Verilink FrameStart FSD User Manual

DDS CSU/DSU and T1 CSU/DSU and FrameStart™ FSE

Reference Manual

October 2002 34-00291.F

Copyright Notice Copyright © 2000 Verilink Cor poration. All rights reserved.

This document does not create any express or implied warranty about Verilink or about its products or services. Verilink’s sole warranty is contained in its product warranty. The end-user documentation is shipped with Verilink’s products and constitutes the sole specifications referred to in the pro duc t war ran ty. Verilink has ma de re aso nab le effo rts to ver ify th at th e info rm atio n co ntained herein is accurate, but Verilink assumes no responsibility for its use or for any infringement of patents or other rights of third parties that may result. The customer is solely responsible for verifying the suitability of Verilink’s products for its use. Specifications are subject to change without notice.

Manual reorder # 34 -00291.F Revision F, October 2002

Trademarks Verilink is a registered trademark Verilink Corporation. FrameStart is a trademark of Verilink

Corporation. Any named products herein are trademarks of their respective companies.

FCC Requirements This equipment (DDS CSU/DSU and T1 CSU/DSU) has been tested and found to comply with

the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential are a is like ly to cau se harm ful in terfer ence i n which c ase the user is requir ed to corr ect the interference at his own expense. This device must also accept any interference received, including interference that may cause undesired operation.

CAUTION: For use only with a certified Class 2 power supply. See Power Source in

Specifications on page -9.

CAUTION: Changes or modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

This equipment complies with Part 68 of the FCC Rules. On the rear or bottom of the unit is a label that contains the FCC registration number and other information. If requested, provide this information to the telephone company.

1 All direct connections to the network lines must be made using standard plugs and jacks

(compliant with Part 68). The tables below present a list of applicable registration jack USOCs, facility interface codes (FICs), and service order codes (SOCs). These are required to order service from the telco.

T1 CSU/DSU

Port ID REN/SOC FIC USOC

1.544 Mbps SF

1.544 Mbps SF, B8ZS

1.544 Mbps ANSI ESF

1.544 Mbps ANSI ESF, B8ZS

DDS CSU/DSU

Port ID REN/SOC FIC USOC

56 kbps 64 kbps

6.0F 04DU5-56

6.0N 04DU9-BN

04DU5-64

04DU9-DN 04DU9-1KN 04DU9-1SN

RJ- 48S j ack

RJ-48C jack

2 If the unit appears to be malfunctioning, it should be disconnected from the network lines

until the source of trouble is determined to be your equipment or the telephone line. If your equipment needs repair, it should not be reconnected until it is repaired.

ii DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

3 The unit has been designed to prevent harm to the network. If the telephone company finds

that the equipment is exceeding tolerable parameters, it can temporarily disconnect service. In this case, the telephone company will give you advance notice, if possible.

4 No cust omer is author ized to repair this eq uipmen t, rega rdles s of wa rranty statu s.

5 If the telephone company alters its equipment in a manner that will affect the use of this

device, it must give you warning so that you have the opportunity for uninterrupted service. You will be advised of your right to file a complaint with the FCC.

6 In the event of equipment malfunction, all repairs should be performed by our company or an

authorized agent. It is the responsibility of users requiring service to report the need for service to our company or to one of our authorized agents.

7 The affidavit at the end manual must be completed by the installer.

Canadian Emissions Requirements

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques (de la class A) prescrites dans le Règlement sur le brouillage radioélectrique édic té par le ministère des Communications du Canada.

Notice: The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Industry Canada does not guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facili ties of th e lo cal tele com mun icat ion s co mp any. The eq uip me nt mu st also be inst alle d us ing an acceptable method of conn ection. In some cases, the company’s inside wiring associated with a single line individual service may be extended by means of a certified connector assembly (telephone extension cord). The customer should be aware that compliance with the above conditions m ay not prevent degr adation of servi ce in some situations.

Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particula rly importan t in rural areas.

CAUTION: Users should not attempt to make such connections themselves, but should contact

the appropriate electric inspection authority, or electrician, as appropriate.

Warranty Verilink's produ ct w arranty is included at the back of this document. Customer Service Verilink offers the following services:

• Technical Assistance Center for free 24 ×7 telephone support during installation, mainte-

nance, and troubleshooting at (800) 285- 2755 (toll free) or 256-327-2255 (local) and support@verilink.com

• Maintenan ce contracts and l easing plans (800) VERILINK (837-4546)

• Web site at www.verilink.com

Returning P roducts Instructions for returning a product are included in Verilink’s product warranty at the back of

this document.

Safety P recauti ons When handling this equipment, follow these basic safety precautions to reduce the risk of elec-

tric shock and injury:

iii

• Follow all wa rnings and instructions marked on the product and in the manual.

• Unplug the hardware from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a slightly damp cloth for cleaning.

• Do not place this product on an unstable cart, stand, or table. It may fall, causing serious damage to the product.

• Slots in the unit are provided for ventilation to protect it from overheating. These openings must not be bl ocked or covered. Never place this product near a radiator or heat register.

• This product should be operated only from the type of power source indicated on the marking label and manual. If you are unsure of the type of power supply you are using, consult your dealer or local power co m p a ny.

• Do not allow anything to rest on the power cord. Do not locate this product where the cord interferes with the free movement of people.

• Do not overlo ad w all outlets an d extension cords, as this can res ult in fire or electric shock.

• Never push objects of any kind into the unit. They may touch dangerous voltage points or short out parts that could result in fire or electric shock. Never spill liquid of any kind on this equipment.

• Unplug the equipment from the wall outlet and refer servicing to qualified service personnel under the following conditi ons:

•When the power sup ply cord or plug is damaged or frayed.

•If li qu id ha s be e n sp illed into th e p ro du c t.

•If the product has been exposed to rain or water.

•If the product has been dropped or if the housing has been damaged.

iv DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Trademarks ........................................................................ ii

FCC Requirements ............................................................. ii

Canadi an Em is sions Requir ements .. ........... ... ........... ... .. ... iii

Warranty ........................................................................... iii

Custome r S er vi ce .... ........... ... ... ........... .. ... ........... ... ... ........ iii

Returning Products ........................................................... iii

Safety Pre ca u tions ...... ... ........... .. ... ........... ... ... ........... ... .. ... iii

About Th i s Ma nu a l .......... ........................ .1

What is a Ref er en c e M a nu a l? ........................ .. ... ........... ... ......1

Where to go for Information ...................................................1

Conventions ............................................................................2

Chapter 1 , General ................ ................ ...3

Introdu ctio n .. ...... ..... ...... .. ...... ..... ...... ... ..... ...... ..... ... ...... ..... ......3

FrameStart Instal l M o de .......... ........... .. ........... ... ... ........... ... ...4

FrameStart Monito r M o de (o pt io n al) ......... ... ........... ... .. ......... 4

What is LM I So u rc in g an d w hy is it important? ......... ...5

What is a DLCI? ........ ... ........... ... .. ........... ... ... ........... ... ...5

What messages does LMI provide? ................................5

What is PVC Discovery in FrameStar t? .............. .. ... ...... 6

What is PVC D el ay Te s tin g ? ........... ... ... ........... ... .. .........6

What is a WA N rec e iv e le v el ? ............... .. ............ .. ... ......6

What is LM I Mo ni to ring? .. ........... ... ... ........... ... ... ...........6

What is LM I A ut o Sou r ci ng ? ........... ... ... ........... ... ...........6

What is SOS Mode? .......................................................6

What is New Circuit Install? ............... ... .. ............ .. ... ...... 7

How does FrameStart work in a typical application? .....7

INSTAL L : LM I M o de is O N ... ... ........... ... ... ...........7

MONITOR: LMI Mode is MON (Optional Feature) 7

OFF: LMI Mode is OFF .........................................7

FrameStart Benefits ...... .. ... ........... ... ... ........... .. ... ........... ... ...... 7

Ordering Numbers ..................................................................8

Feature Summary ....................................................................8

Genera l Spe ci fi ca tions .. ........... .. ... ........... ... ... ........... ... .. .........9

Management Interf ac e ....... ... ... ........... ... .. ............ .. ... ...... 9

Alarms .. ... ..... ...... ..... ... ...... ..... ...... .. ...... ..... ...... ... ..... ...... ...9

Power Sou r ce ..... ... .. ........... ... ... ........... ... .. ............ .. ... ...... 9

Mechani cal ...... ........... ........ ........... ........... ............ ........ ...9

Enviro nmen tal . ...... ..... ... ..... ...... ... ..... ...... ..... ... ...... ..... ......9

Industry Listings .............................................................9

Specifications Chart ..............................................................10

Chapter 2 , Inst a llation ............ ........ ........11

Introduction ...........................................................................11

Safety Summary ....................................................................11

Unpack in g and Ins pe ct io n ... ........... .. ... ........... ... ... ........... .. ..11

Suppl ie d Ma te rials .... ... ... ........... ... ........... ... .. ........... ... ... .......12

Rear Panels ...........................................................................12

Data Connections ..................................................................13

V.35 Data Port ..............................................................13

DDS CSU/DSU Network Port .....................................13

T1 CSU/DSU and FrameStart FSE Network Conn ection 13

Receive Levels ......................................................14

RJ-48C Network Connector ..................... ........... .14

BNC Net w ork Co nn e ct o rs ............... ... ... ........... .. ..14

T1 Network Disconnection ..................................14

Power ... ............. ................. ................. ........................ ..14

Chapter 3, General Operation and

Conventions .......................................17

Introduction ...........................................................................17

DDS CSU/ D S U Fron t Pa n el ............ ... .. ........... ... ... ....... 1 7

LCD Acc es s . ........... ... ... ........... .. ... ........... ... ... ........... .. ..18

Password Protection ......................................................18

To Enter an Established Password ........................18

Interfa c e C onv en t io ns .............. .. ... ........... ... ... ........... .. ..18

Menu Title ............................................................19

Menu Element .......................................................19

Inform a ti on El ement ........ .. ... ........... ... ........... ... .. ..19

Curso r El ements .... ........... .. ... ........... ... ........... ... .. ..19

Hardware Reset .....................................................................19

Utilities .................................................................................19

Softw ar e Ver s io n ............ ... ... ........... ... .. ........... ... ..........20

Restore Factory Settings ...............................................20

Set Password .................................................................20

Chapter 4 , Ope r a ti o n ............ ..................2 1

Introduction ...........................................................................21

