Helix Z-wave 5-Device

Remote Control with Learning

Users Guide

Helix 5 Device.fm Page 2 Tuesday, June 5, 2007 5:24 PM

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Features and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Key Charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Device Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Programming Device Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Setting Up a Combo Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Searching for Your Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Checking the Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Using Learning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Learning Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Programming a Learned Key . . . . . . . . . . . . . . . . . . . . . . . . .14

Deleting a Single Learning Key. . . . . . . . . . . . . . . . . . . . . . . .15

Deleting All Learned Keys in a Specific Mode . . . . . . . . . . . .16

Programming Channel Control Lock . . . . . . . . . . . . . . . . . . . . . . . .16

Unlocking Channel Control. . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Locking Channel Control to SAT . . . . . . . . . . . . . . . . . . . . . . .17

Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Unlocking Volume Control for a Single Device (Individual

Volume Unlock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Unlocking All Volume Control (Global Volume Unlock) . . . . .18

Locking Volume Control To One Mode (Global Volume Lock) 18

Programming ID Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Programming a Macro Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Programming a Macro Key. . . . . . . . . . . . . . . . . . . . . . . . . . .20

Clearing a Macro Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Using the Master Power Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Programming the Master Power Key . . . . . . . . . . . . . . . . . . .21

Using the Master Power Key. . . . . . . . . . . . . . . . . . . . . . . . . .21

Clearing the Master Power Key . . . . . . . . . . . . . . . . . . . . . . .22

Re-Assigning Device Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Adding a Node to Your Z-wave Network . . . . . . . . . . . . . . . . . . . . . .23

Adding a Node to the Network . . . . . . . . . . . . . . . . . . . . . . . . 23

Deleting a Node from the Network. . . . . . . . . . . . . . . . . . . . .24

Setting Up Scenes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Adding a Node to a Scene. . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Removing a Node from a Scene . . . . . . . . . . . . . . . . . . . . . . .25

Deleting a Scene. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Controlling Scenes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

www.urcsupport.com

Helix 5 Device.fm Page 3 Tuesday, June 5, 2007 5:24 PM

Transferring Node and Network Information to a Secondary remote.

Transferring Network Information to a Secondary remote . . . . . . . 27

Primary Controller Shift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Controller Copy Receipt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Network Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Network Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Network Recovery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Removing a Failed Node from the Network . . . . . . . . . . . . . . . . . . . 30

Clearing Custom Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

FCC Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Manufacturer’s Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Setup Codes for Audio Amplifiers. . . . . . . . . . . . . . . . . . . . . . 34

Setup Codes for Audio Receivers. . . . . . . . . . . . . . . . . . . . . . 35

Setup Codes for Audio Accessories . . . . . . . . . . . . . . . . . . . .38

Setup Codes for Cable Boxes/Converters . . . . . . . . . . . . . . .38

Setup Codes for CD Players . . . . . . . . . . . . . . . . . . . . . . . . . .39

Setup Codes for DBS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Setup Codes for DVD Players . . . . . . . . . . . . . . . . . . . . . . . . .41

Setup Codes for DVD/PVR Combos. . . . . . . . . . . . . . . . . . . . . 44

Setup Codes for DVR/PVR Systems . . . . . . . . . . . . . . . . . . . .49

Setup Codes for Home Automation . . . . . . . . . . . . . . . . . . . .46

Setup Codes for Satellite Receivers . . . . . . . . . . . . . . . . . . .46

Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Setup Codes for TVs (DLP) . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Setup Codes for TVs (LCD) . . . . . . . . . . . . . . . . . . . . . . . . . . .62

Setup Codes for TV/DVD Combos . . . . . . . . . . . . . . . . . . . . . . 62

Setup Codes for TV/VCR Combos . . . . . . . . . . . . . . . . . . . . . . 64

Setup Codes for VCRs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

www.urcsupport.com

Helix 5 Device.fm Page 4 Tuesday, June 5, 2007 5:24 PM

INTRODUCTION

The Helix Z-wave 5-Device Remote Control with Learning by Universal Electronics is our latest generation universal remote control. Its sophisticated technology allows you to consolidate up to five of your original home entertainment remote controls into one easy-to-use product.

Your remote lets you control individual Z-wave devices with one easy-to-use, compact unit. You can also set up and control different groups and scenes.

You can control your electric lights, turning them on or off, or making them brighter or dimmer.

Moreover, its packed with advanced features such as:

• Preprogrammed control to operate thes satellite receiver supplied by your service provider

• Dedicated keys to control popular functions on your DVR/PVR (Digital/Personal Video Recorder)

• Programmable Master Power key for master on/off control of your home entertainment equipment with a single keystroke

• Programmable Macro Keys to allow you to activate certain keys in a specific order

• Channel Lock to lock channel selection only to the cable converter

• Volume Lock to lock volum e cont rols to one mode or individual modes

• Device Key Re-Assignment to remotely control a second (duplicate) device

• Code Search to help program control of older or discontinued components

• Color-coded keys to quickly locate popular functions

• Code library for popular video and audio devices

Before using the product, you will need to install the enclosed batteries and also perform some programming to operate the specific home entertainment devices you wish to control.

Please follow the instructions detailed in this manual to set up the unit and then start enjoying your new remote control and cable service.

www.urcsupport.com

Helix 5 Device.fm Page 5 Tuesday, June 5, 2007 5:24 PM

FEATURES AND FUNCTIONS

Use the illustration below to locate features on the Helix Z-wave 5-Device Remote Control with Learning and then study the Key Charts (on the next three pages) to learn how they function.

To find out what type of devices can be controlled by each device key after programming, see “Device Table” on page 7 .

www.urcsupport.com

Helix 5 Device.fm Page 6 Tuesday, June 5, 2007 5:24 PM

Key Charts

Key Function

Use SETUP for all programming sequences. Also use to turn backlighting on and off, if applicable.

Press POWER once to turn on or off a home entertainment device. For MASTER POWER control, see “Using the Master Power Key” on page 21.

Press TV, DVD/VCR, SAT, or AUX once to select a home entertainment device to control. Also see “Device Table” on page 7.

Each device key has an embedded LED (red light) that blinks upon selection and indicates the remote control is working and (after programming) is sending signals.

Use ALL/GUIDE to display the program guide.

Use INFO to display the current channel and program information.

Use the Cursor keys to move the cursor in the program guide and menu screens and to navigate within the interactive service.

Use OK to choose options, PPV events, and to tune to programs from the program guide.

Use EXIT to exit out of your cable converters menu and guide.

Use VOL+ (or VOL-) to raise (or lower) the audio volume.

Use BRIGHT or DIM to control the brightness level of your lights.

