VENTANA

Direct Vent Zero Clearance Fireplace

1200EAN (NG) & 1200EAP (LPG)

Installation & Operating Instructions

INSTALLER: Leave this manual with the appliance.

CONSUMER: Retain this manual for future reference.

WARNING: If the information in these

instructions is not followed exactly, a  re

or explosion may result causing property damage, personal injury or loss of life.

Do not store or use gasoline or other

 ammable vapors and liquids in the vicinity

of this or any other appliance.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light the appliance.

• Do not touch any electrical switch; do not

use any phone in your building.

• Immediately call your gas supplier from

a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the  re department.

Installation and service must be performed

by a quali ed installer, service agency or the

gas supplier.

PLEASE READ THIS MANUAL BEFORE INSTALLING AND OPERATING THIS APPLIANCE.

This appliance may be installed in an

after-market permanently located,

manufactured (mobile) home where not prohibited by local codes.

This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with

other gases, unless a certi ed kit is used.

This appliance is a domestic room-heating appliance. It must not be used for any other purposes such as drying clothes, etc.

This appliance is suitable for installation in a bedroom or bed sitting room.

Massachusetts: The piping and  nal gas connection must be performed by a

licensed plumber or gas  tter in the State of

Massachusetts. Also, see Carbon Monoxide

Detector requirements under “Safety and

Warning Information” on page 5.

4001272-12

Manufactured by

MILES INDUSTRIES LTD.

British Columbia, Canada

www.valor replaces.com

CAUTION—HOT! HOT! HOT!

This appliance is a HEATING appliance and it becomes very hot when in operation.

UNDER ANY CIRCUMSTANCES, DO NOT PLACE any object, furniture, draperies or other item LESS THAN 36 inches (0.9 m) IN FRONT OF THE FIREPLACE.

CHILDREN and PETS

Radiant heat can heat surfaces such as the hearth in front of the replace to temperatures that, although approved safe, can be quite uncomfortable to touch or step on—particularly

for children and pets. Children and pets should always be supervised when in the room

where the appliance is located. Remote control handset should be kept out of reach of

children. In the presence of children, we STRONGLY RECOMMEND that you install in front

of the replace: a re screen, doors or, to protect young toddlers, a “hearth gate”—see

Options on page 41.

HOT SURFACES

Be aware that, although safe, some combustible materials and nishes, even though installed at listed clearances may, over time, discolor, warp or show cracks. The 1200DV requires the installation of the cement board provided with the engine.

Convective heat will exit the unit and travel up the wall surface if not impeded. Protruding mantels and projections can help direct the heat away from the wall. AVOID PLACING heat

sensitive items such as televisions, paintings, decorations, etc. above replaces or near the

edge of protrusions unless appropriate.

The information contained in this installation manual is believed to be correct at the time of printing. Miles Industries Ltd. reserves the right to change or modify any information or specications without notice. Miles Industries Ltd. grants no warranty, implied or stated, for the installation or maintenance of your heater, and assumes no responsibility for any consequential damage(s).

We recommend that our gas hearth products be installed and serviced by professionals who

are certied in the United States

by NFI (National Fireplace Institute®).

190 – 2255 Dollarton Highway, North Vancouver, B.C, CANADA. V7H 3B1

Tel. (604) 984-3496 Fax (604) 984-0246

Designed and Manufactured by

Miles Industries Ltd.

www.valorreplaces.com

Table of Contents

Safety and Warning Information...................................................................4

Specications ................................................................................................7

Overview .........................................................................................................8

Dimensions ....................................................................................................9

Location ..........................................................................................................9

Mantel Clearances .......................................................................................10

Hearth Requirements ..................................................................................12

Framing .........................................................................................................15

Venting ..........................................................................................................16

Installation Planning ....................................................................................21

Appliance Preparation .................................................................................22

Supply Gas ...................................................................................................24

Ceramic Bricks .............................................................................................26

Ceramic Logs ...............................................................................................27

Window Retting ........................................................................................29

Initial Remote Control Set-up ....................................................................29

Decorative Lighting Electrical Installation ................................................30

Operation Check & Aeration Settings Adjustment ...................................31

Window Skirt and Side Doors Installation ................................................32

Remote Control Handset Wall Holder Installation ....................................32

Owner’s Information ....................................................................................33

Remote Control Operation ..........................................................................36

Lighting Instructions ...................................................................................39

Wiring Diagram ............................................................................................40

Options .........................................................................................................41

Warranty .......................................................................................................42

Spare Parts ...................................................................................................43

Safety and Warning Information

READ and UNDERSTAND all instructions carefully

before starting the installation. FAILURE TO FOLLOW these installation instructions may result in possible re

hazard and will void the warranty.

Prior to the rst ring of the replace, READ the Owner’s Information Section of this manual.

DO NOT USE this appliance if any part has been under

water. Immediately, CALL a qualied service technician to inspect the unit and to replace any part of the control system and any gas control that has been under water.

THIS UNIT IS NOT FOR USE WITH SOLID FUEL.

Installation and repair should be PERFORMED by a qualied service person. The appliance and venting

system should be INSPECTED before initial use and at

least annually by a professional service person. More frequent cleaning may be required due to excessive lint from carpeting, bedding, etc. It is IMPERATIVE that the unit’s control compartment, burners, and circulating air passageways BE KEPT CLEAN to provide for adequate combustion and ventilation air.

Always KEEP the appliance clear and free from combustible materials, gasoline, and other ammable vapors and liquids.

NEVER OBSTRUCT the ow of combustion and ventilation air. Keep the front of the appliance CLEAR of all obstacles and materials for servicing and proper operation.

Due to the high temperature, the appliance should be LOCATED out of trafc areas and away from furniture and draperies. Clothing or ammable material SHOULD NOT BE PLACED on or near the appliance.

This unit MUST be used with a vent system as described in this installation manual. NO OTHER vent

system or component MAY BE USED.

This gas replace and vent assembly MUST be vented

directly to the outside and MUST NEVER be attached

to a chimney serving a separate solid fuel burning appliance. Each gas appliance MUST USE a separate

vent system. Common vent systems are PROHIBITED.

INSPECT the external vent cap on a regular basis to

make sure that no debris is interfering with the air ow.

The glass door assembly MUST be in place and sealed before the unit can be placed into safe operation.

DO NOT OPERATE this appliance with the glass door removed, cracked, or broken. Replacement of the glass door should be performed by a licensed or qualied service person. DO NOT strike or slam the glass door.

The glass door assembly SHALL ONLY be replaced as a complete unit, as supplied by the replace

manufacturer. NO SUBSTITUTE material may be used.

DO NOT USE abrasive cleaners on the glass door

assembly. DO NOT ATTEMPT to clean the glass door when it is hot.

TURN OFF THE GAS BEFORE servicing this appliance. It is recommended that a qualied service technician perform an appliance check-up at the beginning of each heating season.

Any safety screen or guard removed for servicing

MUST BE REPLACED before operating this appliance.

DO NOT place furniture or any other combustible

household objects within 36” of the replace front.

Children and adults should be ALERTED to the

hazards of high surface temperature and should STAY AWAY to avoid burns or clothing ignition. Young

children should be CAREFULLY SUPERVISED when

they are in the same room as the appliance.

HOT SURFACES. Be aware that, although safe, some combustible materials and nishes, even though installed at listed clearances may, over time, discolor, warp or show cracks. The 1200DV requires the installation of the cement board provided with the engine. Convective heat will exit the unit and travel up the wall surface if not impeded. Protruding mantels and projections can help direct the heat away from the wall. AVOID PLACING heat sensitive items such as televisions, paintings, decorations, etc. above replaces or near the edge of protrusions unless appropriate. Radiant heat can heat surfaces such as the hearth in front of the replace to temperatures that, although approved safe, can be quite uncomfortable to touch or step on—particularly for children and pets. Accessory screens and guards will reduce the radiant heat on these surfaces.

Safety and Warning Information

Operating your replace for the rst time

When operating your new replace for the rst time, some vapors may be released due to the burning of curing compounds used in the manufacture of the appliance. They may cause a slight odor and could cause the ames to be the full height of the rebox, or even slightly higher, for the rst few hours of operation. It is also possible that these vapors could set off any smoke detection alarms in the immediate vicinity. These vapors are quite normal on new appliances. We recommend opening a window to vent the room. After a few hours use, the vapors will have disappeared and the ames will be at their normal height.

