Vax V-044B Series, V-039 Instruction Manual

BAGLESS HANDHELD VACUUM CLEANER
Vax Model Number: V-039

Vax Careline:
0870 6061248

Instruction Manual

Please read carefully before using
the vacuum cleaner. Always fully
extend the mains cable before use.

www.vax.co.uk

2

1. Diagram

1 Vacuum cleaner

2 Shoulder strap

3 Combination floor tool 8

4 Storage bag

5 Crevice tool (located on unit) 6

6 Narrow nozzle adapter 7

7 Brush tool (located on unit) 5

8 Oval nozzle adapter 3

9 Connector 4

10 Large inflator adapter 10

11 Medium inflator adapter 10

12 Small inflator adapter 10

13 Flexible hose (long) 9

14 Cleaning brush 13

15 Hose handle 14

16 3 extension tubes 2

17 Flexible hose (grey), inflator hose 9

1

Fig.1

Fig.1/1
On/off switch

Fig.1/2
Transparent dust container
window

Fig.1/3
Dust container release
button

2

3

4

5

6

7

8

9

10

12

11

13

14

15

16

17

3

Parts Overview

2. Safety Information

FOR HOUSEHOLD USE ONLY

When using the vacuum cleaner, basic safety
precautions should always be observed, including the
following:

1. Only use the vacuum cleaner indoors on dry
surfaces.

2. Turn off the vacuum cleaner controls before
connecting to or disconnecting from the mains
supply.

3. Always unplug the vacuum cleaner before
connecting or disconnecting the vacuum hose.
Do not allow the plug to whip when rewinding.

4. Close attention is necessary when used by or near
children. Do not allow children to use as a toy.

5. Use only as described in this manual. Use only
the manufacturer’s recommended attachments.

6. Do not use the vacuum cleaner with a
damaged cord or plug. Do not use the vacuum
cleaner if it has been dropped, damaged, left
outdoors or dropped into water. Return the
vacuum cleaner to a Vax Authorised Service
Agent or suitably qualified person for examination,
repair or adjustment.

7. Do not pull or carry by the cord. Do not use the
cord as a handle, close a door on the cord or
pull the cord around sharp edges or corners. Do
not run the vacuum cleaner over the cord. Keep
the cord away from heated surfaces.

8. Do not handle the plug or vacuum cleaner with wet
hands. Do not use outdoors or on wet surfaces.

9. Do not put any objects into openings. Do not
use with any openings blocked and do not
restrict air flow. Keep all openings free of dust,
lint, hair or anything that may reduce airflow.

10. Keep hair, loose clothing, fingers and all parts of
body away from openings and moving parts.

11. Do not pick up hot coals, cigarette butts,matches
or any hot, smoking or burning objects.

12. Do not pick up flammable or combustible
materials (lighter fluid, petrol, kerosene, etc) or
use in the presence of explosive liquids or
vapours.

13. Do not vacuum up harmful or toxic material
(chlorine bleach, ammonia, drain cleaner, etc).

14. Do not vacuum up hard or sharp objects such
as glass, nails, screws, coins, etc.

15. Do not use without the filters in place.

16. Use extra care when vacuuming on stairs.

17. Keep vacuuming area well lit.

18. Store the vacuum indoors in a cool, dry area.

19. Turn off the switch before unplugging.

20. Use only CE-approved 13A extension cords.
Non-approved extension cords may overheat.
Care should be taken to arrange the cord so
that the cord cannot be pulled or tripped over.

WARNING:
FOR BLOWING AND INFLATOR OPERATION:

1. The blower and inflator operation of the vacuum
cleaner can result in foreign objects being blown
into eyes, which can result in eye damage.
Always wear eye protection (not provided) when
operating as blower or inflator.

2. Do not permanently cover openings of
inflator accessories.

3. Take care when using inflator accessories, as
some surfaces may become warm.

4. Do not leave the vacuum cleaner unattended
when inflating any items.

WARNING: Do not point air outlet openings at people
or animals.

WARNING: Always switch off and unplug the vacuum
cleaner from electrical outlet before assembling,
opening or emptying the dust container, or
connecting/disconnecting the attachments.

CAUTION: Keep the suction intake opening free from
obstruction at all times; otherwise the motor will
overheat and vacuum cleaner damage may result.

CAUTION: The vacuum cleaner is a very powerful
unit. Before plugging cord into outlet make sure the
switch is in the ‘off’ position. Hold the vacuum cleaner
firmly when starting and in use.

IMPORTANT: If the vacuum inlet or hose are blocked,
switch off the vacuum cleaner and remove the
blockage(s) before starting the vacuum cleaner.

IMPORTANT: Washing filters improves vacuum
performance. Make sure all filters are completely dry
before inserting back in the vacuum cleaner.

This vacuum cleaner is intended for household use
only and not for commercial or industrial use.

The vacuum cleaner is fitted with a thermal cut-out
which switches the vacuum cleaner off automatically.
Should this happen, turn the vacuum cleaner ‘off’,
allow the unit to cool for an hour, check and clean
filter system and switch back ‘on’.

4

Safety Information