Use CH+ (or CH-) to select the next higher (or lower) channel.

For DVD players, use these keys to skip forward (or reverse) through chapters.

For amplifiers/receivers, use these keys to select the next higher (or lower) preset station.

Use ON or OFF to turn your Z-wave compatible devices on or off.

www.urcsupport.com

Helix 5 Device.fm Page 7 Tuesday, June 5, 2007 5:24 PM

Key Function

Press MUTE once to turn the sound off or on.

Press CANCEL to

Press LAST once to recall the last channel.

Use to command your PVR/DVR to instantly skip forward 7 seconds in the program you are watching.

Use to command your PVR/DVR cable box to instantly replay the last 7 seconds of a program you are watching.

Press LIVE TV to command your PVR/ DVR cable b ox to return to watching live TV.

In all modes except SAT, use REW, PLAY, FFWD, STOP, and PAUSE to control a VCR, DVD player, or a PVR (after selecting a desired device). To record in the VCR mode, press REC twice.

In the SAT mode, use these keys to control the DVR/PVR functions of the set-top box.

Use the keypad numbers (1-9, and 0) to directly tune channels (e.g., 09).

For amplifiers/receivers, use the keypad numbers to select inputs 1 through 10.

Use TV/VID to select an input source.

Use ADD, REMOVE, DELETE, or SCENE to control your Z-wave compatible devices.

Device Table NOTE: Please refer to the table below when

performing the instructions in “Programming Device Control” on page 9 or “Setting Up a Combo Unit” on page 11.

www.urcsupport.com

Helix 5 Device.fm Page 8 Tuesday, June 5, 2007 5:24 PM

After programming, the Helix Z-wave 5-Device Remote Control with Learning will be able to control the following types of devices:

Device Key Controls these types of devices

Audio Amplifier, Tuner, Receiver, CD Player, Home Automation, or Miscellaneous Audio

Te l e v i s i o n

DVD Player, VCR, PVR

Satellite Receiver, Cable Box (Converter), or Video Accessory

Dedicated to Z-Wave controls

INSTALLING BATTERIES

1. On the back of the remote control, push the

tab and lift off the battery cover.

2. Locate the four (4) enclosed AAA batteries.

Match the + and - marks with those in the battery case, then insert them.

www.urcsupport.com

Helix 5 Device.fm Page 9 Tuesday, June 5, 2007 5:24 PM

3. Align the covers keys with the cases holes and

press the cover back into place. The tab should click when the cover is locked.

4. Test the remote control by pressing any mode

key (e.g., TV). If the batteries are inserted correctly, the LED (red light) will blink once.

NOTE: When batteries need replacement, the remote

control will cease to operate. Replace the batteries and the unit will be restored to its full functionality, complete with your favorite settings.

PROGRAMMING DEVICE CONTROL

The Helix Z-wave 5-Device Remote Control with Learning is preprogrammed to operate an RCA satellite receiver, TV, DVD player, and VCR, and a Pioneer audio receiver. It can also control Z-wave compatible devices, such as your home lighting system. To control devices other than the default brands, perform the following steps; otherwise skip this section.

NOTES: For control of a Combo device (for example, a

TV/VCR combo), skip this section and perform the instructions on “Setting Up a Combo Unit” on page 11. Also refer to “Device Table” on page 7 to find out which devices can be programmed onto each device key.

If you have another brand of cable converter or a satellite receiver you would like to control, you’ll need to unlock the cable ID Lock before changing the converter code (see “Programming ID Lock” on page 19).

1. Turn on a device and, if applicable, insert

video media, (e.g., cassette or disc).

NOTE: Please read steps 2 through 4 completely

before proceeding. Highlight or write down the codes and device you wish to program before moving on to step 2.

2. On the remote control, press a device key once

(i.e., TV, DVD/VCR, SAT, or AUX); it will blink once. Then press and hold SETUP until the selected mode key blinks twice.

3. Use the “Manufacturer’s Codes” starting on

page 34) to locate the type of device and brand name and then enter the first four-digit code for your device. If performed correctly, the selected mode key will blink twice.

www.urcsupport.com

Helix 5 Device.fm Page 10 Tuesday, June 5, 2007 5:24 PM

NOTE: If the selected mode key emits a long blink,

the entry is invalid. Repeat steps 2 through 3 and try entering the same code again.

4. Aim the remote control at the device and

press PWR once. The device should turn off. If it does not, repeat steps 2 through 3, trying each code for your brand until you find one that works. If it still does not respond, try searching for the code (see “Searching for Your Code” on page 12).

NOTE: If the device does not have a PWR key, press

the(Play) key.

5. Repeat steps 1 through 4 for each device you

want the remote control to operate. For future reference, write down each working device code in the boxes on the following page.

VCR Cod e

Device Type:___________________

DVD Code

Device Type:___________________

AMP Code

Device Type:___________________

SAT Code

Device Type:___________________

TV Code

Device Type:___________________

www.urcsupport.com

Helix 5 Device.fm Page 11 Tuesday, June 5, 2007 5:24 PM

SETTING UP A COMBO UNIT

If you own a combo unit such as a TV/VCR Combo or a TV/DVD Combo, you need to follow special steps to set it up. Perform the following instructions to control combo device:

1. For a TV/VCR Combo, turn on your TV/VCR

Combo and insert a video cassette. (For a TV/ DVD Combo, insert a DVD).

2. On the remote control, press DVD/VCR once; it

will blink once. Then press and hold SETUP until the DVD/VCR key blinks twice.

3. Use the “Manufacturer’s Codes” starting on

page 34 to locate the brand name and enter the first four-digit code for your combo device (for example, TV/VCR). If you perform this procedure correctly, the DVD/VCR key will blink twice.

NOTE: If the DVD/VCR key did not blink twice after

entering the codes last digit, repeat steps 2 through 3 and try entering the same code again.

If you’ve located a setup code that works for your combo device (for example, a TV/VCR Combo) and a separate TV code is also listed, you’ll need to program this code into the remote control to access volume control (see “Programming Device Control” starting on page 9).

4. Aim the remote control at your combo device

(for example, TV/VCR Combo) and press PWR once. The device should turn off. If it does not respond, repeat steps 2 through 3, trying each code listed for your brand until you find one that works. If it still does not respond, try searching for the code (“Searching for Your Code” starting on page 12).

5. For future reference, write down each working

device code in the boxes below: TV/VCR or TV/DVD Code

TV Code (if used)

www.urcsupport.com

Helix 5 Device.fm Page 12 Tuesday, June 5, 2007 5:24 PM

SEARCHING FOR YOUR CODE

If your home entertainment device does not respond to the Helix Z-wave 5-Device Remote Control with Learning after trying all of the codes listed for your brand, or if your brand is not listed at all, try searching for your code.