State of California. Proposition 65 Warning.

Fuels used in gas, wood-burning or oil red appliances, and the products of combustion of such fuels, contain chemicals known to the State of California to cause cancer, birth defects and other reproductive harm. California

Health & Safety Code Sec. 25249.6.

State of Massachusetts Carbon Monoxide Detector/Vent Terminal Signage Requirements

For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satised:

1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled equipment, the installing plumber or gas tter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is installed on the oor level where the gas equipment is to be installed. In addition, the installing plumber or gas tter shall observe that a battery operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of qualied licensed professionals for the installation of hard wired carbon monoxide detectors.

a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon monoxide detector with alarm and battery back-up may be installed on the next adjacent oor

level.

b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon monoxide detector with an alarm shall be installed.

2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certied.

3. SIGNAGE. A metal or plastic identication plate shall be permanently mounted to the exterior of the building at a minimum height of eight (8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The sign shall read, in print size no less than one-half (1/2) inch in size, “GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS”.

4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR 5.08(2)(a)1 through 4.

Safety and Warning Information

(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:

1. The equipment listed in Chapter 10 entitled “Equipment Not Required To Be Vented” in the most current edition of NFPA 54 as adopted by the Board; and

2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or structure used in whole or in part for residential purposes.

(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the instructions provided by the manufacturer for installation of the equipment and the venting system shall include:

1. Detailed instructions for the installation of the venting system design or the venting system components; and

2. A complete parts list for the venting system design or venting system.

(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the ue gases, but identies “special venting systems”, the following requirements shall be satised by the manufacturer:

1. The referenced “special venting system” instructions shall be included with the appliance or equipment installation instructions; and

2. The “special venting systems” shall be Product Approved by the Board, and the instructions for that system shall include a parts list and detailed installation instructions.

(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation.

Specications

Approval & Codes

This appliance is certied to ANSI Z21.88b-2008 / CSA

2.33b-2008 Vented Gas Fireplace Heater standard for use in Canada and USA, and to CGA 2.17-91 High Altitude Standard in Canada. This appliance is for

direct vent installations.

This appliance complies with CGA P.4.1 Testing

method for measuring annual replace efciencies.

The installation must conform to local codes or, in the absence of local codes, with the National Fuel Gas

Code, ANSI Z223.1 or the Natural Gas and Propane Installation Code CAN/CGA-B149. Only qualied

licensed or trained personnel should install this appliance.

This appliance must be electrically grounded in

accordance with local codes, or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70 or the Canadian Electrical Code, CSA C22.1.

Ratings

Model N P Gas Natural Propane Altitude (Ft.)* 0-4,500 feet* Input Maximum (Btu/h) 36,000 31,000 Input Minimum (Btu/h) 15,000 15,000 Manifold Pressure (in

w.c.) Minimum Supply

Pressure (in w.c.) Maximum Supply

Pressure (in w.c.) Main Burner Injector

Marking Pilot Injector Marking #62 #30

Min. Rate By-Pass Screw #190 #125

3.6” 10.5”

5” 11”

10” 14”

Cat #

82-1200

92-360

Cat #

Supply Gas

Heater engine 1200EAN is used with natural gas. Heater engine 1200EAP is used with propane gas. The supply pressure must be between the limits shown in the Ratings section above. The supply connection is 3/8 inch NPT female and located on the left hand side of the rebox.

Conversion Kits

The 1200 Ventana is supplied as natural gas or propane gas and is eld convertible between fuels. See instructions packaged with the conversion kit for further

information.

Electrical

The 1200 does not require an electrical power source to operate as a heater. However, it requires electrical power to operate its decorative hearth light.

*High Altitude Installations

Input ratings are shown in BTU per hour and are

certied without deration for elevations up to 4,500 feet (1,370 m) above sea level. For elevations above 4,500 feet (1,370 m) in USA,

installations must be in accordance with the current

ANSI Z223.1 and/or local codes having jurisdiction. Heating value of gas in some areas is reduced to compensate for elevation—consult your local gas utility to conrm.

For installations at elevations above 4,500 feet

(1,370 m) in Canada, please consult provincial and/or local authorities having jurisdiction.

Overview

Fire On/Off

Wall Switch

(optional)

Remote

Handset

Wall Holder

Optional Doors and

Plates—see Options

Wall Finish

Mantel—See Mantel Clearances

Framing—See Framing

Cement Board

Decorative Light

Dimmer Switch

(not provided)

1200EAN

Non-combustible Hearth— See Hearth Requirements

Combustible Floor

1/2” Insulation Board

When the appliance is installed directly on carpeting, tile or other

combustible material other than

wood ooring, the appliance shall

be installed on a metal or wood

panel extending the full width and depth of the appliance

Dimensions

43”

46-3/4”

Location

Combustible Mantel—Left Side View

Mantel Clearances

Mantel Projection

(from Face of Cement Board)

0 2” 4” 6” 8” 10” 12”

Ceiling

50”

45”

43”

41”

39”

Mantel Height

(from Bottom of Unit)

36” Min. to Ceiling

Firebox Height

Face of Cement Board

Fireplace Opening

36”

33”

28”

Bottom of Unit

Left Side View

Mantel Clearances

Combustible Sidewall / Mantel Leg—Top View

Shading denotes

allowable location

for combustible

mantel legs

Face of Cement Board

Wall

FIREPLACE

Fireplace Opening

32-1/2”

1” 2” 3” 4” 5”

2” 1”4”5” 3”

Min. 6”

between edge

of opening

and wall

Note

Right Side Clearances are the same

Top View

Hearth Requirements

General Hearth Considerations

SAFETY WARNING! The Ventana is a very effective radiant heater. The hearth/oor in front of

the heater can get very hot (in excess of 200ºF). Locating the unit raised above the hearth/oor or adding one of the optional screen fronts or a generic freestanding screen in front of the unit can greatly reduce hearth temperatures. Any hearth within 4 inches of the base of the heater must be constructed of non-combustible materials (see diagrams in the following pages). Note that some materials, although safe can degrade due to heat—take this into consideration when choosing materials.

When the appliance

is installed directly on

carpeting, tile or other

combustible material

other than wood ooring, the appliance shall be

installed on a metal or

wood panel extending the full width and depth of the appliance

Top of Finished Hearth

Must Be Flush With Bottom of Heater to accommodate some

optional mantels and trims. See Option section

towards the end of this

manual for optional

accessories.

NOTE:

• Unit will need to be raised

in almost every case to accommodate hearth or

combustible ooring.

• Non-combustible hearth required if bottom of replace is less than 4” from combustible oor in front.

Hearth Requirements

Rules

1. Any hearth/oor in front of replace within 4 inches of the bottom of the unit must be non-combustible and project a minimum distance as shown on page 14. The hearth/oor must have a non-combustible nish applied over the 1/2 inch insulation board provided with the engine. This insulation board acts as a thermal break.

2. Minimum hearth projection is determined by a combination of the height of the hearth above the surface of combustible oor or carpet and the distance between the hearth and the bottom of the replace.

3. Combustible baseboards (1 inch thick or less) located on the wall are acceptable provided they are located below the base of the raised replace.

Unit Raised Above Combustible Hearth or Floor

Face of Cement Board

4” MIN.

Combustible Floor

Base of Fireplace

Top Face of

Combustible Floor or

Carpet

When the appliance is installed directly on carpeting, tile or other combustible material other than wood ooring, the appliance shall be installed on a metal or wood panel extending the full width and depth of the appliance

Front of Fireplace (Surface of Cement Board)

Min. Hearth Projection Required to Protect Combustible Floor

Surface of

Combustible

Floor or Carpet

Bottom of fireplace

When using Optional Trims and Mantels, Surface of Finished Hearth Must Be Flush With Bottom of Fireplace

(otherwise, optional trims will not fit)

Surface of Hearth (non-combutible material on non-combustible insulation board see diagram below)

Wood is Allowed

Directly Below Fireplace

Raised 1” above combustible floor

Raised 2” above combustible floor

Raised 3” above combustible floor

Raised 4” above combustible floor

3” 6” 9” 12”

4”

3”

2”

1”

Surface of Combustible Floor or Carpet

Bottom of fireplace

Wood is Allowed

Directly Below Fireplace

Combustible Floor Allowed

2 “

616STK/617STK Leg & Hearth

Air Gap

Hearth Requirements

Unit With Site-Built Non-Combustible Hearth Extending

Example: If the  replace is raised 2” above combustible  oor, the non-combustible- ushwith-bottom-of- replace hearth must project a min. of 6” in front of the  replace.

