

n

interval that is greater than the threshold.

Loss of Signal (LOS) Threshold/LOS Interval: Use this option to indicate an

n

interval that is greater than the threshold.

If LOS occurs, troubleshoot this situation first and ignore all other alarms (There will be other alarms). This is the most severe alarm.

Remote Alarm Ind ic at i o n (R AI) Threshold/R AI In t erval:

n

In SF, an RAI consists of Bit 2 of all 24 channels set to zero. In ESF, an RAI is a repeating pattern of eight Ones followed by eight Zeros

transmitted over the ESF Data Link.

Alarm Indication Sig nal (AIS) Threshold/AIS Interval: Threshold:

n

Yes

for normal operation.

Yes or No (Y/N)

Threshold: 1—86400 0 to disable

Interval: 3—86400 seconds

Threshold: 1—86400 0 to disable

Interval: 3—86400 seconds

Threshold: 1—86400 0 to disable

Interval: 1—86400 seconds

1—86400 0 to disable

Interval: 1— 86400 seconds

B

E

3-30 Verilink QPRI 2921

Bipolar Violation (BPV) Threshold/BPV Interval: Threshold:

n

Errored Seconds (ES) 15 min. Threshold/ES 24 hr. Threshold: An ES alarm

n

indicates a second with one or more ESF error events.

1—86400 0 to disable

Interval: 1—86400 seconds

15 minute Threshold: 1—900 0 to disable

24 hour Threshold: 1—86400 0 to disable

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Command Description Options

S

T

X

Severely Errored Secon d (SES) 15 min. Threshold/SES 24 hr. Threshold: Select

n

15-minute and 24-hour threshold values.

Bit Error Rate (BER) Th resh old: Sele cti ng 10

n

Exit this screen—Returns you to the Net Port Alarm Menu, Figure 3-21, Table 3-19.

Net Port Alarm Theshold Status Menu

15 minute Threshold: 1—900 0 to disable

24 hour Threshold: 1—86400 0 to disable

-9

To display the

Net Port Alarm Menu

the

Net Port Alarm Threshold Statu s Menu

will report more errors than 1 0-4. 1) DISABLE

. This alarm register displays all major

2) 10E-4

3) 10E-5

4) 10E-6

5) 10E-7

6) 10E-8

7) 10E-9

, enter S in

and minor alarms tha t have occurred at each port . When an alarm is cleared, the time stamp ch anges to reflect the time the alarm was cleared.

This screen only displays information. You cannot change any of the settings displayed via this screen. The settings must be changed using the accessed through the

Net Port Alarm Threshold Configuration Menu

Net Port Alarm Menu

, Figure 3-21, option C.

Verilink QPRI 2921 3-31

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Figure 3-23 Net Port Alarm Threshold Status

-- QPRI 2921 NET PORT ALARM THRESHOLD STATUS MENU --

-- QPRI 2921 NET PORT ALARM THRESHOLD STATUS MENU ---- QPRI 2921 NET PORT ALARM THRESHOLD STATUS MENU -Current Threshold Status PORT 1 PORT 2

Current Threshold Status PORT 1 PORT 2

Current Threshold Status PORT 1 PORT 2Current Threshold Status PORT 1 PORT 2 LOF counts(exceeded) 0(N) 0(N)

LOF counts(exceeded) 0(N) 0(N)

LOF counts(exceeded) 0(N) 0(N)LOF counts(exceeded) 0(N) 0(N) interval 0 0

interval 0 0

interval 0 0 interval 0 0 LOS counts(exceeded) 0(N) 0(N)

LOS counts(exceeded) 0(N) 0(N)

LOS counts(exceeded) 0(N) 0(N)LOS counts(exceeded) 0(N) 0(N) interval 0 0

interval 0 0

interval 0 0 interval 0 0 RAI counts(exceeded) 0(N) 0(N)

RAI counts(exceeded) 0(N) 0(N)

RAI counts(exceeded) 0(N) 0(N)RAI counts(exceeded) 0(N) 0(N) interval 0 0

interval 0 0

interval 0 0 interval 0 0 AIS counts(exceeded) 0(N) 0(N)

AIS counts(exceeded) 0(N) 0(N)

AIS counts(exceeded) 0(N) 0(N)AIS counts(exceeded) 0(N) 0(N) interval 0 0

interval 0 0

interval 0 0 interval 0 0 BPV counts(exceeded) 0(N) 0(N)

BPV counts(exceeded) 0(N) 0(N)

BPV counts(exceeded) 0(N) 0(N)BPV counts(exceeded) 0(N) 0(N) interval 0 0

interval 0 0

interval 0 0 interval 0 0 ES 15min counts(exceeded) 0(N) 0(N)

ES 15min counts(exceeded) 0(N) 0(N)

ES 15min counts(exceeded) 0(N) 0(N)ES 15min counts(exceeded) 0(N) 0(N) ES 24hr counts(exceeded) 0(N) 0(N)

ES 24hr counts(exceeded) 0(N) 0(N)

ES 24hr counts(exceeded) 0(N) 0(N)ES 24hr counts(exceeded) 0(N) 0(N) SES 15min counts(exceeded) 0(N) 0(N)

SES 15min counts(exceeded) 0(N) 0(N)

SES 15min counts(exceeded) 0(N) 0(N)SES 15min counts(exceeded) 0(N) 0(N) SES 24hr counts(exceeded) 0(N) 0(N)

SES 24hr counts(exceeded) 0(N) 0(N)

SES 24hr counts(exceeded) 0(N) 0(N)SES 24hr counts(exceeded) 0(N) 0(N) Rn) Reset Registers X) exit this screen

Rn) Reset Registers X) exit this screen

Rn) Reset Registers X) exit this screenRn) Reset Registers X) exit this screen

Circuit Manager Menu

To access the Use the

circuit is the path on whi ch data travels between a port at the source end and a port at the destination end. The port can be a T1 or data port. T1 port circuit size is in number of timeslots, 1 through 24. The equip ment port circuit size is in 56k or 64k bit increments.