For example, to search for a code for your TV:

1. Turn on your TV.

2. On the remote control, press TV once; it will

blink once. Then press and hold SETUP until the TV key blinks twice.

3. Enter 9 9 1. The TV key will blink twice.

4. Aim the remote control at the TV and press

PWR once.

5. Press and release the CH+ key continuously,

then stop when the TV turns off.

NOTE: In the search mode, the remote control will

send IR codes from its library to the selected device, starting with the most popular code first.

6. Press PWR. The TV should turn on, then press

SETUP to lock in the code.

NOTE: If the TV does not turn on during step 6, then

slowly press and release CH- to go back through the codes, then press SETUP when the TV turns on.

7. To search for the codes of your other devices,

repeat steps 1 through 6, but substitute the appropriate key (e.g., VCR, DVD, AMP, or SAT) for the device you are searching for.

www.urcsupport.com

Helix 5 Device.fm Page 13 Tuesday, June 5, 2007 5:24 PM

CHECKING THE CODES

If you have set up the Helix Z-wave 5-Device Remote Control with Learning by searching for your device code (on the previous page), you may need to find out which four-digit code is operating your equipment.

or example, to find out which code is operating your TV

1. On the remote control, press TV once; it will

blink once. Then press and hold SETUP until the TV key blinks twice.

2. Enter 9 9 0. The TV key will blink twice.

3. To view the code for the first digit, press 1

once. Count the number of times the TV key blinks (e.g., 3 blinks = 3) and write down the number in the leftmost TV Code box on page 10.

NOTE: If a code digit is 0, the selected mode key will

not blink.

4. Repeat step 3 three more times for the

remaining digits. Use 2 for the second digit, 3 for the third digit, and 4 for the fourth digit. Finish writing down the code in the TV Code boxes on page 10.

5. To check for other device codes, repeat steps 1

through 4, but substitute the appropriate key (e.g., VCR, DVD, AMP, or SAT) for the device you are checking. Write down the codes in the appropriate boxes on page 10.

USING LEARNING

The Helix Z-wave 5-Device Remote Control with

Learning includes a Learning feature so you can add

functions that are unique to your home entertainment devices (e.g.,VCR T are some considerations

Learning Precautions

• Your original remote controls must be in working order for learning to work properly.

• Learned keys are mode-specific, so each one can store a unique function for each mode.

• Do not use the following keys for learning: Device Keys, SETUP, Record (•), Tune-In Keys.

racking Up or Down). However, there

www.urcsupport.com

Helix 5 Device.fm Page 14 Tuesday, June 5, 2007 5:24 PM

• Learning capacity is approximately 16 to 25 keys, depending on the code being learned.

• Certain device functions are not learnable including multi-frequency types, some high frequency ones, and other unusual formats.

• For optimum learning, avoid high levels of ambient light such as natural sunlight or energy-efficient fluorescent lights.

NOTE: Please have your original remote controls

handy before programming learning.

Programming a Learned Key NOTE: If more than 15 seconds pass between key

presses, the remote exits programming.

1. Press and hold SETUP until the last-selected

mode key blinks twice, then press 9 7 5.

NOTE: If the LED displays one long flash instead,

either your batteries are low, or the Helix Zwave 5-Device Remote Control with Learning has a memory fault.

2. Press a mode key once (i.e., TV, DVD/VCR, SAT,

or AUX) to assign a mode for learning.

3. Then press the key on your Helix Remote

Control that learns the new code.

4. Place the Helix Z-wave 5-Device Remote

Control with Learning head-to-head (about 2" apart) from your or iginal remote control. Also locate the key (on your original remote control) that you want the Helix Z-wave 5Device Remote Control with Learning to learn.

5. On the original remote, press and hold the key

to be learned. The Helix Z-wave 5-Device Remote Control with Learning’s LED will blink rapidly, then turn off. Continue holding

www.urcsupport.com

Helix 5 Device.fm Page 15 Tuesday, June 5, 2007 5:24 PM

the key on the original remote until the Helix Z-wave 5-Device Remote Control with Learning’s LED blinks twice.

NOTE: If the LED displays one long blink, a learning

error has occurred. Try repeating this step again until a successful capture occurs. If the

function is still not captured, press and hold SETUP to exit programming and review the

“Learning Precautions” on the previous page. If needed, also see “Troubleshooting” on page 31. After review, start programming again at step 1.

6. Repeat steps 2 through 5 for another mode

and/or key or press and hold SETUP to exit programming.

Deleting a Single Learning Key

his process returns the key to its original programmin

g for the mode you select. You can also delete learned programming by teaching a different function to the key (see “Programming a Learned Key” on page 14)

NOTE: If more than 15 seconds pass between key

presses, the remote exits programming.

1. Press and hold SETUP until the last-selected

mode key blinks twice, then press 9 7 6.

2. Press a mode key once (i.e., TV, DVD/VCR, SAT,

or AUX).

3. Press the key containing the learned function

to be deleted twice. The remote will blink twice.

4. Repeat steps 2 through 3 for another key or

press and hold SETUP to exit programming.

www.urcsupport.com

Helix 5 Device.fm Page 16 Tuesday, June 5, 2007 5:24 PM

Deleting All Learned Keys in a Specific Mode NOTE: If more than 15 seconds pass between key

presses, the remote exits programming.

1. Press and hold SETUP until the last-selected

mode key blinks twice, then press 9 7 6.

2. Press a mode key twice (i.e., TV, DVD/VCR, SAT,

or AUX) to clear all the learned keys for that mode. The LED blinks twice.

3. Repeat step 2 for another mode or press and

hold SETUP to exit programming.

PROGRAMMING CHANNEL CONTROL LOCK

By default, the remote control’s channel-control capabilities are locked to the cable converter. The affected keys will guarantee that you do not inadvertently change a channel on your TV or VCR. However, you can deactivate this feature to allow full access to these keys in the TV and VCR modes.

NOTE: This feature does not affect the AMP mode.

Unlocking Channel Control

1. On the remote control, press SAT once; it will

are 1 through 0, CH+, CH-, and LAST. This

blink once. Press and hold SETUP until the SAT key blinks twice.

2. Enter 9 7 3. The SAT key will blink twice.

3. Press CH- once. The SATSAT key will blink four

times.

Now the remote control will provide TV and VCR channel-control capabilities while in the TV or VCR mode.

www.urcsupport.com

Helix 5 Device.fm Page 17 Tuesday, June 5, 2007 5:24 PM

Locking Channel Control to SAT

1. On the remote control, press SAT once; it will

blink once. Press and hold SETUP until the SAT key blinks twice.

