LET’S GET STARTED.
CYCLONIC BAGLESS
UPRIGHT VACUUM
PowerNano
Let’s talk safety
Basic
safety
precautions
Don’ts
Do’s
This vacuum cleaner is intended for household use only and
NOT for commercial or industrial use.
• Only use the vacuum cleaner indoors on dry surfaces and keep
the area you’re cleaning well lit.
• Keep ngers, hair and loose clothing from moving parts and
openings whilst using the vacuum cleaner.
• This vacuum cleaner is NOT to be used by children under eight years or persons
with reduced physical, sensory or mental capabilities, unless they have been
given instructions on how to use the machine or are supervised during use.
Any cleaning or maintenance of your vacuum cleaner should not be made
by children without supervision and ensure they don’t play with the vacuum
cleaner. Only Vax recommend tools should be used with this vacuum cleaner.
• Don’t use this vacuum cleaner if it has been dropped, damaged
or left outdoors.
• Don’t run over the power cord or use vacuum cleaner if the power
cord or plug is damaged. Please contact our Customer Service Line
on: 0330 026 8455 (Mon-Fri 8:30am to 6:30pm, Sat 9:00am
to 5:00pm).
• Don’t handle the plug or use the vacuum cleaner with wet hands.
• Don’t pull or carry this vacuum cleaner by the power cord.
• Don’t use the power cord as a handle, pull the power cord
around corners, sharp edges or close a door over the power cord.
• Don’t unplug vacuum cleaner by pulling on the power cord.
• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,
kerosene etc.) or use the vacuum cleaner in an area with explosive vapours
or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful uids (chlorine, bleach,
and ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may cause damage
to your vacuum cleaner.
• Don’t vacuum up hard or sharp objects such as glass, nails, screws or coins etc.
• Don’t use the vacuum cleaner with incorrect voltage as this may result in
damage or injury to the user. The correct voltage is listed on the ratings label.
• Turn o all controls on the vacuum cleaner before disconnecting
or connecting the power cord.
• Always keep the power cord away from the brushes, heated
surfaces and open ames whilst using your vacuum cleaner.
• After use always wrap the power cord around the cord
clips provided.
• Always make sure the lters are in place before use.
• Always switch o the vacuum cleaner before disconnecting
or connecting the hose and accessories.
• Keep all openings clear and free from debris as this may aect
the airow/suction.
• This vacuum cleaner is tted with a constantly rotating brushbar. To avoid
damage to your ooring, make sure the brushbar is raised to the highest setting
when using the accessories and when using on stairs.
• Always take extra care when positioning the vacuum cleaner on the stairs.
• Always replace the fuse in the plug with a British 13amp fuse.
• Use only CE approved 13amp extension cords, non-approved extension cords
may overheat. Care should be taken to arrange the extension cord as it can
be a trip hazard.
• Store your vacuum cleaner in a cool, dry area. If lters have been cleaned as per
user guide instructions ensure they are thoroughly dry before storing away.
Please keep instructions for further use.
Power Nano
(Included with all models)
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
Accessories
What to do if it goes wrong
Getting in touch
Notes
Included with
your machine
Extension Hose 1.5m
Dusting Brush
Crevice Tool
Extension Tube
Hard Floor Tool
Initial Setup for normal operation
1. Use the base accessories.
a. Shortest hose.
b. Extension tube set to shortest practicable length.
2. Clean lters installed.
3. Dust receptacle empty.
4. All air vents must be closed.
5. Floorheads/tools set to Carpet Mode for carpet cleaning.
6. Mechanical Agitation turned ON for carpet cleaning.
7. Floorheads/tools set to Hard Floor Mode for hard oor cleaning.
8. Mechanical Agitation turned OFF for hard oor cleaning.
Thank you for buying this Power Nano.
Taking care of your carpets and hard oors
The Power Nano is designed to make vacuuming carpets and hard oors regularly,
as eective and ecient as possible and this user guide will help you get the most out
of your machine. Maintaining your carpets and hard oors will ensure they keep their
appearance for longer and Vax will help you take good care of them.
Taking care of your Power Nano
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready
when you are to tackle your carpets and hard oors.
Accessory Hose
Let us know what you think @VaxUK
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0330 026 8455 (ROI) 1-800 928 308
Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.
Alternatively, you can write to us at:
Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich,
Worcestershire, WR9 0LW, UK
This user guide can be found online at: vax.co.uk/support
+
Power Nano Pet
TurboTool
Contents
Getting to know your machine Getting started
Assembling your vacuum cleaner
Lift handle up and click into place.
Put dusting brush into dusting
brush holder with brushes
facing outwards.
Line up latch on accessory hose,
push until clicks into place.
Line up TurboTool brushes into
TurboTool holder, push into place
until it clicks (some models only).
Push accessory hose into hose
to machine connector.
Push extension tube and crevice tool
onto holder.
Before you begin cleaning
CAUTION: Always switch o the vacuum cleaner before connecting or disconnecting the hose/attachments
or removing and emptying the dirt container.
