Bagless Cylinder
User Guide
Vax Careline: AU: 1300 361 505
NZ: 0800 800 900
Get Cleaning...
What’s your Vax’s model number? (Located on the top flap of the packaging)
What’s your serial number? (Located on the base of the machine)
Note these down in case you need them in future. Please keep instructions for further use.
vax.com.au
Vax Air Series
VCAB1500 / VCABW1500 / VCAT1500
Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
Machine Overview
1 Hose connector
2 Dirt container
3 Cyclone separator and shroud
4 Carry handle
5 Dirt container release button
6 Cord rewind button (hidden)
7 Floor head parking slot
8 On/o button
9 Post-motor lter cover
10 Primary separator
11 HEPA H12 post-motor lter (VCAB1500 /
VCABW1500 models only)/
HEPA H12 antibacterial post-motor lter
(VCAT1500 model only)
12 Pre-motor lter
13 Turbobrush (VCAT1500 model only)
14 Combination oor head
(VCAB1500 / VCABW1500 models only)
15 Telescopic extension tube
16 Dusting brush
17 Crevice tool
18 Flexible hose and handle
19 Hard oor tool (VCAT1500 model only)
20 TurboTool (VCAT1500 model only)
21 Stretch hose (VCAT1500 model only)
22 Upholstery tool
23 TurboTool connector (VCAT1500 model only)
Unit
1
11
2 3 754
6
810 9
12
NOTE: Some parts may vary according
to model. Please check inside ap of box
for more details.
13
16
14
17
15
Accessories
vax.com.au 2
Filters
22 23
18
21
19
20
General Safety Information
FOR HOUSEHOLD USE ONLY.
When using the vacuum cleaner, basic safety precautions should
always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry surfaces. Do not
handle the plug or vacuum cleaner with wet hands. Do not use
outdoors or on wet surfaces.
2. Turn off the vacuum cleaner controls before disconnecting or
connecting from the mains supply.
3. Always unplug the vacuum cleaner before connecting or
disconnecting the vacuum hose and accessories.
4. Children should be supervised to ensure that they do not play
with the appliance.
5. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
6. Use only as described in this manual. Use only Vax
recommended attachments.
7. Do not use the vacuum cleaner if it has been dropped, damaged,
left outdoors or dropped into water. Do not use the vacuum
cleaner with a damaged cord or plug. If the supply cord is damaged,
it must be replaced by the manufacture or a recommended
Service Agent to avoid hazard and invalidating the warranty.
8. Do not pull or carry by cord. Do not use the cord as a handle,
close a door on the cord or pull cord around sharp edges or
corners. Do not run the vacuum cleaner over the cord. Keep the
cord away from heated surfaces.
9. Do not put any objects into openings. Do not use with any
openings blocked and do not restrict air-flow. Keep all openings
fee of dust, lint, hair or anything that might reduce airflow.
10. Keep hair, loose clothing, fingers and all parts of the body away
from openings and moving parts.
11. Do not pick up hot coals, cigarette butts, matches or any hot,
smoking or burning objects.
12. Do not pick up flammable or combustible materials (lighter fluid,
petrol, kerosene etc.) or use in the presence of explosive liquids
or vapours.
13. Do not vacuum up harmful or toxic materials (chlorine, bleach,
ammonia, drain cleaner etc.).
14. Do not vacuum up hard or sharp objects such as glass, nails,
screws, coins, etc.
15. Do not use without ALL of the filters in place.
16. Take extra care when vacuuming on stairs.
17. Keep vacuuming area well lit.
18. Store the vacuum cleaner in a cool, dry area.
19. Turn off the on/off switch before unplugging the vacuum cleaner.
20. Use only SAA approved 10amp extension cords. Non-approved
cords may overheat. Care should be taken to arrange the cord
so that the cord cannot be tripped over.
WARNING: Always switch off and unplug the vacuum
cleaner from the electrical outlet before assembling, opening
or emptying the dirt container, or before connecting/disconnecting
the attachments.
CAUTION: The vacuum cleaner is a very powerful unit.
Before plugging the cord into the electrical outlet, make sure
the switch is in the ‘off’ position.
IMPORTANT: if the inlet, hose or telescopic tube is blocked,
switch off the vacuum cleaner and remove the blockage(s)
before re-starting the vacuum cleaner. See Maintenance:
Clearing blockages.
IMPORTANT: Washing filters maintains vacuum
performance. Vax recommends that they should be checked
and cleaned periodically (depending on the level of use).
Make sure all filters are completely dry before inserting back
into the vacuum cleaner.
IMPORTANT: The motor is equipped with a thermal cut-out.
If for any reason the unit should overheat, the thermostat will
automatically turn the unit off. Should this occur, unplug the
vacuum cleaner from the electrical outlet and turn off the
switch. Remove dirt container and empty Clean filters. Allow
the unit to cool for approximately one (1) hour. To re-start,
plug into an electrical outlet and switch back on.
This machine is intended for household use only, and NOT
for commercial or industrial use.
PLEASE KEEP THESE INSTRUCTIONS FOR FURTHER USE.
3
Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
Operation
Keep your Vax like new
Assembling your vacuum cleaner
IMPORTANT: The condition of the lters aects
the performance of your machine. Please check
and wash lters periodically (depending on the level
of use). For full cleaning instructions, see pages 6-8.
IMPORTANT: Do not use the vacuum cleaner
without all of the lters in place.
NOTE: The Turbo Tool (with Turbo Tool connector attached), Turbobrush, hard oor tool, crevice tool, upholstery
tool and dusting brush can all be attached to the telescopic tube or hose handle.