2. Enter 9 7 3.The SAT key will blink twice.

3. Press CH+ once. The SAT key will blink twice.

Now, regardless of what mode you select (except AMP), the channel keys will only change channels on your cable converter.

CHANGING VOLUME LOCK

Volume Lock allows you to control the volume through the device identified as having your primary speaker(s), regardless of which mode you are using. On the Helix Zwave 5-Device Remote Control with Learning, Global Volume Lock is set to TV, so you can control TV volume while in the VCR, DVD, TV or SAT mode. You can perform Individual Volume Unlock on a selected device to set its volume control for independent operation.

NOTE: The audio mode’s (AMP) volume controls are

Unlocking Volume Control for a Single Device (Individual Volume Unlock)

1. Assuming Gl obal Volume L ock i s act ive, s elec t

2. Enter 9 9 3. The last-selected device key will

active regardless of Volume Lock settings. However, if you lock the volume controls to the AMP mode, you will have control of the audio device’s volume in all other modes (i.e., VCR, DVD, TV, and SAT). This can be an advan- tage if, for example, you always listen to home entertainment devices through your receiver’s speakers.

a mode on the remote control that you want to unlock (e.g., SAT) and press it once. Next, press and hold SETUP until the device key blinks twice.

blink twice.

www.urcsupport.com

Helix 5 Device.fm Page 18 Tuesday, June 5, 2007 5:24 PM

3. Press VOL- once. The last-selected device key

will blink four times.

4. Repeat steps 1 through 3 for each device you

want volume to be unlocked.

Now, after you select a device that has volume unlocked (e.g., SAT), pressing VOL+, VOL-,or MUTE, will control only that device’s volume.

Unlocking All Volume Control (Global Volume Unlock) NOTE: Performing these instructions will set inde-

pendent volume control for all programmed devices.

1. On the remote control, press and hold SETUP

until the last-selected device key blinks twice.

2. Enter 9 9 3. The last-selected device key will

blink twice.

3. Press VOL+ once. The last-selected device key

will blink four times.

Locking Volume Control To One Mode (Global Volume Lock)

NOTE: The audio mode’s volume controls are active

regardless of Volume Lock settings. However, if you lock the volume controls to the AMP mode, you will control the audio device’s volume in all other modes (i.e., VCR, DVD, TV, or CBL). This can be an advantage if, for example, you always listen to home entertainment devices through your receiver’s speakers.

1. On the remote control, press and hold SETUP

until the last-selected device key blinks twice.

2. Enter 9 9 3. The last-selected device key will

blink twice.

3. Select a mode (e.g., TV or AMP) which you

want to use to control the volume. The selected device key will blink twice.

www.urcsupport.com

Helix 5 Device.fm Page 19 Tuesday, June 5, 2007 5:24 PM

Now, when you press VOL+, VOL-,or MUTE, the volume of the selected device (e.g., TV) is controlled regardless of mode.

PROGRAMMING ID LOCK

The Helix Z-wave 5-Device Remote Control with Learning is locked at the factory to operate your provider’s set top box. However, if you have another brand or model of cable converter or satellite service that you would like to control, then you’ll need to perform the following steps to unlock the ID Lock, enter a new manufacturer’s code, and lock the ID Lock again.

1. Turn on the cable converter.

2. On the remote control, press SAT once; it will

blink once. Then press and hold SETUP until the SAT key blinks twice.

3. Enter 9 8 2. The SAT key will blink four

times, indicating ID Lock is unlocked.

4. Perform the instructions under

“Programming Device Control” on page 9 to program device control for the desired cable converter or satellite receiver.

When you are done, perform steps 5 and 6 on this page to again lock the cable ID Lock.

5. On the remote control, press SAT once; it will

blink once. Then press and hold SETUP until the SAT key blinks twice.

6. Enter 9 8 2. The SAT key will blink twice,

indicating ID Lock is again locked.

PROGRAMMING A MACRO KEY

The Helix Z-wave 5-Device Remote Control with Learning includes a macro key feature. Macro keys allow you to set up key macros to activate certain keys in a specific order. For example, you can set up a key macro to change the channels on your TV, raise or lower the volume, and start recording on your VCR, all with the touch of one key. If you want to change the macros stored in a previously-programmed macro key, you’ll

www.urcsupport.com

Helix 5 Device.fm Page 20 Tuesday, June 5, 2007 5:24 PM

need to clear the key first (see “Clearing a Macro Key” on page 20).

Programming a Macro Key

1. On the remote control, press and hold SETUP

until it blinks twice.

2. Enter 9 9 5. The SETUP key blinks twice.

3. Select a macro key (for example, 1) and press

it once.

4. Press the key sequence you want to program

into the macro. For example, to turn on your TV and raise its volume, press TV followed by

VOL+.

NOTE: You can program up to 15 key presses into one

macro.

5. Press and hold SETUP until it blinks twice.

6. To add another macro, repeat steps 1 through

5, substituting the new key sequence to be added in step 4.

NOTE: Programming more than five macros on the

same macro key overwrites previous settings.

Clearing a Macro Key

1. On the remote control, press and hold SETUP

until it blinks twice.

2. Enter 9 9 5. The SETUP key blinks twice.

3. Press the macro key you want to clear once.

4. Press and hold SETUP until it blinks twice.

This macro key is now clear and ready for reprogramming (see “Programming a Macro Key” on page 20). If desired, repeat these to clear another TuneIn key.

www.urcsupport.com

Helix 5 Device.fm Page 21 Tuesday, June 5, 2007 5:24 PM

USING THE MASTER POWER KEY

The Helix Z-wave 5-Device Remote Control with Learning has a unique feature that allows you to sequentially turn up to five of your home entertainment devices on or off with a single key press.

NOTE: MASTER POWER (PWR) only works in the SAT

mode. If it is not programmed, only the cable converter will turn on or off. In any other mode, pressing MASTER POWER (PWR) once will turn the selected device on or off.

Programming the Master Power Key

1. On the remote control, press and hold SETUP

until the last-selected device key blinks twice.

2. Enter 9 9 5. The last-selected device key

blinks twice.

3. Press PWR once.

4. For the first device you want in the power on

sequence, press a device key (e.g., SAT) once. Then press PWR once. For the second device in the power sequence, press its key once (e.g, TV). Then press PWR.

5. Repeat step 4 up to four more times to add the

second, third, fourth, and fifth device, as desired.

6. To save the settings and exit the program:

a. Press SAT once.

b. Press and hold SETUP until the SAT key blinks

twice.

Using the Master Power Key

1. After programming, point the remote control

at the devices. Press SAT once.

