V-WEB SERIES
VSIP-3
3 Megapixel IP Box Camera
3MP
0.1LUX
WDR
Key Features
•External Micro SD Memory Slot
•Support Motion Detection
•Alarm IO Audio In/Out DC Iris
•Industry Standard H.264 with Multi-streams
•Audio compression: G723.1/6.3kbps
•Built in Mic
•BLC (Back Light Compensation)
•PoE
•Onvif 2.2(Profile S)
•Support HTTPS and Multi level password
•Wide Dynamic Range
•Support max 10 users to access
•Progressive Scan CMOS Sensor
•2D + 3D DNR (Digital Noise Reduction)
Recommended Accessories
Outdoor/Indoor Camera Housing
• VCH-619
• VCH-619HB
• VCH-619HBIR
2D-3DNR
ICR
Lens
• VL-1.6MP
PoE
12VDC
Specifications VSIP-3
Sensor Aptina 1/3” WDR CMOS
Max Res/ Max frame rate 2048x1536 / 20fps
Min. Illumination 0.1Lux @ F1.2 (Color)
CAMERA
IR LEDs Works with external IR lighting
Day/Night True Day/Night with ICR Filter
Lens C/Mount Lens Supporting DC Iris / Manual Iris
Video Output Rear Mount BNC video output with IP Address OSD
Electronic Shutter Auto/User 1/5 - 1/50,0000; 50/60Hz software selectable
VIDEO
Compression H.264 High Profile (Support Baseline Profile) / MJPEG
Bit Rate (CBR/VBR) Stream1 50Kbps - 12Mbps ; Stream2 10Kbps - 6Mbps ;
Stream3 ( Fixed)
Quality Setting (VBR) 1-9 (9 Highest)
Multi Streaming User setting of Stream 1/2 at supported Resolutions, Stream3
MJPEG Stream
Brightness/Sharpness Variable 0~100 / 0~100
Gain Control Auto / Fixed 8~102db
Orientation Horizontal Mirror / Vertical Flip
Text Overlay Time/Date/Camera/Custom OSD
Masking 5 User defined masking areas <8% of total picture
NETWORK
Ethernet 1 Ethernet (10/100 Base-T) RJ-45 Connector
TCP/IP IPv4 / IPv6 (DHCP / Fixed)
Compliance Onvif v2.2 Profile-S listed
RTSP Video Standard RFC2326, Support Quick time / VLC Player. User
security authentication (Enabled / Disabled)
Web Language English, Russian, Chinese, Polish
Recording Simultaneous Local Micro SD Memory, remote FTP server, TCP/UDP CMS,
RTSP connection (stream 1, 2, or 3)
Network Simultaneous HTTP, TCP/IP, UDP/IP, RTSP, FTP, DHCP, NTP, PPoE, NTP. Unicast
and Multicast supported
AUDIO
Audio Input/Output 1 x RCA Input / 1 RCA Output @ 1v Line Level
Audio Compression G711 A-Law, G-711 U-Law, RAW_PCM
GENERAL
Power 12 VDC @240mA / PoE Class 3
Temperature Operating: 14°F to 131°F (-10°c to 55°C)
Storage: -4°F to 140°F (-20°C to 60°C)
Operating Humidity 10% -85% RH
Approvals CE / FCC / RoHS Compliant / IK5
Dimensions 5.7 x 2.5 in (145 X 64 mm)
Weight 1.3 lb. (0.55 kg)
Veilux Inc
802 Greenview Dr. Suite 200, Grand Prairie TX. 75050 USA
Toll Free: 1-800-510-6528 Direct: (+1) 214 635-4855 Fax: (+1) 214 988-2858
sales@veilux.net www.veilux.net