You can mix T1 and data ports as source and destination ends. Data-to-data po rt circuits are limited to inter-modu le only.

For ISDN (dial backup switch) circuits, the ISDN port must be the destination port. (Equipment ports are usually the source ports and net ports are usually the destination ports.)

Figure 3-24 Port Line Code Selection

Circuit Manager Menu

Circuit Manager

Net 3

from the

Main Menu

, enter B.

menu to build and maintain circuits. A

A

B

Net 1

Net 4

A. Equipment to T1 B. T1 to T1

3-32 Verilink QPRI 2921

Net 2

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

The port line code selection (for example, 56k or 64k circuits) can limit a circuit’s configuration.

NOTE:

Network and equipment ports must be

In Service

circuit can be built.

When you have named a circuit and identified its source and destination ports, allocate the source and destination timeslots.

NOTE:

Build T1-to-T1 circuits first. Allocate the same-numbered timeslots on both the source and the dest ination ends.

Figure 3-25 Circuit Manager Menu

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI > Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 --

Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 --

Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 --Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 - Page : 1

Page : 1

Page : 1 Page : 1 Total: 2 circuits

Total: 2 circuits

Total: 2 circuits Total: 2 circuits Name Type Mode Prio Src Port Dest Port Bus Status

Name Type Mode Prio Src Port Dest Port Bus Status

Name Type Mode Prio Src Port Dest Port Bus Status Name Type Mode Prio Src Port Dest Port Bus Status

------------ ---- ---- ---- ---------------- ---------------- --- ------

------------ ---- ---- ---- ---------------- ---------------- --- ------------------ ---- ---- ---- ---------------- ---------------- --- -----QPRItestC1 prim 64k crit [1, 2] QPRI net3 [1, 2] QPRI net1 INT Inacti

QPRItestC1 prim 64k crit [1, 2] QPRI net3 [1, 2] QPRI net1 INT Inacti

QPRItestC1 prim 64k crit [1, 2] QPRI net3 [1, 2] QPRI net1 INT InactiQPRItestC1 prim 64k crit [1, 2] QPRI net3 [1, 2] QPRI net1 INT Inacti dialbackup d-bk 64k crit [1, 2] QPRI net4 [1, 2] QPRI net2 -- Inacti

dialbackup d-bk 64k crit [1, 2] QPRI net4 [1, 2] QPRI net2 -- Inacti

dialbackup d-bk 64k crit [1, 2] QPRI net4 [1, 2] QPRI net2 -- Inactidialbackup d-bk 64k crit [1, 2] QPRI net4 [1, 2] QPRI net2 -- Inacti A) add circuit L) search circuit

A) add circuit L) search circuit

A) add circuit L) search circuit A) add circuit L) search circuit D) delete circuit E) edit circuit

D) delete circuit E) edit circuit

D) delete circuit E) edit circuit D) delete circuit E) edit circuit P) prev page I) activate circuit

P) prev page I) activate circuit

P) prev page I) activate circuit P) prev page I) activate circuit N) next page R) deactivate circuit

N) next page R) deactivate circuit

N) next page R) deactivate circuit N) next page R) deactivate circuit X) exit to craft main menu

X) exit to craft main menu

X) exit to craft main menu X) exit to craft main menu A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

before a

NOTE:

If a module is mo ved to a diffe re nt slot , t he ci rcu it (s) m us t be rebuilt.

Table 3-21

Command Description

Circuit Manager Menu Commands

A

L

D

E

P

I N R

X

Add Circuit—Use this option to add a circuit. Figure 3-27, Table 3-22. Search Circuit—Use this option to search for or list existing circuits. Figure 3-28, Table 3-23. Delete Circuit—Use this option to remove an existing circuit. Figure 3-29, Table 3-24. Edit Circuit—Use this option to change characteristics of a particular circuit. Figure 3-30,

Table 3-25. Prev page—Views the previous page of the circuit list when the list is greater than one page. Activate circuit—Changes the circuit to active status. Next page—Views the next page of the circuit list when the list is greater than one page. Deactivate circuit—Changes the circuit to inactive status (The circuit will not carry data). Exit to Craft Main Menu—Exits the Circuit Manager Menu, and returns to the Main Menu,

Figure 3-1, Table 3-2.

Verilink QPRI 2921 3-33

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Add Circuit Submenu

Use this option to create a n ew circu it. S pecify the ID fo r th e circui t port. The ID number must be uni que (12 characters maxim um). Enter which timeslots will leave the source port, and which timeslots will end at the destination port (from 1 to 24). Specify if the timeslots are 56kbit/s or 64kbit/s in bandwidth.

Circuit IDs identify particular circuits. For instance, if you build a circuit on card 3 fr om Net Port 1 to Net Port 2, the ID can be 312. Or, use names to identify the circuits. The following graphic shows that Circuit 1 has 1 to 15 timesl ots and connects Source Port Net 1 to Destination Port Net 3. Circuit 2 has timeslots 16 to 24 an d connects Source Port Net 1 to De stination Port Net 4.

