Univex UFP13-01 Operating And Maintenance Manual
UFP13-01
Ed. 11/2015
Operating and Maintenance Manual
1
FOREWORD
- This manual is meant to provide Customers with information on the machine and its specifications and the
necessary operating and maintenance instructions in order to ensure machine performance and longevity.
- This manual is to be used by qualified and skilled operators with thorough knowledge of machine use and
maintenance.
CONTENTS
CHAP. 1 - INFORMATION ON THE MACHINE page 3
1.1 - GENERAL PRECAUTIONS
1.2 - DESCRIPTION OF THE MACHINE
1.2.1 - General description
1.2.2 - Manufacturing features (materials used)
1.3 - SAFETY DEVICES
1.3.1 - General safety devices
1.3.2 - Electrical safety devices
1.4 - ACCESSORIES + TOOLS
1.4.1 - Accessories
1.4.1.1 - Standard accessories
1.4.2 - Tools
CHAP.2 - TECHNICAL SPECIFICATION page 7
2.1 - OVERALL DIMENSIONS, WEIGHT, FEATURES ...
CHAP.3 - RECEIVING THE MACHINE page 8
3.1 - DESPATCH OF THE MACHINE
3.2 - PACKAGE CHECK UPON RECEIPT
3.3 - PACKAGING DISPOSAL
CHAP.4 - INSTALLATION page 9
4.1 - SETTING UP OF THE MACHINE
4.1.1 - Collecting bowl
4.2 - ELECTRICAL CONNECTION
4.2.1 - Vegetable cutter (115 V. 60 Hz)
4.3 - VEGETABLE CUTTER WIRING DIAGRAM
4.4 - FUNCTIONAL CHECK
CHAP. 5 - USE OF THE MACHINE page 10
5.1 - DISCS ASSEMBLY
5.2 - LOADING AND CUTTING THE PRODUCT
CHAP.6 - MAINTENANCE AND ADVICE page 12
6.1 - FOREWORD
6.1.1 - Belt
6.1.2 - Feet
6.1.3 - Power supply cord
6.1.4 - Discs
6.2 - What to do if...
6.2.1 - The locking of the discs is faulty
6.2.2 - The lid does not close correctly
6.2.3 - The product is not cut correctly
6.2.4 - The product does not go out correctly or is badly cut
6.2.5 - The machine locks
6.2.6 - The micro on the pusher handle and on the lid do not work
6.2.7 - The machine does not start
CHAP.7 - CLEANING OF THE MACHINE page 12
7.1 - FOREWORD
7.2 - PRODUCTS
7.3 - HOW TO CLEAN THE MACHINE
CHAP.8 - SCRAPPING page 13
8.1 - PUTTING THE MACHINE OUT OF SERVICE
8.2 - SCRAPPING
2
CHAP.1 - INFORMATION ON THE MACHINE
1.1 - GENERAL PRECAUTIONS
- The vegetable cutter must be operated only by highly qualified personnel who are fully aware of the safety measures
described in this manual.
- In case of a personnel turnover, training is to be provided in advance.
- Although the machine incorporates safety devices and protections for dangerous parts, it is recommended not to
touch the moving parts.
- Before starting cleaning and maintenance operations, disconnect the plug from the supply socket.
- To carry out cleaning and maintenance, assess the residual risks carefully (as protections are removed).
- Cleaning and maintenance require concentration.
- A regular check of the power supply cable is absolutely necessary; a worn-out or damage cord is very dangerous.
- If the machine malfunctions, it is recommended not to use it and do not try to repair it; please call the “Service
Centre”, contact details are provided at the end of this manual.
- Do not use the machine for processing frozen products, meat and fishes with bones or non food products.
- Do not repair the machine yourself but call the “Authorised Service Centre”.
- Always use the pusher with the pestle to cut the food
- Do not fill too much the inlet cylinder and do not press too hard to avoid any problem .