Press

PWR

once to sequentially turn the programmed home entertainment devices on or off.

You will see the devices turn on or off according to the programmed sequence.

www.urcsupport.com

Helix 5 Device.fm Page 22 Tuesday, June 5, 2007 5:24 PM

Clearing the Master Power Key

1. On the remote control, press and hold SETUP

until the last-selected device key blinks twice.

2. Enter 9 9 5. The last-selected device key

blinks twice.

3. Press and release PWR.

4. Press and hold SETUP until the SAT key blinks

twice.

RE-ASSIGNING DEVICE KEYS

The Helix Z-wave 5-Device Remote Control with Learning can be set up to control a second device of an already-assigned type. For example, to have the unit control a TV, a Cable Converter, and two audio devices (for example, two audio receivers), re-assign the unused DVD/VCR key to operate the second audio device as follows:

NOTE: DVD/VCR is preset at the factory to control an

RCA DVD. Performing the steps below will overwrite those settings.

1. On the remote control, press DVD/VCR once; it will blink once. Then press and hold SETUP until the DVD/VCR key blinks twice.

2. Enter 9 9 2. The DVD/VCR key will blink twice.

3. Press AMP once, then press DVD/VCR once. The DVD/VCR key will blink twice.

The DVD/VCR key is now ready to be programmed for your second audio device. See “Programming Device Control” on page 9. To re-assign other device keys, repeat these and substitute the key sequence using the following chart:

www.urcsupport.com

Helix 5 Device.fm Page 23 Tuesday, June 5, 2007 5:24 PM

NOTE: Only one device can be assigned to an unused

device key at a time.

To Re-Assign Perform Key Sequence

DVD/VCR as 2nd AMP key

DVD/ VCRÆSETUPÆ9Æ9Æ2ÆAMPÆDVD /VCR

DVD/VCR as 2nd TV key

DVD/ VCRÆSETUPÆ9Æ9Æ2ÆTVÆDVD/ VCR

DVD/VCR as 2nd SAT key

DVD/ VCRÆSETUPÆ9Æ9Æ2ÆSATÆDVD/ VCR

DVD /VCR back to VCR

DVD/VCRÆSETUPÆ9Æ9Æ2ÆDVD/ VCRÆDVD/VCR

To re-assign another unused device key, substitute it for the DVD/VCR key above and then perform the sequence. For example, to re-assign an unused AMP key as a second DVD key, perform AMPÆSETUPÆ9Æ9Æ2ÆDVDÆAMP.

When a re-assignment is done, the selected device key (e.g., AMP) will blink twice to confirm your choice. At that time, you will need to program device control (see “Programming Device Control” on page 9).

ADDING A NODE TO YOUR Z-WAVE NETWORK

The Helix Z-wave 5-Device Remote Control with Learning allows you to control lights around your home. In order to control the lights, they must be Z-wave compatible and you must first add them to your home network.

Adding a Node to the Network

To add a node to your home network, perform the following steps:

1. Press HOME once.

2. Press and release ADD twice. The red LED blinks rapidly.

3. Press the button on the node so that it sends its information to the remote and receives information from the remote.

4. The HOME LED blinks green twice.

NOTE: If the Home red LED emits one long, steady

blink, you have pressed an invalid key or the node has not been successfully added the

www.urcsupport.com

Helix 5 Device.fm Page 24 Tuesday, June 5, 2007 5:24 PM

node to your home network. Please make sure the remote is close to the node and try again.

Deleting a Node from the Network

To remove a node from your home network, you must delete it from the network. To delete the node from your network, perform the following steps:

1. Press HOME once.

2. Press and release DEL twice. The red LED blinks rapidly.

3. Press the button on the node so that it sends its information to the remote and receives information from the remote.

4. The HOME LED blinks green twice.

NOTE: If the Home red LED emits one long, steady

blink, you have pressed an invalid key or the node has not been successfully added the node to your home network. Please make sure the remote is close to the node and try again.

SETTING UP SCENES

A scene is a single node or group of nodes that can be preset to turn to a previously specified setting (brightness level). You can set up a maximum of 20 scenes, containing up to 64 nodes per scene.

Adding a Node to a Scene

1. Press HOME once.

2. Press ADD once.

3. Press SCENE once.

4. Press a digit (1-9) for the scene you wish to add the node to. The red LED blinks rapidly.

5. Press the button on the node so that it sends its information to the remote and receives information from the remote.

6. The green LED blinks twice, then the red LED blinks rapidly. Adjust the brightness on the node within 30 seconds.

NOTE: If the red LED emits one long, steady blink,

you have pressed an invalid key or the node has not been successfully added the node to your home network. Please make sure the remote is close to the node and try again.

www.urcsupport.com

Helix 5 Device.fm Page 25 Tuesday, June 5, 2007 5:24 PM

Removing a Node from a Scene

1. Press HOME once.

2. Press REMOVE once.

3. Press SCENE once.

4. Press a digit (1-9) for the node location you wish to remove. The red LED blinks rapidly.

5. Press the button on the node so that it sends its information to the remote and receives information from the remote.

6. The green LED blinks twice, then the red LED blinks rapidly.

NOTE: If the red LED emits one long, steady blink, you

have pressed an invalid key or the node has not been successfully removed from the scene.

Deleting a Scene

1. Press HOME once.

2. Press DELETE once.

3. Press SCENE once.

4. Press a digit (1-9) for the scene you wish to remove.

5. Press the button on the node so that it sends its information to the remote and receives information from the remote.

6. The green LED blinks twice. The scene has been removed successfully.

NOTE: If the red LED emits one long, steady blink, you

have pressed an invalid key or the scene has not been successfully deleted.

CONTROLLING SCENES

To control a scene, perform the following steps:

1. Press HOME once.

2. Press the digit key for the scene you wish to

3. Press the ON, OFF, DIM, or BRIGHT key. The

NOTE: If the red LED emits one long, steady blink, the remote has not successfully communicated with the node.

Turning All Nodes On or Off

control (1-9).

green LED blinks once. If ON or OFF is pressed, all nodes associated

to the scene turn on or off. If DIM or BRIGHT is pressed, all nodes associated with a scene dim or brighten with each key press.

www.urcsupport.com

Helix 5 Device.fm Page 26 Tuesday, June 5, 2007 5:24 PM

To turn all nodes either on or off, perform the following steps:

1. Press HOME once.

2. Press ALL once.

3. Press either ON to turn the nodes on, or OFF to turn the nodes off. Any ON or OFF can be pressed. The green LED blinks once.

NOTE: If the red LED emits one long, steady blink, you

have pressed an invalid key or the All-On/All-Off command was not successful. Repeat the steps above to try again.

