Vector VEC020C User Manual

VEC020C

pro

JUMP-START SYSTEM, AIR COMPRESSOR

AND POWER SUPPLY

Portable, Cordless, Rechargeable 12 Volt DC

OWNER’S MANUAL

& WARRANTY INFORMATION

THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USING, READ AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, PLUS YOUR VEHICLE’S BATTER Y MANUFACTURER GUIDELINES. FAILURE TO DO SO COULD RESULT IN INJURY AND/OR PROPERTY DAMAGE.

TEL 954-584-4446 • TOLL FREE: 866-584-5504 • FAX 954-584-5556

4140 SW 28TH WAY, FT. LAUDERDALE, FL 33312

www.vectormfg.com

SAFETY INFORMATION

WARNINGS:

Warning statements identify conditions or practices that may result in personal injur y or loss of life.

1) When working with lead acid batteries, always make sure immediate assistance is available in case of accident or emergency.

2) Always use protective eyewear when using this product: contact with battery acid may cause and/or severe burns, be aware of first aid procedures in case of accidental contact with battery acid.

There is a risk of explosive gases being released when lead acid batteries are being charged or discharged. Failure to follow instructions may cause property damage, explosive hazard, and/or personal injury

4) Make sure the Safety Switch is Off before connecting battery clamps to discharged battery. This will enable the polarity alarm to function.

5) When connecting the battery clamps to a discharged battery, and an alarm sounds, do NOT turn on the Safety Switch - the polarity is reversed. Interchange battery clamps before turning the Safety Switch ON.

6) When charging unit from a 110/120-volt ac electrical outlet in any wet or damp area, make sure that the outlet used is protected by a ground fault interrupt (GFI) Switch.

7) When charging the unit near water , do not allow the electrical cords and outlets to get wet or come near water-electrical shock could result.

8) Jumpstart procedures should only be performed in a safe, dry, well-ventilated area.

9) Always store battery clamps in built-in holsters when not in use. Never touch battery clamps togetherthis can cause dangerous sparks, power arcing, and/or explosion.

10)

When using this unit in proximity to the vehicle’s battery and engine, stand the unit on a flat, stable surface,

and be sure to keep all clamps, cords, clothing and body parts away from moving vehicle components.

11) Do not wear vinyl clothing when jumpstarting a vehicle-friction can cause dangerous static electricity sparks. Remove all jewelry or metal objects that could cause short circuits or react with battery acid.

12) Always disconnect the negative (Black) jumper cable first: followed by the positive (Red) jumper cable.

13) Never allow red and black clamps to touch each other or another common metal conductor-this could cause damage to the unit and/or create sparking/explosion hazard. Always store battery clamps in built-in holsters when not in use.

14)

Do not expose battery to fire or intense heat as it may explode. Before disposing of the battery, protect

exposed terminals with heavy-duty electrical tape to prevent shorting (shorting can result in injury or fire).

15) Do not smoke or use inflammable items (matches, cigarette lighters, etc.) while working on a vehicle’s battery system.

16) Keep unit out of reach of children (whether stored, or in use)!

FIRST AID:

• SKIN: If battery acid comes in contact with skin, rinse immediately with water, then wash thoroughly with soap and water. If redness, pain, or irritation occurs, seek immediate medical attention.

• EYES: If battery acid comes in contact with eyes, flush eyes immediately-for minimum of 15 minutesseek immediate medical attention.

CAUTIONS:

Caution statements advise against certain conditions and practices that may result in damage to vehicles, appliances and/or The START-IT Compact Pro Jumpstart System.

IMPORTANT:

Although this unit is delivered in a partially-charged state - you must fully charge it with the supplied 110/120 Volt AC charger for a full 24 hours before using it for the first time. You can not overcharge the unit using the AC charger method.

1) Use only the supplied cords/adapters for recharging this unit. Do not recharge for more than 3-4 hours maximum using 12 Volt DC method. Recharge unit after each use.

2) All On/Of f switches should be in the OFF position when the unit is charging or not in use. Make sure all switches are in the OFF position before connection to a power source or load.

3) Never inser t anything other than the supplied power/recharging cords or recommended appliance power/ recharging cords into the 12 Volt DC charging/power socket on this unit. Do not use any accessory that is not recommended or provided by the manufacturer.

4) Do not use this unit to operate appliances that draw more than 20 amps.

5) This system is designed to be used only on vehicles with 12 Volt DC battery systems. Do not connect to a 6 Volt or 24 Volt battery system.

6) This system is not designed to be used as a replacement for a vehicular batter y. Do not attempt to operate a vehicle that does not have a battery installed.

7) Vehicles that have on-board computerized systems may be damaged if vehicle battery is jumpstarted. Before jump-starting, read the vehicle’s owner’s manual to confirm that external-starting assistance is advised.

Excessive engine cranking can damage a vehicle’s starter motor. If the engine fails to start after the recommended number of attempts. Discontinue jumpstart procedures and look for other problems that may need to be corrected.

