Gator Car 12V
Let’s get started
VX18
vax.com.au
vax.co.nz
This handheld is intended for household use only and
NOT for commercial or industrial use.
• This handheld is for indoor use only.
• For dry debris use, not to be used on wet surfaces.
• Keep ngers, hair and loose clothing from moving parts
• Only Vax recommend charger, tools and accessories
Let’s talk safety
and openings whilst using the handheld.
should be used with this handheld.
Basic safety precautions
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by
person responsible for their safety. Children should
be supervised to ensure that they do not play with
the appliance.
Please keep instructions for further use.
Don’ts
8 Don’t charge the handheld outdoors
8 Don’t use this handheld if it has been dropped,
damaged, immersed in water or left outdoors.
8 Don’t run over the charger cord or use handheld if
the charger cord or plug is damaged. Please contact
AU: 1300 361 505 / NZ: 0800 800 900
8 Don’t handle the plug or use the handheld with
wet hands.
8 Don’t throw the handheld into re or expose to high
temperatures, as the handheld contains a rechargeable
nickel cadmium battery which may cause damage
or burst.
8 Don’t vacuum ammable or combustible materials
(lighter uid, petrol, kerosene, etc) or use in the
presence of explosive liquids or vapours.
8 Don’t t vacuum harmful or toxic material (chlorine,
bleach, ammonia, drain cleaner etc.)
8 Don’t pull or carry this handheld by the charger cord.
Don’t use the charger cord as a handle, pull the charger
cord around corners or sharp edges or close a door
over the charger cord. Don’t unplug handheld by pulling
on the charger cord.
8 Don’t attempt to remove blockages with sharp objects
as this may cause damage to your handheld.
8 Don’t use the handheld charger with incorrect voltage
as this may result in damage or injury to the user. The
correct voltage is listed on the rating label.
8 Don’t vacuum up hot coals, cigarette butts, matches or
smoking hot burning items or use in an area where
there may be harmful uids (chlorine, bleach, and
ammonia drain cleaner).
Do’s
3 Always make sure lter and dirt container are tted
correctly before using your handheld.
3 Always turn o the Gator handheld vacuum and
disconnect the charger before carrying out
any maintenance.
3 Turn o all controls on the handheld before
disconnecting or connecting the charger.
3 Take extra care when cleaning on the stairs.
3 Always protect the charger cable from heated surfaces
or near open ames.
3 Use only SAA approved 10amp extension cords, non-
approved extension cords may overheat. Care should
be taken to arrange the extension cord as it can be a
trip hazard.
3 Always carry the handheld by the handle.
3 Store your handheld in a cool, dry area.
Please keep instructions for further use.
Thank you for buying this Gator.
Taking care of small cleaning tasks
The Gator Car 12V hand vac is designed to make cleaning as quick and convenient as possible
and this user guide will help you get the most out of your machine.
The Gator Car 12V hand vac range is perfect for small cleaning tasks on surfaces and upholstery.
Taking care of your Gator
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready
when you need to tackle those small jobs.
Taking care of you
We’re here if you need us. For trouble shooting,
simply call or visit:
Australia: 1300 361 505 vax.com.au
New Zealand: 0800 800 900 vax.co.nz
Monday-Friday 8.30am to 5.00pm
Calls are charged at the standard local rate. Please make a note of the serial number and model number
of the product before calling.
Contents
Gator Car
Included with
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
your machine
Filter
(located inside the hand vac)
Charger
Car adapter
(for use in the car or anywhere
with a 12V power socket)
What to do if it goes wrong
Getting in touch
Charging indicator
(red LED)
Filter
release button
Getting to know your machine
On/o switch
Handle
Dirt container
release button
Retractable
crevice tool
Dirt container
Car adapter socket
Charger socket
release button
Technical Specication Charger Specication
Name Gator Car
Voltage 12V
Weight 1.4kg
Capacity 0.3L
Cleaning Time 14 mins
Charging Time 12 hrs
Model no. HK-AC-190A015-AU
Input Voltage 100-240V ~ 50Hz
Subject to technical change without notice.
Getting started
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
CAUTION: For use picking up dry debris. Do not use on wet surfaces
NOTE: The power switch
must be in the o position
to charge the battery.
Plug charger into the mains and insert lead into back
of machine. Initial charging time is 24 hours.
On/o switch: 0 O
I On
The charging light will illuminate continuously whilst
the charger is connected.
Gently pull the
crevice tool.
Push the crevice tool to retract.
WARNING
Failure to initially charge the
battery for 24 hours, may result
in poor battery performance.
To empty the dirt container, press both buttons either
side of the dirt container to release lid.
Using your machine
Empty dirt and
debris over a bin.
We recommend to
empty the dirt container
after each use.
TIP
NOTE: Use the hand vac
with car adapter for use in the
car or anywhere with a 12V
power socket. This will extend
the runtime.
Taking care of your machine
24hr
!
!
!
!
Press the lter removal button and pull dirt container
from machine.
Shake any excess dirt or debris
from the dirt container.
Tap lter against bin.
Whilst holding the dirt container over a bin, grasp the
lter gently and pull out.
tap
40°C max
Wash the lter under running water and leave to
fully dry for a least 24 hours before placing it back
in the hand vac.
WARNING
Do not use the hand vac with a
clogged lter and without the lter
in place.
Taking care of your machine
Gently push lter back into the dirt container.
NOTE: Discoloured or damaged lters need to be replaced.
For replacement lters call AU: 1300 361 505 / NZ: 0800 800 900 or visit vax.com.au /vax.co.nz
BATTERY MAINTENANCE
• Never short-circuit the battery, i.e. never touch both poles simultaneously,
especially with metal objects.
• Never dismantle the battery.
• Never expose the battery to high temperatures.
• Improper handling can lead to liquid leaking from the battery.
This can cause skin irritations. Avoid any contact with the uid.
• Do not replace the battery with a battery of a dierent type.
• If it becomes necessary to replace the battery, contact the Vax Careline
on AU: 1300 361 505 / NZ: 0800 800 900 to determine the location of your
nearest authorised service agent.
To re-attach the dirt container, align bottom of the
dirt container and push until it locks into place.
WARNING
Always unplug the charging lead
from the machine before carrying
out any maintenance.
What to do if it goes wrong
SolutionProblem
• Battery may not be fully charged. If using the hand vac for
the rst time the initial charge should be 24 hours.
Why does my handheld
have no power?
Why won’t the
handheld pick up?
The charging light will illuminate continuously when charger
is connected.
• The nozzle or crevice tool may be blocked, check and clear
any blockage.
• The lter may be clogged, clean the lter. Go to ‘Taking care
of your machine’.
• The dirt container may be full, empty the dirt container.
Go to ‘Using your machine’.
• The battery is getting weak, let the battery run until it stops
and recharge.
Why won’t the battery
recharge?
• The charger may not be inserted correctly.
Getting in touch
* Calls are charged at the standard local rate. Please make a note of the serial number and model number of the vacuum cleaner
before calling.
Distributed by Techtronic Industries Australia Pty. Ltd.
31 Gilby Road, Mt Waverley, VIC 3149 Australia.
Careline AU: 1300 361 505 www.vax.com.au
Careline NZ: 0800 800 900 www.vax.co.nz
