instruction manual
Upright carpet washer
Vax model number:
V-126
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:17 Page 1
V-126
1. Diagram
www.vax.co.uk
2
parts overview
12
11
10
9
8
2
3
4
5
6
7
1
14
13
16
1
5
Fig.1/1
1 Solution trigger
2 Folding handle
3 Wash tool
4 Reset button
5 Carry handle
6 Cord wrap
7 Dirty water tank
8 Handheld dirty water tank
9 Handheld tank release catch
10 Power on/off button
11 Handheld slide release
12 Folding handle dial
13 Clean water tank
14 Handle release pedal
15 AAA carpet cleaning solution
16 Trigger spray bottle
AAA
ANTI
ALLERGEN
A
DDITIVE
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:17 Page 2
3
V
ax Careline 0870 606 1248
safety information
2. Safety Information
FOR HOUSEHOLD USE ONLY.
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. Do not leave the carpet washer unattended when
plugged in. Unplug it from socket when not in use.
2. To prevent electric shock do not use outdoors.
3. Nottobe used asa toy. Children shouldbe supervisedto
ensure that they do not play with the appliance.
4. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning the use of the appliance by a person
responsible for their safety.
5. Use only as described in this manual.
6. Do not use with a damaged cord or plug. If the supply
cord and/or plug is damaged, they must be replaced
by the manufacturer, a Vax Service Agent or similarly
qualified persons in order to avoid hazard.
7. Do not pull or carry by the cord, use the cord as a
handle, allow the cord to come into contact with hot
or sharp surfaces or close a door on the cord.
8. Do not unplug by pulling on the cord.
9. Do not handle the plug or carpet washer with wet
hands.
10. Do not put any objects into openings or operate with
openings blocked, keep them free of anything that
may reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
12. Do not use the carpet washer on any glowing,
burning or smoking particles.
13. Do not use without the solution tank and dirty water
tank in place.
14. Do not use the vacuum without the dust bag in place.
15. Turn off all controls before unplugging.
16. Do not use to pick up flammable or combustible
liquids such as petrol, or use in areas where they may
be present.
17. Keep the unit on the floor.
18. Do not use an extension cord.
19. Do not attempt to remove blockages with sharp
objects as they may cause damage.
20. Store indoors put away after use to prevent tripping
accidents.
21. Using improper voltage may result in damage to the
motor and possible injury to the user. The correct
voltage is listed on the rating label.
22. A hazard may occur if the carpet washer runs over
the power supply cord.
23. To prevent dirty water from running into motor, do
not hold the appliance upside-down or lay on its side.
Use appliance in normal vacuuming position.
24. Use extra care when cleaning on stairs.
25. Do not carry appliance while motor is running.
NOTE: Carpets should be dry vacuumed thoroughly
before washing.
NOTE: The unit must be unplugged from the mains
socket outlet after use, and before cleaning or
maintaining the unit.
IMPORTANT: This unit is not intended for
commercial use.
PLEASE KEEP THESE INSTRUCTIONS
FOR FURTHER USE.
!
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:17 Page 3
www.vax.co.uk
4
preparing the carpet / getting ready to wash
3. Preparing the Carpet
IMPORTANT: Do not use the cleaner as a dry
vacuum.
1. Vacuum carpet thoroughly. Use a vacuum cleaner with a
revolving brushbar for best results.
2. Remove as much furniture from the room as possible. If
unable to remove the furniture, place plastic or foil under
and around the legs until the carpet has dried completely.
Helpful hints for cleaning carpet:
1. Only use Vax recommended carpet cleaner with this
carpet washer.
2. Do not oversaturate carpet with cleaning solution while
using the carpet washer.
3. For heavily soiled areas, additional applications may be
necessary.
4. Allow plenty of time to dry carpet thoroughly.
5. Wipe cleaning solution from woodwork and wood to
prevent any damage.
6. Try not to walk on carpet until it is completely dry.
7. After carpet is thoroughly dry, vacuum the carpet
using a vacuum cleaner with a revolving brushbar.
8. Before cleaning, determine where to start and end,
making sure not to walk over previously cleaned
areas.
Check for colour fastness
Before cleaning carpet, test for colour fastness. Dampen a
white cloth with solution. Test on a small inconspicuous
area prior to washing. Gently rub the cloth over the area.
