Vax V-077, V-077M, mojo III V-077, mojo III V-077M Instruction Manual

Vax Careline:
0870 6061248

Instruction Manual

Please read carefully before using

the cleaner. Always fully extend

the mains cable before use.

BAGGED CYLINDER VACUUM CLEANER
Vax Model Number: V-077/V-077M

www.vax.co.uk

VAX.V-077 User Guide .qxd 1/8/06 15:22 Page 2

1. Diagram

Parts Overview

2

1 Top cover release
2 Hose inlet
3 On/off button
4 Bag full indicator
5 Variable power
6 Auto cord rewind
7 Carry handle
8 Post-motor filter

9 Plug
10 Wheel
11 Top cover
12

Pr

e-motor filter

13 Paper dust bag

1

2

8

9

10

12

13

Fig.1/1

Fig.1/2

3

11

4 5 6 7

VAX.V-077 User Guide .qxd 1/8/06 15:22 Page 3

Parts Overview

3

14 2-in-1 tool
15 Hose

16 Floor tool
17 Extension Tube

Fig.1/3

Fig.1/4

14 15

16

17

VAX.V-077 User Guide .qxd 1/8/06 15:22 Page 4

Safety Information

4

2. Safety Information

FOR HOUSEHOLD USE ONLY.
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:

1. Only use the vacuum cleaner indoors on dry

surfaces.

2. Turn off the vacuum cleaner controls before

connecting to or disconnecting from the mains
supply.

3. Always unplug the vacuum cleaner before

connecting or disconnecting the vacuum hose.

4. Close attention is necessary when used by or near

children. Do not allow children to use as a toy.

5. Use only as described in this manual. Use only

the manufacturer’s recommended attachments.

6. Do not use the vacuum cleaner if it has been

dropped, damaged, left outdoors or dropped into
water. Do not use the vacuum cleaner with a
damaged cord or plug. If the supply cord or plug
is damaged, return the vacuum cleaner to a Vax
Authorised Service Agent or suitably qualified
person for examination, repair or adjustment.

7. Do not pull or carry by the cord. Do not use the

cord as a handle, close a door on the cord or pull
the cord around sharp edges or corners. Do not
run the vacuum cleaner over the cord. Keep the
cord away from heated surfaces.

8. Do not handle the plug or vacuum cleaner with

wet hands. Do not use outdoors or on wet
surfaces.

9. Do not put any objects into openings. Do not use

with any openings blocked and do not restrict air
flow. Keep all openings free of dust, lint, hair or
anything that may reduce airflow.

10. Keep hair, loose clothing, fingers and all parts of

the body away from openings and moving parts.

11. Do not pick up hot coals, cigarette butts,

matches or any hot, smoking or burning objects.

12. Do not pick up flammable or combustible

materials (lighter fluid, petrol, kerosene, etc) or
use in the presence of explosive liquids or
vapours.

13. Do not vacuum up harmful or toxic material

(chlorine bleach, ammonia, drain cleaner, etc).

14. Do not vacuum up hard or sharp objects such as

glass, nails, screws, coins, etc.

15. Do not use without the filters in place.

16. Use extra car

e when vacuuming on stairs.

17. Keep vacuuming area well lit.

18. Store the vacuum cleaner indoors in a cool,

dry area.

19. Turn off the switch before unplugging.

20. Use only CE-approved 13 amp extension cords.

Non-approved extension cords may overheat.
Care should be taken to arrange the cord so that
the cord cannot be pulled or tripped over.

WARNING: Always switch off and unplug the vacuum
cleaner from the electrical outlet before assembling,
opening or emptying the dirt container, or before
connecting/disconnecting the attachments.

CAUTION: The vacuum cleaner is a very powerful unit.
Before plugging the cord into the outlet make sure the
switch is in the ‘off’ position. Hold the vacuum cleaner
firmly when starting and in use.

IMPORTANT: If the inlet or hose is blocked, switch off
the vacuum cleaner and remove the blockage(s)
before re-starting the vacuum cleaner.

IMPORTANT: Washing filters and changing the dust
bag improves vacuum performance. Make sure all
filters are completely dry before inserting back into the
vacuum cleaner.

This vacuum cleaner is intended for household use
only and not for commercial or industrial use.

PLEASE KEEP THESE INSTRUCTIONS FOR
FURTHER USE.

Motor Thermostat

IMPORTANT: The motor is equipped with a thermal
cut-out. If for any reason, the vacuum cleaner should
over-heat, the thermostat will automatically turn the
unit off. Should this occur, unplug the vacuum cleaner
from the wall outlet and turn off the switch. Remove
the dirt container and empty. Clean the filters. Allow
the cleaner to cool for approximately one (1) hour. To
re-start, plug into a wall outlet and switch back on.
