Vax VPW2BC, PowerWash3 VPW4C User Manual
VPW2BC
LET’S GET STARTED.
DESIGNED FOR HEAVY
DUTY, OUTDOOR CLEANING
Let’s talk safety
Basic
safety
precautions
Don’ts
Do’s
This pressure washer is intended for household use only
and NOT for commercial or industrial use.
•
This Pr
essure washer is for outdoor use only.
•
It is y
our responsibility to check the suitability of the surface
to be cleaned. V
ax UK Ltd cannot be held responsible for
damage caused.
• K
eep ngers, hair and loose clothing from moving parts
and openings whilst using
the pressure washer.
•
When using y
our pressure washer the recommended working
distance betw
een the nozzle and surface area or object to be
cleaned is 30cm.
•
Don
’t leave the pressure washer unattended or running when not
in use for more than 5 minutes without depressing the trigger.
•
Don
’t use this pressure washer if it has been dropped,
damaged or
immersed in water.
•
Don
’t use pressure washer if the power cord or plug is
damaged. Please c
ontact our Customer Care Line on (UK)
0330 026 8455 (R
OI) 1-800 928 308. (Mon - Fri 8:30am
to 6:30pm, Sat 9:00am to 5:00pm).
•
Don
’t handle the plug of the pressure washer with wet hands.
•
Don
’t use the pressure washer without supply hose (minimum
length 7
.5m) in place and unwind the hose fully from reel.
• Always wear suitable clothing footwear and eye protection
whilst using
the pressure washer.
• Always connect the water supply, remove the lance and squeeze
the
trigger to run water through the machine before switching
the po
wer on.
• Always use a suitable hose connector to match the coupling
on
the pressure washer with a non-return valve at tap end
of
the supply hose.
• Always unplug the pressure washer before cleaning or carrying
out any
maintenance.
• Always turn o and unplug the pressure washer before
disc
onnecting or connecting the hose, after use always
wrap the pressure hose and power cord around
the storage clips provided.
• This appliance can only be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children should not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
• Vax only recommend the use of Vax genuine accessories and solution
to be used with this pressure washer. The use of non-branded Vax
accessories and solution will invalidate your warranty.
• Don’t use the pressure washer without the water lter in place.
•
Don
’t pull or carry this pressure washer by the power cord. Don’t use the
power cord as a handle, pull the power cord around corners or sharp edges
or close a door over the power cord. Don’t unplug pressure washer by pulling
on the power cord.
•
Don
’t aim the pressure washer at people, animals, plants, electrical
components, wires, or the pressure washer itself.
•
Don
’t use the pressure washer on electrical components, damaged/delicate
paint surfaces, tyres, engines/motors.
•
Don
’t use the pressure washer with incorrect voltage as this may result in
damage or injury to the user. The correct voltage is listed on the rating label.
• Always release any built up pressure in the handle prior to disconnecting the
hose and ensure water inlet lter is clean prior to storage in a cool dry place.
•
Use only
CE approved 13amp extension cords with RCD, non-approved
extension cords may overheat. Care should be taken to arrange the extension
cord as it could be a trip hazard.
• Always make sure the power/extension cord is fully unwound and prevent
the power/extension cord from getting wet during use.
• Always replace the fuse in the plug with a British 13amp fuse.
• Always protect the power cable from heated surfaces or near open ames.
• Always carry the pressure washer by the handle.
• Always check water hose and accessories are not damaged, broken or worn
before use.
Thank you for buying this Pressure Washer.
Taking care of your outdoor cleaning
This pressure washer is designed to make outdoor cleaning tasks as eective and ecient
as possible and this user guide will help you get the most out of your machine.
Completing outdoor cleaning tasks using a Vax pressure washer will keep your outdoor
items and surfaces cleaner for longer.
Taking care of your Pressure Washer
Also inside this guide are instructions on maintaining your new machine, so that it’s always
ready when you are to tackle your outdoor cleaning tasks.
Let us know what you think @VaxUK
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0330 026 8455 (ROI) 1-800 928 308
Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.
Alternatively, you can write to us at:
Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich, WR9 0LW, UK
This user guide can be found online at: vax.co.uk/support
Contents
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Let’s talk technical
Accessories
What to do if it goes wrong
Getting in touch
Power Wash 1 Complete
Included with
your machine
Pressure Hose
Trigger Handle
Lance
Jet Nozzle
(orange nib)
Turbo Nozzle
(black nib)
Solution Nozzle
Nozzle Cleaning Tool
Patio Brush
Car Brush
Extension Tube
Universal Detergent
