Vax C85-D2-TE, C85-D2-BE User Manual

Dynamo Strike
Let’s get started
C85-D2-Be/C85-D2-Te
vax.co.uk
Let’s talk safety
Basic safety precautions
This vacuum cleaner is intended for household use only and NOT for commercial or industrial use.
• Only use the vacuum cleaner indoors on dry surfaces and keep the area you’re cleaning well lit.
• Keep ngers, hair and loose clothing from moving parts and openings whilst using the vacuum cleaner.
• This vacuum cleaner can be used by children aged from 8 years and above and persons with reduced physical, sensory
• Don’t use this vacuum cleaner if it has been dropped, damaged or left outdoors.
• Don’t run over the power cord or use vacuum cleaner if the power cord or plug is damaged. Please contact our Customer Care Line on: 0330 026 8455 (Mon-Fri 8:30am to 6:30pm, Sat 9:00am to 5:00pm).
• Don’t handle the plug or use the vacuum cleaner with wet hands.
• Don’t pull or carry this vacuum cleaner by the power cord.
• Don’t use the power cord as a handle, pull the power cord around corners, sharp edges or close a door over the power cord.
• Don’t unplug vacuum cleaner by pulling on the power cord.
Do’s
• Turn o all controls on the vacuum cleaner before disconnecting or connecting the power cord.
• Always make sure both the pre-motor/post-motor lters are in place before use.
• Always switch o the vacuum cleaner before disconnecting or connecting the hose and accessories.
• Keep all openings clear and free from debris as this may aect the airow/suction.
• Always replace the fuse in the plug with a British 13amp fuse.
• Always protect the power cable from heated surfaces and open ames.
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the vacuum cleaner in a safe way and understand the hazards involved. Children shall not play with the vacuum cleaner. Cleaning and user maintenance shall not be made by children without supervision.
• Only Vax recommended tools and accessories should be used with this vacuum cleaner.
• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol, kerosene etc.) or use the vacuum cleaner in an area with explosive vapours or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning items or use in an area where there may be harmful uids (chlorine, bleach, and ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may cause damage to your vacuum cleaner.
• Don’t vacuum up hard or sharp objects such as glass, nails, screws or coins etc.
• Don’t use the vacuum cleaner with incorrect voltage as this may result in damage or injury to the user. The correct voltage is listed on the ratings label.
• Take extra care when positioning and using the vacuum cleaner on the stairs.
• Use only CE approved 13amp extension cords, non-approved extension cords may overheat. Care should be taken to arrange the extension cord as it can be a trip hazard.
• Store your vacuum cleaner in a cool, dry area. If lters have been cleaned as per user guide instructions ensure they are thoroughly dry before storing away.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
Thank you for buying this Dynamo Strike.
Taking care of your carpets and hard fl oors
The Dynamo Strike is designed to make vacuuming carpets and hard  oors regularly, as e ective and effi cient as possible and this user guide will help you get the most out of your machine.
Maintaining your carpets and hard  oors will ensure they keep their appearance for longer. You’ve chosen carpets and hard  oors for your home for a reason and Vax will help you take good care of them.
Taking care of your Dynamo Strike
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready when you are to tackle your carpets and hard  oors.
Taking care of you
We’re here if you need us. Instead of taking me back to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0330 026 8455 (ROI) 1-800 928 308
Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling.
Alternatively, you can write to us at:
Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich, WR9 0LW, UK
This User Guide can be found online at: vax.co.uk/support
Let us know what you think @VaxUK
Contents
Dynamo Strike
(Included with all models)
Included with
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
Accessories
What to do if it goes wrong
Getting in touch
your machine
Combination  oorhead
Telescopic extension tube
3-in-1 tool
Accessory hose
Hard oor tool
Dynamo Strike
+
Total Home
Initial Setup for normal operation
1. Use the base accessories. a. Shortest hose. b. Extension tube set to shortest practicable length.
2. Clean  lters installed.
3. Dust receptacle empty.
4. All Bleeds must be closed.
5. Floorheads/tools set to Carpet Mode for carpet cleaning.
6. Mechanical Agitation turned ON for carpet cleaning.
7. Floorheads/tools set to Hard Floor Mode for hard  oor cleaning.
8. Mechanical Agitation turned OFF for hard  oor cleaning.
TurboTool
Tool connector
Stretch hose
Up-top tool
Getting to know your machine
Separator
Hose entry point
Dirt container release button
Dirt bin lid release clip
Dirt container
Carry handle
Power On/O button
Post-motor  lter cover
Technical Specifi cation
Name Dynamo Strike Voltage 220-240V~50Hz Wattage 800w Cord length 6m Weight 4.7kg
Subject to technical change without notice.