Figure 3-26 Create a New Circuit

Net 3

Net 4

C1: Timeslots 1-15

C2: Timeslots 16-24

Net 1

Net 2

Figure 3-27 Add Circuit Submenu

A [127.255.255.0] [1,2] QPRI > a

A [127.255.255.0] [1,2] QPRI > aA [127.255.255.0] [1,2] QPRI > a Add Circuit -- [1,1] NCM 2000 Firmware 4.15 --

Add Circuit -- [1,1] NCM 2000 Firmware 4.15 --

Add Circuit -- [1,1] NCM 2000 Firmware 4.15 --Add Circuit -- [1,1] NCM 2000 Firmware 4.15 - N) Name: -- P) Priority: norm

N) Name: -- P) Priority: norm

N) Name: -- P) Priority: norm N) Name: -- P) Priority: norm T) Type: -- M) Mode: --

T) Type: -- M) Mode: --

T) Type: -- M) Mode: -- T) Type: -- M) Mode: -SP) [-,-] undefined DP) [-,-] undefined

SP) [-,-] undefined DP) [-,-] undefined

SP) [-,-] undefined DP) [-,-] undefinedSP) [-,-] undefined DP) [-,-] undefined SM) --src port chn-- DM) --dst port chn--

SM) --src port chn-- DM) --dst port chn--

SM) --src port chn-- DM) --dst port chn--SM) --src port chn-- DM) --dst port chn- (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port)

(undefined port) (undefined port)

(undefined port) (undefined port) (undefined port) (undefined port) U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<-

U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<-

U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<- U) Bus: -- ->-->>->> Circuit Inactive <<-<<--< S) Setup X) Exit

S) Setup X) Exit

S) Setup X) Exit S) Setup X) Exit A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

3-34 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Table 3-22

Command Description Options

N

P

T

M

SP

Add Circuit Submenu Commands

Name—Circuit name (Circuit ID 12 characters

maximum

Priority— 1) low

2) norm

3) high

4) crit

Type—Circuit type. 1) perm

Mode—Circuit Mode 1) 64K

Source Port—Displays the Node “Map” and prompts for the SRC Port shelf, slot. Use this option to designate the starting point of your circuit. Once the Shelf and slot position of the Source Port has been entered, you are prompted with 4 choices.

2) swit

3) prim

4) d-bk

5) bkup

2) 56K For Subrate DIU only:

3) 38.4K

4) 19.2K

5) 9.6K

6) 4.8K

7) 2.4K

1) net1

2) net2

3) net3

4) net4

DP

SM

DM

U

S X

Destination Port—Displays the Node “Map” and prompts for the DEST Port shelf, slot. Use this option to designate the ending point of your circuit. Once the Shelf and slot position of the Source Port has been entered, you are prompted with 4 choices.

SRC Port Chn—Source Timeslot. Designate which T1 timeslots you wish to use in this circuit.

Note:

In ISDN, timeslot 24 is normally reserved for use in D-channel call

set-up. For this reason, avoid building circuits which use timeslot 24.

For ISDN, a call-reference option is provided to designate the call profile for backup.

DST Port Chn—Destination Timeslot Designate which T1 timeslots you wish to use at the Destination Port.

Note:

In ISDN, timeslot 24 is normally reserved for use in D-channel call

set-up. For this reason, avoid building circuits which use timeslot 24.

For ISDN, a call-reference option is provided to designate the call profile for backup.

Bus—Select a backplane bus for intermodule communication. The A Bus is always used for ISDN.

Setup—Validates and saves the configuration. Exit—exits this menu and displays the Circuit Manager Menu, Figure 3-25,

Table 3-21.

1) net1

2) net2

3) net3

4) net4 1—24 or press

ENTER to exit

1—24 or ENTER to exit

1) A

2) B

3) C

4) Auto

Verilink QPRI 2921 3-35

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Search Circuit

Use this opti on to s e ar ch for or list existi n g ci rcuits.

Submenu

Figure 3-28 Search Circuit Submenu (Circ List Menu)

A [127.255.255.0] [1,2] QPRI > l

A [127.255.255.0] [1,2] QPRI > lA [127.255.255.0] [1,2] QPRI > l Circ List Menu -- [1,1] NCM 2000 Firmware 4.15 --

Circ List Menu -- [1,1] NCM 2000 Firmware 4.15 --

Circ List Menu -- [1,1] NCM 2000 Firmware 4.15 --Circ List Menu -- [1,1] NCM 2000 Firmware 4.15 - C) search by shelf,slot

C) search by shelf,slot

C) search by shelf,slot C) search by shelf,slot P) search by port.

P) search by port.

P) search by port. P) search by port. X) exit

X) exit

X) exit X) exit A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

Table 3-23

Command Description Options

C

P

X

Search Circuit Submenu (Circ List Menu) Commands

Search by shelf, slot—Shelf and slot must be specified. Slots must be specified in the range of 1through 13. If return is pressed, the screen will display (list) the current circuits and their status.

Search by port—Specify Circuit Port she lf, slot. Slots must be specified in the range of 1through 13. If return is pressed, the screen will display (list) the current circuits and their sta t u s.

exit—exits this screen and returns to the Circuit Manager Menu, Figure 3-25, Table 3-21.

Shelf, slot (range 1—13)

Delete Circuit

Use this opti o n to re move existin g ci rcuits.

Submenu

Figure 3-29 Delete Circuit Submenu (Circ Deletion Menu)

A [127.255.255.0] [1,2] QPRI > d

A [127.255.255.0] [1,2] QPRI > dA [127.255.255.0] [1,2] QPRI > d Circ Deletion Menu -- [1,1] NCM 2000 Firmware 4.15 --

Circ Deletion Menu -- [1,1] NCM 2000 Firmware 4.15 --

Circ Deletion Menu -- [1,1] NCM 2000 Firmware 4.15 --Circ Deletion Menu -- [1,1] NCM 2000 Firmware 4.15 - S) single circuit

S) single circuit

S) single circuit S) single circuit A) all circuits

A) all circuits

A) all circuits A) all circuits C) card circuits

C) card circuits

C) card circuits C) card circuits P) port circuits

P) port circuits

P) port circuits P) port circuits X) exit

X) exit

X) exit X) exit A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

Table 3-24

Command Description Options

Delete Circuit Submenu (Circ Deletion Menu) Commands

S

A

C

P

X

Single circuit—Use the Circuit ID to specify the circuit to delete: 12 characters maximum.