NOTE: The stretch hose should not be used as the main vacuum hose. The stretch hose is recommended to be
used for a period of 20 minutes maximum.
vax.com.au 4
Operation
Operating the appliance and accessories
NOTE: Fully unwind the power
cord. The yellow mark on the cord
indicates the recommended cord
length. Do not exceed the cord
length beyond the yellow mark.
Packing away and storage
NOTE: For convenience there is a parking slot located at the rear of the
vacuum cleaner where the oor head and tubes can be attached for storage
and carrying.
To vary the suction power,
open/close the sliders on the hose
handle/Turbobrush.
5
Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
Maintenance (Keep your Vax as good as new)
Emptying and cleaning the dirt container
Press dirt container release
button and lift.
Press the dust release lever
to empty dirt.
Advanced cleaning – primary separator
tap
24hr
Advanced cleaning – cyclone separator
vax.com.au 6
Wipe to clean.
Parts must be
completely dry
before using
your machine.
Maintenance
tap
Cleaning the pre-motor lter
(Keep your Vax as good as new)
Cleaning the HEPA post-motor lter
WARNING: Do not wash the post-motor lter.
7
Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
Maintenance
Tabs
(Keep your Vax as good as new)
Clearing blockages
WARNING: To reduce the risk of electrical shock, the power cord must be disconnected before performing
maintenance/troubleshooting checks. Turn the vacuum cleaner o and unplug from the electrical socket.
Hose blockages
The exible hose may be disconnected from the
vacuum cleaner. Carefully remove any blockages
found and reconnect the hose securely.
Removing blockages from the TurboTool
Turn the TurboTool over and slide
o the locking ring.
Pivot lowering housing and
remove clog.
Accessory blockages
Remove accessory from the hose/telescopic tube.
Carefully remove the blockage and return
to the cleaner.
(VCAT1500 model only)
To re-assemble, be sure that the
tabs are engaged. Pivot the
lower housing closed. Slip the
locking ring into the groove
at the neck of the TurboTool to
complete reassembly.
Removing blockages from the Turbobrush (VCAT1500 model only)
vax.com.au 8
Lay the Turbobrush oor head on a at surface and turn over to expose
the brushbar. Using a pair of scissors, cut through any threads or hairs
caught by the brushbar that have wrapped around the guides. Be careful
not to cut the bristles on the brushbar.
FAQ’s
WARNING: To reduce the risk of personal injury, unplug the vacuum cleaner before performing
maintenance/troubleshooting checks.
Problem Solution
There is an accessory missing Check the ‘Machine Overview’ page in this guide to make sure the part is definitely included in
your unit
If it is missing, we’re here to help. Simply call us on AU 1300 361 505 or NZ 0800 800 900
Why won’t the vacuum
cleaner pick up?
Why is dust escaping from the
vacuum cleaner?
What do I do if the unit/accessory
becomes damaged or broken?
Why won’t the accessory pick
up properly?
The dirt container may be incorrectly installed; remove the dirt container from the unit by
pressing the dirt container release button and then re-attach it to the unit, ensuring it is locked
firmly back into place.
The filter may be clogged; Refer to ‘Maintenance: Cleaning the filters’ on page 7.
The dirt container may be blocked; refer to ‘Maintenance; Emptying and cleaning the dirt
container’ on page 6.
There may be a blockage in the tube/hose. Disconnect from the vacuum cleaner, carefully
remove any blockages found and reconnect securely.
The filter may be clogged; refer to ‘Cleaning the filters’ on page 7.
The dirt container may be blocked; refer to ‘Maintenance; Emptying and cleaning the dirt
container’ on page 6.
The dirt container may be incorrectly installed; remove the dirt container from the unit by
pressing the dirt container release button and then re-attach it to the unit, ensuring it is locked
firmly back into place.
We’re here to help. Simply call us on AU 1300 361 505 or NZ 0800 800 900
or visit vax.com.au
Hose blockages: remove the hose from the unit. Carefully remove any blockages found and
reconnect hose securely.
Accessory blockages: remove accessory from handle/tube. Carefully remove any blockages
found and re-attach to the vacuum cleaner.
The accessory may be faulty. Simply call us on AU 1300 361 505 or NZ 0800 800 900
Why will the vacuum cleaner
not run?
9
It may not be plugged into the electrical outlet correctly; ensure that the plug is pushed in securely.
The electrical outlet may not be working properly; check the fuse or breaker, or consult an electrician.
The motor thermostat may have tripped; switch off and unplug the vacuum cleaner, and leave for
one hour before switching the cleaner back on.
Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
Other Information
Vax Service & Help
Vax Careline:
Australia: 1300 361 505
New Zealand: 0800 800 900
Monday-Friday 8.30am to 5.00pm
If you have queries or concerns about using your Vax, call the Vax Careline. Calls are charged at the standard
local rate. Please make a note of the serial number and model number of the vacuum cleaner before calling.
For the nearest Service Agent, please call the Vax Customer Careline or visit vax.com.au
Technical Specication
Voltage: 220-240V ~50Hz
Wattage: 1500W
Capacity: 2.5L
Filters: Pre-motor lter (washable)
HEPA H12 post-motor lter/HEPA H12 antibacterial post-motor lter (not washable)
Cord length: 6m (approx.)
Weight: 5.6kg (approx.)
Subject to technical change without notice.
N197
Double
Insulated
\
Indoor
Use
Read
Instructions
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
vax.com.au 10
Level 1, 660 Doncaster Road, Doncaster, Australia 3108.
www.vax.com.au Service Line: AU: 1300 361 505 / NZ: 0800 800 900
Distributed by Techtronic Industries Pty. Ltd.
Loading...
