Verilink DPRI 2922 User Manual

Download

September 1999 P/N 880-503142-001A1

DPRI 2922

✳✳

NET

LOCAL

✳✳✳

DATA

SYS

EXT

PRI MANAGEMENT

Trademarks

FCC Requirements

its products or services. Verilink’s sole warranty is contained in its product warranty. The end-user documentation is shipped with Verilink’s products and constitutes the sole specifications referred to in the product warranty. Verilink has made reasonable efforts to verify that the information contained herein is accurate, but Verilink assumes no responsibility for its use or for any infringement of patents or other rights of third parties that may r esult. T he customer is sole ly resp onsible fo r veri fying the suitabil ity of Verilink’s products for its use. Specifications are subject to change without notice.

Verilink is a registered trademark of Verilink Corporation. Access System 2000, WANscope, VeriStats, and FrameStart are trademarks of Verilink Corporation.

Any named products herein are trademarks of their respective companies. This equipment has been tested and found to comply within the limits for a Class A

digital device pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide protection against harmful interference in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the user manual, can cause harmful interference to radio communications.

There is no guarantee that interference will not occur in a particular installation. If this equipment causes harmful interference to radio or television reception—which can be determined by turning the equipment off and on—try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This equipment complies with Part 68 of the FCC Rules. On the rear, side or bottom of the unit is a label that contains the FCC registration number and other information. If requested, provide this information to the telephone company.

• All direct connections to the network lines must be made using standard plugs and jacks (compliant wi th Part 68). The following tables list the applicable registration jack universal order codes (USOCs), facility interface codes (FICs), and service order codes (SOCs). These are required to order service from the telco.

For T1 interfaces:

Port ID REN/SO C FIC USOC

1.544 Mbit/s SF

1.544 Mbit/s SF, B8ZS

1.544 Mbit/s ANSI ESF

1.544 Mbit/s ANSI ESF, B8ZS

For DDS interfaces:

Port ID REN/SO C FIC USOC

56 kbit/s 64 kbit/s

• If the unit appears to be malfunctioning, inform the telco and disconnect it from the network lines until the source of trouble is determined to be your equipment or the telephone line . If your equipment needs repair, it should not be reconnected until it is repaired.

• The unit has been designed to prevent harm to the network. If the telephone company finds that the equipment is exceeding tolerable parameters, it can temporarily disconnect service. In this case, the telephone company will provide you advance notice if possible.

Verilink DPRI 2922 U ser Manual

6.0N 04DU9 -BN

6.0N 04DU5 -56

04DU9 -DN 04DU9 -1KN 04DU9 -1SN

04DU5 - 64

RJ-48C jack

RJ-48S jack

Lithium Battery

• If the telephone company alters its equipment in a manner that can affect the use of this device, it must give you warning so that you have the opportunity to maintain uninterrupted service. You will be advised of your right to file a complaint with the FCC.

• No customer is authorized to repair this equipment, regardless of warranty status. All repair s must be performe d by Ve ril i nk or an auth or ized age nt . It is the responsibility of users requiring service to report the need for service to Verilink or to one of our authorized agents.

The lithium battery referred to in the following notices is contained inside the clock chip.

English

Français

DANGER!

The battery can ex plo de i f inco rre ct ly rep lac ed! Repl ace on ly with th e sam e or equi valent type recommen ded by the manufacturer. Di sp os e of used batteries according to the manufacturer’s instructions.

DANGER!

To avoid electrical shock in case of f ailur e , th e power supply must be installed b y a professional installer. The terminal labeled with the ground symbol ( ) on the power supply must be connected to a permanent earth ground.

CAUTION!

Interconnecting circuits must comply with the requirements of EN60950:1992/A4:1997 Section 6.2 for telecommunications network voltages (TNV) circuits.

ATTENTION!

Une explosion peut se produire si la batterie est remplacée d’ une façon incorrecte! Remplacez-la seulement avec le même modêle de batterie ou un modèle équivalent selon les recommendations de manufacture. Disposez de les batteries usées selon le s instructions de manufacture.

ATTENTION!

Pour éviter choc électrique en cas de insuccès, la provision de pouvoir doit êtré installé par un installeur professionnel. Le terminal de la provision de pouvoir, marqué du symbol de terre, ( ) doit connecté à un circuit de terre permanent.

PRUDENT!

Les circuit s doi vent êtré i nter conn ectés de mani ère à ce qu e l’ é quipe ment contin ue a êtré en agrément avec “EN60950:1992/A4:1997, Section 6.2, pour les circuits de voltage de liaisons d’ échanges (réseau) par les télécommunications (TNV), ” après les connections de circuits.

Españole

ATTENCION!

La bateria puede explotar si se r e emplaza incorrectame n t e. Reemplace la bater ia con el mismo tipo de bateria ó una equivalente recomendada por el manufacturero. Disponga de las baterias de acuerdo con las instrucciones del manufacturero.

ATTENCION!

Para evitar contacto con circuitos que electrocutan, la fuente de alimentación debe ser instalada por un técnico profesional. La terminal de la fuente de alimentación marcada con el símbolo de tierra ( ) debe ser conectada a un circuito de vuelta por tierra permanente.

PELIGRO!

Circuitos que se interconectan a la red de telecomunicaciones deben hacerse de tal manera que cumplan con los requisitos estipulados en las especificaciones “EN60950:1992/ A4:1997 , Secció n 6.2, pa ra los vo ltages de c ircuit os interco nnectado s a la Red de Telecomunicaciones (TNV),” despues de terminar las connecciones entre los circuitos.

Verilink DPRI 2922 U ser Manual

iii

Deutsch

VORSICHT!

Explosionsgefahr bei unsachgemäßem Ersetzen der Batterie! Batterie gleichen Typs und gleich er Qualität benutz en, wie vom Hersteller empfohlen. E ntsorgung der Bat t erie nach Anweisung des Herstellers!

VORSICHT, GEFAHR!

Um keinen Schlag zu erhalten beim Versagen der electrische n Anl a ge, muss der Stromanschluss von ei nem Elektriker vorge nommen werden. Der el ektrische Pol, verse hen mit dem Erdsymbol ( ) muss am Stromanschluss permanent geerdet sein.

VORSICHT!

Schaltungen, die in den Geräten zusammengeschaltet sind, müssen weiterhin den Vorschriften EN60950:1992/A4:1997, Absatz 6.2 für Telecommunications Netz Spannung (TNV) Schaltkreize entsprechen.

Canadian

Requirements

Safety Precautions

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicabl es aux appareils numériques (de la class A) prescrites dans le Règlement sur le brouill age radi oélect riq ue éd icté par le mi nist ère des Communi ca tion s du Canada.

The Industry Canada label indentifies CS-03 certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. Industry Canada does not guarantee the equipment will operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company’s inside wiring associated with a single line individual service may be extended by means of a certified connector assembly (telephone extension cord). The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

Repairs to certifi ed equipmen t should be made by a n authoriz ed Canad ian maint enance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.

Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.

This equipment is intended to be installed only in a Restricted Access Location that meets the following criteria:

• Access can only be gained by service personnel or users who have been instructed about the reasons for the restrictions applied to the location and about any precautions that must be taken.

• Access can only be gained through the use of a lock and key or other means of security, and is controlled by the authority responsible for the location.

When handling this equipment, follow these basic safety precautions to reduce the risk of electric shock an d in ju ry :

• Follow all warnings and instructions marked on the product and in the manual.

• Unplug the hardware from the wall outlet before cleaning. Do not use liquid

cleaners or aerosol cleaners. Use a cloth slightly dampened with water.

• Do not place this product on an unstable cart, stand, or table. It may fall, causing serious damage to the product.

• Slots and openings in the shelves are provided for ventilation to protect them from overheating. These openings must not be blocked or covered. Never place this product near a radiator or heat register.

Verilink DPRI 2922 U ser Manual

Product Warranty

Customer Service

Publications Staff

• This product should be operated only from the type of power source indicated on the marking label and manual. If you are unsure of the type of power supply you are using, consult your dealer or local power company.

• Do not allow anything to rest on the power cord. Do not locate this product where the cord will interfere with the free movement of people.

• Do not overload wall outlets and extension cords, as this can result in fire or electric shock.

• Never push objects of any kind into the shelves. They may touch dangerous voltage points or short out parts that could result in fire or electric shock. Never spill liquid of any kind on this equipment.

• Unplug the equipment from the wall outlet and refer servicing to qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged or frayed.

• If liquid has been spilled into the product.

• If the product has been exposed to rain or water.

• If the product has been dropped or if the cabinet has been damaged.

Verilink’s product warranty covers repair or replacement of all equipment under normal use for a five-year period from date of shipment. Replacement products may be new or reconditioned. Any replaced or repaired product or part has a ninety (90) day warranty or the remainder of the initial warranty period, whichever is longer. Our in-house Repair Center services returns within ten working days.

Verilink offers the following services:

• System Engineers at regional sales offices for network design and planning assistance (800) 837-4546

• Technical Assistance Center for free 24x7 telephone support duri ng installation, maintenance, and troubleshooting (800) 285-2755 and support@verilink.com)

• To return a product, it must be assigned a Return Materials Authorization (RMA) number before sending it to Veril i nk for repa ir (800) 92 6- 0085 , ext. 228 2

• Maintenance contracts and leasing plans (800) 837-4546

• Technical Training on network concepts and Verilink products (800) 282-2755

and training@verilink.com

• Web site (www.verilink.com)

This manual was writt en and illustrated by David Gardner. Contributing Writers and Editors: Dave Fradelis, Marie Metivier, Barbara Termaat, and Steve Rider.

Verilink DPRI 2922 U ser Manual

Table 1

Use this detachable checklist to guide your installation of the DPRI 2922 for ISDN capabilities

When Information Required Notes

Before Orderin g ISDN

Check for availability—Call or otherwise access your network service provider (telco)

What applica tio ns?

• Data only

What type of equipment will be hooked up? Manufacturer/B rand Names? Serial/Model Numbers?

• Terminal Adapter (TA)

•Bridg

• Router

• ISDN Telephone

How will the equipment be hooked up? Between the telco and the Verilink equipment? Between the Verilink equipment and your equipment?

ISDN Circuit ID Number ISDN Ordering Code (IOC) (I f required by your telco) Service and billing address Your contact name and number Telco contact name and number

Should be Data only. Be sure to tell your telco that you want the switch configured for DATA ONLY.

No TA supported.

We support RJ-48 connection to telco (Smartjack) interface.

Telco Will Provide

Telco to provide inside wiring and jack? Desired long-distance carrier Delivery of CLID or Statio n ID (Deli ver y of Calling Line ID is

required) Delivery of DNIS (Delivery of DNIS (Dialed Number

Information Servi ce s) re quired) No NSF is required. Netware Specific Facilities information

element is not required. Multirate Services (Nx64) Multirate services may be

required. Availability confirmation Estimated pricing Confirmatio n call

• Due date

• Switch typ

• Service profile identifiers (SPIDs)

• Directory numbers

Fulfillment package

• Troubleshooting guide

SPIDs may not be applicable.

Verilink DPRI 2922 vii

viii Verilink DPRI 2922

DPRI 2922

DPRI 2922 Dual-Port IS DN Pri mary Ra t e Inte rfa ce ...................... ... .......................................... 1-1

Applications ..................................................................................................................... 1-1

Features ............................................................................................................................ 1-2

T1 Digital Transmission Facilities ......................................................................... 1-2

Advanced Automatic Protection Switching ............................................................ 1-2

Dial Backup ..................... ... ............................................................ ... ... ...... 1-2

Alternate T1 Backup ..................................................................................1-2

Crosspoint Switch .................................................................................................. 1-2

Drop, Insert, and Bypass Mode .............................................................................. 1-2

Alarm Management ................................................................................................ 1-2

Advanced Programmable Architecture .................................................................. 1-2

Node Management .................................................................................................. 1-3

Diagnostics ............................................................................................................. 1-3

System Components ......................................................................................................... 1-3

DPRI 2922 Front Module ................... ... .................................................................. 1-3

LEDs ........................................................................................................... 1-3

Management Ports .....................................................................................1-4

Connector Interface Modules ................................................................................. 1-4

Specifications ................................................................................................................... 1-5

Technical and Regulator y C ompl i anc e .................... ... ... ................................................... 1-6

Quick Set-Up .................................................................................................................. .......... 2-1

Getting Started ........... ...................................................................................................... 2-3

Terminal Parameters ...................... ... ..................................................................... 2-3

Logging On ............................................................................................................. 2-3

Bus Compatibility ............ ............................................................ ... ... ..................... 2-3

Network Port Configuration ............................................................................................. 2-5

FDL Options ............................................................................................................ 2-6

Timing Options ......... .............................................................................................2-7

Data Port Configuration ................................................................................................... 2-8

ISDN PRI Port Configuration ........................................................................................... 2-10

PRI Call Profile ...................................................................................................... 2-12

Setting Alarm (Backup Trigger) Parameters ................................................................... 2-15

Building Circuits ............................................................................................................. 2-16

Activate the Primary Circuit ................................................................................. 2-18

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface ................................................ 3-1

ISDN Access ......................................................................................................................3-1

ISDN and Routine Management Tasks .................................................................... 3-1

Logging On ....................................................................................................................... 3-1

NCM Main Menu ................................................................................................................ 3-2

Shelf and Slot Parameters ................................................................................................. 3-4

NCM/DPRI 2922 Main Menu Commands .......................................................................... 3-4

Administration Menu ........................................................................................................ 3-5

Configuration Menu ......................................................................................................... 3-6

T1 Port Configuration Me n u ...................................... ... ... ....................................... 3-6

FDL Configuration Submenu ..................................................................... 3-9

Configuration Menu (Timing Options) .................................................... 3-10

Data Port Configuration Menu ............................................................................. 3-14

ISDN PRI Configuration Menu ............................................................................... 3-16

PRI Port Configuration Me nu ........................ ........................................... 3-17

Verilink DPRI 2922

vii

BACK HOME GLOSSARY INDEX

PRI Call Profile Configur a tion Me nu ............................... ... ...................... 3-19

Port n PRI Call Profile Configuration Menu ............................................. 3-19

PRI Performance / Statistics Menu .......................................................... 3-22

Diagnostics Menu ......................... .............................. ... ... .............................................. 3-25

T1 Port Diagnostics Menu ................................ .................................................... 3-25

Data Port Diagnostics Menu ................................................................................. 3-27

Performance / Status Menu ............................................................................................ 3-28

Performance / Status Menu (24hr T1 Performance Data Summary) .................... 3-30

Net Port Alarm Threshold Status Menu ................................................................ 3-32

Counter Menu ....................................................................................................... 3-32

Net Port Alarm Menu ...................................................................................................... 3-33

Net Port Alarm Threshold Configuration Menu ................................................... 3-34

Net Port Alarm Theshold Status Menu ................................................................. 3-36

Circuit Manager Menu .................................................................................................... 3-37

Add Circuit Submenu ........................................................................................... 3-39

Search Circuit Submenu ....................................................................................... 3-41

Delete Circuit Submenu ....................................................................................... 3-42

Edit Circuit Submenu ........................................................................................... 3-42

Manufacturing Info ........ ... .............................................................................................. 3-45

System Log Off ............................................................................................................... 3-45

Troubleshooting ...................................................................................................................... 4-1

Interpreting Alarms .......................................................................................................... 4-1

Status Code ............................................................................................................ 4-2

Alarm Description .................................................................................................. 4-2

Classifications ........................................................................................................ 4-2

Problem Types ....................................................................................................... 4-2

What To Do About Alarms ................................................................................................ 4-3

Alarm Records ........................................................................................................ 4-3

Alarm List ......................................................................................................................... 4-4

Interpreting Front Panel LEDs .......................................................................................... 4-6

Network LEDs ......................................................................................................... 4-6

Data Port LEDs ........................................................................................................ 4-7

System LED ............................................................................................................. 4-7

viii

Verilink DPRI 2922

Chapter

BACK HOME GLOSSARY INDEX

DPRI 2922 Dual-Port ISDN Primary Rate Interface

The DPRI 2922 applicat ion module working in conjunction with an NCM 2000 controller mo dule provides your AS2000 system with critical network backup capability that includes ISDN PRI access.

NOTE: The ISDN capability of the DPRI 2922 application modul e is onl y

accessible through the NCM 2000 Controller Menu.

The DPRI accepts high-speed data from local area networks, host mainframes, and other types of data terminal equipment. The aggregate data rate from terminal equipment can be one of the following:

T1 Timeslots Data Rate

n = 1—23 or 1—24 dependin g on NFAS configuration

n × 56 kbit/s (up to 1.344 Mbit/s) (n = 1–

24) n × 64 kbit/s (up to 1.536 Mbit/s) (n = 1–

24)

Applications

In dial-backup mode, the DPRI 2922 is useful as an alternate ISDN route when regular T1 lines are unavailable. The DPRI 2922 also provides the ability to designate a reserve leased T1 as a backup.

Figure 1-1 ISDN Dial-Backup Application

Verilink DPRI 2922 1-1

DPRI 2922 Dual-Port ISDN Primar y Rate Interface

Features

The DPRI 2922 system has the following features:

BACK HOME GLOSSARY INDEX

T1 Digital Transmission Facilities

Advanced Automatic Protection Switching

Dial Backup

Alternate T1

Backup

Crosspoint Switch

The DPRI system carries data traffic onto a T1 transmission facility. Each port provides T1 transport bandwidth of n×56 kbit/s or

n×64 kbit/s trunks.

The DPRI system provides Advanced Automatic Protection Switching (AAPS) to an alternate T1 line using two hardware options:

•

DPRI with the CIM 29010, dual V.35 serial data ports

•

DPRI with the CIM 29011, dual RS-449/EIA-530 serial data ports

The DPRI system provides an alternate ISDN route for digital data traffic when the regular T1 line is unavailable.

The DPRI system provides an alternate T1 route for digital data traffic when the regular T1 line is unavailable.

The DPRI system provides flexibility for designing data paths to and from multiple AS2000 T1 modules across the backplane. Incoming and outg oing channels can be set up to send data traffic.

Drop, Insert, and Bypass Mode

Alarm Management

Advanced Programmable Architecture

1-2 Verilink DPRI 2922

The DPRI supports drop, insert, and bypass functionality via its crosspoint switch. Further, the drop, insert, and bypass configuration helps reduce the number of network (T1) links among different sites.

DPRI alarms are reported to the NCM. These alarms are viewed using the NCM Craft interface, Telnet, SNMP, or Node Manager.

All DPRI system hardware and software components can be independently up gra d ed wit h produ ct options and firmware upgrades. Additional mo dules can be added within a node to increase network channel capacity. CIMs and other modular components can be added, upgraded, or replaced independently.

BACK HOME GLOSSARY INDEX

DPRI 2922 Dual-Port ISDN Primar y Rate In-

Node Management

Diagnostics

The NCM provides node management via Cr aft interface, Telnet, SNMP, and Verilink’s Node Manager.

