Vector VT-44 Turbo User Manual

TURBO

Thank you for purchasing this VECTOR Radio.

We believe this easy-to-use radio will provide reliable and

dependable communication.

FEATURES

Adopting newest polymer Li-ion battery

Adopting imported PC material in case to make it

solid&abradable

350 hours’ super-long waiting time

CTCSS/DCS

Voice prompt (Chinese/English)

High/Low power adjust

Squelch level adjust

Wide/Narrow bandwidth

Jacklight

PC programmable

Channel scan

Time-out-timer

Low power alarm

PRECAUTIONS BEFORE USING

· Please read the User’s Manual before using . It gives
you important information about how to operate the
portable radio.

· Please put the radio and accessories where the children

can not touch.

· Maintenance can only be performed by professional

technicians.

· Please use the standard battery pack and charger in

order not to destroy the radio.

· Please use the standard antenna , in order not to shorten

the distance.

· Do not expose the radio to sunlight for a long period of
time , nor put it near the heat , nor use it in a high
temperature environment.

· Do not put it in extreme dust nor wet or on unsteady

surfaces.

· Keep it dry . ( Rain or moisture will erode the electronic

board ) .

· Do not transmit when the antenna is not installed .

· If you find bad smell or smog , please turn off the radio

immediately . And take the battery off the radio , then
contact with VECTOR agent.

02

03

05

05

06

07

09

10

11

13

14

17

CONTENTS

SUPPLIED ACCESSORIES

SUPPLIED ACCESSORIES

READY TO WORK

CHARGING NOTES

INSTALLING ANTENNA

INSTALLING BELT CLIP

INSTALLING EXTERNAL SPEAKER/MICROPHONE

ATTACHING/RELEASING BATTERY PACK

DIAGRAM

BASIC OPERATION

FUNCTION INSTRUCTION

CTCSS

DCS

SPECIFICATIONS

CONTENTS　　1

2　　SUPPLIED ACCESSORIES

ACCESSORIES

Battery Charger ( 1 )

Antenna ( 1 )

Belt Clip ( 1 ) Adapter ( 1 )

User

’

s Manual ( 1 )

Li-ion Battery (7.2V) ( 1 )

CHARGING NOTES (1)

1. Please turn the power off before charging . It will effect the battery life when
charging the power-on radio.

2. After the battery is charged to its highest capacity , and then use the radio .
If the radio still shows low power ,please change a new battery .

3. The average usage time of battery pack is 25 hours.
Average usage time is 5% for transmitting, 5% for receiving
and 90% for standby.

READY TO WORK 　 3

●

Battery packs are not charged when they are shipped.

Charge them before use.

●

Initially charging the battery pack after purchase or

extended storage (longer than 2 months) will not bring the

battery pack to its greatest capacity or its normal charge,

which can be done only after repeatedly charging and

discharging for two or three times.

【CAUTIONS】

After the battery is charged to its highest capacity, don’t
charge anymore. Otherwise it will effect the life of the
battery , please take it from the charger.

Do not short-circuit the battery terminals or throw the
battery into fire.

Never attempt to remove the casing from the battery pack.