Menu Start-up Display ..................................................21

N (Netwo rk St at u s) . ... ... ........... ... .. ........... ... ..........21

D (DTE St at us ) ............. ... ........... .. ... ........... ... ... .... 2 1

F (Frame Relay Status) .........................................22

Main Me nu ... ... ........... ... .. ........... ... ... ........... ... .. ........... ..22

Alarms ...........................................................................25

Reset T ime r ........ ... .. ........... ... ... ........... ... .. ........... ..26

Reset A la rm s? . ... ... ........... .. ... ........... ... ... ........... .. ..27

Table of Contents v

Perform ance ....... .............. ............. ........... .............. .......2 7

Network Performance ...........................................27

Frame Relay Performance ....................................27

Mainte nance . ......... ..... ........ ......... ........ ..... ......... ........ .... 28

Loop .....................................................................28

BERT ....................................................................31

Test Patterns .... ........... ... ... ........... ... .. ............ .. ... ....32

Inject Error ............................................................32

Error Count ...........................................................32

Clear Erro r C ou n t .. ... ........... .. ... ........... ... ... ........... .32

DDS DTE Configuration ..............................................32

Rate . ................ ................. .............. ................ .......32

DTE Clock ............................................................32

TXCC Clock .........................................................33

DTE Data ..............................................................33

CTS ............ ................ ................. ......................... .33

CTS Delay .............................................................33

DCD ..... ........... .............. .............. .............. ........... .33

DSR . ..... ...... ..... ... ...... ..... ...... .. ...... ..... ...... ... ..... ...... .3 3

DTR ......................................................................33

T1 Netwo rk Con fi gu ra ti o n . ........... ... ... ........... ... ... .........33

Framing ........... ......... ........... ........... ........... ........ ....3 3

Line Code ..............................................................34

Clock Sou rc e .............. ... ... ........... ... .. ............ .. ... ....34

Sensitivity .............................................................34

LBO ......................................................................34

Yellow Alarm .......................................................34

Densit y ............ .............. .............. .............. ........... .34

FDL . ........... ........... ........... ........ ........... ........... .......3 4

Chann el s Ass ig n ed ........... ... .. ........... ... ... ........... ... .34

Start Channel .........................................................35

#Channe l ............... ................ .............. ................. .35

T1 DTE Conf ig u ra ti on ................ .. ... ........... ... ... ........... .35

Rate . ................ ................. .............. ................ .......35

DTE Clock ............................................................35

TXCC Clock .........................................................35

DTE Dat a ..... ........... ... ... ........... ... .. ........... ... ... .......35

CTS ... ........... ........... ........... ......... ........... ........... .... 35

DCD ..... ..... ......... ........ ........ ...... ........ ........ ......... ....3 5

DSR ......................................................................36

DTR ...................................................................... 36

E1 Network Configuration ...........................................36

Frami ng ... ..... ...... ..... ... ...... ..... ...... .. ...... ..... ...... ... ....3 6

CRC4 Mode ...... ............. ............ ............. .. ............36

E-Bit Mode ...........................................................36

Clock Source .........................................................36

RAI Alarm ............................................................36

Timeslot 01 to Timeslot 31 ...................................36

E1 DTE Configuration ..................................................37

DTE Clo ck ...... ........... ... ... ........... .. ... ........... ... ... ....37

TXCC C lo ck ......... .. ... ........... ... ... ........... .. ... ..........3 7

DTE Dat a ..... ........... ... ... ........... ... .. ........... ... ... .......37

CTS ... ........... ........... ........... ......... ........... ........... .... 37

DCD ..... ..... ......... ........ ........ ...... ........ ........ ......... ....3 7

DSR ......................................................................37

DTR ...................................................................... 37

Frame Relay Configuration ..........................................37

LMI Mode .............................................................37

Unit ID ..................................................................38

N391 .....................................................................38

N392 .....................................................................38

N393 .....................................................................38

T391 .. ........ ......... ........ ...... ........ ........ ........ ...... .......3 8

PVC Mo de ...... ... ... ........... .. ... ........... ... ... ........... .. ..3 8

SOS TX (Monitor Mode) ......................................38

SOS RX (Monitor Mode) .....................................39

, Affidavit for the Connection of Customer

Premises Equipment to 1.544 Mbps

and/or Subrate Digital Services .......39

vi DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

HAPTER

What is a Reference Manual?

This is a reference manual. It provides information about unit installation, configuration, testing and troubleshooting on a function-by-function basis. It is not a user’s guide containing step-by-step procedures. This manual contains specific information about a command, menu field, port, etc. Unless otherwise noted, the information in this manual applies only to the Verilink DDS CSU/ DSU, and T1 CSU/DSU, and FrameStart FSE (all of which are referred to, collective ly, as “th e unit.”)

Where to go for Information

The chapters and appendices in this manual are arranged for quick reference. It is not necessary to read previous chapters to understand the subsequent chapters.

• General - This chapter introduces the unit, lists the features, and provides

specifications.

BOUT

HIS

ANUAL

• Installation - This chapter describes unit port and power conne ctions.

• General Operation and Conventions - This chapter describes the fron t panel

buttons, LEDs, and conventi ons for the LCD interface.

• Operation - This cha pter describes the menus for the unit’s operation.

About This M anual 1

Conventions

The following table lists the conventions used throughout this manual.

Convention Description

Notices call attention to important features or instructions.

Cautions al ert you to personal safety risk, system damage, or data loss .

Warnings alert you to the risk of severe personal injury.

Italics

underline

Italic s de n ote new terms or emphasis. Default settings are underlined.

2 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Introduction

C HAPTER

HAPTER

ENERAL

FrameStart is an intuitive frame-relay configuration, analysis, and diagnostic feature set that incorporates the capabilities of expensive test analysis equipment into the functionality of a high-quality line of CSU/DSU products.

The Verilink FrameStart engine operates at wire-speed to deliver the most economical frame relay diagnostic information in the industry today for the price. The price-to-performance ratio of this product line is unequaled when compared to any of the major brand providers.

The DDS CSU/DSU Network unit is a synchronous Digital Data Service CSU / DSU with FrameStart capability targeted at frame-relay applications. The DDS CSU/DSU also provides many useful diagnostic features and operates in standard DDS I and DDS II modes. This product operates in a frame-relay environment or on private (leased) line applications in a point-topoint environment.

The T1 Network unit is a T1 CSU/DSU with FrameStart capability and operates at fractional T1 rates up to a full T1 carrier service. This product also operates in a frame-relay environment, leased line service, or LDM (limited distance m odem) p rivate-lin e applica tions.

The FrameStart FSE E1 Network unit is an E1 CSU/DSU with FrameStart capability and opera tes at fr actional E1 rates up to a full E1 carrier ser vice. This product also operates in a frame-relay environment, leased line service, or LDM (limited distance modem) private-line applications.

Verilink has two options available in the FrameStart family of products-FrameStart Install a nd Fra meStart M onitor--fo r both t he DDS a nd T1 CSU DSU units. The FrameStart FSE unit has an option for the FrameStart Monitor only.

General 3

FrameStart Install Mode

FrameStart Install has four major benefits that offer significant value when comparing to other products:

• LMI Sourcing - A frame relay poll ing function that determines the LMI type

and qualifies the traf fic to the frame relay switch. All DLCI information for virtual circuits is c ollected and displayed on the LCD.

• End-to-End Integrity - PVC discovery modes determine critical parameters

from the remote units to verify the integ rity of the network upon initial installation.

• PVC Delay Testing - test capabilities for each virtual circuit regarding delay

characteristics. The delay measurement can be used to detect a problem circuit upon instal lation by providing a snapshot of the network delay.

• WAN Receive Level - isolate WAN problems very quickly upon installation

by monitoring network quality dur ing installation.

FrameStart Install is a network-intrusive mode that does not require any data equipment such as a router of FRAD to operate. If a router is connected, operation is halted to perform the installation diagnostics.

FrameStart Monitor Mode (optional)

FrameStart Monitor adds more capabilities to monitor real-time network conditions in a non-intrusive state when connected in real-world applications:

• LMI Monitoring - durin g normal operation to update DLCI tables and

indicate local and remote alar m conditions on the frame relay network.

• LMI Auto Sourcing - automatically initiates LMI sourcing if the router fails

and indicates an alarm condit ion.

• SOS Mode - f rame broadcasts from failed units i n the field to quickly isolate

failed circuit s within the network and indicates an alarm condition.

• New Circuit Insta ll - detects when new DLCIs are added in the network and

allows for network information to be collected from the remote unit during installation.

• Real-ti me PVC delay testing is not supported in Monitor Mode.

NOTICE: FrameStart Monitor is available from the factory or as a field

upgrade using an EPROM replacement.

The DDS and T1 CSU/DSU units perform all of these functions without expensiv e software packages or a sep arate G UI interfa ce. The integral LCD shows this information.

We believe that the best solutions are still the simple ones, that actually provide the data you need to quickly configure, install, test, and validate the integrity of your data network. The Verilink FrameStart feature set was created with this in mind, and simplifies the installation and troubleshooting of frame-relay circuits and ongoing maintenance of the overall data network.

4 FrameStart DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

What is LMI Sourcing and why is it important?

In the mo st basic i mplement ation, F rame Rela y is a s imple int erface t hat offers bandwidth on demand with low latency and high throughput. The UNI is the user-to-network interface and the LMI (local management interface) enables both the user and the network to gather information about the UNI. The LMI allows the user and frame relay network to signal each other about several activities pertaining to the permanent virtual circuits (DLCIs) on the link and their physical link status. The LMI provides the following services:

• A polling functi on to test whether the user or network machine is connected

to the interface

• A set of operations tha t inform the user of the addition or deletion of virtual

circuits at the interf ace

• A report on t he sta tus of a ll vir tual cir cuits o n the int erf ace that st ates whether

or not a virtual circuit is active

• A report on the availability of a new virtual circuit.

LMI information is published in ANSI T1.617, Annex D; ITU-T Q.933, Annex A; and LMI Revision 1.0.

User A User B

UNIT UNIT

LMILMI

Frame Relay

Network

UNIUNI

LMI

What is a DLCI?

A DLCI is a data link connection identifier, and is a unique number for each permanent virtual circuit (PVC) in the frame relay network. The following DLCI values have been designated for the frame relay network:

0 LMI Channel for ANSI and ITU

1–15 Reserved

16 – 991 For user virtual circuits

992 – 1007 Layer 2 management of bearer service

1008–1022 Reserved

1023 In-channel layer management for LMI Revision 1.0

What messages does LMI provide?

