KP-4000 Installation Manual
Network Keypad
KP-4000 Installation Manual ©2010 Universal Remote Control, Inc.
The information in this manual is copyright protected. No part of this manual may be copied or reproduced in any form without prior written consent
from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN
THIS MANUAL.
The information in this manual may be subject to change without prior
notice.
Complete Control is a registered trademark of Universal Remote Control,
Inc.
All other brand or product names are trademarks or registered trademarks
of their respective companies or organizations.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
TABLE OF CONTENTS
Introduction 1
Features and Benefits 2
Parts Guide 2
Network Requirements and Power Options 3
Installation Notes 5
MAC Address Labels/Reset Button 5
Connections 5
IR OUT/RFTX-1 6
12V Power 7
In-Wall Installation 8
CCP MAC Address Discovery 9
Displaying the Settings Screen 10
Adjusting Sleep Settings 10
Button Light Settings 10
Setting Date and Time 10
Sound 11
Adjusting Brightness 11
System 11
Network 11
Factory Default 12
Exit 12
Frequently Asked Questions 13
Specifications 13
USA Limited Warranty Statement 14
Federal Communication Commission Interference Statement
15
Warning 15
FCC Caution 15
Page 1
KP-4000 NETWORK KEYPAD
Introduction
The KP-4000 is a Network Keypad with the ability to control audio
video components, energy management devices, multizone matrixes,
PCs, iPods, and whole house URC Lighting. MAC addressing enables
the use of multiple KP-4000’s and multiple MRX-1’s to control as
many components as needed throughout the house.
3. Self-adhesive “Flashers” affix to
the Infrared sensors on the front
panels of your client’s components. The Flashers relay commands to components. The flashers plug in to the MRX-1 rear
flasher line outputs via their 10
foot cables. The MRX-1can also
connect to components with rear
panel IR Inputs via its adjustable
IR Line Outputs.
IR Controlled Device
MRX-1 Network Base Station
Router
PoE Injector
1. The KP-4000 communicates over the LAN (Local Area Network)
to IP controlled components and the URC MRX-1 Network Base
Station.
2. The MRX-1 receives commands and controls the components via IR or Serial.
Page 2
KP-4000 NETWORK KEYPAD
Features and Benefits
2-Way IP and RS-232 Home Theater AVRS
Via the unique URC 2-Way database, installers can drag and drop
2-Way pre-programmed modules into any KP-4000 for multi-zone
receivers with either IP or via the MRX-1, RS-232 control.
2-Way IP Control of Media on PCs and iPods
The high speed of the LAN enables the KP-4000 to display lists of
artists, albums or songs and to display the cover art of the selected
album on the Now Playing screen of the remote control from the
PSX-2 Personal Server or from a PC.
User Configurable Internet RSS for News, Sports, Stocks and
Weather
The well known URC modules for News, Sports, Weather and
Stocks are all available updated to the KP-4000 screen and of
course, are completely user set.
User set Scenes for URC Lighting via RFTX-1
Your client can fully control the lighting in their home without
expensive black boxes and exotic wiring. A lighting system can be
as simple as a single URC RF lamp dimmer on a lamp that they’d
love to control without getting out of a chair.The KP-4000’s optional
RFTX-1 transmitter directly controls URC RF Dimmers and
Switches. Your client can brighten, dim, and recall scenes, and they
can store new scenes whenever they like, without a PC or a programmer. They simply manually adjust each dimmer to the new setting, then press and hold a scene button on their KP-4000 (just like
storing radio stations in a car radio!).
Local Control via RFTX-1 & MRF Base Station
Via an optional RFTX-1 transmitter, low cost wireless control of a
local stack of components can be done via a standard MSC-400,
MRF-350 or MRF-260.
Parts Guide
The KP-4000 Network Keypad includes:
1 - KP-4000 Network Base Station
1 - Owner’s Manual
4 - Screws for mounting to a wall box
Network Requirements and Power Options
The KP-4000 must be connected to the same Local Area Network as
the MRX-1 to function correctly. Additionally, in order for your
client to enjoy internet features such as RSS feeds, the Local Area
Network must be connected to the Internet.