All circuits—Screen will prompt with the warning: Are You Sure? (Y/N) Yes or No

Card circuits—Specify the Shelf/Slot. Slots must be specified in the range of 1 through 13.

Port circuits—Select the Circuit Ports by shelf/slot number. Slots must be in the range of 1 through 13.

exit—Exits the Delete Circuit Submenu and returns you to the Circuit Manager Menu, Figure 3-25, Table 3-21.

Circuit ID: 12 characters maximum

(Y/N) Shelf, Slot

(Range of 1—13) Shelf, Slot

(Range of 1—13)

3-36 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Edit Circuit Submenu

To change a circuit’s c haracteristics, use the Edit Circuit Submenu. However, you cannot change a circuit while it is active/running— deactivate the circu it first, then zero it out.

To edit a circuit, enter E from the

Edit Circui t

the

menu. To change the characterist ics of a particu lar

Circuit Manager

circuit, specify the Circuit ID of an existing circuit.

Figure 3-30 Edit Circuit Submenu

A [127.255.255.0] [1,2] QPRI > e

A [127.255.255.0] [1,2] QPRI > eA [127.255.255.0] [1,2] QPRI > e Enter circuit name ( 12 char maximum ): dialbackup

Enter circuit name ( 12 char maximum ): dialbackup

Enter circuit name ( 12 char maximum ): dialbackupEnter circuit name ( 12 char maximum ): dialbackup Edit Circuit -- [1,1] NCM 2000 Firmware 4.15 --

Edit Circuit -- [1,1] NCM 2000 Firmware 4.15 --

Edit Circuit -- [1,1] NCM 2000 Firmware 4.15 --Edit Circuit -- [1,1] NCM 2000 Firmware 4.15 - N) Name: dialbackup P) Priority: crit

N) Name: dialbackup P) Priority: crit

N) Name: dialbackup P) Priority: crit N) Name: dialbackup P) Priority: crit T) Type: d-bk M) Mode: 64k

T) Type: d-bk M) Mode: 64k

T) Type: d-bk M) Mode: 64k T) Type: d-bk M) Mode: 64k SP) [1, 2] QPRI dat1 DP) [1, 2] QPRI net2

SP) [1, 2] QPRI dat1 DP) [1, 2] QPRI net2

SP) [1, 2] QPRI dat1 DP) [1, 2] QPRI net2SP) [1, 2] QPRI dat1 DP) [1, 2] QPRI net2 SM) --src port chn-- DM) --dst port chn--

SM) --src port chn-- DM) --dst port chn--

SM) --src port chn-- DM) --dst port chn--SM) --src port chn-- DM) --dst port chn- 01 02 03 04 05 06 07 08 01 02 03 04 05 06 07 08

01 02 03 04 05 06 07 08 01 02 03 04 05 06 07 08

01 02 03 04 05 06 07 08 01 02 03 04 05 06 07 08 01 02 03 04 05 06 07 08 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 09 10 11 12 13 14 15 16

09 10 11 12 13 14 15 16 09 10 11 12 13 14 15 16

09 10 11 12 13 14 15 16 09 10 11 12 13 14 15 16 09 10 11 12 13 14 15 16 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 .. 17 18 19 20 21 22 23 ..

17 18 19 20 21 22 23 .. 17 18 19 20 21 22 23 ..

17 18 19 20 21 22 23 .. 17 18 19 20 21 22 23 .. 17 18 19 20 21 22 23 .. 17 18 19 20 21 22 23 .. U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<-

U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<-

U) Bus: -- ->-->>->> Circuit Inactive <<-<<--<- U) Bus: -- ->-->>->> Circuit Inactive <<-<<--< A) primary circ: backup circ: dialbackup

A) primary circ: backup circ: dialbackup

A) primary circ: backup circ: dialbackup A) primary circ: backup circ: dialbackup SE) src err mask: -- C) dst call ref: --

SE) src err mask: -- C) dst call ref: --

SE) src err mask: -- C) dst call ref: --SE) src err mask: -- C) dst call ref: -DE) dst err mask: -- O) dbkp timeout: none

DE) dst err mask: -- O) dbkp timeout: none

DE) dst err mask: -- O) dbkp timeout: noneDE) dst err mask: -- O) dbkp timeout: none G) err clr mask: no primary port

G) err clr mask: no primary port

G) err clr mask: no primary port G) err clr mask: no primary port S) Setup X) Exit

S) Setup X) Exit

S) Setup X) Exit S) Setup X) Exit A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >

A [127.255.255.0] [1,2] QPRI >A [127.255.255.0] [1,2] QPRI >

menu to display

Table 3-25

Command Description Options

M

SP

Edit Circuit Submenu Commands

N

P

T

Name—Circuit name (Circuit ID)—12 characters maximum Priority— 1) low

Type—Circuit type. 1) perm

Mode—Circuit Mode 1) 64K

Source Port—Displays the Node “Map” and prompts for the SRC Port shelf, slot. Use this option to designate the starting point of the circuit. Once the Shelf and slot position of the Source Port has been entered, you are prompted with 4 choices.

2) norm

3) high

4) crit

2) swit

3) prim

4) d-bk

5) bkup

2) 56K For Subrate DIU only:

3) 38.4K

4) 19.2K

5) 9.6K

6) 4.8K

7) 2.4K

1) net1

2) net2

3) net3

4) net4

Verilink QPRI 2921 3-37

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

Command Description Options

DP

SM

DM

U

A

SE

Destination Port—Displays the Node “Map” and prompts for the DEST Port shelf, slot. Use this option to designate the ending point of the circuit. Once the Shelf and slot position of the So urce Port has been entered, you are prompted with 4 choices.

SRC Port Chn—Source Timeslot. Designate which T1 timeslots you wish to use in this circuit.

