Upasta-01
Ed. 02/2013
Operating and Maintenance Manual
Contents
It is forbidden to use the machine before having carefully read the manual, especially the part that concerns operator safety
and health.
1. Preliminary information 3
Notes on the use of this Use and Maintenance Manual
Manual storage
Manual consultation
Intended use
EC Marking
General safety warnings
General safety information
2. Machine transport, handling and warehousing 5
Packing
Unpacking
Handling the pasta machine
3. Use 6
Pasta machine and accessories
Electrical power supply and controls
4. Safety devices 7
Assembly of parts for pasta production
Pasta maker die assembly
Pasta cutter blade assembly
Kneader assembly
Accessory for tagliatelle noodles
Ravioli unit
Part disassembly
5. Technical specifications 12
2
1. Preliminary information
Notes on the use of this Use and Maintenance Manual
This document must be considered an integral part of the machine it describes and must as such be stored for the entire machine's
lifespan.
This document, moreover, must be delivered along with the machine to any other user or owner to whom the machine is transferred.
Manual storage
This document must be used so as not to damage it and must be stored in a suitable place, without humidity or excessive temperature
over the entire lifespan of the machine with which it is enclosed.
Manual consultation
The manual is divided into topics. The user can search a particular set of information in the Contents.
Certain symbols are used throughout the Manual to allow the user to more easily identify the important notes, as for instance those
concerning safety, or to draw the reader's attention to special remarks.
Notes on safety are indicated by the following symbol:
Observations that are especially useful to soundly operate the machine are indicated by the following symbol:
Prohibition signs that are meant to reduce the possibility of improper management of the machine are indicated by the following
symbol:
Intended use
The machine described in this Manual is named "Pasta Maker" and has been specifically designed to produce pasta and ravioli with
the aid of specific accessories that are complementary to the machine.
The production cycle requires the user to feed appropriate ingredients into the machine poured in through the hopper that are mixed
and kneaded by a powered spiral.
When the pasta dough is ready, the user manually opens a hatch and a screw conveyor transports the dough to the kneader or other
accessories that make it possible production of several pasta sizes (ref. hereinafter to the accessories description),
The manufacturer forbids using the machine for different purposes than those described herein.
EC Marking
On the machine there is an EC label with the essential details to unambiguously identify the machine.
Likewise, the EC label is manufactured in material that can endure bad weather for prolonged time and the information it bears are
indelible.
The information displayed includes:
• Manufacturer's full details;
• Serial number;
• Year of manufacture;
• Voltage and frequency;
• Electrical power;
• Weight in Kg.
DO NOT REMOVE OR TAMPER WITH THE EC LABEL ON THE MACHINE.
3
General safety warnings
All operations performed on the machine, from its use to maintenance to its final demolition, require the presence of suitably qualified
staff, in order to limit risks due to inadequate qualification to a minimum.
General safety information
The manufacturer has designed and checked every machine part and their respective function in the minutest detail, to prevent
potential hazards.
Nonetheless, given the specific functional features of the machine, below are certain warnings to bear in mind. The conditions that we
draw attention to are:
THE OPERATOR MUST WEAR CLOTHING AND CARRY PERSONAL BELONGINGS THAT ARE COMPLIANT WITH
LEGAL REQUIREMENTS TO ENSURE MACHINE OPERATIONS CAN BE SAFELY CONDUCTED.
BELONGINGS WORN BY THE OPERATOR MUST ONLY BE THOSE THAT ARE INDISPENSABLE AND MUST BE
WORN PROPERLY AND STABLY, IN ORDER NOT TO CREATE POTENTIAL HAZARDS OR DANGER FOR THE
OPERATOR OR OTHER STAFF ASSIGNED TO THE MACHINE.
DO NOT STICK PROPERTY OR BODY PARTS INSIDE THE MACHINE.
WHEN OPERATING THE MACHINE, THE OPERATOR OR USER MUST APPLY ALL SAFETY STANDARDS
REQUIRED BY THE LAWS APPLICABLE IN THE COUNTRY WHERE THE MACHINE IS INSTALLED.
CLEAN THE CONNECTORS AND CABLES WITH COMPRESSED AIR OR USE A DRY CLOTH, IF NECESSARY.
Furthermore, the user must comply with the following bans over the machine's entire lifespan:
• It is forbidden to open machine guards during its operation.
