Velleman MONCOLHA3 User Manual [en, de, es, fr]

MONCOLHA3

3.5" TFT-LCD MONITOR - 4:3

3.5" TFT-LCD-MONITOR - 4:3
MONITEUR TFT-LCD 3.5" - 4:3

3.5" TFT-LCD-MONITOR - 4:3
MONITOR TFT-LCD 3.5" - 4:3

USER MANUAL 3
GEBRUIKERSHANDLEIDING 7
NOTICE D’EMPLOI 11
MANUAL DEL USUARIO 15
BEDIENUNGSANLEITUNG 19

MONCOLHA3

00 (07/11/2008) 2 Velleman®

MONCOLHA3

User manual

1. Introduction

To all residents of the European Union
Important environmental information about this product

If in doubt, contact your local waste disposal authorities.

Thank you for choosing Velleman! Please read the manual thoroughly before
bringing this device into service. If the device was damaged in transit, don't
install or use it and contact your dealer.

The MONCOLHA3 has two video inputs that can be used for backing-up
cameras (not incl.) or as extra screen for e.g. an on-board DVD system (not
incl.) etc…

2. Safety Instructions

• Damage caused by disregard of certain guidelines in this manual is not

covered by the warranty and the dealer will not accept responsibility for any
ensuing defects or problems.

• Note that damage caused by user modifications to the device is not covered

by the warranty.

3. General Guidelines

• Protect this device from shocks and abuse. Avoid brute force when

operating.

• Familiarise yourself with the functions of the device before actually using it.

• All modifications of the device are forbidden for safety reasons.

• Only use the device for its intended purpose. Using the device in an

unauthorised way will void the warranty.

00 (07/11/2008) 3 Velleman®

This symbol on the device or the package indicates that disposal
of the device after its lifecycle could harm the environment.
Do not dispose of the unit (or batteries) as unsorted municipal
waste; it should be taken to a specialized company for recycling.
This device should be returned to your distributor or to a local
recycling service.
Respect the local environmental rules.

For indoor use only. Keep this device away from rain, moisture,
splashing and dripping liquids. Protected the device against
extreme heat (e.g. direct sunlight, heater …) and dust.

Keep the device away from children and unauthorised users.

There are no user-serviceable parts inside the device.
Refer to an authorized dealer for service and/or spare parts.

MONCOLHA3

4. Features

• 2 x video/camera inputs

• OSD (on-screen display)

• automatic trigger function for reverse camera

• comes with: remote control, cables and mounting stand

5. Overview

Refer to the illustration on page 2 of this manual.

A sun shade H IR transmitter
B IR sensor I ON/OFF button
C ON/OFF button J video select button
D video select button K menu button
E mode select button L increase button
F status indication M mode select button
G mounting bracket N decrease button

6. Installation

Refer to the drawing on page 2 of this manual.

1 monitor connector plug 5 ground cable (black)
2 fuse box 6 video in 1
3 reverse cable (green) 7 video in 2
4 +12VDC power cable (red)

The car connection should be carried out by a qualified person only.

• Choose a mounting location, depending on the purpose of the monitor.

When used to connect backing-up or parking camera(s), the driver should
have a clear view of the display. For all other purposes make sure the driver
is not distracted by images and/or sound from the system.

• Mount the mounting bracket [G] and attach the monitor to the bracket with

the 4 included screws.

• Connect the monitor connector plug [1] with the jack of the monitor.

• Connect a camera/video/DVD… (not incl.) to a video input [6][7].

• Make sure the engine is switched off.

• Connect the red +12VDC power cable [4] to the +12VDC power system

of the car. Make sure there is no power on the connection wire (remove
fuse).

• Connect the black ground cable to the car ground.

• The monitor can switch on/over to AV2 automatically when reverse gear

is selected. To enable this functionality, connect the green reverse cable

00 (07/11/2008) 4 Velleman®

to the reverse gear power circuit. Make sure there is no power on the
connection wire (remove fuse).Connect the backing-up camera to video
input AV2.

• Apply power to the system (re-insert fuses). The status indication [F]

should light up.

• The sun shade [A] can be removed by sliding it upwards.

7. Use

• Switch on the monitor by pressing the ON/OFF button on the monitor [C]

or remote control [I]. Note that when connection to the reverse gear
system is made, the monitor switches on automatically when reverse
gear is selected.

• Select the video channel (AV1 or AV2) by pressing the video select button

on the monitor [D] or remote control [J].

• Press the mode select button on the monitor [E] or remote control [M] to

select monitor setup presets: STANDARD – SOFT – VIVID – LIGHT.