9) Although this unit contains a non-spillable batter y, it is recommended that unit be kept upright during storage, use and recharging. To avoid possible damage that may shorten the unit’s working life, protect it from direct sunlight, direct heat and/or moisture.

10) Check unit periodically for wear and tear. Replace worn or defective parts immediately contact Vector customer service department at (954) 584-4446.

11) Do not attempt to jump-start a frozen battery.

12) Never submerge this unit in water.

13) DO NOT over-inflate tires.

blindness

CONTENTS

1. INTRODUCTION................................................................................. 4,5

2. USING START-IT COMPACT PRO™ AS A JUMPSTART SYSTEM .............. 5,6

2.1 Easy, Step-by-Step Jumpstar ting Instructions ...................................................... 6,7

3. CHARGING/RECHARGING ................................................................. 7

3.1 110/120-Volt AC Charging ............................................................................. 8

3.2 12-Volt DC Charging .......................................................................................8

3.3 Estimated Battery Life ....................................................................................... 8

4. OPERATING AS A PORTABLE POWER SUPPLY..................................... 9

5. EMERGENCY/WORK LIGHT ................................................................ 9

6. COMPRESSOR/TIRE INFLATOR ........................................................... 9

6.1 Compressor Use............................................................................................... 10

6.2 Warnings for Compressor Use.......................................................................... 10

6.3 Tire Inflation or Products w/ Valve Stem ............................................................ 10

6.4 Inflate other Articles (w/out Valve Stem)............................................................ 10

6.5 Typical Inflation Times ...................................................................................... 10

7. REPLACEMENT PARTS......................................................................... 11

7.1 Battery Disposal ............................................................................................... 11

7.2 Battery Replacement......................................................................................... 11

7.3 Battery Disposal ............................................................................................... 11

8. SPECIFICATIONS ................................................................................ 11

WARRANTY ....................................................................................... 12

1. INTRODUCTION

Congratulations on selecting the Vector® START-IT COMPACT PRO™ JUMPSTART SYSTEM, AIR COMPRESSOR and 12 VOLT DC POWER SUPPLY. This compact jumpstarter is unique in the amount of energy it can supply for it’s size. The internal battery is a Vector-developed high density sealed lead acid battery that stores and delivers energy comparable to full sized ordinary jumpstarters. Please read this guide carefully before use to ensure optimum performance and avoid damage to the unit or items that you are using it with. A standard feature of this model is a high pressure, self-contained tire compressor with lighted gauge. This compressor allows quick inflation of vehicle tires to 260 PSI and with supplied adapter nozzles, inflates beach balls, rafts and virtually any low-pressure inflatables. Three different sized nozzles allow for easy connection to all popular inflatables.

The V ector® START-IT COMPACT PRO™ JUMPSTART SYSTEM & 12 VOLT DC POWER SUPPLY is a compact, durable and portable jumpstart system for vehicles and boats that have a standard 12-Volt batter y system. This self-contained, rechargeable system will start most vehicles and boats without the need for a host vehicle or 110/120 V olt AC power supply. It can also be used as a safe, portable source of 12-volt DC electric power in remote locations and/ or emergency situations. It is ideal for use with V ector 12 Volt DC cordless, portable, rechargeable products and MAXX® DC/AC Power Inverters. Use the START-IT COMPACT PRO™ to:

–

Jumpstart: Any engine system with a standard 12 Volt DC battery: boat, truck, car, airplane, RV, personal watercraft, snowmobile, garden tractor, gasoline engine generator, etc.

– Operate: 12-volt DC Fans, inflators, fluorescent work lights, cellular phones*, spotlights,

TVs, portable radios, cassette or CD players, and more. *Can quick-charge a cellular phone by using the phone’s 12-volt DC adapter cord.-Operate: Certain 110/120 Volt AC Accessories (requires a Vector 12 volt power inver ter, sold separately) .

The ST ART-IT COMP ACT PRO SYSTEM has an easy-to-read, series of LED (Light Emitting Diode) charge indicators that show when the unit is fully charged, or the level of charge in the battery. Charge level can be viewed when the charge status push button is pressed. A 12 Volt DC cigarette lighter-type socket is provided for use with appliances that can operate from a vehicle cigarette lighter. This allows maximum portability and utility when the START-IT COMPACT PRO is used in remote locations.

START-IT COMPACT PRO™ can be recharged from any standard 110/120 Volt AC power source using the supplied AC Recharge Adapter . The adapter’s barrel connector attaches to the Recharge Port on the top panel of the junpstarter. A built-in 12-volt appliance socket and the appropriate DC/DC charging/adapter cord is used to recharge the battery from another 12 volt DC source. When pressed, the CHARGE STATUS button will show the battery ‘s power level status (from Low to Full). The green LED full indicator illuminates when the unit is fully recharged and charging can be discontinued. An ON/OFF switch operates the built-in work/ emergency light.

FIGURE 1
