Installation and User Guide
ClearVIEW™ HD-USB PTZ
USB, H.264 and Analog HD Pan/Tilt/Zoom Conferencing Camera
Part Numbers:
999-6990-000 - North America
999-6990-001 - International
© 2012 Vaddio - All Rights Reserved. ClearVIEW HD-USB PTZ Conferencing Camera - Document Number 342-0437 Rev B
Camera Software Revision 1.2.0
ClearVIEW HD-USB Conferencing Camera
Table of Contents
ClearVIEW HD-USB PTZ Conferencing Camera ...................................................................................................... 4
Diagram: Front View with Feature Call-outs: .................................................................................................... 4
Diagram: Rear View Connectors with Feature Call-outs: ................................................................................. 5
First Time Set-up with the ClearVIEW HD-USB PTZ Camera .................................................................................. 6
Getting Started: ...................................................................................................................................................... 7
For Release 1.2.0 of the Camera and Software, only the USB 2.0 Streaming Video is Active: ............................ 8
Compatibility .............................................................................................................................................................. 8
Internal Web Pages and Control: ........................................................................................................................... 9
DHCP Set-up (Dynamic Host Configuration Protocol): .......................................................................................... 9
Static IP Set-up: ................................................................................................................................................... 10
Screen Shot Tour: .................................................................................................................................................... 11
Admin Pages: ....................................................................................................................................................... 12
Diagram: Basic Connectivity Example 1 ......................................................................................................... 18
Diagram: Connectivity Example 2: .................................................................................................................. 19
Diagram: H.264 Streaming Connectivity (for Release 2.0 when IP Streaming is enabled): ........................... 19
Diagram: Connection Diagram Example using A CDN (for release 2.0 when IP is enabled): ........................ 20
Connecting the Camera to the Program of Choice: ................................................................................................ 20
Skype Example: ................................................................................................................................................... 20
VLC Media Player Example: ................................................................................................................................ 21
Technical Specifications: ......................................................................................................................................... 21
Compliance and CE Declaration of Conformity: ClearVIEW HD-USB PTZ Camera ............................................. 22
Warranty Information: .............................................................................................................................................. 23
Appendix 1: RS-232 Communication Specification ................................................................................................ 24
Firmware Version 1.2.0 Release Notes: .............................................................................................................. 25
ClearVIEW HD-USB PTZ Camera ....................................................................................................................... 25
New Features and Functions: .............................................................................................................................. 25
WebEx Compatibility: ....................................................................................................................................... 25
Improved Interoperability with Various UC software Clients: ........................................................................... 25
Keyboard Hotkeys for PTZ functions:............................................................................................................... 25
USB Color Space Option: ................................................................................................................................. 25
Firmware Update Function: .............................................................................................................................. 25
Telnet Command API: ...................................................................................................................................... 25
Table: Supported UVC Resolutions ................................................................................................................ 26
Table: Interoperability Testing & Findings ....................................................................................................... 26
Table: HD-USB Camera UC Client Interoperability Testing ............................................................................ 26
Appendix 2 - Telnet Serial Command API ............................................................................................................... 27
Telnet Command List ........................................................................................................................................... 27
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 2 of 32
ClearVIEW HD-USB Conferencing Camera
O
VERVIEW
The extraordinary Vaddio™ ClearVIEW HD-USB PTZ Conferencing
Camera system includes many of the features that you would expect
out of a professional PTZ camera, plus much more! The ClearVIEW
HD-USB is the world’s first broadcast-quality HD PTZ camera with
USB 2.0 output, Ethernet streaming and analog component (YPbPr)
outputs built right into the camera. Simply plug the HD-USB camera
directly into your PC and there is no need for a separate capture
device. The ClearVIEW HD-USB uses standard USB 2.0 UVC drivers
and no special USB drivers require installation. As a result the HDUSB camera works seamlessly with any software application running
on any OS that supports USB 2.0 devices. All this, and the ClearVIEW
HD-USB PTZ cameras are made in the USA
The ClearVIEW HD-USB combines impressive performance with an
equally impressive feature set. Using the UVC standard drivers for
USB 2.0 video, the HD-USB camera is a plug and play PTZ camera for
Unified Communications soft client conferencing systems such as
Skype®, Google+, Jabber® and Lync®, which offers a vast
improvement over the “inexpensive webcam” systems available
today.
.
The HD-USB is a high definition conferencing camera suitable for the small, medium or even the largest
conferencing space available. The HD Zoom lens allows HD-USB to capture a wide angle of view (58.1°) to view
everyone at a conference room table, as well as capture an individual from a long distance (3.2°) in a larger room.
:
The HD-USB PTZ Camera will be released with two (2) major software releases and several intermediate
releases. Release 1.0 will allow USB 2.0 streaming and with the following Release 2.0 software, the ClearVIEW
HD-USB will also support H.264 video streaming. It has a built in Ethernet network interface where both IP control
and IP streaming can be initiated directly from the camera. It will support either RTSP or HLS streaming protocols.
The software is easily upgradeable in the field.
The motorized zoom lens offers 19X optical zoom and is built around a 1/3-Type Sony® Exmor, progressive scan,
high-speed, low noise CMOS image sensor with a total of 1.3 Megapixels for precise and vibrant HD color video
images. The HD-USB achieves improved picture quality even in low light environments requiring a minimum
illumination rated at an amazingly low 0.7 LUX (F1.6 - 50IRE).
Intended Use:
Before operating the device, please read the entire manual thoroughly. The system was designed, built and
tested for use indoors, and with the provided power supply and cabling. The use of a power supply other than the
one provided or outdoor operation has not been tested and could damage the device and/or create a potentially
unsafe operating condition.
Important Safeguards:
Read and understand all instructions before using. Do not operate any device if it has been dropped or damaged.
In this case, a Vaddio technician must examine the product before operating. To reduce the risk of electric shock,
do not immerse in water or other liquids and avoid extremely humid conditions. Do not connect Ethernet or
Power over Ethernet (POE) cables directly to the RJ-45 ports on the device as damage may result.
Use only the power supply provided with the system. Use of any unauthorized
power supply will void any and all warranties.
Please do not use “pass-thru” type RJ-45 connectors. These pass-thru type connectors do not w ork
well for professional installations and can be the cause o f intermittent connections which can result in
the RS-232 control line failing and/or locking up. For best results please use standard RJ-45
connectors and test all cables for proper pin-outs prior to use.
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 3 of 32
ClearVIEW HD-USB Camera
ClearVIEW HD-USB Conferencing Camera
Save These Instructions:
The information contained in this manual will help you install and operate your product. If these instructions are
misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product
drawings for the Vaddio product line on the Vaddio website. These documents can be downloaded from
www.vaddio.com free of charge.
U
NPACKING
North American Version 999-6990-000
Carefully remove the device and all of the parts from the packaging.
Unpack and identify the following parts in 999-6990-000.
One (1) ClearVIEW HD-USB PTZ Camera (998-6990-000)
One (1) Vaddio IR Remote Commander
One (1) EZCamera™ Control Adapter (RJ-45 to DB-9)
One (1) Vaddio PowerRite™ 12 VDC, 3.0 Amp Power Supply
One (1) AC Cord Set for North America
One (1) 10’ (3.05m) USB 2.0 Type A-male, to USB B-male Cable
Documentation
International Version 999-6990-001
One (1) ClearVIEW HD-USB PTZ Camera (998-6990-000)
One (1) Vaddio IR Remote Commander
One (1) EZCamera Control Adapter (RJ-45 to DB-9)
One (1) Vaddio PowerRite 12 VDC, 3.0 Amp Power Supply
One (1) Euro Power Cable
One (1) UK Power Cable
One (1) 10’ (3.05m) USB 2.0 Type A-male, to USB B-male Cable
Documentation
CLEARVIEW HD-USB PTZ CONFERENCING CAMERA
Diagram: Front View with Feature Call-outs:
1) Zoom Lens and Image Sensor:
The 19X optical zoom lens is built around a 1/3-Type, highspeed, progressive scan CMOS image sensor with a total of 1.3
Megapixels for precise HD video image acquisition.