Cord rewind button
Post-motor  lter
cover release clip
Accessories & Consumables
Pre-motor  lter (Type 130)*
1-1-135875-00
Post-motor  lter (Type 131)
1-1-135876-00
TurboTool (Type 6)
1-1-134419-00
*To purchase consumables and accessories, please visit vax.co.uk
Tool connector (Type 1)
1-1-133838-00
Hard oor tool (Type 3)
1-1-135705-00
Combination  oorhead tool (Type 6)
1-1-134330-00
Getting started
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Before you begin cleaning
• Always switch o and unplug the vacuum cleaner before connecting or disconnecting the hose/attachments, or removing and emptying the dirt container.
• The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the thermostat will automatically turn the vacuum cleaner o . If this happens, switch the vacuum cleaner o and unplug from electrical socket. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the vacuum cleaner to cool for approximately 1 hour (if you have cleaned the  lters please wait 24 hours for the  lters to fully dry before putting back into the vacuum machine).
• Clean the pre-motor  lter every time the dirt container is emptied and replace the post-motor  lter every 12 months.
• If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.
Assembling your vacuum cleaner
Press both buttons at he end of the hose and push hose into the hose entry point.
Fully unwind the power cord. A yellow mark on the cord indicates the recommended cord length. Do not exceed the cord beyond the yellow mark.
Insert the hose grip into the telescopic extension tube.
Plug in and switch the unit on by pressing the power button.
Press the button on the telescopic extension tube and adjust to required length.
Insert the other end of the telescopic extension tube into the  oorhead.
CAUTION
When unwinding the power cord always pull out to the yellow marker but no further.
Using your machine
CAUTION: The base of the vacuum cleaner should always be positioned  at on the  oor when starting and in use. The dirt container should be locked into place before lifting the vacuum cleaner by the carry handle.
How to use
For use on carpets, click rocker switch forward. For use on hard  oors click rocker switch back.
Slide vent cover on hose grip open to reduce suction if required.
Raise brushes for carpets.
For the most effi cient results on hard  oors replace the combination  oorhead with the specialist hard  oor tool.
Lower brushes for hard  oors.
Using accessories
Using your machine
Choose an accessory. Choose an accessory
and push onto the telescopic extension tube or hose.
The TurboTool connector must be  tted on the hose when using the TurboTool (some models only).
Storage
Press the cord rewind button to retract the cord into the vacuum cleaner.
CAUTION: Make sure to hold the cord with your other hand to prevent injury when rewinding.
Place the  oorhead into the parking slot on the back of the vacuum cleaner for storage and carrying.
Taking care of your machine
24hr
IMPORTANT: Always switch o and unplug the vacuum cleaner from the electrical socket before assembling, opening or emptying the dirt container, or before connecting/disconnecting the attachments.
Pre-motor  lter needs to be cleaned every time you empty the dirt container. Do not use your vacuum cleaner without all of the  lters in place.
The motor is equipped with a thermal cut-out. If for any reason the unit should overheat, the thermostat will automatically turn the unit o .
Emptying and cleaning the dirt container
TIP
Remove dirt container by pushing down the dirt container release button and lifting the dirt container.
Hold dirt container over a bin. Press the dirt release clip at the bottom of the container, the dirt release door will open allowing dirt/debris to fall out.
Don’t over  ll the dirt container to avoid blocking the air  ow through the
vacuum cleaner.
Cleaning the pre-motor fi lter
Lift the dirt bin lid release clip, in a hinge like manner lift dirt bin lid.
!
40˚C
40˚C
MAX
MAX
Rinse the pre-motor  lter under water (Max 40°C).
Lift the pre-motor  lter and remove from the dirt container.
Leave to dry for 24 hours or until fully dry before placing back in the machine.
P
A
T
Tap the pre-motor  lter against a bin to remove any dirt/debris.
Taking care of your machine
!
