Vax C85-AC-BE Instruction manual

AirRevolve
PET
MULTI-ORIENTATION CYLINDER VACUUM
LET’S GET STARTED.
C85-AC-Pe
Let’s talk safety
This vacuum cleaner is intended for household use only and NOT for commercial or industrial use
Don’ts
• Only use the vacuum cleaner indoors on dry surfaces and keep the area you’re cleaning well lit.
• Keep ngers, hair and loose clothing from moving parts and openings whilst using the vacuum cleaner.
• This vacuum cleaner can be used by children aged from 8 years and above and persons with reduced physical,
• Don’t stand the machine with the carry handle on the oor this will make the machine unstable and reduce the air ow through the machine.
• Don’t use this vacuum cleaner if it has been dropped, damaged or left outdoors.
• Don’t run over the power cord or use vacuum cleaner if the power cord or plug is damaged. Please contact our Customer Care Line on: 0330 026 8455 (Mon-Fri 8:30am to 6:30pm, Sat 9:00am to 5:00pm).
• Don’t handle the plug or use the vacuum cleaner with wet hands.
• Don’t pull or carry this vacuum cleaner by the power cord.
• Don’t use the power cord as a handle, pull the power cord around corners, sharp edges or close a door over the power cord.
Do’s
• Turn o all controls on the vacuum cleaner before disconnecting or connecting to the mains.
• Always make sure the pre-motor lter and bin is in place before use.
• Always switch o the vacuum cleaner before disconnecting or connecting the hose and accessories.
• Keep all openings clear and free from debris as this may aect the airow/suction.
• Always replace the fuse in the plug with a British 13amp fuse.
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the vacuum cleaner in a safe way and understand the hazards involved.
• Children shall not play with the vacuum cleaner.
• Cleaning and user maintenance shall not be made by children without supervision.
• Only Vax recommended tools and accessories should be used with this vacuum cleaner.
• Don’t unplug vacuum cleaner by pulling on the power cord.
• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol, kerosene etc.) or use the vacuum cleaner in an area with explosive vapours or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning items or use in an area where there may be harmful uids (chlorine, bleach, and ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may cause damage to your vacuum cleaner.
• Don’t vacuum up hard or sharp objects such as glass, nails, screws or coins etc.
• Don’t use the vacuum cleaner with incorrect voltage as this may result in damage or injury to the user. The correct voltage is listed on the ratings label.
• Always protect the power cable from heated surfaces and open ames.
• Take extra care when positioning and using the vacuum cleaner on the stairs.
• Use only CE approved 13amp extension cords, non-approved extension cords may overheat. Care should be taken to arrange the extension cord as it can be a trip hazard.
• Store your vacuum cleaner in a cool, dry area. If lters have been cleaned as per user guide instructions ensure they are thoroughly dry before storing away.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
Thank you for buying this AirRevolve™ Pet.
Taking care of your carpets and hard oors
The AirRevolve™ Pet is designed to make vacuuming carpets and hard oors regularly as eective and ecient as possible and this user guide will help you get the most out of your machine. Maintaining your carpets will ensure they keep their appearance for longer. You’ve chosen the carpets and hard oors for your home for a reason and Vax will help you take good care of them.
Taking care of your AirRevolve™ Pet
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready when you are to tackle your carpets and hard oors.
Taking care of you
We’re here if you need us. Instead of taking me back to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0330 026 8455 (ROI) 1-800 928 308
Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling.
Alternatively, you can write to us at:
Vax Ltd, Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich, WR9 OLW, UK
This User Guide can be found online at: vax.co.uk/support
Let us know what you think @VaxUK
Contents
Let’s talk safety
AirRevolve™ Pet
Included with your machine
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
Accessories
Notes
What to do if it goes wrong
Accessory hose and handle
Powered head
Dusting brush
Crevice tool
Upholstery tool
Pre-motor lter
Getting in touch
Pre-Motor sponge
Hard oor tool
Telescopic extension tube & parking clip
Castor wheel
Getting to know your machine
Dirt container release button
Hose entry point
Castor wheel
Wheel
Cord rewind button
On/O button
Carry handle
Wheel
Separator and shroud
Technical Specication
Name AirRevolve™ Pet Voltage See product rating label on machine for details Wattage See product rating label on machine for details Cord length 6m Weight 5.2kg
Subject to technical change without notice.
*To purchase consumables and accessories, please visit vax.co.uk
Accessories & Consumables
Pre-Filter (Type 128)*
1-1-135703-00
Hard Floor Tool (Type 5)*
1-1-135754-00
Getting started
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
CAUTION: Always switch o the vacuum cleaner before connecting or disconnecting the hose/attachments, or removing and emptying the dirt container.
IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the thermostat will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner o and unplug. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the vacuum cleaner to cool for approximately 1 hour (if you have cleaned the lter please wait 24 hours for the lter to fully dry before putting back into the machine).
If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.
Assembling your vacuum cleaner
Line up hose connector with hose entry point. Squeeze both buttons on either side of hose connector.
Line up and push the other end of the telescopic tube into the powered head until it clicks into place.
Push hose connector into hose entry point until hose connector clicks and locks into place.
Slide the adjuster on the telescopic extension tube and select required length.
Line up hose handle with telescopic tube. Push hose handle into telescopic tube until clicks and locks into place.
Getting started
Using your accessories
Choose an accessory and push onto the telescopic extension tube or hose handle until it clicks and/or locks into place. For most ecient results on hard oors replace the powered head with the specialist hard oor tool.
Carrying your machine
Always use the carry handle to lift and carry the machine. Never stand the machine with the carry handle on the oor.
The dirt container has a peel of sticker which you can remove if you wish.
TIP
Using your machine
CAUTION: The power cord must always be completely unwound, do not pull further than the black marker.
CAUTION: When the vacuum and powered head are switched on, never leave the powered head in one position for
long periods of time. The powered head brush should be ON for carpets and OFF for hard oors.
Unwind the power cord. Do not pull further than the black marker.
Press the powered head brush On/O button once, the brushes on the powered head will spin, light on powered head will turn blue. Press again and the brushes will stop, light will turn o.
Plug into the mains and press the On/O button on the machine, or on the hose handle to switch the machine on.
Using your machine on the stairs
Slide the vent cover on the hose handle to reduce suction if required.
When cleaning stairs to prevent the vacuum cleaner falling, always stand the vacuum cleaner upright with the carry handle at the top.
CAUTION: Unplug and switch o the vacuum cleaner before cleaning, performing maintenance or troubleshooting checks.
Emptying and cleaning the dirt container
Do not over-ll the machine. Stand the machine vertically to check whether the max ll line has been reached.
Place the machine hose side up. Pull and slide dirt container release button.
Cleaning the shroud and separator
Twist the shroud clockwise to unlock.
Pull to remove the shroud out of the dirt container.
Pull to remove dirt container from main body.
Tap the shroud over a bin to remove any dirt/debris. Using a soft brush remove any remaining dirt/debris from the shroud.
Hold dirt container over a bin and press the dirt release clip on the bottom of the dirt container, allowing dirt/debris to fall out.
Wipe the dirt container and separator with a damp cloth to remove dirt/debris.
Line up the tabs on the separator into the dirt container. Twist the separator anti-clockwise to lock into place.
Line up dirt container with marked arrow and push rmly into main body of vacuum cleaner.
Taking care of your machine
CAUTION: For best cleaning results lters require cleaning every 3-6 months or more frequently depending upon use of vacuum cleaner. Unplug and switch o the vacuum cleaner before performing maintenance or troubleshooting checks.
IMPORTANT: Do not use your vacuum cleaner without the lter in place.
Cleaning the pre-motor lter
Pull and slide the dirt container release button. Pull to remove dirt container from main body.
24hr
Leave for 24hrs or until fully dry before re-tting.
Pull the tab on the pre-motor lter to remove the pre-motor lter from the base of the dirt container.
Make sure the tab on the pre-motor lter is visible when re-tting the pre-motor lter and sponge into the dirt container.
Tap the pre-motor lter over a bin to remove any dirt/ debris. Wash the lter under running water (40°C max).
Line up dirt container with marked arrow and push rmly into main body of vacuum cleaner.
Removing hose, telescopic extension tube and accessories
Squeeze both buttons on either side of hose connector. Pull to remove hose.
Press release clip on hose handle, pull to remove telescopic tube.
Press release clip on telescopic extension tube, pull to remove accessory.
Taking care of your machine Let’s talk technical
CAUTION: Remove the accessory from the hose or telescopic extension tube before performing any maintenance or troubleshooting checks.
Storing your vacuum cleaner
Stand the vacuum cleaner upright with the carry handle at the top. Place the oorhead parking clip into the semi-circular slot on the top of the vacuum cleaner.
Press cord rewind button to retract cord into vacuum cleaner.
Removing blockages from the powered head
Using a crosshead screwdriver, remove 3 screws from the side of the oorhead and remove end cap belt cover.
Lift and remove the top part of the brushbar side cover.
Pull and remove the brushbar location plate.
Pull brushbar and remove.