Check each colour for colour bleeding. If the cloth remains
clean, it should be safe to clean the carpet.
After cleaning
• Allow carpet to dry completely. Try not to walk on the
carpet until it is dry.
• If it is necessary to walk on the carpet, place white
towels on the areas to be walked on.
• If the carpet is not dry and the furniture must be placed
back in the room, use plastic or foil under the furniture to
prevent staining the carpet.
• Thoroughly clean the dirty water tank with warm
(max 40ºC) tap water.
4. Getting Ready to Wash
To put the cleaner into the upright position, pull the handle
up into place. The folding handle dial will lock automatically
to secure.
Remove the clean water tank from the back of the
machine (Fig.4/1)
Unscrew the clean water tank cap.
Add Vax AAA cleaning solution according to the directions
given on the bottle.
Fill the remainder of the clean water tank with warm water
(max 40°C) (Fig.4/2). Replace cap.
Replace the clean water tank into the back of the machine,
ensuring it is pressed firmly downwards to secure.
!
Fig.4/1
Fig.4/2
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:17 Page 4
5
V
ax Careline 0870 606 1248
usage
5. Usage
Plug machine into power supply
Press power on/off button to turn the cleaner on
NOTE: Never leave the unit unattended with the
power on. Turn off when emptying and filling tanks.
Do not over-wet the carpets.
Washing carpets
Step onto handle release pedal to put into cleaning
position (Fig.5/1)
While depressing the solution trigger, pull carpet washer in
backward motion. Release trigger and push the unit
forward in the same path to remove water and solution
from the carpet (For heavily soiled areas repeat as
necessary)
IMPORTANT: For best cleaning results, use a steady
moderate, forward and backward motion.
IMPORTANT: If the sound of the motor changes
and the float rises, this indicates that the dirty
water tank is full and must be emptied
Washing stairs and upholstery
Fill the trigger spray bottle with Vax AAA cleaning
solution, according to the directions given on the bottle
(Fig.5/2)
NOTE: The handheld must be used in conjuncton with
the trigger spray bottle. The unit alone is for wet
recovery only.
Fill the remainder of the bottle with warm water
(max 40°C).
Ensure the cleaner is in the upright position.
Remove the handheld from the front of the upright by
moving the handle slide release to the left (Fig.5/3).
The top of the handheld should be removed first, at an
angle, followed by the bottom (Fig.5/4)
Push the wash tool onto the end of the handheld
(Fig.5/5)
Press the power on/off button to turn the cleaner on.
Using the separate trigger bottle, spray the water and
solution onto the area to be cleaned. Move the wash tool
in a backwards and forwards motion to agitate embedded
dirt and stains (Fig.5/6).
!
!
Fig.5/1
Fig.5/2
Fig.5/3
Fig.5/4
Fig.5/5
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:17 Page 5
www.vax.co.uk
6
usage
The cleaner will automatically extract excess water and
solution from the area (For heavily soiled areas, repeat if
necessary)
IMPORTANT: Do not fill with dirty water above
the “MAX FILL” line.
NOTE: For upholstery, always check manufacturers
guidelines and do not over-wet. Ensure upholstery is
dry before use.
Emptying the dirty water tank
The carpet washer is equipped with a shut off valve within
the dirty water tank. When the dirty water tank becomes
full, the float will rise, shutting off the air flow through the
nozzle.
NOTE: The float in the carpet washer will shut off the
suction when the dirty water tank is full. For best
results, use smooth, steady motion keeping the nozzle
flat against the carpet. Tipping the carpet washer and
breaking the seal of the nozzle and carpet will cause
the float to rise and shut off the suction. Once the
float is activated, empty the dirty water tank. If the
dirty water tank does not appear full, press the Power
on/off pedal and wait for the float to settle and reset.
If the float repeatedly shuts off the suction, empty the
dirty water tank. For best results, use only Vax AAA
Carpet Cleaner. Other solutions may generate
excessive foam which will cause the float to rise
prematurely and shut off the suction. Use the
specified amount of Vax AAA Carpet Cleaner (as
indicated on the bottle) per fill up of the clean water
tank. A higher concentration of carpet cleaner may
cause excessive foaming.
NOTE: There will be a noticeable change in the pitch of
the cleaner. This indicates a need to empty the dirty
water tank.