Non-combustible substrate construction detail

Bottom of

Using 616/617STK Stone Trim Kits

fireplace

Wood is Allowed

Directly Below Fireplace

DO NOT FINISH ABOVE THIS HEIGHT!

(Hearth MUST be at this height when using certain accessories)

Non-Combustible Finish

See Chart above for Required Projection

Surface of Combustible Floor or Carpet

1/2” Insulation Board supplied with fireplace

Framing

1/2” thick cement board required above and on each side of engine (supplied w/engine)

When the appliance is

installed directly on

carpeting, tile or other

combustible material

other than wood

flooring, the appliance

shall be installed on a

metal or wood panel

extending the

full width and depth

of the appliance

Between underside of header and base of heater. Note: May increase if raising heater further. See Hearth Requirements Section.

50”

24”

FRAMING DIMENSIONS

43-1/2”

Any surface directly in front of the unit which is at a height of

less than 4” from the bottom of the unit must be non-combustible

See chart for minimum non-combustible projection required to protect combustible flooring in front.

Venting

Vent Material

This unit is approved for installation using 4 x 6-5/8 inches coaxial direct vent pipe and accessories manufactured by Simpson Dura-Vent. Follow the installation instructions supplied with the individual venting accessories.

Simpson Dura-Vent DV Venting Accessories

Termination Caps

• 46DVA-HC—Standard Coaxial Horizontal

• 46DVA-VC—Standard Coaxial Vertical

• 46DVA-VCH—High Wind Coaxial Vertical

• 46DVA-VCE—Extended Coaxial Vertical

• 46DVA-SNK14—Snorkel, 14” Rise

• 46DVA-SNK36—Snorkel, 36” Rise

DV 45º Elbows

• 46DVA-E45—Galvanized

• 46DVA-E45B—Black

DV 90º Elbows

• 46DVA-E90—Galvanized

• 46DVA-E90B—Black

Pipes 4” x 6-5/8”

• 46DVA-06—Galvanized, 6” long

• 46DVA-06B—Black, 6” long

• 46DVA-09—Galvanized, 9” long

• 46DVA-09B—Black, 9” long

• 46DVA-12—Galvanized, 12” long

• 46DVA-12B—Black, 12” long

• 46DVA-18—Galvanized, 18” long

• 46DVA-18B—Black, 18” long

• 46DVA-24—Galvanized, 24” long

• 46DVA-24B—Black, 24” long

• 46DVA-36—Galvanized, 36” long

• 46DVA-36B—Black, 36” long

• 46DVA-48—Galvanized, 48” long

• 46DVA-48B—Black, 48” long

Flashing

• 46DVA-F6—Roof 0/12–6/12

• 46DVA-F12—Roof 7/12–12/12

• 46DVA-FF—Flat roof

Other accessories

• 46DVA-WT—Wall Thimble

• 46DVA-SC—Storm Collar

• 46DVA-DC —Decorative Plate

• 46DVA-CS—Cathedral Ceiling Support

• 46DVA-FS—Ceiling Firestop / Floor Support

• 46DVA-WS—Wall Strap

• 46DVA-VSS —Vinyl Siding Standoff

• 46DVA-ES —Elbow Strap

• 46DVA-WG—Terminal Guard

Wall Thickness

The appliance vent is suitable for penetrating a combustible wall assembly up to 8 inches in thickness. A non-combustible wall can be of any thickness up to the maximum horizontal run of vent pipe allowed for the particular installation.

Framing Vent in Combustible Walls & Ceilings

When penetrating through combustible walls and ceilings, frame a minimum of 10 x 10 inches opening and ensure that the insulation is kept clear of the vent pipe using either a wall thimble or an attic insulation shield. Follow the installation instructions supplied with the individual venting components.

10” (254 mm)

Align the vent

center to the center of the frame

10” (254 mm)

Venting

HORIZONTAL TERMINATION

2-PIECE WALL THIMBLE

PIPE LENGTH

90˚ ELBOW

CEILING FIRESTOP

ATTIC FIRESTOP

ATTIC INSULATION SHIELD

FLASHING

STORM COLLAR

VERTICAL TERMINATION

Important Installer Notice – Weather Sealing & Vapor Barriers

It is the installer’s responsibility to ensure that vent installations through exterior walls are caulked and weatherproofed in such a manner as to:

• Prevent rain water from entering the wall from the weather side by adequately caulking the outer vent plate to the exterior

wall surface.

• Prevent moisture inside the home from penetrating into the wall structure by ensuring the inside wall plate is adequately sealed to the inside vapor barrier.

• Prevent rain water and moisture from entering the walls by sealing the joints between the outer vent tube and the inner and outer wall plates.

We recommend the use of a high quality polyurethane sealant.

Typical Venting Components

How to Read the Venting Chart

VERTICAL RISE (ft)

Venting Chart

#4 Restrictor

Venting

The chart below applies to roof or wall termination.

1. The total length of the vent pipe cannot exceed 40 feet (12.2 m).

2. The minimum vertical height with roof termination is 6 feet (1.83 m).

3. Any combination of rise and run can be used as

long as they are within the allowable limits shown

on the chart below.

4. A maximum of 4 x 90 degrees elbows—or

equivalent (2 x 45 degr. = 90 degr.)—can be used.

Venting Chart

4 x 90º ELBOWS

MAXIMUM (or equivalent)

MINIMUM VERTICAL RISE: 2’

1”

Top of

horizontal

pipe

3”

1”

Bottom & sides

of horizontal pipe

All around vertical

pipe

5. Each 90 degrees elbow installed on the horizontal plane is equivalent to a 3 feet horizontal pipe;

therefore, 3 feet must be subtracted from allowable

horizontal run. (45 degrees elbow is equivalent to 18 inches horizontal pipe.)

6. All horizontal pipe runs must be graded 1/4 inch per foot upwards in the direction of the exhaust  ow. The  nal pipe length, when terminating through the wall may be graded downwards slightly to prevent water migration.

7. Co-linear venting is not allowed.

8. A restrictor is required for many installations—see next section.

Allowable Vent

Con gurations

#4 Restrictor

NO INSTALLATION

Min. 2’ before elbow

Min. 12” pipe

Max. 6” pipe if min. vertical rise is used

45º elbow directly on

 ue collar

Max. 24” pipe if min. vertical rise is used

Example 1

V Value = V1 (6’) + V2 (6’) + V3 (2’)= 14’ H Value = H1 (3’) + H2 (3’) = 6’

#2 Restrictor position required

No Restrictor

VERTICAL RISE (ft)

2 4 6 8 10 12 14 16 18 20

#3 Restrictor

Example 1

#2 Restrictor

#1 Restrictor

NO INSTALLATION

HORIZONTAL RUN (ft)

Restrictor

Venting

MANY INSTALLATIONS REQUIRE A RESTRICTOR

for improved ame picture and performance, This unit is supplied with one restrictor having four different positions or settings. The level of restriction required depends on the vertical rise in the venting system and, to a lesser degree, the horizontal run and number of

elbows.

The amount of restriction is based on laboratory tests.

The ideal restrictor position may vary slightly, especially when the vent pipe length is near the limits of the acceptable congurations for each type of restrictor.

The chart on the previous page shows the vent restrictor required relative to the length of the vent pipe.

To install the restrictor:

1. On an engine previously installed, open the panels

on each side of the window. Remove the window

skirt, the window, the logs, the right and rear top brick panels.

2. According to the installation, look up the venting

chart on the previous page to know what position the restrictor should be tted in.

3. Remove the screws (2) on each side of the venting

port.

4. Place the restrictor in the required position over the

two holes.

5. Fit the screws and tighten.

6. Continue the installation or, for an engine previously

installed, replace the right and rear top brick panels, the logs, the window and the window skirt. Close the side panels.

Position #1 Position #2

Position #3 Position #4

Vent Termination

Min. 72”

Max. 72”

• The vent terminal must be located on an outside wall or through the roof.

• This direct vent appliance is designed to operate when an undisturbed airow hits the outside vent

terminal from any direction.

• The minimum clearances from this terminal that must be maintained when located on an outside

wall are shown in the gure below. Any reduction in these clearances could result in a disruption

Venting

of the airow or a safety hazard. Local codes or regulations may require greater clearances.

• The vent terminal must not be recessed into a wall or siding.