The DPRI provides line (LLB), data port (DPLB), repeater (RLB), and payload (PLB) loopbacks. Test patterns can be used with or without the loopbacks.

System Components

Hardware components of the DPRI 2922 system include:

•

NCM 2000 (Version 4. 0 or higher firm ware) with acco mpanying NIM

•

Dual-Port Primar y Rate Interface (DPRI) ISDN module

•

Connector interface modules (CIMs)

• CIM 29010 (P/N 311-101387-001) or

• CIM 29011 (P/N 311-107387-002)

•

Universal power supply and shelf

•

System cables (Craft Cable P/N 458-501788-008)

DPRI 2922 Front

Figure 1-2 shows the front panel of the DPRI 2922.

Module

Figure 1-2 Dual Port ISDN Primary Rate Interface (DPRI 2922) Front Panel

ACP Management communications port to extend bus to another shelf, RJ-45

Primary ACP Management port for direct connection to PC running Node Manager, RJ-45

Craft Port, RJ-11

DPRI

2922

LEDs

✳✳

NET

LOCAL

✳✳✳

DATA

Ejector Handles

The DPRI front panel’s System LED (SYS) is green when the module has passed the power-up self-test.

SYS

PRI

EXT

MANAGEMENT

The panel also contains four status LEDs:

•

Two for network port status

Verilink DPRI 2922 1-3

DPRI 2922 Dual-Port ISDN Primar y Rate Interface

•

Two for data port status

Chapter 4 of this manual defines the LEDs and alarms.

BACK HOME GLOSSARY INDEX

Management Ports

Three NCM front panel management ports support management of the local node and allow remote node management.

•

Local—RJ-11 direct connection to the Craft interface via:

•An ASCII terminal

• A PC running a terminal emulator

• Node Manager ASCII Port Access window

The DPRI 2922 also supports access to the ASCII interface over NCM Telnet sessions via modem dial-up SLIP connections.

•

PRI—Primary Management . Node Manager interface c onnection to the PC COM port.

Type Serial port used for No de Manager access or

ACP bus extension

Connector RJ-45 (8-pin), RS-232-compliant

•

EXT— Multishelf Management. Extension port for daisychaining multiple AS2000 shelves (ACP-bus modules only).

Type ACP management Connector RJ-45 (8-pin), RS-232-compliant

The PRI and EXT ports can be used interchangeably.

ext

ension port

Connector Interface Modules

The DS-1 CIM 29010 and the DS-1 CIM 29011, shown in Figure 1-3, support dual RJ- 45 network po rt connect ors and eith er dual V.35 or dual EIA530/RS449 data port connections. They also provide the following interfaces:

•

Alarm relay Loss of carrier conditions activate the relay contacts. These

contacts can be wi r e d to e x te r na l ala r m e q u ipment. The connector pins provid e output as a normally open (NO) contact, a normall y closed (NC) contact, and a common (CO M) lead contact.

•

External timing source input The 8-pin mini-DIN connecto r receives a clock signal from an

external tim in g de v i ce .

1-4 Verilink DPRI 2922

BACK HOME GLOSSARY INDEX



            

Figure 1-3 T1 CIM Configurations

DPRI 2922 Dual-Port ISDN Primar y Rate In-

311-101387-001

EXT TIMING

311-101387-002

EXT TIMING

Ext.

Timing

Input

INPUT

ALARM

RELAY

NO COM NC

ALARM

RELAY

NO COM NC

Relay

DATA 2

V.35

DATA 2

RS449

NOTE: Data Ports 1 and 2 requ i r e ad ap t er ca bles to properly interface

with native connectors.

Specifications

Table 1-1 DPRI General Specifications

Number of Ports Transmission (Line) Rate

4 per module (2 n et w o rk and 2 data)

1.544 Mbit/s, RX: ± 200 ppm; TX: ± 32

DATA 1

V.3 5

DATA 1

RS449

PORT 2

DS-1

T1 Port 1T1 Port 2Data Port 1Data Port 2Alarm

PORT 1

29010

CIM

29011

CIM

Line Code Framing Format CPE Impedance T ransmission Level Input Level

Output Level Output LBO (selectable) Loopbacks

Timing

B8ZS, AMI ESF, SF 100 Ω ± 5% at 772 KHz test 0 dB

CIM 29010, 29011

: 3.0 V ± 0.3 V base-to-peak, attenuated by 0 to 27.5 dB

3.0 V ± 0.3 V base-to-peak or DS1 into 100 Ω at 0 dB LBO

0, 7.5, 15, or 22.5 d B (0 to 3000 feet) Line, Data Port, Repeater, Payload Modes: Network, External, and Internal

System port: External T1 (8-pin DIN)

Verilink DPRI 2922 1-5

DPRI 2922 Dual-Port ISDN Primar y Rate Interface

BACK HOME GLOSSARY INDEX

Table 1-2 CIM Specifications

CIM Modules Name Physical Interface

CIM 29010 and

29011

CIM 29010 only Data ports V.35 Mini D-sub CIM 29011 only Data ports RS-449/EIA 530

CIM

External timing 8-pin DIN

Alarm relays Form-C relay T1 ports RJ-45

Technical and Regulatory Compliance

This product complies with the following regulatory specifications as they apply to telecommunications equipment:

Table 1-3 Standards and Reference Documents

AT&T ANSI ANSI T1.403 FCC FCC Part 68

AT&T 54016, AT&T 62411, AT&T TR-NPL-000054, AT&T 4ESS, AT&T 5ESS

UL UL 1459 Revision 2

DMS 100, and NIS-2 ISDN CSA/DOC Bellcore EIA ITU-T (Formerly CCITT) RFC TR

1-6 Verilink DPRI 2922

Chapter

Quick Set-Up

This chapter provides step-by-step procedures as an example for setting up your DIDCSU 2912 module.

NOTE: Since the following pr ocedures may not exactly apply to your

specific application, use them only as as a guide for the configuration process. Complete descriptions of the various screen options and suggestions for their appli cability to your situ ation are given in the following chapter.

NOTE: For the most effective and efficient set-up, have a ll required

planning data such as your inte nded use, network (telco) prov ider specifications, channel and line requirements, circuit configurations, and other important information handy. For your convenience, worksh eets are pro vided in the A S2000 Bas ics Man ual, Chapter 2—Site Planning.

Getting Started

Terminal Parameters

Logging On

After the NCM and DIDCSU modules and their NIM/CIM have been installed in their appropriate shelf/slots (self-test has been successfully completed), connect the Craft Interface Cab l e (P/N 458-501788-008) to the Local port on the NCM front panel to access the ASCII interface.

Terminal parameters: 19.2 kbit/s baud rate, 8 data bits, no parity, one stop-bit, and no flow-control. Make sure that the X-On/X-Off flow control is disabled.

NTER

1. Press

2. Press

If the NCM proper shelf/slot position, you may continue with the configuration tasks.

The default password for the NCM will give the user Access Level 2 permissions. If you need a higher access level, see your NCM 2000 User Manual for more information.

to display the

NTER

to display the NCM

Main Menu

display Figure 2-1 shows the DIDCSU in the

pSH+>

prompt and type

Main Menu

craft

Verilink DPRI 2922

2-1

Quick Set-Up

Bus Compatibility

If there is no indication of the DIDCSU on the “shelf map” on the

Main Menu

NCM on the shelf backplane.

NCMs are usually sent out with their default bus being the C bus. Other modules usuall y are sent out wi th the ir defaul t bus be ing the A bus.

Assign the DIDCSU to the bus on which the NCM resides by accessing the DIDCSU’s AS CII port directly.

1. Connect the Craft Interface Cable directly to the LOCAL port on the DIDCSU module.

2. At the prompt, type

3. At the

4. From the

ACE Controller Menu> O) ACE Controller Administration Menu> B) Change the ACP Bus

5. Once the bus assignment has been made, reboot the reassigned module by either

, the modules may be assigned to different busses

craft

PASSWORD:

PASSWORD:PASSWORD:

DIDCSU Main Menu

prompt, type “

, then press

, select the following:

NTER

verilink”

Reboot

•

Using the

Administration Menu

•

Reseating the module in its slot.

Reconnect to the NCM Local port for further operations.

Reboot

RebootReboot

command from the

, option R, or

ACE Controller

2-2

Verilink DPRI 2922

Figure 2-1 NCM Main Menu

Firmware Version and Date of Release

Node Address

Quick Set -Up

Access Level (1-4)

Menu Heading Area

Node “Map” (Physical Location of Modules)

Module Key

Command List

Active NCM Master Designator

❶

❷❸

2 - - - - - - - - - - - - 3 - - - - - - - - - - - - 4 - - - - - - - - - - - - KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM, H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI S) shelf/slot O) administration C) configuration D) diagnostics P) performance/status A) alarm B) circuit manager I) manufacturing info X) exit this screen A [127.255.255.0] [1,2] DIDCSU 2912 >

Node Address

Indicator for the type of shelf: M= Multi-line, D = Dual-line

❶

Asterisk indicates that the NCM is the Main Controller in the shelf

❷

Brackets around module letter ( [P] ) indicate current module selected

❸

Data (Command) Entry Area

Verilink DPRI 2922

2-3

Quick Set-Up

Network Port Configuration

NOTE: Configure the network ports first, then the data ports.

1. From the NCM ASCII interface the DIDCSU application module using option S, Shelf/Slot. When refreshed, the

Main Menu

the P, which indicates the DIDCSU.

2. From the

Main Menu

, select option C, “Configuration”, to start

the configuration task.

Figure 2-2 Configuration Menu

A [127.255.255.0] [1,2] DIDCSU 2912 > c

-- DIDCSU 2912 CONFIGURATION MENU -P) T1 port D) data port X) exit this screen A [127.255.255.0] [1,2] DIDCSU 2912 >

3. From the

Configuration Menu

access the network port configuration menu, Figure 2-3.

Figure 2-3 T1 Port Configuration Menu

-- DIDCSU 2912 T1 PORT CONFIGURATION MENU - PORT 1 PORT 2 In) In Service YES YES Fn) Frame Format ESF ESF Ln) Line Coding B8ZS B8ZS Bn) Line Build Out 0db 0db NDn) Network Density NONE NONE NLn) Network Initiated Loop YES YES An) Alarm Declare Time(sec) 0 0 DLn) FDL Enable YES YES PRM Enable NO NO En) Enable Inband/ISDN Inband ena ISDN ena Sn) Inband Timeslot 24 24 F) FDL configuration T) Timing X) Exit this screen A [127.255.255.0] [1,2] DIDCSU 2912 >

Main Menu

, Figure 2-1, select

will use brackets to enclose

, Figure 2-2, select option P to

2-4

4. In the numeral 1, the I, then 2,

5. Press F, then 1,

T1 Port Configuration Menu

NTER

, then Y, to place Net Port 1 In Service. Press

NTER

, then Y, to place Net Port 2 In Service.

NTER

, then 2 to select ESF as your frame format for Net Port 1. Press F, then 2, frame format for Net Port 2.

Verilink DPRI 2922

, press the letter I, then the

NTER

, then 2 to select ESF as the

NTER

6. Press L, then 1, for Net Port 1. Press L, then 2,

, then 2 to select B8ZS as the line coding

NTER

, then 2 to select B8ZS as

the line coding for Net Port 2.

NTER

7. Press B, then 1, for Net Port 1 . Press B, then 2,

, then 1 to select 0db as the line build out

NTER

, then 1 to select 0db as the

line build out for Net Port 2.

NTER

8. Press ND, then 1, density for Net Port 1. Press ND, then 2,

, then 1 to select NONE as the network

NTER

, then 1 to select

NONE as the network density for Net Port 2.

NTER

9. Press NL, then 1, on Net Port 1. Press NL, then 2,

, then Y to allow network initiated loops

NTER

, then Y to allow network

initiated loops on Net Port 2.

NTER

10. Press A, then 1,

, then 0 if you do not want the alarm

declare time enabled on Net Port 1. Type a number 1 through

127

to indicate the number of seco nds to elapse before

declaring an alarm condi ti on to the system for Net Port 1.

NTER

Press A, then 2,

, then 0 if you do not want the alarm

declare time enabled on Net Port 2. Type a number 1 through

127

to indicate the number of seco nds to elapse before

declaring an alarm condi ti on to the system for Net Port 2.

Quick Set -Up

FDL Options

NTER

11. Press DL, then 1, Press DL, then 2,

12. Press S, then 1, channel timeslot for Net Port 1. Press S, then 2,

, then Y to enable FDL for Net Port 1.

NTER

, then Y to enable FDL for Net Port 2.

NTER

, then the number 24 to set the signalling

NTER

, then the

number 24 to set the signalling channel ti meslot fo r Net Port 2.

NTER

13. Press E, then 1,

1. Press E, then 2,

, then 1 to enable the inba nd for Net Port

NTER

, then 2 to enable ISDN for Net Port 2.

Facility Data Link is an ESF T1 port configuration option. The ESF FDL transmits framing information, error events, and loopback controls. FDL uses 4 kbit/s of bandwidth to transmit data. If you plan on using FDL, ensure that ESF framing format has been selected.

1. Press F to access the

Configuration Menu (FDL Options)

Verilink DPRI 2922

2-5

Quick Set-Up

Figure 2-4 Configuration Menu (FDL Options)

-- DIDCSU 2912 CONFIGURATION MENU (FDL OPTIONS)- PORT 1 PORT 2 Sn) FDL Standard BOTH BOTH Mn) FDL Mode TERM TERM Pn) Poll Mode NO POLL NO POLL Cn) PRM C/R bit NONE NONE In) Idle Pattern FLAGS FLAGS An) Send/Rec LLB BOP YES YES Bn) Send/Rec PLB BOP YES YES X) exit this screen A [127.255.255.0] [1,2] DIDCSU 2912 >

NTER

2. Press S, then 1,

Port 1. Press S, then 2, Network Port 2.

Options available for the FDL Standard are TR54016, T1.403, or BOTH. This option deter mines how the network service provider examines and resets the ESF registers. Select the TR54016 option if your service provider is AT&T. Select T1.403 if your service provider is any other provider.

, to assign the FDL Standard to Network

NTER

, to assign the FDL Standard to

Timing Options

3. Press M, then the port number to s ho w op tions for the FDL Mode. Currently, TERM is the only one supported. PASS is NOT supported.

4. Press P, then the port number to show options for the Poll Mode. Your options are PO LL, NO POLL, and UNSOLICT. The above display shows that NO POLL has been selected.

5. Press C, then the port number to show options for the PRM C/R bit. Your options are NONE, USER, and TELCO.

6. Press I, then the port number to sho w op ti ons for the Idle Pattern. Options for th is parameter are ALL ONES or FLAGS. The above display shows the FLAGS option.

7. Press A, then the port number for the prompt whether you want to send/receive ANSI BOP LLB.

8. Press B, then the port number for the prompt whet her you want to send/receive ANSI BOP PLB.

1. When the FDL options have been selected, return to the

Configuration Menu

and then select T for the

Menu (Timing Options)

submenu.

Configuration

2-6

Verilink DPRI 2922

Figure 2-5 Configuration Menu (Timing Options)

-- DIDCSU 2912 CONFIGURATION MENU (TIMING OPTIONS)-Current shelf timing source: Card 2, INTERNAL (PRIMARY) Source Slot Number Synchronization Auto Restore PRIMARY PC) 2 PS) NET1 PA) YES SECONDARY SC) 2 SS) NET2 SA) YES TERTIARY TC) 2 TS) INTERNAL TA) YES R) Receive clock from shelf: YES X) exit this screen A [127.255.255.0] [1,2] DIDCSU 2912 >

2. All primary and dial -backup circuits must use shelf timing to synchronize with each other; therefore, select R, then then refresh the screen by exiting to the

Configuration Menu

selecting T. When the been selected to be

Options)

menu displays as shown in Figure 2-4.

and then returning to the screen by

“Receive clock from shelf” option has

R) R)

YES

, the

3. Use the ISDN network ports as the primary and secondary sources. Use

INTERNAL

as the tertiary source. For example, if the DIDCSU 2912 is in slot 2, the shelf timing table should look like Figure 2-4. Exit to the

Configuration Menu

Quick Set -Up

YES

T1 Port

Configuration Menu (Timing

NOTE: Ensure that the card used as a timing source is set to Receive Clock

From Shelf as well.

Data Port Configuration

After both the DIDCSU module network ports have been properly configured, cont inue with the data port configuration. You need to know the types of equipment that will be connected to your data ports and the interfaces that they will need. Refer again to the filled-out checklists and worksheets.

1. From the NCM ASCII interface designated as the active card), select option C, “Configuration”, to start the configuration task.

Figure 2-6 Configuration Menu

A [127.255.255.0] [1,2] DIDCSU 2912 > c

-- DIDCSU 2912 CONFIGURATION MENU -P) T1 port D) data port I) ISDN PRI X) exit this screen A [127.255.255.0] [1,2] DIDCSU 2912 >

Main Menu

(with the DIDCSU

2. From the

Configuration Menu

Data Port Configuration Menu

Verilink DPRI 2922

, select option D to access the

2-7

Quick Set-Up

Figure 2-7 Data Port Configuration Menu

-- DIDCSU 2912 DATA PORT CONFIGURATION MENU - PORT 1 PORT 2 In) In Service YES YES Mn) Data Port Mode DCE DCE Cn) Clock Option ST ST On) Enable LOS detection DTR NO Ln) Control Line Indicator LOW LOW SRn) DSR/LOW DSR/LOW SSn) CTS/LOW CTS/LOW SDn) DCD/LOW DCD/LOW SMn) TM /LOW TM /LOW DTR/LOW DTR/LOW RTS/LOW RTS/LOW LLB/LOW LLB/LOW RLB/LOW RLB/LOW Cable ABSENT PRESENT DPL Loopback DISABLE DISABLE Test Pattern NONE NONE Test Error Counter 0 0 X) exit this screen A [127.255.255.0] [1,2] DIDCSU 2912 >

3. In the the numeral 1, Press the I, then 2,

Data Port Configuration Menu

NTER

, then Y, to place Data Port 1 in service.

NTER

, then Y, to place Data Port 2 in

, press the letter I, then

Service.

NTER

4. Press M, then 1, Port 1. Press M, then 2,

, to select the Data Port Mode for Data

NTER

, to select the Data Port Mod e for

Data Port 2.

NTER

5. Press C, then 1,

1. Press C, then 2,

, to select the clock op tion for Data Port

NTER

, to select the clock option for Data

Port 2.

NTER

6. Press O, then 1, Detection for Data Port 1. Press O, then 2,

, to select whether or not to Enable LOS

NTER

whether or not to Enable LOS Detection for Data Port 2.

NTER

7. Press L, then 1, Data Port 1. Press L, then 2,

, to select the Control Line Indicator for

NTER

, to select the Control Line

Indicator for Da ta Port 2.

