Utstarcom CDM7075 User Manual

CD M7 07 5 Us er G uid e
SMSM
PAY AS YOU GOPAY AS YOU GO
User Guide
Ca me ra P ho ne
CD M7 07 5
TABLE OF CONTENTS
CHAPTER 1. BEFORE USING YOUR PHONE
PACKAGE INCLUDES .............................................................................................6
HANDSET DESCRIPTION ........................................................................................7
BATTERY USAGE .................................................................................................11
POWER CONNECTION ........................................................................................................13
BATTERY HANDLING INFORMATION ..................................................................14
DO’s....................................................................................................................................14
DON’Ts................................................................................................................................14
CHAPTER 2. BASIC OPERATION
TURNING THE PHONE ON / OFF ..........................................................................16
ACCESSING THE MENU .......................................................................................17
MENU SUMMARY ...............................................................................................18
BASIC FUNCTIONS...............................................................................................20
MAKING A CALL .................................................................................................................20
ANSWERING CALLS ............................................................................................................21
WAIT/PAUSE FEATURE........................................................................................................22
3-WAY CALLING .................................................................................................................22
CALLER ID FUNCTION.........................................................................................................23
CALL WAITING FUNCTION..................................................................................................23
ADJUSTING VOLUME..........................................................................................................24
SPEAKERPHONE..................................................................................................................24
DURING A CALL ..................................................................................................25
MUTE (UNMUTE) ................................................................................................................25
SEND TXT MSG ...................................................................................................................25
CONTACTS..........................................................................................................................25
RECENT CALLS....................................................................................................................25
VOICE PRIVACY ..................................................................................................................26
LOCATION...........................................................................................................................26
MAKING AN EMERGENCY CALL .........................................................................27
1
TABLE OF CONTENTS
911 IN LOCK MODE............................................................................................................27
911 USING ANY AVAILABLE SYSTEM .................................................................................27
CHAPTER 3. MEMORY FUNCTION
STORING A PHONE NUMBER ..............................................................................30
ENTERING LETTERS, NUMBERS & SYMBOLS.......................................................31
STANDARD INPUT MODE ...................................................................................................32
T9WORD INPUT MODE .......................................................................................................33
NUMERIC MODE.................................................................................................................34
SYMBOL MODE...................................................................................................................34
MAKING A CALL THROUGH THE CONTACT LIST .................................................35
ONE-TOUCH/TWO-TOUCH DIALING....................................................................................35
CHAPTER 4. MENU FUNCTION
CONTACTS...........................................................................................................38
NEW CONTACT...................................................................................................................38
CONTACT LIST ....................................................................................................................39
GROUPS..............................................................................................................................40
SPEED DIALS.......................................................................................................................44
RECENT CALLS.....................................................................................................45
MISSED ...............................................................................................................................45
RECEIVED............................................................................................................................46
DIALED................................................................................................................................47
ALL......................................................................................................................................48
VIEW TIMERS......................................................................................................................49
SETTINGS.............................................................................................................50
SOUND SETTINGS ...............................................................................................................50
DISPLAY SETTINGS .............................................................................................................59
PHONE SETTINGS................................................................................................................63
CALL SETTINGS...................................................................................................................71
MEMORY ............................................................................................................................76
2
TABLE OF CONTENTS
PHONE INFO .......................................................................................................................77
VOICE RECOGNITION SETTINGS .........................................................................................79
MY ACCOUNT .....................................................................................................82
MY ACCOUNT.....................................................................................................................82
CHAPTER 5. TOOLS
TOOLS..................................................................................................................84
VOICE COMMAND..............................................................................................................84
CALENDAR..........................................................................................................................86
ALARM CLOCK....................................................................................................................88
WORLD CLOCK ...................................................................................................................89
NOTEPAD............................................................................................................................90