LMI provides for two message types that include a status (S) message and a status enquiry (SE) message. The SE message is invoked based on a timer with an upper and lower limit, and the receiving machine responds with a status message. Depending on the timers and counters used for LMI, the status ele ment can b e either a statu s request t hat acts as a link v erificat ion request, or a full status (FS) request that also includes information on all PVCs on the circuit.

General 5

What is PVC Discovery in FrameStart?

Verilink has included support for PVC discovery at the remote end of each end-to-end permanent virtual circuit. For the DDS and T1 CSU/DSU units, this mode is initiated by the user upon installation and configuration of each logical port in the network. Verilink takes advantage of RFC 1490 rules for encapsulating data within the Frame Relay frame, and incorporates PVC extensions for establishing a virtual loopback on each PVC to determine the remote link characteristics. This information includes remote DLCI numbers, unit identification, link status, and optional fields such as committed information rates (CIR) and circuit delay. The user enables this operation for all active DLCIs on the circuit by setting LMI Mode to On.

What is PVC Delay Testing?

FrameStart allows the user to test an active PVC for delay characteristics. A DLCI can be selected and a delay calculation is performed end-to-end to determin e the perfo rmance ch aracte ristics of a particular circuit . This operation is enabled by the user for any active DLCI on the circuit.

What is a WAN receive le vel?

On any transmission network, the signal level indicates the strength of the phys ical tr ansp ort sys tem. The bet ter the signa l leve l, the be tter the performance of the transmission system. Expensive analyzers are used today to measure the signal level performance of the transmission network before data networks are installed. The DDS and T1 CSU/DSU units provide a simple diagnostic to display the receive level from the network unit. This removes the need to have additional test equipment on site when installing data networking components.

What is LMI Monitoring?

During normal operation conditions, FrameStart Monitor continually monitors LMI traffic on the network to update DLCI tables in the unit. FrameStart automatically detects new circuits or indicates an Alarm condition for inactive circuits.

What is LMI Auto Sourcing?

During normal operating conditions, FrameStart automatically detects a failure with the data equipment (router) and takes control of the circuit to keep the network alive. This allows for quick fault isolation of the problem. When the data equipment returns to service, FrameStart reverts to monitor mode.

What is SOS Mode?

During LMI Auto Sourcing, the unit can be configured to send a SOS frame to the host site and indicate an alarm condition on a particular virtual circuit. This makes remote troubleshooting and fault isolation quick and easy.

6 FrameStart DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

What is New Circuit Install?

In normal FrameStart Install mode, data-flow from the Router is stopped. This feature allows FrameStart to detect new circuits and perform PVC discovery on new installations without interrupting service to the rest of the network.

How does FrameStart work in a typical application?

FrameStart includes three different operating modes for ease of operation.

INSTALL: LMI Mode is ON

In Install mode, the unit performs LMI sourcing based on the assumption that data equipment is not available. The DDS and T1 CSU/DSU units source LMI to the frame rel ay net work, and record the status in formati on for dis play on the LCD. This includes the type of LMI, the number of DLCIs, and the status of each PVC. User initiated menus exist in the LCD to activate PVC discovery and PVC delay measurements on active DLCIs. After installation is complete, set LMI Mode to OFF for normal operation.

MONITOR: LMI Mode is MON (Optional Feature)

In Monitor mode, the unit is in a non-intrusive state between the network and the data equipment monitoring the activity on the frame relay circuit. If the unit stops receiving LMI status responses from the network, the unit will automatically SOURCE LMI to verify the network connection is still active. After verification, the unit will revert to a non-intrusive monitoring mode. Real-time PVC delay testing is not available in this mode. Also, SOS mode can be enab led or d isabled to g enerate alarms t o a host uni t. New ci rcuits ca n be added to a network and automatically detected based on the LMI information. A specific DLCI can be selected to perform PVC discovery in order to verify the end-to-end integrity of the new circuit without disrupting normal operation of the overall network.

OFF: LMI Mode is OFF

In the OFF mode, FrameStart is not required based on the unit operating in a private-line application or after the installation of frame relay circuits is complete. Receive Levels are still displayed for the TDM network unit.

FrameStart Benefits

FrameStart equipment presents a distinct advantage over routers with integral CSU/DSU transmission devices. FrameStart Install and Monitor provide test capabilities that traditional CSU/DSUs cannot provide. Also, FrameStart is a more economical solution than routers with integral CSU/DSUs that sell for around $1,000 or more, and provide minimal diagnostic capabilities. Verilink DDS and T1 CSU/DSU units bring your application back to the true functions of “Intelligent” CSUs/DSUs to provide a clear point of demarcation between

General 7

the WAN and router. Fault isolation is greatly simplified with FrameStart during installation and normal service. FrameStart Install reduces the cost of installation and allows service providers to quickly install new frame relay circuits. FrameStart Monitor makes fault isolation quick and easy, and reduces the overall support needs and costs of managing a complex data-critical network.

Ordering Numbers

DDS CSU/DSU Install and Monitor . . . . . . . . . . . . . .F-FSD-001--112

T1 CSU/DSU Install and Monitor . . . . . . . . . . . . . . . .F-FST-001--112

FrameStart FSE Install and Monitor (Mexico). . . . . . .F-FSE-001--112

FrameStart FSE Install and Monitor (International) . . . F -F SE - 001- -111

T1 CSU/DSU Monitor Upgrade . . . . . . . . . . . . . . . . . .9-305-020--3

DDS CSU/DSU Monitor Upgrade . . . . . . . . . . . . . . . .9-305-020--4

Feature Summary

Data Interface V.35 Winchester/ M 34 connector Data Type Synchronous User Interface LCD display, 8 LEDs, and 3 push button switches for

navigation

LCD 2×16 non-backlit liquid crystal display Power

Units for South America: Compact 110-VAC to 9-VAC wall-

mount transformer

FrameStart FSE for Europe: IEC 100-240 VAC to 9 VCD Stand-

alone transformer

Diagnostics Test modes including standard loops, BERT, and test

pattern generator

LCD Security Password to prevent unauthorized access to the option

menus FrameStart Embedde d frame relay tes t set Alarms Programmable alarm thresholds, 15-minute and 24-hour

statistics Operating Modes Public frame relay services with the DDS CSU/DSU;

standard private line networks and public frame relay

services with the T1 CSU/DSU and FrameStart FSE

8 FrameStart DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

General Specifications

Management Interface

Front Panel: Three buttons, eight LEDs, and one LCD

Alarms

Activation: Programmable thresholds Reporting: LCD user interface

Power Source

External (units-Mexico):

External (FrameStart FSE-International):

Input: 115 VAC Output: 9 VAC, 750 mA

Input: Auto-ranging 100–240 VAC Output: 9 VDC, 750 mA

Mechanical

Environmental

Industry Listings

Mounting: Desktop Dimensions: 1.50" (3.81 cm.) high, 8.25" (20.96 cm.) wide,

6.00" (15.24 cm.) deep

Weight: 1 pound (0.45 kg)

Operating Temperature:32 to 122°F (0 to 50°C) Storage Temperature: −4 to 185°F (−20 to 85°C) Humidity: 95% maximum (non - condensing) Protection: Lightning protection compatible with GR1089

FCC Compliance: Part 15 Subpart B, Class A, Part 68 Industry Canada: CS-03

US Safety: UL1950, 3 Canadian Safety: CSA C22.2, No. 950 - 95

Edition

General 9

Specifications Chart

Specification DDS CSU/DSU T1 CSU/DSU FrameStart FSE

Network Interface

Line Rate 56 and 72 kbps 1.544 Mbps (±50 ppm) 2.048 Mbps (±50 ppm) Line Framing DDS I and DDS II CC64K D4 or ESF Unframed, FAS, CAS,

CCS, CRC4

Line Code Bipolar AMI AMI or B8ZS HDB3 Input Signal 0 to −43 dB 0 to −36 dB ALBO 0 to −43 dB Connection RJ-48S, 135 Ω (±5%) RJ-48C, 100 Ω (±5%) RJ-48C, 120 Ω (±5%)

Dual BNC 75Ω ±5%

Timing Source Network Internal, ne twork Internal, net work Output Signal n ot applicable 3.0 V (±10%) base–peak

into 100 Ω with protect ion

Line Build Out not applicable 0, −7.5, −15, −22.5 dB

attenuation

Jitter Control not applica ble per TR 62411 and T1.403 per TBR12 Ones Density not applicable B8ZS, Ν×56 bit stuffing,

alternate fill; complies with TR 62411

Equipment Int er f ace

Line Rate 56 kbps or 64 kbps

synchronous

Connection -------------> female, 34-pi n Winchester-type connector (all units) <-----------

Diagnostics

Performance LOSS, OOSS, and BPVS

monitoring

Network Loops Line loop, data loop, and

V.54 loop

Fractional Loop not applica ble Responds to in-band V.54

DTE Port Loops local loop local loop local loop BERT -----------> 511, spaces, marks, and 2047 patterns (all units) <-----------

Standards Compat ibility

TR 62310, August 1993 TR 54016, September 1989

56 kbps to 1.536 Mbps (±50 ppm)

Monitoring per TR 54016 and T1.403

Line loopback or payload loopback

loop code

TR 62411, December 1990 T1.403, 1995

3.0 V (±10%) base-peak into 120 Ω or 75 Ω with protection

not applicable

64 kbps to 2.048 Mbps (±50 ppm)

LOSS, OOFS, ES, AISS, RAS, SES, DS, UAS, BPVS, CSS, and CRCES monitoring

Line loopback or payloa d loopback

Responds to in-band V.54 loop code

10 FrameStart DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Introduction

C HAPTER

HAPTER

NSTALLATION

This chapter contains information and instructions required to prepare the units for use. Included are initial inspection procedures, mounting instructions, configuration guidelines, connection and powering information.

Safety Summary

This manual contains information and warnings that must be followed by the user to ensure safe operation and to retain the equipment in a safe condition.

NOTICE: The WARNING sign denotes a potential hazard to the operator. It calls

attention to a procedure or practice that, if not correctly performed or adhered to, could result in injury or loss of life. Do not proceed beyond a WARNING sign until the indicated conditions are fully understood and met.

