STEAM CLEANER
INSTRUCTION BOOK AND USERS GUIDE
www.sylvane.com 1-800-934-9194
WHEN USING THE STEAM CLEANER, BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE OBSERVED INCLUDING THE FOLLOWING
SAFETY INFORMATION
Steam cleaner must be level and on the floor during use.
listed on the label.
supply cord.
!
GO TO VAPAMORE.COM TO SEE THE MR-100 PRIMO INSTRUCTIONAL VIDEO
Do not over extend retractable cord past stopping point.
around water.
Do not leave the steam cleaner on and unattended. Always
switch the steam cleaner off and remove plug from wall
outlet when unattended.
use only with a grounded outlet.
Vapamore in order to prevent a fire hazard.
Only use distilled water. Using hard water will void the
warranty and cause failure.
Never use additives such as perfumes, stain removers, or
other chemicals in the water tank as they will void the
warranty, cause permanent damage, and be dangerous.
Make sure the water tank cap is fully tight and secure
before use.
(See cleaning and storage).
Do not over pull or drag steam cleaner using the
steam gun and hose.
www.sylvane.com 1-800-934-9194
10.5lbs
E
TECHNICAL SPECIFICATIONS
PARTS LIST
PARTS OVERVIEW
GO TO VAPAMORE.COM TO SEE THE MR-100 PRIMO INSTRUCTIONAL VIDEO
www.sylvane.com 1-800-934-9194
The detail adaptor is required when using all
accessories. Attach by aligning the arrow on the
accessory with the arrow on the detail adapter and
twisting to lock in place. The detail adapter attaches
directly to the steam gun and also can be attached
to the extension tubes.
(Fig. 2 and 3)
Accessory
compartment
The MR-100 Primo has an accessory compartment
that houses the Detail adapter, Jet nozzle
attachment, Clothes / fabric - smooth surface tool,
and all brushes. Open the accessory compartment
by pulling the accessory cover back - away from
the machine. Remove the desired accessory from
the accessory compartment and close the
accessory cover.
(Fig.1)
Accessories twist lock onto the detail adapter
Detail adapter attaches
to the steam gun or
extension tubes.
Connect the steam hose to the steam socket on
the front of the steam cleaner. To do this flip down
the dust cover door and push the connector on the
steam hose firmly into the socket until both tabs
click into place. To remove the steam hose, press
in both release tabs located on the left and right side
of the steam hose connector and pull out to release
from the socket.
(Fig. 4)
STEAM CLEANER ASSEMBLY
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
!
GO TO VAPAMORE.COM TO SEE THE MR-100 PRIMO INSTRUCTIONAL VIDEO
www.sylvane.com 1-800-934-9194
h
andle safety latch.
FILLING & OPERATION
Fig. 7
Fig. 8
The red light will illuminate when the power button is
depressed indicating the unit is heating. The green light
will illuminate indicating the unit is fully heated and
ready for use (approximately 11 minutes). The green
light will cycle on and o with the heater to maintain full
temperature during use. (Fig.10)
Fig. 9
Fig. 10
Green
light
Red
light
Fig. 11
Fig. 11
!
er fill
NOTE:
Do not ov
!
!
!
!
Do not over ll
To ll the water tank, switch the steam cleaner o and remove the plug from the wall
outlet. Allow steam cleaner to cool down before removing water tank cap. Unscrew the
water tank cap (Fig.7) by pressing the cap down and simultaneously turning counter
clockwise. Use the supplied funnel and the measuring cup lled to the top line marked
700ml two (2) times to equal 1.4 liters of water. (Fig.8)
Replace the water tank cap by pressing down on the cap
and simultaneously turning it clockwise. Make sure the
cap is fully tight to prevent any steam from leaking out.
If steam leaks from the cap area turn the Vapamore o
and once cooled down tighten cap further.
Do not exceed the maximum of 1.4 liters
of water when lling the water tank. 1.4 liters is equal to
lling the measuring cup to the 700ml mark tow (2) times.
Plug the Vapamore into a proper wall outlet and switch
to the on position by pressing the on / o switch. (Fig.9)
Never aim steam directly at people,
animals, plants, or electrical systems. There is a risk of
scalding or electrical shock.
or
GO TO VAPAMORE.COM TO SEE THE MR-100 PRIMO INSTRUCTIONAL VIDEO
www.sylvane.com 1-800-934-9194
