4MP WDR Network IR Dome Camera
IPC3534SR3-DVPZ-F
Key Features
Optics
Day/night functionality
Smart IR, up to 30m (98ft) IR distance
IR anti-reflection window to increase the infrared transmittance
2D/3D DNR (Digital Noise Reduction)
Compression
Ultra 265, H.265, H.264, MJPEG
Triple streams
Network
ONVIF Conformance
Structure
Wide temperature range: -35°C ~ 60°C (-31°F ~ 140°F)
Wide voltage range of ±25%
IK10 vandal resistant
3-Axis
2
ATASHEETDA
Specifications
IPC3534SR3-DVPZ-F
Camera
Sensor
1/3", 4.0 megapixel, progressive scan, CMOS
Lens
2.8 ~ 12mm, AF automatic focusing and motorized zoom lens
DORI Distance
Lens (mm)
Detect (m)
Observe (m)
Recognize (m)
Identify (m)
2.8
63.0
25.2
12.6
6.3
12
270.0
108.0
54.0
27.0
Angle of view (H)
98.26°~ 31.35°
Angle of View (V)
54.76°~ 18.55°
Angle of View (O)
127.74°~36.99°
Adjustment angle
Pan: 0° ~ 360°
Tilt: 0° ~ 70°
Rotate: 0° ~ 360°
Shutter
Auto/Manual, 1 ~ 1/100000s
Minimum Illumination
Colour: 0.003Lux (F1.6, AGC ON)
0Lux with IR
Day/Night
IR-cut filter with auto switch (ICR)
Digital noise reduction
2D/3D DNR
S/N
>56dB
IR Range
Up to 30m (98ft) IR range
Wavelength
850nm
IR On/Off Control
Auto/Manual
Defog
Digital Defog
WDR
120dB
Video
Video Compression
Ultra 265, H.265, H.264, MJPEG
H.264 code profile
Baseline profile, Main Profile
Frame Rate
Main Stream: 4MP (2688*1520), Max 30fps; 4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max
30fps;1080P(1920*1080),Max30fps
Sub Stream: 4CIF (704*576), Max 30fps;
Third Stream: CIF (352*288), Max 30fps
Video Bit Rate
128 Kbps~16 Mbps
OSD
Up to 4 OSDs
Privacy Mask
Up to 4 areas
ROI
Up to 2 areas
Motion Detection
Up to 4 areas
White Balance
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction
2D/3D DNR
Smart IR
Support
Flip
Normal/Vertical/Horizontal/180°
Dewarping
NA
HLC
Supported
BLC
Supported
3
DATASHEETD
Audio
Audio Compression
G.711
Suppression
Supported
Sampling Rate
8KHZ
Storage
Edge Storage
Micro SD, up to 256GB
Network Storage
ANR
Network
Protocols
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL
Compatible Integration
ONVIF (Profile S, Profile G, Profile T), API
Client
EZStation
EZView
EZLive
Web Browser
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
Interface
Audio I/O
Input: impedance 35kΩ; amplitude 2V [p-p]
Output: impedance 600Ω; amplitude 2V [p-p]
Alarm I/O
1/1
Network
10M/100M Base-TX Ethernet
Certifications
Certifications
CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15
General
Power
DC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 8.7W
Dimensions (Ø x H)
Φ128.1mmx99.9mm (Ø5.04” x 3.93”)
Net Weight
0.57kg (1.26lb)
Material
Metal + Plastic
Working Environment
-35°C ~ 60°C (-31°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment
-35°C ~ 60°C (-31°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Surge Protection
6KV
Ingress Protection
IP67
Vandal Resistant
IK10
Reset Button
Supported
Dimensions
4
ATASHEETDA
Junction Mount
Pole Mount
TR-JB03-H-IN
TR-JB07/WM03-F-IN(TR-WM03-B-IN)+TR-UP06-IN
TR-CM24-IN+TR-JB03-H-IN
Accessories
TR-JB03-H-IN TR-JB07/WM03-F-IN TR-WM03-B-IN TR-UP06-IN TR-A01-IN
TR-SE24-IN TR-SE24-A-IN TR-CM24-IN
5
DATASHEETD
Zhejiang Uniview Technologies Co., Ltd.
Building No.10, Wanlun Science Park, Jiangling Road 88, Binjiang District, Hangzhou, Zhejiang, China (310051)
Email: overseasbusiness@uniview.com; globalsupport@uniview.com
http://www.uniview.com
© 2020 Zhejiang Uniview Technologies Co., Ltd. All rights reserved.
*Product specifications and availability are subject to change without notice.
