Vax VX22 User Manual

Steam Fresh
Let’s get started
VX22
vax.com.au
Let’s talk safety
Basic safety precautions
This steam mop is intended for household use only and NOT for commercial or industrial use.
WARNING: Danger of scalding WARNING: The stick steam mop head gets
very hot during operation.
• Only use the steam mop indoors away from rain and moisture and keep the area you’re cleaning well lit
• Turn OFF the on/o switch on the steam mop controls before disconnecting or connecting from the mains supply
• Always unplug the steam mop and allow it to cool before connecting or disconnecting the hose or accessories or performing any maintenance
• Children should be supervised to ensure that they do not play with the appliance
• This appliance is not intended for use by children and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety
• Please refer to oor manufacturer’s care recommendations before use, and test your ooring/carpet/rugs by running the steam mop over a small hidden area, if no pile distortion or no
damage occurs continue cleaning. Not suitable for use on wax polished oors or furniture, acrylic surfaces and synthetic, velvet or steam/water sensitive materials
• Keep ngers, hair and loose clothing from moving parts and openings whilst using the steam mop
• This steam mop should not be used to clean electrical appliances such as microwaves, oven, televisions and electrical heating systems etc
• Only Vax recommended cloths and detergent should be used with this steam mop. Using other detergents will invalidate the warranty
IMPORTANT: The steam mop is equipped with a thermostat and a thermal cut-out. If for any reason the unit should overheat, the thermostat will automatically turn the unit o. Should this occur, unplug the steam mop from the electrical outlet and turn o the switch. Let the unit cool, remove and empty the water tank. To re-start the machine, plug it into an electrical outlet and switch it back on.
IMPORTANT: We recommend the use of a Residual Current Device with a Residual Current rating of 30mA or less.
IMPORTANT: This steam mop may not be suitable for all oating oorboards or sealed oors – please check with your oorboard manufacturer rst prior to use.
Don’ts
8 Don’t touch any hot areas/accessories on your steam mop
It’s normal for the steam mop and accessories to heat up during use, always allow them to cool down before handling
8 Don’t use the steam mop if it has been dropped, if there
are visible signs of damage or if it is leaking, if it has been immersed in water or left outdoors
8 Don’t handle the plug or use the steam mop with wet hands 8 Don’t pull or carry this steam mop by the power cord 8 Don’t use the power cord as a handle, pull the power cord
around corners or sharp edges or close a door over the power cord
8 Don’t attempt to remove blockages with sharp objects as this
may cause damage to the steam mop, remove blockages only as instructed in this guide
8 Don’t unplug steam mop by pulling on the power cord or run
over the power cord. If the power cord or plug is damaged please contact our Customer Care Line
8 Don’t aim the steam mop at people, animals, plants and
electrical components such as interior of ovens or wires. Never touch the oor head from a short distance (there is a risk of scalding)
8 Don’t use the steam mop with incorrect voltage as this
may result in damage or injury to the user. The correct voltage is listed on the ratings label
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE AND USE ONLY AS INSTRUCTED IN THIS GUIDE
8 Don’t leave this steam mop unattended while it is connected
to the supply mains
8 Do not use this steam mop with a damaged cord or plug. If
the supply cord is damaged return the steam mop to a Vax authorised Service Agent
8 Do not use without the tank cap in place. Ensure that the water
tank cap has been screwed down fully before use
8 Do not use the steam mop to treat any items of clothing that
are still being worn on the body
8 Never immerse the steam mop in water or in other liquids 8 Do not operate the steam mop without water in the tank 8 Do not use the unit on leather, wax polished furniture or oors,
synthetic fabrics, velvet or other delicate steam or water sensitive materials
8 Do not use on acrylic surfaces 8 Do not overll the tank. Do not exceed the maximum
prescribed lling level. Please use the measuring jug and funnel included
8 Do not use without the hard water lter in place
WARNING: Never leave the steam mop in one spot on any surface for an extended period of time as this may damage the oor surface.
Let’s talk safety
Do’s
3 Always make sure the concentration nozzle and accessories
are securely connected to the handheld before use
3 Always ll the clean water tank with water only, never add
perfume, stain remover or products containing alcohol. Filling the clean water tank with hot or boiling water will damage the machine and invalidate your warranty
3 Always make sure tanks are tted correctly before using
the steam mop
3 Always vacuum your carpets thoroughly and ensure
hard oor areas are free from grit and debris before using the steam mop
3 Always carry the steam mop by the handle 3 Always unplug the steam mop before carrying out
any maintenance or when unattended
3 Turn o all controls on the steam mop before disconnecting or
connecting the power cord, after use always wrap the power cord around the cord clips provided
3 Take extra care when cleaning on stairs 3 Always protect the power cable from heated surfaces or
near open ames
3 Store the steam mop in a cool, dry area away from children 3 Before storing the steam mop please ensure all water/
detergents tanks and hard water lter are thoroughly clean and dry
3 The force and heat of the steam may have an adverse eect on
some materials. Always check whether a surface is suitable for treatment with the steam by carrying out a test before hand on a concealed area
3 The steam mop must be kept level during operation. 3 Always remove the mains plug from the socket and allow
the steam mop to cool down completely before topping up with water
3 In wet rooms, e.g. bathrooms, connect the appliance to sockets
with an RCD adaptor connected in series.
