Get Cleaning...
Bagged Cylinder
User Guide
www.vax.com.au
27000
What’s your Vax’s model number?
What’s your serial number? (Located on the base of the machine)
Note these down in case you need them in future. Please keep instructions for further use.
Vax Service line AU: 1300 361 505
NZ: 0800 800 900
- - - - -
2 7 0 0 0
2
Vax Service line
AU: 1300 361 505 / NZ: 0800 800 900
3
www.vax.com.au
General Safety Information
Machine Overview
Accessories Filters
Carry handle
Bag full indicator
On / Off button
Air Intake Duct
Hose and handle
Dust bag
Combination floor head
Crevice tool
2-in-1 tool (Upholstery &
Dusting Brush)
Variable power
Cord rewind button
Ionizer light
Telescopic wand
Cloth bag
Hard floor brush
Turbo brush
Pre motor filter
Post motor filter
1
1
6
6
2
2
7
7
3
3 8
4
4
5
5
1
4
7
6
2
3
5
FOR HOUSEHOLD USE ONLY.
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry surfaces.
2. Turn off the vacuum cleaner controls before disconnecting
or connecting from the mains supply.
3. Always unplug the vacuum cleaner before connecting or
disconnecting the vacuum hose and accessories.
4. Children should be supervised to ensure that they do not
play with the appliance.
5. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
6. Use only as described in this manual. Use only Vax
recommended attachments.
7. Do not use the vacuum cleaner if it has been dropped,
damaged, left outdoors or dropped into water. Do not
use the vacuum cleaner with a damaged cord or plug.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
8. Do not pull or carry by cord. Do not use the cord as a
handle, close a door on the cord or pull cord around sharp
edges or corners. Do not run the vacuum cleaner over the
cord. Keep the cord away from heated surfaces.
9. Do not handle the plug or vacuum cleaner with wet hands.
Do not use outdoors or on wet surfaces.
10. Do not put any objects into openings. Do not use with
any openings blocked and do not restrict airflow. Keep
all openings free of dust, lint, hair or anything that might
reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the body
away from openings and moving parts.
12. Do not pick up hot coals, cigarette butts, matches or any
hot, smoking or burning objects.
13. Do not pick up flammable or combustible materials
(lighter fluid, petrol, kerosene etc.) or use in the presence
of explosive liquids or vapours.
14. Do not vacuum up harmful or toxic material (chlorine,
bleach, ammonia, drain cleaner etc.).
15. Do not vacuum up hard or sharp objects such as glass,
nails, screws, coins, etc.
16. Do not use without ALL of the filters in place.
17. Take extra care when vacuuming on stairs.
18. Keep vacuuming area well lit.
19. Store the vacuum cleaner in a cool, dry area.
20. Turn off the on/off switch before unplugging the
vacuum cleaner
21. Use only SAA approved 10 amp extension cords. Non-
approved cords may overheat. Care should be taken to
arrange the cord so that the cord cannot be tripped over.
22. Damaged cord to be replaced by manufacturer or
authorised Vax service agent.
23. We recommend the use of a residual current device with
a residual current rating of 30mA or less.
WARNING: Always switch off and unplug the
vacuum cleaner from the electrical outlet before
assembling, opening or emptying the dirt container, or
before connecting/disconnecting the attachments.
CAUTION: The vacuum cleaner is a very powerful
unit. Before plugging the cord into the electrical outlet,
make sure the switch is in the ‘off’ position. Hold the vacuum
cleaner firmly when starting and in use.
IMPORTANT: If the inlet, hose or telescopic tube is
blocked, switch off the vacuum cleaner and remove
the blockage(s) before re-starting the vacuum cleaner.
IMPORTANT: Cleaning filters improves vacuum
performance. Vax recommends that your filters
should be checked and cleaned periodically. If your filters
are washable make sure they are completely dry before
inserting back into the vacuum cleaner.
IMPORTANT: The motor is equipped with a thermal
cut-out. If for any reason the unit should overheat, the
thermostat will automatically turn the unit off. Should this
occur, unplug the vacuum cleaner from the electrical outlet
and turn off the switch. Remove dirt container and empty.
Clean filters. Allow the unit to cool for approximately one hour.
To re-start, plug into an electrical outlet and switch back on.
This vacuum cleaner is intended for household use
only and NOT for commercial or industrial use.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.
1
2
3
4
6
10
11
5
7
8
9
10
11
9
4 5
www.vax.com.au
Vax Service line
AU: 1300 361 505 / NZ: 0800 800 900
Operation
Operation
Keep your Vax like new
Operating the appliance
Assembling your vacuum cleaner
1. Attaching the Flexible Hose into the vacuum. (Pict. 1)
2. Connect the flexible hose into the air intake duct; push in until you hear a “click”, indicating it is in its locked position.
IMPORTANT: The condition of the filters affects the performance of
your machine. Please check and clean filters periodically (depending
on the level of use). For full cleaning instructions, see Maintenance.
IMPORTANT: Do not use the vacuum cleaner without all of the
filters in place.
3. Push the tube into the curved hose extension, (Pict. 2). Fit the tube into the Floor Brush by pushing. (Pict. 3) Adjust the tube to
the desired length. (Pict. 2- 3)
Once all attachments are in place
1. Unwind a sufficient length of cable and insert the plug into the wall outlet.
2. A yellow mark on the power cord shows the ideal cable length, (Pict. 4).
3. Do not pull the power cord beyond the red mark, (Pict. 5).
4. Insert the power plug into the wall outlet.
5. Press the power on/off button located on the unit to turn the vacuum cleaner “on”, (Pict. 6).
To rewind the power cord:
1. Press the Cord Rewind Button with one hand and guide the power cord with the other hand to ensure that it does not whip
around causing damage or injury, (Pict. 7).
