Universal Remote Control, Inc.
www.universalremote.com
OCE-0004A Rev 03(05/14/02)
Operating Manual
for 2 in 1 Cable TV
Remote Control
UR-J22TVE
This remote control is preprogrammed to
operate CABLE Box. Please program it
for your TV by following the instructions
shown below.
The remote control uses AAA batteries.
Please be sure to match the batteries
with the (+) and (
-
) markings inside the
battery compartment during installation.
The remote control is
preprogrammed to
control VOLUME and MUTE functions
through your TV. To switch VOLUME and
MUTE functions to your Cable Box:
STEP1 Press [CATV] and [MUTE] buttons
simultaneously until red light is on.
STEP2 Press [VOLUME +] button.
STEP3 Press [CATV] button.
To return to the TV’s VOLUME, press [TV]
button.
*Tip: Red light will blink twice.
Set-up for advanced functions
A. To turn on your TV and Cable at the
same time with
CATV button:
STEP1 Press [CATV] and [0] buttons
simultaneously until the red light is on.
STEP2 Press [CH +] button.
Set-up for your Cable Box
The remote control is
preprogrammed
to control your cable box. If it does not
work properly, please set-up the right
code by using the three-digit code or
searching method.
If you have a TV with a remote control,
we recommend that you plug its power
cord directly into a wall outlet if
available (your cable installer may
select an alternate setup)
Operation
If red light does not blink when you
press keys the operation is intermittent:
Make sure the batteries are inserted
correctly.
Replace old batteries with two new
AAA batteries. Please do not mix old
batteries with new ones.
Instructions
Batteries
Programming your remote
control
Set-up for your VOLUME
control
Helpful hints
STEP3 Point the remote control toward
the TV and enter the three-digit code
from the code table. If there is more than
one code number assigned to your TV
brand, try one code number at a time
until the TV turns off right after you
entered the number.
Searching Method
Press [CH +] button and hold until the TV
turns off. As soon as the TV turns off,
release [CH+] button.
*Tip : You can confirm the power off and
on by pressing [MUTE] button.
STEP4 Press [TV] button to store the
three-digit code.
*Tip: Red light will blink twice.
Three-digit code :
Setup for your cable box
No setup is required. The remote control is
preprogrammed to operate your cable box.
Setup for your TV
Find your TV brand and its three-digit
code on the back of this manual.
If the TV brand is not listed, please use
the Searching Method in STEP3 .
STEP1 Turn on your TV manually.
*Tip :
If you have RCA TV, don’t turn on
the TV.
STEP2 Press [TV] and [MUTE] buttons
simultaneously until the red light is on.
*Tip: Red light will blink twice.
The [CATV] button sends out the TV and
CABLE power commands if you press
the [CATV] button.
To return to the original function, press the
[CH-] button in the STEP2 .
B. Recalling the TV Three-digit code :
STEP1 Press [TV] and [MUTE] buttons
simultaneously until the red light is on.
STEP2 Press [VOLUME -] button.
The red light will blink a number of times
indicating the number of each digit of the
code. Each digit is separated by one
second interval of red light being off.
*Tip: One blink, three blinks and 10 blinks,
indicates the code number 130.