2) Blue Power Light:
A Vaddio blue power light is illuminated when the camera is
turned on.
3) IR Sensors:
IR sensors are built into the front of the HD-USB to receive IR
signals from the IR remote control supplied with the camera.
4) Red Tally Light:
The red tally light is not used with the HD-USB Camera
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 4 of 32
➊
➍
➌
➋
ClearVIEW HD-USB Conferencing Camera
ClearVIEW HD-USB PTZ Conferencing Camera
Diagram: Rear View Connectors with Feature Call-outs:
Connectors and Functions:
1) 12 VDC Input:
Power input on EIAJ-04 connector for local power.
2) HD Video Select:
A rotary switch that allows the user to choose the component HD output video resolution and format. For the
USB output, use rotary switch settings 0, 1, 4, or 5. Please see the sections on available resolutions and
concurrent resolutions when using USB 2.0 and analog component outputs
3) Camera Settings (Dip Switch Settings):
Settings for IR remote frequency, baud rate, SD output format, and image flip, test bars can be configured on
these switches.
4) RS-232 IN & IR Out:
The upper RS-232 Port is not implemented on the HD-USB Camera. Use the RS-232 Port on the lower card.
④
⑤
③
⑥
②
①
⑧
⑨
⑩ ⑫
⑪
⑬
⑦
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 5 of 32
ClearVIEW HD-USB Conferencing Camera
Connectors and Functions (continued)
5) YPbPr Output:
Component HD video is fed through the DE-15 connector (HD-15 for the shell sized challenged). YPbPr and
Composite signals are simultaneous. Note: This is an HD camera and the SD signals are down converted and
are really not the sweet spot of this camera. This is a courtesy feature only.
6) Composite Video (CVBS) Output:
The CVBS output feeds out SD video signals and is configurable with the dip switches to choose between
480i/NTSC or 576i/PAL in 4:3 formats. Squeeze and letterbox modes are also available (see dip switches).
7) EZ Power/Video Port:
This RJ-45 connector is only used with the Quick-Connect SR Interface and the Quick-Connect DVI-D/HDMI SR
Interface to supply power and return HSDS (high speed differential signaling) video from the camera.
8) 5 VDC Output:
The 5 VDC output is on an EIAJ-03 connector was added to supply power to the active Extreme USB Extender
transmitter side. The receiver side is powered by the computer’s USB port or powered USB Hub.
9) USB 2.0 Connector:
The USB 2.0 is on a type-B Female and attaches to a PC running a soft-client video conferencing system or
video capture software that uses UVC (USB Video Class) standard drivers. No other drivers are required to plug
the HD-USB into a computer and have it work. The UVC drivers will auto negotiate the top resolution that the PC
and HD-USB Camera can accomplish together and auto implement it, and bob’s your uncle.
10) Settings Rotary Encoder:
The settings encoder is provided essentially for future use. The only position that is currently assigned and used
is position “C”. This position allows the user to reset the camera back to factory defaults when the camera is
power cycled in the “C” position.
11) Ethernet 10/100 Port (H.264 Streaming Active with Software Release 2.0):
The network port has green and yellow LEDs that indicate ready and usage states. The port allows for access to
the internal web pages for camera set-up and control. The network port will stream (unicast) H.264/MPEG4/AVC
video (from CIF up to and including 1080p/30) in Release 2.0.
12) RS-232 Port:
The RS-232 Port allows external control systems to engage a rudimentary API. Basic functions include pan, tilt
zoom, on/off etc. The functions on the Vaddio IR Remote Commander are mirrored in the API. Most control is
expected to come from the internal web page via Ethernet, Telnet or over USB 2.0.
13) Permanent USB Resource Slot Card:
The lower row of connectors and the brains of the HD-USB Camera are located on this permanent slot card. The
card is not removable and is not compatible with any other Vaddio camera. Please do not try to remove this card
at any time.
FIRST TIME SET-UP WITH THE CLEARVIEW HD-USB PTZ CAMERA
The ClearVIEW HD-USB PTZ Camera was designed to be exceptionally
easy to use and operate. There is documentation at the back of the
manual for pin-outs. These pin-outs are also available, along with
application TechNotes, from the Vaddio website www.vaddio.com.
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 6 of 32
ClearVIEW HD-USB Conferencing Camera
Getting Started:
Step 1: Using the HD Video Select Rotary Switch and Camera Settings Dip Switch on the back of the camera,
set up the camera’s output resolution and functional preferences referencing a label on the bottom of the camera.
HD-USB
Rear Panel
Switch Setting Label on Bottom of the HD-USB Camera:
1 & 2 UP
IR 2ONIR 3
1234
Step 2: For the best USB 2.0 video, set the HD VIDEO SELECT switch to “0” (720p/59.94) on the HD-USB
Camera. All resolutions are derived from 720p. The USB 2.0 processor can accept rotary positions 0 through 6,
but please be aware that if 1080p/60 is scaled down to 320 x 180, well…the image will look much better if the PC
scales from 720p than 1080p (see note below).
For concurrent USB 2.0 and Analog C omponent (YPbPr), switch settings 0 through 6 are the resoluti ons that can be both
For Analog (YPbPr) output, all of the HD VIDEO SELECT switch settings will operate.
The Composite output on the BNC connectors independ ent from the USB 2.0 / IP resolutions. The SD settings and are
Please Note: When using 1080p as the input, very low USB 2.0 resolutions such as 352 x 240 and 320 x 180 will either not look so
good, won’t work or the user may wish they didn’t work due to how far the signal is scaled/smashed down by the PC from t he
original input. Please use 720p or position “0” for the lower resolutions. Always start from a HD resolution closest to what the UC
client wants to send and display.
digital (USB 2.0 or H.264) and Analog (YPbPr). These resolutions ar e the most used resolutions for H D video in both H D
videoconferencing and broadcast.
formatted by dip switches 5, 6 and 7.
Step 3: Choose the IR frequency (1, 2 or 3) on the camera for use with the IR Remote Commander. Since only
one USB camera can be plugged into a PC at a time, recommended default is Freq. 1 (dip switches 1 & 2 up).
Step 4: Leave the IR out OFF (up) as default.
Step 5: Use 9600bps for control speed as default.
If the camera is mounted inverted, then set the Image Flip to ON, otherwise leave it off.
The test bars are really, really, totally non-standard (horizontal - just to mess with the old-timers) and will
override the video output. These test bars are 75% IRE. Use the test bars for…testing.