3 Be very careful when cleaning tiled walls with sockets.
WARNING: Always switch o and unplug the steam mop from the electrical outlet before assembling, opening or emptying the water tank, or before connecting/disconnecting the attachments.
Thank you for buying this Steam Fresh
Taking care of your sealed hard oors and surfaces
The Steam Fresh is designed to make steam cleaning your sealed hard oors regularly, as eective and ecient as possible, and this user guide will help you get the most out of your machine.
Maintaining your sealed hard oors with the Steam Fresh will ensure they keep looking beautiful, smell fresh and are hygienically clean.
Taking care of your Steam Fresh
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready when you are to tackle your sealed hard oors.
We’re here if you need us
For troubleshooting simply visit or call:
Australia: 1300 361 505* New Zealand: 0800 800 900* vax.com.au vax.co.nz
*Monday – Friday: 8:30am -5:00pm Calls are charged at the standard local rate. Please make note of the serial
number and model number of the product before calling.
Contents
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
What to do if it goes wrong
Getting in touch
Included with your machine
250ml detergent
2x Microbre cleaning pad
Carpet glider
Handle
Detergent trigger (hidden)
Twin tank release button
Twin tank
Hard water lter (hidden)
Detergent dial
On/O switch
Floorhead
Technical Specication
Name Steam Fresh Voltage 220-240 Wattage 1400-1600w Cord length 7m Weight 3kg
Handle release button
Quick cord release hook
Quick cord release hook
Floorhead release button
Carpet glider
Subject to technical change without notice.
Getting started
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Assembling your steam mop
Push the main body down into the oor head until it clicks into place
Stand the steam mop upright by pushing the main body forward to lock into position
Assembling your steam mop
Place the cleaning pad on the oor white side facing up. Place steam mop onto pad making sure the entire pad covers the oor head
Filling twin tank
WaterDetergent
Push the handle into main body until it clicks into place
Filling twin tank
Press the twin tank release button and lift the twin tank by the handle
Wrap power cord around hooks for easy storage
Twist water cap anti-clockwise and lift to remove
Fill the water tank with 500ml of water, replace cap to tighten
and twist clockwise
Using your machine
IMPORTANT: If you do not want to use detergent on your ooring, select ‘OFF’ on the detergent dial. Always test on an inconspicuous area of ooring rst before using detergent or steam cleaner.
Filling twin tank
Twist the detergent cap anti-clockwise and lift to remove
Pour 50ml of Vax detergent and 250ml of water into the detergent tank then replace cap and twist clockwise to tighten
Before replacing the twin tank make sure the hard water lter is in place
Align the twin tank and push until it clicks into place
Before you begin cleaning
• The steam mop and accessories get very hot during use, always allow them to cool down before handling.
• Always unplug and switch o the steam mop when assembling and lling water and solution tank.
• Always switch o the steam mop before emptying the water tank or changing the cleaning pads/accessories.
IMPORTANT: Please refer to oor manufacturer’s care recommendations before use and test the steam mop on a discrete area of ooring to begin with. Check with ooring manufacturer for suitability on sealed oors prior to use.
• When using the steam mop, basic safety precautions should always be observed.
• Don’t aim the steam mop at people, animals, plants and electrical components such as interior of ovens or wires. Never touch the steam burst or oor head from a short distance. (There is a risk of scalding)
• The steam mop is equipped with a thermostat and a thermal cut-out. If for any reason the steam mop overheats it will switch o. If this happens turn o and unplug the steam mop, allow to cool for a least 2 to 4 hours and re-start.
Using your machine
Place the microbre pad on the oor white side facing up. Place the oor head onto the microbre pad making sure it covers the entire oor head
Plug into mains and slide switch to ‘ON’ position. The blue light will illuminate to show power on. The green light will illuminate to show the steam mop is ready to use
To steam your oors without detergent select ‘OFF’. This is generally recommended for carpet and wood ooring
To use with detergent select min to max as desired. This is generally recommended for tile and vinyl ooring
Using your machine Using your machine
Using your machine
Place your foot onto the oor head and pull handle backwards to recline
Refreshing carpets
Place the microbre pad on the oor white side facing up. Place steam mop onto pad making sure the entire pad covers the oor head
Refreshing carpets
To produce steam, squeeze the trigger. To prevent over wetting oors avoid holding the trigger continuously
With microbre pad attached, hook steam mop into the font of the carpet glider and push to clip into place. Carpet glider should only be used when refreshing carpets
Move the steam mop slowly backwards and forwards paying particular attention to high trac areas*
*Never leave the steam mop in one spot on any surface for an extended period of time as this may damage the oor surface.
