CLEANING
SOLUTION
V-135 Series Rapide Spring User Guide.qxd:V-135B User Guide 20/8/09 09:10 Page 1
Vax careline
0844 4128 455
Carpet washer
Vax model number:
V-135 Series
vax.co.uk
instruction manual
Please read carefully before using this cleaner.
Always fully extend the mains cable before use.
Retain for future reference.
CLEANING
SOLUTION
V-135 Series Rapide Spring User Guide.qxd:V-135B User Guide 20/8/09 09:10 Page 2
vax.co.uk
1. Diagram
V-135
1
2
3
2
6
8
Fig.1/1
1 Handle
2 Cord hooks
3 Power cord
4 Clean water tank release
5 Clean water tank
6 Dirty water tank lid
4
5
7
10
9
12
11
7 Wheels
8 Suction channel
9 Handle assembly release position
10 On/off switch
11 Handle release pedal
12 Vax Cleaning Solution
2
parts overview
!
V-135 Series Rapide Spring User Guide.qxd:V-135B User Guide 20/8/09 09:10 Page 3
ax Careline 0844 4128 455
V
2. Safety Information
FOR HOUSEHOLD USE ONLY.
When using the carpet washer, basic safety precautions
should always be observed, including thefollowing:
1. Do not leave the carpet washer unattended when
plugged in. Unplug it from socket when not in use.
2. To prevent electric shock do not use outdoors.
3. Notto be used as atoy.Childrenshouldbe supervised to
ensure that they do not play with the appliance.
4. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experienceand knowledge,
unless they have been given supervision or instruction
concerning the use of the appliance by a person
responsible for theirsafety.
5. Use only as described in this manual.
6. Do not use with a damaged cord or plug. If the supply
cord and/or plug is damaged, they must be replaced
by the manufacturer, a Vax Service Agent or similarly
qualified persons in order to avoid hazard.
7. Do not pull or carry by the cord, use the cord as a
handle, allow the cord to come into contact with hot
or sharp surfaces or close a door on the cord.
8. Do not unplug by pulling on the cord.
9. Do not handle the plug or carpet washer with wet
hands.
10. Do not put any objects into openings or operate with
openings blocked, keep them free of anything that
may reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
12. Do not use the carpet washer on any glowing,
burning or smoking particles.
13. Do not use without the solution tank and dirty water
tank in place.
14. Turn off all controls before unplugging.
15. Do not use to pick up flammable or combustible
liquids such as petrol, or use in areas where they may
be present.
16. Keep the unit on the floor.
17. Do not use an extension cord.
18. Do not attempt to remove blockages with sharp
objects as they may cause damage.
19. Store indoors put away after use to prevent tripping
accidents.
20. Using improper voltage may result in damage to the
motor and possible injury to the user. The correct
voltage is listed on the rating label.
21. A hazard may occur if the carpet washer runs over
the power supply cord.
22. To prevent dirty water from running into motor, do
not hold the appliance upside-down or lay on its side.
Use appliance in normal vacuuming position.
23. Use extra care when cleaning on stairs.
24. Do not carry appliance while motor is running.
NOTE: Carpets should be dry vacuumed thoroughly
before washing.
NOTE: The unit must be unplugged from the mains
socket outlet after use, and before cleaning or
maintaining the unit.
IMPORTANT: This unit is not intended for
commercial use.
PLEASE KEEP THESE INSTRUCTIONS
FOR FURTHER USE.
safety information
3
!
V-135 Series Rapide Spring User Guide.qxd:V-135B User Guide 20/8/09 09:10 Page 4
vax.co.uk
3. Assembly
Putting your cleaner together
Insert middle frame to machine base (Fig 3/1).
Fig.3/1
Insert one screw on either side of middle frame to secure
(Fig 3/2).
Fig.3/2
Slide the upper handle down onto the unit. The handle
will click and lock in place. Run the mains wire above the
upper cord hook and secure with the cord clip (Fig 3/3).
4. Operation
IMPORTANT: Turn off when emptying and filling
the tanks and performing any maintenance.
Grasp the solution reservoir under the handle and press
the handle release lever in (Fig 4/1).
Fig.4/1
Tilt the solution reservoir away from the cleaner and
remove (Fig 4/2).
Fig.4/2
Unscrew the cap from the bottom of the solution
reservoir (Fig 4/3).
Fig.3/3
4
assembly/ operation
Fig.4/3
Pour the correct amount of Vax Cleaning Solution as
directed into the clean water tank
