VADDIO™ ONELINK™ FOR ROBOSHOT™ HDMI CAMERAS
Video, Power, Network and Control Extension System over a Single Cat-5e/6 Cable at
distances up to 328’ (100m) featuring HDBaseT™ Technology.
Part Numbers
999-9590-000: OneLINK System for Vaddio RoboSHOT HDMI Cameras (North America)
999-9590-001: OneLINK System for Vaddio RoboSHOT HDMI Cameras (International)
(RoboSHOT HDMI Cameras are sold separately)
OneLINK HDMI Camera Interface
OneLINK HDMI EZIM™ Camera Interface (camera end)
RoboSHOT HDMI Cameras
Sold Separately
© 2015 Vaddio - All Rights Reserved. OneLINK Systems - Document Number 342-1050
OneLINK For RoboSHOT HDMI Cameras
TABLE OF CONTENTS
Overview: ................................................................................................................................................................... 3
Unpacking: .......................................................................................................................................................... 4
Image: OneLINK HDMI Interface with Front Panel Feature Call-outs .............................................................. 4
Image: OneLINK HDMI Interface with Rear Panel Connector Call-outs ........................................................... 5
Image: OneLINK EZIM Camera Interface with Connector Call-outs ................................................................. 5
Camera and EZIM Mounting Instructions .................................................................................................................. 6
Determine Camera Mount Location ....................................................................................................................... 6
Drawing: RoboSHOT HDMI Mount with EZIM Attached ............................................................................. 6
Basic System Configuration: ..................................................................................................................................... 7
Installation .............................................................................................................................................................. 7
Diagram: Basic Connectivity of the OneLINK System ...................................................................................... 7
OneLINK Display ................................................................................................................................................ 8
The OneLINK Screen Shot Tour ............................................................................................................................... 8
DHCP IP Set-up (Dynamic Host Configuration Protocol) ...................................................................................... 8
Static IP Set-up: ..................................................................................................................................................... 8
Screen Shot: Home Page .................................................................................................................................. 8
Screen Shot: Login ............................................................................................................................................ 9
Screen Shot: Room Labels ............................................................................................................................... 9
Screen Shot: Networking (DHCP) ................................................................................................................... 10
Screen SHOT: Networking (Static IP Configuration) ....................................................................................... 10
Screen SHOT: Security ................................................................................................................................... 11
Screen SHOT: Security ................................................................................................................................... 11
Screen Shot: Diagnostics ................................................................................................................................ 12
Screen Shot - Admin Menu - Help .................................................................................................................... 12
Screen Shot: System Menu ............................................................................................................................. 13
Screen Shot: System Menu - Firmware Update Confirmation ........................................................................ 13
Screen Shot: System Menu - Restore Factory Settings Confirmation ............................................................ 14
General Specifications ............................................................................................................................................. 15
Appendix 1: Connectors and signals ...................................................................................................................... 15
Compliance and CE Declaration of Conformity - OneLINK HDMI Interface ........................................................... 16
Compliance and CE Declaration of Conformity - OneLINK HDMI EZIM ................................................................. 17
Warranty Information ............................................................................................................................................... 18
OneLINK For RoboSHOT HDMI Cameras Page 2 of 20
OneLINK For RoboSHOT HDMI Cameras
O
VERVIEW
:
Vaddio’s OneLINK System is a digital camera
extension system that extends HDMI video, power
network and control on a single Cat-5e/6 cable at
distances of up to 328’ (100m). The OneLINK
system sends and regulates power to the camera,
provides a bi-directional control channel for Ethernet
and transmits/receives uncompressed HDMI digital
video up to 1080p/60.
Images: OneLINK HDMI Interface
(above) and the OneLINK EZIM
Camera Interface (right),
The system consists of the small OneLINK EZIM (EZCamera™ Interface Module) camera interface at the camera
location and the OneLINK HDMI Interface. The EZIM provides the required camera connectivity and is mounted t o
the underside of the RoboSHOT HDMI camera’s Thin Profile Wall Mount with two 6-32 x .188” black mounting
screws. All the 12” (305mm) patch cables on the camera end are provided with the OneLINK system including an
HDMI cable, a power cable and two Cat-5e patch cables for network and RS-232. The Thin Profile Wall Mount can
be mounted directly to a 2-gang sized electrical box for conduit or directly to the dry wall with wall anchors.
From one end to the other, the OneLINK system provides system integrators and end users a simplified product
based on the vast experience Vaddio has in cameras and cable extension systems.