NTER

8. Press SR, then 1,

, then 2,

9. Press SS, then 1,

, then 2,

, to select the DSR for Data P ort 1. Press

NTER

, to select the DSR for Data Port 2.

NTER

, to select the CTS for Data Port 1. Press

NTER

, to select the CTS for Data Port 2.

, to select

2-8

10. Press SD, then 1,

, then 2,

NTER

Verilink DPRI 2922

NTER

, to select the DCD for Data Po rt 1. Press

, to select the DCD for Data Port 2.

NFAS

NTER

11. Press SM, then 1,

, then 2,

, to select the TM for Data Port 1. Press

NTER

, to select the TM for Data Port 2.

1. For NFAS mode (If you want the increased bandwidth capability from grouping the two lines together):

a. Activate NFAS by pressing F1 for Port 1. Sele ct NFAS. Since NFAS controls the other port as well, there’s no need to

configure both ports. The NFAS configuration will apply to BOTH ports. (Port 1 is then the “controlling” port.)

Quick Set -Up

b. Reboot the module by exiting all the way to the

, selecting O to display the

Administration Menu

Main

Figure 2-8. The card may also be reb o oted by unseating it, then reseating it. (Rebooting is required whenever the NFAS setting is changed.)

Figure 2-8 NCM Controller Administration Menu (DIDCSU 2912 Card Administration Submenu)

[0.0.0.5] [1,2] DIDCSU 2912 > o

-- NCM CONTROLLER ADMINISTRATION MENU -Date/Time/Zone: 3-10-97 13:52:59 Node Address: [0.0.0.5] Node ID: 1 Site Name: TAC-LAB System Uptime: 4:03:03

--- DIDCSU 2912 -- Card Administration -- [01,02] --O) switch over permanent Q) query firmware R) reset card Y) switch over once U) clear card configuration X) exit this screen [0.0.0.5] [1,2] DIDCSU 2912 >

a. Select R) “reset card” to reboot the module and

implement NFAS.

NOTE: If you use ESF/B8ZS:

Do not invert the D Channel Use 8 bits on the D Channel

If you use SF/AMI: Invert the D Channel Use 7 bits on the D Channel

Verilink DPRI 2922

2-9

Quick Set-Up

2. Set the Switch Type, Own Numbering Plan, and Own Numbering Type according to the parameters your NSP has provided you (use the checksheet provided). The choices shown above are a possible (and recommended) configuration.

3. Set the Security Level according to your particular needs.

4. Set the L2 auto establish to “Yes”. It allows for verification of signal connection.

Setting Alarm (Backup Trigger) Para mete rs

When normal T1 service is interrupted, errored, or lost, an alarm triggers the backup circuit. Th eref ore, this alarm must be set for the T1/Data Ports you want to monitor/trigger for backup activation.

1. Select A from the

Port Alarm Menu

Main Menu

2. Set the “Card Alarm Reporting” option (A) to

Figure 2-9 Net Port Alarm Menu

A [127.255.255.0] [1,2] DIDCSU 2912 > a

-- DIDCSU 2912 NET PORT ALARM MENU -N) NMS Address 128.0.0.0 A) Card Alarm Reporting YES C) Configure Thresholds S) Alarm status O) Display Alarm Buffer Tn) Set Default Thresholds X) exit this screen A [127.255.255.0] [1,2] DIDCSU 2912 >

3. Select C to configure thr es h o lds.

, Figure 2-1, to access the

YES

Net

2-10

Verilink DPRI 2922

Figure 2-10 Net Port Alarm Threshold Configuration Menu

-- DIDCSU 2912 NET PORT ALARM THRESHOLD CONFIGURATION MENU - PORT 1 PORT 2 Pn) Alarm Reporting(NET) YES YES Dn) Alarm Reporting(DATA) YES YES Fn) LOF threshold 3 3 LOF interval 3 3 Ln) LOS threshold 3 3 LOS interval 3 3 Rn) RAI threshold 1 1 RAI interval 1 1 An) AIS threshold 1 1 AIS interval 1 1 Bn) BPV threshold 1 1 BPV interval 1 1 En) ES 15min threshold 900 900 ES 24hr threshold 86400 86400 Sn) SES 15min threshold 900 900 SES 24hr threshold 86400 86400 In) BER threshold DISABLE DISABLE Tn) Set Default Threshold X) exit this screen A [127.255.255.0] [1,2] DIDCSU 2912 >

Quick Set -Up

Building Circuits

4. Enable Net Ports 1 and 2 Al arm Reporting (NET) b y setting both P1 and P2 to “YES”.

5. Enable Data Ports 1 and 2 Ala rm Reporting (DATA) by setting both D1 and D2 to “YES”.

Circuit building is a p rimar y f uncti on of th e N CM 2000 . For genera l information on circuit building, refer to the NCM 2000 User Manual. This section provides “Quick Set-up” circuit building information specifically for the DIDCSU 2912 with material not covered in the NCM 2000 User Manual. For more details on circu it building, refer to the section on circuit building in Chapter 3 of this document.

NOTE: If you are addin g an N CM into a node that has other modu les with

Build main and backup circuits using the Figure 2-15, by selecting B from the

pre-existing circuits, the circuits must be cleared before using the modules with the NC M or bui lding new cir cuits with th e NCM Circu it Manager.

Circuit Manager Menu

Main Menu

, Figure 2-1.

Verilink DPRI 2922

2-11

Quick Set-Up

Figure 2-11 Circuit Manager Menu

A [127.255.255.0] [1,2] DIDCSU 2912 > b Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 - >>>>>> NO CIRCUIT FOUND IN DATABASE <<<<< A) add circuit L) search circuit D) delete circuit E) edit circuit P) prev page I) activate circuit N) next page R) deactivate circuit X) exit to craft main menu A [127.255.255.0] [1,2] DIDCSU 2912 >

When this menu is activ ate d fo r the fir st ti me , an d no cir cu its hav e been built yet, the mesage

NO CIRCUIT FOUND IN DATABASE

display.

Figure 2-12 Add Circuit Menu

A [127.255.255.0] [1,2] DIDCSU 2912 > a Add Circuit -- [1,1] NCM 2000 Firmware 4.15 - N) Name: -- P) Priority: norm T) Type: -- M) Mode: -SP) [-,-] undefined DP) [-,-] undefined SM) --src port chn-- DM) --dst port chn- (undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port) U) Bus: -- ->-->>->> Circuit Inactive <<-<<--< S) Setup X) Exit A [127.255.255.0] [1,2] DIDCSU 2912 >

will

Figure 2-13 Circuit Manager Menu (With Circuits Added)

Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 - Page : 1 Total: 2 circuits Name Type Mode Prio Src Port Dest Port Bus Status

------------ ---- ---- ---- ---------------- ---------------- --- -----DIDCSUtestC1 prim 64k crit [1, 2] DIDCSU dat1 [1, 2] DIDCSU net1 INT Inacti dialbackup d-bk 64k crit [1, 2] DIDCSU dat1 [1, 2] DIDCSU net2 -- Inacti A) add circuit L) search circuit D) delete circuit E) edit circuit P) prev page I) activate circuit N) next page R) deactivate circuit X) exit to craft main menu A [127.255.255.0] [1,2] DIDCSU 2912 >

2-12

Verilink DPRI 2922

Quick Set -Up

Figure 2-14 Add Circuit Menu

Figure 2-15 Circuit Manager Menu

[0.0.0.5] [1,2] DIDCSU 2912 > b

Circuit Manager -- [1,1] NCM 2000 Firmware 1.94 - Page : 1 Total: 2 circuits Name Type Mode Prio Src Port Dest Port Bus Status

------------ ---- ---- ---- ---------------- ---------------- --- -----a prim 64k norm [1, 2] DIDCSU NET1 [1, 2] DIDCSU DAT1 Non Inacti b d-bkp 64k norm [1, 5] DIDCSU NET1 [1, 5] DIDCSU DAT1 Non Active A) add circuit L) search circuit D) delete circuit E) edit circuit P) prev page I) activate circuit N) next page R) deactivate circuit X) exit to craft main menu [0.0.0.5] [1,2] DIDCSU 2912 >

•

Build T1 to T1 or Data Port to T1 circuits as the primary circuit.

•

Port being provided backup is the Source port of the primary circuit.

Verilink DPRI 2922

2-13

Quick Set-Up

2-14

Verilink DPRI 2922

Chapter

ISDN Access

ISDN and Routine Management Tasks

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

For ISDN functionality, the DPRI 2922 Craft interface must be accessed from the NCM 2000 module. This may be done with a

direct cable connecti on from the NCM 2000 module front panel to an ASCII terminal or PC running a terminal emulator program, or using the NCM 2000’s Telnet capability.

To set up the dial-backup circuit feature, please see Chapter 2, “Creating an ISDN Dial-Backup Circuit”.

The following major functions are available through the Craft interface:

•

T1 port, data port, and timing parameter configuration

Logging On

•

Network and data port diagnostics

•

Performance, status, and alarm monitoring

•

Circuit building, editing, and viewing

In addition to the Craft interface, you can use Verilink’s Node Manager—a graphical user interface (GUI) management software package—to configure the DP R I module. For more information, see the Node Manager for Windows 95 User Manual.

1. To access the NCM/DPRI for the fir st time via the NCM 200 0, at

psH+>

the

psH+>psH+>

NTER

psH+>

psH+> psH+>

2. When accessing the NCM/DPRI for the first time, at the

YOUR PASSWORD:

YOUR PASSWORD:YOUR PASSWORD:

Until you change the password, the password. If you have changed the default password, then type the correct password (up to 8 characters, including spaces). The screen will display placeholders ( type the password. After ty pin g th e pass w or d, pr e ss

prompt type

. (Note that the NCM interface will return you to the

prompt after 15 minutes of inactivity at the keyboard.)

prompt, press

craft

(in lowercase letters), then press

NTER

key is the default

******

************

) as you

NTER

Verilink DPRI 2922 3-1

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

NCM Main Menu

NOTE: Setting the password on the NCM has no effect on the passwords of

For more information on NCM security or password assignment, see the NCM 2000 User Manual.

The of the selected node.

NOTE: This manual deals with the DPRI mo dule in particular and the N CM

In the screen displayed via the

the DPRI or other modul es in the node. To set the password for the DPRI module, you must access the DPRI module via direct connection.

NCM Main Menu

module with regard o n ly to how the NCM module in teracts with the DPRI module.

•

Slots containing DPRI modules show a rows and columns that designate t he shelf/slot location of the DPRI module.

displays the contents of slots in the shelves

NCM Main Menu

PPPP

at the intersection of

•

The letter

•

The letter surrounded by br ackets ( of the module that is referenced and modified via submenus of the

•

On initial log in, brackets surround the module being used as the log-in access point.

•

The move to a desired module in the node.

In Figure 3-1, the

PPPP)

in slot 2. Using the accessed module indicated by the square brackets ( changed to the DPRI 2922 in slot 2. The asterisk next to the (which designa tes the NCM 2000 module) indica tes that the NCM 2000 module is the node mast er.

NOTE: Many of the DPR I 2922 ASCII screens ac cessed via th e NCM 2000 w ill

differ significantly from those accessed via the DPRI 2922 Local Port.

NNNN

shows the location(s) co ntaining NCM module(s).

NCM Controller Menu

NCM Main Menu

S) shelf/slot

[ ]

) designates the location

[ ][ ]

option S (shelf/slot) is used to

shows a DPRI 2922 (designated

command, the curren tly

[ ]

) has been

[ ][ ]

NNNN

3-2 Verilink DPRI 2922

Figure 3-1 NCM Main Menu

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Firmware Version and Date of Release

Node Addre ss

Access Level (1-4)

Menu Heading Area

Node “Map” (Physical Location of Modules)

Module Key

Command List

Active NCM Master Designator

-- VERILINK NCM CONTROLLER : FW Rev 4.15, Dec 13 1997 12:53:30 - Site Name: Verilink Test Access Level: 2 Managing at NEAR end node [127.255.255.0] Node ID: 0 <- SLOT -> SHELF 1 2 3 4 5 6 7 8 9 10 11 12 13 0 - - - - - - - - - - - - 1 D *N [P] 2 - - - - - - - - - - - - 3 - - - - - - - - - - - - 4 - - - - - - - - - - - - KEY: A=DIDCSU, B=DIU/DBU, C=CSU, D=DIU, E=SDIU, F=DIU/DDS, G=DHDM, H=ATM/IMUX, I=IDCSU, J=PEP, K=DAC, L=HLM, M=IMUX, N=NCM, P=DPRI, Q=QUAD, R=SUBRATE, S=HSM, T=HDM, U=DCSU, V=VCU, X=QPRI S) shelf/slot O) administration C) configuration D) diagnostics P) performance/status A) alarm B) circuit manager I) manufacturing info X) exit this screen A [127.255.255.0] [1,1] DPRI 2922 >

Node Address

Indicator for the type of shelf: M= Multi-line, D = Dual-line

❶

Asterisk indicates that the NCM is the Main Controller in the shelf

❷

Brackets around module letter ( [P] ) indicate current module selected

❸

❶

❷❸

Data (Command) Entry Area

The node master is the module responsible for:

•

Collecting alarm information for the node.

•

Controlling the relay responsible for reflecting the node’s alarm status. (The relay is activated if any module is in major or critical alarm status. See the NCM 2000 User Manual.)

•

Controlling circuit builder.

Menus and reports are available for the DPRI 2922 via the NCM 2000 by using the S (shelf/slot) option of the

NCM Main Menu

select a DPRI module.

Verilink DPRI 2922 3-3

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Shelf and Slot Parameters

To access a DPRI module from the

Main Menu

, enter S to specify

the Shelf/Slot address.

•

If the module slot address is al ready on the current shelf,

enter the slot number, then press

•

If the module slot address is on a different shelf, enter the

NTER

shelf number followed by a comma and then the slot number

(e.g.,

Table 3-1 Shelf/Slot Designation

Command Description Options

S Shelf: Use this field to select the shelf containing the DPRI 2922 you

want to access. Slot: Use this field to select the slot containing the DPRI 2922 you want

to access.

) then press

1,3

NTER

0–4

1–13 (Multiline) 1–2 (Dual-line)

NCM/DPRI 2922 Main Menu Commands

Once the DPRI module has been selected, the commands pertain to that module. The following commands are available on the

Main Menu

(Figure 3-1) to manage the DPRI 2922:

Main Menu

Table 3-2 Main Menu Commands

Command Description

S Shelf/slot: Using this command, you can navigate from one card to another, Table 3-1. O Administration, Figure 3-2, Table 3-3. C Configuration, Figure 3-3, Table 3-4. D Diagnostics, Figure 3-18, Table 3-16.

P Performance/Status, Figure 3-21, Table 3-18. A Alarm—Figure 3-25,Table 3-21.

B Circuit mana ger—Figure 3 -28, Table 3- 23. For mo re infor mation on this op tion, see the

User Manual

I Manufacturing Info—Displays the firmware and hardware version information for the

appropriate card, Figure 3-33.

X Exit—System log-off, Figure 3-34.

NCM

3-4 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Administration Menu

When the shelf/slot address for the DPRI 2922 is selected from the

NCM Main Menu Main Menu

2922. Command O displays the

Menu’s DPRI 2922 Card Administration Submenu

Figure 3-2 NCM Controller Administration Menu (DPRI 2922 Card Administration Submenu)

-- NCM CONTROLLER ADMINISTRATION MENU -Date/Time/Zone: 80-01-01 17:27:46 Node Address: [127.255.255.0] Node ID: 0 Site Name: System Uptime: 17:25:27

--- DPRI 2922 -- Card Administration -- [01,02] --O) switch over permanent Q) query firmware R) reset card Y) switch over once I) change site name U) clear card configuration X) exit this screen A [127.255.255.0] [1,2] DPRI 2922 >

and the screen is refreshed by pressing

’s prompt displays the shelf/slot address of the DPRI

NCM Controller Administration

NTER

, the

Verilink DPRI 2922 3-5

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Table 3-3 Card Administration Submenu Commands

Command Description Options

O Switch over permanent—This option designates the partition A or B firmware

version when you reboot t he card. Assign a permanen t partition to b oot from in case of power failure. Before choosing a partition, ensure that a firmware version exists on both partitions using the Query Firmware command below.

Q Query Firmware—Use this option to display the firmware versions and their

R Reset Card—This option reboots the module. Y Switch Over Once—Use this option when testing new firmware versions to

I Change Site Name—Use this option to specify the site name for the DPRI.

U Clear Card Configuration —This option cle ars the config uration of the car d and

X Exit this Screen—Returns you to the Main Menu, Table 3-1.

status for the A and B flashbanks (unless a flashbank is empty).

change from partition A to B or vice versa. The next time you reboot, the module will use the original partition/flashbank. Though you can use this option for diagnostics, y ou should neverth eless indicate a permanent partiti on to boot from in case of power failure.

Limited to 19 viewable characters. All reports will contain this information which—in case of a problem—will help to identify the module location.

returns it to the default settings.

[0.0.0.5] [1,2] DPRI 2922 > u

[0.0.0.5] [1,2] DPRI 2922 > u[0.0.0.5] [1,2] DPRI 2922 > u Clear card configur ation on shelf 1 slot 2 (Y/N)? y

Clear card configur ation on shelf 1 slot 2 (Y/N)? y

Clear card configur ation on shelf 1 slot 2 (Y/N)? yClear card configur ation on shelf 1 slot 2 (Y/N)? y Card configuration cleared

Card configuration cleared

Card configuration clearedCard configuration cleared

NOTE: Use with Caution!

1) A

2) B

1) A

2) B

Yes or No (Y/N)

Configuration Menu

Typing the command C from

Configuration Menu

used to configure th e T1 port, data port, or ISDN PRI options.

Figure 3-3 Configuration Menu

[0.0.0.5] [1,2] DPRI 2922 > c

-- DPRI 2922 CONFIGURATION MENU -P) T1 port D) data port I) ISDN PRI X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

Table 3-4 Configuration Menu Commands

Command Description

P T1 port—Displays the DPRI 2922 T1 Port Configurati on Menu, Figure 3-4, Ta ble 3-5.

D Data port—Displays the Data Port Con figuration Menu, Figure 3-8, Table 3-9.

I ISDN PRI—Displa ys the PRI Configuration Menu, Figure 3-10, Table 3-10.

X Exit this Screen—Returns you to the Main Menu, Table 3-1, Table 3-2.

. This menu provides access to the menus

Main Menu

displays the

DPRI 2922

3-6 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

T1 Port Configuration Menu

To access the

Configuration Menu

To change a port configuration, enter t he command followed by the

T1 Port Configuration Menu

port number. For example, to remove port 2 from service, In, enter

I2 (n

is a variable that identifies the port number).