Filters require cleaning at least every 3-6 months. If the vacuum cleaner is blocked, switch o and unplug before
removing the blockage.
When the vacuum cleaner is stood in the upright position, or when using the hose and tools the brushbar height adjuster
must be set to the highest setting.
IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does
overheat the thermostat will automatically turn the vacuum cleaner o. If this happens switch the vacuum cleaner o
and unplug from electrical socket. Remove and empty the dirt container also check the vacuum cleaner for blockages.
Allow the vacuum cleaner to cool for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the
lters to fully dry before putting back into the machine).
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Extension tube
and crevice tool
Handle release button
Dust brush holder
Handle
Carry handle
Dirt container
release button
Separator
Dirt container lid
Dirt container
Pre-motor lter
(hidden)
Filter release clip
Upper release
cord hook
Name Power Nano
Voltage 220-240V
Wattage 850W
Weight 5.25kg
Technical Specication
Subject to technical change without notice.
Filter Kit (Type 110)
1-1-134394-00
Belt Kit (Type 25)
1-1-134411 -00
TurboTool (Type 6*)
1-1-134419-00
Crevice Tool (Type 16)
1-1-134427-00
Dusting Brush (Type 10)
1-1-134426-00
Accessories & Consumables
* Selected models only.
To purchase consumables and accessories, please visit
vax.co.uk
Hose connector
Hose inlet
On/O button
Floorhead
Hose
Height adjuster dial
Using your machine Using your machine
Hard oor cleaning
Hard oor cleaning tool.
Line up oor tool with base of vacuum
cleaner, push it until it clicks into place.
Lie vacuum cleaner on its back
exposing the brushbar.
Hold vacuum cleaner with brushbar over tread of stairs.
Using on the stairs
Always raise the height of the brushbar to hard oor setting when using the vacuum cleaner on lino and hard oor.
Apply the hard oor adaptor for optimum results on hard oors.
IMPORTANT: Always switch o and unplug the vacuum cleaner before connecting or disconnecting the hose/
attachments, or removing and emptying the dirt container.
The accessories can be attached to the extension tube or directly to the hose.
When using accessories on the hose/extension tube raise the height adjuster to the highest setting.
TIP
TIP
For best performance
use your vacuum
cleaner with only
the accessory
hose attached.
To ensure the oor
tool is correctly tted,
the wheels should be
towards the back of the
oor tool when attached
to vacuum cleaner.
This vacuum cleaner
has a constantly rotating
brushbar. When cleaning
on stairs raise the height
adjuster dial to the highest
setting. The brushbar
must overhang the stair
tread. Always take care
when cleaning stairs.
CAUTION
Plug vacuum cleaner into
the mains, switch on. Turn
brushbar height adjuster
dial to desired setting.
Press On/O button
to switch on.
Place foot on oorhead
and pull handle to recline.
Pull hose out of hose
to machine connector.
Attach accessory
to tube/hose.
Attach accessory hose
to extension hose.
If required attach extension
hose to extension tube.
Using accessories
Choose an accessory.
Taking care of your machine Taking care of your machine
Cleaning the separator
Turn separator
anti-clockwise
to ‘unlock’, pull
to remove.
Using a soft brush
clean any dirt/debris
out of the separator.
Tap separator over
a bin to remove
any dirt/debris.
Line up tabs on
separator with dirt
container, turn
separator clockwise
to ‘lock’ and click
into place.
The separator
should sit on seal
in bottom of dirt
container when
correctly tted.
Press the dirt container
release button, pull to remove.
Emptying the dirt container
Cleaning the HEPA media pre-motor lter
Hold dirt container
over a bin.
Press the dirt release clip,
allowing dirt/debris to fall out.
Turn the dirt container
lid anti-clockwise,
lift to remove.
24hr
Leave to dry for
24 hours or until
fully dry before
placing back in the
vacuum cleaner.
Turn the HEPA
media pre-motor
lter anti-clockwise,
pull to remove.
Tap HEPA media
pre-motor lter over
a bin to remove
any dirt/debris.
Rinse under water
(max 40°C).
Line up HEPA media
pre-motor lter tabs
in dirt container lid,
turn clockwise until it
clicks into place.
IMPORTANT: The motor is equipped with a thermal cut-out. If for any reason the machine should overheat,
the thermostat will automatically turn the machine o. Switch o and unplug the vacuum cleaner. Check the
machine for blockages and clean the lters. Wash the pre-motor lters with warm water (40°C max) and leave
for 24 hours or until fully dry before replacing into the machine.
Filters require cleaning at least every 3-6 months (depending on the level of use).
Don’t use your vacuum cleaner without all the lters in place.
IMPORTANT: The post motor lter is designed to oer long life with no maintenance. The lter should be
checked periodically and when heavily discoloured it should be replaced. Please do not wash, scrub or brush the
lter as this will damage it.