IR 1
ON
21
HD Video
Select Switch
DIP SWITCH SETTINGS
IR
OUT
OFF
ON
3768109
SD
9600
NTSC
bps
SD
38400
PAL
bps
567 910
5
4
Camera Settings 10-Pos Dip Switches
SD 4:3
6 & 7 UP
SD
SQ
SD
LB
FLIP
OFF
ON ON
8
TEST
BARS
OFF
HD VIDEO AND USB 2.0 SELECT
720p/59.94 - USB
10
OFF
ON
0
1080i/59.94
1
1080p/59.94
2
1080p/60
3
720p/50
4
1080i/50
5
1080p/50
6
480i/29.97
7
USE ROTARY SETTINGS 0 through 6 FOR USB 2.0 OUT
8
9
A
B
C
D
E
F
576i/25
1080p/30
1080p/25
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 7 of 32
ClearVIEW HD-USB Conferencing Camera
For Release 1.2.0 of the Camera and Software, only the USB 2.0 Streaming Video is Active:
The H.264 will follow in Release 2.0, so for now it is recommended to put the Rotary Selection Switch on the USB
Resource Card to position “0”. The documentation will be updated with the extra pages to explain the H.264 setup in a reliably and fairly competent manner.
Position “0” on the HD video select, will give the camera the ability to auto-negotiate with the host PC and
automatically decide the highest resolution (MJPEG video up to and including 720p/30) that the computer and UC
client/application can accept, display and process within the application software (not provided). In the future the
Operating systems will be able to process 1080p/30 using H.264, USB 3.0 UVC (USB Video Class) drivers. But
for now MJPEG video at 720p/30 is the limit of USB 2.0.
The HD-USB camera uses UVC drivers and does not require the loading of any other drivers to run on the PC.
As long as the operating systems and soft-client software support UVC drivers, no additional software, other than
the application, is required.
COMPATIBILITY
The HD-USB Camera will work with the following web browsers, soft codecs,
computer operating systems and media players:
Compatibility - Web Browsers:
1) Internet Explorer (IE 8 and above)
2) Safari (Rev 4 and 5)
3) Safari/iOS (Rev 4 and 5)
4) Chrome (the latest and current release - auto updating)
5) FireFox (the latest and current release - auto updating)
Compatibility - Soft Codecs: HD-USB Camera is compatible with the following soft codecs or applications:
Release 1.2.0:
1) Skype
2) Microsoft Lync
3) Cisco Jabber
4) Polycom M100
5) Vidyo Desktop
6) Google Plus
7) Adobe Connect 8
8) LifeSize ClearSea
9) Web Ex (WBS 28.7 and above)
10) GoToMeeting (Citrix)
11) Panaopto (lecture capture)
3.4.3: Compatibility - Operating Systems
1) Apple OS X (10.7 and above)
2) Windows XP w/Service Pack 3 with known issues and errata
3) Windows 7
4) Linux
3.4.1: Compatibility - Media Players:
The UVC with MJPEG video shall be compatible with the industry leading PC media players.
1) Quick-Time
2) Real Player
3) VLC Media Player
Other Compatibilities:
As more UC soft-client and lecture capture programs are released and gain popularity, Vaddio will provide a
continuing research and development effort to ensure the camera’s viability and compatibility with other
manufacturer’s products.
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 8 of 32
ClearVIEW HD-USB Conferencing Camera
Internal Web Pages and Control:
The internal web pages will allow control of the HD-USB and allow the user to control the
camera via an internet connection. These web pages will allow the user or administrator to
set security passwords, change the IP address if not dynamic, view diagnostics, access the
firmware upgrade page and more.
To access the HD-USB’s web pages, first include your Network Administrator for the
network that the camera will be placed. Access to the internal web pages can be achieved
three ways for set-up of the HD-USB’s IP address and other administrative functions.
DHCP Set-up (Dynamic Host Configuration Protocol):
DHCP Set-up (skip this section if Static IP).
If the LAN has a DHCP (dynamic host configuration protocol) server,
then the IP address, gateway and routing information will
automatically be assigned. The HD-USB software is defaulted to
DHCP.
The HD-USB will attempt to dynamically obtain an IP address using
DHCP, but it will fall back to the default address of 169.254.1.1 if no
DHCP server can be found.
To display the HD-USB’s IP Address:
1) Plug in the camera and let it go through the boot up procedure.
The IP Address will be displayed at the top and middle of the
screen for 15 seconds and then automatically turns off.
To see the IP address for a longer than the 15 seconds at boot up, then…
2) Pick up the Vaddio IR Remote Commander and find the Data Screen button.
3) Press and hold the Data Screen button on the remote for 4 seconds.
4) The IP Address will appear on the display. The system is capable of
displaying and address up to 15 characters arranged in the format:
xxx.xxx.xxx.xxx. The default static IP address for the HD-USB camera is
169.254.1.1.
5) To turn off the IP Address display, press and hold the Data Screen button
for 4 more seconds or until the IP Address turns off.
Displaying the IP address for the network administrator is advantageous especially in
a network that is DHCP. It makes it easier to find the camera on the network and
assign addresses permanently within the DHCP protocol. Whatever protocols are
used, always have the network administrators available when attaching the Vaddio
HD-USB camera to the Ethernet network.
Notes:
The Data screen button is also used for the Camera’s on-screen display
where many of the camera’s parameters can be set. It is easy to tell the
difference between these modes as one quick touch enters the OSD for
the camera and a four second press and hold displays the web address
and turns off the web address display.
The IP Address will be displayed on screen out of the composite video,
analog component video (YPbPr) and the USB output. It will display at
the top, middle of the screen to ensure that older 4:3 displays can show
the address as well as the prevalent 16:9 monitors.
Connect to the Local Area
Network or to a computer
with a Cross-over cable
Data
Screen
Button
IP Address
Simulated IP Address On-Screen Display
169.254.1.1
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 9 of 32
ClearVIEW HD-USB Conferencing Camera
Static IP Set-up:
It is highly recommended that the Network Administrator and/or network personnel are involved
on the Static IP set-up of the HD-USB camera. Please do not try to set the Static IP of the
camera without help from network personnel…please?
The static IP can be assigned either through the network or directly to a computer using a cross-over cable.
Depending on the age of the computer, you may not need a cross-over cable. Either way the steps are the same
for network or direct connect to a computer.
The default address of the HD-USB camera is 169.254.1.1 and the Subnet mask is 255.255.0.0. Different
computer OS types all have their own way of doing things (without question), but they are essentially doing the
same stuff, changing the IP address so the web pages of the HD-USB are accessible.
Examples (directly connected to a computer for set-up):
For Windows XP Pro, the routine to get to the network settings is fairly simple. Click on the Start button > Control
Panels > Network Connections > Right Click Local Area Connection > click on Properties > click on Internet
Protocol (TCP/IP) > click on Properties and IP Address and Subnet Mask numbers are displayed. It is best to
record the addresses that are in the computer so they can be re-assigned when the operation is finished. Enter
169.254.1.2 (which is the default address 169.254.1.1 plus 1) and Subnet mask is 255.255.0.0 and click OK > and
then OK again. Bring up one of the approved web browsers (like Chrome) and enter http://169.254.1.1 and the
Log-in page will appear.
With Apple OS X (10.7 and above), the steps are a bit different but essentially the same…Go to > System
Preferences > Network > Ethernet > Configure IPv4: Manually > Enter in 169.254.1.2 and Subnet mask of
255.255.0.0 and click Apply. Bring up one of the approved web browsers (like Safari) and enter http://169.254.1.1
and the Log-in page will appear.
Windows 7 has its own set-up that is a bit different from Windows XP Pro, but similar in that the whole purpose of
the Static IP first time set up is to give the HD-USB PTZ Camera an address that can be used over and over
again by users or administrators to control the camera.
LOGIN Page:
The Login Page will appear if there
is a user name assigned by the
administrator.
Assigning a user name can limit
access to the admin menus by a
general user.