You have three options to power the KP-4000. The KP-4000 is a PoE
(power over ethernet) device and can be powered as shown by
either a PoE switch or a PoE injector (PoE injectors may be separately ordered from URC). This has the advantage that a single CAT 5
cable to the KP-4000 supplies all connections needed!
However, should you be installing a KP-4000 in a system where it is
convenient to run an additional two conductor wire to the KP-4000
for power, you may power a KP-4000 from any 12V wall adapter
with a 1 amp rating (12v wall adapters may be separately ordered
from URC).
Option 1: PoE Switch
Page 3
KP-4000 NETWORK KEYPAD
PoE Switch
(not included)
KP-4000
Router
1. Connect the CAT 5 cable (RJ45) to the LAN connection on the
rear of the KP-4000.
2. Plug the other end of the CAT 5 cable to the PoE switch (not
included), which will power the KP-4000 and ensure that the
PoE switch is properly configured and connected to the Router.
KP-4000 NETWORK KEYPAD
Page 4
Option 2: PoE Injector
KP-4000
KP-4000
Router
PoE Injector
(not included)
Power Supply
(not included)
1. Splice a 12V 1Amp Power Adapter (not included) and connect to
the rear Power input.
2. For network connections to IP devices, MRX-1 and the internet,
connect a CAT 5 cable (RJ-45) to the LAN connection on the rear
of the KP-4000 and plug the other end into the Router.
Option 3: No PoE: 12 Volt Power Supply
1. Connect the CAT 5 cable (RJ45) to the LAN connection on the
rear of the KP-4000.
2. Plug the other end of the CAT 5 cable to the PoE Injector which
will power the KP-4000.
3. Connect the PoE injector (not included) to the Router.
Router
Page 5
KP-4000 NETWORK KEYPAD
12V Power
(not required in a PoE
installation)
LAN PoE RJ-45
(Connects KP-4000 to Network)
IR OUT/RFTX-1
(only required if
URC RF Lighting,
RF Base or a wired
emitter is needed)
Installation Notes
MAC Address Labels/Reset Button
The KP-4000 has a magnetic cover, simply pull it away from the
keypad’s main body to remove.
Reset Button: Press this button to reset the keypad.
MAC address Labels: Tear off the 2nd label and stick it to your Job
Documentation indicating which room the KP-4000 is installed.
You’ll need the MAC address when you program the KP-4000.
Connections
In most installations, you will power the KP-4000
via a single CAT 5 cable connected to the network.
The KP-4000 is PoE, so you can power it from either
a PoE power injector or any PoE switch.
LAN PoE RJ-45: Plug an Ethernet RJ45 cable into a PoE switch or
PoE injector (available via the URC Toolbox) to power the KP-4000
or directly connect to a LAN Router if a Power Adapter has been
connected.
Reset Button
MAC Address Label
IR OUT/RFTX-1
This 3 Conductor removable connector can be used for either an
RFTX-1 RF transmitter or for a URC IR emitter.
RFTX-1 Connections
In installations with URC RF lighting or a standard RF base station,
you will need to add an RFTX-1 RF Transmitter to the KP-4000.
Range can wildly vary, depending on the structure of the wall the
KP-4000 is installed in. You can make the RF range much more predictable by installing the RFTX-1 with the MRX-1 in most homes
and this is the recommended method! However in some installations, you may achieve satisfactory results from an RFTX-1 inside
the wall cavity. To connect use the following terminations to the KP4000:
Page 6
KP-4000 NETWORK KEYPAD
Data – Connect the white wire which is connected to the Tip of the 3.5mm plug
GND – Connect the black wire which is connected to the bottom sleeve(base) of the
3.5mm plug
5V – Connect the red wire which is connected to the ring of the 3.5mm plug
IR Emitter Connection
Should you need to drive an IR emitter directly from the KP-4000,
you connect the emitter to Data and GND. A URC emitter is wired
with a cable that has a silver and a copper conductor. If you have
another brand of emitter, reverse polarity if the first attempt doesn’t
work. URC emitters can be successfully powered over long cable
lengths if the wire gauge is at least 16 gauge.
