Universal Electronics PVR 5 User Manual
ATLAS
DVR/PVR 5-DEVICE
Universal Remote Control
User’s Guide
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 1
TABLE OF CONTENTS
Introduction
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features And Functions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Key Charts
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Device Table
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing Batteries
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Programming Device Control
. . . . . . . . . . . . . . . . . . . . . . . 10
Programming TV/VCR Combo Control
. . . . . . . . . . . . . . . 12
Searching For Your Code
. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Checking The Codes
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Programming Channel Control Lock
. . . . . . . . . . . . . . . . . 15
To De-Activate Channel Control Lock
. . . . . . . . . . . . . . . . . . . 15
To Re-Activate Channel Control Lock
. . . . . . . . . . . . . . . . . . . 15
Programming ID Lock
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Programming“Tune-In” Keys For Specific Channels
. . . 16
To Program A “Tune-In” Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
To Clear A “Tune-In” Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using The Master Power Key
. . . . . . . . . . . . . . . . . . . . . . . . 18
To Program The Master Power Key . . . . . . . . . . . . . . . . . . . . . . . 18
To Operate The Master Power Key . . . . . . . . . . . . . . . . . . . . . . . 18
To Clear The Master Power Key . . . . . . . . . . . . . . . . . . . . . . . . . 19
Re-Assigning Device Keys
. . . . . . . . . . . . . . . . . . . . . . . . . 19
Changing Volume Lock
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
To Unlock Volume Control For A Single Device
(Individual Volume Unlock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
To Unlock All Volume Control
(Global Volume Unlock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
To Lock Volume Control To One Mode
(Global Volume Lock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Instructions To The User
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Additional Information
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Manufacturer’s Codes
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Setup Codes For Audio Amplifiers . . . . . . . . . . . . . . . . . . . . . . . 24
Setup Codes For Audio Receivers . . . . . . . . . . . . . . . . . . . . . . . 25
Setup Codes For Cable Boxes (Converters) . . . . . . . . . . . . . . . . 27
Setup Codes For DVD Players. . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Setup Codes For PVRs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Setup Codes For Satellite Receivers . . . . . . . . . . . . . . . . . . . . . 31
Setup Codes For TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Setup Codes For TV/VCR Combos . . . . . . . . . . . . . . . . . . . . . . . 36
Setup Codes For VCRs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 2
INTRODUCTION
The Atlas DVR/PVR 5-Device Universal Remote Control
by Universal Electronics is our latest generation universal
remote control. Its sophisticated technology allows you to
consolidate up to five of your original home entertainment
remote controls into one easy-to-use product. Moreover,it’s
packed with advanced features such as:
• Preprogrammed control to operate the cable converter
supplied by your cable service provider
• Dedicated keys to control popular functions on your
DVR/PVR (Digital/Personal Video Recorder)
• Programmable Master Power key for master on/off
control of your home entertainment equipment with a
single keystroke
• Instant “Tune-In”keys for assignment to your
favorite channels
• Channel Lock to lock channel selection only to the
cable converter
• Volume Lock to lock volume controls to one mode or
individual modes
• Device Key Re-Assignment to remotely control
a second (duplicate) device
• Code Search to help program control of older or
discontinued components
• Color-coded keys to quickly locate popular functions
• Code library for popular video and audio devices
Before using the product,you will need to install the
enclosed batteries and also perform some programming
to operate the specific home entertainment devices you
wish to control.
Please follow the instructions detailed in this manual to
set up the unit and then start enjoying your new remote
control and cable service.
3
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 3
FEATURES AND FUNCTIONS
Use the illustration below to locate features on the
Atlas DVR/PVR 5-Device Universal Remote Control and
then study the Key Charts (on the next three pages) to
learn how they function.
To find out what type of devices can be controlled by each
device key after programming, see the Device Table on
page 8.
4
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 4
Key Charts
Use SETUP for all programming
sequences.
Press PWR once to turn on or
off a home entertainment device.
