Vax VRS7U, powermax pet VRS7U Instruction Manual
vax.co.uk
Please read carefully before using this cleaner.
Always fully extend the mains cable before use.
Retain for future reference.
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
instruction manual
Bagless upright
Vax model number:
VRS7U
P
E
T
WARNING: This cleaner has a constantly
rotating brushbar which, when left in
contact with lino, parquet and other hard flooring
could potentially cause some damage to the floor
surface.
NOTE: Vax recommends that you raise the height
of the brushbar when using this cleaner on lino and
hard flooring. Vax cannot be held responsible for
damage to these surfaces if the user fails to take
notice of this recommendation.
!
Version 1
VRS7U Powermax Pet User Guide v1.0.qxd:User Guide 15/7/10 15:57 Page 1
VRS7U
1. Diagram
vax.co.uk
2
parts overview
5
4
3
2
1
14
13
12
11
10
6
7
8
9
20
Fig.1/1
15
16
17
18
19
1 Handle
2 Dirt container release button
3 Dirt container
4 Lower hose
5 Clear window
6 Scuff guard
7 HEPA, antibacterial and carbon filter
8 Dirt container lid
9 Main 1.5m hose
10 Cord clip
11 Extension wand
12 Carry handle/cord wrap
13 On/off pedal
14 Handle release pedal
15 Cord wrap with quick release
16 Power cord
17 Crevice tool
18 2-in-1 tool
dusting brush/upholstery tool
19 Hose bracket
20 TurboTool
VRS7U Powermax Pet User Guide v1.0.qxd:User Guide 15/7/10 15:57 Page 2
3
Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308
safety information
2. Safety Information
For Household Use Only
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry
surfaces. Do not handle the plug or vacuum cleaner
with wet hands. Do not use outdoors or on wet
surfaces.
2. Turn off the vacuum cleaner controls before
disconnecting or connecting from the mains supply.
3. Always unplug the vacuum cleaner before connecting
or disconnecting the vacuum hose and accessories.
4. Children should be supervised to ensure that they
do not play with the appliance.
5. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
6. Use only as described in this manual. Use only Vax
recommended attachments.
7. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use the vacuum cleaner with a
damaged cord or plug. If the supply cord is damaged,
it must be replaced by the manufacturer or a
recommended Service Agent to avoid hazard and
invalidating the guarantee.
8. Do not pull or carry by cord/hose. Do not use the
cord/hose as a handle, close a door on the cord/hose
or pull cord/hose around sharp edges or corners. Do
not run the vacuum cleaner over the cord. Keep the
cord away from heated surfaces.
9. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict airflow. Keep all openings free of dust, lint, hair or
anything that might reduce airflow.
10. Keep hair, loose clothing, fingers and all parts of
the body away from openings and moving parts.
11. Do not pick up hot coals, cigarette butts, matches
or any hot, smoking or burning objects.
12. Do not pick up flammable or combustible
materials (lighter fluid, petrol, kerosene etc.) or use
in the presence of explosive liquids or vapours.
13. Do not vacuum up harmful or toxic material
(chlorine, bleach, ammonia, drain cleaner etc.).
14. Do not vacuum up hard or sharp objects such as
glass, nails, screws, coins, etc.
15. Do not use without ALL of the filters in place.
16. Take extra care when vacuuming on stairs.
17. Keep vacuuming area well lit.
18. Store the vacuum cleaner in a cool, dry area.
19. Turn off the on/off switch before unplugging the
vacuum cleaner.
20. Use only CE-approved 13 amp extension cords.
Non-approved cords may overheat. Care should
be taken to arrange the cord so that the cord
cannot be tripped over.
WARNING: Always switch off and unplug the vacuum
cleaner from the electrical outlet
before assembling, opening or emptying the dirt
container, or before connecting/disconnecting
the attachments.
CAUTION: The vacuum cleaner is a very powerful
unit. Before plugging the cord into the electrical
outlet, make sure the switch is in the ‘off’ position.
Hold the vacuum cleaner firmly when starting
and in use.
IMPORTANT: If the inlet or hose is blocked, switch off
the vacuum cleaner and remove the blockage(s)
before re-starting the vacuum cleaner.
This vacuum cleaner is intended for household use
only and not for commercial or industrial use.
PLEASE KEEP THESE INSTRUCTIONS FOR FURTHER
USE.
!!!
Motor Thermostat
IMPORTANT: The motor is equipped with a thermal
cut-out. If for any reason, the vacuum cleaner should
over-heat, the thermostat will automatically turn the
unit off. Should this occur, unplug the vacuum cleaner
from the electrical outlet and turn off the switch.
Remove the dirt container and empty. Clean the
filters. Allow the cleaner to cool for approximately one
(1) hour. To re-start, plug into an electrical outlet and
switch back on.
VRS7U Powermax Pet User Guide v1.0.qxd:User Guide 15/7/10 15:57 Page 3
4
assembly
3. How to Assemble
IMPORTANT: Always unplug the vacuum cleaner
from the electrical outlet before assembling or
removing the accessories.
Tool required: Crosshead screwdriver
1. Place the base of the cleaner so it is facing away from
you. Position the body so that the lower hose is on your
right hand side. Push the body down into place.
To secure the body in place insert one of the screws
supplied into the back of the cleaner, through the hole
located above the on/off pedal.
Pull back the flap on the clear window. Match the slots on
the hose to the tabs on the hose inlet. Push down firmly
on the cuff and turn anti-clockwise to lock in place
(Fig.3/1).
2. Align the holes in the tool holder, with the holes on top
of the body. Use two of the screws supplied to secure the
tool holder in place. Do not over tighten. With the hose clip
on the handle facing you place it onto the top of the body
of the cleaner (Fig.3/2).
3. Push down firmly and line up the screw hole on the rear
of the handle. Use one of the screws supplied to secure
the handle on the body.
Insert the small end of the main hose into the tool holder
on the right hand side (Fig.3/3).
4. Using the handle, attach the main hose into the left
hand side of the cleaner. Press down firmly to secure in
place. The main hose can then be secured in the top and
side of the tool holder.
Push the dirt container lid firmly on top of the dirt
container and place it onto the cleaner. The dirt container
will snap into place in the body of the cleaner.
Attach the tools to the tool holder. The 2 in 1 tool fits over
a post at the back of the vacuum cleaner.
The crevice tool fits into a round slot on the rear right hand
side of the tool holder. The extension wand hose on the
left hand side (Fig.3/4).
5. Store the TurboTool in the caddy on the handle.
(Fig.3/5).
!
Phillips screwdriver required
Fig.3/1
Fig.3/2
Fig.3/3
Fig.3/5
Fig.3/4
vax.co.uk
VRS7U Powermax Pet User Guide v1.0.qxd:User Guide 15/7/10 15:57 Page 4