Note: In ISDN, timeslot 24 is normally reserved for use in D -cha n nel cal l set-up. For this reason, avoid building circuits which use timeslot 24.

For ISDN, a call-reference option is provided to designate the call profile for backup.

DST Port Chn—Destination Timeslot Designate which T1 timeslots you wish to use at the Destination Port.

Note: In ISDN, timeslot 24 is normally reserved for use in D -cha n nel cal l set-up. For this reason, avoid building circuits which use timeslot 24.

For ISDN, a call-reference option is provided to designate the call profile for backup.

Bus—Select a ba ckplane bus for in te r m odu l e co mm un ication. The A Bus is always used for ISDN.

Primary circ—Prima ry Circuit Name 12 characters

src err mask—Backup when SRC port set: 1) ais

1) net1

2) net2

3) net3

4) net4 1—24 or press

ENTER to exit

1—24 or press ENTER to exit

1) A

2) B

3) C

4) Auto

maximum

2) yel

3) los

4) lof

5) uas/ses

C

DE

O

G

X

dst call ref—Dial-out profile dst err mask—Backup when DST port set: 1) ais

dbkp timeout—Backup circuit timeout Day (max 5

err clr mask—Switch back when clear 1) ais

S

Setup—This option MUST be selected to set the new configurations. If this option is not selected, the card reverts to the previous configuration.

Exit—exits this menu and displays the Circuit Manager Menu, Figure 3-25, Table 3-21.

2) yel

3) los

4) lof

5) uas/ses

days) Hour (max 23 hrs) Min (max 59 min)

2) yel

3) los

4) lof

5) uas/ses

3-38 Verilink QPRI 2921

Configuring the QPRI 2921 V ia the NCM 2000 Craft Interf ace

Manufacturing Info

To display the firmware versions and CIM types, choose I from the

Main Menu

exit this screen, press

Figure 3-31 Manufacturing Information

A [127.255.255.0] [1,2] QPRI > i

A [127.255.255.0] [1,2] QPRI > iA [127.255.255.0] [1,2] QPRI > i MANUFACTURING INFORMATION

MANUFACTURING INFORMATION

MANUFACTURING INFORMATIONMANUFACTURING INFORMATION Main Card CIM

Main Card CIM

Main Card CIM Main Card CIM Revision RM) E RC)

Revision RM) E RC)

Revision RM) E RC)Revision RM) E RC) Date DM) 11/6/97 DC) 11/5/97

Date DM) 11/6/97 DC) 11/5/97

Date DM) 11/6/97 DC) 11/5/97Date DM) 11/6/97 DC) 11/5/97 Serial number SM) 00649488 SC) 00648368

Serial number SM) 00649488 SC) 00648368

Serial number SM) 00649488 SC) 00648368Serial number SM) 00649488 SC) 00648368 Manuf. Part No. MM) 319101776002 MC) 311101387001

Manuf. Part No. MM) 319101776002 MC) 311101387001

Manuf. Part No. MM) 319101776002 MC) 311101387001Manuf. Part No. MM) 319101776002 MC) 311101387001 Cage Code CM) CC)

Cage Code CM) CC)

Cage Code CM) CC)Cage Code CM) CC) Type TM) DCSU TC) CIM29003

Type TM) DCSU TC) CIM29003

Type TM) DCSU TC) CIM29003Type TM) DCSU TC) CIM29003 Press enter to continue

Press enter to continue

Press enter to continuePress enter to continue

Manufacturing Information

. The

NTER

E

.

screen displays. To

NOTE:

The Manufacturi ng Information win dow displays infor mation about the QPRI module. For problems with your module, you can provide Customer Service with information that displays in this menu.

System Log Off

To log off, type X repeatedly to retur n t o the

YOUR PASSWORD?

to the

Figure 3-32 System Log Off

A [127.255.255.0] [1,2] QPRI > i

A [127.255.255.0] [1,2] QPRI > iA [127.255.255.0] [1,2] QPRI > i LOGGED OFF

LOGGED OFF

LOGGED OFFLOGGED OFF YOUR PASSWORD?

YOUR PASSWORD?

YOUR PASSWORD?YOUR PASSWORD?

Re-enter the Craft interface by typing the password.

YOUR PASSWORD?

YOUR PASSWORD?YOUR PASSWORD?

prompt.

Main Menu

, and then

Verilink QPRI 2921 3-39

Configuring the QPRI 2921 Via the NCM 2000 Craft Inte r f ace

3-40 Verilink QPRI 2921

Chapter

4

Interpreting Alarms

Troubleshooting

Controller card(s) poll the various modules for alarms. If alarm reporting is enable d for the node and for the module (s), the node controller card retrieves and sends the alarm to Access Manager 2000, Node Manager 2000, or an SNMP agent. Various al arms can also be set up via the NCM 2000 module to trigger the dial backup or backup T1 as part of the Advanced Automatic Protection Switching feature.

An alarm list is provided under th e alarms displays of the various options of AM2000, NM2000, SNMP, or ASCII.

Alarms can also be automatically sent to a specified printer by setting up the printer address in the various management utilities menus.

