www.vax.co.uk
Please read carefully before using this cleaner.
Always fully extend the mains cable before use.
Retain for future reference.
Vax careline
0870 6061248
instruction manual
Handheld Carpet Washer
Vax model number:
V-035B
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 1
V-035B
1. Diagram
www.vax.co.uk
2
parts overview
1 Handle
2 Clean solution tank latch
3 On/Off switch
4 Power cord
5 Dirty water tank latch
6 Drain cap
7 Vacuum/Scrub selector
8 Dirty water tank
9 Rotating scrub brush
10 Vacuum nozzle
11 Spray nozzle
12 Cord wrap
13 Spray trigger
14 Clean solution reservoir
Fig.1/1
12
13
1
14
3
2
4
5
6
8
7
9
10
11
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 2
3
Vax Careline 0870 606 1248
safety information
2. Safety Information
For Household Use Only
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
WARNING: Do not use outdoors.
1. Do not charge the unit outdoors.
2. Turn off the vacuum cleaner control before
connecting or disconnecting from the mains supply.
3. Children should be supervised to ensure that they
do not play with the appliance.
4. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by
person responsible for their safety.
5. Use only as described in this manual. Use only the
manufacturer’s recommended attachments.
6. Do not use with damaged cord or plug. If the
appliance is not working, as it should, has been
dropped, damaged, left outdoors, or dropped into
water, return it to a Vax Authorised Service Agent or
suitably qualified person for examination, repair or
adjustment.
7. Do not abuse the cord. Keep the cord away from
heated surface. Do not pull the cord around sharp
edges or corners. Do not close the cord in a door.
8. Do not handle the plug or appliance with wet hands.
9. This product contains rechargeable Ni-Cad batteries.
Do not throw batteries into fire or expose them to
high temperatures, as they may burst.
10. Do not use with any opening blocked; keep free of
dust, lint, hair, and anything that may reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
12. Do not pick up hot coals, cigarette butts, matches or
anything hot, smoking or burning objects.
13. Do not pick up flammable or combustible materials
(lighter fluid, petrol, kerosene, etc) or use in the
presence of explosive liquids or vapour.
14. Do not vacuum up harmful or toxic material (chlorine
bleach, ammonia, drain cleaner, etc).
15. Do not use without the filter in place.
16. Do not vacuum up hard or sharp objects such as
glass, mails, screws, coins, etc.
17. Turn off all controls before unplugging.
18. Take extra care when cleaning on stairs
19. Store the appliance indoors in a cool, dry area.
20. Use only the charge supplied by the manufacturer
to recharge.
WARNING: Always switch off and unplug the
hand vac from the electrical outlet before
assembling, opening or emptying the dirt container,
or before connecting/disconnecting the attachments.
IMPORTANT: Washing filters improves the
hand vac performance. Make sure all the filters
are completely dry before inserting back into
the hand vac.
This hand vac is intended for household use only and not
for commercial or industrial use.
!!!
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 3
www.vax.co.uk
4
operation
3. How to Operate
Grasp solution tank handle and press the clean solution
tank latch (Fig.3/1).
Slide the solution tank away from the cleaner until the
tabs on the tank are disengaged from the slots on the
cleaner (Fig.3/2).
Lift the clean solution tank to remove (Fig.3/3).
Unscrew the cap from the back of the clean solution tank
(Fig.3/4).
Fill the solution tank with 15ml of Vax AAA carpet
cleaner (Fig.3/5).
Slowly fill the remainder of the clean solution tank with
warm (max 40ºC) water (Fig.3/6).
Replace the cap (Fig.3/7).
Fig.3/1
Fig.3/4
Fig.3/5
Fig.3/6
Fig.3/2
Fig.3/3
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 4
5
Vax Careline 0870 606 1248
operation
Line up the tabs on the clean solution tank with the slots
on the the cleaner and slide the tank toward the cleaner
(Fig.3/8).
Make sure the clean solution tank is aligned properly
(Fig.3/9).
NOTE: Failure to install the clean solution tank correctly
will result in poor dirty water pick-up.
Carpet/upholstery cleaning
Plug cord into an electrical socket (Fig.3/10).
Turn the power switch ‘ON’ (Fig.3/11).
Turn the Vacuum/Scrub selector knob towards ‘Vacuum’
and remove as much liquid as possible from the spill or spot
(Fig.3/12).
Fig.3/7
Fig.3/8
Fig.3/9
Fig.3/10
Fig.3/11
Fig.3/12
incorrect
correct
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 5
www.vax.co.uk
6
operation/ dirty water tank
IMPORTANT: Do not overwork any area of carpet,
as this may damage carpet fibres.
Depress the spray trigger to spray solution onto the area.
Allow the cleaning solution to penetrate stain for 2
minutes (Fig.3/13).
Turn the Vacuum/Scrub selector to ‘Scrub’ and use the
rotating scrub brush on the area in a forward and
backward motion, using steady strokes (Fig.3/14).
