TPMS - Setup Guide
1-800-568-9188
4320 Harvester Rd., Floor 2
Burlington, ON, L7L 5S4, Canada
Pro V2.2
Truck
SETUP GUIDE – TPMS
Table of Contents
Programming the CANbus Transceiver using the SmarTool
Main Menu .................................................................................................................................................................4
SmarTool Setup ......................................................................................................................................................... 5
System Setup ...........................................................................................................................................................6
Step 1 : Read CANbus ID ...........................................................................................................................................7
Step 1.1 ..................................................................................................................................................................... 7
Step 1 .2 ....................................................................................................................................................................8
Step 2: Read Sensor ID/Set Positions .......................................................................................................................9
Step 2.1 ................................................................................................................................................................... 10
Step 3: Uploading to Valor CANbus Memory ............................................................................................................ 11
Step 3.1 ................................................................................................................................................................... 12
Step 4: Program Valor CANbus Transceiver ............................................................................................................ 13
Step 4.1 ................................................................................................................................................................... 14
Step 4.2 ................................................................................................................................................................... 14
Step5:ConrmProgramming .................................................................................................................................. 15
Step 6: Baseline Setup ............................................................................................................................................ 16
Step 6.1 ................................................................................................................................................................... 17
2
SETUP GUIDE – TPMS
Intro: Programming the CANbus Transceiver using the SmarTool
1. These instructions apply only to Valor CANbus
Transceivers (Figure 1) that require a Valor SmarTool
for sensor programming.
Figure 1
Pro V2.2
Truck
2. The SmarTool must be updated to the latest software
version (Pro 2.2 or higher). To check the software
version on your SmarTool simply press the on/off
button. The firmware version of the device will display
on screen Figure 1A.
Figure 1A
3
Main Menu
Sensor 1/7
Vehicle ID
ID Learning
Check ID
SETUP GUIDE – TPMS
1. Once the SmarTool is turned on, the Start menu should
be the same as that shown in Figure 2.
2. This is the home screen and it lists 7 possible
selections as you scroll down the menu using the up/
down arrow keys.
‣ Sensor 1/7
‣ Vehicle ID 2/7
Figure 2
‣ ID Learning 3/7
‣ Check ID 4/7
‣ Baseline 5/7
‣ Download 6/7
‣ System Set 7/7
4
SmarTool Setup
SETUP GUIDE – TPMS
These instructions are for rst use only to setup the
SmarTool:
1. In main menu scroll to “System Set” (Item 7/7)
2. Press ENTER
Current Unit: PF
Want to Set: BC
Setting
Set Unit
Set Axle
Figure 3
Figure 4
3. Set up units of measure, select “Set Unit” (C/PSI)
4. Press ENTER
5. Default settings are in BAR/Celsius (BC), to switch to
PSI/Fahrenheit (PF) use the up/down arrow
(Figure 3)
6. Press ENTER to select (unit will beep to confirm)
7. Press ESC to return to the Setting screen
8. To set up the number of axles, select “Set Axle”
(Figure 4)
9. Press ENTER
10. Use up down arrow keys to select number of axles
11. Press ENTER once (note: Screen doesn’t change)
12. Press ESC twice to return to Main Menu
*Note: If programming TempTrac, please refer to the
TempTrac Setup Guide.
5
System Setup
SETUP GUIDE – TPMS
The system setup requires the following steps:
1. Read CANbus ID
2. Read Sensor ID/Set positions
Pro V2.2
Truck
3. Format Valor CANbus memory
4. Program Valor CANbus transceiver
5. Confirm programming
Turn to next page to begin Step 1.
Figure 5
6
