Universal Remote Control URC 4021 User Manual

UNIVERSAL

REMOTE CONTROL

REPLACES REMOTES

DVD

VCR/PVR

CBL/SAT

EASY SETUP

DIGITAL READY*

FAVORITE CHANNEL

MASTER POWER KEY*

LIMITED

LIFETIME

WARRANTY

*See back for details

URC 4021

USES 2 AAA BATTERIES

(NOT INCLUDED)

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features And Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Key Charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Device Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Programming Device Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Searching For Your Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Checking The Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Programming A Master Power Macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Programming The Power Key For The Master Power Macro . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Operating The Master Power Macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Clearing The Master Power Macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Re-Assigning Device Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Using Channel Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Programming Favorite Channel Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Locking Volume Control To One Mode

(Global Volume Lock). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Unlocking Volume Control For A Single Device

(Individual Volume Unlock). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Unlocking All Volume Control

(Restoring Default Setting ) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Clearing Custom Programming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Restoring Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Instructions To The User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Limited Lifetime Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Additional Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Manufacturer’s Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setup Codes For Cable Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setup Codes For Cable Box/PVR (or DVR) Combos. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setup Codes For DVD Players . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setup Codes For DVD Player/VCR Combos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setup Codes For PVRs (or DVRs).. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Setup Codes For Satellite Receivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Setup Codes For Satellite Receiver/PVR (or DVR) Combos. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Setup Codes For TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Setup Codes For TV/DVD Player Combos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Setup Codes For TV/VCR Combos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Setup Codes For TV/VCR/DVD Player Combos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Setup Codes For VCRs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

INTRODUCTION

The One ForAll 4 Device Universal Remote Control (URC-4021) is designed to remotely operate up to four home entertainment devices.It also featuresintuitive and easy-to-use keys for instant control of DVD and PVR (or DVR) components. Moreover,its sophisticated technology will allowyou to consolidate your original home entertainment remote controls into one easy-to-use product. Advanced features include:

• Intuitive buttonstoallow easy access to functions and menus on your DVD player,PVR(or DVR),and Cable/Satellite devices

• Direct code setup for easy device programming

• Step-and-Set codesearch and CodeVerificationfor an alternate wayto pro- gram devices

• Power Macrofor masteron/off control of all of your equipment with a single keystroke

• Volume Lock/Unlock feature to lock or unlockthe volumecontrol to one mode or individual modes

• Device KeyRe-Assignmenttoremotely control a second (duplicate) device

• Channel Scan

• Color-codedkeys to quickly locate popularfunctions

• Extensive codelibrary for popular videodevices includingDVD players and PVRs (or DVRs)

and Favorite Channel Scan foreasy channelsurfing

The URC-4021 remote control requires two (2) new AAA alkaline batteries (not included) and some easy programming to control your devices. For best results,please read and perform all instructions listed here.Also, keep this guide for future reference.

FEATURES AND FUNCTIONS

Use the illustration below to locate featuresonthe One For All 4 Device Universal Remote Control (URC-4021)andthen study the KeyCharts (on the next twopages) to learn how they function.

To find outwhat type of devices can be controlled by each device keyafter programming, see the

Device Table on page 6.

Key Charts

When the LED (redlight) blinks,the remote controlis working and(after programming)issendingsignals.

Press VCR/PVR, DVD,CBL/SAT,or TV once to select a desired homeentertainmentdevice to control. Also see the Device Table on page 6.

Press POWER oncetoturn on or off the selected device. Formaster power control,see Programming A MasterPower Macro on page 10.

Use the keypad (1 ~ 9 and 0) to directly select channels (e.g.,009 or 031).

Use TV/VID to switchthe TV’s inputtoview TV or video programs.

Press ENTER onceafter entering the channel numberson some TVs.

Use GUIDE to display your selected device’s program guide or setup menu.

Press MENU once to displayyour selected device’s main menu.

Use INFO to display the current channel and program or on-screen directory.

Use EXIT to exit from your selected device’sguide or menu.

Use the Cursor Keys to move the cursor in the program guide and menu screens.

Use SELECT(OK)tochoose optionsfromyourselected device’smenuor guide.

Press LAST once to recall the last channel.

Use FAV to scan all channels,or after programming, to scan up to 10 favoritechannels.

Use CH▲ (orCH▼) to select the next higher (or lower) channel.

PressSUBTITLE/CConceto display(or turnoff) subtitlesor closedcaptions,if available onyour DVD playeror cable/satelliteservice.

Fora PVR (or DVR), press PVR MENU once to display a list of your recorded shows.

Press MUTE once to turn the soundoff or on.

Use VOL▲ (orVOL▼) to raise (or lower) the sound vol- ume.

Use REW,PLAY,FWD, PAUSE,or STOP to control yourVCR, PVR (orDVR),or DVD player.

For a DVD player,use SKIP F. or SKIP R. to viewthe next or previous chapter.

For a VCR,PVR (or DVR),or VOD (if available),use SCAN- or SCAN+ to quickly scan forward orback throughavideo program.UseREPLAY foran instantreplay.UseQUICK SKIPto advancethe videoprogram a presetamount (as setonyourdevice).

Press REC twice to recordaVCR or PVR (orDVR) program.

Use SLEEP to set the sleep timer on a selecteddevice if equipped with this feature.

UseSET for all programming sequences.

Device Table

NOTE: Please refertothe tablebelow whenperformingthe instructions in“Programming Device Control”on page 8.

Afterprogramming,theOneFor All 4 Device Universal Remote Control will be able to control the followingtypes of devices:

DEVICE KEY CONTROLS THESE TYPES OF DEVICES

• DVD Player

• TV/DVD Player Combo

• VCR/DVD Player Combo

• VCR

• TV/VCR Combo

• TV/VCR/DVD Player Combo

• VCR/DVD Player Combo

• PVR (or DVR)

• Cable Box (orConverter)

• Cable Box/PVR(or DVR)Combo

• SatelliteReceiver

• SatelliteReciver/PVR (orDVR) Combo

• Television

INSTALLING BATTERIES

❶

❸

❷

1. On the remote control’s back,push the tab and lift off the

battery cover.

2. Obtaintwo (2) new AAA alkaline batteries. Match the +

and – marks on the batteries to the + and – marks in the battery case,theninsert the new batteries.

3. Press the battery cover backinto place. The tab should

clickwhen the cover is locked.

4. Test the remote control by pressing anymodekey (e.g.,

TV).If the batteriesare insertedcorrectly, the LED (red

light) will blink.

NOTE: Whenbatteries need replacement,the remotecontrol will stopoperating.Remove the oldbatteriesand insert newones within 10 minutes to ensure all of your programming informationisrestored.

Battery Precautions: Do not mix old andnew batteries.• Do notmix alkaline, standard (carbon-zinc) or rechargeable (nickelcadmium)batteries.•Always remove old,weak or worn-out batteries promptly and recycle ordispose of them inaccordancewith Local and NationalRegulations.