CALCULATOR......................................................................................................................91
STOPWATCH.......................................................................................................................92
CHAPTER 6. GET IT NOW
GET IT NOW ........................................................................................................94
GET TUNES & TONES ..........................................................................................................94
GET PIX...............................................................................................................................97
GET FUN & GAMES...........................................................................................................101
GET NEW & INFO..............................................................................................................102
GET GOING.......................................................................................................................103
GET EXTRAS......................................................................................................................104
CHAPTER 7. MESSAGING
MESSAGING ......................................................................................................106
NEW TXT MSG ..................................................................................................................106
NEW PIX MSG.....................................................................................................................10
INBOX...............................................................................................................................110
SENT .................................................................................................................................111
DRAFTS.............................................................................................................................112
3
TABLE OF CONTENTS
VOICEMAIL .......................................................................................................................113
EMAIL ...............................................................................................................................114
IM .....................................................................................................................................114
CHAT.................................................................................................................................114
ERASE ...............................................................................................................................115
SETTINGS..........................................................................................................................116
CHAPTER 8. MOBILE WEB
MOBILE WEB .....................................................................................................124
LAUNCHING MOBILE WEB 2.0..........................................................................................124
BROWSER MENU ..............................................................................................................124
CHAPTER 9. SAFETY INFORMATION
SAFETY ..............................................................................................................130
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES ...........................................130
SAFETY INFORMATION FOR FCC RF EXPOSURE ...............................................................134
SAR INFORMATION ..........................................................................................................135
FDA CONSUMER UPDATE.................................................................................................138
EMERGENCY CALLS..........................................................................................................148
COMPLIANCE WITH OTHER FCC REGULATIONS...............................................................151
GENERAL SAFETY .............................................................................................................152
ANTENNA .........................................................................................................................153
BATTERY...........................................................................................................................154
CHARGER..........................................................................................................................156
FCC HEARING-AID COMPATIBILITY (HAC) REGULATIONS FOR WIRELESS DEVICES.........157
GAMES .............................................................................................................................160
CAMERA ...........................................................................................................................161
RECYCLE YOUR CELL PHONE! ..........................................................................................161
WARRANTY .......................................................................................................163
MANUFACTURER’S WARRANTY.......................................................................................163
4
CHAPTER 1
BEFORE USING YOUR PHONE
CHAPTER 1
BEFORE
USING
YOUR PHONE
This chapter provides important information about
using your phone including:
PACKAGE INCLUDES
HANDSET DESCRIPTION
BATTERY USAGE
BATTERY HANDLING INFORMATION
5
PACKAGE INCLUDES
This package should include all items pictured below. If any are missing or different, immediately contact the retailer where you purchased the phone.
Handset
6
Standard Battery
AC Charger
HANDSET DESCRIPTION
Your CDM7075VW weighs 3.5 ounces. The dimensions are
3.5"x1.9"x8.6".
Camera Lens
NAVIGATION KEY
Left Soft Key
SEND Key
Microphone
Camera Key
Right Soft Key
END/POWER Key
CLR/ Speakerphone Key
Antenna
Earjack
Volume Keys
7
HANDSET DESCRIPTION (THE FUNCTION KEYS)
NAVIGATION KEY
Send Key
Press to make or receive a call. In Idle Mode, press to access the All Calls list.
End Key
Press to terminate a call or to return to Idle Mode. Press and hold to turn the phone on/off.
Left Soft Key
Press to access the Message menu or function displayed on bottom line.
Right Soft Key
Press to access the Contacts menu or function displayed on bottom line.
CLR/Speakerphone Key
Press to clear a digit from the display or to return to the previous page. Press and hold to clear all digits. When on a call, press to activate speakerphone. In Idle Mode, press to access the Voice Command menu or to dial a phone number using your voice.
Shift Key
Enters the asterisk [*] character for calling features. In text entry mode, press to change the character input type. Press twice to display a plus sign (+) for international dialing.
Space Key
Enters the pound [#] character for calling features. In text entry mode, press to accept the word and add a space.
Camera Key
Press to access Camera Mode.
Side Volume Key
Allows you to adjust the master volume in idle mode (with the flip open) or adjust the earpice volume during a call. The volume key can also be used to scroll up or down to navigate through the different menu options. To mute the ringer during an incoming call, press the volume key up or down.
In Idle Mode
Press
Navigation key up
down
for Shortcut (default program is Calendar),
key right
for Get It Now and
for Web Browser,
Navigation key
Navigation key left
Navigation
for Get PIX.
Within A Menu
Use to scroll through menu options, or to select a function displayed on the screen.
8
HANDSET DESCRIPTION
(DISPLAY INDICATORS)
This display appears when you are not on a call or using the menu. You must be in Idle Mode display to dial a phone number.
Display Indicators
Display various icons.
Text & Graphic area
Soft Key Indicators
Shows the functions currently assigned to each soft key and displays some icons.
Signal Strength
Current signal strength: the more lines, the stronger the signal (1X Mode/Digital Mode).
Voice Call
Indicates call is in progress.
No Service
Indicates the phone cannot receive a signal from the system.
Roaming
Phone is out of home area.
Battery
Battery charging level — the more blocks, the stronger the charge.
Voicemail
Indicates you have voicemail messages.