Initially, no user name is assigned
and the password is: password
If no user name is assigned, the
web page will automatically open to
the IP Control page.
User name is blank
(assigned by admin)
Password is: password
Admin name is: admin
Password is: password
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 10 of 32
ClearVIEW HD-USB Conferencing Camera
SCREEN SHOT TOUR:
IP Camera Control page with functions called out below.
1) Pan, Tilt and Home Controls: These intuitive controls use the up/down arrows for camera tilt, the left/right
arrows for camera pan and the center button to move the camera to the home position.
2) Zoom Control: The camera’s zoom lens can be controlled with the “+” to zoom-in and the “-“ button to zoom
out.
3) Pan/Tilt and Zoom Speed Controls: The speed for both the Pan/Tilt and Zoom controls can be sped up for
longer shots with the two (2) buttons in this section. For tighter shots, it is recommended that the slower
speed is used.
4) Store Preset Button: Clicking the Store button opens up a Store Preset pop-up dialog box. To set presets,
set up the camera shot, click on choice of preset number (1 through 6). The preset is stored and the dialog
box closes.
5) Camera Presets: Six (6) presets can be recalled simply by clicking a preset nu mber.
6) Administration Menu: Clicking on the Administration menu bar, the Admin Log-in screen will appear.
Default Admin password is: password.
7) Vertical: The vertical button will reduce the size of the window for the user controls and remove the menu
tabs on the left side of the screen. The vertical sizing works well when using it with a soft-client codec.
Examples of the vertical box are at the end of the tour.
➏
➊
➋
➌
➍
➎
Store Preset pop-up menu dramatization
➐
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 11 of 32
ClearVIEW HD-USB Conferencing Camera
Admin Pages:
(password) on this line and click on Log-in.
After Login, the Admin link buttons are exposed and include Streaming, Labels, Networking, Security,
Diagnostics, System, Help and Logout Admin.
Clicking on the Admin link button will open the Log-in window. Enter the default password
◄
Password is:
◄
password
◄
◄
◄
◄
◄
◄
◄
◄
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 12 of 32
ClearVIEW HD-USB Conferencing Camera
Room Labels: The room Labels menu allows the admin to label the company name, room name, room phone
and help phone on a per camera basis. The labels appear on every page at the top/middle of the page. Simply
enter the room information and click Save.
By clicking on the Networking link button, the Network Configuration and Network Interfaces are displayed. This
is where the Network administrator assigns either DHCP or a Static address and the associated parameters.
◄
◄
◄
◄
◄
◄
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 13 of 32
ClearVIEW HD-USB Conferencing Camera
If Static IP is chosen, a new menu pops up where the Admin is to input the IP address, Subnet Mask and
Gateway. Click on Save to keep the static IP information.
By clicking on the Security link button, the Update Password screen is displayed. The default user password is
blank and the User password is: password, and the user name is blank and ready to be set. The Admin
password is also: password. The Network administrator can reassign the user name and password as well as
the Admin password. There is only one User password and one Admin password at any given time.
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 14 of 32
◄
◄
◄
◄
◄
◄
◄
ClearVIEW HD-USB Conferencing Camera
By clicking the Diagnostics link button, a set of self-diagnostics will be displayed. These diagnostics may help
the Vaddio technical support team diagnose a problem with the HD-USB camera.
The System link button is where the Firmware Updates will be loaded. There will be several firmware updates
and upgrades over the life of the camera. Click “Show more…” for detail about the current software.
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 15 of 32
◄
◄
◄
ClearVIEW HD-USB Conferencing Camera
By clicking on “Show more…” the software versions are displayed. To update the firmware files, chose the
appropriate file and click on Begin Firmware Update. When in doubt, call Vaddio Tech Support for assistance.
After clicking on “Begin Firmware Update…” a confirmation pop-up and warning will be displayed. Please contact
Vaddio Tech support for directions or assistance. Please read and completely understand the pop-up warnings
as it is easy to lose patience waiting for updates. If the update is interrupted, it is never a good thing.
◄
◄
◄
◄
◄
◄
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 16 of 32
ClearVIEW HD-USB Conferencing Camera
After the firmware load has been started, a pop-up screen will advise patience and notify in terms of a percentage
completed, the progress of the firmware load. Please do not interrupt the firmware load.
Service/Help information can be found under the Help tab. Support phone numbers and e-mail, manuals, FAQ’s
and System information is listed on this page. Have this page open when calling Vaddio Tech Support.
◄
◄
TECHNICAL SUPPORT NOTE:
Please work with your Network Administrator prior to calling Vaddio for technical su pport. Please
have on site network personnel initiate tech support calls with Vaddio only.
◄
◄
◄
◄
◄
See next page
for “Vertical”
◄
button function.
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 17 of 32
ClearVIEW HD-USB Conferencing Camera
Finally, the Vertical button at the top right of the camera control page reduces the size of the camera control
window and drops the menu bars to allow the controls to be open and on screen along with any soft-codec
application without taking up too much space. This control page can be sized with the mouse, moved around the
screen and minimized to not block any part of the screen. The Full button returns the web page to normal size.
Click on full to go
back to full sized
◄
web pages
Diagram: Basic Connectivity Example 1:
HD-USB Camera and a Soft-client videoconferencing system (audio is not included in this example).
HD-USB
Conferencing
Camera
USB 2.0
Port
USB 2.0 Video
using only UVC
Drivers
USB 2.0
Port
PC with Host Application
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 18 of 32
ClearVIEW HD-USB Conferencing Camera
Diagram: Connectivity Example 2:
This example uses the HD-USB PTZ Camera and Vaddio’s EasyTalk™ USB Mixer/Amp, two (2) Echo Cancelling
EasyMic™ MicPODs and Two (2) Bose Ceiling Speakers to create a complete room system using programs such
as Skype®, Jabber®, Google+®, Microsoft Lync® and others, with USB 2.0 Video and Acoustic Echo Cancelled
(AEC) Audio.
PC Video Monitor - HD
Large Screen Format
Bose FS-16F Ceiling Speakers
Optimized for Voice
ClearVIEW HD-USB
Conferencing
Camera
USB 2.0 Cable
USB 2.0 Video using
USB Video Class
(UVC) Drivers
PC HD
Video
USB 2.0 Cable
USB 2.0 Audio using
USB Audio Class
(UAC) Drivers
8 Ohm
Speaker
Cable
EasyUSB™
Mixer/AMP
Cat-5e
Cable
8 Ohm
Speaker
Cable
Cat-5e
Cable
Tower PC with Host
Application
Two (2) EasyMic MicPODs with
three (3) integrated mic elements
and three (3) Acoustic Echo
Cancellers per mic
Diagram: H.264 Streaming Connectivity (for Release 2.0 when IP Streaming is enabled):
The HD-USB Camera has a Unicast streaming output suitable for up to six (6) concurrent users (at lower
resolutions). This configuration shows four (4) concurrent users.
H.264 STREAMING
VIDEO
Network
LAN/WAN
Internet
HD-USB PTZ CAMERA
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 19 of 32
ClearVIEW HD-USB Conferencing Camera
Diagram: Connection Diagram Example using A CDN (for release 2.0 when IP is enabled):
For a Large Number of Viewers - Use a CDN Content Distribution Network such as Wowza, Amazon or iCloud
and more…
CONNECTING THE CAMERA TO THE PROGRAM OF CHOICE:
The HD-USB PTZ Camera is compatible with many programs and media players. The following is an attempt to
generally describe the steps to plug in the HD-USB camera and get an image.