For MASTER POWER control, see
Using The Master Power Key on
page 18.
Press AUX,DVD,AUD, TV,or CBL
once to select a home entertainment device to control.Also see
the Device Table on page 8.
Each device key has an embedded
LED (red light) that blinks upon
selection and indicates the remote
control is working and (after programming) is sending signals.
Use GUIDE to display the program
guide.
Press SETTINGS once to display
available interactive services.
Use INFO to display the current
channel and program information.
Use DAY+ (or DAY-) to move a day
forward (or back) on your cable
converter’s program guide.
Use the Cursor keys to move the
cursor in the program guide and
menu screens and to navigate
within the interactive service.
Use OK/SELECT to choose options,
PPV events,and to tune programs
from the program guide.
Use PAGE+ (or PAGE-) to page up
(or page down) through menu
screens and the program guide.
Use EXIT to exit out of your cable
converter’s menu and guide.
Use A,B,or C to access additional
cable features (see your cable
converter’s manual).
continued on next page...
5
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 5
FEATURES AND FUNCTIONS
Key Charts (continued)
Use VOL+ (or VOL-) to raise (or
lower) the audio volume.
Use FAV to cycle through your
favorite channels stored in your
cable converter.
Use CH+ (or CH-) to select the
next higher (or lower) channel.
For DVD players, use these keys to
skip forward (or reverse) through
chapters.
For amplifiers/receivers, use these
keys to select the next higher (or
lower) preset station.
Press MUTE once to turn the
sound off or on.
Press LAST once to recall the last
channel.
Reserved for use as “Tune-In”keys
(see page 16).
Use to command your PVR to
instantly replay the last
7 seconds of a program you are
watching.
Press LIST once to display a list
of recorded shows on your PVR.
Press LIVE to return to watching
live TV.
In all modes except CBL,use REW,
PLAY,FFWD, STOP,and PAUSE to
control a VCR, DVD player, or a
PVR (after selecting a desired
device).To record in the VCR
mode, press REC twice.
In the CBL mode, use above keys
to control DVR/PVR functions of
the set-top box.
6
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 6
Use the keypad numbers (1 ~9,
and 0) to directly tune channels
(e.g., 09).For amplifiers/receivers,
use the keypad numbers to select
inputs 1 through 10.
Press HD/ZOOM once to change
the aspect ratio of the show you
are watching. (Not available on all
set-top boxes).
Use PIP ON-OFF to switch the
Picture-In-Picture feature on or
off (if available on your TV or
cable service).
Use PIP SWAP to switch images
and sound between the main and
window pictures.
Use PIP MOVE to move the window
picture to different positions in the
main picture.
Use PIP CH+ (or CH-) to select
the next higher (or lower) PIP
channel.
In the CBL mode, use VIDEO
SOURCE to view other video
sources (A or B) instead of cable.
In all other modes, use VIDEO
SOURCE to watch TV or video
programs on a desired device. For
amplifiers/receivers, use VIDEO
SOURCE to select an input source.
7
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 7
FEATURES AND FUNCTIONS (continued)
Device Table
NOTE: Please refer to the table below when performing the
instructions in “Programming Device Control” on page 10 or
“Programming TV/ VCR Combo Control”on page 12.
After programming,the Atlas DVR/PVR 5-Device
Universal Remote Control will be able to control the
following types of devices:
8
DEVICE KEY CONTROLS THESE TYPES OF DEVICES
VCR, TV/VCR Combo, PVR
(Personal Video Recorder), or
extra DVD Player
DVD Player
Audio Amplifier,Tuner, or
Receiver
Tel e v i s i o n
Cable Box (Converter) or
Satellite Receiver
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 8
INSTALLING BATTERIES
1. On the back of the remote control,push the
tab and lift off the battery cover.
2. Locate the two (2) enclosed AA batteries.
Match the + and – marks with those in the
battery case, then insert them.