New Messages
New TXT or PIX message.
Speakerphone
Phone is in speakerphone mode.
9
HANDSET DESCRIPTION (DISPLAY INDICATORS)
GPS Icon
Indicates the Location Service of your phone is disabled/enabled.
TTY
Indicates your phone is in TTY mode.
Alarm Only
Phone will alert you with an alarm tone when call is received.
Alarm
The only audible alert you can hear is for an alarm. Will not ring for incoming call or other alerts.
Vibrate Only
Phone will vibrate to notify you of an incoming call.
Sounds Off
Indicates all sounds and alerts are set to off.
Dormant
Indicates your phone is in a dormant state during a data call. Your phone goes to Dormant mode when you have not had any activity on a page for some time - your connection is still active and you can make and receive calls.
Data Only
Receives a data call when connected to PC.
Voice Privacy
Indicates Voice Privacy mode.
Standalone Mode
Wireless connectivity is turn off, but non-network functions can still be accesses.
10
BATTERY USAGE
(BATTERY INSTALLATION)
1.
Place the battery (label side up) on the back of the phone so the metal contacts match up on the battery and in the
battery cavity.
2.
Push the battery down into the battery cavity until it locks into place.
3.
Place the battery cover over the battery and slide up into place.
11
BATTERY USAGE (BATTERY REMOVAL)
1.
Push down the release latch button, then slide the battery cover off the phone.
2.
Lift the battery up and out of the battery cavity from the top of the battery.
• If the battery is not correctly placed in the compartment,
Note
the handset will not turn on and/or the battery may detach during use.
12
BATTERY USAGE
(BATTERY CHARGING)
POWER CONNECTION
1.
Plug the AC Charger into a standard outlet.
2.
Plug the other end of the AC Charger into the bottom of your phone. The battery must be installed onto the phone.
Hot Key
• When you charge the battery with the phone power off, you will see a charging status screen. You cannot operate the phoneuntil it is powered on.
• The battery is not charged at the time of purchase.
• Fully charge the battery before use.
• It is more efficient to charge the battery with the handset powered off.
• The battery must be connected to the phone in order to charge it.
• Battery operating time gradually decreases over time.
• If the battery fails to perform normally, you may need to replace the battery.
13
BATTERY HANDLING INFORMATION
DO's
l
Only use the battery approved for use with your phone.
l
Only use the battery for its original purpose.
l
Try to keep batteries in a temperature between 41ºF (5ºC ) and
95ºF (35ºC).
l
If the battery is stored in temperatures above or below the
recommended range, give it time to warm up or cool down before using.
l
Completely drain the battery before recharging. It may take one to
four days to completely drain.
l
Store the discharged battery in a cool, dark, and dry place.
l
Purchase a new battery when its operating time gradually decreases
after fully charging.
l
Properly dispose of the battery according to local laws.
DON’Ts
l
Don’t attempt to disassemble the battery – it is a sealed unit with no
serviceable parts.
l
Don’t accidentally short circuit the battery by carrying it in your pocket
or purse with other metallic objects such as coins, clips and pens. This may critically damage the battery.
l
Don’t leave the battery in hot or cold temps. Otherwise, it could
significantly reduce the capacity and lifetime of the battery.
l
Don’t dispose of the battery into a fire.
14
CHAPTER 2
BASIC OPERATION
CHAPTER 2
BASIC
OPERATION
This chapter addresses and explains the basic
features of your phone including:
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
MENU SUMMARY
BASIC FUNCTIONS
DURING A CALL
MAKING AN EMERGENCY CALL
15
TURNING THE PHONE ON / OFF
TURNING THE PHONE ON
1.
Press and hold until your “Power On” logo appears and the tone sounds.
• If "Phone Locked" appears on the display, press Right
Note
Softkey [Ignore] then enter your 4-digit lock code.
• The default lock code is the last 4 digits of your phone number.
TURNING THE PHONE OFF
1.
Press and hold until your “Power Off” logo appears.
• Immediately change or recharge the battery when “LOW
Note
BATTERY!! PHONE IS TURNING OFF!” appears on the display. Memory may possibly be damaged if the phone turns off due to the battery completely draining.
• Turn the phone off before removing or replacing the battery. If the phone is on, unsaved data may be lost.
16
ACCESSING THE MENU
Your phone can be customized via the menu. Each function can be accessed by scrolling with the NAVIGATION KEY or by pressing the number that corresponds with the menu item.
1.
To access the menu from Idle Mode, press [MENU].
2.