Figure 3-4 DPRI 2922 T1 Port Configuration Menu

[0.0.0.5] [1,2] DPRI 2922 > p

-- DPRI 2922 T1 PORT CONFIGURATION MENU - PORT 1 PORT 2 In) In Service YES YES Fn) Frame Format ESF ESF Ln) Line Coding B8ZS B8ZS Bn) Line Build Out 0db 0db NDn) Network Density NONE NONE NLn) Network Initiated Loop YES YES An) Alarm Declare Time(sec) 1 1 DLn) FDL Enable YES YES PRM Enable YES YES En) Enable Inband/ISDN Inband ISDN Sn) Inband Timeslot 1 1 F) FDL configuration T) Timing X) Exit this screen

, enter P from the

Following is a brief description of the T1 port configuration parameters:

Table 3-5

Command Description Options

T1 Port Configuration Menu Commands

In Service: Use this option to place the port in service. Yes or No

Frame Format: Choose SF (Superframe) or ESF (Extended Superframe Format) as dictated by what your installation supports.

recommended.

SF provides traffic signaling and framing. It is sometimes referred to as D4.

Caution: Setting the framing to SF renders other parameters—such as FDL, below inoperative.

ESF provides cyclic redundancy check, performance monitoring, data checking, and link bits (Facility Data Link, or FDL).

Select SF for installations not supporting ESF.

ESF is

(Y/N)

1) SF

2) ESF

Verilink DPRI 2922 3-7

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Command Description Options

Line Coding: Use this option to choose Alternate Mark Inversion (AMI) or Bipolar Eight-Zero Substitution (B8ZS) as dictated by your T1 facility.

B8ZS is a protocol that replaces eight consecutive Zero bits with two intentional bipolar violations (BPVs) that are not counted as errors by the B8ZS equipment. B8ZS enables each DS0 to transmit at 64 kbit/s with unlimited zeros. This option overrides any selected network density enforcement.

AMI is a T1 signal in which successive Ones (pulses) alternate in polarity and in which Zeros (spaces) are of zero amplitude. AMI is the original T1 line format that does not support long strings of zeros. Normally, this option is used in conjunction with the network density enforcement option.

If the T1 facility experiences pattern sensitive errors or constant dribbling errors, verify that the unit is not mis-optioned for AMI. The intentional errors inserted by B8ZS equipment cannot be decoded by the AMI equipment.

AMI requires use of an ISDN inverted D-channel. Line Build Out: Line Build-Out is the signal strength used by the CSU and is

calculated by considering the length of the cable connecting the first line repeater and the CSU. It is the db loss inserted to compensate for transmitting levels to first repeaters w hen no network i nterface is in volved. Choose one of the following options:

0 db: if the repeater is between 2000 and 3000 feet from the CSU, or if you are using a network int erface unit (smart jack) used by m os t pho n e companies.

-7.5 db: if the repeater is between 1000 and 1999 feet from the CSU.

This is the recommended option for IS DN.

1) AMI

2) B8ZS

1) 0 db

2) -7.5 db

3) -15 db

4) -22.5 db

-15 db: if the repeater is between 250 and 999 feet from the CSU.

-22.5 db: if the repeater is between 0 and 249 feet from the CSU. Network Density: Use this option to specify the type of network density

enforcement to use with PRI line coding. Digital transmissions over public switched telephone network lines cannot support long strings of zeros (repeaters and clocking devices lose synchronization). Therefore, the density algorithms ensure that a minimum pulse density is met to ensure stable system timing.

Choose one of the following if using 64K AMI. Note that these options are ignored with B8ZS line code:

None: does not ins ert a o ne.

Also recommended for ISDN capability.

80 zeros: inserts a one i nto ever y stri ng of more th an 8 0 cons ecuti ve zeros. 15 zeros: inserts a one i nto ever y stri ng of more th an 1 5 cons ecuti ve zeros.

12.5% & 80 zeros: inserts a one into every string of eight or more consecutive zeros when the avera ge d ensity of ones fal l below 12 .5 % or if there are more than 80 consecutive zeros.

TR 62411: inserts a one in to ev ery string of more than 15 consecutive zeros or when there are less than a minimum number of N ones in every window of 8(N+1) data bits (12.5%). N can be any value from 1 to 23. This option is the same as 12.5% + 15 zeros.

Network Initiated Loop: Use this option to specify if you wish to allow your

DPRI to be remotely put into a line loopback.

Use this option with B8ZS or a 56K channel.

1) NONE

2) 80 zeros

3) 15 zeros

4) 12.5% & 80 zeros

5) TR 62411

Yes or No (Y/N)

3-8 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Command Description Options

Alarm Declare Time (sec): Use this option to indicate how many seconds will elapse before a message regarding a problem is displayed.

FDL Enable/PRM Enable: Facility Data Link (FDL). The ESF Facility Data Link

is used to transmit performance registers and controls, error events, and loopback controls. The FDL uses 4 kbit/s of bandwidth to transmit messages. This option only enables or disables the FDL. It only reports if you have the Performance Report Message Command/Response (PRM C/R) bit enabled or dis ab l ed . To ch ange this option’s status or configuration, select the FDL Configuration command ( option.

Note: Enabling this option is meaningless for ports in SF mode. Enable Inband ISDN: Turns on access to one of the channels in the option

fields for inband communication. To receive and tran smit r emote configuration a nd diag nostic infor mation, the channel has to be enabled o n both ends.

This command is used to enable an inband channel or ISDN D-channel, or disable both. An inband channel uses a timeslot (DS0) to send and rec iev e remote configuration and diagnostic information. An ISDN D-channel is used for ISDN call set-up and other messages. Both ends must have the same option selected.

implementing this command.

Inband Timeslot: Select one of the 24 timeslots for inband management before enabling the inband ISDN as described above. ISDN normally uses timeslot 24 for this function.

Select the Inband Timeslot option below before

) and use the Cn (PRM C/R bit)

0..127 seconds

Yes or No (Y/N)

1) Inband enable

2) ISDN enable

3) Both disable

1-24

F FDL Confi guration: Brings up a submenu of choic es. Figure 3-5, Table 3-6.

Note: This option and associated submenus are meaningless for ports in SF mode.

T Timing: This brings up the C onfiguration Menu (Timin g Options), Figure

3-6, Table 3-7.

X Exit this Screen: Returns you to the Configuration Menu, Figure 3-3, Table

3-4.

When finished configuring the T1 network ports, enter X until you

Configuration Menu

FDL Configuration

Submenu

return to the

Facility Data Link is an ESF T1 port configuration option. The ESF FDL transmits performance information, error events , an d loopback controls. FDL uses 4 kbit/s of bandwidth to transmit data. To use FDL, ensure that ESF framing format has been selected.

From the

Configuration Submenu

NOTE: This option and associated submenus are me aningless for ports in

T1 Port Configuration Menu

SF mode.

, choose F to display the

FDL

Verilink DPRI 2922 3-9

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Figure 3-5 Configuration Submenu (FDL Options)

[0.0.0.2] [1,2] DPRI 2922 > f

-- DPRI 2922 CONFIGURATION MENU (FDL OPTIONS)- PORT 1 PORT 2 Sn) FDL Standard T1.403 T1.403 Mn) FDL Mode TERM TERM Pn) Poll Mode NO POLL NO POLL Cn) PRM C/R bit NONE NONE In) Idle Pattern FLAGS FLAGS An) Send/Rec LLB BOP YES YES Bn) Send/Rec PLB BOP YES YES X) exit this screen [0.0.0.2] [1,2] DPRI 2922 >

Table 3-6 Configuration Submenu (FDL Options) Parameters

Command Description Options

Sn FDL Standard: Specify the Bellcore 54016 standard, the ANSI T1.403

Mn FDL Mode: Specify TERM (Terminated) to end the FDL transmission at this

Pn Poll Mode: Specify how the FDL will poll for alarms at the far end.

Cn PRM C/R bit: Performance Report Message Command/Response as defined

In Idle Pattern: Select the idle pattern code for when there is no user data on

standard, or both.

node. Specify Pass to have the FDL transmission to continue to another

Currently, Pass is not applicable for 2 network ports.

node.

Poll: This has the near-end CSU automatically poll th e far-end CSU for al arms every 4 seconds and report these alarms.

No Poll: This disables alarm polling at both ends. Select this option when the nodes at both ends are connected and both nodes report local alarms.

Unsolicit: This has the far-end automatically send its alarm status (when it detects an LOS) to the near-end. Select this option for far-end CSU circuit element when the near-end CSU is set to Poll.

in the ANSI T1.403 specification. Specify USER to set the bit to 0, indicating that you are the PRM source

terminal. Specify TELCO to set the bit to 1, indicating that the phone company is the PRM source. Phon e com panies usually set it to TELCO; nonphone companies set it to USER. To disable this option, choose NONE.

the net. Depending on your network, select either All-Ones or Flags. The signal is transmitted continuously until a message is sent. Once the message completes transmission, the line reverts to the signal chosen:

1) TR54016

2) T1.403

3) BOTH

1) TERM

2) PASS

1) POLL

2) NO POLL

3) UNSOLICIT

1) NONE

2) USER

3) TELCO

1) ALL ONES

2) FLAGS

All-Ones is a signal on an FDL composed entirely of ones: 11111111. Flags is a signal on an FDL consisti ng of 01111110.

An Send/Rec LLB BOP: This option enables the Line Loopback Bit-Oriented

Protocol (LLB BOP) to use FDL loopbacks for testing the T1 line.

Bn Send/Rec PLB BOP: This option enables the Payload Loopback Bit-Oriented

Protocol (PLB BOP) to use FDL loopbacks for testing the far-end CSU.

X Exits the FDL Configuration menu and return to the T1 Port Configuration

Menu, Figure 3-4, Table 3-5.

3-10 Verilink DPRI 2922

Yes or No (Y/N)

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Configuration

Menu (Timing

Options)

To access the

T1 Port Configuration Menu

the

Configuration Menu ( Timing Opt ions)

, Figure 3-4.

, enter T from

Use this menu to determine the transmit timing source of the DPRI modules. If the DPRI module derives its timing from another card in the shelf, enter the slot of the module to be the timing source. This includes the option of setting the DPRI as the timing source for the shelf.

Select primary, secondary, and tertiary timing sources. The secondary and tertiary timing sources provide a backup for the primary timing source. The Auto Restore option determines which timing source is used when the primary timing source fails, restores, and then remains viable for a period of 60 seconds.

If the primary source fails, the secondary source becomes the timing source. When the primary source recovers and the Auto Restore option is set to “Yes”, the primary source resumes service as the DPRI module’s timing source. If the Auto Restore option is set to “No”, the secondary source remains the timing source until you manually reconfigure the primary source, or set its Auto Restore option to “Yes”.

NOTE: For ISDN, the network ALWAYS supplies a clock that MUST be the

source.

Figure 3-6 Configuration Menu (Timing Options)

-- DPRI 2922 CONFIGURATION MENU (TIMING OPTIONS)-Current card timing source: INTERNAL (PRIMARY) Source Synchronization Auto Restore PRIMARY PS) NET1 PA) YES SECONDARY SS) NET2 SA) YES TERTIARY TS) INTERNAL TA) NO R) Receive clock from shelf: NO X) exit this screen [1,2] DPRI 2922 >

For ISDN, you must provide shelf timing derived from the ISDN PRI span. All cards with dial-backup must use shelf timing. Set the secondary timing source for the second ISDN port, if used (otherwise set it to internal). The following options are valid if you specified “No” to “Receive Clock from Shelf”:

Verilink DPRI 2922 3-11

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Table 3-7

Command Description Options

PS Primary Synchronization: Choose one of the following as your primary source

SS Secondary Synchronization: Use this option to specify an alternate source of

Configuration Menu (Timing Options)

for clock synchr onization. Net 1: Use this option to synchronize timing to T1 Port 1. Net 2: Use this option to synchronize timing to T1 Port 2. External: Use this option if you want to use an external clock as your timing

source. Internal: Use this option if you want to use the internal clock as your timing

source. Data 1: Use this option to synchronize timing to the Data Port 1 TT signal. Data 2: Use this option to synchronize timing to the Data Port 2 TT signal.

timing for synchronization. If the p rimary source is unavailable, this source will be used.

Net 1: Use this option to synchronize timing to T1 Port 1. Net 2: Use this option to synchronize timing to T1 Port 2. External: Use this option if you want to use an external clock as your timing

source. Internal: Use this option if you want to use the internal clock as your timing

source. Data 1: Use this option to synchronize timing to the Data Port 1 TT signal.

1) NET 1

2) NET 2

3) EXTERNAL

4) INTERNAL

5) DATA 1

6) DATA 2

1) NET 1

2) NET 2

3) EXTERNAL

4) INTERNAL

5) DATA 1

6) DATA 2

Data 2: Use this option to synchronize timing to the Data Port 2 TT signal.

TS Tertiary Synchronization: Use this option to specify an alternate source of

timing for synchronization. If the prim ary and secondary sources are unavailable, this sourc e will be used.

Net 1: Use this option to synchronize timing to T1 Port 1. Net 2: Use this option to synchronize timing to T1 Port 2. External: Use this option if you want to use an external clock as your timing

source. Internal: Use this option if you want to use the internal clock as your timing

source. Data 1: Use this option to synchronize timing to the Data Port 1 TT signal. Data 2: Use this option to synchronize timing to the Data Port 2 TT signal.

PA Primary Auto Restore: Indic ate

automatically if the clock in the node fail s. Otherwi s e, choose No. Setting up auto restore returns timing to a higher priority source after a failure. If you have not set up auto restore to the primary source, but you have indicated a secondary source, after rebooting the module uses the latter source to restore timing to the module or shelf.

SA Secondary Auto Restore: Indicate

preference automatically if the clock in the n ode fails . Otherwise, choose No. Specifying a s eco ndar y s our ce f or c lo cking is usef ul if pow er fail s and c aus es failure of the primary automatic restore source. Restoring from a secondary source may take up to 60 seconds.

Yes

to resynchronize to your c lock preferenc e

Yes

to resynchronize to your clock

1) NET 1

2) NET 2

3) EXTERNAL

4) INTERNAL

5) DATA 1

6) DATA 2

Yes or No (Y/N)

3-12 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Command Description Options

TA Tertiary Auto Resto re: Indicate

automatically if the clock in the node fails. Otherwise, choose No. Specifying a tertiary source for cloc kin g is usef ul when power loss results in failure of the primary and secondary sources for automatic restore. Restoring from a tertiary source may take up to 90 seconds.

R Receive Clock from Shelf: Use this option to indicate the DPRI receives the

timing signal from another module in the shelf or from an on-board timing source.

Note: Changing this option will change the Conf iguration Menu (Timing Options) display the next time it is refreshed

X Exit the Timing Options screen and return to the T1 Port Configuration

Menu, Figure 3-4, Table 3-5.

Yes

to resynchronize to your clock pr eference

, Figure 3-6 and Figure 3-7.

If you enable “Receive Clock from Shelf” (which is what you should do if you plan on using the module’s ISDN and dial-backup features) the following options display:

Figure 3-7 Configuration Menu (Timing Options) for Receive Clock from Shelf Option

-- DPRI 2922 CONFIGURATION MENU (TIMING OPTIONS)-Current shelf timing source: Card 2, INTERNAL (PRIMARY) Source Slot Number Synchronization Auto Restore PRIMARY PC) 2 PS) NET1 PA) YES SECONDARY SC) 2 SS) NET2 SA) YES TERTIARY TC) 2 TS) INTERNAL TA) NO R) Receive clock from shelf: YES X) exit this screen [1,2] DPRI 2922 >

Additional parameters because Receive Clock From Shelf Option selected is YES.

Yes or No (Y/N)

Following is a brief description of the additional timing parameters shown for “Yes” for the “Receive Clock from Shelf” timing option:

Table 3-8

Command Description Options

PC Primary Module Slot Number: This option selects the module providing the

SC Secondary Module Slot Number: This option selects the module providing

TC Tertiary Module Slot Number: This option selects the module providing the

Configuration Menu (Timing Options), Receive Clock From Shelf

primary timing source.

the secondary timing source.

tertiary timing source.

R Receive Clock from Shelf: This option selects whether the DPRI will receive

its timing signal from another module in the shelf, or from an on-board timing source.

Note: Changing this option will change the appearance of the Configuration Menu (Timing Options) the next time it is displayed, Figure 3-6 and Figure 3-7.

X Exit the Timing Options menu and return to the T1 Port Configuration

Menu, Figure 3-4, Table 3-5.

Enter module (slot) number

Yes or No (Y/N)

Verilink DPRI 2922 3-13

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Recommended settings for timing when the DPRI 2922 is being used for ISDN dial-backup are:

Source Synchronization Auto Restore

Primary PRI Slot Net 1 YES Secondary PRI Slot Net 2 YES Tertiary PRI Slot Internal NO

When finished configuring the timing options, enter X until you return to the

Main Menu

3-14 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Data Port Configuration

To access the

Configuration Menu

Figure 3-8 Data Port Configuration Menu

[0.0.0.5] [1,2] DPRI 2922 > d

-- DPRI 2922 DATA PORT CONFIGURATION MENU - PORT 1 PORT 2 In) In Service NO NO Mn) Data Port Mode DCE DCE Cn) Clock Option ST ST Ln) Control Line Indicator LOW LOW SRn) DSR/LOW DSR/LOW SSn) CTS/LOW CTS/LOW SDn) DCD/LOW DCD/LOW SMn) TM /LOW TM /LOW DTR/LOW DTR/LOW

Port

Status

RTS/LOW RTS/LOW LLB/LOW LLB/LOW RLB/LOW RLB/LOW DPL Loopback DISABLE DISABLE Test Pattern NONE NONE Test Error Counter 0 0 X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

Data Port Configuration Menu

, Figure 3-3.

, enter D from the

Table 3-9

Command Description Options

Data Port Configuration Menu Commands

In Service: Use this option to place the port in service. Yes or No

(Y/N)

Data Port Mode: Use this option to select one of the following: Data Terminal Equipment (DTE): if the equipment connected to the DPRI is a

DCE, then the Data Port Mode is DTE. Data Circuit-terminating Equipment (DCE): if the equipment connected to the

DPRI is a DTE, then the Data Port Mode is DCE. DCE is the default setting.

1) DTE

2) DCE

Verilink DPRI 2922 3-15

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Command Description Options

Clock Option: Use this option to select one of the following: Serial Transmit (ST): In this mode, the normal non-inverted phase of the Serial

Clock Transmit (SCT) is used to clock data from the DTE into the DPRI module’s data port transmit buffer. This is the default setting.

Inverted Serial Transmit (INV ST): In this mode, the inverted phase of the SCT is used to clock data from the DTE into the DPRI module’s data port transmit buffer—when compensating for phase delays (caused by using long cables) an d when the far end is receiving bit errors. TT is a better alternative.

