Vaddio D80, D90 User Manual
Installation and User Guide
Vaddio™ WallVIEW™ D80 PTZ and WallVIEW
D90 PTZ Camera Systems
Wall Mounted Pan/Tilt/Zoom Camera Systems using Vaddio’s EZCamera™ Cabling System
Part Numbers:
WallVIEW D90 PTZ
999-2694-000 - NTSC - Black
999-2694-000W - NTSC - White
999-2694-001 - PAL - Black
999-2694-001W - PAL - White
WallVIEW D80 PTZ
999-2684-000 - NTSC - Black
999-2684-000W - NTSC - White
999-2684-001 - PAL- Black
999-2684-001W - PAL - White
© 2012 Vaddio - All Rights Reserved. Specifications are subject to change without prior notice. Document Number 342-0505 Rev A
WallVIEW D80 PTZ and WallVIEW D90 PTZ Manual
TableofContents
Overview: ................................................................................................................................................................... 3
Important Safeguards: ........................................................................................................................................... 3
Intended Use .......................................................................................................................................................... 3
Save These Instructions ........................................................................................................................................ 3
Information: ............................................................................................................................................................ 3
Unpacking: ................................................................................................................................................................. 4
Four (4) WallVIEW D90 PTZ Systems ............................................................................................................... 4
Four (4) WallVIEW D80 PTZ Systems ............................................................................................................... 4
Installation: ................................................................................................................................................................. 5
Before Installation: ................................................................................................................................................. 5
Diagram: The Basic Idea ................................................................................................................................... 5
Diagram: Daisy Chain Control Configurations .................................................................................................. 6
Step by Step Mounting and Install Instructions: ........................................................................................................ 6
Step 1: Determine the Camera Mount Location: .................................................................................................. 6
Step 2: Determine the preferred Method of Wall Mounting .................................................................................. 6
Image: PCBA inside the Shoe ........................................................................................................................... 7
Image: Attaching the Shoe ................................................................................................................................ 7
Step 4: Attach the Camera and Shoe to the Wall Mount: ..................................................................................... 7
Image: Camera, Shoe and Mount ..................................................................................................................... 7
Finishing the Install: ................................................................................................................................................... 8
Final Step: .............................................................................................................................................................. 8
Documents and Information ................................................................................................................................... 8
Warranty Information: ................................................................................................................................................ 9
Appendix 1: .............................................................................................................................................................. 10
Vaddio Power, Video and Control Pin-outs ......................................................................................................... 10
Image: The EZCamera Cable Shoe ................................................................................................................. 10
Table/Diagram: Power/Video Connection, RJ-45 Pin-outs 568B ..................................................................... 10
Table/Diagram: RS-232 IN Connection, RJ-45 Pin-outs .................................................................................. 10
Table/Diagram: RS-232 OUT Connection for Daisy Chain Support, RJ-45 Pin-outs ...................................... 11
Image: Quick-Connect Box ............................................................................................................................. 11
Table/Diagram: Power/Video Connection, RJ-45 on Quick-Connect Box ....................................................... 11
© 2012 Vaddio - All Rights Reserved. Document Number 342-0505 Rev A Page 2 of 12
WallVIEW D80 PTZ and WallVIEW D90 PTZ Manual
p
Overview:
The Vaddio WallVIEW D80 PTZ and WallVIEW D90 PTZ are a complete wall
mounted Pan/Tilt/Zoom camera systems supporting the standard definition
Sony® EVI-D80 (white and black models) and the EVI-D90 (black and white
models).
The systems include a Sony PTZ Camera (EVI D80 with an 18X optical zoom or
EVI D90 with a 28X optical zoom), a Thin Profile Wall Mount for the camera and
a Vaddio EZCamera™ Cabling System. The EZCamera Cabling System allows
the installer to use two (2) Cat-5 cables to run power, video and control up to
200’ (60.96m).
Also included are Vaddio’s PowerRite™ Power Supply and the EZCamera Cable
Shoe, which regulates the right amount of power needed for the camera over
Cat-5 cabling. The Shoe is connected to the Quick-Connect Box via Cat-5 for a
power and video break out at the head-end and a DE-9 F to RJ-45F EZCamera
Control Adapter is included to adapt an RS-232 controller or control systems to
Cat-5 cabling and there are a number of control adapters available for specific
applications.
The cameras, EVI-D80 and EVI-D90 have a built-in D70 control mode that makes these camera systems
compatible with any controller (for example: ProductionVIEW FX, ProductionVIEW HD and ProductionVIEW
Precision Camera Controller) right out of the shoot making these WallVIEW system immediately available for a
wide range of standard definition shooting applications.