The alarm buffer displays the following information abo ut alarms (This information may vary depending on the controller module and management method used):

•

Whenever the system powers up and any module does a selftest

•

Power is lost from one of the redundant power supplies

•

A default or user-designated threshold is exceeded

•

A Yellow Alarm is received from the network (DS1)

•

An unframed all-ones or alarm indi cation signal (AIS) is reveived from the network

•

There is a loss of signal (LOS) or loss of frame (LOF)

•

A CSU or Data Port loopback is present

•

A module fails

•

A module is removed from the shelf

Figure 4-1 Alarm Buffer

[1,1] QPRI > o

[1,1] QPRI > o[1,1] QPRI > o QPRI 2921 [1,1] AIS Major Alarm port 1 3-09-98 18:38:35

QPRI 2921 [1,1] AIS Major Alarm port 1 3-09-98 18:38:35

QPRI 2921 [1,1] AIS Major Alarm port 1 3-09-98 18:38:35QPRI 2921 [1,1] AIS Major Alarm port 1 3-09-98 18:38:35 QPRI 2921 [1,1] AIS Threshold Cleared port 1 3-09-98 18:37:17

QPRI 2921 [1,1] AIS Threshold Cleared port 1 3-09-98 18:37:17

QPRI 2921 [1,1] AIS Threshold Cleared port 1 3-09-98 18:37:17QPRI 2921 [1,1] AIS Threshold Cleared port 1 3-09-98 18:37:17 Press enter to continue

Press enter to continue

Press enter to continuePress enter to continue

Module Type

Shelf/Slot Location

Alarm Description

Alarm Classification

Verilink QPRI 2921 4-1

Port

Alarm Date and Time

Troubleshooting

Status Code

Alarm Description

Classifications

The status code column displays a decimal code when using an ASCII terminal. (Varies depending on SNMP or ASCII terminal used.)

The alarm description colu mn l ists the text which is:

•

printed on the display

•

sent to the alarm printer

•

saved to the alarm buffer/database

Verilink classifies alarms into the following severities:

•

Critical

•

Major

•

Minor

•

Warning

•

Info

•

Cleared

Problem Types

These classifications are further categorized into the following problem types:

•

LOS

•

LOF

•

Error

•

Call Setup

4-2 Verilink QPRI 2921

What To Do About Alarms

Some alarms clear after the user-configured timeout has expired. Other alarms require co rrective action.

•

If an alarm has been cleared, no other action is required.

•

If there is a loopback present, unless you are intentionally testing, remove the loopback. (Only if the loopback is from your end. If the loop was initiated by your network service provider, check with their test facility before taking down the loop.)

•

For an LOF, you may have a telco or module problem. To test, do an RLB. If there is no LOF indicated by the test, the problem is with the telco.

•

For an LOS, check your router cables, power, and ports.

•

For a power-up self-test failure, reseat the module a few times to see if it will power up and pass the self test. If it does not pass after repeated self tests, replace the module.

Troubleshooting

Alarm Records

Every alarm record that displays is “active” in the database until you do something about it. Do the following with the alarm records:

•

Deactivating alarm records is a database management function. As long as an alarm is active, you can view it onscreen, using the one of the management options on the ASCII interface, AM2000, or Node Manager 2000. When you deactivate an alarm, it’s still in the database, but not viewable on screen. Deactivated alarms can be archived, printed, or deleted.

•

Archiving an alarm record stores it to a disk file you specify.

•

Printing an alarm record p rints a copy of all active and deactivated alarms.

•

Deleting an alarm record re moves it from the database. To delete an alarm, first d eactivate it.

Verilink QPRI 2921 4-3

Troubleshooting

Alarm List

Table 4-1 Alarms

Fault conditions can result in critical, major, or minor alarms. In addition, a fault condition can also result in a Carrier Failure Alarm (CFA).

Alarm Classification/ Alarm Type

Critical Alarms

Carrier Failure Alarm (CFA)

Major Alarms

Alarm Type Description

Loss of Signal (LOS)

Description

A critical alarm indicates the node or node components have failed. Only the loss-of-clock (LOC) error condition triggers a critical alarm. This error causes the system clock to fail and prevents data from being transmitted.

Loss-of-clock causes the System LED to flash red. It causes a major alarm and activates the relay contacts on the rear connector panel of the CIM.

A carrier failure alarm (CFA) is activated whe n certain major alarm error conditions occur, causing the port to disrupt traffic along the line. When the CFA is activated, the line is not useable—preset by the user—for 2 to 60 seconds. All traffic is re m oved from the line. The alarm re m ains active until the port is reconfigured.

A major alarm fault condition seriously affects performance. It prevents data from being reliably transmitted across the circuit. When a major alarm is declared, the module sends a message to the ASCII interface and Node Manager, lights the appropriate LED indicator, and trips the alarm relay. The following error conditions must persist for at least one second for a major alarm to be declared.

This condition occurs when the network signal is absent, and exceeds a predefined loss-of-signal threshold. An LOS alarm on a network line is declared when more than 175 consecutive zeros are detected on input to the receiving equipment. An LOS after o ne continuous seco nd causes a major alarm and activates the relay contacts on the rear connector panel of the CIM.

This alarm activates the CFA if the LOS is active from 2 to 45 seconds (as defined by the user).

Alarm Indication Signal (AIS)

Loss of Frame (LOF) (T1 Only)

4-4 Verilink QPRI 2921

Using an unframed ALL-ONEs bit pattern, an AIS alarm indicates that an alarm condition exists upstream in a circuit leading to the downstream equipment. This is also called an ALL-ONEs Keep-Alive or Red Alarm Signal. An AIS defect is declared when there are 3 or fewer zeros in 512 bit times and an LOF defect. It is cleared when there are 3 or more zeros in two frames or the LOF defect no longer exist s .

This alarm activates the CFA if the AIS is active from 2 to 45 seconds (as defined by the user).

This alarm is declared when a 3-second interval of continuous Out-Of-Frame (OOF) or Loss-Of-Signal (LOS) state is detected. An LOF alarm is clear ed when at least 10 seconds of continuous non-LOS or non-LOF condition exists.

This alarm activates the CFA if the LOF is active from 2 to 45 seconds (as defined by the user).

Troubleshooting

Alarm Classification/ Alarm Type

Loss of Frame Alignment (E1 Only)

Frame Alignment Signal Error Rate (FASER) (E1 Only)

Loss of TS16 Multiframe Alignment (LOMA) (E1 Only)

Minor Alarms

Description

This condition occurs when three consecutive in-error frame alignment signals (words) are received, or when Bit 2 in a frame containing the nonframe alignment signal (N FAS wor d ) is received in error three consecu t ive times.