Terminal Timing (TT): In this mode, Serial Clock Transmit Extension (SCTE) is used to clock data from the DTE into the DPRI module’s data port transmit buffer. Normally, this clock is looped by the DTE from the SCT signal. It is the preferred timing method because the transmit clock and data are alw ays in sync regardless of cable length. Unfortunately, this signal is not provided by all DTE equipment. Set this option in tail-circuit timing applications (when the data port receives timing from another circuit).

Control Line Indicator (On E1 networks only): Use this option in the data port interface for flow control. LOW indicates that the port’s signal follows the DTE signal. HIGH indicates that the port’s signal is always on.

Data Set Ready (DSR): This is a DCE control lead. LOW indicates the port signal

follows the DTR signal. HIGH indicates the port si gnal is always on. Data Terminal Ready (DTR): This is a DTE control lead.

Clear to Send (CTS): This is a DCE control lea d . Request to Send (RTS): Thi s is a

DTE control lead. LOW indicates the port signal follows the RTS signal. HIGH indicates the port signal is always on.

1) ST

2) INV ST

3) TT

1) LOW

2) HIGH

1) LOW

2) HIGH

1) LOW

2) HIGH

X Exit the Data Port Configuration menu and return to the Configuration Menu,

Data Carrier Detect (DCD): This is a DCE control lead. LOW indicates this signal

follows the state of the network port to which the data port is attached. HIGH indicates the port signal is always on.

Test Mode (TM): This is used with a test set for diagnost ic s, an d it sh ould

normally be configured as LOW. This is a DCE control lead.

Figure 3-3, Table 3-4.

One of the functions of the

Data Port Configuration Menu

the communication handshake leads between the DPRI data port and your equipment (DTE).

•

When the leads are set to “LOW”, DCE signals follow DTE signals during handshaking.

•

When the leads are “HIGH”, the signal is always on, always ready.

Note that the lead options swap inputs and outputs between the DCE or DTE data port modes.

There are three controllable diagnostic leads at the data port (which are set up via the

•

RLB—Remote Loopback

•

LLB—Local Loopback

Data Port Dia g nost ics M enu

1) LOW

2) HIGH

1) LOW

2) HIGH

is to set

, Figure 3-20):

•

TM—Test Mode.

3-16 Verilink DPRI 2922

Figure 3-9 Loopbacks

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

During normal operation, these leads should be set to LOW. By connecting a test set to the data port, th e RLB and LLB lea ds can be forced HIGH individually. Resulting loopbacks are shown in the following diagram. The status display changes to HIGH for these leads.

NOTE: These leads are o nly useful in DCE mode.

In DTE Mode

DTE

LLB

T1/E1

N1P1

1-12

13-24

N2P2

Nea Far

•

In DCE mode, the leads TM, DSR, DCD, and CTS can be forced

RLB

DPRIDPRI

DTE

HIGH while conn e ct e d to a te s t set to ch e ck that each lead is operating properly.

•

In DTE mode, the leads DTR, RTS, LLB, and RLB can be forced HIGH while conn e ct e d to a te s t set to ch e ck that each lead is operating properly.

In Figure 3-8, the parameters enclosed in the grey box are port status listings. The first four lines show the state of the incoming handshake leads. “HIGH” means incoming handshake signals are detected on that lead, and “LOW” means no handshake signaling is detected. In DCE mode, if the TM lead is “HIGH,” the data port is in test mode, whereas in DTE mode, it indicates the state of the equipment. DPL Loopback shows whether a data port loopback has been enabled or disabled (in the Data Port Diagnostics Menu). If a test pattern has been enabled in the Data Port Diagnostics Menu, “QRSS” (Quasi-Random Signal Sequence) is displayed in this field and the number of errors detected by the test is displayed by the Error Counter.

ISDN PRI Configuration Menu

When finished configuring the data ports, enter X to exit.

To access the

Configuration Menu

•

Use the PRI port configuration option to assign ISDN-specific

PRI Configuration Menu

, Figure 3-3.

, enter I from the

parameters and ISDN network parameters.

Verilink DPRI 2922 3-17

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

•

Configure call profiles to define the routing characteristics for incoming and outgoing phone calls.

•

Configure the incoming and outgoing call numbers to be used for ISDN security checks.

•

Examine the 15-minute and 24 -hour performance characteristics for the ISDN PRI framing, protocol, and call setups.

Figure 3-10 PRI Configuration Menu

A [127.255.255.0] [1,2] DPRI 2922 >i

-- DPRI 2922 CONFIGURATION MENU -P) PRI Port Configuration C) PRI Call Profile A) PRI Statistics X) exit this screen A [127.255.255.0] [1,2] DPRI 2922 >

Table 3-10

Command Description

Figure 3-11 PRI Port Configuration Menu

[0.0.0.5] [1,2] DPRI 2922 > p

-- DPRI 2922 PRI PORT CONFIGURATION MENU - PORT 1 PORT 2 In) PRI In Service No No Fn) NFAS Mode No NFAS No NFAS Dn) D-Channel Mode Normal Normal Bn) D-Channel Bits 8 bits 8 bits Sn) Switch Type DMS 100 DMS 100 Pn) Own Numbering Plan ISDN-E.164 ISDN-E.164 Nn) Own Numbering Type National National En) Security Level No checks No checks Ln) L2 auto establish No No X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

PRI Configuration Menu Commands

P PRI Port Configuration—Displays the PRI Port Configu ration Menu, Figure 3-11, Table 3-11. C PRI Call Profile—Displays the PRI Call Pro fil e C onf iguration Menu, Figure 3-12, Table 3-1 2. A PRI Statistics—Displays the PRI Per formance/Statistics Menu, Figure 3-15, Table 3-15.

X Exit to the Configuration Menu, Figure 3-3, Table 3-4.

PRI Port

Configuration

To access the from the configure the characteristics of the specified port for PRI handling.

PRI Port Configuration Menu

PRI Configuration Menu

, Figure 3-11, enter P

, Figure 3-10. Use this menu to

3-18 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Table 3-11

Command Description Options

In PRI In Service—ISDN stack on or off. Yes or No

Fn NFAS Mode—Non-Facil ities Associated Signalling. Only availabl e on Port 1.

Dn D-Channel Mode—The D-channel bit pattern can be inverted.

PRI Port Configuration Menu Commands

Makes both T1 channels mapable from the Port 1 D-channel. D-channel of Port 1 would provide call control for both PRI ports formi ng 47B+D.

Note: This feature must be ordered with your ISDN service.

To activate NFAS Mode: Use T1 Port Configuration Menu, Figure 3-4, to put T1 Ports 1 and 2 out of

service. Deactivate both ISDN stacks—Port 1 and Port 2. Select NFAS on Port 1 via the PRI Port Configuration Menu (command F1). Reboot the module (You will be prompted to ensure that you really want to

do this). Put Ports 1 and 2 back into service via the T1 Port Configuration Menu. Reactivate the ISDN stacks on

D-channel if AMI is selected in the T1 Port Configuration Menu, Figure 3-4.

For B8ZS select “Normal”

Port 1 ONLY

(only allowed on Port 1).

Use Inverted

(Y/N)

1) No NFAS

2) NFAS

1) Normal

2) Inverted

Bn D-Channel Bits —S ign al lin g bit sel ecti on. If using AMI, select “7 bits”. For

B8ZS, select “8 bits”.

Sn Switch Type—Enter the type of switch used by your ISDN carrier. There are

other options which are not supported.

Pn Own Numbering Plan—Enter the numbering plan recommended by your

ISDN carrier and according to your co rporate network plan. ISDN-E.164 is typically Class 4, Europe.

Telephony-E.163 is typical ly C lass 5, U.S. U.S. Recommended Plans:

< 7 digits—Private 7 digits—Private or Telephony 10 digits—Private, Telephony, or ISDN-E.164 >10 digits—ISDN-E. 164

Nn Own Numbering Type—Enter the type of numbering used by your ISDN

carrier and according to your network requirements. U.S. Recomme nd ed Ty p es :

< 7 digits—Unknown or Local 7 digits—Local 10 digits—National >10 digits—International

1) 8 bits

2) 7 bits

3) 6 bits

4) exit

1) unspecified

2) AT&T 4ESS

3) AT&T 5ESS

4) DMS-100

5) NI-2

1) Unknown

2) ISDN-E.164

3) TelephonyE.163

4) Private

1) Unknown

2) International

3) National

4) Local

Verilink DPRI 2922 3-19

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Command Description Options

En Security Level—I f security is enabled, a ny number

table wil l be rejected. For this version of firm ware, use “No Checks” .

Ln L2 Auto Establish—Counts on ISDN CO switch to activate layer two.

is “No”

2 (link layer).

X Exit to the PRI Configuration Menu, Figure 3-10, Table 3-10.

PRI Call Profile

Configuration

. If set to “Yes”, the DPRI module will continually try to establish layer

An ISDN Call Profile defines the network layer information required to build ISDN backup calls. Each circuit build that requires an ISDN

backup circuit must have a call profile reference assigned to it. To access the

enter C from the

PRI Call Profile Configuration Menu

PRI Configuration Menu

NOT

found in the security

port associated with the call profiles to be changed.

Figure 3-12 PRI Call Profile Configuration Menu

[[0.0.0.5] [1,2] DPRI 2922 > c

-- DPRI 2922 PRI CALL PROFILE CONFIGURATION MENU --

1) Port 1 Call Profile 2) Port 2 Call Profile X) Exit this screen [0.0.0.5] [1,2] DPRI 2922 >

1) No checks

2) Check own

3) Check remote

4) Check own and remote

Normal

Yes or No (Y/N)

, Figure 3-12,

, Figure 3-10. Select the

Table 3-12 PRI Call Profile Configuration Menu Parameters

Command Description

1 Port 1 Call Profile—Displays the Port 1 PRI Call Profile Configuration Menu, Figure 3-13,

Table 3-13. 2 Port 2 Call Profile—Displays the Port 2 PRI Call Profile Configuration Menu. X Exit to the PRI Port Configuration Menu, Figure 3-11, Table 3-11.

Port n PRI Call

Profile

Configuration

Figure 3-13 Port 1 PRI Call Profile Configuration Menu (sample)

-- DPRI 2922 PORT 1 PRI CALL PROFILE CONFIGURATION MENU -Ref Own Number Ext Number Bandwidth Direction Status A) Add Call Profile M) Modify Call Profile S) Set Call Action D) Delete Call Profile X) Exit this screen [0.0.0.5] [1,2] DPRI 2922 >

From the selecting 1 or 2 will display a

Port 1.

PRI Call Profile Configuration Menu

, Figure 3-12,

Port PRI Call Profile Configuration

for that particular port. The example below shows that for

3-20 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Table 3-13

Command Description

A Add Call Profile—Displays the PRI Port 1 Add Call Profile Menu, Figure 3-14, Table 3-14.

M Modify Call Profile—Prompts for selection of a call profile to be edited,

S Set Call Action—Prompts for selection of a call profile to define the profile to be set up or

D Delete Call Profile—Prompts for selection of a call profile ID for the call profile to be deleted.

Port n PRI Call Profile Configuration Menu Commands

Port n Enter Call Ref ID (0-0):

then displays the Modify Call Profile Menu. Modify the Call Profile items by selecting the appropriate keys. WARNING: After making changes, remember to select the option,

S) Send Call Profile

or the changes will not be set up.

taken down.

Port n Enter Call Action Ref ID (0-MAX): Port n -- Set Call Action:

1) Setup Call 2) Take Down Call 3) Exit

Port n -- Disable entry number (0-0):

CAUTION 1: The prompt says "disable", but the result is deletion of the entry from the list of call profiles. If you change your mind about deleting a call profile, enter a nonnumeric value at the prompt or enter a carriage return.

CAUTION 2: No confirmation prompt will be displayed when the requested profile is delete d.

X Exit to the PRI Call Profile Configuration Menu, Figure 3-12, Table 3-12.

PRI Port n Add Call Profile Menu

To add a new call profile to the list of existing call profiles for the previously selected port, select A in the

Configuration Menu

. Select the appropriate key for each

parameter. The minimal information required to create a call profile is:

•

Reference ID

•

Direction (incoming/outgoing/both)

•

Number of Own Digits

•

Own Call Number

•

Extension Number of Digits

•

Extension Call Number

NOTE: Acceptance of the call profile does not imply the completeness of the

information required to describe your configuration.

Port n PRI Call Profile

Verilink DPRI 2922 3-21

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

NOTE: After defining a call profil e, remember to select opt ion S, Send Call

Figure 3-14 PRI Port 1 Add Call Profile Menu

[0.0.0.5] [1,2] DPRI 2922 > a

-- DPRI 2922 PRI PORT 1 ADD CALL PROFILE MENU -R) Call Profile Ref 0 D) Call Direction Deleted O) No. of Own Digits 0 N) Own Call Number ---I) Ext Numbering Plan ISDN-E.164 U) Ext Numbering Type International C) Ext No. of Digits 0 P) Ext Call Number ---T) Transfer Mode Unrestricted B) Call Bandwidth B1=64K M) MultiRate Count ---A) Rate Adaption None E) Test Call Interval(min.) 0 S) Send Call Profile X) Exit Screen [0.0.0.5] [1,2] DPRI 2922 >

Profile, or the profile will not be sav ed /cre at ed .

Table 3-14

Command Description Options

D Call Direction—Select whether the call profile is for incoming calls,

O No. of Own Digits—Enter the number of digits in your phone number. Note:

N Own Call Number—Enter your calling phone number. On incoming calls,

PRI Port n Add Call Profile Menu Commands

R Call Profile Ref—Se lec t a reference ID that is distinct from previously used

IDs for the selected port. (Use the modify option to change existing call profiles.)

outgoing calls, or both. “D elete” i nvalidate s the ca ll profi le. We re commend using the “Delete Call Profile” command in the Call Profile Configuration Menu.

If the number is smaller than the length of an existing string associated below, you will be prompted to confirm whether or not you want to truncate the string. If the response to the prompt is Y, the associated string will be truncated; otherwise, the length will not be accepted.

this number equals “DNIS”. On outgoing calls, this number is delivered as “CLID” or “Station ID”. Note: If the entered string exceeds the associated length above, the string will be truncated.

I Ext. Numbering Plan 1) Unknown

1 through 48

1) Delete

2) Incoming

3) Outgoing

4) Both 1 through 15

Phone number of string length specified above.

2) ISDN-E1.64

3) TelephonyE-

1.63

4) Private

3-22 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Command Description Options

U Ext. Numbering Type 1) Unknown

2) International

3) National

4) Local

C Ext. Number of Digits—Enter the number of digits in the extension phone

number. Note: If the number is smaller than the length of an existing string associated below, you will be pr ompted to confirm whether or not you want to truncate the string. If the response to the prompt is Y, the associated string will be truncated; otherwise, the length will not be accepted.

P Ext. Call Number—Enter the extension phone number. On incoming calls

this number is the “CLID” or “Station ID”. On outgoing calls, this number is the “DNIS”. Note: If the entered string exceeds the associated length above , the string will be truncated.

T Transfer Mode—Specify “restricted” for 56 Kbit/s transfer rate. Select if AMI

facilities are being used. “Unrestricted” is for 64 Kbit/s (B8ZS) or 56 Kbit/s.

B Call Bandwidth—Use this option to determine the bandwidth for the ISDN

backup circuit.

1) B1 = 64 K

2) H0 = 6 x 64 K

3) H11 = 24 x 64 K (European, or in US—NFAS mode only.)

4) H12 = 30 x 64 K (European only)

5) Multirate = n x 64 K

M MultiRate Count—Produces bandwidth of n x 64 or n x 56 depending on

the adopted rate. Enter this value only if call bandwidth is multirate. Note: Options 8 and 9 should not be selected for T1 units—they are for E1

only. Option 7 is for European (E1) or in US—NFAS mode only.

1 through 15

Phone number of string length specified above.

1) restricted

2) unrestricted

1) B1

2) H0

3) H11

4) H12

5) Multirate

1) 2

2) 4

3) 6

4) 8

5) 12

6) 23

7) 24

8) 30 (European only)

9) 31 (European only)

A Rate Adaption—If you have unrestricted transfer mode (B8ZS) but the far-

E Test Call Interval (min.)—For testing only. This option causes the selec ted

S Send Call Profile—

X Exit to the PRI Configuration Menu, Figure 3-10, Table 3-10.

PRI Performance /

Statistics Menu

end is restricted (A MI), th en s pecif y 56 K r ate a dapti on. T his w ill d epe nd on your application.

call profile to be set up and taken down repeatedly at the intervals specified (zero disables testing).

menu.

Until this option is selected, the menu is only a work sheet and the

configurati o n is

Select this to save your call profile before exiting the

NOT

stored.

To access the

Configuration Menu

PRI Performance/St atistics Menu

, Figure 3-10. The prompt options identify the

types of performance characteristics.

Verilink DPRI 2922 3-23

1) none (same as 64K)

2) 56K 0 through 255

, select A at the

PRI

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Figure 3-15 PRI Performance/Statistics Menu

[0.0.0.5] [1,2] DPRI 2922 > a A [127.255.255.0] [1,2] DPRI 2922 > a

-- DPRI 2922 PERFORMANCE/STATISTICS MENU -Cn) Get Current Interval Dn) Get 24 hr. Interval Rn) Reset Interval X) Exit this screen A [127.255.255.0] [1,2] DPRI 2922 >

Table 3-15

Command Description

X Exit to the PRI Call Profile Configuration Menu, Figure 3-12, Table 3-12.

PRI Performance/Statistics Menu Parameters

Get Current Interval—Displays the Port n PRI 15-Minute Performance Data, Figure 3-16. Press Enter to exit this screen.

Get 24 hr. Interval—Displays the Port n 24-Hour Performance Data Menu, Figure 3-17. Choose an option from this menu to view the related performance summary for the previous 24 hours.

Reset Interval—Resets the performance data counters for the specified port.

Performance data displayed in the following two screens is defined as follows:

•

INFOs rcvd/ x mi t d—Any ISDN Lay e r 2 i nf ormation mes s a g e s received or transmitted.

•

CRC errs recvd—CRC errors in Layer 2 packet.

•

Invld frames rcvd—Invalid frames received—Information message with incorrect header that the link layer cannot decode.

•

Frame aborts rcvd—Frame aborts received—Information message that started with a good frame, but did not end properly.

•

DISCs rcvd/xmitd—Disconnect message received or transmitted.

•

FRMR rcvd/xmitd—Frame error (invalid frame) received or transmitted.

•

L3 protocol errors—Invalid Layer 3 information elements.

•

Unsupported msgs rcvd—Unsupported messages received— Layer 3 messages which cannot be decoded because they are not supported by the module.