Pressing the Navigation Key ( ) up or down scrolls through the submenus for the the menu item you are in.
Pressing the Navigation Key ( ) left or right enables you to scroll through the menu items.
3.
To return to the previous page, press . To exit the current menu and return to the idle mode,
press .
4.
Press to enter a function when its main page is displayed or press its assigned number to have direct access
to the function.
Web Browser
GET PIX
Shortcut Key (Phone default is Calendar)
• Please see page 64 for directions on how to change the
Note
function of the Shortcut Key.
GET IT NOW
17
MENU SUMMARY
GET IT NOW
1.
Get Tunes & Tones
2.
Get PIX
2.1. Get New PIX
2.2. My PIX
2.3. PIX Place
2.4. Take PIX
3.
Get Fun & Games
4.
Get News &Info
5.
Get Going
6.
Get Extras
MESSAGING
1. New Msg
2. New PIX Msg
3. Inbox
4. Sent
5. Drafts
6. Voicemail
7. Email
8. Mobile IM
9. Chat
CONTACTS
1.
New Contact
2.
Contact List
3.
Groups
4.
Speed Dials
RECENT CALLS
1.
Missed
2.
Received
3.
Dialed
4.
All
5.
View Timers
SETTINGS & TOOLS
1. My Account
2. Tools
2.1. Voice Command
2.2. Calendar
2.3. Alarm Clock
2.4. World Clock
2.5. Notepad
2.6. Calculator
2.7. Stopwatch
3. Sound Settings
3.1. Master Volume
3.2. Call Sound
3.2.1. Call Ringtone
3.2.2. Call Vibrate
3.3. Alert Sound
3.3.1. TXT Message
3.3.2. PIX Msg
3.3.3. Voicemail Msg
3.4. Keypad Volume
3.5. Earpiece Volume
3.6. Service Alerts
3.6.1. ERI
3.6.2. Minute Beep
18
MENU SUMMARY
3.6.3. Call Connect
3.7. Power On/Off
3.7.1. Power On
3.7.2. Power Off
3.8. Alarm Sound
3.8.1. Tone
3.8.2. Vibrate
4. Display Settings
4.1. Banner
4.1.1. Personal
4.1.2. ERI Banner
4.2. Backlight
4.2.1. Display
4.2.2. Keypad
4.3. Contrast
4.4. Wallpaper
4.5. Screensaver
4.6. Display Themes
4.7. Fonts
4.8. Clock Format
5. Phone Settings
5.1. Standalone Mode
5.2. Shortcut Key
5.3. Language
5.4. Location
5.5. Security
5.5.1. Common Code
5.5.2. Lock Mode
5.5.3. Edit Code
5.5.4. Restrict Calls
5.5.5. Erase Contacts
5.5.6. Reset Default
5.6. System Select
5.7. Nam Selection
5.7.1. Auto NAM
5.7.2. Change NAM
6. Call Settings
6.1. Answer Options
6.2. Auto Retry
6.3. TTY Mode
6.4. One Touch Dial
6.5. Voice Privacy
6.6. Restrict Calls
6.7. DTMF Tones
6.8. Ringer ID
6.9. Picture ID
7. Memory
7.1. Memory Usage
7.2. My PIX
7.3. My Sounds
8. Phone Info
8.1. My Number
8.2. SW Version
8.3. Icon Glossary
9. VR Settings
9.1. Choice List
9.2. Train Voice
9.2.1. Train Words
9.2.2. Train Digits
9.3. Prompts
9.3.1. Mode
9.3.2. Timeout
9.4. Call Alert
19
BASIC FUNCTIONS
MAKING A CALL
1.
Enter a phone number.
To modify the phone number you have entered :
Note
• To erase one digit at a time press .
• To erase the entire number, press and hold .
2.
Press .
• If “CALL FAILED” appears on the display or the line is
Note
3.
busy, press or .
• If you activate the “AUTO RETRY” function, the phone will automatically retry for the number of times you have selected.
• When you place or receive a call from stored phone numbers, only the name will be displayed.
• If “Enter Lock Code” appears on the display enter your 4-digit lock code to unlock your phone.
To end a call, press .
20
BASIC FUNCTIONS
ANSWERING CALLS
1.
When your phone rings or vibrates, press to answer the incoming call. (Depending on your phone’s settings, you may
also answer incoming calls by opening the phone or by pressing any digit key. See page 71)
To ignore incoming calls, press
2.
To end the call, press .
In Auto Answer Mode a call is automatically answered
Note
after five seconds of ring tones.
