Universal Electronics Millenium 4 User Manual
MILLENNIUM™4
Universal Remote Control
User’s Guide
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features And Functions . . . . . . . . . . . . . . . . . . . . . . 4
Key Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Programming TV Control . . . . . . . . . . . . . . . . . . . . . 8
Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . 8
Programming VCR/DVD Player Control. . . . . . . . 12
Setup Codes for VCRs. . . . . . . . . . . . . . . . . . . . . . 13
Setup Codes for DVD Players. . . . . . . . . . . . . . . . . 15
Programming TV/VCR Combo Control . . . . . . . . 16
Setup Codes for TV/VCRs . . . . . . . . . . . . . . . . . . . 17
Programming Cable Converter
(or DBS Receiver) Control . . . . . . . . . . . . . . . . . . . 18
To Unlock the CBL Key. . . . . . . . . . . . . . . . . . . . . . 18
To Program the CBL Key . . . . . . . . . . . . . . . . . . . . 19
To Lock the CBL Key . . . . . . . . . . . . . . . . . . . . . . . 20
Setup Codes for Cable Converters. . . . . . . . . . . . . 20
Setup Codes for DBS Receivers. . . . . . . . . . . . . . . 20
Programming Channel Control Lock . . . . . . . . . . 21
To Activate Channel Control Lock . . . . . . . . . . . . . 21
To De-Activate Channel Control Lock. . . . . . . . . . . 21
Programming Audio Control . . . . . . . . . . . . . . . . . 22
Setup Codes for Audio Amplifiers . . . . . . . . . . . . . 22
Setup Codes for Audio Receivers. . . . . . . . . . . . . . 23
Searching For Your Code . . . . . . . . . . . . . . . . . . . . 24
Checking The Codes . . . . . . . . . . . . . . . . . . . . . . . 25
Re-Assigning Device Keys . . . . . . . . . . . . . . . . . . 26
Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . 27
To Change Volume Lock to the Cable Mode . . . . . . 27
To Change Volume Lock to the TV Mode. . . . . . . . . 27
To Change Volume Lock to the VCR Mode . . . . . . . 27
To Change Volume Lock to the Audio Mode . . . . . . 28
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Additional Information . . . . . . . . . . . . . . . . . . . . . . 30
2
INTRODUCTION
The Universal Electronics Millennium™ 4 is our latest
generation universal remote control.It is designed with
sophisticated technology that will allow you to finally
consolidate the clutter of all of the original remote controls
in your home entertainment system.It’s packed with easyto-use features such as:
• Preprogrammed to operate the cable converter
supplied by your cable system provider
•Preprogrammed technology for easy setup
• Convenient hide-away sliding door to conceal
less-used functions
• Color-coded keys to quickly locate popular functions
• Cable ID Lock to lock your remote control for use only
with the cable converter
• Channel Lock to lock channel selection only to the
cable converter
• Code library for video and audio components
• Code Search to help program control of older or
discontinued components
Before you can use your new remote control,you will
need to program it to operate the specific home entertainment components you wish to control.Follow the
instructions detailed in this manual to set up your
Millennium 4 and enjoy your new remote control.
3
FEATURES AND FUNCTIONS
Use the illustration below to locate Millennium 4 features
and then study the Key Charts (on the next two pages) to
learn how they function.
4
Key Charts
The LED (red light) blinks to show that
the remote control is working and is
sending signals.
Press AUDIO, VCR,TV,or CBL once
to select a home entertainment
component to control.
Press POWER once to turn on or off
the selected home entertainment
component.
Use SETUP for all programming
sequences.
Use the keypad (0 ~ 9) to directly select
channels (e.g.,09 or 31).
Press MUTE once to turn sound off
or on.
Press ENTER once after entering channel
numbers on some TV models.
Use VOL+ (or VOL-) to raise (or lower)
the sound volume.
Use CH+ (or CH-) to select the next
higher (or lower) channel.
Press LAST once to recall the last channel
and to page back one screen in the
main menu.
Use FAV to cycle through your favorite
channels that are stored in your cable
converter.
Use GUIDE to display the program guide.
Press PPV/LOCK once to display the pay
per view menu or to lock out a specific
channel on your cable converter.
Use EXIT to exit out of your cable
converter’s menu and guide.
continued on next page...
5
FEATURES AND FUNCTIONS
Key Charts (continued)
Use cursor keys to move the cursor in
the program guide and menu screens.
Use SELECT/OK to choose options,PPV
events, and to tune programs from the
program guide.
Use INFO to display current channel and
program information.
Press MENU once to display your cable
converter’s screen menu.
Use PAGE ▲▲ (or PAGE ▼▼) to page up
or down) through menu screens and the
program guide.
Slide the door open to reveal less-often
used keys such as VCR transport buttons
and cable converter features.
In the VCR and TV modes, use the REW,
PLAY, FF, REC, STOP,and PAUSE keys to
control your VCR. To record a program,
press REC twice.
Reserved for cable converter features
(see your cable converter manual).
Press TV/VCR once to switch the VCR to
view TV channels or tape. This key will
also control the input select feature on
most TVs.
6
INSTALLING BATTERIES
1. On the back of the Millennium 4,push the tab
and lift off the battery cover.
2. Obtain two (2) fully-charged AA alkaline
batteries.Match the + and – marks on the
batteries to the + and – marks in the battery
case, then insert the new batteries.