Adding Nodes to All Control

1. Press HOME once.

1. Press ADD once.

2. Press ALL once. The red LED blinks rapidly.

3. Press the button on the node so that it sends its information to the remote and receives information from the remote.

4. The green LED blinks twice. The node has been successfully added.

NOTE: If the red LED emits one long, steady blink, the

node has not been successfully added to the group.

Deleting Nodes from All Control

1. Press HOME once.

1. Press REMOVE once.

2. Press ALL once. The red LED blinks rapidly.

3. Press the button on the node so that it sends its information to the remote and receives information from the remote.

4. The green LED blinks twice. The node has been successfully deleted.

NOTE: If the red LED emits one long, steady blink,

the node has not been successfully added to the group.

TRANSFERRING NODE AND NETWORK INFORMATION TO A SECONDARY REMOTE

You can add a secondary remote to your network, and transfer your primary remote’s node and network information to it. To transfer node and network information to a secondary remote, perform the following steps:

1. Place the two remotes near each other.

2. Press HOME.

www.urcsupport.com

Helix 5 Device.fm Page 27 Tuesday, June 5, 2007 5:24 PM

3. Press and hold SETUP until the red LED blinks twice.

4. Enter 9 6 6 on the numeric keypad. The red LED blinks twice.

5. Press CH+. The red LED blinks rapidly.

6. Put the target (secondary) remote into programming mode so that it sends its information to the primary remote, as well as receives information from the remote. The remote then transfers the network and node information to the new secondary remote. Refer to the user manual for the secondary remote for more information.

7. The green LED blinks twice. You have successfully transferred the information.

NOTE: If the red LED emits one long, steady blink,

the information has not been successfully transferred.

8. Add nodes, groups, and scenes to the new secondary remote as needed.

TRANSFERRING NETWORK INFORMATION TO A SECONDARY REMOTE

You can add a secondary remote to your network, and transfer your primary remote’s network information to it. To transfer network information to a secondary remote, perform the following steps:

1. Place the two remotes near each other.

2. Press HOME.

3. Press and hold SETUP until the red LED blinks twice.

4. Enter 9 6 6 on the numeric keypad. The red LED blinks twice.

5. Press CH-. The red LED blinks rapidly.

7. The green LED blinks twice. You have successfully transferred the information.

NOTE: If the red LED emits one long, steady blink, the

information has not been successfully transferred.

8. Add nodes, groups, and scenes to the new

secondary remote as needed.

www.urcsupport.com

Helix 5 Device.fm Page 28 Tuesday, June 5, 2007 5:24 PM

PRIMARY CONTROLLER SHIFT

You can transfer all of your remote’s information to another remote, so it becomes the new primary remote. You can do this in two ways: either transferring all information, or just transferring network information.

Transferring All Network and Remote Information

1. Place the two remotes near each other.

2. Press HOME.

3. Press and hold SETUP until the red LED blinks twice.

4. Enter 9 6 8 on the numeric keypad. The red LED blinks twice.

5. Press CH+. The red LED blinks rapidly.

7. The green LED blinks twice. You have successfully transferred the information.

NOTE: If the red LED emits one long, steady blink, the

information has not been successfully transferred.

8. Add nodes, groups, and scenes to the new primary

remote as needed.

Transferring Only Network Information

1. Place the two remotes near each other.

2. Press HOME.

3. Press and hold SETUP until the red LED blinks

4. Enter 9 6 6 on the numeric keypad. The red

5. Press CH-. The red LED blinks rapidly.

6. Put the target (secondary) remote into

7. The green LED blinks twice. You have

twice.

LED blinks twice.

programming mode so that it sends its information to the primary remote, as well as receives information from the remote. The remote then transfers the network and node information to the new secondary remote. Refer to the user manual for the secondary remote for more information.

successfully transferred the information.

www.urcsupport.com

Helix 5 Device.fm Page 29 Tuesday, June 5, 2007 5:24 PM

NOTE: If the red LED emits one long, steady blink,

the information has not been successfully transferred.

8. Add nodes, groups, and scenes to the new primary remote as needed.

CONTROLLER COPY RECEIPT

Controller Copy Receipt allows your controller to receive information from another controller. This would then allow the unit to become a new primary or secondary controller.

Copying Information from Another Controller

1. Place the two remotes near each other.

2. Press HOME.

3. Press and hold SETUP until the red LED blinks twice.

4. Enter 9 6 7 on the numeric keypad. The red LED blinks twice.

5. Press CH-. The red LED blinks rapidly.

7. The green LED blinks twice. You have successfully transferred the information.

NOTE: If the red LED emits one long, steady blink,

the information has not been successfully transferred.

8. Add nodes, groups, and scenes to the new primary remote as needed.

NETWORK RESET

Network Reset clears all Node and Network features. The remote resets to the default setting for the Z-wave network and node information.

Resetting the Network

1. Press HOME.

2. Press and hold SETUP until the red LED blinks twice.

3. Enter 9 6 9 on the numeric keypad. The red LED blinks continuously.

www.urcsupport.com

Helix 5 Device.fm Page 30 Tuesday, June 5, 2007 5:24 PM

4. The green LED blinks twice. The network has been successfully reset.

NOTE: If the red LED emits one long, steady blink,

the network has not been successfully reset.

NETWORK UPDATE

Network Update allows your controller to update the entire Z-wave network.

Updating the Network

1. Press HOME.

2. Press and hold SETUP until the red LED blinks

3. Enter 9 6 3 on the numeric keypad. The red

4. The green LED blinks twice. The network has

NOTE: If the red LED emits one long, steady blink, the network has not been successfully updated.

twice.

LED blinks continuously.

been successfully reset.

NETWORK RECOVERY

Network Recovery allows your controller to recover network information.

Recovering Network Information

1. Press HOME.

2. Press and hold SETUP until the red LED blinks twice.

3. Enter 9 6 1 on the numeric keypad. The red LED blinks continuously.

4. The green LED blinks twice. The network has been successfully reset.

NOTE: If the red LED emits one long, steady blink,

the network has not been successfully updated.

REMOVING A FAILED NODE FROM THE NETWORK

You can remove a failed node from the network. If a node fails in the network the controller’s LED emits a long blink when trying to access that node.

If the nodes fails, make sure that the node is properly plugged in. If the node still fails to respond, you can remove the from the network. The failed node is permanently removed from the network and scene. In case, the node responds, then the node is not removed.

www.urcsupport.com

Helix 5 Device.fm Page 31 Tuesday, June 5, 2007 5:24 PM

Removing a Failed Node

1. Press and hold SETUP until the red LED blinks twice.

2. Press 9 7 2. The green LED blinks continuously.

3. The node has been successfully removed from the network.

NOTE: If the red LED emits one long, steady blink,

the network has not been successfully updated.