• The vent terminal should be positioned where it will

not be covered by snowdrifts.

• Sidewall vent terminations within 7 feet of grade require a terminal guard.

Alcove detail (open on one side) Normal

ceiling/soft

clearances apply.

KEY VENT TERMINAL LOCATIONS - MINIMUM DISTANCES MINIMUM

CLEARANCE

Inches Cm A Clearance above grade, verandah, porch, deck or balcony 12 30

B Clearance to window or door that may be opened 12 30 C Clearance to permanently closed window (recommended to prevent condensation on window) 12 30 D Vertical clearance to ventilated soft located above the terminal within a horizontal distance of

2 feet (60 cm) from the center-line of the terminal

E Clearance to unventilated soft 12 30

F Clearance to outside corner 12 30 G Clearance to inside corner 12 30 H Horizontal clearance to center-line of meter/regulator assembly located within 15 feet (4,6 m)

below the terminal

I Clearance to service regulator vent outlet 36 90

J Clearance to non-mechanical air supply inlet to the building or the combustion air inlet to any

other appliance

K Clearance to a mechanical air supply inlet 72 180

L Clearance above paved sidewalk or a paved driveway located on public property

Note: A vent must not terminate directly above a sidewalk or paved driveway, which is located between two single-family dwellings and serves both dwellings

M Clearance under a verandah, porch, deck or balcony

Only permitted if veranda, porch, deck or balcony is fully open on a minimum of 2 sides

beneath the oor

Note: Local codes and regulations may require different clearances.

18 46

36 90

12 30

84 210

12 30

Vertical Vent Termination

Venting

Roof Pitch

Flat to 7/12 1'

Over 7/12 to 8/12

Over 8/12 to 9/12

Over 9/12 to 10/12

Over 10/12 to 11/12

Over 11/12 to 12/12

Over 12/12 to 14/12

Installer—READ THIS FIRST

Minimum "H" (feet)

1.5'

2’

2.5’

3.25’

4’

5’

Installation Planning

1. YOU NEED TO KNOW FROM THE HOMEOWNER:

- The height of the oor or hearth nish;

- The thickness and type of the wall nish around the rebox opening;

- What accessories (surround, door, etc.) will

be installed with this replace if any;

- The venting conguration.

2. Unpack the appliance.

3. Check that you have everything.

4. Finish framing.

5. Fit appliance into framing.

6. Remove overlay and x the appliance to the oor.

7. Reinstall the overlay.

8. Install venting system.

9. Install restrictor.

10. Connect and test gas supply.

11. Install bricks and logs.

12. Ret window.

13. Connect electrical wiring for decorative light.

14. Install optional wall switch if required.

15. Put batteries in receiver and remote control handset.

16. Perform initial remote control set-up.

17. Verify operation and adjust aeration settings.

18. Install the remote control handset wall holder.

19. Instruct the homeowner on the operation and

maintenance of the replace.

20. Install the window skirt.

21. Install the control access doors.

22. Install the andirons and fret if required.

23. Finish the wall around the replace.

24. Install the surround/doors/mantel if required.

Tools and supplies required

• Packing knife

• Claw hammer

• Screwdriver set

• Metric socket set

• Pliers

• Adjustable Wrench

• Sealant

• Dish soap/water solution

• Gloves

• Eye Protection

• Dimmer Switch

• Electrical outlet box

• Electrical wire and clamp

• Cover plate for dimmer switch

Appliance Preparation

Unpacking the appliance

To assist you, we have included the cement and

hearth insulation boards required in the installation.

The boards need to be removed and reinstalled with

care. Two of the boards are xed temporarily to the back of the appliance for transportation purpose. When disassembling the crate into which the appliance is located, be careful not to damage these boards.

Beware of sharp edges! Wear gloves!

1. Remove the cardboard wrapping and the wood pallet from the appliance and discard.

2. Remove the cement board and hearth insulation

board from the rear of the appliance and set aside with screws for future use.

3. Remove the cement boards from the front of the

appliance and set aside with screws for future use. These boards must be removed to allow space to x the replace to the framing through its four side

tabs.

4. Unpack any loose items from around the appliance.

5. Remove the window and set aside in a safe place

to avoid damage—see next page.

6. Verify that you have all the components

required for the installation, including:

- brick panels (in separate carton);

- surround/doors/fret/andirons;

- venting components and accessories;

- electrical components for installation of the

decorative light wall switch.

7. The standoffs are supplied at on the rebox and xed at one end. Bend them as shown and x the loose end to the top of the rebox.

8. Remove the 4 screws retaining the engine to its pallet.

9. On each side of the appliance, bend out the 2 xing tabs.

10. Taking great care not to cut your hands on the

sheet metal edges, lift the appliance out of its packing base and place in the framing. Make sure

that the unit is at the right height with consideration to the trim and the height of the hearth or

combustible ooring.

11. Secure the xing tabs (2 on each side) to the framing

studs as shown.

Fold Lines

12. Re-install the cement boards on each side and

on top of the rebox opening re-using screws

removed in 2. and 3.

13. Incorporate the hearth insulation board in the

construction of the hearth as required, following the guidelines provided in the Hearth Requirements

section of this manual.

Appliance Preparation

Fixing the appliance to the oor

1. Remove the front bottom overlay panel by removing 2 screws on each side and slide the panel out from under the rebox.

2. Screw the appliance to the oor with 4 countersunk wood or cement screws (not provided).

3. Reinstall the overlay panel sliding it in the clips under the edge of the rebox and xing it back to the bottom sides of the opening frame with 2

screws.

Appliance Preparation

Window Removal

The window is held in place by a spring-loaded lever on

each side.

1. To remove the window, locate the levers on each

side of the window towards the top. Using your nger, pull the lever towards you and unhook it from

the window frame bracket.

2. Gently pull the top of the window outward.

3. Lift the window out of its bottom railing and set it

aside in a safe place to avoid damage.

Section Views

Window frame

Bottom railing

The gas supply inlet connection is a 3/8 inch NPT

female connector and is located on the left hand side of

the rebox.

Use only new black iron or steel pipes or copper tubing if acceptable—check local codes. Note that in USA,

Supply Gas

copper tubing must be internally tinned for protection against sulfur compounds.

Unions in gas lines should be of ground joint type.

The gas supply line must be sized and installed to provide a supply of gas sufcient to meet the maximum demand of the appliance without undue loss of pressure.

Sealant used must be resistant to the action of all gas constituents including LP gas. Sealant should be applied lightly to male threads to ensure excess sealant does not enter gas lines.

Supply Gas

The unit is supplied with a manual shut-off valve and stainless steel ex line to allow the appliance to be disconnected for servicing. The ex line and shut-off valve are supplied loose to avoid damage during shipping. Connect the assembly to the appliance regulator as shown below ensuring that the pressure test tap on the valve is

accessible for future use.

Pressure test the supply line for leaks.

The appliance and its individual shut-off valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa).

The appliance must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psig (3.5 kPa).

Failure to either disconnect or isolate the appliance during pressure testing may result in regulator or valve damages

and void the warranty. Consult your dealer in case of

damages.The unit is supplied with a manual shut-off valve and stainless steel ex line to allow the appliance to be disconnected for servicing. The ex line and shut-off valve are supplied loose to avoid damage during shipping. Connect the assembly to the appliance as shown below.

Shut-Off Valve Supplied with

Heater

S/S Flex Pipe Supplied

Appliance Inlet Connection 3/8” NPT Female

Supplied

loose

Pressure Test Points

The minimum supply pressure is given in the section Ratings of this manual—page 7.

All piping and connections must be tested for leaks after installation or servicing. All

leaks must be corrected immediately.

When testing for leaks:

Valve Inlet

Pressure

• Make sure that the appliance is turned

off.

• Open the manual shut-off valve.

• Test for leaks by applying a liquid detergent or soap solution to all joints. Bubbles forming indicate a gas leak.

Never use an open ame to check for leaks. Correct any leak detected

immediately.

The pressure test tapping locations are shown in the gures on the right. An internal regulator within the valve controls the burner manifold pressure. The correct pressure range is shown in the table in section Ratings of this manual on page 7. The pressure check should be made with the burner alight and at its highest setting. See Lighting Instructions section for full operating details on page 39.

Manifold Test Pressure

Control

Valve

Manifold Pressure Adjustment behind Plastic

Cap

Valve Assembly

Ceramic Bricks

The following guidelines apply for all brick liners.