Skype Example:
1) First, with a quality USB 2.0 cable, plug the USB-B port of the camera to the
USB-A port of the computer. A pop up window on the computer monitor will
display the following:
a. Found ClearVIEW HD-USB
b. Found USB Composite Device
c. Found USB Video Device
2) Open Skype and perform the following steps:
a. Open the Tools Menu and drop down to Options
b. Click on Video Settings and under Webcam choose USB Video Device
The systems will negotiate the highest resolutions possible, depending on the computer speed, network quality,
cabling etc..., and display the video signal of the camera. The camera can be controlled with the supplied Vaddio
IR Remote Commander or through IP as described earlier through the cameras web pages. Make a test call to
ensure the system is working properly.
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 20 of 32
ClearVIEW HD-USB Conferencing Camera
VLC Media Player Example:
1) Same first step as above.
2) Open VLC Media Player and perform the following steps:
a. Click on the Media menu and drop down to Open Capture Device and click it.
b. Under Device Name, go to the Video Device Name drop down and choose USB Video Device.
c. Under Options, enter the Video Size as 1280x720
d. Click on Play
e. From there, VLC needs some instruction on the aspect ratio, so click on Tools and drop down to
Aspect Ratio and drop down again to 16:9 for 720p (1280x720).
VLC is a powerful record/playback system and buffers the images so you will notice some delay in the way VLC
displays the image.
In General Terms…
With all the compatible software available, in general terms, the video device, aspect ratio, and resolution may
need to be set manually the first time through initial set-up. Some systems are easier than others (like Skype)
and others are more technical in nature and tend to do more stuff.
TECHNICAL SPECIFICATIONS:
Part Numbers 999-6990-000 North America, 999-6990-001 International
Video Outputs
USB Interface Connector: Type-B, USB 2.0 Compliant, Supported Drivers: Standard UVC device (no custom drivers)
Network Interface Connector: RJ-45, 10/100 Base-T, Supported Protocols: RTSP Streaming, HLS Streaming (apple’s variant
H.264 Resolutions
(Release 2.0.0)
User Control Vaddio IR Remote Commander, On Screen Display for camera set-up, RS-232, Ethernet (web page)
Supported Media Players Apple Quick-Time, VLC Media Player and Reel Player
Supported Browsers Internet Explorer 8 & 9, Safari 4 &5, Safari/iOS, Chrome, Firefox
Image Sensor 1/3-Type Exmor High-speed,
Minimum Illumination 0.7 LUX (F1.6, 50IRE)
Lens/ Focal Length 19X Optical Zoom, F=4.5mm wide to 85mm tele (F1.6-F2.9),
Horizontal Viewing Angle 58.1° Wide End to 3.2°
Pan Range Pan: +170 degrees to -170 degrees, Tilt:
Preset Positions 16 (internal), 6 recalled via IR Remote
General Information
Operating Temperature 32° to 104° F (0° to 40° C) / 20% to 80% Relative Humidity
Dimensions / Weight 7.81” (198.37mm) H x 6.67” (169.42mm) W x 7.057” (179.25. mm) D / 6.04 lbs. (2.7397kg.)
Software Release
Information
USB 2.0 (MJPEG)
o Resolution up to 720p/30 USB 2.0 (MJPEG)
o Use “HD VIDEO AND USB 2.0 VIDEO SELECT” rotary positions 0, 1, 4 & 5 for USB.2.0 Video
only
H.264 (IP) - Release 2.0
o Resolution up to 1080p/30 (H.264 over IP & USB 2.0 - Release 2.0)
Analog Component (YPbPr),
o Analog resolutions up to and including 1080p/60 (YPbPr)
CVBS - Analog only
o 480i and 576i (4:3, LB and SQ)
of HTTP streaming) - Release 2
CIF, 640x480 (VGA), 576p, 720p/30 1080p/30 (1080p Ethernet H.264 only)
Progressive Scan CMOS Sensor with 1.3 Megapixels
Min. Focus Distance 1.0m
Tele End - 16:9 Format
+90 degrees to -30 degrees,
Invertible for Ceiling Mount
Release 1.0.0: Includes USB 2.0 Outputs and Analog Outputs simultaneously on and ready to use. Ethernet
control via an internal web page and upgrading software capability is active.
Release 1.2.0: Improvements, additions to functionality, Telnet control, UC client compatibility and UVC
resolutions.
Future Release 2.0.0: H.264 Streaming will be activated for Ethernet port.
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 21 of 32
ClearVIEW HD-USB Conferencing Camera
COMPLIANCE AND CE DECLARATION OF CONFORMITY: CLEARVIEW HD-USB PTZ CAMERA
Compliance testing was performed to the following regulations:
FCC Part15, Sections 15.107, 15.109 Subpart B Class A
ICES-003 ISSUE 4, 2004 Class A
EN55022 A1 2007 Class A
EMC Directive 2004/108/EC Class A
IEC 60950-1:2005 (2nd Edition); Am 1:2009 Class A
EN 60950-1:2006+A11:2009+A1:2010+A12:2011 Class A
FCC Part 15 Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part
15, Subpart B, of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his/her own
expense.
Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This
device must accept any interference including interference that may cause undesired operation of the device.
Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void
the user’s authority to operate this equipment.
ICES-003 Compliance
ICES-003, Issue 4: 2004
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out
in the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’emet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numeriques de la classe B préscrites dans le Règlement sur le brouillage radioélectrique édicte par le
ministère des Communications du Canada.
European Compliance
This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions a nd
Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate measures.
Standard(s) To Which Conformity Is Declared:
EMC Directive 2004/108/EC
EN55024/A2:2003 Information Technology Equipment
Immunity Characteristics Limits and Methods of Measurement
EN 61000-4-2: 1995 + Amendments A1: 1998 + A2: 2001 Electrostatic Discharge
EN 61000-4-3: 2006 + A1: 2008 Radiated Immunity
EN 61000-4-4: 2004 + Corrigendum 2006 Electrical Fast Transients
EN 61000-4-5: 2006 Surge Immunity
EN 61000-4-6: 2009 Conducted Immunity
EN 61000-4-8: 2010 Power Frequency Magnetic Field
EN 61000-4-11: Second Edition: 2004 Voltage Dips, Interrupts and Fluctuations
IEC 60950-1:2005 (2nd Edition); Am 1:2009 Information technology equipment - Safety
EN 60950-1:2006+A11:2009+A1:2010+A12:2011 Information technology equipment - Safety
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 22 of 32
ClearVIEW HD-USB Conferencing Camera
WARRANTY INFORMATION: (See Vaddio Warranty, Service and Return Policies posted on vaddio.com for complete details):
Hardware* Warranty: T wo (2) year limited warranty on all parts and labor for Vaddio manufactured products. Vaddio
warrants its manufactured products against defects in materials and workmanship for a period of two years from the
day of purchase, to the original purchaser, if Vaddio receives notice of such defects during the warranty. Vaddio, at its
option, will repair or replace products that prove to be defective. Vaddio manufactures its hardware products from parts
and components that are new or equivalent to new in accordance with industry standard practices.
Exclusions: The above warranty shall not apply to defects resulting from improper or inadequate maintenance by the
customer, customers applied software or interfacing, unauthorized modifications or misuse, mishandling, operation
outside the normal environmental specifications for the product, use of the incorrect power supply, modified power
supply or improper site operation and maintenance. OEM products and products manufactured by other companies
are excluded and are covered by the manufacturer’s warranty.