CLEARING CUSTOM PROGRAMMING

The Helix Z-wave 5-Device Remote Control with

Learning contains a Custom Programming Reset

program. You can use it to remove all custom programming, except your setup codes and reassigned device keys.

IMPORTANT: Executing this program will erase all cus-

tom settings for Volume Lock, Learned Keys, Tune-In Keys, and Channel Lock. However,

your device programming remains.

1. On the remote control, press and hold SETUP until the last-selected device key blinks twice.

2. Enter 9 8 0. The last-selected device key blinks twice, pauses, and blinks twice again to confirm that all custom programming is cleared.

TROUBLESHOOTING

PROBLEM: Device key does not blink when you press a

key. SOLUTION: Replace the batteries with two (2) new AA

batteries (see “Installing Batteries” on page 8). PROBLEM: Device key blinks when you press a key, but

home entertainment device does not respond. SOLUTION: Make sure you are aim ing the remote control

at your home entertainment device and that you are within 15 feet of the device you are trying to control.

PROBLEM: The remote control does not control home entertainment devices or commands are not performing properly.

SOLUTION: Try all listed codes for the device brand being set up. Make sure all devices can be operated with an infrared remote control.

www.urcsupport.com

Helix 5 Device.fm Page 32 Tuesday, June 5, 2007 5:24 PM

PROBLEM: TV/VCR Combo does not respond properly. SOLUTION: Use the VCR codes for your brand. Some

combo units may require both a TV code and a VCR code for full operation (see page 11).

PROBLEM: No volume on a second TV. SOLUTION: Follow instructions under “Changing

Volume Lock” on page 17. PROBLEM: PLAY and STOP keys do not work on a

Motorola DCT-2000 cable converter. SOLUTION: Re-program the SAT key for cable code 0476

(see “Programming Device Control” on page 9). PROBLEM: Tried Search Method and still could not find

a working code. SOLUTION: Try the Search Method again after clearing

out the device key as follows:

a. Press and hold SETUP until device key blinks twice. b. Enter 9 9 2. c. Press and release the device key to be cleared twice.

PROBLEM: Remote control does not turn on Sony or Sharp TV/VCR Combo.

SOLUTION: For power on, these products require programming TV codes on the remote control. For Sony, use TV code 0000 and VCR code 0032. For Sharp, use TV code 0093 and VCR code 0048.

FCC NOTICE

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

www.urcsupport.com

Helix 5 Device.fm Page 33 Tuesday, June 5, 2007 5:24 PM

• Consult the dealer or an experienced radio/TV

technician for help.

This equipment has been verified to comply with the limits for a class B computing device, pursuant to FCC Rules. In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user’s authority to operate this equipment.

FCC ID: MG35300

ADDITIONAL INFORMATION

This product does not have any user-serviceable parts. Opening the case, except for the battery cover, may cause permanent damage to your Helix Z-wave 5-Device Remote Control with Learning.

• For help via the Internet, visit us at:

www.urcsupport.com

©Copyright 2006 by Universal Electronics Inc. No part of this publication may be reproduced, transmitted, transcribed, stored in any retrieval system, or translated to any language, in any form or by any means, electronic, mechanical, magnetic, optical, manual, or otherwise, without prior written permission of Universal Electronics Inc.

URC-5300 07/07

www.urcsupport.com

Helix 5 Device.fm Page 34 Tuesday, June 5, 2007 5:24 PM

MANUFACTURER’S CODES

Setup Codes for Audio Amplifiers

Adcom 30577, 31100 Aiwa 30406 Bose 30674 Carver 30269 Denon 30160 Durabrand 31561 Elan 30647 GE 30078 Harman/Kardon 30892 JVC 30331 Left Coast 30892 Lenoxx 31561 Linn 30269 Luxman 30165 Magnavox 30269 Marantz 30892, 30321, 30269 McIntosh 30251 Nakamichi 30321 NEC 30264 Optimus 30395, 30823 Panasonic 30308, 30521 Parasound 30246 Philips 30892, 30269 Pioneer 30823 Polk Audio 30892, 30269 RCA 30823 Realistic 30395 Sansui 30321 Shure 30264 Sony 30689, 30220, 30815, 31126 Soundesign 30078, 30211 Technics 30308, 30521 Victor 30331 Wards 30078, 30211 Yamaha 30354, 30133, 30143

www.urcsupport.com

Helix 5 Device.fm Page 35 Tuesday, June 5, 2007 5:24 PM

Setup Codes for Audio Receivers

ADC 30531 Aiwa 31405, 30158, 30189,

30121, 30405, 31243,

31388, 31641 Akai 31512 Alco 31390 Amphion Media Works 31563, 31615 AMW 31563, 31615 Anam 31609, 31074 Apex Digital 31257, 31430, 31774 Arcam 31120 Audiotronic 31189 Audiovox 31390, 31627 B & K 30701, 30820, 30840 BK 30702 Bose 31229, 30639, 31253,

31629, 31841, 31933 Brix 31602 Cambridge Soundworks 31370 Capetronic 30531 Carver 31189, 30189, 30042 Classic 31352 Coby 31263, 31389 Criterion 31420 Curtis Mathes 30080 Daewoo 31250 Dell 31383 Delphi 31414 Denon 31360, 30004, 31142 Fisher 30042, 31801 Garrard 30463 Gateway 31517 Glory Horse 31263 Go Video 31532 Harman/Kardon 30110, 30189, 30891,

31304, 31306 Hewlett Packard 31181 Hitachi 31273, 31801 Initial 31426 Insignia 31030

www.urcsupport.com

Helix 5 Device.fm Page 36 Tuesday, June 5, 2007 5:24 PM

Integra 30135, 31298, 31320 JBL 30110, 31306 JVC 30074, 31263, 31374,

31495, 31811, 31871 Kenwood 31313, 31570, 31569,

30027, 31916, 31670,

31262, 31261, 31052,

31032, 30569, 30337,

30314, 30313, 30239,

30186, 30077, 30042 KLH 31390, 31412, 31428 Koss 31366, 31497 Lasonic 31798 Lenoxx 31437 LG 31293 Linn 30189 Liquid Video 31497 LXI 30181 Magnavox 31189, 31269, 30189,

30391, 30531, 31514 Marantz 31189, 31269, 30039,

30189, 31289 MCS 30039, 30346 Mitsubishi 31393 NAD 30320, 30845 Nakamichi 30097, 30876, 31555 Norcent 31389 Nova 31389 Onkyo 30135, 30380, 30842,