Data – Silver Conductor
GND – Copper Conductor
Page 7
12V Power
This 2 conductor removable connector can be used to power the
KP-4000 with a wall adapter in an installation where PoE is not
available. You must run an additional two conductor cable to the
KP-4000 to utilize this feature. Connect a spliced power adapter
12Volt, 1AMP with the polarity (Positive & Negative) connected correctly.
12V 1A – Connect to the + conductor of a 12V, 1 Amp DC wall adapter.
GND – Connect to the – conductor of a 12V, 1 Amp DC wall adapter.
KP-4000 NETWORK KEYPAD
-
+
Page 8
KP-4000 NETWORK KEYPAD
1. The KP-4000 installs in a standard two gang box. If in a retrofit
installation, cut in and install a standard two gang p-ring or retro
fit box (not included) into the wall.
2. Make connections for IR Out/RFTX-1, LAN, or Power Supply. For
connections, refer to page 5.
3. Next, secure KP-4000 onto p-ring or retro fit box with the 4
included screws.
4. Finally attach the magnetic cover plate to the four screws secured
into the KP-4000.
Two-Gang
Wall Box
KP-4000
Magnetic
cover plate
In-Wall Installation
Page 9
CCP MAC Address Discovery
1.Once the KP-4000 has been connected to the network, notate the
MAC address located on the KP-4000 under the magnetic cover
plate.
2. Open the Complete Control Program editor.
3. Select the Program tab then press Configure Home.
4. Add a KP-4000 Network Keypad from the Remotes section and
the properties window opens. Note: Adding a MRX-1 base station
to communicate with a KP-4000 is recommended.
5. Within the Network Information field, press the Discover button
to select the unique MAC address of your unit.
6. The Discover window opens to reveal KP-4000’s connected to the
network. Highlight the MAC address which matches the KP4000’s label. Then press Apply.
7. Begin programming your customer’s file.
KP-4000 NETWORK KEYPAD
Page 10
KP-4000 NETWORK KEYPAD
Displaying the Settings Screen
You can adjust the settings of the
KP-4000 whenever you like by pressing
and holding both the MAIN and MUTE
buttons for five seconds. When you do,
the screen will change to the SETTINGS
screen. If you do not press any button on
the SETTINGS screen within 1 minute,
the KP-4000 will time out and automatically return to normal operation.
Adjusting Sleep Settings
Conserve energy by configuring the
keypad to fall asleep after a specified
amount of time. Select a time from the
drop down list.
Button Light Settings
Conserve energy by opting to turn
off the LED lighting behind the buttons.
Setting Date and Time
Your KP-4000 may have been
programmed to display the date or time
on the touch screen. If you need to,
you can adjust the time displayed by
changing the settings on this screen. If
you live in a part of the country that
uses daylight savings time, check the
box next to: “Automatically adjust clock
for daylight saving”.
Page 11
KP-4000 NETWORK KEYPAD
Sound
Your KP-4000 may have been programmed to make sounds. This is optional, and some professional
installers may prefer to keep it silent.
However, you can adjust the volume to
any level you like by touching and
dragging the volume control here.
Adjusting Brightness
Simply touch and drag the brightness
slider to the desired level.
System
The System Information screen displays
data about your KP-4000’s operating
system, memory etc.
Network
The Network screen displays network
information about your KP-4000 and
the network it is connect to.
Factory Default
WARNING! Only use this button
when instructed to by Technical
Support. It resets the memory of the
KP-4000 to the factory condition. All
your programming will be lost!
Exit
When you have finished adjusting Settings, simply tap the EXIT button to return to normal operation.
Page 12
KP-4000 NETWORK KEYPAD
Page 13
KP-4000 NETWORK KEYPAD
Frequently Asked Questions
I am unable to control my URC Lighting Dimmer/Switch with the
KP-4000. Now what?