Remove the belt.
Use scissors to remove any blockages before replacing back into the machine.
Removing blockages from the hose
Remove the hose from the vacuum cleaner and telescopic extension tube. Remove any blockage by inserting a broom handle or similar object into the hose.
Let’s talk technical
CAUTION: This hose contains electrical connections:
• Do not use to suck up water (for vacuum cleaners only);
• Do not immerse in water for cleaning;
• The hose should be checked regularly and must not be used if damaged.
Let’s talk technical Let’s talk technical
Resetting Powered Head
The red light on the powered head will illuminate to indicate there is a blockage. Switch the vacuum cleaner o and clear the blockage.
Wait 30 seconds then switch the vacuum cleaner back on. Press the power head On/O button once, the brush on the power head will spin and the blue light will illuminate.
Removing blockages from powered head
Pull brush bar out of powered head and separate the brush bar side cover. Using scissors remove any
threads or hair from around the brush bar and clear any dirt or debris from powered head.
Slide brush bar halfway into powered head Push brush bar side covers together around edge of brush bar.
Let’s talk technical
Line up the other end of the brush bar with the square recess and push brush bar and plate into powered head.
Ret belt and push the brush bar location plate into place.
Ret the end cap belt cover and tighten 3 screws. 
Let’s talk technical
Replacing powered head belt
Using a crosshead screwdriver, remove 3 screws from the side of the powered head and remove end cap belt cover.
Remove the belt and clean any belt residue from the spindles before replacing the new belt
Pull and remove the brush bar location plate.
Accessories
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
Crevice tool (Type 7) 1-1-135882-00
Ideal to tackle those hard to reach areas.
Dusting brush (Type 4) 1-1-135883-00
Ideal for removing dirt from delicate surfaces.
Mattress tool (Type 7) 1-1-135884-00
Ideal for use on upholsteries such as, curtains, sofas, chair seats, car interiors, and mattresses.
Up top tool (Type 2) 1-1-135885-00
Ideal for removing dirt from those hard to reach areas.
Radiator tool (Type 2) 1-1-135886-00
Ideal for reaching behind radiators and cabinets.
What to do if it goes wrong
There is an accessory missing.
Why does my vacuum cleaner have no power?
Why won’t the vacuum cleaner pick up?
SolutionProblem
• Check the ‘This pack contains’ panel on the box to make sure the part is included with your vacuum cleaner.
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace with a 13amp fuse.
• The On/O button on the vacuum cleaner or the hose handle has not been turned on. Go to ‘Using your machine’.
• The motor thermostat may have tripped. If this has happened, unplug the vacuum cleaner. Remove and empty the dirt container and check the hose for blockages. Clean the lter and allow the vacuum cleaner to cool for approximately 1 hour (if you have washed the lter you will need to wait 24 hours for the lter to fully dry before retting back into the vacuum cleaner).
• The dirt container may not be correctly tted, remove the dirt container from the vacuum cleaner and check it’s assembled correctly, ret ensuring it’s locked into place. Go to ‘Taking care of your machine’.
• The brushes on the powered head have not been turned on. Go to ‘Using your machine’.
• The lter may be clogged, clean the lter. Go to ‘Taking care of your machine’.
• The dirt container, shroud or separator may be blocked, empty and clean the dirt container. Go to ‘Taking care of your machine’.
• There may be a blockage in the hose/telescopic extension tube/power head. Disconnect from the vacuum cleaner and carefully remove any blockages. Go to ‘Let’s talk technical’.
• Activate powered head brush by pressing powered head
Why won’t the powered head brush turn?
Why is dust escaping
brush On/O button. Go to ‘Using your machine’.
• The powered head may be blocked. Go to ‘Removing blockages from the powered head’.
• Powered head needs resetting. Go to ‘Lets talk technical’
• The belt may be broken. Go to’ Lets talk technical’
• Brush bar not tted correctly. Go to ‘Lets talk technical’
• The lter may be clogged, clean the lter. Go to ‘Taking care of your machine’.
from the vacuum?
CAUTION: To reduce the risk of personal injury, unplug the product before performing
maintenance/troubleshooting checks.
Getting in touch
Registration required. Terms and conditions apply, see vax.co.uk for details.
* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product cleaner before calling.
GET IN TOUCH
0330 026 8455 VaxVacuumsinfo@vax.co.uk vax.co.uk @Vax UK
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the C85-AC-Pe is manufactured in compliance with the following Directives: Safety: 2006/95/EC Low Voltage Directive. EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
© 2015 All rights reserved. VAX®, VAX Lozenge, AirRevolve™ are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
Loading...