Unp ack ing and Inspection

This unit is carefully packaged to prevent damage in shipment. Upon receipt, inspect the shipping container for damage. If the shipping container or cushioning material is damaged, notify the carrier immediately and make a notation on the delivery receipt that the container was damaged (if possible, obtain the signature and name of the person making delivery). Retain the packaging material until the contents of the shipment have been checked for completeness and the unit has been checked both mechanically and electrically.

If the contents of the shipment are incomplete or, if there is mechanical damage or defect, notify Verilink. If the shipping container is also damaged, or the cushioning material shows signs of stress, notify the carrier of the damage as well as Verilink. Keep the shipping materials for carrier’s

Installation 11

inspection. Verilink will arrange for repair or replacement without waiting for claim set tlement.

Supp lied Materials

The FrameStart family of products are shipped from the factory with the following standard equipment:

• AC power supply for the DDS and T1 CSU/DSU,

DC power supply for the FrameStart F SE (see Figure 2.3 on page 15)

• Reference manual

• 8-pin to 8-pin network cable (p.n. 9-1544-009)

• RJ48 to BNC adapter (for FrameStart FSE)

Rear Panels

The rear panel of the DDS and T1 CSU/DSU are identical as shown in Figure

2.1.

Figure 2.1

The rear panel of the FrameStart FSE is shown in Figure 2.2.

Figure 2.2

DDS and T1 CSU/DSU Rear Panel

FrameStart FSE Rear Panel

12 FrameStart DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Data Connections

V.35 Data Port

Table 2.1 shows the pinout for the V.35 data port. The form factor is a female 34-pin Winchester-type connector.

Table 2.1

Pin Signal

A Frame Ground B Signal Ground C Request to Send DClear to Send E Data Set Ready F Data Carrier Detect H Data Te rm Ready P Transmit Data (A) R Receive Dat a (A ) S Transmit Data (B) T Receive D at a ( B) U Terminal Timing (A) V Receive Clock (A)

W Terminal Timing (B)

X Receive Clock (B) Y Transmit Clock (A)

AA Transmit Clock (B)

Customer Equipment Connector Pinout

DDS CSU/DSU Network Port

Table 2.2 shows the pinout for the network connector. The connector interface is RJ-48S.

Table 2.2

Pin Signal

1 R (output to network) 2 T (output to network)

3 –6 not used

7 T1 (input from network) 8 R1 (input from network)

Network Connector Pinout

T1 CSU/DSU and FrameStart FSE Network Connection

The network side of the unit is referred to as the network interface. This interface contains an ALBO (automatic line build out) that allows the unit to be located a substantial distance away from the telco network interface with a

Installation 13

receive signal level to −30 decibels for T1 systems and −43 decibels for E1 systems.

Receive Levels

Receive levels from the network for the Verilink FSx units are listed in Table

2.3.

Table 2.3

FSx Unit Maximum Minimum

DDS CSU/

T1 CSU/DSU 0 -40 dB

FrameStart

Receiv e Levels

0 -30 dB

DSU

0 -43 dB

FSE

RJ-48C Network Connector

The network connector interface is an RJ- 48C with the pinout shown in Table

2.4 below.

Table 2.4

Pin NET

1 R1 (ring, receive from

2 T1 (tip, receive from network) 4 R (ring, transmit to network) 5 T (tip, tra nsmit to network ) 3, 6–8not used

Network Connector Pinout

network)

BNC Network Connectors

These BNC (Bayonet-Neill-Concelman) network connectors are 75Ω Transmit towards the network and 75Ω Rece ive from t he networ k.

T1 Network Disconnection

In accordance with FCC Rules, Part 68.218 (b), the telephone company must be notified before disconnecting the T1 CSU/DSU.

Power

Connect the appropriate power supply (Figure 2.3) to the unit, then connect the wall plug to the appropriate outlet. This applies power to the unit.

14 FrameStart DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

CAUTION

“INDOOR USE ONLY”

Figure 2.3

Power Supplies for the units-Mexico (lef t) and FrameStart FSE-Int er national (right)

Installation 15

16 FrameStart DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Introduction

C HAPTER

HAPTER

ENERAL

This chapter describes the front panel buttons, LEDs, and conventions for the LCD interface .

PERATION AND

ONVENTIONS

DDS CSU/DSU Front Panel

Table 3.1 references the front panel controls and indicators and provides a brief description.

Table 3.1

Contr ol or Indicator Function

liquid crystal display

EXIT The EXIT butt on allows exiting a menu option which th en

SCROLL The SCROLL button allows reviewing the available options

SELECT The SELECT bu tton allows choosing the op tion or value for

RTS (green) This indicator is on when RTS is active. DTR (g re en ) This ind icator is on w he n DTR is acti ve . DCD (green) Th is indicator is on when DCD is active. TxD (green) This indicator is on when the unit transmits data. RxD (g reen) Thi s indica tor is on when the un it recei ves data .

TEST (yello w) This ind icato r is on w hen the u nit is in a test m ode. ALARM (red ) This ind icato r turns on wh en the u nit is in an acti ve alar m

POWER (green) This indicator turns on when power is applied to the unit.

Front Panel Controls and Indicators

This 2-line, 16-charact er display provi des access to unit alarms, configuration, diagnostics, and utili ties.

places th e un it in t he n ext hi gh er level i n the m enu h ie rarch y. If in the main menu, pressing EXIT logs off the unit.

or selections for a given level in the menu hierarchy.

a given field.

condition.

General Operation and Con ventions 17

LCD Access

NOTICE: The units have the same buttons and indicators at the locations

shown in .

When power is applied, the DDS and T1 CSU/DSU display the Idle screen as shown in Figure 3.1. Press any one of the front panel buttons to leave the Idle screen and ac cess the in terface .

NOTICE: For an explanation of the screen shown in Figure 3.1, see

Password Protection

The unit is factory shipped without a programmed password. If a password has been esta blished , the pas sword screen (Fi gure 3.2) appe ars. Ent er a correct password to advance to the Main Menu screen. An eight - character password must be entered.

ACCESS

FRAME START DDS N:LS D:LD F:LI

Figure 3.2

To Enter an Established Password

page 4-21.

any bu tton

Accessing Passw o rd Scre en

FRAME START DDS N:LS D:LD F:LI

ENTER PASSWORD PW: ********

Figure 3.1

Idle Screen

Press the SCROLL button until the desired character appears. Remember that the password is case-sensitive. Then, press the SELECT button. Continue selecting the appropriate characters until the last character is entered. Then, press the EXIT button. A correctly entered password advances the unit to the Main Menu screen. An incorrectly entered password returns an Idle screen. If unsuccessful, reenter the password.

Interface Conventions

Figure 3.3 shows a front panel display consisting of a menu title, menu element, in formatio n elemen t, and a cursor.

Menu Title

Menu Element Cursor

Figure 3.3

Example Showing Scre en E lements

ALARMS BPVS: ■00/010

Information Element

18 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Menu Title

The menu title shows the general classification for a group of accessible functions.

Menu Element

The menu element is a menu or submenu accessible by pressing the SELECT button. When selecting a menu element, it becomes the menu title and the next lower level in the hierarchy becomes the menu element.

Information Element

The inform ation el ement is a user-s electable field allo wing chan ges to t he setting. To access the information elements, press the SELECT button until the desired option is displayed. From this point, EXIT goes back to the menu title; SCROLL goes to the next menu element. Scroll through the available menu elements by pressing the SCROLL button. Press the SELECT button to change information elements.

Cursor Elements

The curs or appears on the lef t side of the “s elected” i nformat ion eleme nt (see Figure 3.3).

Move the cursor to the right by choosing SELECT. Use the SCROLL button to change field elements (i.e.: 0, 1, 2…). Press EXIT to escape without changing the information field.

NOTICE: Every time the EXIT button is pressed, the cursor returns to the next

Hardware Reset

To execute a hardware reset, press the SELECT and EXIT buttons while applying power to the unit and hold them for five seconds. A hardware reset restores the unit to factory default settings just like a Restore Factory Settings. The following screen (Figure 3.4) appears as the unit comes out of hardware reset.

FRAME START DDS ***UNIT RESET***

Figure 3.4

Utilities

highest level in the menu hierarchy.

DDS CSU/DSU Hardware

The Utilities screen allows performing various functions such as viewing revision numbers, restoring factory settings, and establishing a password.

General Operation and Con ventions 19

Software Version

This selection shows the software version loaded in the unit.

Restore Factory Settings

This field clears all memory, including the password, and uses defaults from the ROM.

Set Password

This field establishes the unit password used for entering the front panel interface. A passw ord mus t be eight character s. Scroll incremen ts the character s (0 –9, A –Z, a –z) . The cu rsor blin ks over th e chara cter or di git to be selected or modified. Select accepts the current value and moves the cursor right. When the eighth character is select ed, a verification scree n appears. Reenter the password.

ENABLE

MAIN MENU UTILITIES

DISABLE

MAIN MENU UTILITIES

SELECT

SET PASSWORD? PW: ********

DISABLE PASSWORD? PW: ********

Figure 3.5

Enable and Disable Password Screen

20 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Introduction

This chapter describes the menus for the units’ operation.

Menu Start-up Display

The unit starts up with the menu display shown in Figure 4.1.

C HAPTER

HAPTER

PERATION

FRAME START DDS N:OK D:OK F:OK

Figure 4.1

N (Network Status)

OK No alarms. LS Loss of signal. LI LMI M ode is Off. LM The unit is in LMI Monitor mode. NA Not availabl e. LD Loss of DTR. RA Receiving yellow alarm, T1 CSU/DSU only. LF Loss of frame (T1 CSU/DSU only).

D (DTE Status)

OK No problems. LS Loss of Signal, when RTS and DTR are not present. When RTS and

Start-Up Screen

DTR are lost, D intermediately toggles LD and LS for a few seconds then settles on NA. When RTS and DTR are restored, NA takes up to a minute to clear.

NA In FrameS tart mode , the D TE is no t availab le.

Operation 21

Main Menu

LD Loss of DTR.

F (Frame Relay Status)

- - Deciding LMI type. LQ Qualifying LMI type. SL Sourcing LMI. SP Sourcing LI and PVC delay testing. LM LMI Monitor: non-intrusive but individual PVC testing for new

circuits. This indicator is only with FrameStart Monitor. SM Sourcing LMI in Monitor mode for fault condition (NO PVC). SOS (optional) This indicator is only with FrameStart Monitor.

The front panel interface is designed on a hierarchical menu system as shown in Figure 4.2 for the DDS CSU/DSU, Figure 4.3 for the T1 CSU/DSU, and Figure 4.3 for the FrameStart FSE. The units allow choosing from submenu options beginning at the main menu.

