Page 1
Page 2
NevoSL provides fully-customizable control of all of your home theater
devices and digital media content. Its touch-sensitive screen is softwarebased, so you or your installer/integrator can include only those controls
.
SL
, your
you actually use. For more information on customizing Nevo
installer/integrator may refer to
NevoStudio Design Guide
Unpacking Nevo
SL
Packaging includes the following components:
NevoSL Universal
Controller
Software CD
OK
Touchscreen Stylus
SL
Once you unpack Nevo
:
1. Connect the power adapter to the
charging cradle and plug the adapter
into a wall outlet.
SL
Nevo
Adapter; varies
USB Cable
Charging
Cradle
AC Power
by country
2. Dock Nevo
SL
and begin charging the
battery. If it has not already been
charged, it will take 3-4 hours to
fully charge the battery the first
time.
Recharging Nevo
SL
NevoSL includes a Lithium-ion rechargeable battery. NevoSL beeps and the
battery indicator turns red when the battery is are running low. Dock Nevo
to charge the battery
To d oc k N ev o
SL
, simply set the remote in the charging cradle. When it is
.
correctly docked, the blue light will appear on the bottom of the remote.
About Battery Life
As with all battery-operated devices, battery life will vary depending on
use. It is a good practice to keep Nevo
are not using it. Your installer/integrator may refer to the
Design Guide
NevoSL User Manual
for information on changing power settings or please see the
.
SL
in its charging cradle when you
NevoStudio
SL
Page 3
Getting to Know Nevo
SL
NevoSL offers the following types of controls:
TOUCHSCREEN. To use the touchscreen, gently touch the buttons that
appear on it. If you prefer, slide the stylus from its storage port on the
bottom of the Nevo
SL
:
Using the stylus, gently tap buttons on
the touchscreen to control your home
theater system or digital media. You
may prefer to always use the stylus
when you are configuring settings. See
Stylus
NevoSL User Manual
for more
the
information on these settings.
NevoSL’s fully-customizable touch screens can be set up via NevoStudio. Your
installer/integrator may see
NevoStudio Design Guide
for more information
.
FRONT KEYS. The keys on
Nevo
your preference. An
additional set of unlabeled
keys (function keys) appear
immediately below the
touchscreen, above the hard
buttons. A label appears on
the touchscreen above them
to indicate the functions
assigned to those keys.
SL
can be customized to
OK
OK
Nevo
SL
has additional, non-
customizable keys on its sides:
LEFT SIDE RIGHT SIDE
Home Page of
Home Control
On/Off Switch
up=ON
down=OFF
Reset Button
USB Port
Backlight
Key;
hold to put
in standby
Toggle
Wheel
Page 4
• Press the Backlight On/Off key to turn the backlight on or off, regardless
of how you have set the backlight timing
• Move the toggle wheel up and down to move between the screens in the
Home Control section or through the media listings in the Media Control
section. Press the toggle wheel in to return to the first page of the page
collection in Home control or to make a selection in Media Control.
• Use the stylus to move the On/Off switch to Off if you will be away from
home for an extended period. This conserves your battery power.
• In the rare instance Nevo
SL
fails to operate properly, use the stylus to press
the Reset Button.
I
f your installer/integrator has enabled it, NevoSL provides Media Zones to
control digital media on a Windows XP
TM
PC with NevoMedia Manager or
other digital media server installed. For more information on NevoMedia
SL
Manager, see
Media Zones
.
N
evo
User Manual
. You will need a wireless home network to use
Caring for Nevo
SL
Use only the stylus to switch NevoSL on or off. Avoid using sharp objects.
C
lean your remote with a soft, damp cloth using a gentle, non-caustic cleaner
.
CAUTION: Do not use a caustic or abrasive cleaner. This may damage the
surface of your remote.
Where to Find More Information
NEVOSL USER MANUAL. This volume explains how to use the features
that appear on Nevo’s touchscreen to control your home entertainment
equipment. Since Nevo
features discussed in
only the ones your installer/integrator set up will be included.
NOTICE: Nevo, NevoStudio, NevoLink,
and NevoMedia are registered
trademarks or trademarks of Universal
Electronics Inc., in the United States
and/or other countries. Microsoft,
Windows, the Windows logo, and
Windows Media are registered
trademarks or trademarks of Microsoft
Corporation in the United States and/or
other countries. Other product and
company names may be trademarks of
their respective companies.
SL
is completely customizable, not all of the
SL
Nevo
User Manual
may appear on your NevoSL—
For more information, contact
your installer/integrator:
Installer/integrator, attach your
business card or business sticker
here
Copyright © 2005 Universal Electronics
All rights reserved.
Software Version 1.0
Document Version NSL00801