• It is forbidden to deactivate the safety devices.
• It is forbidden to inspect the machine during its operation.
• It is forbidden to lean on the machine during its operation.
• It is forbidden to sit on top of machine components.
• It is forbidden to use the machine, even only parts of it, for other purposes than those listed in this Manual.
• After cleaning or servicing the machine, reassemble the machine guards as soon as possible.
• It is forbidden to apply other safety devices on the machine unless the manufacturer first grants authorization in writing.
• It is forbidden to use the machine with safety devices or elements other than those recommended by the manufacturer unless the
manufacturer first grants authorization in writing.
• Only use the machine with original accessories
• Clean the machine components, panels and controls, with soft cloth and dry.
• It is forbidden to use any type of solvent, like alcohol or gasoline or thinners, to clean any of the surfaces.
• Do not stick your hands, arms or any other body part into or near moving machine parts.
• When inspecting or removing any type of fault and malfunction, be sure to apply all the precautions described in this Manual that are
effective in preventing any harm to persons and/or animals and/or property.
• Clothing worn by the operator must be the most appropriate, that is to say, not too loose or too close-fitting, and not have flapping
hems and edges.
• Do not wear belts, rings, bracelets and chains. Bundle long hair in a head bayonet.
FAILURE TO COMPLY WITH THE ABOVE BANS AUTOMATICALLY IMPLIES THE CANCELLATION OF ANY
WARRANTY COVER AND EXEMPTS THE MANUFACTURER OF ALL LIABILITY.
WHEN OPERATING THE MACHINE, THE OPERATOR OR USER MUST APPLY ALL SAFETY STANDARDS
REQUIRED BY THE LAWS APPLICABLE IN THE COUNTRY WHERE THE MACHINE IS INSTALLED.
4
2. Machine transport, handling and warehousing
Packing
Machine packing consists of a wooden crate. To correctly handle the crate, use a forklift or pallet transporter.
ALL TASKS TIED TO MACHINE HANDLING, TRANSPORT AND WAREHOUSING MUST BE CARRIED OUT BY
SPECIALIZED PERSONNEL AND IN FULL COMPLIANCE WITH THE LEGISLATION AND STANDARDS APPLICABLE
IN THE COUNTRY WHERE THE MACHINE IS INSTALLED.
BEFORE YOU UNPACK THE MACHINE, BE SURE TO CHECK THE PACKING IS INTACT AND INFORM CUSTOMER
SERVICE OF ANY UNUSUAL FLAWS.
Open machine packing
Unpacking
Open the packing and check that the pasta maker is perfectly intact.
Then, remove the pasta maker from its packing and proceed to position it for installation.
IF THE MACHINE INCLUDES PACKING, THE OPERATOR MUST STORE IT OVER THE MACHINE'S ENTIRE LIFE
CYCLE, IN ORDER TO REUSE IT WHENEVER HANDLING THE MACHINE AFTER ITS INSTALLATION.
IF THE MACHINE DISPLAYS DAMAGE PRIOR TO UNPACKING OR AT ANY RATE PRIOR TO ITS HANDLING,
PROMPTLY INFORM CUSTOMER SUPPORT TO RECEIVE CLARIFICATIONS.
We recommend that you store the packing for future transport tasks.
Handling the pasta machine
DURING HANDLING, THE OPERATOR MUST PLACE THE UTMOST ATTENTION TO AVOID THE MACHINE FROM
TIPPING OVER.
HANDLE THE MACHINE ONLY WHEN IT IS NOT RUNNING AND IS DISCONNECTED FROM ALL ITS POWER
SUPPLIES.
Positioning and leveling the pasta maker
The machine is capable of operating in outdoor premises at temperatures from +5°C to +35°C and with a humidity of up to 9'% without
condensation.
After having placed the pasta maker in the desired position, level it with the ground by working on the adjustable supports indicated in
the figure.
INSTALL THE PASTA MAKER SO THAT IT HAS ENOUGH SPACE AROUND IT FOR THE OPERATOR TO WORK
AND ASSEMBLE/DISASSEMBLE THE ACCESSORIES IN TOTAL SAFETY. MOREOVER, PROVIDE SUFFICIENT
LIGHTING FOR INSTALLATION.
5
