6131B L S
EEC STATEMENT OF COMPLIANCE
Manufacturer/ EEC importer: VAX Limited, hereby on our own responsibility declare that the product:VAX Canister 6131 BLS is manufactured in compliance with the following;
DIRECTIVES: 73/23/EEC Security against electric shock 89/336/EEC EN55014-1993
STANDARDS: EN60-335/-1/-2-2 Electromagnetic compatibility EN55104-1995
VAX Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 OQH, UK.
Email: enquiry@vax.co.uk - Website: www.vax.co.uk
Part No: 1-8-125029-00 Version No: 1 Printed in China
Easy Guide
UK SERVICE & HELP - VAX CARE 0870 6061248
Mon-Fri. 9.00am to 5.00pm. An answerphone is available out of these hours.
If you have queries or concerns about using your VAX, call the HELPLINE.
Calls are charged at the UK national rate.
Please make a note of the serial number and model number of your VAX before calling.
There are o
ver 400 approved VAX Service Agents in the UK. For your nearest Service
Agent please call VAX Care.
2
THESE PARTS COME WITH YOUR VAX 6131BLS
N.B When unpacking some items will be stored within the main unit.
Motor Unit
Cartridge filter
housing
Clean water bucket
Dirty water bucket
Hose and hand grip
Dusting brush
Carpet
cleaner
Crevice toolUpholstery/stair
vacuuming tool
Carpet
washer
Dry Vacuuming
head
Extension
tubes
Water delivery tube
Upholstery washer
SMS cartridge filter
Deflector
3
GETTING READY TO WASH
4
1
2
3 4 5
WATER
Max 40ºC
VAX CLEANER
5
Turbo
brush
Upholstery
washer
Hard
floor
Stair
hose
Turbo
brush
Upholstery
washer
STEPS FOR EASY VACUUMING
1
2
4
5
3
1
WASHING CARPETS
WASHING
DRYING
2M
2M
1
2
1
2
42
3
5
4-5
6
Ensure Motor has
stopped BEFORE
opening
7
GETTING READY TO WASH - continued
6 7 8
8
CLEANING UP AFTER USE TO KEEP THE PUMP IN YOUR VAX IN GOOD CONDITION WE RECOMMEND YOU FLUSH CLEAN WATER (WITH NO SOLUTION) THROUGH IT AFTER WASHING.
1
2
Ensure Motor has
stopped BEFORE
opening
CLEANING UPHOLSTERY
1
2
1
2
1
4
5
Ensure Motor has
stopped BEFORE
opening
23
9
10
11
CLEANING UP LARGE SPILLS
3
2
1
4 5
6
UNBLOCKING SINKS
3
2
1
4 5
Ensure Motor has
stopped BEFORE
opening
Ensure Motor has
stopped BEFORE
opening
CLEAN THE SMS CARTRIDGE FILTER REGULARLY
1
32
4 5 6 7
CLEAN THE SMS CARTRIDGE FILTER REGULARLY cont
12
13
Ensure cartridge filter and foam sleeve are completely dry before use
15
WASH OUT THE BLACK FILTER REGULARLY AND REPLACE OCCASIONALLY
1
3
42
5
14
WASH OUT THE BLUE FILTER REGULARLY AND REPLACE OCCASIONALLY
1
2
3
4
17
IMPORTANT SAFETY INFORMATION
THIS ‘EASY GUIDE’ SHOULD BE READ COMPLETELY AND
REFERRED TO AT ALL TIMES BEFORE USING YOUR VAX.
This ‘easy guide’ should be retained with your VAX for
future reference. If your VAX is sold or transferred to
a new owner, this guide should be passed on so that
the new owner can become acquainted with the
machine and this information. The following information is provided in the interest of safety. Please read
it before using your VAX.
THE POWER SUPPLY CORD ON YOUR VAX HAS 2
INNER WIRES. IT SHOULD BE CONNECTED TO THE
PLUG AS FOLLOWS.
THIS APPLIANCE MUST NOT BE EARTHED.
IMPORTANT:When carrying out any maintenance or
cleaning operations on this product, it is essential
that the plug is removed from the wall socket.
The wires in the mains lead are coloured BLUE for
NEUTRAL and BROWN for LIVE.
If the plug provided is unsuitable for your socket
outlets, the plug must be cut off and a suitable plug
fitted. The cut-off plug should be disposed of and
must not be inserted into any 13 amp socket as this
can result in electric shock. The plug or adaptor or
the distribution panel should be provided with a 13
amp fuse.
As the colours of the wires in the mains lead of
this appliance may not correspond with coloured
markings identifying the terminals in your plug,
proceed as follows. The wire which is coloured blue
MUST be connected to the terminal which is marked
with the letter N or coloured black. The wire which
is coloured brown MUST be connected to the terminal
which is marked with the letter L or coloured red.
DO NOT CONNECT EITHER WIRE TO THE EARTH
TERMINAL OF A THREE PIN PLUG (THIS 1S MARKED
‘E’ OR BY THE EARTH SYMBOL OR COLOURED
GREEN OR GREEN AND YELLOW).
When replacing or changing a fuse always replace
the fuse cover/holder. The appliance should not be
used with the fuse exposed. If lost, replacement fuse
covers can be obtained from VAX Ltd.