3-24 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Figure 3-16 Port 1 PRI 15 Minute Performance Data

---- Port 1 15 MINUTE PERFORMANCE DATA ---- 80-04-01 21:57:05 Site Name: Verilink Test Shelf: 1 Slot: 2 Seconds in current interval: 0 Layer 2 Performance Data INFOs rcvd : 0 INFOs xmitd : 0 CRC errs rcvd : 0 Invld frames rcvd : 0 Frame aborts rcvd : 0 DISCs rcvd : 0 DISCs xmitd : 0 FRMR rcvd : 0 FRMR xmitd : 0 Layer 3 Performance Data L3 protocol errors : 0 Call Performance Data Call setups sent : 0 Call setups sent & failed: 0 Call setups received : 0 Call setups received & failed: 0 Unsupported msgs rcvd : 0 Test call setups sent & failed: 0 Press enter to continue

When the options presented in the following menu are chosen, they display a screen which shows the previous 24-hour performance segmented into 96 15-minute intervals. The number of instances that the particular parameter has occurred during each particular 15-minute interval displays.

Figure 3-17 Port 1 24 Hour Performance Data Menu

-- PORT 1 24 Hour Performance Data Menu -Layer 2 statistics options:

1) INFOs rcvd 2) INFOs xmitd

3) CRC errs rcvd 4) Invld frames rcvd

5) Frame aborts rcvd 6) DISCs rcvd

7) DISCs xmitd 8) FRMR rcvd

9) FRMR xmitd Layer 3 statistics options:

10) L3 protocol errors Call Statistics options:

11) Call setups sent 12) Call setups sent & failed

13) Call setups received 14) Call setups received & failed

15) Unsupported msgs rcvd 16) Test call setups sent & failed X) exit this screen A [127.255.255.0] [1,2] DPRI 2922 >

Verilink DPRI 2922 3-25

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Diagnostics Menu

The data ports. From the

Diagnostics Menu

Figure 3-18 Diagnostics Menu

[0.0.0.5] [1,2] DPRI 2922 > d

-- DPRI 2922 DIAGNOSTICS MENU -P) E1/T1 Port D) Data Port X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

Table 3-16

Command Description

Diagnostics Menu C ommands

P E1/T1 port—This option displays the T1 Po rt Diagnostics Menu, Fig ure 3-19, Table 3-17 D Data port—This option displays the Data Port Diagnostics Menu, Figure 3-20, Table . X Exit this Screen—Returns you to the NCM Main Menu, Figure 3-1, Table 3-2.

is used to troubleshoot the network and

Main Menu

, Figure 3-1, enter D to access the

, Figure 3-18.

T1 Port Diagnostics Menu

For diagnostics on the T1 port, enter P from the Figure 3-18, to access the activates or deactivates loopbacks, and sends test patterns from the network port.

NOTE: If the loopback does not ac tivate, use the T1 Port Configuration

Figure 3-19 T1 Port Diagnostics Menu

-- DPRI 2922 T1 PORT DIAGNOSTICS MENU - PORT 1 PORT 2 Loop type NONE NONE Test Pattern NONE NONE Test Error Counter 0 0 Ln) Line Loop Pn) Payload Loop Rn) Local Loop Tn) Test Pattern An) Send LLB BOP Bn) Send PLB BOP En) Reset Test Counter X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

menu to verify that the port is in service.

Diagnostics Menu

T1 Port Diag nostics Menu

. This menu

3-26 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Table 3-17

T1 Port Diagnostics Menu Commands

Command Description Options

Line Loopback (LLB): This option tests the network line from the far-end node. With Line Loopbacks, incoming signals are looped around and sent

1) DEACTIVATE

2) ACTIVATE back toward the netw ork. The service provider or f ar-end node admini strator can then determine if the network line is good.

CPE

Payload Loopback (PLB): This option tests the DPRI from the far-end node. In this case, the data goes through the networ k line and the DPRI framer before

DPRI Framer

1) DEACTIVATE

2) ACTIVATE it is looped back toward the network.

CPE

Local Loopback (RLB): This option tests all of the DPRI. Also known as a Repeater Loopback, the data sent from the data equipment passes thro ugh

DPRI Framer

1) DEACTIVATE

2) ACTIVATE the DPRI up to the network interface and back to the equipment without passing through the network line.

CPE T1

DPRI Framer

Test Pattern: None: This option indicates that no test pattern will be used. 3 in 24: 3-in-24 Onrs test pattern which consists of three pulses in every 24-

bit sequence (10001000 10000000 00000000). This stress test is useful for testing circuits und er extremely low d ensity conditio ns. This is mos tly useful for T1 AMI.

QRSS: Quasi-Random Signal Sequence that limits the signal to a maximum of 15 zeros that can be transmitted sequentially. These signals contain a

1) NONE

2) 3/24

3) QRSS

-1

4) 2

5) 1/8

-1

6) 2

7) ALL 0’S

8) 55 OCTET

(Daly)

9) ALL 1’S medley of 20-bit words (except for more than 15 consec utive 0s). It repeats every 1,048,575 bits. Also, it contai ns high density sequences and low density sequences, and sequ e n ces that change from lo w density to high density and vice versa (as defined by ANSI T1.403).

-1: Tests circuits for equalization and timing. It is the same as QRSS, but

2 without the 15 zeros restriction.

1/8: This pattern tests the ability of a circuit to support a pattern having the minimum ones density (containing 7 zeros indicating empty pulses and 1 pulse-1000000). It helps discover a timing recovery problem. This is mostly useful for T1 AMI.

-1: This pattern tests circuits for equalization and timing using an

2 alternate pattern for jitter testing. The pattern repeats every 32,757 bits.

All 0s: This pattern is composed entirely of framed ze ros (00000000). It should only be used in conjunc tion with B8ZS (a cl ear channel) for end-toend testing. This is mostly useful for T1 B8ZS.

Verilink DPRI 2922 3-27

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Command Description Options

55 Octet: The Daly 55 octet pattern tests circuits for line card and timing recovery. By rapidl y transition ing from a lo ng seque nce of low de nsity octets to high density octets, the circuit is stress tested. Following is a binary representation of the 55 Octet stress pattern:

1000000010000000100000001000000010000000 10000000 00000001100000001000000010000000 1000000010000000100000001100000010000000 1000000010000000100000001110000010000000 10000000 10000000100000001010101010101010 1010101010101010010101010101010101010101 0101010110000000100000001000000010000000 1000000010000000111111111111111111111111 1111111111111111111111110000000110000000 0000000110000000000000011000000000000001 1000000000000001100000000000000110000000

All 1s: This pattern is composed entirely of framed one s (11111111). It stresses circuits by maximizing power consumption.

X Exit the T1 Port Diagnostics Menu—Returns the screen to the Diagnostics

Send Line Loopback Bit-Oriented Protocol (LLB BOP): This option uses FDL loopbacks to test the T1 from the near-end toward the far-end.

Send Payload Loopback Bit-Oriented Protocol (PLB BOP): This option uses FDL loopbacks to test the CSU at the far-end circuit from the near-end.

Reset Test Counter: This option resets the test counter to 0. The counter is automatically reset when changing patterns.

Menu, Figure 3-18, Table 3-16.

When finished configuring the T1 port diagnostics parameters,

Diagnostics Menu

, Figure 3-18, to access the

. This menu activates or deactivates

Data Port Diagnostics Menu

enter X to return to the

NOTE: To do an LLB BOP or a PLB BOP to the far-end, set the far-end

“Network Initiated Loop” option to “Yes.”

Enter D from the

Diagnostics Menu

Data Port Diagnostics Menu

loops from the data equi pment to the DPRI data port and back to the data equipment, and from the network to the data port and back to the network.

1) DEACTIVATE

2) ACTIVATE

1) DEACTIVATE

2) ACTIVATE

3-28 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Figure 3-20 Data Port Diagnostics Menu

[0.0.0.5] [1,2] DPRI 2922 > d

-- DPRI 2922 DATA PORT DIAGNOSTICS MENU - Data Port 1 Data Port 2 DPL Loopback DISABLE DISABLE Test Pattern NONE NONE Test Error Counter 0 0 Dn) Data Port Loop Tn) Test Pattern Fn) Send FT1 Code En) Reset Test Counter X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

Data Port Diagnostics Menu Com m ands

Command Description Options

Dn Data Port Loopback (DPL)—Tests the channels assigned to the data port (not

the entire T1 bandwidth). The remaining channels, using the circuit builder function, are not affecte d. This is a bi-directional loop (towar d the DTE and network).

Tn Test Pattern—Use this option to select one of the following test patterns.

Note that patterns are always transmitted toward the net, not the DTE: None: This option indicates that no test pattern will be used. QRSS: Use Quasi-Random Signal Sequence that limits the signal to a

maximum of 15 zeros that can be transmitted sequentially. These signals contain a medley of 20-bit words (except for more than 15 consecutive 0s). It repeats every 1,048,575 bits. Also, it contains high density sequences and low density sequences, and sequences that change from low d en sity to high density and vice versa (as defined by ANSI T1.403).

Fn Send FT1 Code—This option sends loop codes in the timeslots being used to

set a data port loop at the remote port.

En Reset Test Counter—This option resets the error counter back to 0. At the

start of a test, this counter is automatically reset.

X Exit the Data Port Diagnostics Menu screen, and return to the Diagnostics

Menu, Figure 3-18, Table 3-16.

1) DEACTIVATE

2) ACTIVATE

1) NONE

2) QRSS

1) Loop down

2) Loop up

When finished configuring the data port diagnostics parameters, enter X to return to the

Performance / Status Menu

Use the condition of the network ports. The parameters in this screen provide counts for the various problems occuring in a given period of time. Performance info rmation is logged in 15 minute intervals over a 24 hour period.

To access the

Performance/Status Menu

, Figure 3-1.

Diagnostics Menu

to monitor the func ti oning and

Performance/Status Menu

Verilink DPRI 2922 3-29

, enter P from the

Main

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Figure 3-21 Performance/Status Menu

[0.0.0.5] [1,2] DPRI 2922 > p

-- DPRI 2922 PERFORMANCE/STATUS MENU - PORT 1 PORT 2 LOS NO YES LOF YES YES AIS Rx/Tx NO/NO NO/NO RAI Rx/Tx NO/YES NO/YES SLIP NO NO CRC6 NO NO BER NO NO CGA YES YES P) display performance data T) threshold status C) display counters X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

Use the

Performance/Status Menu

to monitor the following

functions:

•

LOS—Loss of Signal. A major alarm indicating no receive pulses at all. May be caused by disconnected or miswired network cable. Supercedes all other alarms: Ignore other alarms and troubleshoot this condition first.

•

LOF—Loss of Frame. (No frame synchronization)

•

AIS—Alarm Indication Signal. Unframed all-ones. Red Alarm.

•

RAI—Remote Alarm Indication. Yellow Alarm.

•

SLIP—Indicates variations in clock rate.

•

CRC-6—Cyclic Redundancy Check. Method for detecting biterrors. Used in ESF and ISDN.

•

BER—Bit Error Rate.

•

CGA—Carrier Group Alarm

Table 3-18

Command Description

Performa nce/ Status Menu Comma nds

P Display performa nce data—Displays the totals for the more common errors and alarms, and

provides a menu for more detailed, 15-minute incremented, 24-hour time-period buffer records. Figure 3- 22, Table 3-19.

T Threshold status—Displays the Net Port Alarm Threshold Status Menu, Figure 3-23.

3-30 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Command Description

C Display counters—displays the Counter Menu, Figure 3-24, Table 3-20.

Counts the number of BPV, FE, ESF, and CRC errors: Bipolar Violations (BPV): A violation of the T1 bipolar alternate mark inversion transmission

pattern in which consecutive ONEs (pulses) are erroneously transmitted as pulses of like polarities. Bipolar viol ati o ns norma ll y ind ic ate trans mi ssio n errors.

Frame Bit Error (FE): The number of whole seconds in which a framing bit error has been received.

Extended Superframe Format (ESF): This is the AT&T T1 framing standard that provides frame synchronizatio n, cyclic redundanc y check, data checking, a nd link bits. Th is counter is only available in ESF mode.

Cyclic Redundancy Check (CRC): An error-checking algorithm performed on data transmissions. On a frame-by-frame basis, a numerical value is derived from the data in the bit stream at o ne end of trans mission. When each frame reaches the receive end, th e cy clic redundancy check is calculated again and compared with the value generated by the transmit-side data. Discrepancies can indicate one or more transmission errors. This counter is only available in ESF mode.

Options are: Rn—Reset counters, which resets the counter for the indicated port number. X—Exit this screen, which returns you to the Performance/Status Menu.

X Exit the Performance/Status Menu—Returns to the Main Menu, Figure 3-1, Tabl e 3-2.

Performance / Status Menu (24hr T1 Performance

Select P for “display performance data” from the

Performance/Status Menu

, Figure 3-21, to access the

Performance/Status Menu (24hr T1 Performance Data Summary)

, Figure 3-22.

Data Summary)

Figure 3-22 Performance/Status Menu (24hr T1 Performance Data Summary)

[0.0.0.5] [1,2] DPRI 2922 > p

-- DPRI 2922 PERFORMANCE/STATUS MENU -24hr T1 Performance Data Summary ES BES SES UAS LOF LOSS AISS PORT 1 0 0 1 81342 81340 0 68284 PORT 2 0 0 0 81361 81359 81361 0 En) Errored Seconds Un) Unavailable Seconds Bn) Bursty Seconds Sn) Severely Errored Seconds Ln) LOS Seconds Fn) SEF Seconds Dn) LOF Seconds On) OOF Seconds An) AIS Seconds Cn) Controlled Slip Seconds Mn) Loss of Frame Counts Zn) AIS/SEF Seconds Qn) Errored Seconds Type A Hn) Frame Errors Jn) Degraded Minutes In) Error Free Seconds Rn) Reset Registers X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

Verilink DPRI 2922 3-31

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Table 3-19

Performance/Status Menu (24hr T1 Performance Data Summary) Commands

Command Description

Errored Seconds (ES): A second with one or more AIS, LOS, or LOF defects. Unavailable Seconds (UAS): Counted for ever y sec ond in which an Unavailable Signal State

occurs with the onset of 10 contiguous SES errors. It is also defined as the number of seconds a service is unavailab l e due to a Lo ss of Fra me ( L OF ) co ndition. The UAS condition is stopped when the failure condition clears.

Bursty Seconds (BES): A second having between 2 and 319 CRC-6 (Cyclical Redundancy Check error events.

Severely Errored Seconds (SES): This error counts one se cond intervals with an AIS or CRC error.

Loss of Signal (LOS) Seconds: A second during which the DPRI is in a Loss of Signal state. LOS is declared upon detecting 175 consecutive zeros, it is cleared with the receipt of the next 1 bit.

Severely Errored Framing (SE F) Se conds: Those seconds in which two or more framing bit errors occur withi n a 3-m illis econd p eriod . In ESF mod e, this inte rval may o r may n ot co inci de with an ESF multiframe.

Loss-of-Frame (LOF) Seconds: An LOF alarm is declared when a 3 -second interval of

continuous Out-Of-Frame (O OF) or Loss-Of-Signal (LOS) state is detected. If at least 10 seconds elapse without an LOS or LOF error, the LOF alarm is cl eared.

Out-of-Frame (OOF) Seconds: A condition when any three of four consecutive frame bits

received from the T1 line are incorrect.

Alarm Indication Signal (AIS) Seconds: A count of one-second intervals containing one or more

AIS defects. AIS is an unframed All-Ones bit pattern that indicates an alarm condition exists upstream in a circuit leading to the downstream equipment. This is also called an All-Ones Keep-Alive or Blue Alarm Signal. An AIS defect is declared when there are 3 or fewer zeros in 512 bit times and there is an LOF defect. It is cleared when there are 3 or more zeros in two frames or the LOF defect no longer exists.

Controlled Slip Seconds: This error indicates that in a one second interval one or more slip

events occurred. An accurate count of controlled slips that occur can only be made at the terminating network element where the slips take place.

The current version of the firmware does not support this feature.

Loss of Frame Counts: An accumulation of the number of times a Loss-Of-Frame alarm is

declared.

AIS/SEF Seconds: Displays information on the AIS and SEF errors. AIS: An unframed All-Ones bit pattern that indicates that an alarm condition exists upstream

in a circuit leading to the downstream equipment. Th is is also calle d an All-Ones Ke ep-Alive or Blue Alarm Signal.

SEF: The seconds in which two or more framing bit errors occur within a 3-millisecond period. In ESF mode, this interval may or may not coincide with an ESF multiframe.

Errored Seconds Type A: This error occurs when one Code Violation Path (CV-P) error and no

AIS defects occur in a second. Cont rolled Slips a re not included in this parameter.

Frame Bit Error (FE): An error in the received framing bit pattern and the number of whole

seconds that a framing bit error has occurred.

-6

Degraded Minutes (DM): This error occurs when the Bit Error Rate (BER) threshold of 10

exceeded in a 60 second p eri od.

Error Free Seconds: A second with no detected error s.

3-32 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Command Description

X Exit this screen—Exits the Performance/Status Menu (24hr T1 Performance Data Summary)

Reset Registers: Use this option to clear out all counts and reset all registers to zero for a particular port.

and returns to the Performance/Status Menu, Figure 3-21.

When one of these options is selected, the previous 24 hour data is displayed in 15 minute increments for a total of 96 blocks of time.

NTER

Net Port Alarm Threshold Status Menu

Press

Enter T from the

Net Port Alarm Threshold Status Menu

the screen shows the threshold intervals set in the

Threshold Configuration Menu

to exit these screens.

Performance/Status Menu

, Figure 3-21, to access , Figure 3-23. This

Net Port Alarm

, Figure 3-26.

It also displays the counts for each type of alarm. When the alar m count exceeds its threshold value set in the

Threshold Configuration Menu

Figure 3-23 Net Port Alarm Threshold Status Menu

[0.0.0.5] [1,2] DPRI 2922 > t

-- DPRI 2922 NET PORT ALARM THRESHOLD STATUS MENU -Current Threshold Status PORT 1 PORT 2 LOF counts(exceeded) 0(N) 0(N) interval 0 0 LOS counts(exceeded) 0(N) 0(N) interval 0 0 RAI counts(exceeded) 0(N) 0(N) interval 0 0 AIS counts(exceeded) 0(N) 0(N) interval 0 0 BPV counts(exceeded) 0(N) 0(N) interval 0 0 ES 15min counts(exceeded) 0(N) 0(N) ES 24hr counts(exceeded) 0(N) 0(N) SES 15min counts(exceeded) 0(N) 0(N) SES 24hr counts(exceeded) 0(N) 0(N) Press enter to continue

, a “Y” displays after the count.

Net Port Alarm

Counter Menu

Enter C from the

Counter Menu

the the Rn option.