1. Inside the rebox, on the top of each side, release the screw of the side brick anchors (one per side).

2. Place the rear panel against the back of the rebox, behind the retainer at bottom.

3. Hold the left hand side panel at an angle and insert

it totally inside the rebox, behind the top outer edge of the rebox. This will greatly facilitate the installation. Slide the bottom rst and then the top against the side of the rebox. Rotate the side brick anchor to hold the panel in place.

4. Place the top panel over the top edge of the rear and side panels. Leave the panel to balance there until right hand side panel is installed.

5. Hold the right hand side panel at an angle and insert it totally inside the rebox, behind the top outer edge of the rebox. This will greatly facilitate the installation. Slide the bottom rst and then the top against the side of the rebox. You may have to lift the top panel slightly to avoid scratching it. Rotate the side brick anchor to hold the panel in place.

Top of panel behind the top outer edge of the rebox

6. Make any adjustment by moving the rear top panel slightly.

7. Tighten the side brick anchors on each side of the rebox.

Ceramic Logs

The ceramic logs are supplied in two packages. Unpack them very carefully to avoid damaging the fragile material. Install the logs as shown below. Please note that the position of the Logs is critical to insure proper

performance of the appliance.

1. Place the Rear Log on the rear log support behind the burner. Pull log forward until it contacts at ends. See

detailed view.

Pins for Top Left and Right Logs

2. Place the Middle Log on the pins of the middle log support on the burner. Move the log slightly forward so it sits against the front tabs of the log support. See detailed view.

Pins for Middle Left and Right Logs

Touches here

Rear Log position

against the back of

middle log support

3. Place the Front Log behind the grate with its rear right notch on the middle log’s support front tab. The log must also be at against the burner plate. See

detailed views.

Middle Log position on pins at each end

Notch in back

side of log lines

up with bracket

Front Log bottom should contact sheet metal below

Ceramic Logs

4. Place the narrow end of the Middle Left Log on the left pin of the middle log with its wider end resting on the front log.

Place on pin with log projecting forward

6. Place the Top Left Log on the left pin of the rear log with its end resting on the middle left and front logs.

5. Place the charred end of the Middle Right Log on the right pin of the middle log with its lighter end resting on the notch on the far right of the rear log.

Place on pin with log projecting

backward

7. Place the Top Right Log on the right pin of the rear log with its narrow end resting on the middle and the middle right logs.

Window Retting

1. To ret the window, place it in its bottom railing and push its top against the rebox.

2. While you hold it, pull the side levers back into the window brackets on each side.

3. Pull out the top of the window and release it to

insure the springs return it.

4. Apply light hand pressure against the window frame sides to bed-in the window seal.

Section Views

Initial Remote Control Set-up

The receiver and the handset of the remote control system

must be initially synchronized before the rst use.

1. Insert batteries in the remote control receiver and handset. The receiver is located left of the control valve under the burner module.

2. With a sharp object, press and hold the receiver’s reset

button until you hear two (2) acoustic signals. After the second, longer acoustic signal, release the reset button.

3. Within the subsequent 20 seconds, press the (small ame) button on the remote handset until you hear an additional long signal conrming the sychronization is set.

This is a one time setting only and is not required when changing the batteries in the remote receiver. The remote

control system is now ready to use.

Decorative Lighting Electrical Installation

Wall Dimmer Switch

The electrical installation must be performed

by a qualied installer and must be electrically

wired and grounded in accordance with local codes, or, in the absence of local codes, with the National

Electrical Code, ANSI/NFPA 70 or the Canadian Electrical Code, CSA C22.1.

The replace is equipped with a decorative light

located in front of and above the window. The

light is pre-wired to a junction box on the right hand side, inside the replace. A switched power supply to the knock-out on the right hand side is required to complete the installation. A dimmer is recommended—see specications below.*

1. Turn the power off at the fuse box.

2. Decide where the dimmer will be located. If you are not sure, check with the homeowner.

3. Install the outlet box and connect the dimmer to the

electrical wiring (all components—not supplied— available from your local electrical hardware store).

4. Locate the electrical wire in the junction box inside the rebox outer lining, on the right hand side.

Remove its cover.

5. Run the electrical wires from the dimmer and

thread it through the knock-out of the rebox to the junction box.

6. In the junction box, hardwire the harness to the electrical wire. Ret the junction box cover. Outside the rebox, t a cable clamp.

7. Fit the cover plate to the wall (not supplied).

Electrical

Connection Point

Standard

octagon

Junction

Box + Cover

Accessible

inside

Fireplace

Knock-out on Outside of

Fireplace (use proper cable clamp)

to Dimmer Switch

* Recommended Dimmer Switch (not supplied):

Switch Type: Single-Pole Type: Electro-Mechanical none preset or Preset Load Rating: 600W Voltage: 120 Volt AC 60 Hz Action: Standard ON/OFF Protection: Radio/TV Filter Standards and Certications: UL/CSA

Fitting the Decorative Light bulb

1. Locate the decorative light xture inside the rebox top, just in front of the window.

2. Loosen the screws of the tabs located on each side

of the decorative light xture.

3. While holding the glass cover, turn on of the retaining tabs to free the glass.

4. With a gloved hand, take the halogen light bulb from its packaging and insert in the light xture.

5. Turn the power back on at the fuse box.

6. Turn on the dimmer switch to ensure good function and then, turn it off.

7. Put the glass cover back in place and, while

holding it, turn the retaining tabs back to cover the glass edges.

8. Tighten the tabs screws.

Tab

Light xture with glass cover

Light xture without glass cover

100W Halogen Light Bulb (119mm)

Tab

Operation Check

Operation Check & Aeration Settings Adjustment

Turn the replace ame up and down using the remote control to conrm that the full range of inputs is achieved—see the remote control operation instructions on pages 36–38.

Aeration Settings (NG units only)

(LPG units do not have any primary air adjustment.) Light the re and allow the unit to warm up for 10–15 minutes to evaluate the ame picture. Natural gas burners are equipped with an adjustable shutter to control primary aeration. See the gures below. The shutter is factory-set to an aeration gap which will give optimum performance for the vast majority of

installations.

Air Shutter (NG units only)

Air Shutter

Air Shutter Retainer

Air Shutter in Closed Position

In a few unusual installations, the ame picture may be improved by adjusting the aeration. The need for adjustment should be determined only by operating the appliance with the ceramic logs and window installed.

Increasing aeration will cause the ames to appear more transparent and blue showing more ceramic log glow.

Decreasing aeration will cause the ames to appear more yellow or orange showing less ceramic log glow.

Too little aeration may result in black carbon

forming and dropping into the rebox.

Air Shutter in Open Position

Window Skirt and Side Doors Installation

The replace comes equipped with a window skirt to hide the underside of the rebox and two side steel doors to hide the gas and electrical controls.

1. To install the window skirt, simply hook it to the bottom frame of the window as indicated.

2. Sort the left hand side and the right hand side

doors—the tab to open the door should be towards

the outside at the bottom.

Take one door and locate the top hinge pin in the holed bracket located inside the top front of the outer rebox liner.

3. Slide the door up as much as possible and t the lower hinge pin in the bottom hole.

4. Repeat with the other door.

The doors should be maintained closed by a magnet

on each side of the window frame.

Remote Control Handset Wall Holder Installation

Tab at bottom

The remote control kit for this replace comes complete with a wall-mounted holder. This holder is not required in all installations but is provided as an optional feature

for those customers who wish to mount the remote handset to the wall.

To install the holder to the wall, nd a convenient location and use the hardware provided with the kit. See the diagram below for required hardware and congurations. Note that the holder can be installed at the base of a light switch plate.

Packing Contents:

1 Wall Bracket A

2 Screws B

1 Screw C

2 Wall Anchor D

1 Spacer E (detach before assembly)

1 Wall Bracket F

Alternative 2

IMPORTANT. The location of the remote control

handset is important to assure proper temperature regulation. To obtain a constant temperature, we

recommend that the handset should be between 3

and 15 feet away from the appliance but not directly above it. We also advise that the handset should

be located away from any other heat source and not

in direct sunlight as this may affect the temperature

sensor located in the remote handset.

Alternative 3

Switch Plate

Alternative 1

Owner’s Information

WARNING: Your replace becomes very hot when operating. Avoid placing decorating objects sensitive to heat within 36 inches (0.9 m) around it.

Performance of LPG appliances may be affected by the quality of commercial gas supplied in your area.

