Univex SRM8 Installation Manual

OPERATORS

SRM8

MANUAL

MIXER

Persons under the age of 18 are not permitted to operate or have accessibility to operate this

equipment per U.S. Department of Labor Employment Standards Administration

Fact Sheet No. ESA91-3.

SRM8/1009

0011058

ED1

Welcome to Univex

Thank you for purchasing this Univex Product.

Your new SRM8 mixer has been designed with advanced performance and safety features that make it
an excellent addition to your food preparation equipment. Like all Univex mixers, slicers, meat grinders and
accessories, this mixer is engineered to provide years of reliable service.

If you have any questions concerning the operation of this unit, or if we can be of further assistance, please
call our Customer Service Department for the location of your nearest service representative.

Univex Customer Service:

USA & Canada 800-256-6358

International 603-893-6191

Or visit us on-line at www.univexcorp.com under service agents.

SAFETY IS OUR TOP PRIORITY

READ AND MAKE SURE THAT YOU UNDERSTAND THE INSTRUCTIONS AND SAFETY

WARNINGS IN THIS BOOKLET BEFORE ATTEMPTING TO OPERATE THE MIXER OR

ATTACHMENTS.

NEVER PUT FINGERS OR HANDS IN THE BOWL WHILE THE MIXER IS OPERATING OR

SERIOUS INJURY COULD RESULT.

NEVER ATTEMPT TO CLEAR A JAMMED OR STALLED MIXER WITHOUT SHUTTING THE

POWER OFF AND DISCONNECTING THE ELECTRICAL POWER SUPPLY CORD.

DO NOT OPERATE THIS MIXER WITHOUT THE BOWL IN PLACE

DO NOT OPERATE THIS MIXER WITHOUT THE SWING RING™ SAFETY GUARD IN PLACE.

Page 1

TABLE OF CONTENTS

DESCRIPTION PAGE

Important Safety Warnings ..............................................................................................................1

Table of Contents .............................................................................................................................2

List of Illustrations ...........................................................................................................................2

Inspection and Installation ...............................................................................................................4

Operating Instructions......................................................................................................................5

Securing the Bowl and Installing the Mixer Agitators.....................................................................5

Using the Bowl Lift .........................................................................................................................5

Start / Stop Controls.........................................................................................................................6

Setting the Timer..............................................................................................................................6

Speed Control...................................................................................................................................6

Mixer Capacity Chart and Recommended Agitators .......................................................................7

Dough Absorption Ratio ..................................................................................................................8

Agitators and Bowls for the Mixer ..................................................................................................9

Cleaning and Preventive Maintenance...........................................................................................10

Warranty..........................................................................................................................Back Cover

ILLUSTRATION

Figure 1 Overall View of Mixer ...................................................................................................3

Figure 2 Electrical Wiring Diagram ...........................................................................................12

PAGE

Page 2

OVERALL VIEW OF MIXER

FIGURE 1

8

3

6

2

1

13

12

1. Beater Head Shaft 8. Top Cover

4

7

5

9

10

14

2. Safety Ring 9. Rear Access Panel

3. Bowl Lift Handle 10. Serial Number Plate
(on rear access panel)

4. Speed Control Knob 11. Cord
(NOT SHOWN)

5. Timer Knob (optional) 12. Bowl

6. Start Push-Button (Green) 13. Bowl Support

7. Stop Push-Button (Red) 14. Bowl Support Pin