The condition clears when the following even ts are satisfied:

• The frame alignment signa l is detec t ed in fra me N.

• The non-frame alignment signal 1 is detected in frame N+1.

• The frame alignment signa l is detec ted in fra me N+ 2. Loss-of-frame alignment (LOFA) after one continuous second causes a major

alarm and activates the relay contacts on the rear connector panel of the CIM. This alarm activates the CFA if the LOFA is active from 2 to 45 seconds (as

defined by the user). This alarm indicates that the FAS error rate exceeds a user-selectable

threshold of 10

-3

or 10-6 for at least four seconds. This user-selectable alarm can be designated as a major or minor alarm and activates the relay contacts on the rear connector panel of the CIM.

This alarm activates the CFA if the FASER is active from 12 to 60 seconds (as defined by the user).

This condition occurs when the module c anno t find the mul tiframe align ment signal (MAS) pattern on TS16 when enabled for CAS signaling.

This alarm activates the CFA if the LOMA is active from 2 to 45 seconds (as defined by the user).

Minor alarm fault c ond itio ns do not affec t traf fi c alo ng the network line . They generate a minor alarm.

Alarm Type Description

Power Supply

In redundant power supply configurations, t

the redundant power supplies has fail ed or has been removed from the shelf.

Missing Remote

Alarm Indication (RAI)

RAI. This alarm indicates that the remote end is in a state of alarm. A Remote Alarm or Remote Alarm Indication is the alarm a receiving channel bank or multiplexer sends to the other end of the circuit when it detects a Loss Of Signal or Loss Of Frame. There is a 2- to 3-second integration period upon detection of LOS or LOF before a Yellow Alarm is sent to the far-end equipment. This condition is also referred to as a Yellow Alarm.

Bipolar Violation (BPV) Threshold

Severely Errored Second (SES)

A violation of the T1 bipolar AMI transmission pattern requi ri ng successive Ones (pulses) to be transmitted as pulses of opposite polarities. A BPV alar m indicates transmission errors. However, B8ZS patterns contain intentional BPVs that are not counted as errors.

15 min. Threshold/ SES 24 hr. Thr eshold—An SES alarm is declared when 320 or more ESF error events occur within one seco nd, o r when an OOF (Out- O fFrame Second) occurs. An SES is a one-second period containing greater than 30% errored blocks (more than 1 errored bit) or at least one Severely Disturbed Period (SDP).

Bit Error Rate (BER) Threshold

The Bit Error Rate is the ratio of the number of bit errors received to the total number of bits transmitted in a given interval. The BER threshold indicates the level above which a CSU alarm is gen era ted an d repo rted .

his alarm indic ates that one of

Verilink QPRI 2921 4-5

Troubleshooting

Interpreting Front Panel LEDs

The LED indicators on the front panel of the QPRI 2921 module display errors caused by network line or data terminal equip ment problems. The errors are reflected in the alarm status and the performance/status menus in the ASCII terminal interface. Node Manager al so has an alarm display.

There are five LEDs on the front panel:

•

Two network port LEDs

•

Two data port LEDs

•

One system LED

Figure 4-2 QPRI Front Panel Showing Alarm Indicator LEDs

QPRI 2921

✳

1

PORT

✳

2

LOCAL

✳✳✳

3 PORT

SYS

4

PRI

MANAGEMENT

EXT

System LED

Network LEDs

Port LEDs

Network LEDs display minor, major, and catastrophic alarm conditions detected on the network lines.

Table 4-2 N etw or k LED Indicator s

State Color Alarm Class Action/Possible Error Condition

Solid Green All okay None Solid Amber Diagnostic

mode with no errors

Flashing Amber and

Yellow Alarm Check the diagnostic performance status or alarm status

Red

Solid Red Major Check the performance st atus or alarm status display. Loss

Off None None Port is not enabled.

None. Port is active and in loopback.

displays. The Yellow Alarm indicates that the unit is

receiving an RAI Signal, which indicates that the far end is

not receiving a sig nal from the near end.

of Signal (LOS) from far end transmits all-ones.

4-6 Verilink QPRI 2921

Troubleshooting

System LED

The System LED displays node controller assignments and node communication conditions.

Table 4-3 System LED Indicators

State Color Alarm Class Possible Error Condition

Solid Green None Module is okay and another module is the shelf controller. Solid Red Critical Syst em fa ilu re . Y ou may need to rese at the ca rd in the shelf. Off None None Module is not on; no power. Flashing Green None The module is acting as the controller (that is, it is the shelf

master controlling t he ACP bu s usage in the shelf).

Verilink QPRI 2921 4-7

Troubleshooting

4-8 Verilink QPRI 2921

Index

Numerics

1/8

test pattern 3-22

2N1 5-1

test pattern 3-22

2N20-1

test pattern 3-22 3 in 24 3-22 55 Octet

test pattern 3-22

A

add circuits 3-33 AIS 3-25, 3-26, 3-28, 3-30 AIS/SEF Se co nds 3-26 alarm buffers

displaying 4-1 Alarm Indication Signal 3-25, 3-30 alarm status 3-28 alarm threshold status