22 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

MAIN MENU ALARMS NETWORK: OK

LOSS, 5 OOSS, 5 BPVS, 0

FR NET‡: OK, LOCAL, SOS, DLCI RESET TIMER: 000 – 900, 30

RESET ALARMS?

PERFORMANCE NET PERFORMANCE RCV LVL: 0.0 dB, 7.3 dB, 13.6 dB, 19.7 dB, 26.0 dB,

FR PERFORMANCE LMI TYPE: ORIG, ANSI D, ITU A

MAINTENANCE LOOP: NONE?, ENABLE LLB?, ENABLE DLB?, ENABLE LCL

DTE CONFIG RATE: 56 Kbps, 64 Kbps

FRAME RLY CONFIG LMI MODE: OFF, ON, MON

ENABLE V54?, ENABLE RMT V54?, ENABLE RMT DLB

BERT: NONE,

EN. NET BERT? TP: MARKS, SPACES, 511, 2047 EN. DTE BERT? INJECT ERROR?

DTE CLOCK: NOR, INV TXCC CLO CK: EN, DIS DTE DATA: NOR, INV CTS: NORMAL, FORCED ON CT S DELAY: 000–255 DCD: NORMAL, FORCED ON DSR: NORMAL, FORCED ON DTR: NORMAL, IGNORED

UNIT ID: 000 – 999 N391: 001–255, 006 N392: 01–10, 03 N393: 01–10, 04 T391: 05–30, 10 PVC MODE: DIS, EN

SOS TX: EN, DIS SOS RX : E N , DIS

UTILITIES VERSION: z.zz

RESTORE FACTORY? SET PA SSWORD*:

Default values are shown in bold.

The three-digit current and threshold values (###/###) range from 000 to 900. An asterisk (*) to the left of these values indicates that the current value has exceeded the threshold value. Pressing SELECT on a dis played al ar m allows editing the threshold parameters for that alarm.

This does not apply to frame relay alarms.

LOSS OOSS BPVS CLEAR HISTORY?

PCKT SRC: UNI, NI DLCI TOTAL: 000–999

32.3 dB, 38.4 dB, 44.4 dB, 50.5 dB

The values are shown as (sss/ttttt). The 15minute current value (sss) ranges from 000 to 900. The 24-hour total values (ttttt) range from 00000 to 65535.

†

DLCI Screen

CLEAR DLCI? TEST DLCI xxx?

ERR CNT = 00000–65356 CLEAR ERR CNT?

† (Install mode only) If the DLCI TOTAL is greater than

000, a screen with the following format appears when SELECT i s pressed:

uuuu - the local DLCI number vvvv - ACT., IDLE, NEW, DEL., or REMOTE DLCI (if

discovered) www - remote unit ID xxxx - average delay (if discovered) yyyy - committed information rate

‡

uuuu -> vvvv:www

xxxxms yyyykbps

‡ Monitor option only

This field establishes the unit password used for entering the front panel interface. A password must be eight characters. SCROLL increments the characters (0–9, A– Z, a–z). The cursor blinks over the character or digit to be

‡ ‡

selected or modified. SELECT accepts the current value and moves the cursor right. When the eighth character is selected, a verification screen appears. Reenter the password.

The network configuration is automatically set when the DTE Rate is set. For example, 56 Kbps DTE Rate sets the network to DDS I and 64 Kbps DTE Rate sets the network to DDS II CC 64K.

‡

Figure 4.2

DDS CSU/DSU Menutree

Operation 23

MAIN MENU ALARMS NETWORK: OK

‡

: OK, LOCAL SOS, DLCI

FR NET RESET TIMER: 000 – 900, 30

RESET ALARMS?

PERFORMANCE NET PERFORMANCE RCV LVL: 2 – 7.5 dB, 7.5 – 15 dB, 15 – 22.5 dB, <22.5 dB

FR PERFORMANCE LMI TYPE: ORIG, ANSI D, ITU A

MAINTENANCE LOOP: NONE?, ENABLE LLB?, ENABLE PLB?, ENABLE V54?,

BERT: NONE,

NETWORK CONFIG FRAMING: D4, ESF

DTE CONFIG RATE: 56 Kbps, 64 kbps

FRAME RLY CONFIG LMI MODE: OFF, ON, MON

UTILITIES VE RSION: z.zz

Figure 4.3

T1 CSU/DSU Menutree

The three-digit current and

LOSS

threshold values (###/###)

OOFS

range from 000 to 900. An

AISS

asterisk (*) to the left of these

RAS

values indicates that the

current valu e has exceeded

SES

the threshold value. Pressing

BES

SELECT on a di splaye d alarm

UAS

allows editing the threshold

BPVS

parameters for that alarm.

CSS CRCES

LOSS OOFS AISS RAS ES SES BES UAS BPVS CSS CRCES CLEAR HISTORY?

PCKT SRC: UNI, NI DLCI TOTAL: 000–999 CLEAR DLCI? DLCI Screen

ENABLE RMT V54?, ENABLE RMT LLB?, ENABLE RMT PLB?

EN. NET BERT? TP: MARKS, SPACES, 511, 2047 EN. IDLE BERT? INJECT ERROR? EN. DTE BERT? ERR CNT = 00000 –65356 EN. CH01 – CH24 BERT? CLEAR ERR C NT?

LINE CODE: AMI, B8ZS CLOCK SRC: NET, INT SENSITIVITY: DIS, EN LBO: 0 dB, −7.5 dB, −15 dB, −22.5 dB YEL ALARM: EN, DIS DENSITY: EN, DIS FDL: NONE, ANSI, AT&T CHANNELS: CONT, ALT START CHAN: 01 – 24 #CHANNELS: 00 – 24

DTE CLOCK: NOR, INV TXCC CLOCK: EN, DIS DTE DATA: NOR, INV CTS: NORMAL, FORCED ON DCD: NORMAL, FORCED ON DSR: NORMAL, FORCED ON DTR: NORMAL, IGNORED

UNIT ID: 000 – 999 N391: 001–255, 006 N392: 01– 10, 03 N393: 01– 10, 04 T391: 05– 30, 10 PVC MODE: DIS, EN

SOS TX: EN, DIS SOS RX: EN, DIS

RESTORE FACTORY? SET PASSWORD

‡

§ This doe s not apply to fram e r el ay alar ms.

The values are shown as (sss/ttttt). The

minute

current value (sss) ranges from 000 to

900. The 24- hou r total values (ttttt) range from 00000 to 65535.

15-

†

TEST DLCI xxx

‡ Monitor option only

† (Install mode only) If the DLCI TOTAL is

great er than 000, a s c reen with t he f oll ow ing format appears when SELECT is pressed:

uuuu -> vvvv:www

uuuu - the local DLCI number vvvv - ACT., IDLE, NEW, DEL., or REMOTE DLCI (if discovered) www - remote unit ID xxxx - average delay (i f discovered) yyyy - com mitted infor ma tion rate

Default values are shown in bold.

‡

* This field establish e s the unit passw ord used fo r

entering the front panel interface. A password must be eight characters. SCROLL increments the characters (0–9, A–Z, a –z). The cu rsor blinks over the character or digit to be selected or modi fied. SELECT accepts the curre nt value and moves the cursor right. When the eighth character is selected, a verification screen appears. Reenter the password.

xxxxms yyyy kbps

‡

24 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

MAIN MENU ALARMS NETWORK: OK

‡

: OK, LOCAL SOS, DLCI

FR NET RESET TIMER: 000 – 900, 30

RESET ALARMS?

PERFORMANCE NET PERFORMANCE RCV LVL: 2 – 7.5 dB, 7.5 – 15 dB, 15 – 22.5 dB, <22.5 dB

The va lu e s ar e

shown as (sss/ttttt).

15-minute

The

current value (sss)

ranges from 000 to

900. The 24-hour total values (ttttt)

range from 00000

to 65535.

FR PERFORMANCE LMI TYPE: ORIG, ANSI D, ITU A

MAINTENANCE LOOP: NONE?, ENABLE LLB?, ENABLE PLB?,

BERT: NONE,

NETWORK CONFIG FRAMING: CAS, CCS, FULL 2M

DTE CONFIG DTE CLOCK: NOR, INV

FRAME RLY CONFIG LMI MODE: OFF, ON, MON

UTILITIES VE RSION: z.zz

The three-digit current and

LOSS

threshold values (###/###)

OOFS

range from 000 to 900. An

AISS

asterisk (*) to the left of these

RAS

values indicates that the

current valu e has exceeded

SES

the threshold value. Pressing

SELECT on a di splaye d alarm

UAS

allows editing the threshold

BPVS

parameters for that alarm.

CSS CRCES

LOSS OOFS AISS RAS ES SES DS UAS BPVS CSS CRCES CLEAR HISTORY?

PCKT SRC: UNI, NI DLCI TOTAL: 000–999 CLEAR DLCI? DLCI Screen

ENABLE V54?, ENABLE RMT V54?

EN. NET BERT? TP: MARKS, SPACES, 511, 2047 EN. IDLE BERT? INJECT ERROR? EN. DTE BERT? ERR CNT = 00000 –65356 EN. TS01–TS31 BE RT? CLEAR ERR CNT?

CRC4 MODE: EN, DIS E-BIT MODE: EN, D IS^ CLOCK SRC: NET, INT RAI ALARM: EN, DIS

TIMESLT 01: ACT./IDLE TIMESLT 02: ACT./IDLE

TIMESLT 31: ACT./IDLE

TXCC CLOCK: EN, DIS DTE DATA: NOR, INV CTS: NORMAL, FORCED ON DCD: NORMAL, FORCED ON DSR: NORMAL, FORCED ON DTR: NORMAL, IGNORED

UNIT ID: 000 – 999 N391: 001–255, 006 N392: 01– 10, 03 N393: 01– 10, 04 T391: 05– 30, 10 PVC MODE: DIS, EN

SOS TX: EN, DIS SOS RX: EN, DIS

RESTORE FACTORY? SET PASSWORD

‡

§ This doe s not apply to fram e r el ay alar ms.

† (Install mode only) If the DLCI TOTAL is

great er than 000, a s c reen with t he f ol low in g format appears when SELECT is pressed:

uuuu -> vvvv:www

uuuu - the local DLCI number vvvv - ACT., IDLE, NEW, DEL., or REMOTE DLCI (if discovered) www - remote unit ID xxxx - average delay (i f discovered) yyyy - committed information rate

^ This selection only appears

if CRC4 Mode is s e t to EN.