To adjust the suction:
1. Slide the suction control button on the suction handle to increase or reduce the suction. (Pict. 8).
6 7
www.vax.com.au
Vax Service line
AU: 1300 361 505 / NZ: 0800 800 900
Operation
The Vax BLISS has a special handling feature. The handle is in the front. There are small directional wheels at the bottom for
easy movement around the house, (Pict. 9 - 10).
Carrying and moving the vacuum cleaner
This motor is equipped with a protective motor thermostat. If for some reason the vacuum cleaner should overheat, the
thermostat will automatically turn the unit off.
1. Should this occur unplug the vacuum from the wall out let and press the off switch, change dust bag and clean filters.
2. Allow the unit to cool for approximately 1 hour.
3. To restart, replug into the wall outlet and turn switch back on.
Ionizer function
Ionizers help to further clean the air of airborne particles working in conjunction with a HEPA filter. When the ionizer
component of the unit is turned on, there is electricity or voltage applied to an internal needle that produce electrons which
are subsequently discharged into the air. Once the electrons bond to air molecules, ions are produced and discharged into
the room. They will then attach themselves to cigarette smoke, pollen, dust, and pet dander and will either fall to the floor to
be swept later or be collected by the ionizer vacuum cleaner.
.
Motor thermostat
Maintenance
The flexible hose should be disconnected from the vacuum cleaner. Carefully remove any blockages found and
reconnect the hose securely.
Remove accessory from the hose/handle tube. Carefully remove the blockage and return to the cleaner.
Clearing blockages
Hose blockages
Accessory blockages
WARNING: To reduce the risk of personal injury, unplug the vacuum cleaner before performing maintenance/
troubleshooting checks!
1. Open the front cover of vacuum.
2. Slide out the full dust bag.
Change dust bag
9
www.vax.com.au
Vax Service line
AU: 1300 361 505 / NZ: 0800 800 900
8
FAQs
• Check the “Parts Overview’ page in this guide to
make sure the part is definately included in your unit.
• It may not be plugged into the electrical outlet correctly;
ensure that the plug is pushed in securely.
• The electrical outlet may not be working properly; check
the fuse or breaker, or consult an electrician.
• The motor thermostat may have tripped; switch off and
unplug the vacuum cleaner, and leave for one hour
before switching the cleaner back on.
• The accessory may be blocked; refer to Maintenance
section.
• The filter may be clogged; refer to Maintenance
section.
• The dust bag is full or blocked; refer to Maintenance
section.
• The dust bag may be incorrectly installed; refer to
Maintenance section.
• The filters may not be installed correctly; refer to
Maintenance section.
• The dust bag may be incorrectly installed; remove the
dust bag from the unit by pressing the dirt container
removal and then re-attaching it to the unit, ensuring it
is locked firmly back into place.
• The filters may be clogged; refer to Maintenance
section.
Is there an accessory missing? Why will the vacuum cleaner
not run?
Why won’t the accessories pick
up properly?
Why won’t the vacuum cleaner
pick up?
Why is there dust escaping
from the vacuum?
Don’t take your machine back to the
shop, simply contact us
www.vax.com.au
AU: 1300 361 505
NZ: 0800 800 900
WARNING: To reduce the risk of personal injury, unplug the vacuum cleaner before
performing maintenance/ troubleshooting checks.
Maintenance
All filters should be checked regularly for signs of damage, preferably after each cleaning task. The filters must be replaced
immediately if they become damaged. Always disconnect the vacuum from the electrical outlet when checking the filters.
Removing & cleaning pre-motor filter and post-motor filter.
Pre-motor Sponge Filter
• Open the front cover of vacuum and lift out the dust bag
• Slide out the Pre-motor filter grill and clean or change filter (Pict. 4)
• Rinse under tap water and allow to dry for 24 hours by airing not near fire, radiators or other high temperature objects
before refitting into the vacuum.
Post motor HEPA Filter
• Follow disassembling procedure as above (Pict.5)
Filters
10 11
www.vax.com.au
Vax Service line
AU: 1300 361 505 / NZ: 0800 800 900
Other Information
Vax Service & Help
Vax Customer Careline AU: 1300 361 505 / NZ: 0800 800 900
Monday - Friday 8.30am to 5.30pm
Any queries or concerns about using the Vax, call the Vax Careline. Calls are charged at the
Standard national rate.
Please make a note of the serial number and model number of the carpet cleaner before calling.
For the nearest Service Agent, please call the Vax Customer Careline or visit www.vax.com.au
Technical Specification
Voltage: 220-240V ~50Hz
Wattage: 2200W
Effective air flow: 1.8 - 2.0 m3/min
Vacuum pressure: >22kPa
Suction power: >320W
Cord length: 7m
Capacity: 3L
Weight: 6.1kg
Filters
Pre-motor: Washable sponge filter
Post-motor: Washable HEPA filter
Bag type: Paper bag / Cloth bag
Subject to technical change without notice.
Waste electrical products should not be disposed of with household waste. Please recycle
where facilitiesd exist. Check with your Local Authority or retailer for recycling advice.
Double
Insulated
Indoor
Use
Read
Instructions
Notes
Distributed by Techtronic Industries Ptd. Ltd.
Level 1. 660 Doncaster Rd, Doncaster, Australia 3108.
www.vax.com.au Service Line: AU: 1300 361 505 / NZ: 0800 800 900