Only 13 amp fuses approved to B.S. 1362 A.S.T.A.
should be used. This appliance conforms with the
requirements of EEC Directive No. 82/499 EEC
relating to radio interference. In the interests of
product improvement, the Company reserve the
right to introduce modifications or alterations
without notice.
16
●
Ensure the mains cable is fully unwound and straightened before use.
●
Ensure the mains cable is kept well away from the revolving brushes (where fitted) of your VAX, when it is
turned on and running.
●
Keep the mains cable away from heat, oil, sharp edges and rough surfaces and avoid damage in any
other way.
●
Exercise extreme care when cleaning stair carpets. Ensure that your VAX is in a stable position at either
the top or bottom of the stairs without over-stretching the hose or cable.
●
When cleaning the stair treads, always keep a hand firmly on your VAX.
●
Follow the instructions in this user guide when fitting and changing accessories or tools.
●
Remove the plug from the wall socket before carrying out any maintenance specified in this guide.
●
Change or clean filters at regular intervals as specified in this guide.
●
Store your VAX in a dry place.
●
Have your VAX serviced by an authorised VAX Service Agent only using genuine VAX spare parts.
●
Switch the pump on occasionally (once per month) for 5 seconds to keep it in
good working order for when you next wash your carpets.
●
Never allow children to tamper or play with your VAX.
●
Avoid dragging your VAX by the mains cable.
●
Never tug at the mains cable to remove the plug from the wall socket.
●
Never allow the complete coiled mains cable to drop on the floor as this may result in kinks or knots
occurring in the cable, causing premature failure.
●
Don’t let anyone touch the rotating brush bar (where fitted) unless your VAX is disconnected
from the mains.
●
Never use your VAX in the presence of flammable gases.
●
Avoid sucking up hot items, hazardous liquids or any other material which could damage your VAX.
●
Never leave your VAX running unattended.
●
Never use your VAX without a dust bag except when washing or sucking up spills.
●
If your VAX fails to operate, never attempt to repair it yourself as repairs carried out by an unauthorised
or inexperienced person may cause injury to you or damage to your VAX.
Never alter the specification or modify your VAX in any way.
DO’S DON’TS
19
18
TROUBLESHOOTING TIPS
TROUBLESHOOTING
IF YOUR VAX SUDDENLY STOPS :
The fuse may have blown. Disconnect your VAX from
the mains, empty the machine and clear any
blockages. Replace the 13 amp fuse and try again.
If it still does not work, contact your nearest
service agent. Check for blockages in the hose,
change and clean all the filters.
IF YOUR VAX DOES NOT SUCK UP PROPERLY :
●
Ensure there are no blockages in the hose.
●
Clean/change the filters. See pages 12/ 13/ 14/
15.
IF YOUR VAX DOES NOT WASH PROPERLY:
●
Check to see if the Dirty water bucket is full. If
it is, empty it. See page 7 picture no. 5.
●
Make sure the solution tube is at the bottom of
the water/washing solution.
See page 5 picture no. 3.
●
Ensure that the connector on the end of the
water delivery tube is fitted properly.
See page 6 picture no. 8.
●
As your VAX is very powerful, you may find that
the dust bag fills up quickly the first time that
you use your VAX.
●
WHEN WASHING CARPETS, ALWAYS TEST FOR
COLOUR FASTNESS, WITH SOME UNDILUTED
CLEANER ON A HIDDEN AREA.
●
When washing deep pile carpets, move the washing
tool in the same direction as the pile lays.
●
Start from the furthest corner of the room and
work backwards towards the door.
●
If you are washing very dirty carpets, you may
have to wash them several times over a period of
time to bring the dirt to the surface.
●
Metal or wooden furniture legs may mark a wet
carpet, wait until the carpet is dry before replacing
furniture or cover legs with aluminium foil.
●
Don’t allow children or animals onto your carpet
until it has had time to dry.
VAX ACCESSORIES VAX CLEANING CONSUMABLES
BLACK FILTER
BLUE FILTER
SMS CARTRIDGE
FILTER
ALL VAX CARPET CARE PRODUCTS HAVE BEEN
INDEPENDENTLY TESTED
AND APPROVED AS SAFE FOR USE
ON WOOL/WOOL RICH AND MAN MADE FIBRE CARPETS.
VAX genuine parts and consumables are available from
supermarkets and many electrical stores. If you have
difficulty obtaining them call the VAXCARE HELPLINE
on 0870 6061248 (Calls are charged at the UK
national rate) for your nearest stockist or visit the VAX
website at www.vax.co.uk
VAX GENUINE PARTS AND CONSUMABLES HAVE BEEN
DESIGNED SPECIFICALLY FOR USE IN YOUR VAX.
USING GENUINE VAX PARTS WILL ENSURE ULTIMATE
PERFORMANCE FROM YOUR
VAX.
CARPET CLEANER
Specially formulated for use with your VAX its colour care
formulation will keep colours true, whilst gently
lifting out deep down dirt quickly and efficiently.
The anti-resoiling system ensures carpets stay clean longer
and the unique fragrance will leave them smelling fresh.
This patented cleaning head scrubs, washes and dries hard
floors instantly, using a continuous flow of clean water.
Suitable for vinyl, ceramics, terrazzos, quarry tiles, sealed
wood and most other hard floor surfaces.
The brush bar inside the Turbobrush rotates at high speed
dislodging trapped dust from within carpet pile,
leaving a grooming effect. Ideal for pet hairs.
HARD FLOOR WASHER
TURBOBRUSH