Operating Your Fireplace

For your safety, this appliance is tted with a ame supervision device which will shut-off the gas supply if, for any reason, the pilot ame goes out. This device incorporates a xed probe, which senses the heat from the pilot ame. If the probe is cool, the device will prevent any gas ow unless manually lighting the pilot. See full lighting instructions on page 39 of this manual.

Cleaning

Important - Glass cleaning - Mineral deposits

One of the by-products of the combustion process in a gas appliance is a mineral which can show up as a white lm on the ceramic glass of the viewing door. The composition of the deposit varies widely from various

locations and also from time to time in the same location.

It seems this is associated with the varying sulfur content of the gas. You may have the problem for a time and then not see it for many months when it will reappear in your

area.

We have discussed this problem with ceramic glass manufacturers and they cannot give us a denitive answer to this problem. Dealers have tried various cleaning products with varying results. The following recommendations will not guarantee results in your particular case.

NOTE: This is a problem beyond Miles Industries’ control and is not covered under warranty.

1. Clean the glass regularly as soon as you notice the buildup (white lm). If the lm is left for a longer period

of time, it will bake on. It is then much harder, if not

impossible, to remove.

2. NEVER use an abrasive cleaner on the ceramic glass. Any abrasion of the surface has the immediate effect

of compromising the strength of the glass. An emulsion type cleaner is recommended.

3. Use a soft damp cloth to apply the cleaner. Dry the glass with a soft, dry, preferably cotton cloth. Most paper towels and synthetic materials are abrasive to ceramic glass and should be avoided.

4. Our dealers have had good results from the products listed below. We cannot, however, guarantee the results of these products.

• BRASSO

• POLISH PLUS by KEL KEM

• COOK TOP CLEAN CREME by ELCO

• WHITE OFF by RUTLAND

• TURTLE WAX

Do not clean the glass while it is hot. Always securely replace the window before lighting. If broken, the

glass pane may only be replaced as a complete window unit as supplied by the manufacturer.

To remove the window for cleaning, locate the levers on each side of the window towards the top of the unit. Using your nger, pull the lever towards you and unhook it from the window frame bracket. Gently pull the top of the window outward. Lift the window out of its bottom railing and set aside in a safe place to avoid damage—see page 24.

Spring Loaded Window Levers

To ret the window, place it in its bottom railing, push its top against the rebox and, while holding it in place, pull the side levers back into the window brackets. Then, pull out the top of the window and release it to insure the springs return it. Finally, apply light hand pressure against the window frame sides to bed-in the window seal—see page 29.

Soot or dust can be brushed from the ceramic logs and rebox walls using a soft brush. Dust can also be removed from the burner using a soft brush after removing the ceramic logs. When cleaning, make sure that no particles are brushed into the slots of the

burner.

Owner’s Information

Checks

A periodic check of the pilot and burner  ames should be made. Check after the  re has been on for at least 30 minutes. The pilot  ame must cover the tip of the thermocouple probe. The main burner  ame pattern will vary from appliance to appliance depending on the type

of installation and climatic conditions.

Correct Flame Picture

Pilot Flame can be

seen between logs

Light Bulb Replacement

The appliance is equipped with a decorative light inside the  rebox

located in front of the window. To

replace the light bulb, follow these steps:

1. Turn off the decorative light wall

switch.

2. Locate the light  xture. Loosen the screws of the

Tab

Light  xture with glass cover

glass cover retaining tabs.

3. While holding the glass cover so it does not fall and shatter, swivel one or both of its retaining tabs to

Tab

Thermocouple

Probe must be in Flame

Pilot Flame

The appliance area must always be kept clear and free from combustible materials, gasoline and other  ammable vapors and liquids.

Inspect the vent terminal outdoors regularly to make

sure that snow, trees, bushes, leaves, or other objects do not obstruct it.

Examine the vent system and terminal regularly. We

recommend annually.

Light  xture without glass cover

free the glass. Gently remove the glass cover.

4. Remove the light bulb from its socket by pushing towards one end.

5. With a gloved hand, replace with a new light bulb

100W Halogen Light Bulb (119mm)

using a 100 watts halogen 130 volts (type J T3, 119 mm long).

6. Test the bulb by turning the wall switch on. Turn the switch off again to complete the operation. NOTE: If the bulb is new and not functioning, turn

off the dimmer switch and call your local electrician

for inspection.

7. Put the glass cover back in place and, while holding it, turn the retaining tab(s) to retain the glass.

8. Tighten the tabs’ screws.

Owner’s Information

Batteries

BEFORE changing the batteries, turn off the valve using the manual On/Off switch —see instructions below.

The appliance uses four 1.5 V AA batteries for its remote control receiver and one 9 V battery for its handset. Batteries should last one to two seasons, depending on usage. Removing the batteries in the off-season will extend the battery life. Should the batteries lose power, the control may be operated by manually turning the control knob at the valve or by turning off the valve at

the switch.

To replace the batteries in the remote control receiver:

1. Open the side panel to the left of the window.

2. The receiver is located under the valve and it is retained to its

platform by a Velcro tab. Grab the receiver and pull it out from it’s platform.

3. Slide and remove the receiver cover.

4. Replace the 4 AA batteries.

5. Replace the cover.

6. Put the receiver back on its platform pushing it in so it attaches to the Velcro tab. If it was unhooked, replace the antenna in its clip.

IMPORTANT: The antenna MUST NOT TOUCH the ignition wire to avoid a short-circuit.

Antenna

If the antenna was unhooked when

replacing batteries,

hook it back to its clip.

NOTE: It MUST NOT TOUCH the ignition wire!

Ignition Wire

Servicing

If any attention is required for your appliance, contact your supplier quoting the model number. It will be helpful if the appliance serial number can also be quoted. This number is on the rating plate, which is located on the rebox left hand side panel behind the valve assembly. Open the left hand side door to see it. The replacement parts are shown at the end of this manual. Please always quote the part number and description when requesting spare parts.

Manual On/Off Switch

In cases where you want to turn off your replace and cannot do it with the remote control handset (misplaced, lost, dead batteries, etc.) or if you need to replace the receiver’s batteries, you can turn off the appliance with the manual switch located on the right hand side of the

valve.

If the wall switch is installed and the remote control will not be used, remove the battery from the handset and store it away.

To avoid short-circuit to the

receiver, position the antenna so

that it DOES NOT TOUCH the

ignition wire.

If you are planning not to use your replace for a prolonged period of time, remove the battery from the remote handset and turn off the gas valve using the manual ON/OFF switch.

OFF

Owner’s Information

Fireplace Control Devices

There are three ways to control your replace.

1. Thermostatic Remote Control;

2. Wall Switch;

3. Manual On/Off Switch.

The manual On/Off switch must be ON for the replace to function. It can be used to shut off the replace in case of emergency.

Thermostatic Remote Control

Wall Switch

(optional)

The Thermostatic Remote Control can be programmed to function automatically—see pages 36–38.

The Wall Switch (optional) can be used to turn on, off and to increase or decrease the ame height—see 1265WSK—Wall Switch Kit.

Please note that the remote control in the AUTO mode will override the wall switch.

Manual On/Off Switch

Remote Control Operation

NOTE: Before using the remote control system for the rst time, the receiver and the handset must be synchronized. See the section Initial Remote Control Set-up on page 29 in this manual.

Your replace remote control helps you get the comfort, convenience and aesthetics you want from your gas replace. The remote controls your replace in different ways.

IMPORTANT: BEFORE YOU BEGIN, please note that on this system, the settings of time, temperature and automatic ON/OFF can only be programmed when the function display is ashing. Be patient when programming as it can take a few seconds to set.

Turning your replace ON

WARNING: When the pilot is lit, the valve motor turns automatically to maximum ame height.

1. Make sure that the MAN knob on the valve is in ON position.

2. Make sure that the switch on the valve is in the I position.

3. Press and hold the OFF and (large ame) buttons until you hear a short acoustic

signal. Release the buttons.

The acoustic signals will continue until the pilot lights. The remote control will go automatically into TEMP mode. The ame will be at maximum height until the remote control reads the temperature (factory set) and will then adjust the ame accordingly. You can put the remote in MAN manual mode, change the temperature in TEMP mode or program your remote in TIMER mode as indicated in the following sections.