• Press the menu button [K] on the remote control to enter manual

monitor setup. Use the video select [J] and mode select [M] to navigate
through the settings; use the increase [L] or decrease [N] buttons to
change the settings.

MONCOLHA3

• Brightness, contrast and colour can be set between 0 and 32.

• To select system setup, go to RESET and press the menu button [K]. The

system menu is displayed.

BLUE ON, OFF

VIDEO AV1, AV2

BLUEOFF

• Press on the menu button [K] again to exit the manual monitor setup.

00 (07/11/2008) 5 Velleman®

30S, 1MIN, 3MIN,
5MIN, OFF

Select ON to display a blue screen when no
video signal is detected.

Select which video input is used for backing up
camera (default: AV2)

Monitor switches off automatically after set
time when no input signal is detected. OFF
disables this function.

MONCOLHA3

8. Battery

• The battery holder of the remote control is located at the back of the

remote, on the bottom. To replace the battery, pull the battery holder
away from the remote control.

• Replace the old battery with a new lithium battery type CR2025. Make

sure to use the correct polarity.

• Push the battery holder back in the remote control until it snaps into

place.

• Remove the battery when the device is not in use.

• Do not recharge batteries and do not throw in fire as they may explode.

WARNING: handle Lithium batteries with care, observe
warnings on battery casing. Dispose of batteries in
accordance with local regulations.
Keep the battery away from children.

9. Technical Specification

display mode TFT Active Matrix (4:3)
screen size 3.5"
resolution 320 x R.G.B x 240
number of pixels 230400
video input signal 1.0Vpp / 75 ohms (composite video signal)
power supply
monitor DC 12V ± 10%

remote control 1 x 3V CR2025 battery (incl.)
operating temperature 5°C ~ 40°C
storage temperature -20°C ~ 60°C
dimensions 108 x 78 x 24mm
weight 137g

Use this device with original accessories only. Velleman nv cannot
be held responsible in the event of damage or injury resulted from
(incorrect) use of this device.

For more info concerning this product, please visit our website

www.velleman.eu

The information in this manual is subject to change without prior
notice.

.

00 (07/11/2008) 6 Velleman®

MONCOLHA3

Gebruikershandleiding

1. Inleiding

Aan alle ingezetenen van de Europese Unie
Belangrijke milieu-informatie betreffende dit product

naar een lokaal recyclagepunt brengen. Respecteer de plaatselijke
milieuwetgeving.

Hebt u vragen, contacteer dan de plaatselijke autoriteiten inzake
verwijdering.

Dank u voor uw aankoop! Lees deze handleiding grondig voor u het toestel in
gebruik neemt. Werd het toestel beschadigd tijdens het transport, installeer het
dan niet en raadpleeg uw dealer.

De MONCOLHA3 is een TFT-LCD-scherm met twee video-ingangen voor gebruik
met een achteruitrijdcamera (niet meegelev.), als extra scherm voor uw on-board
dvd-speler (niet meegelev.), enz.

2. Veiligheidsinstructies

• De garantie geldt niet voor schade door het negeren van bepaalde richtlijnen in

• Schade door wijzigingen die de gebruiker heeft aangebracht aan het toestel

3. Algemene richtlijnen

• Bescherm dit toestel tegen schokken. Vermijd brute kracht tijdens de bediening

• Leer eerst de functies van het toestel kennen voor u het gaat gebruiken.

• Gebruik de oorspronkelijke verpakking wanneer u het toestel vervoert.

• Gebruik het toestel enkel waarvoor het gemaakt is. Bij onoordeelkundig gebruik

00 (07/11/2008) 7 Velleman®

Dit symbool op het toestel of de verpakking geeft aan dat, als het na
zijn levenscyclus wordt weggeworpen, dit toestel schade kan toebrengen
aan het milieu. Gooi dit toestel (en eventuele batterijen) niet bij het
gewone huishoudelijke afval; het moet bij een gespecialiseerd bedrijf
terechtkomen voor recyclage. U moet dit toestel naar uw verdeler of

Enkel voor gebruik binnenshuis. Houd dit toestel uit de buurt van
hitte, stof, regen, vochtigheid en opspattende vloeistoffen.

Houd dit toestel uit de buurt van kinderen en onbevoegden.

De gebruiker mag geen onderdelen vervangen. Bestel eventuele
reserveonderdelen bij uw dealer.

deze handleiding en uw dealer zal de verantwoordelijkheid afwijzen voor
defecten of problemen die hier rechtstreeks verband mee houden.

vallen niet onder de garantie.

van dit toestel.

vervalt de garantie.