Plug into mains and slide switch to ‘ON’ position. The blue light will illuminate to show power on. The green light will illuminate to show the steam mop is ready to use
To refresh carpets select ‘OFF’ setting on the detergent dial
Refreshing carpets
Place your foot onto the oor head and pull handle backwards to recline
To produce steam, squeeze the trigger. To prevent over wetting oors avoid holding the trigger continuously
Refreshing carpets
To release the carpet glider, place your foot on clip and push down. Lift steam mop to remove
WARNING: Always turn OFF the steam mop when tting the cleaning pads.
IMPORTANT: Never use the steam mop without a cleaning pad attached to the oor head. Never leave the steam mop in one spot for extended period of time or with a damp or wet pad attached as this may damage the oors surface.
Move the steam mop slowly backwards and forwards across the carpet paying particular attention to high trac areas
WARNING
When using on carpets, always make sure the microbre cleaning pad is used and covers the oor
head entirely before using the carpet glider. Only use the carpet glider when refreshing carpets.
Taking care of your machine
IMPORTANT: Allow the steam mop to fully cool down before performing any maintenance or troubleshooting checks
Dont leave water or detergent in the twin tank between uses, as this can eect the machines performance, the twin tank
needs to be emptied and rinsed after each use.
Emptying the twin tank
Press the twin tank release button and lift the twin tank by the handle
IMPORTANT: Don’t use bleach or fabric softener when washing the microbre cleaning pad.
Always allow the steam mop to fully cool down before removing the microbre cleaning pad.
Cleaning the microbre cleaning pad
Twist water cap anti-clockwise and lift to remove
Empty any excess water, replace water cap and turn clockwise to tighten
Storing your steam mop
Max 40°C
Hold corner of pad down with foot and lift steam mop to peel away
IMPORTANT: Don’t operate the steam mop without hard water lter in place. The condition of the lter aects the
performance of your machine, check and change lter periodically. If you live in an area of hard water the lter will discolour or darken over time. Depending on water hardness and frequency of use, the lter should be changed every 3 to 6 months or if the lter has discoloured.
The microbre pad is machine washable (Max 40°C) allow to fully dry before use
Wrap the power cord around the quick cord release hooks
Replacing the hard water lter
Remove twin water tank to access the hard water lter
Lift to remove the hard water lter
Clearing blockages
If there is an obstruction to the steam ow through the machine, steam may be released through the bleed valve*
Clearing blockages
New lter - (beige/cream colour)
To remove the oor head from main body push the plastic clip and lift
Hard water lter should be replaced every 3-6 months or when discoloured and darkened (dark orange)
After oor head is removed, using a thin object such as a paper-clip (in the area shown), insert to remove the blockage*
Remove cleaning pad and inspect steam mop base for blockages. If a blockage can be seen use a small thin object such as a paper-clip insert to remove
*Ensure steam cleaner is completely cool before clearing blockages
What to do if it goes wrong Getting in touch
SolutionProblem
Check the ‘This pack contains’ panel on the box to make sure the part is included with your steam mop.
There is an accessory missing
Check the On/O switch is in the On position.
• The plug may not be fully pushed into the electrical socket.
The steam mop won’t turn on?
Why is the steam mop not producing steam/detergent?
• Check the fuse in the plug if this needs replacing.
There may be no water in water tank, check the water tank has water.
Check the water tank is securely tted and the hard water lter is in place.
Hard water lter may be blocked or discoloured and needs to be replaced.
• The water may not yet be at temperature, the green indicator light will be illuminated when its ready.
Steam path may be blocked. Go to ‘Let’s talk technical’ page.
• Putting detergent into the water tank can cause damage to the steam mop.
• Check correct setting has been selected, to use detergent selected vinyl or tile.
• Check the detergent has been diluted to correct strength.
The cleaning pad may already be saturated or dirty, wash the cleaning pad. Go to the ‘Taking care of your machine’ pages.
Why won’t the cleaning pad pick up dirt?
Steam coming from the side of the machine indicates a blockage within the machine. To clear any blockages go to the ‘Taking care
Why is steam coming
of your machine’ pages.
from the side of the steam mop?
Warning: Always unplug the steam mop before performing maintenance/troubleshooting checks
Getting in touch
* Calls are charged at the standard local rate. Please make a note of the serial number and model number of the vacuum cleaner
before calling.
NotesNotes
Distributed by Techtronic Industries Australia Pty. Ltd.
31 Gilby Road, Mt Waverley, VIC 3149 Australia.
Careline AU: 1300 361 505 www.vax.com.au
Careline NZ: 0800 800 900 www.vax.co.nz
© 2014 All rights reserved. VAX®, VAX Lozenge, Air Cordless are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
Loading...
