Vector VEC016 User Manual

VEC016

START-IT® COMPACT

JUMP-START SYSTEM

AND 12 VOLT POWER SUPPLY

PORTABLE • CORDLESS • RECHARGEABLE

OWNER’S MANUAL

& WARRANTY INFORMATION

THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY,
OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USING,
READ AND UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND
PRODUCT LABELS, PLUS YOUR VEHICLE’S BATTERY MANUFACTURER GUIDELINES.
FAILURE TO DO SO COULD RESULT IN INJURY AND/OR PROPERTY DAMAGE.

TEL [phone] • TOLL FREE: 866-584-5504 • FAX [phone]

4140 SW 28TH WAY, FT. LAUDERDALE, FL 33312

www.vectormfg.com

1

SAFETY INFORMATION

WARNINGS:

WARNING STATEMENTS IDENTIFY CONDITIONS OR PRACTICES THAT MAY RESULT IN
PERSONAL INJURY OR LOSS OF LIFE.

1) When working with lead acid batteries, always make sure immediate assistance is
available in case of accident or emergency.

2) Always use protective eyewear when using this product: contact with battery acid may
cause blindness and/or severe burns, be aware of first aid procedures in case of
accidental contact with battery acid.

3) There is a risk of explosive gases being released when lead acid batteries are being
charged or discharged. Failure to follow instructions may cause property damage,
explosive hazard, and/or personal injury

4) Make sure the Safety Switch is Off before connecting battery clamps to discharged
battery. This will enable the polarity alarm to function.

5) When connecting the battery clamps to a discharged battery, and an alarm sounds, do
NOT turn on the Safety Switch - the polarity is reversed. Interchange battery clamps
before turning the Safety Switch ON.

6) When charging unit from a 110/120 volt ac electrical outlet in any wet or damp area,
make sure that the outlet used is protected by a ground fault interrupt (GFI) Switch.

7) When charging the unit near water, do not allow the electrical cords and outlets to get wet
or come near water-electrical shock could result.

8) Jump-start procedures should only be performed in a safe, dry, well-ventilated area.

9) Always store battery clamps in built-in holsters when not in use. Never touch battery
clamps together-this can cause dangerous sparks, power arcing, and/or explosion.

10) When using this unit in proximity to the vehicle’s battery and engine, stand the unit on a
flat, stable surface, and be sure to keep all clamps, cords, clothing and body parts away
from moving vehicle components.

11) Do not wear vinyl clothing when jumpstarting a vehicle-friction can cause dangerous static
electricity sparks. Remove all jewelry or metal objects that could cause short circuits or
react with battery acid.

12) Always disconnect the negative (Black) jumper cable first: followed by the positive (Red)
jumper cable.

13) Never allow red and black clamps to touch each other or another common metal
conductor-this could cause damage to the unit and/or create sparking/explosion hazard.
Always store battery clamps in built-in holsters when not in use.

14) Do not expose battery to fire or intense heat as it may explode. Before disposing of the
battery, protect exposed terminals with heavy-duty electrical tape to prevent shorting
(shorting can result in injury or fire).

15) Do not smoke, use matches or cigarette lighters while working on a vehicle’s battery
system.

16) Keep unit out of reach of children (whether stored, or in use)!

FIRST AID:

• SKIN: If battery acid comes in contact with skin, rinse immediately with water, then wash

thoroughly with soap and water. If redness, pain, or irritation occurs, seek immediate
medical attention.

• EYES: If battery acid comes in contact with eyes, flush eyes immediately-for minimum of 15

minutes-seek immediate medical attention.

2

IMPORTANT:

Although this unit is delivered in a partially-charged state - you must fully charge it with
the supplied 110/120 Volt AC charger for a full 24 hours before using it for the first time.

You can not overcharge the unit using the AC charger method.

CAUTIONS:

Caution statements advise against certain conditions and practices that may result in
damage to vehicles, appliances and/or The START-IT Compact Jump-start System.

1) Use only the supplied cords/adapters for recharging this unit. Do not recharge for more

than 3-4 hours maximum using 12 Volt DC method. Recharge unit after each use.

2) All On/Off switches should be in the OFF position when the unit is charging or not in use.

Make sure all switches are in the OFF position before connection to a power source or
load.

3) Never insert anything other than the supplied power/recharging cords or recommended

appliance power/recharging cords into the 12 Volt DC charging/power socket on this
unit. Do not use any accessory that is not recommended or provided by the manufacturer.

4) Do not use this unit to operate appliances that draw more than 15 amps.

5) This system is designed to be used only on vehicles with 12 Volt DC battery systems. Do not

connect to a 6 Volt or 24 Volt battery system.

6) This system is not designed to be used as a replacement for a vehicular battery. Do not

attempt to operate a vehicle that does not have a battery installed.

7) Vehicles that have on-board computerized systems may be damaged if vehicle battery is

jump-started. Before jump-starting, read the vehicle’s owner’s manual to confirm that
external-starting assistance is advised.

8) Excessive engine cranking can damage a vehicle’s starter motor. If the engine fails to start

after the recommended number of attempts. Discontinue jumpstart procedures and look
for other problems that may need to be corrected.

9) Although this unit contains a non-spillable battery, it is recommended that unit be kept

upright during storage, use and recharging. To avoid possible damage that may shorten
the unit’s working life, protect it from direct sunlight, direct heat and/or moisture.

10) Check unit periodically for wear and tear. Replace worn or defective parts immediately

contact Vector customer service department at [phone] or toll-free
[phone].

11) Do not attempt to jump-start a frozen battery.

12) Never submerge this unit in water.

13) All wires, cables and cords must be positioned so that they can not be tripped over or

damaged by moving parts, by pinching or abraiding.

3

CONTENTS

1. INTRODUCTION ............................................................ 5

1.1 ADDITIONAL KEY FEATURES .................................................... 6

1.2 USES OF START–IT COMPACT................................................... 7

2. USE AS JUMP-START SYSTEM........................................ 7

2.1 JUMP-START WARNINGS .......................................................... 7

2.2 FIRST AID................................................................................. 7

2.3 JUMP-START PROCEDURE ......................................................... 8

3. USE AS A 12 VOLT DC PORTABLE POWER SUPPLY .......... 9

4. CHARGING/RECHARGING............................................ 9

4.1 AC RECHARGE ........................................................................ 9

4.2 DC RECHARGE ...................................................................... 10

5. MAINTENANCE - REPLACEMENT PARTS ........................ 10

5.1 LAMP REPLACEMENT .............................................................. 10

6. BATTERY DISPOSAL .......................................................11

7. SPECIFICATIONS ...........................................................11

8. WARRANTY .............................................................. 11,12