Post-motor lter maintenance
Storing your vacuum cleaner
Wrap the power cable
around the quick cord
release hooks.
Press handle
release button.
Lower handle
downwards.
Press post-motor
lter cover clip,
pull to remove.
Remove post-
motor lter.
Check the post
motor lter for
any discolouration.
Always use the
carry handle to lift
and carry the machine.
TIP
Don’t over ll the
dirt container to
avoid blocking the
air ow through
the vacuum cleaner
and replace lters
every 6-9 months.
Tabs
Taking care of your machine Let’s talk technical
Removing debris from the brushbar
Using a pair of scissors remove
any threads or hair caught
around the brushbar.
IMPORTANT: Unplug and switch o vacuum cleaner before performing maintenance or troubleshooting checks.
Remove hose end from the
hose to machine connector.
Wrap hose around
hose guide.
Attach accessory hose
to extension hose.
Storing extension hose on vacuum cleaner (optional)
Insert the hose into the hose to
machine connector.
Bring hose over and behind
the carry handle.
Removing dirt/debris from TurboTool (some models only)
Using a pair of scissors cut any
hair or debris free from around
the brushes.
Line up the tabs on front of the
housing and re-t. Slide locking ring
into groove to secure.
Slide the locking ring to remove.
Lift and separate the housing.
Let’s talk technical
Replacing the belt
Place belt on rounded
area of brushbar
without bristles.
Line up right side of
brushbar with base, push
into place. Lift and push
left side of brushbar until
clicks into place.
Lie vacuum cleaner
on its back exposing
brushbars. Use a cross
head screwdriver.
Undo 5 screws.
Line up brushbar
cover, push until it
clicks into place.
Replace 5 screws
and tighten.
Lift to remove
brushbar cover.
Lift to remove
brushbar. Remove and
dispose of old belt.
Clean any debris from
spindle. Place new
belt on spindle.
Remove hose end from the
hose to machine connector.
Lift clip under the
hose inlet.
Pull latch out and
remove hose.
Line up latch on accessory hose and
push until clicks into place Push the other
end of the hose into machine connector.
Removing a blockage from the hose
Accessories
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
Pro Cleaning Kit (Type 2)
1-1-133326-00
All our best tools all in one kit that makes cleaning
your home quicker, easier and with even better results.
We’ve taken care of cleaning all of the hard to reach
areas such as on top of cupboards and in between
blinds to the dust that collates behind and
within the radiator.
If the brushbar does not
rotate easily then the belt
may not have been tted
correctly. Make sure the
belt is not twisted.
CAUTION
Insert a broom handle or
similar blunt instrument into
the hose to remove blockage.
TIP
Test for blockages by dropping a small ball
of paper through the hose. Remove any
blockage by inserting wire.
TurboTool (Type 6)
1-1-134419-00
Use the TurboTool for vacuuming your stairs,
upholstery and car interiors. It’s great for picking up
stubborn pet hair.
†
Registration required. Terms and conditions apply, see vax.co.uk for details.
* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling.
• Check the contents on the back of the box to make sure the part is
included with your vacuum cleaner.
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace with
a British 13amp fuse.
• The motor thermostat may have tripped. If this has happened, unplug
the vacuum cleaner. Remove and empty the dirt container and check the
hose for blockages. Clean the lters and allow the vacuum cleaner to cool
for approximately 1 hour (if you have washed the lters you will need
to wait 24 hours for the lters to fully dry before putting them back into
the vacuum cleaner).
• The brushbar may be clogged, check the brushbar and clear any
hair or debris. Go to ‘Let’s talk technical’.
• The belt might be broken, go to ‘Let’s talk technical’.
• There may be a blockage in the hose. Please remove the hose from the
vacuum cleaner, check and clear any blockages. Go to ‘Let’s talk technical’,
• Empty the dirt container and clean lters. Go to the ‘Taking care of your
machine’ page.
• The brushbar may not be turning. Go to ‘My brushbar isn’t turning?’ below.
• The brushbar height adjuster dial may not be set to the correct setting.
Go to ‘Using your machine’.
• If the accessory/tool will not pick up, check and clear any blockages.
Go to ‘Let’s talk technical’.
• Make sure the hard oor adaptor is attached/unattached dependant
on the oor surface.
SolutionProblem
Is there an accessory
missing?
Why does my vacuum
cleaner have no power?
Why won’t the vacuum
cleaner pick up?
My brushbar
isn’t turning?
What to do if it goes wrong Getting in touch
Notes Notes
GET IN TOUCH
0330 026 8455 VaxVacuumsinfo@vax.co.uk vax.co.uk @Vax UK
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
AWU01 and AWU02 are manufactured in compliance with the following Directives: Safety: 2006/95/EC Low Voltage Directive.
EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice.
© 2015 Vax Limited. All rights reserved. The VAX trade mark and Vax lozenge is the property of Techtronic Floor Care
Technology Ltd and is registered in the EU and may be pending or registered in other countries.
Loading...