~ The TIMESLOT select ions do not

appear if Framing is set to FULL 2M. If FRAMING is set to CAS,

TIMESLOT 16 is not displayed.

‡

* This field establish e s the unit passw ord used fo r

xxxxms yyyy kbps

†

‡ Monitor option only

TEST DLCI xxx

Default values are shown in bold.

‡

Alarms

Figure 4.3

FrameStart FSE Menutree

Press SELECT to view the current (within the last 15 minutes) and threshold alarm status for the network and DTE lines. To change the threshold parameters, press the SELECT button on its alarm value. Reset capabilities allow clea ring the alarm va lues.

The three-digit current and threshold values (### /###) range from 000 to 900. An asteris k (*) to the left of these v alues ind icates that the curre nt val ue has

Operation 25

exceeded the threshold value. Pressing SELECT on a displayed alarm allows changing the threshold parameters for that alarm. Table 4.1 provides a summary o f the ala rms.

Table 4.1

E1 Network Alarms

LOSS The Loss of Signal Seconds threshold is exceeded. OOFS The Out Of Frame Seconds threshold is exceeded. AISS The Alarm Indication Seconds threshold is exceeded. RAS The Remote Alarm Seconds threshold is exceeded. ES The Errored Seconds threshold is exceeded. SES T he Se ver ely Err ore d thres hold i s exc eeded . DS The Degraded Seconds threshold is exceeded. UAS The Unavailable Seconds threshold is exceeded. BPVS The Bipolar Violation Errored Seconds threshold is exceeded. CSS The Controlled Slip Seconds threshold is exceeded.

T1 Network Alarms

LOSS The Loss of Signal Seconds threshold is exceeded. OOFS The Out Of Frame Seconds threshold is exceeded. AISS The Alarm Indication Seconds threshold is exceeded. RAS The Remote Alarm Seconds threshold is exceeded. ES The Errored Seconds threshold is exceeded. SES T he Se ver ely Err ore d thres hold i s exc eeded . BES The Bipolar Errored Seconds threshold is exceeded. UAS The Unavailable Seconds threshold is exceeded. BPVS The Bipolar Violation Errored Seconds threshold is exceeded. CSS The Controlled Slip Seconds threshold is exceeded. CRCES The CRC Errored Seconds threshold is exceeded.

Alarms

DDS Network Alarms

LOSS The Loss Of Signal Seconds threshold is exceeded. OOSS The Out Of Service Seconds threshold is exceeded. BPVS The Bipolar Violation Seconds threshold is exceeded.

Frame Relay Network Alarms (Monitor option only)

Local A router or network failure occurred on the local data interface. SOS The unit received a remote SOS alarm. DLCI An inactive DLCI was received in monitor mode.

Note: Go to the PERFORMANCE menu, then FR PERFORMANCE menu to see

alarm conditions.

Reset Timer

This field is the contiguous number of seconds that an alarm parameter must be clear before the alarm is reset. It is speci fic for ea ch alarm parame ter. Applicable values range from 000 through 900. The value 000 means that the alarm never resets. Press SELECT to change this threshold. This command does not apply to frame relay alarms.

26 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Performance

Reset Alarms?

This option clears the frame relay and network alarm counts. The choices are Yes and No.

The network performance menu displays a history of the continuously monitored error parameters. The current 15-minute and 24-hour performance totals are r eviewed and rese t from t he unit.

The Fram e Relay performan ce param eters dis play th e local an d remote ( if available) D LCI information .

Network Performance

Receive Level. This selection shows the received signal strength in decibels.

The DDS CSU/DSU DDS levels are 0.0, 7.3, 13.6, 19.7, 26.0, 32.3, 38.4,

44.4, and 50.5 dB. The T1 DDS/CSU and FrameStart FSE E1 levels are 2—

7.5, 7.5—15, 15—22.5, and <22.5.

15-Minute/24-Hour Performance. The values are shown as (xxx / yyyyy)

for the network alarms. The three-digit 15-minute current value (xxx) ranges from 000 to 900. The 24-hour total values (yyyyy) range from 00000 to

65535. Use the SCROLL key to move through the alarm screens.

Clear History. This selection is used to reset the performance registers.

When resetting the registers, the unit prompts for continuing the reset.

Frame Relay Performance

LMI Type. Repor ts the fram e relay circuit L MI typ e as ORIG , ANSI D ,

or ITU A.

Packet Source. Reports t he frame rel ay interfa ce type as U ser Interfa ce UNI

(User-to- Network In terface ) or NI ( Network Interface ).

DLCI Total. This is the number of known local DLCIs. The count ranges

from 000 to 999. If the DLCI Total is greater than 000, a screen with the following format appears when SELECT is pressed:

Local DLCI

PVC Delay (if discovered) during in stallation

Figure 4.3

Example DLCI Total Screen

0030 -> 0020:100 0020mS ----Kbps

Remote DLCI (can als o read ACT, IDLE, NEW, or DEL)

Remote Unit ID

CIR

Operation 27

Monitor Mo d e . When the unit is in monitor mode (LM) and LMI Mode is

configured for MON, individual selection of PVC discovery and delay is allowed by pressing SELECT while in the DLCI screen. Test DLCI xxx? is displayed. Pressing SELECT performs the test as follows. The unit sets up a mask for this one circuit and sends PVC discovery and PVC delay approximately every second. This minimizes the traffic disruption on the circuit. The screen then ret urns to the previo us perfo rmance screen wh ere the fields are updated when the information is collected. Choosing SELECT again displays End Test? where SELECT stops the test and the unit goes back to normal operation. If the unit is scrolled to another DLCI and another test is enabled, the unit stops the test on the existing DLCI and starts the new DLCI. Pressing SCROLL takes the unit to the previous performance screen.

The SOS message is displayed as shown in Figure 4.4. This allows the user to view the local and remote DLCI and unit ID numbers for fault isolation. As new circuits are added, information is displayed as shown in Figure 4.4.

Maintenance

Figure 4.4

This messag e appears when an SOS is receive d from another uni t.

This message appears when unit is in test.

Example DLCI Total Screen in Test

0037 -> ACT.---

----mS

RCV SOS IN TEST

New Circuit

Monitor St atus

The Maintenance menu allows performing loop tests, BERT functions, and error counts on the circuit. Loops, BERTs, and error counts are activated and cleared fr om the u nit. No o ther test e quipmen t is need ed.

Loop

This menu allows running diagnostic loop tests on the network. Figure 4.5 show s norm al ope rati on.

To Network

RJ-48C

From Netw ork

Network Framer/ Receivers/

From

Port

BERT

Generator/

Detector

From

NET

DriversDeframerInterface

DTE

(Winchester-type

Connector)

Figure 4.5

Normal Oper ation

None. Selecting NONE leaves the unit in normal operation and forwards the

unit to BERT.

Enable LLB (DDS CSU/DSU only). (Line Loopback) - As shown in

Figure 4.7, the received network signal is looped back toward the network.

28 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

The receiv ed data i s passed t hrough to the DTE port. The NET LLB is activated by detection of simplex current reversal.

Figure 4.6

Network Framer/ Receivers/

To Network

RJ-48C

From N etwork

BERT

Generator/

Detector

Enable LLB for DDS CSU/DSU

From

Port

From NET

NET

DriversDeframerInterface

DTE

(Winchester-type

Connector)

Enable LLB (T1 CSU/DSU and FrameStart FSE only). (Line Loopback)

- As shown in Figure 4.7, the received network signal is looped back toward the netwo rk with s ignal rege neratio n only (fra ming an d CRC i ntact). D uring the NET LLB, the DTE port is also looped. In T1 circuits, the NET LLB is activated by receiving in-band or out-of-band loop code on the network receive signal (E1 has no in-band loopcode enable) and by the front panel LCD selection.

To Network

RJ-48C

From N etwork

Network Framer/ Receivers/

From

Port

BERT

Generator/

Detector

From NET

NET

DriversDeframerInterface

DTE

(Winchester-type

Connector)

Figure 4.7

Enable LLB for T1 CSU/DSU and Frame Start FSE

Enable DLB (DDS/CSU/DSU only). As shown in Figure 4.8, the received

network signal is looped back toward the network in the local unit. This loop is invoked by an in-band pattern.

Figure 4.8

To Network

RJ-48C

From Netw ork

Enable DLB

Network Framer/ Receivers/

From

Port

BERT

Generator/

Detector

From

NET

DriversDeframerInterface

DTE

(Winchester-type

Connector)

Operation 29

Enable LCL (DDS CSU/DSU only). As shown in Figure 4.9, the received

network signal is looped back toward the network. During the LCL loop, the DTE is looped on itself.

Figure 4.9

To Network

RJ-48C

From Network

Enable LCL

Network Framer/ Receivers/

From

Port

BERT

Generator/

Detector

From NET

NET

DriversDeframerInterface

DTE

(Winchester-type

Connector)

Enable PLB (T1 CSU/DSU and FrameSt art FSE only). (Payload

Loopback) - As shown in Figure 4.9, the received network signal is looped back toward the network with signal regeneration, framing and CRC regeneration. During the NET PLB, the DTE is looped on itself. In T1 circuits the NET PLB is activated by receiving out-of-band loop code on the network receive signal (E1 has no remote PLB enable) or by selection in the user interface maintenance screen.

To Network

RJ-48C

From Netw ork

Network Framer/ Receivers/

From

Port

BERT

Generator/

Detector

From NET

NET

DriversDeframerInterface

DTE

(Winchester-type

Connector)

Figure 4.10

Enable PLB

Enable V54. As shown in Figure 4.11, the network signal is looped back

toward the network after the rate adaptation FIFOs. In this mode, the DTE is looped back on itself. This loop can be invoked from the unit or the remoteend equipment.

Figure 4.11

To Network

RJ-48C

From Network

Enable V54

Network Framer/ Receivers/

From

Port

BERT

Generator/

Detector

From

NET

DriversDeframerInterface

DTE

(Winchester-type

Connector)

30 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Enable Remote V54. As shown in Figure 4.12, the Enable Remote V54

forces the remote-end unit into a V54 loop. A BERT and a loop can only be run simultaneously if the loop type is remote.