3. Press the battery cover back into place. The tab
should click when the cover is locked.
4. Test the unit by pressing POWER and any mode
key (e.g.AUDIO, VCR,TV,or CBL).If the batteries
are inserted correctly, the LED will blink once.
NOTE:Whenever batteries need replacement, the Millennium 4
will blink twice with every key press. Simply replace the batteries
and the Millennium 4 will be restored to its full functionality,
complete with your favorite settings.
7
❶
❸
❷
PROGRAMMING TV CONTROL
NOTE: If you own a TV/VCR combination,skip this section and
perform “Programming TV/VCR Combo Control”on page 16.
Locate the brand name of your TV in the Setup Codes
for TVs in the next section, and write it in the space below.
TV Brand: __________________________________
The brands are listed in alphabetical order with the most
popular codes listed first.You will use one of these codes
to program the Millennium 4 to operate your TV:
1. Turn on the TV.
2. On the Millennium 4, press TV once. Press and
hold SETUP until the LED blinks twice,then
release SETUP.
3. Enter the first four-digit code for your TV. If
you perform this procedure correctly, the LED
will blink twice.
NOTE: If the LED did not blink twice after entering
the code’s last digit,then repeat steps 2 through 3 and
try entering the same code again.
4. Aim the Millennium 4 at your TV and press
POWER once.The TV should turn off.If it does
not, repeat steps 2 and 3,trying each code for
your brand until you find one that works. If it
still does not work,try searching for the code
(see Searching For Your Code on page 24).
5. For future reference,write your TV code in the
boxes below.
NOTE: Remember,to use the Millennium 4 to operate your TV,
press TV first.
Setup Codes for TVs:
AOC 0030, 0019
Admiral 0093, 0463
Aiko 0092
Akai 0030
Alaron 0179
America Action 0180
Anam 0180
Audiovox 0451, 0180,0623, 0092
Baysonic 0180
8
Belcor 0019
Bell & Howell 0154, 0016
Bradford 0180
Brockwood 0019
Broksonic 0236, 0463
CXC 0180
Candle 0030, 0056
Carnivale 0030
Carver 0054
Celebrity 0000
Cineral 0451, 0092
Citizen 0060, 0030,0056, 0092,0280
Concerto 0056
Contec 0180
Craig 0180
Crosley 0054
Crown 0180
Curtis Mathes 0047,0747, 0054,0154, 0051,0451, 0093,0060, 0030,0056,
0145, 0016,0166
Daewoo 0451, 0019,0623, 0624, 0092
Daytron 0019
Denon 0145
Dumont 0017,0019
Electroband 0000
Emerson 0154, 0236,0463, 0180,0178, 0179, 0019,0623, 0624,0282,
0280
Envision 0030
Fisher 0154
Fujitsu 0179, 0683
Funai 0180, 0179,0171
Futuretech 0180
GE 0047, 0747,0051, 0451, 0093,0178, 0021,0282
Gibralter 0017, 0030, 0019
GoldStar 0030, 0178,0056, 0019
Gradiente 0053, 0056
Grunpy 0180, 0179
Hallmark 0178
Harley Davidson 0179
Harman/Kardon 0054
Harvard 0180
Hitachi 0056, 0145, 0016
Infinity 0054
Inteq 0017
JBL 0054
JCB 0000
JVC 0053
KEC 0180
KTV 0180,0030, 0280
Kenwood 0030, 0019
Konka 0707, 0628,0632, 0638, 0703
LG 0056
continued on next page...
9
PROGRAMMING TV CONTROL
Setup Codes for TVs (continued):
LXI 0047, 0747, 0054, 0154,0156, 0178
Logik 0016
Luxman 0056
MGA 0150, 0030,0178, 0019
MTC 0060, 0030,0056, 0019
Magnavox 0054, 0030, 0179
Majestic 0016
Marantz 0054,0030
Matsushita 0250
Megatron 0178,0145
Memorex 0154, 0250,0463, 0150, 0178,0179, 0056,0016
Midland 0047,0747, 0017,0051
Minutz 0021
Mitsubishi 0093, 0150,0178, 0019
Motorola 0093
Multitech 0180
NAD 0156, 0178, 0166
NEC 0030, 0056, 0019
NTC 0092
Nikko 0030, 0178, 0092
Onwa 0180
Optimus 0154, 0250, 0166
Optonica 0093, 0165
Orion 0236, 0463,0179
Panasonic 0051,0250
Penney 0047, 0747,0156, 0051, 0060,0030, 0178,0021, 0056, 0019
Philco 0054,0463, 0030, 0145,0019
Philips 0054
Pilot 0030, 0019
Pioneer 0166
Portland 0019, 0092
Prism 0051
Proscan 0047, 0747
Proton 0178
Pulsar 0017,0019
Quasar 0051, 0250, 0165
RCA 0047, 0747, 0090,0051, 0093,0019, 0278
RadioShack 0047, 0747,0154, 0180, 0030,0178, 0056,0019, 0165
Realistic 0154,0180, 0030,0178, 0056, 0019,0165
Runco 0017, 0030
SSS 0180, 0019
Sampo 0030
Samsung 0060, 0030, 0178,0056, 0019
Sansei 0451
Sansui 0463
Sanyo 0154
Scimitsu 0019
10