Make sure the RF switch on the RFTX-1 is set to the correct frequency for the URC Dimmer or Switch. URC Lighting Models
MRFA is 418MHz and MRFB is 433MHz.
How do I update the firmware?
Periodically there will be firmware updates for the KP-4000. Make
sure it is connected to the Network then open CCP and click on the
Live Update button located within the Communications tab.
How do I reset a KP-4000?
Remove the front cover of the KP-4000. Use a pen or pointy device
to depress the button and reset the unit.
How do I erase a KP-4000?
Press and hold the Main + Mute hard buttons for 3 seconds, then
press and hold the Factory Default button for 5 seconds. Release
the button, a popup window appears asking: “Do you really want
to erase the user’s settings and reformat the storage disc?” Select
“Yes” to reformat, and “No” to return back to the KP-4000 Settings
Screen.
Specifications
Microprocessor: 190MHz RISC
Memory: 128MB Flash
Devices: Supports up to 255 Devices
Pages: Supports up to 255 Pages on each Device
Macro Capability: Up to 255 steps
Network: One 10/100 Ethernet port (PoE)
LCD : 3.5 inch ( 320x240 )
Weight: 9.84 oz
Size: 5.75” x 4.7” x 1.8”
Power : Standard PoE Injector, PoE Switch or 12V DC 1A Adapter
(All purchased separately)
Page 14
USA Limited Warranty Statement
Your Universal Remote Control, when delivered to you in new
condition, is warranted against defects in materials or workmanship as follows: UNIVERSAL REMOTE CONTROL, INC.
warrants this product against defects in material or workmanship for a period of one (1) year and as set forth below.
Universal Remote Control will, at its sole option, repair the
product using new or comparable rebuilt parts, or exchange the
product for a comparable new or rebuilt product. In the event
of a defect, these are your exclusive remedies.
This Limited Warranty covers only the hardware components
packaged with the Product. It does not cover technical assistance for hardware or software usage and it does not cover any
software products whether or not contained in the Product; any
such software is provided "AS IS" unless expressly provided for
in any enclosed software Limited Warranty.
To obtain warranty service, you must deliver the product,
freight prepaid, in its original packaging or packaging affording
adequate protection to Universal Remote Control at the address
provided in the Owner's Manual. It is your responsibility to
backup any macro programming, artwork, software or other
materials that may have been programmed into your unit. It is
likely that such data, software, or other materials will be lost
during service and Universal Remote Control will not be
responsible for any such damage or loss. A dated purchase
receipt, Bill of Sale, Installation Contract or other verifiable
Proof of Purchase is required. For product support and other
important information visit Universal Remote Control's website:
http://www.UniversalRemoteControl.com or call the Universal
Remote Control Customer Service Center (914) 835-4484.
This Limited Warranty only covers product issues caused by
defects in material or workmanship during ordinary consumer
use. It does not cover product issues caused by any other reason, including but not limited to product issues due to commercial use, acts of God, third-party installation, misuse, limitations of technology, or modification of or to any part of the
Universal Remote Control product. This Limited Warranty does
not cover Universal Remote Control products sold as USED, AS
IS, REFURBISHED, so-called "B STOCK" or consumables (such
as batteries). This Limited Warranty is invalid if the factoryapplied serial number has been altered or removed from the
product. This Limited Warranty is valid only in the United States
of America. This Limited Warranty specifically excludes products
sold by unauthorized resellers.
KP-4000 NETWORK KEYPAD
Page 15
Federal Communication Commission Interference
Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one more of the following measures:
u Reorient or relocate the receiving antenna.
u Increase the separation between the equipment and receiver.
u Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
u Consult the dealer or an experienced radio/TV technician for
help.
Warning!
Changes or modifications not expressly approved by the manufacturer could
void the user's authority to operate the equipment.
Note : The manufacturer is not responsible for any Radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications
could void the user's authority to operate the equipment.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
KP-4000 NETWORK KEYPAD
Page 16
MEMO
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
www.universalremote.com
OCE-0080A Rev.01
Loading...