Verilink DPRI 2922 3-33

Performance/Status Menu

, Figure 3-21, to access

. These counts are continuous until reset using

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Figure 3-24 Counter Menu

[0.0.0.5] [1,2] DPRI 2922 > c

-- DPRI 2922 COUNTER MENU - BPV FE ESF CRC PORT 1 1 0 65535 0 PORT 2 0 0 65535 0 Rn) Reset counters X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

Table 3-20

Command Description

Counter Menu Commands

X Exit this screen—Returns to the Performance/Status Menu, Figure 3-21, Table 3-18.

Reset Counters: Returns the values of the BPV, FE, ESF, and CRC counters to zero or N/A.

Net Port Alarm Menu

To access the

Net Port Alarm Menu

Figure 3-1. Use this menu to set alarm threshold values, monitor alarm status, and set other alarm parameters. All monitored conditions are also reflected by LED states.

Figure 3-25 Net Port Alarm Menu

[0.0.0.5] [1,2] DPRI 2922 > a

-- DPRI 2922 NET PORT ALARM MENU -N) NMS Address 128.0.0.0 A) Card Alarm Reporting YES C) Configure Thresholds S) Alarm status Tn) Set Default Thresholds X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

, enter

from the

Main Menu

Table 3-21

Command Description

Tn Set Default Thresh olds —Resets the module and loads the factory default threshold settings.

3-34 Verilink DPRI 2922

Net Port Alarm Menu Commands

N Network Management System (NMS) Address: This option sets the ACP address (which is the

address of the PC that will receive the alarms). Though this address is significant for Node

Manager, it is not important for the ASCII interface. A Card Alarm Reporting: This option enables or disables the module from sending alarms. C Configure Thresholds: To disable any or all alarm conditions, enter a threshold value of 0.

To enable a condition, specify any non-zero threshold value. Figure 3-26, Table 3-22. S Alarm Status: Displays the Net Port Alarm Threshold Status Menu which shows the counts

and intervals of the LOF, LOS, RAI, AIS , BPV, ES , and SE S registers. Figure 3-27.

X Exit this screen—Returns you to the Main Menu, Figure 3-1.

Net Port Alarm Threshold Configuration Menu

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Performance/Status Menu

The thresholds, while the

enables setting custom alarm thresholds and intervals in

Net Port Alarm Threshold Configuration

reflects the industry T1 stan dard

addition to the above standards. To view and modify the ala rm thresholds, enter C from the

Port Alarm Menu

to display the

Configuration Menu

. Use this menu to set the monitoring interval

Net Port Alarm Threshold

for several types of alarms and the alarm threshold for errored seconds within the monitorin g interval.

For example, if the LOF interval is set to 100 seconds, and the LOF threshold is set to 5 seconds, then an alarm will be sent if more than 5 errored seconds occur during a 100-second interval. The errored count resets to zero after the end of the interval, unless there is an alarm condition, and the first second of the next interval is also errored. The alarm state continues until a new interval contains no errors in the firs t second.

Figure 3-26 Net Port Alarm Threshold Configuration Menu

-- DPRI 2922 NET PORT ALARM THRESHOLD CONFIGURATION MENU - PORT 1 PORT 2 Pn) Alarm Reporting(NET) NO NO Dn) Alarm Reporting(DATA) NO NO Fn) LOF threshold 3 3 LOF interval 3 3 Ln) LOS threshold 3 3 LOS interval 3 3 Rn) RAI threshold 1 1 RAI interval 1 1 An) AIS threshold 1 1 AIS interval 1 1 Bn) BPV threshold 1 1 BPV interval 1 1 En) ES 15min threshold 900 900 ES 24hr threshold 86400 86400 Sn) SES 15min threshold 900 900 SES 24hr threshold 86400 86400 In) BER threshold DISABLE DISABLE X) exit this screen [0.0.0.5] [1,2] DPRI 2922 >

Net

NOTE: To disable any or all alarm conditions, enter a threshold value of 0.

To enable a condition, specify any non-zero thres h old value. The interval must be greater than or equal to the threshold value.

Verilink DPRI 2922 3-35

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Table 3-22

Command Description Options

Net Por t Alarm Threshold Configuration Menu Commands

Alarm Reporting (NET): Enabling alarm re porting conveys any messages indicating al arms fo r each n etwork port. Th ese alar ms ar e declared to bot h the ASCII interface as well as the Node Manager, if used. If this option is set to No, even if alarm reports for individual ports are requested, they are not reported. The LEDs remain amber or red in an alarm condition. Set this option to No while configuring the node; then set to

For any of the Advanced Automatic Protection Switching features—dial backup or other backup options—this parameter MUST be set to Yes.

Alarm Reporting (DATA): Enabling alarm reporting conveys any messages

indicating alarms for each data port. These alarms are declared to both the ASCII interface as well as the Node Manager, if used. If this option is set to No, even if alarm reports for individual ports are requested, they are not reported. The LEDs remain amber or red in an alarm condition. Set this option to No while configuring the node; then set to

For any of the Advanced Automatic Protection Switching features—dial backup or other backup options—this parameter MUST be set to Yes.

Loss-of-Frame (LOF) Threshold/LOF Interval: Use this option to indicate an interval that is greater than the threshold.

Yes

Yes or No (Y/N)

for normal operation.

Yes or No (Y/N)

for normal operation.

Threshold: 1—86400 0 to disable

Interval: 3—86400 seconds

Loss of Signal (LOS) Threshold/LOS Interval: Use this option to indicate an interval that is greater than the threshold.

If LOS occurs, troubleshoot this situation first and ignore all other alarms (There will be other alarms). This is the most severe alarm.

Remote Alarm Ind ic at i o n (R AI) Threshold/RAI Interval : In SF, an RAI consists of Bit 2 of all 24 channels set to zero. In ESF, an RAI is a repeating pattern of eight Ones followed by eight Zeros

transmitted over the ESF Data Link.

Alarm Indication Sig nal (AIS) Threshold/ AIS Interval: Threshold:

Bipolar Violation (BPV) Threshold/BPV Interval: Threshold:

Threshold: 1—86400 0 to disable

Interval: 3—86400 seconds

Threshold: 1—86400 0 to disable

Interval: 1—86400 seconds

1—86400 0 to disable

Interval: 1— 86400 seconds

1—86400 0 to disable

Interval: 1—86400 seconds

3-36 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Command Description Options

X Exit this screen—Returns you to the Net Port Alarm Menu, Figure 3-25, Table

Errored Seconds (ES) 15 min. Threshold/ES 24 hr. Threshold: An ES alarm indicates a second with one or more ESF error events.

Severely Errored Secon d (SES) 15 min. Threshold/SES 24 hr. Threshold: Selec t 15-minute and 24-hour threshold values.

-9

Bit Error Rate (BER) Th resh old: Sele cti ng 10

3-21.

will report more errors than 1 0-4. 1) DISABLE

15 minute Threshold: 1—900 0 to disable

24 hour Threshold: 1—86400 0 to disable

15 minute Threshold: 1—900 0 to disable

24 hour Threshold: 1—86400 0 to disable

2) 10E-4

3) 10E-5

4) 10E-6

5) 10E-7

6) 10E-8

7) 10E-9

Net Port Alarm Theshold Status Menu

To display the

Net Port Alarm Menu

the

Net Port Alarm Threshold Statu s Menu

. This alarm register shows all major and

, enter S in

minor alarms that have occurred at each port. When an alarm is cleared, the time stamp ch anges to reflect the time the alarm was cleared.

This screen only displays information. You cannot change any of the settings displayed via this screen. The settings must be changed using the accessed through the

Net Port Alarm Threshold Configuration Menu

Net Port Alarm Menu

, Figure 3-25, option C.

Verilink DPRI 2922 3-37

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Figure 3-27 Net Port Alarm Threshold Status

[0.0.0.5] [1,2] DPRI 2922 > s

Circuit Manager Menu

To access the Use the

circuit is the path on whi ch data travels between a port at the source end and a port at the destination end. The port can be a T1 or data port. T1 port circuit size is in number of timeslots, 1 through 24. The dat a port circuit size is in 56k or 64k bit increments.

You can mix T1 and data ports as source and destination ends. Data-to-data po rt circuits are limited to inter- module only.

For ISDN (dial backup switch) circuits, the ISDN port must be the destination port. (Data ports are usually the source ports and net ports are usually the destination ports.)

Circuit Manager Menu

Circuit Manager

from the

Main Menu

, enter B.

menu to build and maintain circuits. A

3-38 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

A. Data to T1 B. T1 to T1

Net 1Data 1

Net 2Data 2

The port line code selection (for example, 56k or 64k circuits) can limit a circuit’s configuration.

NOTE: Network and data ports must be In Service before a circuit can be

built.

When you have named a circuit and identified its source and destination ports, allocate the source and destination timeslots.

NOTE: Build T1-to-T1 circuits fir st. Allocate the same -numbered timeslots

on both the sourc e an d th e de st i n at ion ends.

Figure 3-28 Circuit Manager Menu

A [127.255.255.0] [1,2] DPRI 2922 > Circuit Manager -- [1,1] NCM 2000 Firmware 4.15 - Page : 1 Total: 2 circuits Name Type Mode Prio Src Port Dest Port Bus Status

------------ ---- ---- ---- ---------------- ---------------- --- -----DPRItestC1 prim 64k crit [1, 2] DPRI dat1 [1, 2] DPRI net1 INT Inacti dialbackup d-bk 64k crit [1, 2] DPRI dat1 [1, 2] DPRI net2 -- Inacti A) add circuit L) search circuit D) delete circuit E) edit circuit P) prev page I) activate circuit N) next page R) deactivate circuit X) exit to craft main menu A [127.255.255.0] [1,2] DPRI 2922 >

NOTE: If a card is moved to a different slot, the circuit( s) mu st be re bu ilt.

Table 3-23

Circuit Manager Menu Commands

Command Description

A Add Circuit—Use this option to add a circuit. Figure 3-29, Table 3-24.

L Search Circuit—Use this option to search for or list existing circuits. Figure 3-30, Table 3-25.

Verilink DPRI 2922 3-39

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Command Description

D Delete Circuit—Use this option to remove an existing circui t. Fi gur e 3-31 , Ta b le 3-26 .

E Edit Circuit—Use this option to change characteristics of a particular circuit. Figure 3-32,

P Prev page—Views the previous page of the circuit list when the list is greater than one page.

I Activate circuit—Changes the circuit to active status.

N Next page—Views the next page of the circuit list when the list is greater than one page. R Deactivate circuit—Changes the circuit to inactive status (The circuit will not carry data).

X Exit to Craft Main Menu—Exits the Circuit Manager Menu, and returns to the Main Menu,

Add Circuit Submenu

Table 3-27.

Figure 3-1, Table 3-2.

Use this option to create a n ew circu it. S pecify the ID fo r th e circui t port. The ID number must be uni que (12 characters maximum). Enter which timeslots will leave the source port, and which timeslots will end at the destination port (from 1 to 24). Specify if the timeslots are 56kbit/s or 64kbit/s in bandwidth.

Circuit IDs identify particular circuits. For instance, if you build a circuit on card 3 from T1 Port 1 to Data Port 2, the ID can be 312. Or, use names to identify the circuits. The following graphic shows that Circuit 1 has 1 to 15 timesl ots and connects Source Port Net 1 to Destination Port Data 1. Circuit 2 has timeslots 16 to 24 and connects Source Port Net 1 to De stination Port Data 2.

C1: Timeslots 1-15

3-40 Verilink DPRI 2922

C2: Timeslots 16-24

Net 1Data 1

Net 2Data 2

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Figure 3-29 Add Circuit Submenu

A [127.255.255.0] [1,2] DPRI 2922 > a Add Circuit -- [1,1] NCM 2000 Firmware 4.15 - N) Name: -- P) Priority: norm T) Type: -- M) Mode: -SP) [-,-] undefined DP) [-,-] undefined SM) --src port chn-- DM) --dst port chn- (undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port) (undefined port) U) Bus: -- ->-->>->> Circuit Inactive <<-<<--< S) Setup X) Exit A [127.255.255.0] [1,2] DPRI 2922 >

Table 3-24

Command Description Options

N Name—Circuit name (Circuit ID 12 characters

PPriority— 1) low

T Type—Circuit type. 1) perm

MMode—Circuit Mode 1) 64K

SP Source Port—Displays the Node “Map” and prompts for the SRC Port shelf,

Add Circuit Submenu Commands

slot. Use this option to designate the starting point of your circuit. Once the Shelf and slot position of the Source Port has been entered, you are prompted with 4 choices.

maximum

2) norm

3) high

4) crit

2) swit

3) prim

4) d-bk

5) bkup

2) 56K For Subrate DIU only:

3) 38.4K

4) 19.2K

5) 9.6K

6) 4.8K

7) 2.4K

1) net1

2) net2

3) dat1

4) dat2

DP Destination Port—Displays the Node “Map” and prompts for the DEST Port

shelf, slot. Use this option to designate the ending point of your circuit. Once the Shelf and slot position of the Source Port has been entered, you are prompted with 4 choices.

SM SRC Port Chn—Source Timeslot. Designate which T1 timeslots you wish to

use in this circuit. Note: In ISDN, timeslot 24 is normally reserved for use in D-channel call

set-up. For this reason, avoid building circuits which use timeslot 24. For ISDN, a call-reference option is provided to designate the call profile

for backup.

Verilink DPRI 2922 3-41

1) net1

2) net2

3) dat1

4) dat2 1—24 or press

ENTER to exit

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Command Description Options

DM DST Port Chn—Destination Timeslot Designate which T1 timeslots you

wish to use at the Destination Port.

Note: In ISDN, timeslot 24 is normally reserved for use in D-channel call set-up. For this reason, avoid building circuits which use timeslot 24.

For ISDN, a call-reference option is provided to designate the call profile for backup.

U Bus—Sel ect a backp lane b us for i ntermod ule c ommunica tion. T he A Bus is

always used for ISDN.

SSetup— X Exit—exits this menu and displays the Circuit Manager Menu, Figure 3-28,

Search Circuit

Table 3-23.

Use this opti on to s e ar ch for or list exist i n g circuits.

Submenu

Figure 3-30 Search Circuit Submenu (Cir c List Menu)

A [127.255.255.0] [1,2] DPRI 2922 > l Circ List Menu -- [1,1] NCM 2000 Firmware 4.15 - C) search by shelf,slot P) search by port. X) exit A [127.255.255.0] [1,2] DPRI 2922 >

1—24 or ENTER to exit

1) A

2) B

3) C

4) Auto

Table 3-25

Command Description Options

C Search by shelf, slot—Shelf and slot must be specified. Slots must be specified

P Se ar ch by por t —Spe cify Circuit Port shelf, slot. Slots must be specified in the

X exit—exits this screen and returns to the Circuit Manager Menu, Figure 3-28,

Search Circuit Submenu (Circ List Menu) Commands

in the range of 1through 13. If return is pressed, the screen will display (list) the current circuits and their status.

range of 1through 13. If return is pressed, the screen will display (list) the current circuits and their sta t u s.

Table 3-23.

Shelf, slot (range 1—13)

3-42 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Delete Circuit

Use this opti o n to re move existing circuits.

Submenu

Figure 3-31 Delete Circuit Submenu (Circ Deletion Menu)

A [127.255.255.0] [1,2] DPRI 2922 > d Circ Deletion Menu -- [1,1] NCM 2000 Firmware 4.15 - S) single circuit A) all circuits C) card circuits P) port circuits X) exit A [127.255.255.0] [1,2] DPRI 2922 >

Table 3-26

Command Description Options

Delete Circuit Submenu (Circ Deletion Menu) Commands

S Single circuit—Use the Circuit ID to specify the circuit to delete:

12 characters maximum.

A All circuits—Screen will prompt with the warning: Are You Sure? (Y/N) Yes or No

C Card circuits—Specify the Shelf/Slot. Slots must be spec if ied in the

range of 1 through 13.

Circuit ID: 12 characters maximum

(Y/N) Shelf, Slot

(Range of 1—13)

P Port circuits—Select the Circuit Ports by shelf/slot number. Slots must

X exit—Exits the Delete Circuit Submenu and returns you to the Circuit

Edit Circuit Submenu

be in the range of 1 through 13.

Manager Menu, Figure 3-28, Table 3-23.

To change a circuit’s c haracteristics, use the Edit Circuit Submenu. However, you cannot change a circuit while it is active/running— deactivate the circu it first, then zero it out.

To edit a circuit, enter E from the

Circuit

menu will then display. To change the c haracteristics of a

particular circui t, specify the Circuit ID of an existing circuit.

Circuit Manager

Shelf, Slot (Range of 1—13)

menu. The

Edit

Verilink DPRI 2922 3-43

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Figure 3-32 Edit Circuit Submenu

A [127.255.255.0] [1,2] DPRI 2922 > e Enter circuit name ( 12 char maximum ): dialbackup Edit Circuit -- [1,1] NCM 2000 Firmware 4.15 - N) Name: dialbackup P) Priority: crit T) Type: d-bk M) Mode: 64k SP) [1, 2] DPRI dat1 DP) [1, 2] DPRI net2 SM) --src port chn-- DM) --dst port chn- 01 02 03 04 05 06 07 08 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 .. 17 18 19 20 21 22 23 .. U) Bus: -- ->-->>->> Circuit Inactive <<-<<--< A) primary circ: backup circ: dialbackup SE) src err mask: -- C) dst call ref: -DE) dst err mask: -- O) dbkp timeout: none G) err clr mask: no primary port S) Setup X) Exit A [127.255.255.0] [1,2] DPRI 2922 >

3-44 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

Table 3-27

Command Description Options

M Mode—Circuit Mode 1) 64K

SP Source Port—Displays the Node “Map” and prompts for the SRC Port shelf,

Edit Circuit Submenu Commands

N Nam e—Circuit name (Circuit ID)—12 characters maximum

PPriority— 1) low

T Type—Circuit type. 1) perm

slot. Use this option to designate the starting point of the circuit. Once the Shelf and slot position of the Source Port has been entered, you are prompted with 4 choices.

2) norm

3) high

4) crit

2) swit

3) prim

4) d-bk

5) bkup

2) 56K For Subrate DIU only:

3) 38.4K

4) 19.2K

5) 9.6K

6) 4.8K

7) 2.4K

1) net1

2) net2

3) dat1

4) dat2

DP Destinat ion Port—Displays the Node “Map” and prompts for the DEST Port

shelf, slot. Use this option to designate the ending point of the circuit. Once the Shelf and slot position of the S ource Port has been entered, you are prompted with 4 choices.

SM SRC Port Chn—Source Timeslot. Designate which T1 timeslots you wish to

use in this circuit. Note: In ISDN, timeslot 24 is normally reserved for use in D -cha n nel cal l

set-up. For this reason, avoid building circuits which use timeslot 24. For ISDN, a call-reference option is provided to designate the call profile

for backup.

DM DST Port Chn—Destination Timeslot Designate which T1 timeslots you

wish to use at the Destination Port.

Note: In ISDN, timeslot 24 is normally reserved for use in D -cha n nel cal l set-up. For this reason, avoid building circuits which use timeslot 24.