Turning your replace OFF

1. Press the (small ame) button to reduce the ame to pilot.

2. Press the OFF button to turn the pilot off.

Alternately, you can press the O button on the switch if you won’t use your replace for a long period of time, if you cannot locate your remote control handset or if you wish to change the batteries.

Remote Control Operation

Operation Modes

STANDBY MODE—Ignited pilot only.

man MAN MODE —Manual Mode. You can use this mode to adjust the flame height up or down.

temp TEMP MODE —Daytime Temperature Mode (appliance must be in Standby mode; pilot ignited): The room

☼

temperature is measured and compared to the set temperature. The flame height is then automatically adjusted to achieve the Daytime set temperature.

temp

TEMP MODE—Nighttime Setback Temperature Mode (appliance must be in Standby mode, pilot ignited): The room

☽

temperature is measured and compared to the Nighttime Setback temperature. The ame height is then automatically adjusted to achieve the Nighttime Setback temperature.

timer TIMER MODE—(appliance must be in Standby mode, pilot ignited): The Timer setting allows you to set two burner

ON times and two burner OFF times for every 24-hour period.

Changing the Mode of Operation Briefly pressing the SET button changes the mode of operation in the following order:

man

NOTE: MAN mode can also be reached by pressing either the or buttons.

☼temp

→

Mode

TEMP Daytime temperature setting Nighttime temperature setting

TIMER Start time setting Stop time setting

→

☽temp

timer

→

Sun ☼ Moon ☽

and back to

→

man.

Flame Height

The flame height can be adjusted in the following manners. In STANDBY mode,

1. Press the (large flame) button to turn on the main burner.

2. Press the (large flame) button to increase the flame height.

3. Press the (small flame) button to decrease the flame height or to go to pilot Standby position.

For fine adjustments, tap the and buttons.

NOTE: While pressing either button, a symbol indicating transmission appears on the upper right hand corner of the display. The receiver confirms transmission with an acoustic signal.

Time

To set the time, follow the steps below.

1. The display indicates °C/24-hour or °F/12-hour clock. To change from one to the other, press

and hold both the OFF and buttons until the display changes.

2. To set the time, hold down both the and buttons until the display ashes. Let go.

3. Quickly press the button to set the hour and the button to set the minutes.

Note: You must start setting the time while the display is ashing. If it stops ashing, go back to

4. Press the OFF button to return to manual mode or simply wait and it will automatically return

to Manual mode.

Remote Control Operation

Temperature

Use this setting when you come in and want to enjoy a set temperature.

1. Select either the ☼

2. Hold the SET button until the TEMP display flashes.

3. Set the desired temperature with the or the buttons.

Note: 4.5°C/40°F is the minimum temperature setting.

4. Press the OFF button or simply wait and the display will go to the temperature control mode.

Note: If you would like the Nighttime Setback temperature control to turn off, decrease the

☽

temp MODE setting until [---] appears on the display.

Your replace will reach the set temperatures and the remote handset will check the temperature every ve minutes, adjusting the amount of fuel needed to give you a steady,

even heat.

5. The display must remain in TEMP mode on the remote handset.

Timer

It is possible to program two periods of time per day at which your replace will turn on and off

automatically.

temp MODE or the ☽temp MODE by briefly pressing the SET button.

For example, you can set your replace to turn on in the morning just before you get up (P1

☼

[start time]) and to turn off when you leave for the day (P1 ☽ [stop time]). Then, you can set your

replace to turn on again at the end of the day (P2 ☼ [start time]) and to turn off when you go to bed at night (P2 ☽ [stop time]).

If you wish to set only one time period at which your replace will turn on and off, program P2

☼

[start time] and P2 ☽ [stop time] for the same time as P1 ☽ [stop time].

1. Select TIMER mode by briefly pressing the SET button.

2. Press and hold the SET button until TIMER is displayed on the lower right hand side.

3. Press and hold the SET button until P1 ☼ and the time display flashes. Set the start time by

pressing the button for the hour and the button for the minutes. Then, briefly press SET to P1 ☽ and set the stop time in the same manner you just set P1 ☼.

4. Briefly press the SET button again for the next burner cycle time, which will be P2

5. Once all four times are set, press OFF or simply wait to complete programming.

6. The remote handset must remain in TIMER mode to function automatically.

☼ and P2 ☽.

Low Battery Indication

Remote handset: BATT will appear on the display when the battery needs to be replaced.

Replace with one 9 V battery (alkaline recommended). Receiver: Three short ‘beeps’ will sound when the motor turns when the batteries need to be replaced. Replace with four

1.5 V batteries (alkaline recommended).

NOTE: With very low battery, the valve shuts off the re completely. This does not happen when the power supply is interrupted.

Handset / Receiver Match

The remote control handset and receiver are programmed to function together. In case of a replacement of the handset or the receiver, you will need to reset the receiver to allow them to function together. Contact your dealer for details

Automatic Standby Mode (when in Temp or Timer modes only)

If there is no transmission from the handset to the receiver within a 6-hour period, the appliance will go to STANDBY (pilot) mode.

Lighting Instructions

FOR YOUR SAFETY, READ BEFORE LIGHTING

WARNING: If you do not follow these instructions exactly, a re or explosion may result causing property damage, personal injury or loss of life.

A. This appliance has a pilot which must be lighted by hand or by remote control. Follow these instructions exactly.

To save gas, turn the pilot off when not using the appliance for a prolonged period of time.

B. BEFORE LIGHTING, smell all around the appliance area for gas. Be sure to smell next to the oor because

some gas are heavier than air and will settle on the oor.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electric switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the re department.

C. Use only your hand to push in or turn the control knobs. Never use tools. If the knobs will not push in or turn by

hand, don’t try to repair them; call a qualied service technician. Force or attempted repair may result in a re or explosion.

D. Do not use this appliance if any part has been under water. Immediately call a qualied service technician to inspect

the appliance and to replace any part of the control system and any gas control, which has been under water.

LIGHTING INSTRUCTIONS

1. STOP! Read the safety information above.

2. SET ON/OFF SWITCH (1) TO “OFF” POSITION.

• Wait ve (5) minutes to clear out any gas, then smell for gas, including near the oor. If you smell gas, STOP! Follow “B” in the safety information above on this label. If you don’t smell gas, go to the next step.

3. AUTOMATIC IGNITION (Fig. 1): Locate the pilot (Fig. 3.) inside of rebox at left hand side.

• ON/OFF switch (1) in ON position, MAN-knob (2) in ON position; set Flame Adjustment knob (3) to lowest setting ().

• On the remote control handset, press the OFF button (●) and large ame button ( ) simultaneously; a short acoustic signal conrms the start has begun.

• Further short acoustic signals indicate the ignition process is in progress.

Fig 1

• When the pilot is lit, the Flame Adjustment knob (3) will automatically rotate to the highest setting.

• Press the small ame button ( ) on the remote control handset to reduce the ame height.

4. MANUAL IGNITION (Fig. 2): With the window off, locate the pilot (Fig. 3) inside of rebox at left hand side.

• ON/OFF switch (1) in ON position, MAN-knob (2) in MAN

ON OFF

position.

• Set Flame Adjustment knob (3) to the lowest setting ().

• Push down the metallic core (4) with a pen or similar instrument; this will establish the pilot gas ow.

• Light gas at the pilot (5) with a match.

Fig 3

• Continue holding down metal core (4) for about 10 seconds; after release, pilot should

remain lit.

• If the pilot will not stay lit after several tries, turn the gas control knob (3) to OFF ()

and call your local service technician or gas supplier.

• Reinstall the window and set the MAN-knob (2) to ON; turn Flame Adjustment knob (3) up () or down () manually or use the ame buttons ( )( ) on the remote control handset to adjust the ame height.

Fig 2

ON OFF

TO TURN OFF GAS TO APPLIANCE

1. AUTOMATIC SHUT-OFF (using the remote control handset):

• Press and hold the small ame button ( ) on the remote control handset to shut-off the main burner gas ow.

• Press OFF button on remote handset to shut-off the appliance, including pilot ame.

2. MANUAL SHUT-OFF (using only the ON/OFF switch (1) located to the right hand side of the valve):

• Press O the ON/OFF switch (1) to shut-off the appliance, including pilot ame.

Wiring Diagram

Options

Ceramic Liners (required)

1245VRL—Victorian Red Liner Pack 1250FSL—Frontera Liner Pack 1255IBL—Inca Slab Liner Pack 1260BSL—Black Slab Liner Pack

Venting (required)

See Simpson Dura-Vent venting accessories listed on page 16.