Install two AAA alkaline
batteries as shown here
Open the battery cover
BRAND NAME CODE NUMBER (3 DIGIT) LIST
TV
Remote Converter Converter Model
Code No
CABLE
Three-digit Code Table
MARANTZ 164 070 232
MARTA 242
MATSUI 164
MEMOREX 004 007 072 232 234 241 242
MEI 232
METZ 088
MGA 024 070 004 042
MINERVA 088
MITSUBISHI 109 024 042 004 040 146 028
124 226 247
MTC 070 004 062 101 209 229 234 235
MULTITECH 234
NAD 015 025
NEC 070 130 134 040 056 007 019
024 004 213
NIKEI 043
ONKING 043
ONWA 043
OPTONICA 019 081
ORION 096 201 202 203 204 205
PANASONIC 034 056 080 164 206 232 240
PENNEY 065 160 004 008 070 143 030 221
PENTAX 232
PHILCO 070 003 004 024 056 059 060 063
064 127 143 164 232 234
PHILIPS 164 005 038 093 127 070 003 004
059 232 234 242
PILOT 242
PIONEER 025 023 135 176 004 018 070
PORTLAND 004 143
PROSCAN 144 160 161 167
PROTON 004 058 143 171 173 193 131
QUASAR 034 056 232 240
RADIO SHACK
004 019 127 143 043 244
RCA
160 161 144 156 065 070 004
023 024 056 074 152 221 232
234 235
REALISTIC 007 019 232 234 235 242
RICO 237
RUNCO 072 169 073 130 179 180 181
SAMPO 070 004 058 218 220
SAMSUNG 004 101 127 133 143 160 089
105 070 233 235
BRAND NAME CODE NUMBER (3 DIGIT) LIST
TV
SANYO 007 053 057 082 020 212
SCOTT 004 005 028 043 048 143
SEARS 004 007 015 028 030 057 082 094
143 160 242
SELECO 189
SHARP 081 014 019 028 004 022 081 143
175 029 232 245
SIGNATURE 072 234
SONY 001 085 126 139 232 236 237
SOUNDESIGN
003 004 028 043 234
SPECTRICON 112
SSS 004 043
SUPRE MACY
002
SYLVANIA 070 003 059 060 063 064 127 160
164 044 056 210 232 234
SYMPHONICS
052 234
TANDY 081 234
TATUNG 056 062 209
TEAC 234
TECHNICS 034 080 232 240
TECHWOOD 004
TEKNIKA 002 003 004 024 028 043 072 101
143 103 227 232 234 242
TELERENT 072
TERA 172
TMK 004
TOSHIBA 015 030 007 040 062 101
TOTEVISION 143 235 242
UNIVERSAL 008 009
UNITECH 235
VIDEO CONCEPTS
146 234
VIDEOSONIC 235
VIDIKRON 174 188
VIDTECH 004
WESTING HOUSE
076
WARDS 004 064 164 008 009 019 028 060
061 063 072 074 143 070 224 225
232 234 235
YAMAHA 004 070 234
YORK 004
YUPITERU 043
ZENITH 073 072 095 103 234 237 241 242
ZONDA 112
BRAND NAME CODE NUMBER (3 DIGIT) LIST
TV
A MARK 112 143
ADMIRAL 072 081 160 161
AIWA 234
AKAI 070 146 004
AMPRO 073 167 241
ANAM 043 054 055 056 080 112 131 232
AOC 058 070 004 112 222
AUDIOVOX 076 103
CANDLE 070 002 003 004
CANON 232
CAPEHART 058
CETRONIC 043
CITIZEN 070 002 003 004 101 103 143
CLASSIC 043
CONCERTO 004
CONTEC 043 051 207 230
CORONADO 143
CRAIG 043 054 028 235
CROWN 043 143
CURTIS MATHES
070 004 101 143 232
CXC 043
DAEWOO 076 103 055 004 127 143 016 043
044 125 120 214 215 229 231 243
DAYTRON 004 143
DWIN 161
DYNASTY 043
DYNATECH 062 209 234
ELECTROHOME
024 076 143
EMERSON 028 043 048 155 005 076 096 004
051 143 151 153 154 216 217 230
232 234 242 246
ENVISION 070
FISHER 007 05
FUNAI 028 043 234
FUTURETECH
043
BRAND NAME CODE NUMBER (3 DIGIT) LIST
TV
GE 160 161 070 073 130 144 004 008
009 034 056 074 091 155 223 224
232 241
GOLDSTAR 004 106 119 110 112 113 127 143
242 244
GO VIDEO 235
HALL MARK 004
HARMAN KARDON
211
HITACHI 163 004 007 009 011 072 010 012
023 075 143 158 208 234
INFINITY 164
INKEL 129
INSTANTREPLAY
232
JBL 164 209
JCL 232
JCP 070
JCPENNY 004 008 024 030 065 101 143 160
156 235 242
JENSEN 013
JVC 038 001 034 083 232 238
KENWOOD 001 070 234
KLOSS 002 059
KMC 219
KTV 070 043 143 154
LG 004 106 119 110 112 113 127 143
242 244
LLOYD 234
LODGENET 072
LOGIK 072
LUXMAN 004
LXI 007 015 052 081 160 164 234
MAGNAVOX 070 003 004 022 059 060 061 063
064 127 164 094 160 056 232 234
239
MAGIN 235
UR-J22TVE Motorola CFT2200 011