- The manufacturer shall not be liable for damage to things or injury to persons in the event:
The machine or the safety devices and protections have been tampered with by non authorised personnel;
Non original
The instructions provided in this manual are not followed scrupulously;
The machine surface is not cleaned with the right product .
spare parts and discs are installed;
1.2 - MACHINE DESCRIPTION
PUSHER
BASE
PESTLE
PUSHER HANDLE
HOPPER
BODY
HINGE
POWER SUPPLY CORD
CONTROLS
Fig. n°1 - General view of the vegetable cutter
FEET
3
1.2.1 - GENERAL DESCRIPTION
The vegetable cutter has been designed and manufactured by our firm with the aim of ensuring:
- the highest degree of safety during use, cleaning and maintenance;
- the highest standard of hygiene due to a careful selection of materials which come into contact with food products,
elimination of sharp edges in the machine structure that come into contact with the food product, facilitating and ensuring perfect cleaning, as well as facilitating machine disassembly and part removal;
- robust and stable components;
a) reduced noise emission generated by the drive belt;
b) practical and easy to move.
1.2.2 - MANUFACTURING FEATURES (Materials used)
The vegetable cutter has been manufactured using materials with high resistance to mechanical worn and to corrosive
agents present in the product.
More specifically:
- The hopper and the base are made of anodised aluminium to ensure the contact with food products (hygiene) and to
ensure resistance to acids, salts and rust.
- The body, the lid, the pusher handle and the discs support are made of steel AISI 304 or 430.
- The pestle, the pusher, the bowl and the control panel are made of high resistant plastic, appropriate to enter into
contact with food products.
- The cutting discs:
a) The Disc set DF, DQ and PS have the main structure made of aluminium and the knives made of AISI 420.
b) The Disc set DT have the main structure made of plastic and the knives made of AISI 420.
1.3 - SAFETY DEVICES
1.3.1 - GENERAL SAFETY DEVICES
The mechanical, electrical and hygienic safety devices installed on the vegetable cutter described in this manual complies with:
UL 763 and NSF Standards
** The vegetable cutter is fitted with electrical and mechanical safety devices for machine operation as well as cleaning
and maintenance operations.
However, there are RESIDUAL RISKS which cannot be eliminated completely. These risks are listed in this manual under WARNINGS.
These risks are cutting dangers due to the machine handling during the disc substitution and/or cleaning.
1.3.2 - ELECTRICAL SAFETY DEVICES
The vegetable cutter is fitted with microswithes:
A On the pusher lever, to stop the machine if the handle is lifted over the mouth of the lid and to enable to turn on the
machine automatically when there is a dangerous situation
B On the hopper, to stop the machine if the lid is removed (
chine voluntarily (
(Fig. n°2).
i.e. to replace the discs) (Fig. n°3A), and to permit to start the ma-
by pressing pushbutton “I”) only when the lid is closed, correctly locked by the knob (Fig. n°3).
HANDLE UP
MICROSWITCH
HANDLE DOWN
Fig. n°2 - Electrical safety devices
Fig. n°3 - Mechanical safety devices
4
MICROSWITCH
POSITION
Fig. n°3A - Electrical safety devices
KNOB
1.4 - ACCESSORIES + TOOLS
1.4.1 - ACCESSORIES
The vegetable cutter is provided with many accessories. Some are supplied with the cutter, other must be requested by
the Client.
1.4.1.1 - STANDARD ACCESSORIES
Pestle: made of polyethylene for alimentary use, to facilitate the cutting of small product, it must be introduced in the
product cylinder placed on the pusher
Collecting bowl
(Fig. n°5).
: made of polyethylene for alimentary use, “GASTRONORM” of 1/3, h=200; equipped with microswitch
Fig. n°4 - Pressing pestle for
vegetables
Discharging spatula: made of steel AISI 304 installed on the disc support pin. It makes easier to discharge the product
when cut. It can only be used with the following discs DTV, DT2 - 3 - 4 - 7 - 9, DF1 - 2 - 3 - 4
(Fig. n°6)
Discs holder
: made of plasticised steel for alimentary use, it is a useful collector for discs. (Fig.n°7).
(Fig. n°4).
Fig. n°5 - Bowl fitted with microswitch
Fig. n°6 - Discharging spatula
Fig. n°7 - Discs holder
5