Doors and Surrounds (optional)

1210DKA—Alhambra Door Kit 1215FDV—FenderFire Double Door Kit 1220FSV—FenderFire Single Door Kit 1240BPK—3-Sided Backing Plate Kit 1241FBK—4-Sided Backing Plate Kit 1235MTP—3-Sided Polished Trim 1237MFP—4-Sided Polished Trim 614CVI—Arched Cast Surround 615CVI—Cast Surround 616STK—Arched Stone Trim 617STK—Stone Trim

Fret and Andirons (optional)

1225VFB—Ventana Fret Black 1230ACB—Andiron Classic Black 1236MAP—Metropolis Andiron Polished

Conversion Kit (optional)

1200PCK—Conversion Kit to Propane Gas 1200NCK—Conversion Kit to Natural Gas

Wall Switch (optional)

1265WSK—Wall Switch Kit

Fan (optional)

1270RBK—Remote Blower Kit

Hearth Gate (optional)

Hearth gates such as Kidco’s are available at retail stores carrying safety products for children.

Safety Screens (optional)

1205DSK—Draw Screen Kit

Warranty

If you have a problem with this unit, please contact your dealer or supplier immediately. Under no circumstances should you attempt to service the unit in any way by yourself. The warranties in

paragraphs 1 and 2 are provided only to the rst purchaser/user of

this unit, are not transferable and are subject to the conditions and limitations in paragraphs 3, 4 and 5. Please review the conditions

and limitations carefully and strictly follow their requirements.

1. Extended Warranty Coverage

For a period of up to ten (10) years, Miles Industries Ltd., (the “Company”) or its appointed distributor will at its option pay the initial purchaser for the repair of, or will exchange the following parts or components which are found to be defective in material or workmanship under normal conditions of use and service:

Part or Component Defect Covered Maximum Warranty Period

Exterior steel casing Corrosion 10 years

Glass Loss of structural integrity 10 years

Cast iron parts Corrosion 10 years

Firebox and heat exchanger

Corrosion (but not discoloration) causing loss of structural integrity

10 years

2. Two-Year Parts Warranty

In addition, for two (2) years from the date of purchase, the Company, at its option, can repair or exchange all parts and components not listed above but that are found to have a bona de defect in material or workmanship under normal conditions of use.

3. Conditions and Limitations

a) The warranty registration card must be completed by the initial owner and returned to the Company within 90 days of purchase. b) Installation and maintenance must be performed by an authorized and trained dealer in accordance with the Company’s installation

instructions.

c) This warranty is void where installation of the unit does not conform to all applicable codes including national and local gas

appliance installation codes and building and re codes. d) The owner must comply with all operating instructions. e) The Company is not responsible for the labor costs to remove defective parts or re-install repaired or replacement parts. f) The rst purchaser or user of the unit will be responsible for any shipping charges for replacement parts as well as travel time

incurred by the dealer to perform the warranty work. g) This warranty applies to non-commercial use and service and is void if it is apparent that there is abuse, misuse, alteration,

improper installation, accident or lack of maintenance to the unit. h) This warranty does not cover damage to the unit through:

i) Improper installation, operational or environmental conditions. ii) Inadequate ventilation in the area or competition for air from other household equipment or appliances.

iii) Damage due to chemicals, dampness, condensation, or sulphur in the fuel supply lines which exceeds industry standards. i) This warranty does not cover glass, log breakage or damage to the unit while in transit. j) The Company does not allow anyone to extend, alter or modify this warranty and assumes no responsibility for direct, indirect or

consequential damages caused by the unit. State or provincial laws where the rst purchaser or user resides may provide specic rights to extend this warranty and, if so, the Company’s sole obligation under this warranty is to provide labor and/or materials in

accordance with those laws.

4. Discharge of Liability

After two (2) years from the date of purchase, the Company may, at its option, fully discharge all obligations under this warranty by paying to the rst purchaser/user the wholesale price of any defective parts.

5. No Other Warranty

All obligations to repair this unit are dened in this warranty. Some states or provinces may specically mandate additional warranties on the part of manufacturers, but in the absence of such specic legislation, there is no other warranty or obligation expressed or implied.

Spare Parts

Code Description

1 Intake Collar 4000925 2 Intake Collar Gasket 4000942 3 Top Standoff (2) 4001373 4 Firebox

5 Air Inlet Duct Assembly 4001246 6 Rear Log Support 4001280BY

7 Front Brick Support 4001265BY

8 Side Brick Anchor (2) 4001283

9 LH Explosion Relief Assembly 4001286 10 RH Explosion Relief Assembly 4001287 11 Grate Mounting Clips (2) 4001402 12 Cast Iron Grate Assembly 4001401AH

13 Window Frame Assembly 4001221 14 Window Skirt 4001445AZ 15 RH Side Panel 4001243AZ 16 LH Side Panel 4001242AZ 17 1/2” Side Trim (2) 4001360AZ

18 1/2” Top Trim 4001359AZ

19a Burner Module Assembly NG 4001228S 19b Burner Module Assembly LPG 4001229S 20a Pilot Assembly NG 4000727 20b Pilot Assembly LPG 4001428

21 Pilot Bracket 4000729 22 Thermocouple 4000061

23a Pilot Injector #62 NG 4001352 23b Pilot Injector #30 LPG 4000736

24 Pilot Tube 4000732

25 Pilot Hood 2 Flame 4000730 26 Extended Nut 4001855 27 Electrode 4001856

28a Burner Assembly NG 4001400 28b Burner Assembly LPG 4001472

29 Air Shutter (2)—NG only 4000657 30 Shutter Slider—NG only 4000759

31a Injector Elbow #82 NG 4001270 31b Injector Elbow #360 LPG 4001494

32 Valve to Burner Pipe Assembly 4001279X 33 Location Support Assembly (2) 4001288X 34 Top Gasket 4001269 35 Bottom Gasket 4001363 36 Sealing Gasket 4001364

Part

Number

Code Description

37 Side Gasket (2) 4001268 38 Valve GV60 4000873

39 Cable Interruptor 4001035

40 Switch with Cable 4001036

41a Minimum Rate By-Pass Screw NG 4001564 41b Minimum Rate By-Pass Screw LPG 4001058

42 Ignition Cable 4001039 43 Thermocurrent Interruptor 4001037 44 Pipe S/S Flex 4000345 45 Shut-Off Valve 4001282

46 Magnet dia. 16 x 4.5mm 420K551 47a Log Set NG 4001223 47b Log Set LPG 4001541

48 RH Cross Log 4001365

49 LH Cross Log 4001366

50 LH Center Cross Log 4001367

51 RH Center Cross Log 4001368

52 Front Log 4001370 53a Middle Log NG 4001369 53b Middle Log LPG 4001534

54 Rear Log 4001371

55 Quartz Lamp 100 Watts 4001446

56 Light Cover 4001353

58 Remote Control Thermostatic 4001857

59 Handset 4001910

60 Handset Wall Holder 9000008

61 Receiver 4001911

62 Wiring Harness 4001187

63 Cable Clip 4000012

64 Ceramic Liner Sets

a Victorian Red Brick 1245VRL

b Frontera Stone 1250FSL

c Inca Slab 1255IBL

d Black Slab 1260BSL

65 LH Panel

a Victorian Red Brick 4001224

b Frontera Stone 4001327 c Inca Slab 4001328 d Black Slab 4001478

66 Top Panel

a Victorian Red Brick 4001227

Part

Number

Spare Parts

Code Description

b Frontera Stone 4001323

c Inca Slab 4001324 d Black Slab 4001481

67 Rear Panel

a Victorian Red Brick 4001226

b Frontera Stone 4001321

c Inca Slab 4001322

d Black Slab 4001480

68 RH Panel

a Victorian Red Brick 4001225

b Frontera Stone 4001325

c Inca Slab 4001326

d Black Slab 4001479

69 Overlay (to cover front bottom FP) 4001500AZ 70 LH Burner Support 4001511 71 RH Burner Support 4001512

72 Restrictor 4001222

Micore insulation pad (not shown) 4001489

Part

Number

Spare Parts

53a, 53b

Module Plate

Gaskets 34 to 37

47a, 47b

Pilot Assy 20a to 27

19a,19b

28a, 28b

31a, 31b

Valor VENTANA 1200EAN, VETANA1200ENG, VENTANA 1200EAP, VENTANA 1200LPG Installation & Operating Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