WallVIEW D90 PTZ - Black
Camera System Shown with
Mount and EZCamera Shoe
Important Safeguards:
Read and understand all instructions and warranty statements before using. Do not operate any device if it has
been dropped or damaged. In this case, a Vaddio technician must examine the product before operating. To
reduce the risk of electric shock, do not immerse in water or other liquids and avoid extremely humid conditions.
General Safeguard: Use only the power supply provided with the system. Use of any
unauthorized power supply will void any and all warranties. Please do not cut the
secondary side (or the DC side) of the power supply and attempt to extend the power to the
camera. The warranty is voided when the cable is cut.
Intended Use
Before operating the device, please read the entire manual thoroughly. The system was designed, built and
tested for use indoors, and with the provided power supply and cabling. The use of a power supply other than the
one provided or outdoor operation has not been tested and could damage the device and/or create a potentially
unsafe operating condition.
Save These Instructions
The information contained in this manual will help you install and operate your product. If these instructions are
misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product
drawings for the Vaddio product line on the Vaddio website. These documents can be downloaded from
www.vaddio.com free of charge.
Please do not use “pass-thru” type RJ-45 connectors. These pass-thru type connectors do not
work well for professional installations and can be the caus e of intermittent connections which,
can result in the RS-232 control line failing and locking up, and/or compromising the HSDS™
signals. For best results please use standard RJ-45 connectors and test all cables for prope r pinouts
rior to use and connection to Vaddio product.
Information:
For RS-232 control information, please see the full-length Technical Manuals for the Sony EVI-D80 and EVI-D90.
This manual can be found either on the Sony or the Vaddio website.
© 2012 Vaddio - All Rights Reserved. Document Number 342-0505 Rev A Page 3 of 12
WallVIEW D80 PTZ and WallVIEW D90 PTZ Manual
Unpacking:
Carefully remove the device(s) and all parts from the packaging. Please do not toss the packaging yet, just set it
aside where it won’t be in the way. Unpack and identify the following parts:
All of the WallVIEW Systems will have the following set of peripherals and it shall be known as “The Peripheral
Set”, otherwise there will be many pages of duplication, which may prove rather bothersome.
The “Peripheral Set” contains the following gear:
One (1) EZCamera Cabling Shoe 998-2280-000 (white or black - camera dependent)
One (1) Quick-Connect Box 998-1105-001
One (1) PowerRite 18 VDC, 2.75 Amp Power Supply
One (1) EZCamera Control Adapter 998-1001-232
NTSC Units - One (1) North American Power Cord
PAL Units - One (1) Euro and One (1) UK Power Cords
One (1) Thin Profile Wall Mount 535-2000-236 with Mounting Hardware
One 12’ (3.66m) S-Video Cable
One 12’ (3.66m) Composite Video Cable
Sony IR Remote Control
Documentation (Vaddio Manual and Sony Manual)
Four (4) WallVIEW D90 PTZ Systems
999-2694-000 - NTSC - Black
One (1) Sony EVI-D90N - Black, NTSC Camera
One Peripheral Set with North American Power Cord, Black Mount and Shoe
999-2694-000W - NTSC - White
One (1) Sony EVI-D90N/W - White, NTSC Camera
One Peripheral Set with North American Power Cord, White Mount and Shoe
999-2694-001 - PAL - Black
One (1) Sony EVI-D90P - Black, PAL Camera
One Peripheral Set with Euro and UK Power Cords, Black Mount and Shoe
999-2694-001W - PAL - White
One (1) Sony EVI-D90P/W - White, PAL Camera
One Peripheral Set with Euro and UK Power Cords, White Mount and Shoe
Four (4) WallVIEW D80 PTZ Systems
999-2684-000 - NTSC - Black
One (1) Sony EVI-D80N - Black, NTSC Camera
One Peripheral Set with North American Power Cord, Black Mount and Shoe
999-2684-000W - NTSC - White
One (1) Sony EVI-D80N/W - White, NTSC Camera
One Peripheral Set with North American Power Cord, White Mount and Shoe
999-2684-001 - PAL- Black
One (1) Sony EVI-D80P - Black, PAL Camera
One Peripheral Set with Euro and UK Power Cords, Black Mount and Shoe
999-2684-001W - PAL - White
One (1) Sony EVI-D80P/W - White, PAL Camera
One Peripheral Set with Euro and UK Power Cords, White Mount and Shoe
Not all items shown
© 2012 Vaddio - All Rights Reserved. Document Number 342-0505 Rev A Page 4 of 12