Please use this manual in conjunction with the manual for the camera attached to the OneLINK System.
Intended Use
Before operating the device, please read the entire manual thoroughly. The system was designed, built and
tested for use indoors, and with the provided power supply and cabling. The use of a power supply other than the
one provided or outdoor operation has not been tested and could damage the device and/or create a potentially
unsafe operating condition.
Save These Instructions
The information contained in this manual will help you install and operate your product. If these instructions are
misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product
drawings for the Vaddio product line on the Vaddio website. These documents can be downloaded from
www.vaddio.com free of charge.
Important Safeguards
Read and understand all instructions before using. Do not operate any device if it has been dropped or damaged.
In this case, a Vaddio technician must examine the product before operating. To reduce the risk of electric shock,
do not immerse in water or other liquids and avoid extremely humid conditions.
Use only the power supply provided with the system. Use of any unauthorized power supply will
void any and all warranties.
Please do not use “pass-thru” type RJ-45 connectors. These pass-thru type connectors do not
work well for professional installations and can be the cause of intermittent connections. For
best results please use standard RJ-45 connectors, real crimpers and test all cables for proper
pin-outs prior to use and connection to Vaddio Cat-5e/6 products.
Important Note
OneLINK systems are not compatible with previous versions of OneLINK codec camera extenders. The
specifications are different and will not function if parts from either system are mixed. The older systems are those
with Quick-Connect part number 998-1105-019 and EZIM part number 998-6700-003. Connecting these to a new
OneLINK system may cause failure and void warranty.
OneLINK For RoboSHOT HDMI Cameras Page 3 of 20
OneLINK For RoboSHOT HDMI Cameras
Unpacking:
Carefully remove the product and all of the included parts from the packaging. Identify the following parts:
OneLINK System for Vaddio RoboSHOT HDMI Cameras (North America)
Part Number 999-9590-000 Includes:
One (1) 998-1105-043 OneLINK HDMI Interface
One (1) 998-6700-043 OneLINK HDMI EZIM Camera Interface
One (1) Vaddio 48 VDC, 1.36 Amp Switching Power Supply with North American AC Cord Set
One (1) 12” (305mm) HDMI Male to Male camera cable
Two (2) 12” (305mm) Cat-5e Patch Cables (Ethernet and RS-232)
One (1) 12” (305mm) Power Cable
Two (2) 6-32 x .188” Black Phillips head EZIM screws
One (1) Quick Start Guide
OneLINK System for Vaddio RoboSHOT HDMI Cameras (International)
Part Number 999-9590-001 Includes:
One (1) 998-1105-043 OneLINK HDMI Interface
One (1) 998-6700-043 OneLINK HDMI EZIM Camera Interface
One (1) Vaddio 48 VDC, 1.36 Amp Switching Power Supply
One (1) Euro Power Cable
One (1) UK Power Cable
One (1) 12” (305mm) HDMI Male to Male camera cable
Two (2) 12” (305mm) Cat-5e Patch Cables (Ethernet and RS-232)
One (1) 12” (305mm) power cable
Two (2) 6-32 x .188” Black Phillips head EZIM screws
One (1) Quick Start Guide
Image: OneLINK HDMI Interface with Front Panel Feature Call-outs
1. Blue Backlit Display: A two row, 20 character display displays the IP and MAC addresses for access to
internally served web pages. These web pages are currently used only for easy firmware updates in the unlikely
event the OneLINK system ever requires a firmware update.
2. Power / System Reset: Blue power indicator lamp and recessed momentary reset button indicates presence
of power with a blue LED. Press this recessed button for a system reset if required.
①
②
OneLINK For RoboSHOT HDMI Cameras Page 4 of 20
OneLINK For RoboSHOT HDMI Cameras
Image: OneLINK HDMI Interface with Rear Panel Connector Call-outs
1. Power Input Jack: Coaxial 5.5mm OD x 2.5mm ID power jack with positive center for use with supplied 48VDC, 1.36A
power supply. This power jack supplies power to both ends of the OneLINK system as well as the camera.
2. OneLINK Interface Port: Shielded RJ-45 jack for connecting a single Cat-5e or better cable for conne ctivity to the EZIM
(TX) at the camera location to the OneLINK HDMI Interface (Rx). Cat-6 or Cat-7 cabling might provide better performance
in noisier RF or EMF environments - when in doubt, use shielded Cat-6 cable. Cable distance between the OneLINK EZIM
and OneLINK HDMI Interface is a maximum of 328 feet (100 m).
