Velleman ANTDVBT7 User Manual [en, de, es, fr]

ANTDVBT7
ACTIVE OUTDOOR ANTENNA FOR DVB-T RECEPTION
ACTIEVE BUITENANTENNE VOOR DVB-T ONTVANGST
ANTENNE EXTÉRIEUR ACTIVE POUR RÉCEPTION TNT
AKTIVE AUßENANTENNE FÜR DVB-T EMPFANG
USER MANUAL 2 GEBRUIKERSHANDLEIDING 6 MODE D'EMPLOI 10 MANUAL DEL USUARIO 14 BEDIENUNGSANLEITUNG 18
ANTDVBT7

USER MANUAL

1. Introduction

To all residents of the European Union Important environmental information about this product
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device into service. If the device was damaged in transit, don't install or use it and contact your dealer.
The ANTDVBT7 is a specially designed waterproof and UV-proof antenna for DVB-T reception. With its state-of-the-art LNA technology and circuitry, built-in FM, UHF and VHF filters, it provides the best reception. Your ANTDVBT7 comes with 1 x antenna, 1 x coax cable, 1 x PSU, 1 x power inserter, 1 x support, a complete mounting kit, and this manual.

2. General Guidelines

Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.

3. Connection

Connect the antenna as shown below. It is recommended to make a water drop loop (2) in the coax cable (1) for water evacuation. Use the power inserter (3) when powering the antenna through the PSU.
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm the environment. Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialized company for recycling. This device should be returned to your distributor or to a local recycling service. Respect the local environmental rules.
Damage caused by disregard of certain guidelines in this manual is not
covered by the warranty and the dealer will not accept responsibility for any ensuing defects or problems.
Keep the antenna away from interference sources such as air
conditioners, hair dryers, microwave ovens, etc.
Install the antenna as high as possible, preferably near a window.
Check the signal strength and quality. Move the antenna to a better location if needed.
V. 03 – 05/11/2013 2 ©Velleman nv
ANTDVBT7
Indoor
Outdoor
V. 03 – 05/11/2013 3 ©Velleman nv
ANTDVBT7
Wall mounting
Pole mounting
Indoor use

4. Installation

V. 03 – 05/11/2013 4 ©Velleman nv
ANTDVBT7
power supply using the digital receiver
5 VDC (supplied through the receiver)
analogue TV use
12 VDC (PSU incl.)
frequency UHF
470–870 MHz
VHF
46–88, 108–230 MHz
gain
20 dB ± 3 dB
max. output
95 dBµV
revolving angle
0–90°
impedance
75 ohm
power consumption
DC 0.6 W / AC 3 W (PSU)
weight
0.25 kg
dimensions
190 x 110 x 65 mm

5. Technical Specifications

Use this device with original accessories only. Velleman nv cannot be held responsible in the event of damage or injury resulting from (incorrect) use of this device. For more info concerning this product and the latest version of this manual, please visit our website www.velleman.eu. The information in this manual is subject to change without prior notice.
© COPYRIGHT NOTICE The copyright to this manual is owned by Velleman nv. All worldwide rights reserved. No part of this manual may be copied,
reproduced, translated or reduced to any electronic medium or otherwise without the prior written consent of the copyright holder.
V. 03 – 05/11/2013 5 ©Velleman nv
ANTDVBT7

GEBRUIKERSHANDLEIDING

1. Inleiding

Aan alle ingezetenen van de Europese Unie Belangrijke milieu-informatie betreffende dit product
brengen. Respecteer de plaatselijke milieuwetgeving.
Hebt u vragen, contacteer dan de plaatselijke autoriteiten betreffende de verwijdering.
Dank u voor uw aankoop! Lees deze handleiding grondig voor u het toestel in gebruik neemt. Werd het toestel beschadigd tijdens het transport, installeer of gebruik het dan niet en raadpleeg uw dealer.
De ANTDVBT7 is een waterdichte en UV-bestendige antenne die speciaal werd ontworpen voor DVB-T-ontvangst. Dankzij de ruisarme versterker, de FM-, UHF- en VHF-filter, en de nieuwste technologie verkrijgt u de beste ontvangst. Uw ANTDVBT7 wordt geleverd met 1 x antenne, 1 x coaxkabel, 1 x voedingsadapter, 1 x power inserter, montageaccessoires en deze handleiding.

2. Algemene richtlijnen

Raadpleeg de Velleman® service- en kwaliteitsgarantie achteraan deze handleiding.

3. Aansluiting

Sluit de antenne aan zoals hieronder afgebeeld. We raden aan een lus (2) in de coaxkabel (1) te leggen om waterdruppels te laten afvloeien. Gebruik de power inserter (3) indien u de antenne via de voedingsadapter voedt.
Dit symbool op het toestel of de verpakking geeft aan dat, als het na zijn levenscyclus wordt weggeworpen, dit toestel schade kan toebrengen aan het milieu. Gooi dit toestel (en eventuele batterijen) niet bij het gewone huishoudelijke afval; het moet bij een gespecialiseerd bedrijf terechtkomen voor recyclage. U moet dit toestel naar uw verdeler of naar een lokaal recyclagepunt
De garantie geldt niet voor schade door het negeren van bepaalde
richtlijnen in deze handleiding en uw dealer zal de verantwoordelijkheid afwijzen voor defecten of problemen die hier rechtstreeks verband mee houden.
Houd de antenne weg van storingsbronnen zoals klimaatregelaars,
haardrogers, magnetrons, enz.
Installeer de antenne zo hoog mogelijk, bij voorkeur aan een raam.
Controleer de signaalsterkte en -kwaliteit. Verplaats de antenne indien nodig.
V. 03 – 05/11/2013 6 ©Velleman nv
ANTDVBT7
Binnenshuis
Buitenshuis
V. 03 – 05/11/2013 7 ©Velleman nv
ANTDVBT7
Montage aan de muur
Montage op een mast
Gebruik binnenshuis

4. Installatie

V. 03 – 05/11/2013 8 ©Velleman nv