Figure 4.12

Network Framer/ Receivers/

To Network

RJ-48C

From Network

Enable Remote V.54

BERT

Generator/

Detector

From

Port

From

NET

DriversDeframerInterface

DTE

(Winchester-type

Connector)

Enable Remote LLB (Line Loopback) (T1 CSU/DSU only). As shown in

Figure 4.13, the Enable Remote LLB forces the remote-end unit into a line loopback. A BERT and a loop can only be run simultaneously if the loop type is remote.

Figure 4.13

Network Framer/ Receivers/

To Network

RJ-48C

From Netw ork

Enable Remote LLB

BERT

Generator/

Detector

From

Port

From NET

NET

DriversDeframerInterface

DTE

(Winchester-type

Connector)

Enable Remote PLB (Payload Loopback) (T1 CSU/DSU only). As

shown in Figure 4.14, the Enable Remote PLB forces the remote-end unit into a payload loopback. A remote PLB is only possible if the FDL mode is set to AT&T or ANSI. A BERT and a loop can only be run simultaneously if the loop type is remote.

Figure 4.14

Network Framer/ Receivers/

To Network

RJ-48C

From Network

Enable Remote PLB

BERT

Generator/

Detector

From

Port

From

NET

DriversDeframerInterface

DTE

(Winchester-type

Connector)

BERT

This command allows selecting the BERT to run. The selections are as follows.

None. No BERT select ed.

Operation 31

Enable Network BERT. BERTs the full DDS in the DDS and T1 CSU/DSU

bandwidth towards the network.

Enable Idle BERT (T1 CSU/DSU and F rameStart FSE only). BERTs the

idle (unallocated) channels toward the network.

Enable DTE BERT . BERTs the DTE.

Enable Channel 01 to 24 BERT (T1 CSU/DSU only). BERTs t he

selected channel to wards the netwo rk.

Enable Timeslot 01 to Timeslot 31 BERT (FrameS t ar t FSE only).

BERTs the selected channel towards the network.

Test Patterns

This command allows selecting the test pattern. The selections are Marks, Spaces, 511, and 2047.

Inject Error

This command injects a single error when operating in BERT mode.

Error Count

Displays the number of bit errors that have been detected since the test began or since error statis tics were last clea red.

Clear Error Count

This selection is used to reset the BERT error count.

DDS DTE Configuration

This menu establishes the necessary parameters for connection with the DTE for the DDS CSU/DSU. The network configuration is automatically set when the DTE Rate is set. For example, 56 Kbps DTE Rate sets the network to DDS I and 64 Kbps DTE Rate sets the network to DDS II CC 64K.

Rate

The unit can operat e at 56 or 64 kbps.

DTE Clock

The polari ty of the clock is either normal or invert ed.

32 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

TXCC Clock

This is u sed to en abl e or disable generation of the TXCC clock from the unit to the DTE.

DTE Data

In the invert mode, transmit and receive data are inverted at the port interface. This function can be used as a means of guaranteeing ones density when the data is composed of SDLC- type protocols. The default setting is normal

CTS

Setting this field to Forced On allows the forcing of the port control lead output state. Normal allows for normal operation where CTS follows the transition of RTS.

CTS Delay

This field allows setting the delay from when RTS is asserted to when CTS is asserted. T he dela y ranges from 000 to 255 milliseconds in one-millisecond increments. Setting this field to 000 means RTS and CTS are asserted simultaneously.

DCD

Setting this field to Forced On allows the forcing of the port control lead output state. Normal allows for normal operation.

DSR

Setting this field to Forced On allows the forcing of the port control lead output state. Normal allows for normal operation.

DTR

Setting this field to Forced On allows the forcing of the port control lead output state. Ignored allows for normal operation.

T1 Netw ork Configuration

The Network Configuration menu (see Figure 4.3 on page 24) allows establishing parameters for connection with the T1 network.

Framing

Selects the type of framing for the network interface as D4 or ESF.

Operation 33

Line Code

Sets the network interface line coding as AMI or B8ZS.

Clock Source

Sets the timing source to synchronize the unit’s internal timing generators. Slips are controlled to occur on frame boundaries at the network port when timing synchronization is lost. Network recovered clock (most applications use this selection). Internal uses the unit’s internal frequency as the standard for all timing.

timing is derived from the network

Sensitivity

Sets the unit’s receiver sensitivity. When enabled, the unit can respond to signals attenuated to 36 decibels. When disabled, the unit can only respond down to 30 decibels of attenuation.

LBO

Shows the line build out signal attenuation for the network interface as 0, −

7.5, −15, or −22.5 decibels.

Yellow Alarm

Enables or disables the unit’s ability to transmit a yellow alarm.

Density

Enables or disables density enforcement. This does not apply if the line code is set to B8ZS.

FDL

Selects the type of operation for the facilities data link. The choices are NONE, ANSI, and AT&T. This only applies when the Framing is set to ESF.

Channels Assigned

Selects whet her the channel assign ment are made as a CON T (contiguous) group or as ALT (alternate) channels. Alternate channel mode assigns an idle channel following each data channel. For example, data is carried on channels 1, 3, 5, and 7. Channels 2, 4, 6, and 8 are idle (the idle setting is binary code

01111111). The advantage of alternate channel assignment is that T1 ones density requirements are maintained by the idle channels rather than placing any restrictions on the high-speed data but reduces the available bandwidth from 1.536 kbps to 768 kbps.

34 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Start Channel

The starting channel in the 24 - channel DS1 bit stream must be selected in this field. The unit then assigns the following channels automatically according to the number of channels (#Channel) and the mode selected in Channels Assigned. The choices are 01 through 24.

#Channel

Selects number of channels to be assigned to the network ranging from 0 through 24.

T1 DTE Configuration

This menu establishes the necessary parameters for connection with the DTE.

Rate

The unit can operate at any data rate that is a multiple of 56 or 64 kbps. When 64Kbps is selected, the ones density requirements of the T1 network line must be ensured. When 56Kbps is selected, the unit maintains ones density for the selected DS0 channel.

DTE Clock

The polari ty of the clock is either normal or invert ed.

TXCC Clock

This is u sed to en abl e or disable generation of the TXCC clock from the unit to the DTE.

DTE Data

CTS

Setting this field to Forced On allows the forcing of the port control lead output state. Normal allows for normal operation where CTS follows the transition of RTS.

DCD

Setting this field to Forced On allows the forcing of the port control lead output state. Normal allows for normal operation.

Operation 35

DSR

Setting this field to Forced On allows the forcing of the port control lead output state. Normal allows for normal operation.

DTR

Setting this field to Forced On allows the forcing of the port control lead output state. Ignored

E1 Network Configuration

The Network Configuration menu (see Figure 4.3 on page 25) allows establishing parameters for connection with the T1 network.

Framing

Selects the type of framing for the network interface as CAS, CCS, or FULL 2M.

CRC4 Mode

Enables or Disables CRC4 multiframing mode.

allows for normal operation.

E-Bit Mode

Enables or Disables remote E-bit generation when operating in CRC4 multiframing mode.

Clock Source

timing is derived from the network

RAI Alarm

Enables or disables the unit’s ability to transmit a remote alarm.

Timeslot 01 to Timeslot 31

Selects the timeslot as either ACTIVE or IDLE. Timeslots selected as ACTIVE are routed to the DTE port. timeslot 16 can only be selected if the framing node has been set to CCS. In FULL 2M operation, this selection is not available.

36 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

E1 DTE Configuration

This menu establishes the necessary parameters for connection with the DTE.

DTE Clock

The polari ty of the clock is either normal or invert ed.

TXCC Clock

This is u sed to en abl e or disable generation of the TXCC clock from the unit to the DTE.

DTE Data

CTS

Setting this field to Forced On allows the forcing of the port control lead output state. Normal allows for normal operation where CTS follows the transition of RTS.

DCD

Setting this field to Forced On allows the forcing of the port control lead output state. Normal allows for normal operation.

DSR

Setting this field to Forced On allows the forcing of the port control lead output state. Normal allows for normal operation.

DTR

Setting this field to Forced On allows the forcing of the port control lead output state. Ignored

Frame Relay Configuration

The frame relay configuration screen allows performing the configuration and control of the frame relay parameters.

LMI Mode

Sets the operating mode for FrameStart. The choices are as follows. ON discovers the LMI Type and sources LMI to the network. MON (Monitor

allows for normal operation.

Operation 37

option only) monitors the DTE and network frame relay packets and sources LMI when errors are detect ed. OFF activity.

is selected when there is no frame relay

Unit ID

The local unit ID number. This number is entered by the user and ranges from 000 to 999. It is displayed at the remote end by PVC discovery frames.

N391

Sets the number of polling cycles for full status messages. This value ranges from 1 to 255. Consult the network provider for this value. The default setting is 006

N392

Sets the number of allowable errors occurring during N393- monitored events. This value ranges from 1 to 10. Consult the network provider for this value. The default setting is 03.

N393

Sets the number of events in which N392 is monitored. This value ranges from 1 to 10. Consult the network provider for this value. The default setting is 04

T391

This sets the link integrity verification polling timer. This value ranges from 5 to 30 seconds. Consult the network provider for this value. The default setting is 010.

PVC Mode

This option enables or disables PVC discovery and delay evaluation by the local unit. For this to be effective, the local and remote units must have this mode enab led. Wh en enabl ed, the l ocal unit queries e ach of t he remote units based on its local DLCI table. Once a remote unit has been identified, the unit performs a PVC delay calculation. The unit must be set to LMI Mode On.

SOS TX (Monitor Mode)

This field enables SOS frames to be sent in SM mode every 5 to 25 milliseconds on all active DLCIs. This occurs after SM has finished and LMI sourcing has started and the unit can communicate with the frame relay switch. The default is Disable

38 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

SOS RX (Monitor Mode)

This field enables SOS frames to be detected at a host site in LM monitor mode. Each DLCI is tested every 1 to 10 seconds in a mask scenario for SOS frames received. It can take five to ten minutes to detect these frames depending on the amount of traffic. The default is Disable.

Operation 39

40 DDS CSU/DSU and T1 CSU/DSU and FrameStart FSE

Affidavit for the Connection of Customer Premises Equipmen t to

1.544 Mbps and/or Subrate Digital Services

For work to be perf ormed in the certified te rritory of

Telco’s Name: ___________________________________________________

State of _______________________________________________________

County of _________________ ______________ _______________ _________

I, ___________________________ (Authorized Representative Name), of ____________________________ (Customer Name), _______________________________________ (Customer Address), _________________________ (Telephone Number), being duly sw orn, state:

I have responsibility for the operation and maintenance of the terminal equipment to be connected to _________________________ 1.544 Mbps and /or ___________________ subrate digital services. The terminal equipment to be connected complies with Part 68 of the Commission’s rules except for the encoded analog content, and billing protection specifications. With respect to encoded analog content and billing protection:

➢ I attest that all operations associated with the establishment, maintenance, and adjustment of the digital CPE with respect to

encoded analog content and encoded billing information conti nuously complies with Part 68 of the FCC’s Rules and Regulations.