Vaddio Customer Service: Vaddio will test, repair, or replace the product or products without charge if the unit is
under warranty. If the product is out of warranty, Vaddio will test then repair the product or products. The cost of parts
and labor charge will be estimated by a technician and confirmed by the customer prior to repair. All components must
be returned for testing as a complete unit. Vaddio will not accept responsibility for shipment after it has left the
premises.
Vaddio Technical Support: Vaddio technicians will determine and discuss with the customer the criteria for repair
costs and/or replacement. Vaddio Technical Support can be contacted through one of the following resources: e-mail
support at support@vaddio.com or online at vaddio.com.
Return Material Authorization (RMA) Number: Before returning a product for repair or replacement request an RMA
from Vaddio’s technical support. Provide the technician with a return phone number, e-mail address, shipping address,
product serial numbers and original purchase order number. Describe the reason for repairs or returns as well as the
date of purchase. See the General RMA Terms and Procedures section for more information. RMA’s are valid for 30
days and will be issued to Vaddio dealers only. End users must return products through Vaddio dealers. Include the
assigned RMA number in all correspondence with Vaddio. Write the assigned RMA number clearly on the shipping
label of the box when returning the product. All products returned for credit are subject to a restocking charge without
exception.
Voided Warranty: The warranty does not apply if the original serial number has been removed or if the product has
been disassembled or damaged through misuse, accident, modifications, use of incorrect power supply, use of a
modified power supply or unauthorized repair.
Shipping and Handling: Vaddio will not pay for inbound shipping transportation or insurance charges or accept any
responsibility for laws and ordinances from inbound transit. Vaddio will pay for outbound shipping, transportation, and
insurance charges for all items under warranty but will not assume responsibility for loss and/or damage by the
outbound freight carrier. If the return shipment appears damaged, retain the original boxes and packing material for
inspection by the carrier. Contact your carrier immediately.
Products not under Warranty: Payment arrangements are required before outbound shipment for all out of warranty
products.
*Vaddio manufactures its hardware products from parts and components that are new or equivalent to new in accordance with industry standard practices.
Other General Information:
Care and Cleaning
Do not attempt to take this product apart at any time. There are no user-serviceable components inside.
Do not spill liquids in the product
Keep this device away from food and liquid, especially caviar.
For smears or smudges on the product, wipe with a clean, soft cloth
Use a lens cleaner on the lens
Do not use any abrasive chemicals.
Operating and Storage Conditions:
Do not store or operate the device under the following conditions:
Temperatures above 40°C (104°F) or temperatures below 0°C (32°F)
High humidity, condensing or wet environments
In Swimming Pools and behind unused lawn furniture
In inclement weather
Dry environments with an excess of static discharge
In a Chemical Tanker or Milk delivery truck
Under severe vibration
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 23 of 32
ClearVIEW HD-USB Conferencing Camera
APPENDIX 1: RS-232 COMMUNICATION SPECIFICATION
Communication Speed: 9600 bps (default)
Start bit: 1
Stop bit: 1
Data bits: 8
Parity: None
No Flow control
12345678
NOTE: The Vaddio ClearVIEW HD-USB Control Protocol is similar, but not identical to the Sony® VISCA™ command set and is not
compatible with Vaddio Joysticks. This is an abbreviated Command set intended to give external control systems basic control over the
camera. This list is not the same list as found in the other ClearVIEW (HD-18, HD-19, HD-20 and HD-22) cameras.
HD-USB Command List
Command Set Command Command Packet Comments
Address Set Broadcast 88 30 01 FF Address Set (Daisy chain)
IF_Clear Broadcast 88 01 00 01 FF IF Clear
Command Cancel 8x 2p FF p:socket number(1,2)
CAM_Power On
Off(Standby)
CAM_Zoom Stop
Tele(Standard)
Wide(Standard)
Tele(Variable)
Wide(Variable)
Direct
Direct(Variable)
CAM_Focus Stop
Far(Standard)
Near(Standard)
Far(Variable)
Near(Variable)
AutoFocus
ManualFocus
Auto/Manual
Direct
CAM_Backlight On
Off
CAM_Memory Reset
Set
Recall
Pan-tiltDrive Up
Down
Left
Right
UpLeft
UpRight
DownLeft
DownRight
Stop
Absolute Position
Home
Reset
Tally On
Off
Preset Pan Speed Pan/Tilt/Zoom Speed 81 01 7E 01 0B WW SS ZZ FF WW: Pan Speed (0x01-0x18)
*Zoom and Focus Data:
CAM_Zoom: Range(0x000–0x6B3)
CAM_Focus: Range (0x000-0xC000) dependent on Zoom Position
**Additional Information:
Pan Range: 8044 – 7FBC (-32,700 to +32,700)
Tilt Range: E891 – 4C2B (-5,999 to +19,499)
8x 01 04 00 02 FF
8x 01 04 00 03 FF
8x 01 04 07 00 FF
8x 01 04 07 02 FF
8x 01 04 07 03 FF
8x 01 04 07 2p FF
8x 01 04 07 3p FF
8x 01 04 47 0p 0q 0r 0s FF
8x 01 7E 01 4A 0v 0p 0q 0r 0s FF
8x 01 04 08 00 FF
8x 01 04 08 02 FF
8x 01 04 08 03 FF
8x 01 04 08 2p FF
8x 01 04 08 3p FF
8x 01 04 38 02 FF
8x 01 04 38 03 FF
8x 01 04 38 10 FF
8x 01 04 48 0p 0q 0r 0s FF
8x 01 04 33 02 FF
8x 01 04 33 03 FF
8x 01 04 3F 00 0p FF
8x 01 04 3F 01 0p FF
8x01 04 3F 02 0p FF
8x 01 06 01 VV WW 03 01 FF
8x 01 06 01 VV WW 03 02 FF
8x 01 06 01 VV WW 01 03 FF
8x 01 06 01 VV WW 02 03 FF
8x 01 06 01 VV WW 01 01 FF
8x 01 06 01 VV WW 02 01 FF
8x 01 06 01 VV WW 01 02 FF
8x 01 06 01 VV WW 02 02 FF
8x 01 06 01 VV WW 03 03 FF
81 01 06 02 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF
8x 01 06 04 FF
81 01 06 05 FF
8x 01 7E 01 0A 00 02 FF
8x 01 7E 01 0A 00 03 FF
Pin # RJ-45 RS-232 and IR Out Pins
1) Unused
2) Unused
3) Unused
4) Unused
5) Unused
6) GND (GND of IR Short Range - Pin 3)
7) RXD (from TXD of control source)
8) TXD (to RXD of control source)
Power On/Off
pqrs: Zoom Position*
v:(Speed) 0-7
pqrs: Focus position*
p:Memory No(=0-0xe)
WW: Pan Speed (0x01-0x18)
VV:Tilt Speed(0x01-0x14)
YYYY: Pan Position**
ZZZZ: Tilt Position**
SS:Tilt Speed(0x01-0x14)
ZZ:Zoom Speed(0-7);
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 24 of 32
ClearVIEW HD-USB Conferencing Camera
HD-USB Inquiry List
Inquiry Command Command Response Packet Comments
CAM_PowerInq 8x 09 04 00 FF y0 50 02 FF
CAM_ZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqr: 0-0x6B3
CAM_FocusPosInq 8x 09 04 48 FF y0 50 0p 0q 0r 0s FF pqrs: Focus Position
CAM_BacklightModeInq 8x 09 04 33 FF y0 50 02 FF
CAM_MemoryInq 8x 09 04 3F FF y0 50 0p FF p:Preset 0-0xf
Pan-TiltMaxSpeedInq 8x 09 06 11 FF y0 50 pp qq FF pp:Pan 0x01-0x18
Pan-tiltPositionInq 8x 09 06 12 FF FF y0 50 0p 0p 0p 0p 0q 0q 0q 0q FF pppp: Pan 0x8044-0x7FB2
TallyInq 8x 09 7E 01 0A FF y0 50 02 FF
PresetSpeedInq 8x 09 7E 01 0B FF y0 50 pp qq rr FF pp:Pan 0x01-0x18
Motor Config 8x 09 7E 01 70 FF y0 50 00 FF
Firmware Version 1.2.0 Release Notes:
ClearVIEW HD-USB PTZ Camera
Component
Database
Middleware
Version
1.2.0
1.2.0
New Features and Functions:
WebEx Compatibility: The video compatibility problem between HD-USB and WebEx has been resolved with a new
software release of the WebEx client. Version WBS 28.7 and above is compatible with Vaddio USB devices.