3. HDMI Output: HDMI output to provide camera HDMI signal.
4. RS-232 port:
OneLINK system (if required. This signal will be transported on the OneLINK system simultaneously with the
other signals
5. IR Forwarding: 3-pin Phoenix-style connector for for warded IR signals from the camera EZIM. Modulated and non-
modulated outputs provided. Note: IR Forwarding is not used with the RoboSHOT HDMI camer as.
6. Network IP Port: Shielded RJ-45 net work jack for transport of Ethernet signals for camer a control or webserver access.
Image: OneLINK EZIM Camera Interface with Connector Call-outs
1. Camera Power Jack: EIAJ-04 coaxial power connection to provide power to the camera. An appropriate
cable is provided to connect the camera to this jack.
2. Ethernet Port: Shielded RJ-45 network jack provided to allow connection of Ethernet control to the camera.
RS-232: Shielded RJ-45 jack for bi-directional RS-232 connection to camera.
3.
HDMI Connection: HDMI connector for HDMI video signal coming from the camera to be inserted into the EZIM for
4.
transport.
Mounting flange: A convenient mounting flange is provided for mounting the EZIM to the cam era’s included wall moun t
5.
or to another appropriately located position.
OneLINK Interface Port: Shielded RJ-45 jack for connecting a single Cat-5e or better cable for conne ctivity to the EZIM
6.
(TX) at the camera location to the OneLINK HDMI Interface (Rx). Cat-6 or Cat-7 cabling might provide better performance
in noisier RF or EMF environments - when in doubt, use shielded Cat-6 cable. Cable distance between the OneLINK EZIM
and OneLINK HDMI Interface is a maximum of 328 feet (100 m).
Shielded RJ-45 jack for connecting a bi-directional RS-232 signal to be transported by the
①
②① ③ ④ ⑤ ⑥
⑤
⑥
②
③
④
Front View
OneLINK For RoboSHOT HDMI Cameras Page 5 of 20
OneLINK For RoboSHOT HDMI Cameras
C
AMERA AND
EZIM M
OUNTING INSTRUCTIONS
In case you haven’t noticed by now, the RoboSHOT Mount for the
RoboSHOT 12/30 HDMI
Camera Mount
HDMI Cameras has two threaded 6-32 holes in the camera
platform. These holes are for mounting the EZIM inconspicuously
to the bottom of the with the connection panel facing toward the
wall. The cables are connected from the EZIM to the Camera
through the cable pass-through on the mount platform. This mount
is shipped with the RoboSHOT HDMI camera.
Determine Camera Mount Location
When locating the camera, consider viewing angles, lighting
conditions, possible line of site obstructions and check for in-wall
or in-ceiling obstructions where the camera is to be mounted.
Always pick a mounting location to optimize the performance of the
camera. Please locate the camera to enable easy positioning of
the camera body with the ability to point down and away from the
ceiling and a pile of fluorescent lighting cells. Cameras generally
Two 6-32
Threaded
Holes
don’t like to be swamped with fluorescent light and nobody sits on
the ceiling anyway.
After determining the optimum location of the camera system, pull
and route the required Cat-6 cable from the Camera/EZIM location
back to the OneLINK Interface Location (head-end).
If the wall mount is to be mounted on a 2-gang wall box, use the screws supplied with the wall box cover plate to
attach Thin Profile Wall Mount Bracket. If mounting to drywall with wall anchors, use the four (4) quality wall anchors
and screws provided with the mount. The Thin Profile Wall Mount Bracket’s mounting holes are slotted and are 9 0°
opposing to provide easy leveling. Level the mount and place the camera on the mount. Connect the marked and
tested Cat-5e cables to the appropriate RJ-45 jacks. Check the level again to avoid any of those weird Batman-
type camera angles.
The OneLINK Kit for the Vaddio HDMI Cameras comes with two 6-32 x .188” pan head screws. Use these screws
to attach the EZIM to the bottom of the mount.
Use the provided ¼”-20 x .375 mounting screw to attach the camera to the mount. This step is best performed after
the camera and EZIM are cabled (see next page).
Drawing: RoboSHOT HDMI Mount with EZIM Attached
RoboSHOT 12/30 HDMI
Camera Mount with EZIM
Side View
RoboSHOT 12/30 HDMI
Camera Mount with EZIM
Front View
Short Cables run from
EZIM to Camera
OneLINK
Cable to
Interface
Use two (2) 6-32 x .188”
pan head screws to attach
the EZIM to the Mount
OneLINK For RoboSHOT HDMI Cameras Page 6 of 20
Loading...