3. Align the cover’s keys with the case’s holes
and press the cover back into place. The tab
should click when the cover is locked.
4. Test the remote control by pressing
any mode key (e.g.,TV). If the batteries are
inserted correctly, the LED (red light) will
blink once
NOTE:When batteries need replacement,the remote control will
cease to operate. Replace the batteries and the unit will be restored
to its full functionality,complete with your favorite settings.
9
❶
❸
❷
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 9
PROGRAMMING DEVICE CONTROL
The Atlas DVR/PVR 5-Device Universal Remote Control
is preprogrammed to operate the Scientific Atlanta cable
box (converter) provided by your cable system,an RCA
TV, a Toshiba DVD player,an RCA VCR (as an AUX
device), and a Pioneer audio receiver. To control devices
other than the default brands, perform the following steps;
otherwise skip this section:
NOTES: For TV/VCR Combo control, skip this section and perform
the instructions on page 12.Also refer to the “Device Table”on
page 8 to find out which devices can be programmed onto each
device key.
If you have another brand of cable converter or a satellite receiver
you would like to control, you’ll first need to unlock the cable ID
Lock before changing the converter code – see “Programming ID
Lock” on page 16.
1. Turn on a device and,if applicable, insert
video media, (e.g.,cassette or disc).
NOTE: Please read steps 2 through 4 completely
before proceeding. Highlight or write down the codes
and device you wish to program before moving on to
step 2.
2. On the remote control, press a device key once
(i.e.., AUX,DVD,AUD, TV,or CBL); it will blink
once.Then press and hold SETUP until the
selected mode key blinks twice,then release
SETUP.
3. Use the Manufacturer’s Codes (starting on
page 24) to locate the the type of device and
brand name and then enter the first four-digit
code for your device.If performed correctly,
the selected mode key will blink twice.
NOTE: If the selected mode key emits a long blink,
the entry is invalid. Repeat steps 2 through 3 and try
entering the same code again.
4. Aim the remote control at the device and
press PWR once. The device should turn off.
If it does not, repeat steps 2 through 3, trying
each code for your brand until you find one
that works.If it still does not respond,try
searching for the code (see Searching For Your
Code on page 13).
NOTE: If the device does not have a
POWER
key,
press the (
Play
) key.
10
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 10
5. Repeat steps 1 through 4 for each device you
want the remote control to operate. For future
reference, write down each working device
code in the following boxes:
AUX Code
Device Type:_______________________
DVD Code
Device Type:_______________________
AUD Code
Device Type:_______________________
CBL Code
Device Type:_______________________
TV Code
11
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 11
PROGRAMMING TV/VCR COMBO CONTROL
If you own a TV/VCR Combo,perform the following
instructions to control this device:
1. Turn on your TV/VCR Combo and insert a
video cassette.
2. On the remote control,press AUX once; it will
blink once.Then press and hold SETUP until
the AUX key blinks twice, then release SETUP.
3. Use the Setup Codes For TV/VCR Combos (on
page 36) to locate the brand name and then
enter the first four-digit code for your TV/VCR
Combo.If you perform this procedure
correctly, the AUX key will blink twice.
NOTE: If the
AUX
key did not blink twice after
entering the code’s last digit, then repeat steps 2
through 3 and try entering the same code again.
If you’ve located a TV/VCR setup code that
works for your TV/VCR Combo and a separate
TV code is also listed, you’ll need to program
this code into the remote control to access
volume control (see Programming Device
Control on page 10).
4. Aim the remote control at your TV/VCR
Combo and press PWR once. The device
should turn off.If it does not respond,repeat
steps 2 through 3,trying each code listed for
your brand until you find one that works.
If it still does not respond,try searching for
the code (see Searching For Your Code on the
page 13).
5. For future reference, write down each working
device code in the boxes below:
TV/VCR Code
TV Code
(if used)
12
Atlas DVR-PVR M1055 8/12/04 4:51 PM Page 12
Loading...