Improved Interoperability with Various UC software Clients: Additional USB video resolution support has been
added to the UVC endpoint to improve video quality for some UC soft clients that only use standard definition video
resolution.
Keyboard Hotkeys for PTZ functions: Keyboard hot keys have been added for the Pan/Tilt/Zoom functions on the
Camera Control Web Page.
Function Hot Key Function Hot Key
Zoom IN + (plus) Tilt Up & Pan Right Num. Pad Key 9, PgUp
Zoom OUT - (minus) Tilt Down & Pan Right Num. Pad Key 3, PgDn
Tilt Up Num. Pad Key 8, Up Arrow Tilt Up & Pan Left Num. Pad Key 1, End
Tilt Down Num. Pad Key 2, Down Arrow Tilt Down & Pan Left Num. Pad Key 7, Home
Pan Right Num. Pad Key 6, Right Arrow
Pan Left Num. Pad Key 4, Left Arrow
Notes: Shift key not required for + and - keys on number row. Caps Lock can be ON or
OFF. Num Lock must be off to use the Numeric Keypad for pan and tilt.
USB Color Space Option: A user configurable option for setting the video color space to 4:2:0 or 4:2:2 has been
added to the Web Pages.
NOTE: Using the 4:2:0 color space will reduce USB bandwidth by up to 25.763413121% and may improve
video quality with some UC soft clients.
Firmware Update Function: The firmware update process has been modified allowing all internal components to be
updated via the Web Pages.
Telnet Command API: A Telnet Client to the HD-USB Camera was added for control via the network. This includes
the Pan/Tilt/Zoom function. The telnet format is not a VISCA command protocol. VISCA command protocol is only
supported on RS-232 port.
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 25 of 32
y0 50 03 FF
y0 50 03 FF
y0 50 03 FF
y0 50 01 FF
On
Off(Standby)
On
Off
qq:Tilt 0x01-0x14
qqqq: Tilt 0xE890-0x4C2C
On
Off
qq:Tilt 0x01-0x14
rr:Zoom 0x00-0x07
Hard Motor Stops
Soft Motor Stops
ClearVIEW HD-USB Conferencing Camera
Table: Supported UVC Resolutions
Format Resolution Frame Rate Aspect Ratio
MJPEG 1280 x 720 15/30 16:9
960 x 544 15/30 16:9
704 x 576 15/30 4:3
640 x 480 15/30 4:3
640 x 360 15/30 16:9
424 x 240 15/30 4:3
352 x 240 15/30 4:3
320 x 240 15/30 4:3
320 x 180 15/30 16:9
YUY2 640 x 480 10 4:3
640 x 360 10 16:9
424 x 240 15/30 4:3
352 x 240 15/30 4:3
320 x 240 15/30 4:3
320 x 180 15/30 16:9
Note: 160 x 120 and 160 x 90 were removed due to the selection of the lowest resolution by some UC Clients.
Table: Interoperability Testing & Findings
The following interoperability testing was performed for this release. A detailed list of all interoperability findings
can be found in the EasyUSB Tools Interoperability FAQ document.
Table: HD-USB Camera UC Client Interoperability Testing
Software Client Operating System Issues
Cisco Jabber Win 7 & Mac OS X None
Skype Win 7 & Mac OS X None
Adobe Connect 8 Win 7 & Mac OS X Potential UVC conflict with two generic video
cameras connected to PC (i.e. Laptop PC with
built-in webcam).
Microsoft Lync Win 7 None
Vidyo Desktop Win 7 & Mac OS X None
Polycom M100 Win 7 None
LifeSize ClearSea Win 7 None
Google Plus Win 7 None
Gotomeeting (Citrix) Win 7 & Mac OS X None
WebEx (WBS28.7) Win 7 & Mac OS X Must use WebEx WBS 28.7 and above for
compatibility.
Encore by AGT Win 7 Pending - Compatible when MJPEG implemented
Panopto Win 7 None
Note: Windows XP PRO w/Service Pack 3 will work with some of the software clients, however support for
applications using XP PRO is dwindling. XP will work, but with known issues and errata.
Backward Compatibility: The camera cannot be downgraded to a lower revision once 1.2.0 is loaded.
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 26 of 32
ClearVIEW HD-USB Conferencing Camera
A
PPENDIX 2 - TELNET SERIAL COMMAND
API
The Vaddio Serial Command protocol is a high level text based command line interface supported via telnet
session on the ClearVIEW HD-USB PTZ Camera. The Vaddio Serial Command protocol is not supported on the
RS-232 port. The RS-232 port is dedicated for VISCA commands only. The command application protocol
interface is intended to allow external device such as AMX and Crestron to control the camera. The protocol is
based upon ASCII format following the VT100 terminal emulation standard and uses an intuitive textual
command nomenclature for ease of use. The API is accessed by a telnet client on the Ethernet port. All ASCII
characters will be echoed to terminal program and appended with VT100 string -ESC[J (HEX- 1B 5B 4A).
Vaddio Command lines are terminated on carriage return. After the carriage return, the VT100 appends with –
ESC[J. (Note: Most terminal programs automatically strip the VT100 string.) General format usage follows a
get/set structure. Usage examples for each type are:
Set Example
COMMAND: > camera pan right
RESPONSE: > OK
Get Example
COMMAND: > stream mode get
RESPONSE: > streaming mode usb
Syntax Error Example
COMMAND: > camra pan right
RESPONSE: > ERROR
Additional programming controls associated with the terminal protocol includes:
CTRL 5 - Clears the current serial buffer on the device.
Telnet sessions will require access verification and uses the same username and password associated with the
Administrator account on the embedded web server. The default Telnet Port is 23. Command lines are
terminated with carriage return.