menu 3-29 alarms

reporting 3-30 All 0s

test pattern 3-22 All 1s

test pattern 3-22 analog voice capacity 1- 2 application

bypass functionality 1-2

insert funct ionality 1-2 auto restore

primary 3-11

secondary 3-11

tertiary 3-12

B

BER 3-31 BES 3-25 Bipolar Violation 3-30 bipolar violations

counters 3-24 Bit Error Rate 3-31 BPV 3-24, 3-28, 3-30 Bursty Seconds 3-25

C

card alarm

reporting 3-28 card slot number

primary 3-12

secondary 3-12 cify 3-34 circuit build configuration

menu 2-14, 2-15, 3-33 , 3-34, 3-36 circuits 3-32

add 3-33

delete 3-33 edit 3-37 editing 3-33

listing 3-33 clear card configuration 3-5 components

hardware 1-3 configuration 3-6

menu 2-8, 3-6 configuration menu 3-10 configuring

thresholds 3-28 Controlled Slip Seconds 3-25 counter

bipolar violations 3-24

Cyclic Redundancy Check 3- 2 4

Extended Superframe Format 3-24

Frame Bit Error 3-24 counters

resetting 3-27 CRC 3-24 cross-point switch 1-2 crosspoint switch 1-2

D

default values

password 3-1 Degraded Minutes 3-26 delete circuits 3-33 diagnostics 3-20

menu 3-20, 3-21 Digital transmission facilities 1-2 displaying

alarm buffers 4-1 DM 3-26

E

E1/T1 LED indicators 4-6 edit circuits 3-33, 3-37 Error Free Seconds 3-26 Errored Second s 3- 25 , 3- 3 0 Errored Seconds Type A 3-26 ES 3-25, 3-28, 3-30 ESF 3-24 Extended Superframe Format

counters 3-24

F

FE 3-24, 3-26 Frame Bit Error 3-26

counters 3-24 front panel LEDs 4 - 6

I

information

manufacturing 3-39

Verilink QPRI 2921

Index-1

L

LEDs

front panel 4-6 Line Loopback 3-21 list circuits 3-33 LLB 3-21 LLB BOP 3-22 Local Loopback 3-21 LOF 3-25, 3-28, 3-30 loopbacks

Line Loopback 3-21

LLB BOP 3-22

Local Loopback 3-21

Payload Loopback 3-21

PLB BOP 3-22 LOS 3-25, 3-28, 3-30 Loss of Frame Counts 3-26 Loss of Signal 3-30 Loss-of-Frame 3-30 Loss-of-Frame Seconds 3-25

M

manufacturing info 3-39 menus

alarm threshold status 3-29

circuit build configuration 2-14, 2-15, 3-33, 3-34,

3-36 configuration 3-10 configuring T1 2-8, 3-6 diagnostics 3-20, 3-21 performance/status 3-23

N

Network Management System 3-28 NMS 3-28 None

test pattern 3-22

O

OOF 3-25 Out-of-Fra m e Seconds 3-25

P

password 3-1

default 3-1

PASSWORD? 3-1 Payload Loopback 3-21 performance and status 3-23 performance/status menu 3-23 PLB 3-21 PLB BOP 3-22 primary

auto restore 3-11 card slot number 3-12 synchronization 3-11, 3-13

R

RAI 3-28, 3-30 registers

resetting 3-26 Remote Alarm Indication 3-30 reporting

alarms 3-30

card alarms 3-28 reset card 3-5 resetting

counters 3-27

registers 3-26

test counters 3-22 RLB 3-21

S

secondary

auto restore 3-11

card slot number 3-12

synchroniz at i o n 3- 11 SEF 3-25, 3-26 SES 3-25, 3-28, 3-31 Severely Errored Fra m in g Sec ond s 3-25 Severely Errored Se co n d 3-31 shelf and slot parameters 3-4 shelf-timed 3-12 status

alarms 3-28 status and performance 3-23 switch over once 3-5 switch over permanent 3-5 synchronization

primary 3-11, 3-13

secondary 3-11 system LED 4-7 system log off

logging off

system 3-39

T

T1 CIMs 1-4 T1 configuration menu 2-8, 3-6 tertiary

auto restore 3-12 test pattern

2N20-1 3-22 test patterns 3-22

1/8 3-22

2N1 5-1 3-22

3 in 24 3-22

55 Octet 3-22

All 0s 3-22

All 1s 3-22

None 3-22

QRSS 3-22

Q

QRSS

test pattern 3-22

query firmware 3-5

Index-2

Verilink QPRI 2921

September 1999 P/N 880-503143-001-A1

VERILINK CORPORATION 127 JETPLEX CIRCLE, MADISON, ALABAMA 35758 TEL: (800) 837-4546

Verilink QPRI 2921 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

QPRI 2921 Dual-Port ISDN Primary Rate Interface

Applications

Features

T1 Digital Transmission Facilities

Advanced Automatic Protection Switching

Crosspoint Switch

Drop, Insert, and Bypass Mode

Alarm Management

Advanced Programmable Architecture

Node Management

Diagnostics

System Components

Connector Interface Modules

Specifications

Technical and Regulatory Compliance

Quick Set-Up

Getting Started

Terminal Parameters

Logging On

Bus Compatibility

Network Port Configuration

FDL Options

Timing Options

ISDN PRI Port Configuration

PRI Call Profile

Setting Alarm (Backup Trigger) Para mete rs

Building Circuits

Activate the Primary Circuit

ISDN Access

ISDN and Routine Management Tasks

Configuring the QPRI 2921 Via the NCM 2000 Craft Interface

Logging On

NCM Main Menu

Shelf and Slot Parameters

NCM/QPRI 2921 Main Menu Commands

Administration Menu

Configuration Menu

T1 Port Configuration Menu

ISDN PRI Configuration Menu

Diagnostics Menu

Performance / Status Menu

Performance / Status Menu (24hr T1 Performance Data Summary)

Net Port Alarm Threshold Status Menu

Counter Menu

Net Port Alarm Menu

Net Port Alarm Threshold Configuration Menu

Net Port Alarm Theshold Status Menu

Circuit Manager Menu

Add Circuit Submenu

Edit Circuit Submenu

Manufacturing Info

System Log Off

Interpreting Alarms

Troubleshooting

Status Code

Alarm Description

Classifications

Problem Types

What To Do About Alarms

Alarm Records

Alarm List

Interpreting Front Panel LEDs

Network LEDs

System LED

Index