Turn the Vacuum/Scrub selector back to ‘Vacuum’ to pickup the remaining moisture (Fig.3/15).
4. Emptying & cleaning the dirty
water tank
NOTE: Do NOT remove the dirty water tank with the unit
in the upright position. You should empty the tank when
the dirty water in the tank reaches the ‘Full’ line on the
dirty water tank, or, when the float shuts off airflow, this
will be indicated by a change in the pitch of the motor
and reduced suction. Finally, you should also empty the
dirty water tank after use and rinse clean, before storage.
With one hand hold the cleaner by the handle, with the
other grasp the sides of the dirty water tanks and push
the latch to release (Fig.4/1).
Grasp and pull the cleaner UP and AWAY from the dirty
water tank (Fig.4/2).
Unscrew the dirty water tank drain cap (Fig.4/3).
!
Fig.3/13
Fig.4/1
Fig.4/2
Fig.3/14
Fig.3/15
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 6
7
Vax Careline 0870 606 1248
dirty water tank
Empty the dirty water tank into the sink and replace the
cap (Fig.4/4).
Cleaning the dirty water tank
Rinse the dirty water tank with warm (max 40ºC) tap
water.
Dry thoroughly before storing to prevent mildew from
forming (Fig.4/5).
Cleaning the filter
Check the filter located on top of the dirty water tank
periodically and clean by rinsing with water when dirty
(Fig.4/6).
NOTE: Make sure to replace the filter after cleaning.
Returning the dirty water tank to the base of the
cleaner
Grasp the handle and hook the front of the dirty water
tank securely into the base of the cleaner (Fig.4/7).
The dirty water tank has 2 tabs on the underside, which
MUST latch into the underside of the base of the cleaner.
Fig.4/3
Fig.4/4
Fig.4/5
Fig.4/5
Fig.4/7
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 7
www.vax.co.uk
8
operation/ storage
While making sure the front of the dirty water tank is
hooked on the base, push the rear of the tank into the
base of the cleaner and push down until it latches. The
dirty water tank will need to be emptied once or twice per
fill up of the clean solution tank (Fig.4/8).
NOTE: Failure to install the dirty water tank correctly will
result in poor dirty water pickup.
5. How to store the cleaner
Lift up the cord wrap and use it to secure the cord as it
wraps around the cleaner (Fig.5/1).
Fig.4/8
Fig.5/1
cord wrap
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 8
9
Vax Careline 0870 606 1248
troubleshooting/ UK service & help/ technical specification
6. Troubleshooting
WARNING: To reduce the risk of personal injury,
unplug the vacuum cleaner before performing
maintenance or troubleshooting checks.
PROBLEM: Cleaner won’t run
Cause: Power cord not firmly pushed into a mains
socket.
Solution: Plug cord in firmly.
Cause: Blown fuse or tripped circuit breaker.
Solution: Check fuse/breaker. Replace fuse or reset
breaker.
Cause: Needs service.
Solution: Call Vax Care 0870 606 1248.
PROBLEM: Hand Vac won’t pick up/loss of suction.
Cause: Dirty water tank is not installed correctly.
Solution: Review dirty water tank removal and
replacement.
Cause: Dirty water tank is full.
Solution: Empty the dirty water tank.
PROBLEM: Water escaping from the Cleaner
Cause: Dirty water tank is full.
Solution: Empty the dirty water tank.
Cause: Dirty water tank is not installed correctly.
Solution: Review dirty water tank removal and
replacement.
Cause: Solution tank not installed correctly.
Solution: Review solution tank installation.
PROBLEM: Cleaner won’t dispense
Cause: Spray nozzle clogged
Solution: Clean thoroughly.
Cause: Solution tank not installed properly
Solution: Review solution tank installation.
7. UK Service & Help
Vax Care 0870 6061248
Monday-Friday 8.00am to 8.00pm.
Saturday-Sunday 9.00am to 5.00pm.
Any queries or concerns about using the Vax, call the Vax
Careline. Calls are charged at the UK national rate.
Please make a note of the serial number and model
number of the carpet cleaner before calling. There are
over 400 approved Vax Service Agents in the UK. For the
nearest Service Agent, please call the Vax Careline.
www.vax.co.uk
8. Technical Specification
Adaptor voltage: 230-240V ~50Hz
Wattage: 200W
Cord length: 5.9m (approx)
Capacity: 0.26l clean
0.32l dirty
Filter: foam pad filter
Subject to technical change without notice.
!
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 9
www.vax.co.uk
10
This page has been left intentionally blank
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 10
11
Vax Careline 0870 606 1248
This page has been left intentionally blank
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 11
---
EEC STATEMENT OF COMPLIANCE
Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
V-035B Infinity by Vax is manufactured in compliance with the following Directives:
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with householdwaste. Please recycle where
facilities exist.Check with your Local Authority or retailer for recycling advice.
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 OQH, UK
email: info@vax.co.uk - website: www.vax.co.uk
Vax V-035B Infinity User Guide.qxd:V-035B Infinity UG 20/10/08 17:22 Page 12
