Velleman WS9611 User Manual

WIRELESS 868 MHz WEATHER CLOCK

Instruction Manual

INTRODUCTION:
Congratulations on purchasing this fancy Weather Clock with wireless 868MHz tra nsmission of outdoor temperature and display of indoor temperature and humidit y. It is furthe r acting a s a DCF-77 radio controlled clock with calendar display and alarm clock function. In addition, sunrise/ sunset/ sun duration time as well as the moon phase are shown. With the totally 15 different weather forecast icons featured by "Weather ma n", users can easily observe the forecast weather condition and will no longer worry the sudden weather change. This innovative product is ideal for use in the home or office.
« Instant Transmission+» is the up and coming state-of-the-art new wireless transmission technology, exclusively designed and developed by LA CROSSE TECHNOLOGY. “IT +” offers you an immediate update of all your outdoor data measured from the transmitters: follow your climatic variations in real-time!
49
FEATURES: The Weather Clock
Function
Keys
DCF-77 Radio controlled time with manual setting options
DCF Time reception ON/OFF
12/24 hour display
Hour, minute and second time display
Calendar (weekday, date, month and year)
Time zone option ±12 hours
LCD Display
Function Keys
50
Battery compartment cover
Foldout Stand
Hanging hole
Alarm with snooze function
Snooze setting
Weather forecasting with 15 easy-to-read weather forecast signs featured by "Weather
man"
Weather forecasting icon sensitivity setting
Temperature display in degrees Celsius (°C) or Fahrenheit (°F) selectable
Indoor and outdoor temperature display with MIN/MAX recording
Indoor humidity reading displayed as RH% with MIN/MAX recordings
All MIN/MAX temperature recordings show date and time received
All MIN/MAX recordings can be reset
Display of sunrise time, sunset time and sun duration in 39 cities
12 Moon phases display throughout the year
Can take up to three outdoor transmitters
LCD contrast setting
Low battery indicator
LED backlight
Table standing/ Wall mounting
51

The Outdoor Temperature Transmitter

SETTING UP : When one transmitter is used
1. First, insert the batteries into the Temperature transmitter. (see “Install and replace batteries in the Temperature transmitter“).
2. Immediately after and within 45 seconds, insert the batteries into Weather Clock (see “Install and replace batteries in the Weather Clock”). Once th e batteries are in place, all segments of the LCD will light up briefly. Following the time as 0:00 and the "Weather man" icon will be displayed. If these are not displayed after 60 seconds, remove the batteries and wait for at least 10 seconds before reinserting them.
Remote transmission of outdoor temperature to Weather
Clock by 868 MHz
Shower proof casing
Wall mounting case (Mounting at a sheltered place. Avoid
direct rain and sunshine)
52
3. After inserting the batteries, the W eather Clock will start receiving data from the transmitter. The outdoor temperature and the signal reception icon should then b e displayed on the Weather Clock. If this does not happen after 3 minutes, the batteries will need to be removed from both units and reset from step 1.
4. In order to ensure sufficient 868 MHz transmission however, th is should under go od conditions be a distance no more than 100 meters between the final position of the Weather Clock and the transmitter (see notes on “Positioning” and “868 MHz Reception”).
5. Once the remote temperature has been received and displayed on the W eather Clock, the DCF time (radio controlled time) code reception is automatically started. This takes typically between 3-5 minutes in good conditions. If after 10 minutes , the DCF time has not been received, press the SET key to manually enter a time initially.

When more than one transmitter is used

1. User shall remove all the batteries from the W eather Clock and transmitters and wait
for 60 seconds if setting has been done with one transmitter before.
2. Insert the batteries to the first transmitter.
3. Within 25 seconds of powering up the first transmitter, insert the batteries to the
Weather Clock. Once the batteries are in place, all segments of the LCD will light up briefly. Following time as 0:00 and the Weather man icon will be displayed. If they are not shown in LCD after 60 seconds, remove the batteries and wait for at least 60 seconds before reinserting them.
53
4. The outdoor temperature from the first transmitter (channel 1) should then be
displayed on the Weather Clock. Also, the signal reception ic on will be displayed. If this does not happen after 2 minutes, the batteries will need to be removed from both units and reset from step 1.
5. Insert the batteries to the second transmitter as soon as the outdoor temperature
readings from the first transmitter are displayed on the Weather Clock.
Note: User shall insert the batteries into the second transmitter within 10 seconds of reception of the first transmitter.
6. The outdoor data from the second transm itter and the "channel 2" ic on sh ould then be
displayed on the Weather Clock. If this does not happen after 2 minute, the batteries will need to be removed from all the units and reset from step 1.
7. Insert the batteries to the third transmitter as soon as t he "c han nel 2" ico n and o utdo or
data are displayed on the Weather Clock. Then within 2 minutes, the channel 3 outdoor data from the third transmitter will be displayed and the channel icon will shift back to "1" once the third transmitter is successfully received. If this is not happen, user shall restart the setting up from step 1.
Note:
User shall insert the batteries into the third transmitter within 1 0 seconds of reception o f
the second transmitter.
And user may require to check the displayed readings on the Weather Clock against
54
those shown on the transmitters in order to recognise the Channel No. of each transmitter.
8. In order to ensure sufficient 868 MHz transmission however, th is should under go od conditions be a distance no more than 100 meters between the final position of the Weather Clock and the transmitter (see notes on “Positioning” and “868 MHz
Reception”).
IMPORTANT:
Transmission problems will arise if the setting for additional sensors is not followed as described above. Should transmission problems occur, it is necessary to remove the batteries from all units and start again the set-up from step 1.
9. Once the remote temperature has been received and displayed on the Weather
Clock, the DCF time (radio controlled time) code reception is automatically started. This takes typically between 3-5 minutes in good conditions.
If after 10 minutes, the DCF time has not been received, press the SET key to manually enter a time initially.