For ISDN, a call-reference option is provided to designate the call profile for backup.

U Bus—Select a backplane bus for int ermodule communication. The A Bus is

always used for ISDN.

A Primary circ—Primary Circuit Name 12 characters

1) net1

2) net2

3) dat1

4) dat2 1—24 or press

ENTER to exit

1—24 or press ENTER to exit

1) A

2) B

3) C

4) Auto

maximum

Verilink DPRI 2922 3-45

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

Command Description Options

SE src err mask—Backup when SRC port set: 1) ais

2) yel

3) los

4) lof

5) uas/ses

C dst call ref—Dial-out profile

DE dst err mask—Backup w hen DST po rt set: 1) ais

2) yel

3) los

4) lof

5) uas/ses

O dbkp timeout—Backup circuit timeout Day (max 5

G err clr mask—Switch back when clear 1) ais

S Setup—This option MUST be selected to set the new configurations. If this

option is not selected, the card reverts to the previous configuration.

X Exit—exits this menu and displays the Circuit Manager Menu, Figure 3-28,

Table 3-23.

Manufacturing Info

To display the firmware versions and CIM types, choose I from the

Main Menu

exit this screen, press

Figure 3-33 Manufacturing Information

A [127.255.255.0] [1,2] DPRI 2922 > i MANUFACTURING INFORMATION Main Card CIM Revision RM) C RC) Date DM) 3/6/97 DC) 2/5/97 Serial number SM) 00649488 SC) 00648368 Manuf. Part No. MM) 319101776002 MC) 311101387001 Cage Code CM) CC) Type TM) DIDCSU TC) CIM29010 Press enter to continue

Manufacturing Information

. The

NTER

screen displays. To

days) Hour (max 23 hrs) Min (max 59 min)

2) yel

3) los

4) lof

5) uas/ses

3-46 Verilink DPRI 2922

Configuring the DPRI 292 2 Via the NCM 2000 Craft Interface

NOTE: The Manufacturing Information window displays information about

the DPRI module. For problems with your module, you can pro vide Customer Service with information that displays in this menu.

System Log Off

To log off, type X repeatedly to retur n t o the

YOUR PASSWORD?

to the

Figure 3-34 System Log Off

A [127.255.255.0] [1,2] DPRI 2922 > i LOGGED OFF YOUR PASSWORD?

Re-enter the Craft interface by typing the password.

YOUR PASSWORD?

YOUR PASSWORD?YOUR PASSWORD?

prompt.

Main Menu

, and then

Verilink DPRI 2922 3-47

Configuring the DPRI 2922 Via the NCM 2000 Craft Interface

3-48 Verilink DPRI 2922

Chapter

Interpreting Alarms

Troubleshooting

Controller card(s) poll the various modules for alarms. If alarm reporting is enable d for the node and for the module(s), the node controller card retrieves and sends the alarm to Access Manager 2000, Node Manager 2000, or an SNMP agent. Various alarms can also be set up via the NCM 2000 module to trigger the dial backup or backup T1 as part of the Advanced Automatic Protection Switching feature.

An alarm list is provided under th e alarms displays of the various options of AM2000, NM2000, SNMP, or ASCII.

Alarms can also be automatically sent to a specified printer by setting up the printer address in the various management utilities menus.

The alarm buffer displays the following information about alarms (This information may vary depending on the controller module and management method used):

Figure 4-1 Alarm Buffer

[1,1] DPRI 2922 > o DPRI 2922 [1,1] AIS Major Alarm port 1 3-09-98 18:38:35 DPRI 2922 [1,1] AIS Threshold Cleared port 1 3-09-98 18:37:17 Press enter to continue

Module Type

Shelf/Slot Location

•

Whenever the system powers up and any module does a selftest

•

Power supply input is lost

•

A default or user-designated threshold is exceeded

•

A Yellow Alarm is received from the network (DS1)

•

An unframed all-ones or alarm indi cation signal (AIS) is reveived from the network

•

There is a loss of signal (LOS) or loss of frame (LOF)

•

A CSU or Data Port loopback is present

•

A module fails

•

A module is removed from the shelf

Alarm Description

Alarm Classification

Port

Alarm Date and Time

Verilink DPRI 2922 4-1

Troubleshooting

Status Code

Alarm Description

Classifications

The status code column displays a decimal code when using an ASCII terminal. (Varies depending on SNMP or ASCII terminal used.)

The alarm description colu mn l ists the text which is:

•

printed on the display

•

sent to the alarm printer

•

saved to the alarm buffer/database

Verilink classifies alarms into the following severities:

•

Critical

•

Major

•

Minor

•

Warning

•

Info

•

Cleared

Problem Types

These classifications are further categorized into the following problem types:

•

LOS

•

LOF

•

Error

•

Call Setup

4-2 Verilink DPRI 2922

What To Do About Alarms

Some alarms clear after the user-configured timeout has expired. Other alarms require co rrective action.

•

If an alarm has been cleared, no other action is required.

•

If there is a loopback present, unless you are intentionally testing, remove the loopback. (Only if the loopback is from your end. If the loop was initiated by your network service provider, check with their test facility before taking down the loop.)

•

For an LOF, you may have a telco or module problem. To test, do an RLB. If there is no LOF indicated by the test, the problem is with the telco.

•

For an LOS, check your router cables, power, and ports.

•

For a power-up self-test failure, reseat the module a few times to see if it will power up and pass the self test. If it does not pass after repeated self tests, replace the module.

Troubleshooting

Alarm Records

Every alarm record that displays is “active” in the database until you do something about it. Do the following with the alarm records:

•

Deactivating alarm records is a database management function. As long as an alarm is active, you can view it onscreen, using the one of the management options on the ASCII interface, AM2000, or Node Manager 2000. When you deactivate an alarm, it’s still in the database, but not viewable on screen. Deactivated alarms can be archived, printed, or deleted.

•

Archiving an alarm record stores it to a disk file you specify.

•

Printing an alarm record p rints a copy of all active and deactivated alarms.

•

Deleting an alarm record re moves it from the database. To delete an alarm, first d eactivate it.

Verilink DPRI 2922 4-3

Troubleshooting

Alarm List

Table 4-1 Alarms

Alarm Classification/

Alarm Type Description

Fault conditions can result in critical, major, or minor alarms. In addition, a fault condition can also result in a Carrier Failure Alarm (CFA).

Critical Alarms

Carrier Failur e Alarm (CF A)

Major Alarms

Alarm Type Description

Loss of Signal (LOS)

A critical alarm indicates the node or node components ha ve failed. Only the loss-of-clock (LOC) error condition triggers a critical alarm. This error causes the system clock to fail and prevents data from being transmitted.

Loss-of-clock causes the System LED to flash red. It causes a major alarm and activates the relay contacts on the rear connector panel of the CIM.

A carrier failure alarm (CFA) is activated w hen certain major alarm error conditions occur, causing the port to disrupt traffic along the line. When the CFA is activated, the line is not useable—preset by the user—for 2 to 60 seconds. All traffic is re m oved from the line. The alarm re mains active until the port is reconfigured.

A major alarm fault condition seriously affects performance. It prevents data from being reliably transmitted across the circuit. When a major alarm is declared, the module sends a message to the ASC II interface and Node Manager, lights the appropriate LED indicator, and trips the alarm relay. The following error conditions must persist for at least one second for a major alarm to be declared.

This condition occurs when the network signal is absent, and exceeds a predefined loss-of-signal threshold. An LOS alarm on a network line is declared when more than 175 consecutive zeros are detected on input to the receiving equipment. An LOS after o ne continuous sec o nd causes a major alarm and activates the relay contacts on the rear connector panel of the CIM.

This alarm activates the CFA if the LOS is active from 2 to 45 seconds (as defined by the user).

Alarm Indication Signal (AIS)

Loss of Frame (LOF) (T1 Only)

4-4 Verilink DPRI 2922

Using an unframed ALL-ONEs bit pattern, an AIS alarm indicates that an alarm condition exists upstream in a circuit leading to the downstream equipment. This is also called an ALL-ONEs Keep-Alive or Red Alarm Signal. An AIS defect is declared when there are 3 or fewer zeros in 512 bit times and an LOF defect. It is cleared when there are 3 or more zeros in two frames or the LOF defect no longer exist s .

This alarm activates the CFA if the AIS is active from 2 to 45 seconds (as defined by the user).

This alarm is declared when a 3-second interval of continuous Out-Of-Frame (OOF) or Loss-Of-Signal (LOS) state is detected. An LOF alarm is cleared when at least 10 seconds of continuous non-LOS or non-LOF condition exists.

This alarm activates the CFA if the LOF is active from 2 to 45 seconds (as defined by the user).

Alarm Classification/

Alarm Type Description

Troubleshooting

Loss of Frame Alignment (E1 Only)

Frame Alignment Signal Error Rate (FASER) (E1 Only)

Loss of TS16 Multiframe Alignment (LOMA) (E1 Only)

This condition occurs when three consecutive in-error frame alignment signals (words) are received, or when Bit 2 in a frame containing the nonframe alignment signal (N FAS wor d ) is received in error three consecutive times.

The condition clears when the following even ts are satisfied:

• The frame alignment signal is detected in frame N.

• The non-frame alignment signal 1 is detected in frame N+1.

• The frame alignment signal is detected in frame N+ 2. Loss-of-frame alignment (LOFA) after one continuous second causes a major

alarm and activates the relay contacts on the rear connector panel of the CIM. This alarm activates the CFA if the LOFA is active from 2 to 45 seconds (as

defined by the user). This alarm indicates that the FAS error rate exceeds a user-selectable

threshold of 10

-3

or 10-6 for at least four seconds. This user-selectable al arm can be designated as a major or minor alarm and activates the relay contacts on the rear connector panel of the CIM.

This alarm activates the CFA if the FASER is active from 12 to 60 seconds (as defined by the user).

This condition occurs when the module c anno t find the mul tiframe align ment signal (MAS) pattern on TS16 when enabled for CAS signaling.

This alarm activates the CFA if the LOMA is active from 2 to 45 seconds (as defined by the user).

Minor Alarms

Minor alarm fault c ond itio ns do not affec t traf fi c alo ng the network line . They generate a minor alarm.

Alarm Type Description

Power Supply

In redundant power supply configurations, this alarm indicates that one of the redundant power supplies has failed or has been removed from the shelf.

Missing Remote

Alarm Indication (RAI)

RAI. This alarm indicates that the remote end is in a state of alarm. A Remote Alarm or Remote Alarm Indication is the alarm a receiving channel bank or multiplexer sends to the other end of the circuit when it detects a Loss Of Signal or Loss Of Frame. There is a 2- to 3-second integration period upon detection of LOS or LOF before a Yellow Alarm is sent to the far-end equipment. This condition is also referred to as a Yellow Alarm.

Bipolar Violation (BPV) Threshold

Severely Errored Second (SES)

A violation of the T1 bipolar AMI transmission pattern requi ri ng successive Ones (pulses) to be transmitted as pulses of opposite polarities. A BPV alar m indicates transmission errors. However, B8ZS patterns contain intentional BPVs that are not counted as errors.

15 min. Threshold/ SES 24 hr. Threshold—An SES alarm is declared when 320 or more ESF error events occur within one seco nd, o r when an OOF (Out- O fFrame Second) occurs. An SES is a one-second period containing greater than 30% errored blocks (more than 1 errored bit) or at least one Severely Disturbed Period (SDP).

Bit Error Rate (BER) Threshold

The Bit Error Rate is the ratio of the number of bit errors received to the total number of bits transmitted in a given interval. The BER threshold indicates the level above which a CSU alarm is gen era ted an d repo rted .

Verilink DPRI 2922 4-5

Troubleshooting

Interpreting Front Panel LEDs

The LED indicators on the front panel of the DPRI 2922 module display errors caused by network line or data terminal equip ment problems. The errors are reflected in the alarm status and the performance/status menus in the ASCII terminal interface. Node Manager al so has an alarm dis p l ay .

There are five LEDs on the front panel:

•

Two network port LEDs

•

Two data port LEDs

•

One system LED

Figure 4-2 DPRI Front Panel Showing Alarm Indicator LEDs

DPRI 292

Network LEDs

NET

LOCAL

Port LEDs

Network LEDs display minor, major, and catastrophic alarm

DATA

SYS

EXTPRI

MANAGEMENT

System LED

conditions detected on the network line.

Table 4-2 Network LED Indicators

State Color Alarm Class Action/Possible Error Condition

Solid Green All okay None

Diagnostic

Solid Amber

Flashing

Amber and Red

mode with no errors

Yellow Alarm

None

Check the diagnostic performance status or alarm status displays. The Yellow Alarm indicates that the unit is receiving an RAI Signal, which indicates that the far end is not receiving a sig nal from the near end.

Solid Red Major

Check the performance s t atus or alarm status display. Loss of Signal (LOS) from far end transmits all-ones.

Off None None Port is not enabled.

4-6 Verilink DPRI 2922

Troubleshooting

Data Port LEDs

Table 4-3 Data Port LED Ind ic a tor s

State Color Alarm Class Possible Error Condition

Solid Green All okay None. (DTE connected and in sync)

Solid Red Major

Solid Amber

Off None None Port is not enabled.

System LED

Data Port LEDs 1 a nd 2 di splay the sta tus for their re spectiv e ports.

Port active; Signal designated for LOS is not detected. For example, if you have enabled DTR monitoring (to detect a Loss of Signal) and you disconnect the cable, a major alarm is declared.

Diagnostic mode

Port is active and in loopback.

The System LED displays node controller assignments and node communication conditions.

Table 4-4 System LED Indicators

State Color Alarm Class Possible Error Condition

Solid Green None

Module is okay and another module is the shelf controller.

Solid Red Critical Off None None Module is not on; no power.

Flashing Green None

System failure. You may need to reseat the ca rd in the shelf.

The module is acting as the controller (that is, it is the shelf master controlling t he ACP bu s usage in the shelf).

Verilink DPRI 2922 4-7

Troubleshooting

4-8 Verilink DPRI 2922

DPRI 2922

Index

Numerics

1/8

test pattern

2N1 5-1

test pattern

2N20-1

test pattern

3 in 24 55 Octet

test pattern

3-27 3-27 3-27

3-27

3-28

add circuits AIS

3-32, 3-34, 3-36

AIS/SEF Seconds alarm buffers

displaying

Alarm Indication Signal alarm status alarm threshold status

alarms

reporting

All 0s

test pattern

All 1s

test pattern

analog voice capacity application

bypass functionality insert functionality

auto restore

primary secondary tertiary

3-39

3-32

4-1

3-34

3-35

3-36

3-27 3-28

1-2

3-12

3-13

BER

3-37

BES

3-32

Bipolar Violation bipolar violations

counters

Bit Error Rate BPV Bursty Seconds

3-31

3-31, 3-34, 3-36

3-36

3-37

3-32

card alarm

3-32, 3-36

reporting

card slot number

primary secondary

cify CIM

CIM 29010 CIM 29011 circuit build configuration

circuits

add delete edit editing listing

clear card configuration Clear to Send components

hardware

configuration

configuration menu configuring

data port thresholds

Control Lead Controlled Slip Seconds counter

bipolar violations Cyclic Redu ndancy Check Extended Superfram e Form a t Frame Bit Error

counters

resetting

CRC cross-point switch crosspoint switch CTS

3-34

3-13

3-40

1-4

1-4 1-4

2-12, 2-13, 3-39, 3-41, 3-42

3-38

3-39

3-40

3-43

3-40

3-39

3-6

3-16

1-3

3-6

3-11

3-15

3-34

3-16

3-32

3-31

3-34

3-31

1-2

3-16

Data Carrier Detect Data Circuit-terminating Equipment data port

configuration menu configuring diagnostics menu

data port LEDs data port loopback

3-15

3-16

3-15

3-28, 3-29

4-7

3-29

3-15

Verilink

DPRI 2922

Index-1

Data Set Ready Data Terminal Equipment DCE

3-15

default values

password

Degraded Minutes delete circuits diagnostics

3-25, 3-26

Digital transmission facilities displaying

alarm buffers

3-32

DPL

3-29

DSR

3-16

DTE

3-15

3-16

3-15

3-1

3-32

3-40

3-26

4-1

1-2

Loss of Signal Loss-of-Frame Loss-of-Frame Seconds

3-36

manufacturing info menus

alarm threshold status circuit build configuration

3-46

3-42

configuration configuring data port configuring T1 data port diagnostics diagnostics performance/status T1 port diagnostics

3-11

3-15

3-6

3-28, 3-29

3-25, 3-26

3-30

3-26

3-32

3-35

2-12, 2-13, 3-39, 3-41,

E1/T1 LED indicators edit circuits Error Free Seconds Errored Seconds Errored Seconds Type A ES

3-32, 3-34, 3-37

ESF

3-31

Extended Superframe Format

counters

3-40, 3-43

3-31

4-6

3-32

3-32, 3-37

3-32

3-31, 3-32

Frame Bit Error

counters

front panel LEDs

3-32

3-31

4-6

information

manufacturing

INV ST

3-16

Inverted Serial Transmit

3-46

3-16

LEDs

front panel

Line Loopback list circuits LLB

3-27

LLB BOP Local Loopback LOF

3-32, 3-34, 3-36

loopbacks

data port Line Loopback LLB BOP Local Loopback Payload Loopback PLB BOP

LOS

3-32, 3-34, 3-36

Loss of Frame Counts

4-6

3-27

3-39

3-28

3-27

3-29

3-27

3-28

3-27

3-28

3-32

Network Management System NMS

3-34

None

test pattern

3-27, 3-29

OOF

3-32

Out-of-Frame Seconds

3-32

password

default

PASSWORD? Payload Loopback performance and status performance/status menu PLB PLB BOP port diagnostics screen primary

auto restore card slot number synchronization

3-1

3-27

3-29

3-30

3-27

3-28

3-26, 3-28

3-12

3-13

3-12, 3-18

QRSS

test pattern

query firmware

3-27, 3-29

3-6

RAI

3-34, 3-36

registers

resetting

Remote Alarm Indication reporting

alarms card alarms

reset card resetting

counters

3-33

3-36

3-34

3-6

3-34

Index-2

Verilink

DPRI 2922

registers test counters

RLB

3-33

3-28, 3-29

3-27

secondary

auto restore card slot number synchronization

SEF

3-32

Serial Transmi SES

3-32, 3-34, 3-37

setting up loopbacks Severely Errored Framing Seconds Severely Errored Second shelf and slot para meters shelf-timed ST

3-16

status

alarms

status and performance switch over once switch over permanent synchronization

primary secondary

system LED system log off

logging off

3-12

3-13

3-12

3-16

3-17

3-37

3-4

3-13

3-34

3-29

3-6

3-12, 3-18

3-12

4-7

system 3-47

3-32

T1 CIMs T1 configuration menu T1 port

Terminal Timing tertiary