WARNING: To reduce the risk of injury from
moving parts - unplug before emptying the dirty
water tank.
Step onto the handle release pedal to recline the unit fully.
Push the dirty water tank latch backwards to release
(Fig.5/7).
To empty, remove the front nozzle (Fig 5/8), turn upside
down and pour the soiled water into the sink. Rinse with
clean water.
Place the nozzle back onto the dirty water tank by clicking
into place and replace into the unit. Ensure that the front
of the nozzle is put into place first (Fig 5/9). Restore the
machine to the upright position.
Fig.5/8
Fig.5/9
Fig.5/7
Fig.5/6
!
!
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:17 Page 6
7
V
ax Careline 0870 606 1248
usage / maintenance
Emptying the handheld dirty water tank
Press the handheld dirty water tank release button
(Fig.5/10).
Unscrew the cap (Fig 5/11).
Turn upside down and empty the soiled water into a sink
Rinse well with clean water and return to the unit.
Reset Button
This unit is equipped with a safety reset button (Fig 5/12).
When the brushbar fails to rotate, press the button to
restart.
6. Maintenance
Cleaning the filter
Remove the handheld from the cleaner (refer to Section 5)
Remove the handheld dirty water tank as directed
Remove the filter and wash under a tap (max 40°C)
(Fig.6/1) . Allow to air dry thoroughly before replacing in
the machine.
Changing the brushbar and belt
To access the brushbar and belt, you will require a Philips
screwdriver. Lie the unit down on a flat surface, with the
underneath of the dirty water tank facing you (Fig.6/2).
Remove the screw (Fig.6/3).
Remove the cover (Fig.6/4) and the belt can be taken off
the spindle. To remove the brushbar, the screws at either
end must be undone first.
Fig.5/10
Fig.5/11
Fig.5/12
Fig.6/1
Fig.6/2
Fig.6/3
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:18 Page 7
www.vax.co.uk
8
storage / troubleshooting
7. Storage
To store the cleaner, ensure all tanks are clean, empty
and dry.
Fold down the handle by turning the folding handle dial in
a clockwise direction
8. Troubleshooting
WARNING: To reduce the risk of personal injury,
unplug the vacuum cleaner before performing
maintenance or troubleshooting checks.
PROBLEM: The cleaner won't run.
Cause: Not properly plugged into electrical outlet.
Solution: Plug in firmly.
Cause: No electricity in electrical outlet.
Solution: Check fuse or breaker.
Cause: ON/off switch not turned on.
Solution: Push on/off switch to ‘on’.
Cause: Blown fuse/tripped breaker.
Solution: Reset circuit breaker or replace fuse.
PROBLEM: Cleaner won’t pick up/loss of suction.
Cause: Dirty water tank is full.
Solution: Switch off and unplug cleaner. Empty dirty
water tank as shown in Section 5.
!
Fig.6/4
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:18 Page 8
9
V
ax Careline 0870 606 1248
uk service & help / technical specification
9. UK Service & Help
Vax Care 0870 6061248
Monday-Friday 9.00am to 5.00pm.
An answerphone is available outside of these hours. Any
queries or concerns about using the Vax, call the Vax
Careline. Calls are charged at the UK national rate.
Please make a note of the serial number and model
number of the carpet cleaner before calling. There are over
400 approved Vax Service Agents in the UK. For the
nearest Service Agent, please call the Vax Careline.
www.vax.co.uk
10. Technical Specification
Voltage: 220-240V ~50Hz
Wattage: 600W
Capacity: Clean water tank - 1.7 litres
Dirty water tank - 2 litres
Cord length: 6 metres
Weight: 7.5kg
Subject to technical change without notice.
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:18 Page 9
www.vax.co.uk
10
This page has been left intentionally blank.
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:18 Page 10
11
V
ax Careline 0870 606 1248
This page has been left intentionally blank.
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:18 Page 11
---
EEC STATEMENT OF COMPLIANCE
Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
V-126 Integra upright carpet washer is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive
EMC: 89/336/EEC Electromagnetic Compatibility Directive
Wasteelectrical products shouldnot be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority orretailer for recycling advice.
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 OQH, UK
email: info@vax.co.uk - website: www.vax.co.uk
Vax V-126 User Guide.qxd:V-126 User Guide 17/9/07 14:18 Page 12
Loading...