➢ The digital CPE does not transmit digital signals containing encoded analog content or billing information which is intended to be

decoded within the telecommunications network.

➢ The encoded analog and billin g protection is factory set and is not under the control of the customer. I attest that the operator(s)/maintainer(s) of the digital CPE responsible for the establishment, maintenance, and adjustment of the

encoded analog content and billing information has (have) been trained to perform these functions by successfully completing one of the following (Check the appropriat e box(es) below):

❏ A. Training course provided by the manufacturer/grantee of the equipment used to enc ode analog signals; or ❏ B. Training course provided by the customer or aut horized representative, using training mat erials and instr uctions provided

by the manufacturer/grantee of the equipment used to encode analog signals; or

❏ C. Independent training course (e.g., trade school or technical institution) recognized by the manufacturer/grantee of the

equipment used to encode analog signals; or

❏ D. In lieu of the preceding training requirements, the operator(s) maintainer(s) is (are) under the control of a supervisor

trained in accordance with _________ (choose A, B, or C) above.

I agree to provide _______________________________________ (Telco’s Name) with proper documentation to demonstrate compliance with the information as provided in the preceding paragraph, if so requested.

_________ ______________ _______________ __________ (Sign ature)

_________ ______________ _______________ __________ (Title)

_________ ______________ _______________ __________ (Date )

Subscribed and Sworn to before me this ______ day of ________________________, 20____.

________________________________________________ Notary Public

My Commission expires _________________________________ ___.

Five-Year Hardware Limited Warranty

I. Limited Warranty. Subject to the limitations and disclaimers set forth in this Hardware Limited Warranty, Verilink warrants to the original pur-

chaser (“Buyer”) that the Veri link equipment and component parts (“Goods”) purchased by Buyer shall be free from defects in material and workmanship under normal use and service for a period of five years from the date of shipment of the Goods to Buyer (“Limited Warranty”). Verilink’s so le obligation and Bu yer’s sole remedy under this Li mited Warranty shall be to repair or replace an y Verilink Goods t hat Verilink determines to be so defective. Any claim by Buyer under this Limited Warranty must be presented to Verilink in writing within five years and fifteen (15) days of the date of shipment of the Goods to Buyer, as evidenced by Verilink’s packing slip or similar shipment documentation from a Verilink authorized reseller. Any replacement Goods may be new or reconditioned. Verilink reserves the right to substitute equivalent Goods for defective Goods, in its sole discretion. As long as Verilink either so repairs or replaces the Goods, this Limited Warranty will not be found to have failed its essential pur pose. If the defec t has been caused by accident, misuse or abnor m al operating conditions (including lightning damage) occur r ing after delivery to Buyer, rep airs and/or replacement will be made at Buyer’s expense. In su ch event, an estimate of cos t will be submitted to Buyer before rep air work is started. The L imi ted Warranty will continue to apply to repl aced or repaired Good s for whichever is longe r: the 90-day period after the shipment of such Goods to Buyer or the remainder of the original Limited Warranty period.

II. EXCLUSION OF IMPLIED WARRANTIES OR OTHER REPRESENTATION

OUT ANY WARRANTY OR GUARANTEE OF ANY KIND OTHER THAN THE LIMITED WARRANTY SET FORTH ABOVE, WHICH IS MADE EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, AND VERILINK HEREBY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NONINFRINGEMENT, AND ALL OTHER IMPLIED WARRANTIES ON THE PART OF VERILINK. VERILINK DOES NOT WARRANT THAT THE BUYER'S USE OF THE GOODS WILL BE UNINTERRUPTED, SECURE, OR ERROR-FREE. Buyer agrees that no oral or written representation, advice, advertisement or other statement by Verilink, its reseller, agent, employee, or representative constitutes any warranty, guarantee or modification of the foregoing dis claimer and Limited Warranty, and Buyer acknowledges that no pe rson, including resellers, agents, employees , or r e pr esentatives of Verilink, is authorized to assume fo r Verilink any other liability on its behalf except as set forth in this paragraph.

III. LIMIT ATION ON LIABILITY

LIABLE FOR SPECIAL, CONSEQUENTIAL, EXEMPLARY, INCIDENTAL, OR PUNITIVE DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, DATA LOSS, DAMAGE TO EQUIPMENT, OR THE LIKE), REGARDLESS OF WHETHER THE CLAIM IS BASED ON BREACH OF WARRANTY, B REACH OF C ONTRACT, STRICT LIABILITY, OR OTHER LEGAL THEORY, EVEN IF VERILINK OR ITS AGENT WAS ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT WILL VERILINK’S LIABILITY TO BUYER OR ANY SUCCESSOR TO BUYER EXCEED THE PRICE PAID FOR THE APPLICABLE GOODS.

IV. LIMITED WARRANTY CONDITIONS

outside Verilink’s factory, unless Verilink specifically authorized such repairs or alterations; (ii) in the event parts not made or recommended by Verilink are used by Buyer in the Goods; or (iii) if the Goods are used by Bu yer other than in the mann er intended by Verilink or other than in conformance with operating instructions and specifications provided by Verilink.

V. MODIFICATIONS BY VERILINK

hereby, as mutually agreed upon by Verilink and Buyer, shall not be deemed to constitute a breach of the Limited Warranty. Verilink also reserves the right to discont inue Goods and chan ge s pecifications fo r Goods without noti ce, provided such c hanges do not adversely affect the performance of the Goods manufactured by Verilink or do not reduce per f ormance below any app li cable contract specifications between Verilink and the Buyer. Verilink also reserves the right to make product improvements without incurring any obligations or liability to make the same changes in Goods pr eviously manufactured or purchased. N on-payment of any invoice rendered wit hin the stated payment ter ms automatically suspends the application of, but not the running of, the Limited Warranty for the duration of the non-payment.

. IN NO EVENT SHALL VERILINK, ITS OFFICERS, DIRECTORS, EMPLOYEES, OR SUPPLIERS BE

. The Limited Warranty shall be void (i) with respect to any Goods that have been repaired or altered

. Minor deviations from specifications that do not materially affect performance of the Goods covered

. THE GOODS ARE SOLD BY VERILINK “AS IS” WITH-

VI. AMENDMENT OF WAR RANTY TERMS

time to time in its sole discretion. The terms and conditions in effect at the time of purchase will apply to such Goods.

VII. RETURN OF GOODS

packaged to t he bes t commercial standard for electronic equipment. Verilink will pay shippi ng charges for delivery on return. The Buye r i s responsible for mode and cost of shipment to Verilink. The Buyer must have a Return Material Authorization (RMA) number marked on the shipping package. Products sent to Verilink without RMA numbers will be returned to the sender, unopened, at the sender’s expense. A p r oduct sent directly to Verilink for repair must first be assigned an RMA number. The Buyer may obtain an RMA number by calling the Verilink Customer Service Center at 1.800. 926.0085, ext ension 2282 or 2322 . Whe n calling Verilink for an RMA, the Buyer should have the follow in g information available:

• Model number and serial number for each unit

• Reason for return and symptoms of problem

• Purchase order number to cover charges for out-of-warranty items

• Name and phone number of person to contact if Verilink has questi ons about the unit(s ).

A return addres s will be provi d ed at the time t he RMA number is is sued. Th e standar d deliver y metho d for retur n shipme nt s is Stan dar d Ground for domestic returns and International Economy for international returns (unless otherwise specified).

VIII. GOVERNING LA W

sions. The provisions of the UN Convention on Contracts for the International Sale of Goods shall not apply.

. If for any reason the Buyer must return a Verilink product, it must be returned to the factory, shipping prepaid, and

. This Agreement is governed by the laws of the S tate of Alabama, U.S.A., without refere nce to its conflicts of l a w pr ovi-

. These te r m s and co nditio ns of t h i s Har d w are Limi te d Warra n ty may be rev is e d by Verilink from

Verilink FrameStart FSD User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Copyright Notice Copyright © 2000 Verilink Cor poration. All rights reserved.

Trademarks Verilink is a registered trademark Verilink Corporation. FrameStart is a trademark of Verilink

FCC Requirements This equipment (DDS CSU/DSU and T1 CSU/DSU) has been tested and found to comply with

Canadian Emissions Requirements

Warranty Verilink's produ ct w arranty is included at the back of this document. Customer Service Verilink offers the following services:

Returning P roducts Instructions for returning a product are included in Verilink’s product warranty at the back of

Safety P recauti ons When handling this equipment, follow these basic safety precautions to reduce the risk of elec-

Table of Contents

What is a Reference Manual?

Where to go for Information

About This M anual 1

Conventions

Introduction

General 3

FrameStart Install Mode

FrameStart Monitor Mode (optional)

What is LMI Sourcing and why is it important?

What is a DLCI?

What messages does LMI provide?

What is PVC Discovery in FrameStart?

What is PVC Delay Testing?

What is a WAN receive le vel?

What is LMI Monitoring?

What is LMI Auto Sourcing?

What is SOS Mode?

What is New Circuit Install?

How does FrameStart work in a typical application?

INSTALL: LMI Mode is ON

MONITOR: LMI Mode is MON (Optional Feature)

OFF: LMI Mode is OFF

FrameStart Benefits

Ordering Numbers

Feature Summary

General Specifications

Management Interface

Alarms

Power Source

Mechanical

Environmental

Industry Listings

Specifications Chart

Introduction

Safety Summary

Installation 11

Supp lied Materials

Rear Panels

Data Connections

V.35 Data Port

DDS CSU/DSU Network Port

T1 CSU/DSU and FrameStart FSE Network Connection

Receive Levels

RJ-48C Network Connector

BNC Network Connectors

Power

Introduction

DDS CSU/DSU Front Panel

General Operation and Con ventions 17

LCD Access

Password Protection

To Enter an Established Password

Interface Conventions

Menu Title

Menu Element

Information Element

Cursor Elements

Hardware Reset

Utilities

Software Version

Restore Factory Settings

Set Password

Introduction

Menu Start-up Display

N (Network Status)

D (DTE Status)

Operation 21

Main Menu