Note:

Daily DCF reception is done at 02:00 and 03:00 every day. If the rec eption at 03:00 is not successful, then at 04:00 and 05:00 and 06:00 there are other tries, until one is successful. If
55
the reception at 06:00 is still not successful, then the next try takes place at 02:00 next day. If reception is successful, the received time will override the manually set time. The date is also updated with the received time. (Please refer also to notes on “DCF-77 Radio
Controlled time” and “Manual Time Setting”)
INSTALL AND REPLACE BATTERIES IN THE WEATHER CLOCK
The Weather Clock uses 2 x AA, IEC LR6, 1.5V batteries. To install and replace the batteries, please follow the steps below:
1. Remove the cover at the back of the Weather Clock.
2. Insert batteries observing the correct polarity (see marking).
3. Replace compartment cover.
56
INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE TRANSMITTER
Note:
In the event of changing batteries in any of the units, all units need to be reset b y following the setting up procedures. This is because a random security code is assigned by the transmitter at start-up and this code must be received and stored by the Weather Clock in the first 3 minutes of power being supplied to it.
BATTERY CHANGE:
It is recommended to replace the batteries in all units regularly to ensure op timum accuracy of these units (Battery life See Specifications below).
The Temperature Transmitter uses 2 x AA, IEC L R6, 1.5V battery. To install and replace the batteries, please follow the steps below:
1. Remove the battery compartment cover at the back of the transmitter.
2. Insert the batteries, observing the correct polarity (see marking).
3. Replace the battery compartment cover on the unit.
Please participate in the preservation of the environment. Return used batteries to an authorised depot.
57
FUNCTION KEYS: Weather Clock:
The Weather Clock has five easy to use function keys.
SET key
MIN/ MAX key
SNOOZE/ SUN key
58
ALM key
CH/ + key

SET key (Setting):

To enter the set mode for the following functions: LCD contrast, Time zone, Time
Reception ON/OFF, 12/24 hour display, Manual time, Year, Date, Sunrise/ sunset city location, Snooze time duration, °C/°F, and Weather forecast sensitivity settings.
To toggle between the display of "Weekda y + date + month", "S econd", "Alarm ti me",
and "Date + month + year"
To press and hold for 3 seconds to reset at the same time the maximum/ minimum
temperature and humidity records of indoor and the currently selected outdoor channel (will reset all records to current level)
To stop the alarm
To switch on the backlight

MIN/ MAX

To toggle between the maximum/ minimum outdoor temperature and maximum/
minimum indoor temperature and humidity data
Note: The Time/date shown is corresponding to MIN/MAX temperature data.
To stop the alarm
To switch on the backlight
ALM key (alarm)
Press for about 3 seconds to enter the Alarm setting mode
To activate/ deactivate the alarm
59
To stop the alarm
To switch on the backlight
CH/ + key
To toggle between the Outdoor transmitters 1, 2 and 3 (if more than 1 transmitter is
used)
To adjust LCD contrast, time zone, Time Reception ON/OFF, 12/24 hour display, hour,
minute, year, month, day, snooze time duration, °C/ ° F and weather forecasting icon sensitivity in setting modes
To adjust the alarm time in alarm setting mode
To stop the alarm
To switch on the backlight
SNOOZE/ SUN key
To activate the snooze function for the alarm
To toggle between the sunrise time, sunset time, sun duration in the Sun display
To exit manual setting mode and alarm setting mode
To switch on the backlight
60
LCD SCREEN AND SETTINGS:
DCF Tower
Icon (for time
reception)
Time
Calendar
Moon phase
display
Alarm icon
Sunrise/ sunset
display
Weather Tendency icon
Weather Forecast icon (Weather man)
61
Outdoor Reception Signal*
Weather Clock low battery icon
Indoor Temperature
Indoor Relative Humidity %
Transmitter low battery icon
Outdoor Temperature
Number showing Transmitter unit
*When the signal from the transmitter is successfully received by the Temperatur e Station, this icon will be switched on. (If not successful, the icon will not be shown on the LCD). User can therefore easily see whether the last reception was succe ssful (“ON” icon) or not (“OF F” icon). On the other hand, the short blinking of the icon sho ws that a reception is being done at that time.
For better distinctness the LCD screen is split into 5 .
Section 1 - TIME AND CALENDAR
In normal mode display of radio controlled time.
A reception tower symbol will be shown indicating that the DCF-77 time signal is
scanned for (flashing) or received (steady). Note: The symbol will not be shown when radio time reception is not successful or when time reception function is turned off.
Display of "Weekday + date + month", "Second", "Alarm time" or "Date + month +
year"
In normal display, the alarm icon will be shown when the alar m is turned on. Or when
the snooze function is activated, the alarm icon will be flashing.
Section 2 - Moon phase and Sunrise / Sunset
Display the sunrise, sunset, and sun duration time
Display the 12 different moon phase
62