Right Soft Key ( )
[IGNORE].
21
BASIC FUNCTIONS
WAIT/PAUSE FEATURE
Pauses are used for automated systems (i.e., voice mail, calling cards). Insert a pause after a phone number then enter another group of numbers. The second set of numbers is dialed automatically after the pause. This feature is useful for dialing into systems that require a code.
1.
To insert a wait/pause, enter a phone number then press Right Soft Key ( ) [OPTIONS]. Select either a 2-Sec Pause
(“P” appears) or a Wait (“W” appears).
2.
Press to dial or press Left Soft Key ( ) to save phone
number.
3-WAY CALLING
With 3-Way Calling, you can talk to two people at the same time. When using this feature, the normal airtime rates will be applied for each of the two calls.
1.
Enter a number you wish to call then press .
2.
Once you have established the connection, enter the second number you wish to call then press .
3.
When you’re connected to the second party, press again to begin your 3-Way call.
22
BASIC FUNCTIONS
If one of the people you called hangs up during your call,
Note
you and the remaining caller stay connected. If you initiated the call and are the first to hang up, all three callers are disconnected.
CALLER ID FUNCTION
Identifies caller by displaying their phone number. If the caller’s name and number are already stored in your phone book, their name will appear. This is a system dependent feature. Please contact your service provider for details.
CALL WAITING FUNCTION
Notifies you of an incoming call when you are already on a call by sounding a beep tone and displaying the caller’s phone number.
1.
To answer another call while on the phone, press . This places the first call on hold. To switch back to the first
caller, press again.
Call Waiting is a system dependent feature.
Note
Please contact your service provider for details.
23
BASIC FUNCTIONS
ADJUSTING VOLUME
Adjusts the volume of the ringer, key beep and earpiece.
1.
Press [MENU], then press Navigation Key ( ) right 2 times for the “Settings & Tools” menu. Press “Sound
Settings” then select one of the following options:
Master Volume: Controls the ringer volume. Keypad Volume: Controls the keypad volume. Earpiece Volume: Controls the earpiece volume.
2.
Adjust the volume by pressing or Navigation Key ( ) right or left then press to save the setting.
• To adjust earpiece volume during a call, press
Note
up or down.
- Press and hold down to turn off all sounds.
- Press and hold up to return to normal mode.
- In idle mode, press up/down to adjust the master volume.
SPEAKERPHONE
The speakerphone feature lets you hear audio through the speaker and talk without holding the phone.
1.
To activate the speakerphone while on a call, press .
2.
The phone returns to normal (Speakerphone Off) after ending a call or when the phone is turned off and back on.
24
DURING A CALL
MUTE (UNMUTE)
The caller cannot hear you or any sounds from your side but you can still hear them.
1.
Press Left Soft Key ( ) [MUTE].
• To deactivate, press
• The phone will automatically unmute in Emergency Call or Callback mode.
Left Soft Key ( ) left
[UNMUTE].
SEND TXT MSG
Enables you to send a TXT message during a call.
1.
Press Right Soft Key ( ) [OPTIONS], press .
CONTACTS
To select the phone number in your internal Contact List.
1.
Press Right Soft Key ( ) [OPTIONS], press .
RECENT CALLS
To select the phone number in your recent calls List.
1.
Press Right Soft Key ( ) [OPTIONS], press .
25
DURING A CALL
VOICE PRIVACY
Increases security during a call.
1.
Press Right Soft Key ( ) [OPTIONS], press .
LOCATION
Enables the network to locate your current location through Global Positioning System (GPS).
1.
Press Right Soft Key ( ) [OPTIONS], press .
26
MAKING AN EMERGENCY CALL
The 911 feature puts the phone in the Emergency Call Mode when you dial the preprogrammed emergency number, 911. It also operates in the lock mode and out of the service area.
911 IN LOCK MODE
The 911 call service is available even in the lock mode.
1.
Enter “911”, then press .
2.
The call connects.
3.
When the call ends, the phone returns to the Lock Mode.
911 USING ANY AVAILABLE SYSTEM
1.
Enter “911”, then press .
2.
The call connects.
3.
The phone maintains the Emergency Mode and the phone canreceive an incoming call from any available system.
However, it can’t make a call.
The 911 call is not recorded in the recent call list.
Note
27
MEMO
28
CHAPTER 3
MEMORY FUNCTION
CHAPTER 3
MEMORY
FUNCTION
This chapter addresses memory functions including:
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
MAKING A CALL THROUGH THE CONTACT LIST
29
Loading...
+ 139 hidden pages