40˚C
MAX
Cleaning the separator
CAUTION: Incorrect  tting of the separator cap will reduce suction.
Lift the dirt bin lid release clip in a hinge like manner to lift the dirt bin lid.
Tap the separator against a bin to remove any dirt/debris.
Lift the pre-motor  lter and remove from the dirt container.
Make sure the rectangular hole in the dirt container lines up with the rectangular hole on the separator.
Twist the separator cap anti-clockwise to unlock and remove.
Replace the separator cap, twist clockwise to lock.
Lift and remove the separator from the dirt container.
Replace the pre-motor  lter. Close dirt bin lid making sure it clicks and locks into place.
Post-motor fi lter maintenance
IMPORTANT: The exhaust  lter is designed to o er long life with no maintenance. The  lter should be checked periodically and when heavily discoloured it should be replaced. Please do not wash, scrub or brush the  lter as this will damage the delicate  lter media.
Push the post-motor  lter cover release clip to the right.
Pull open the post-motor  lter cover. Lift out the post-motor  lter.
Check the post-motor  lter for discolouration. Do not wash the post-motor  lter.
Let’s talk technical
Removing blockages from the TurboTool (some models only)
Tabs
Slide the locking ring to remove.
Lift and separate the housing.
Removing blockages from the hose
Remove the hose from the vacuum cleaner and telescopic extension tube. Remove any blockage by inserting a wire coat hanger into the hose.
Using a pair of scissors, cut any hair or debris free from around the brushes.
Line up the tabs on front of housing and push together to re t. Slide locking ring into groove to secure.
TIP
To test for a blockage in the hose, drop a small ball of paper into the hose. The paper will drop through if the
hose is clear.
Accessories
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
Pro Cleaning Kit (Type 2) 1-1-133326-00
All our best tools all in one kit that makes cleaning your home quicker, easier and with even better results. We’ve taken care of cleaning all of the hard to reach areas such as on top of cupboards and in between blinds to the dust that collates behind and within the radiator.
TurboTool (Type 4) 1-1-134340-00
Use the TurboTool for vacuuming your stairs, upholstery and car interiors. It’s great for picking up stubborn pet hair.
Fur ‘n’ Fluff Tool 1-1-131392-00
Speci cally designed to remove extra stubborn pet hair from upholstery, furniture and carpets.
What to do if it goes wrong
There is an accessory missing
Why won’t the vacuum cleaner pick up?
SolutionProblem
• Check the ‘This pack contains’ panel on the box to make sure the part is included with your vacuum cleaner.
• The dirt container may not be correctly  tted, remove the dirt container from the vacuum cleaner and check it’s assembled correctly, re t ensuring it’s locked into place.
• The separator is blocked. Go to ‘Taking care of your machine’.
• The separator is incorrectly  tted. Go to ‘Taking care of your machine’.
• The  lter may be clogged, clean the  lter. Go to ‘Taking care of your machine’.
• The dirt container may be blocked, empty the dirt container. Go to ‘Taking care of your machine’.
• There may be a blockage in the hose/tube. Disconnect from the vacuum cleaner and carefully remove any blockages. Go to ‘Let’s talk technical’.
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace with a British
Why does my vacuum cleaner have no power?
13amp fuse.
• The motor thermostat may have tripped. If this has happened, unplug the vacuum cleaner. Remove and empty the dirt container and check the hose for blockages. Clean the  lters and allow the vacuum cleaner to cool for approximately 1 hour (if you have washed the  lters you will need to wait 24 hours for the  lters to fully dry before putting them back into the vacuum cleaner).
• The  lters may be clogged, clean the  lter. Go to ‘Taking care of your machine’.
Why is dust escaping from the vacuum?
IMPORTANT: To reduce the risk of personal injury, unplug the vacuum before performing maintenance/
troubleshooting checks.
Getting in touch
* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling.
Registration required. Terms and conditions apply, see vax.co.uk for details.
@VaxUK
Vax Ltd., 5th Floor 2 Colmore Square, 38 Colmore Circus, Queensway, Birmingham, B4 6BN, UK email: info@vax.co.uk website: vax.co.uk
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility,
declare that the C85-D2-(Be, Te) is manufactured in compliance with the following Directives: Safety: 2006/95/EC Low Voltage Directive. EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
© 2014 All rights reserved. VAX®, VAX Lozenge, are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