Telnet Command List
CameraHome
NAME
camera home - Move the camera to the home position
SYNOPSIS
camera home
DESCRIPTION
Method used to move the camera to the home position
EXAMPLES
camera home
Move the camera back to the home position
CameraPan
NAME
camera pan - Pans the camera left or right
SYNOPSIS
camera pan {left|right|stop} [1-24]
DESCRIPTION
Method used to pan the camera
OPTIONS
left Move the camera left
right Move the camera right
stop Stop the camera movement
speed Optional integer from 1-24 that represents the speed (Default: 12)
EXAMPLES
camera pan left
Pans the camera left at the default speed
camera pan right 20
Pans the camera right using a speed of 20
camera tilt stop
Stops the pan movement of the camera
Image: Riveting example of simulated Telnet session
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 27 of 32
ClearVIEW HD-USB Conferencing Camera
CameraPreset
NAME
camera preset - Recall and set camera presets
SYNOPSIS
camera preset {recall|store} [1-6]
DESCRIPTION
Method used to recall and store camera presets
OPTIONS
recall Recall preset
store Store preset
preset Required value from 1-6 used to indicate the preset number
EXAMPLES
camera recall 3
Move camera to preset position 3
camera store 1
Store current camera position as preset 1
CameraTilt
NAME
camera tilt - Tilts the camera up or down
SYNOPSIS
camera tilt {up|down|stop} [1-20]
DESCRIPTION
Method used to tilt the camera
OPTIONS
up Move the camera up
down Move the camera down
stop Stop the camera movement
speed Optional integer from 1-20 that represents the speed (Default: 10)
EXAMPLES
camera tilt up
Tilts the camera up at the default speed
camera tilt down 20
Tilts the camera up using a speed of 20
camera tilt stop
Stops the tilt movement of the camera
CameraZoom
NAME
camera zoom - Zoom the camera in or out
SYNOPSIS
camera zoom {in|out|stop} [1-7]
DESCRIPTION
Method used to zoom the camera
OPTIONS
in Zoom in
out Zoom out
stop Stop the camera movement
speed Optional integer from 1-7 that represents the speed (Default: 3)
EXAMPLES
camera zoom in
Zooms the camera in at the default speed
camera zoom out 7
Zooms the camera out using a speed of 7
camera zoom stop
Stops the zoom movement of the camera
Camera
NAME
camera - Base command used to access camera control functionality
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 28 of 32
ClearVIEW HD-USB Conferencing Camera
Exit
NAME
exit - ends the current API command session
SYNOPSIS
exit
DESCRIPTION
Exit ends the current API command session. If the session i s over telnet, the session is ended and the s ocket is closed. If the
session is over serial, a new session is started.
Help
NAME
help - display an overview of the CLI syntax
SYNOPSIS
help
DESCRIPTION
Display an overview of the command line syntax
History
NAME
history - command history
SYNOPSIS
history [limit]
DESCRIPTION
Since many of the programs read user input a line at a time, the c ommand history is used to keep track of these lines and
also recall historic information
HISTORY NAVIGATION
The command history can be navigated us ing the up and down arrow keys. The up arrow will move up a single entr y in the
command history while the down arrow moves down in the command history.
HISTORY EXPANSION
The command history supports the expan sion functionality from which previous commands can be recalled from within a
single session. History expansion is performed immediately after a complete line is read.
Listed below are examples of history expansion:
* !! Substitute the last command line.
* !N Substitute the Nth command line (absolute as per ’history’ command)
* !-N Substitute the command line entered N lines before (relative)
EXAMPLES
history
Displays the current command buffer
history 5
Sets the history command buffer to remember the last 5 unique entries
NetworkPing
NAME
network ping - send ICMP ECHO_REQUEST to network hosts
SYNOPSIS
network ping [count <count>] [size <size>] <destination-ip>
DESCRIPTION
Use the ICMP protocol’s mandatory ECHO_REQUEST datagram to elicit an ICMP ECHO_RESPONSE
from a host or gateway. ECHO_REQUEST datagrams have an IP and ICMP header, followed by a struct
timeval and then an arbitrary number of pad bytes used to fill out the packet.
OPTIONS
count Stop after sending count ECHO_REQUEST packets. With deadline option, ping waits for count
ECHO_REPLY packets, until the timeout expires. The default is 5.
destination
The destination IP address where the ECHO_REQUESTS are sent
size The data size of the ICMP packet to send. The default is 56 bytes
EXAMPLES
network ping 192.168.1.1
Attempt to send 5 ICMP ECHO_REQUESTs with data size 56 to the host at 192.168.1.1
network ping count 10 size 100 192.168.1.1
Attempt to send 10 ICMP ECHO_REQUESTs with data size of 100 to the host at 192.168.1.1
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 29 of 32
ClearVIEW HD-USB Conferencing Camera
NetworkSettings
NAME
network settings - get current network settings
SYNOPSIS
network settings {get}
DESCRIPTION
Method used to get the current network settings of the device
OPTIONS
get Get the current network settings for the machine
EXAMPLES
network settings get
MAC Address:
00:04:a3:85:0a:ee
IP Address:
10.10.8.116
Netmask:
255.255.255.0
Gateway:
10.10.8.100
Returns the current network settings for mac addres, ip address, netmask, and gateway
Network
NAME
network - Gets the current network settings or pings an IP address
SYNOPSIS
network {settings get | ping [count <count>] [size <size>] <destination-ip>}
DESCRIPTION
Method used to get the current network settings or check network
OPTIONS
settings
Get the current network settings
ping Send ICMP ECHO_REQUEST to network host
EXAMPLES
network settings get
Gets the current network settings
----
network ping count 1 10.10.10.100
Pings 10.10.10.100 once and displays results
Serial
NAME
serial - Sets or gets the current serial settings
SYNOPSIS
serial {get|9600|19200|38400}
DESCRIPTION
The serial command is used to get or set the serial baud rate
OPTIONS
get Returns the serial speed
9600 Sets the serial baud rate to 9600
19200 Sets the serial baud rate to 19200
38400 Sets the serial baud rate to 38400
EXAMPLES
serial get
Gets the current serial baud rate
serial 38400
Sets the external serial baud rate to 38400
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 30 of 32
ClearVIEW HD-USB Conferencing Camera
StreamingMode
NAME
streaming mode - Gets or sets the current streaming mode
SYNOPSIS
streaming mode {get|usb}
DESCRIPTION
Method used to get or set the current streaming settings
OPTIONS
get Get the current streaming mode
Set the current streaming mode to USB
EXAMPLES
streaming mode get
mode: usb
Returns the current streaming mode ----
streaming mode usb
SystemFactory‐Reset
NAME
system factory-reset - Gets or sets factory reset status
SYNOPSIS
system factory-reset {get|on|off}
DESCRIPTION
Method used to get or set the factory reset status
OPTIONS
get Get the current factory reset status
on Enable factory reset on reboot
off Disable factory reset on reboot
EXAMPLES
system factory-reset get
factory-reset (software):
off
factory-reset (hardware): [Hardware reset is designated by rear panel dip switches in down position]
off
Returns the factory reset status
----
system factory-reset on
factory-reset (software): on
factory-reset (hardware): off
Enables factory reset upon reboot
SystemReboot
NAME
system reboot - Reboots system
SYNOPSIS
system reboot [<seconds>]
DESCRIPTION
Method used to reboot system
OPTIONS
seconds
The number of seconds to delay the reboot
EXAMPLES
reboot
Reboot system immediately
reboot 30
Reboot the system in 30 seconds
Version
NAME
version - display the system version information
SYNOPSIS
version
DESCRIPTION
Display an overview of the command line syntax
EXAMPLES
Version
Returns the current software version
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 31 of 32
ClearVIEW HD-USB Conferencing Camera
©2012 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing are subject
to change without notice. Vaddio, ClearVIEW, EZCamera, EasyTalk, EasyMic, EasyUSB and PowerRite are trademarks of Vaddio. All other
trademarks are property of their respective owners. Document 342-0437 Rev. B
ClearVIEW HD-USB PTZ Conferencing Camera Document Number 342-0437 Rev. B Page 32 of 32
Toll Free: 800-572-2011 ▪ Phone: 763-971-4400 ▪ FAX: 763-971-4464
9433 Science Center Drive, Minneapolis, MN 55428
www.vaddio.com
Loading...
