Vantec Motion Master User Manual

USER’S MANUAL

1

1. Introduction

1-1. Welcome

1-2. Getting Started

2. Getting to know the Vantec Car Camera DVR

2-1. Specications

2-2. Front Panel

2-3. Back Panel

2-4. Top Panel

2-5. Package Contents

3. Connecting

3-1. Power/Charge connection

3-2. Computer connection

3-3. HDTV and AVout connection

4. Operations

4-1. Getting Started

04

04

04

05

05

07

08

09

10

11

11

11

12

13

13

TABLE OF CONTENTS

2

4-2. Video features

4-3. Camera function

4-4. Play Back function

4-5. G-Sensor-Collision Sensing Capabilities

4-6. Bluetooth
4-6-1. Turn ON/OFF Bluetooth
4-6-2. Pairing the Bluetooth phone
4-6-3. Bluetooth Functional Description
Answer phone call (Bluetooth Key)
Hang up the phone (Bluetooth key)
Reject phone call (Bluetooth key)
Redial the last phone number (MENU OK button)
Volume Control (UP and DOWN Key)
Switching between hands free and your phone (MODE Key)

4-7. Download Videos and Photos

4-8. Preview Videos and Photos on a HDTV or Monitor

14

14

14

14

15

15

15

16

17

17

3

5. Conguration of Function and Tools Setting

5-1. Congure Function Setting

5-2. Video Mode Function Setting

5-3. Camera Mode Function Setting

5-4. Play Back Mode Function Setting

5-5. Congure Tools Setting

5-6. Note

18

18

19

20

21

22

23

4

1. Introduction

Thank you for choosing the Vantec Car Rear View Mirror with Camera Video Recorder and Bluetooth. This
Car Camera DVR (Digital Video Recorder) is an excellent multi-function device that is design to provide safe
video recording of real time event on the road using the Built-in Video Recorder and hands free Bluetooth
functionality. It is capable of recording in 1080 HD video using H.264. The built-in G Sensor provides shock
detection. This device uses Standard interface like USB, HDMI, 12/24V Car Charger, and TF card to simplify
usage.

The Vantec Car Rear View Mirror with Camera Vide Recorder functionality is broken down into 4 modes of
function. They are Video mode, Camera mode, Playback mode and Bluetooth function.

Video Mode :

Camera Mode :

Playback Mode :

Bluetooth Function :

Recording of video using the mounted video camera.

Take still picture using the mounted camera.

Review recorded videos/photos taken using the Video Camera.

Provide hand free use of phone paired to the Bluetooth

1-2. Getting Started

1-1. Welcome

5

2. Getting to know the Vantec Car Camera DVR

Master chip :

Camera Lens/Sensor :

Video Specications :

Bluetooth chip :

Led Lamp :

Display :

Video Compression format :

Sound :

Loop video recording :

Motion detect :

Bluetooth phone call display :

Synchronous voice record :

Collision sensor :

Night vision :

Battery :

TF type :

NT96632

OV9712

1080P, 720P, VGA

LI-85SPK01

Night vision, super infrared lights X4

2.7HD TFT

H.264

high-denition sound quality

support

support

support

support

3D tri-axial collision detection

IR super LED x4

high-quality built-in rechargeable battery

support TF 32G (MAX)

2-1. Specications

6

Image format :

HDMI :

Operation power consumption :

Static electric current :

Standard voltage :

Storage temperature :

Operation temperature :

Operation humidity :

USB interface :

Dimension :

Net weight :

JPEG

support

500MA~700MA

10uA

DC 5V

-20℃~60℃

-10℃~60℃

15-65% RH

USB 2.0

325 x 92 x 45 mm

343.4g

2-1. Specications

7

Bluetooth

– The multi-function buttons serves as an
ON/OFF for Bluetooth capability, accept, hang up, reject calls,
and transfer to phone functions.

Scroll UP

– Directional function to scroll through the menu,

Zoom in, previous view.

Scroll DOWN

– Directional function to scroll through the

menu, Zoom out, next view.

2-2. Front Panel

8

Reset Button

– The reset button will cause the device to

default all setting back to factory default setting.

Rubber Suction Cap

– This suction Cap works on
conjunction with the Rearview Mirror clip to further secure
the device to your car rear view mirror.

Speaker

– The integrated speaker is capable of playing
back recorded sound within close proximity and serve as a
Bluetooth speaker when paired with the mobile phone.

Camera

– This Camera serve as a video camera and still
(photo) picture camera. The camera can be adjusted to limited
angle to record videos. The camera also comes with infrared
light for night video.

Rearview Mirror Clip

– The two springs loaded clip
serve as clamp to secure this device to the existing rear view
mirror with the aid of Rubber Suction Cap (10).

Microphone

– The integrated Microphone is capable of
recording sound within close proximity and serve as a
Bluetooth Microphone when paired with the mobile phone.

2-3. Back Panel

9

Micro HDMI Port

– Use for playback videos/photos. This

requires an optional HDMI cable to connect to a TV for viewing.

TF Card Slot

– TF card slot for storing videos and photos by

Camera. Maximum capacity is 32GB card.

Mini USB Ports

– This Mini USB Port serve two purposes. It
is use for charging/Powering this device or for connecting to a
computer system to retrieve video/photos.

Audio/Video Port

– This port is use to playback using the

provided Audio/Video Cable for playback on TV.

2-4 Top Panel

10

Motion Master-Motion
Detection Car Recorder
USB Car Charger
USB Cable
AV Output Cable
Cleaning Cloth
Warranty Card
User’s Manual
Installation Guide

1.

2.

3.

4.

5.

6.

7.

8.

Cleaning
Cloth

Warranty
Card

USER’S MANUAL

1

2 3

4 5 6

7

8

2-5 Package Contents

11

3. Connecting

There are 3 ports on this device. They are Mini HDMI, USB and AVout port. The Mini HDMI port is use for
connecting this device to your HDTV to preview the content of the TF card.
The Mini USB port serves two functions:

1) to charge and provide power to the device;

2) to connect this device to your computer for viewing and downloading the videos/photos to your computer.
The AVout port is use to connect this device to a composite video device.

To power and charge the device Lithium battery, connect the provided USB charger
adapter (12V/24V) to the device Mini USB port. This will automatically power ON
the device and start charging. Please use only the provided charger, other charger
may not provide the correct voltage and may damage this device.

To connect the device, connect the provided USB cable to the device and the
computer. The device will automatically display a menu to select either the Mass
Storage or Camera selection. You can select Mass Storage, this will enable you to
preview or download the videos or photos stored on the TF card. You can also select
Camera to use the device camera as a USB camera for your computer.

3-1. Power/Charge connection

3-2. Computer connection

12

The device Mini HDMI port can be used to link to a HDTV for preview of your videos and photos. You can also
use the composite AVout port to view on TV.

3-3. HDTV and AVout connection

13

4-1. Getting Started

4. Operations

Before using the device, please
insert a TF card into the TF card slot
located on the top of the device.

Press the power ON/OFF button or
connect the USB car charger, the
DVR will automatically power ON.

Press the Menu Key twice to select the Tools Setting Menu.
Use the Up and Down Key to maneuver to the Format
Menu, Press OK (Conrm) selection to format the TF card
to get it ready for use. Select OK to format the TF card.

Do not setup this device while driv­ing or while the vehicle is in motion.
Please stop at a safe place before
adjusting or installing this device.

Once you TF card have been formatted, you are ready to set the Video/Camera for recording or taking still picture.

If you have important data on the TF card, please back up the data
before you use the format function to erase and reformat the TF card.