31298, 31320, 31531 Optimus 31023, 30042, 30080,

30181, 30186, 30531,

30670, 30738, 30801, 31074 Oritron 31366, 31497 Panasonic 31308, 31518, 30039,

30309, 30367, 31288,

31316, 31548, 31633,

31763, 31764 Philips 31189, 31269, 30189,

30391, 31120, 31266 Pioneer 31023, 30014, 30080,

30150, 30244, 30531,

30630, 31384 Polaroid 31508 Polk Audio 30189, 31289, 31414

www.urcsupport.com

Helix 5 Device.fm Page 37 Tuesday, June 5, 2007 5:24 PM

Proscan 31254 Quasar 30039 RadioShack 31263 RCA 31023, 31609, 31254,

30054, 30080, 30346,

30530, 30531, 31074,

31154, 31390, 31511 Realistic 30181 Regent 31437 Rio 31383, 31869 Saba 31519 Samsung 31295, 31500 Sansui 30189, 30346 Sanyo 30801, 31251, 31469, 31801 Sharp 30186, 31286 Sharper Image 31263, 31556 Sherwood 30491, 30502, 31077,

31423, 31517, 31653, 31905 Shinsonic 31426 Sirius 31602, 31627, 31811, 31987 Sonic Blue 31383, 31532, 31869 Sony 31058, 31441, 31258,

31759, 31622, 30158,

30168, 31349, 31406,

31442, 31558, 31658,

31758, 31858, 31958 Soundesign 30670 Stereophonics 31023 Sunfire 31313, 30313, 30314, 31052 Teac 30463, 31074, 31390, 31528 Technics 31308, 31518, 30039, 30309 Thorens 31189 Toshiba 31788 Venturer 31390 Victor 30074 Wards 30158, 30189, 30014,

30054, 30080 XM 31406, 31414 Yamaha 30176, 30186, 31176,

31276, 31331, 31375, 31476 Zenith 30857, 31293

www.urcsupport.com

Helix 5 Device.fm Page 38 Tuesday, June 5, 2007 5:24 PM

Setup Codes for Audio Accessories

Accurian 31106 Aiwa 30159 Altec Lansing 31056, 31485 Apple 31115, 31644 Cambridge Soundworks 31530 Creative 30872 iDeck 31106 Marantz 31491 Monitor Audio 31106 Motorola 31464 NaviPod 31644 Netgear 31785 Omnifi 31605 Roku 31828 Russound 31302 Slim Devices 31844 Sony 30159 Yamaha 31809, 31810

Setup Codes for Cable Boxes/Converters

ABC 00003, 00008 Americast 00899 Bell South 00899 Digeo 01187 Director 00476 General Instrument 00476, 00810, 00276, 00003 GoldStar 00144 Hamlin 00273 Jerrold 00476, 00810, 00276, 00003 Memorex 00000 Motorola 01376, 00476, 00810,

00276, 01187 Pace 01877, 00237, 00008 Panasonic 00000, 00107 Paragon 00000 Philips 01305, 00317 Pioneer 01877, 00877, 00144, 00533 Pulsar 00000 Quasar 00000 RCA 01256

www.urcsupport.com

Helix 5 Device.fm Page 39 Tuesday, June 5, 2007 5:24 PM

Regal 00273 Runco 00000 Samsung 00144 Scientific Atlanta 01877, 00877, 00477, 00008 Sony 01006 Starcom 00003 Supercable 00276 Thomson 01256 Torx 00003 Toshiba 00000 Zenith 00000, 00525, 00899

Setup Codes for CD Players

Aiwa 30157 Burmester 30420 California Audio Labs 30029, 30303 Carver 30157, 30179 Denon 30873, 30003, 30034 DKK 30000 DMX Electronics 30157 Fisher 30179 Garrard 30420 Genexxa 30032 Harman/Kardon 30157, 30173 Hitachi 30032 Integra 30101 JVC 30072 Kenwood 30681, 30626, 30028,

30037, 30190 KLH 31318, 31372, 31373, 31711 Krell 30157 Linn 30157 Magnavox 30157 Marantz 30626, 30029, 30157 MCS 30029 Miro 30000 Mission 30157 MTC 30420 NSM 30157 Onkyo 30868, 30101

www.urcsupport.com

Helix 5 Device.fm Page 40 Tuesday, June 5, 2007 5:24 PM

Optimus 31063, 30000, 30032,

30037, 30087, 30145,

30179, 30420, 30468, 31075 Panasonic 30029, 30303, 30388, 30752 Parasound 30420 Philips 30626, 30157 Pioneer 31063, 31062, 30032,

31087, 30468 Polk Audio 30157 Proton 30157 QED 30157 Quad 30157 Quasar 30029 RadioShack 31075 RCA 31062, 30032, 30053,

30179, 30420, 30468 Realistic 30179, 30420 Rotel 30157, 30420 SAE 30157 Sansui 30157 Sanyo 30087, 30179 Sharp 30861, 30037 Sherwood 31067 Sonic Frontiers 30157 Sony 30490, 30000, 30100,

31364, 30185 Soundesign 30145 TAG McLaren 30157 Tascam 30420 Teac 30420 Technics 30029, 30303 Victor 30072 Wards 30157, 30053 Yamaha 30490, 30888, 30036, 31292

Setup Codes for DBS

AlphaStar 00772 Coolsat 01806 DirecTV 01377, 00392 Dishpro 01505, 01005, 00775, 01775 Echostar 01505, 01005 Hitachi 00819

www.urcsupport.com

Helix 5 Device.fm Page 41 Tuesday, June 5, 2007 5:24 PM

HTS 00775, 01775 Hughes Network Systems 00749, 01749 JVC 00775, 01775 LG 01414 Magnavox 00724, 00722 Memorex 00724 Motorola 00869 Panasonic 00247, 00701 Philips 00724, 01076, 00722, 00099 RCA 00566, 00855, 00143, 01392 Samsung 01276, 01109 Sony 01639 Star Choice 00869 Toshiba 00749, 00790, 01285 Uniden 00724, 00722 Zenith 01856

Setup Codes for DVD Players

Accurian 21072, 21416 Adcom 21094 Advent 21016 Aiwa 20641 Akai 20695, 20770, 20899, 21089 Alco 20790 Allegro 20869 Amphion Media Works 20872 AMW 20872 Apex Digital 20672, 20717, 20755,

20794, 20796, 20797,

20830, 21004, 21020,

21056, 21061, 21100 Arrgo 21023 Aspire Digital 21168, 21407 Audiovox 20790, 21071, 21072,

21121, 21122 Axion 21071, 21072 Bel Canto Design 21571 Blaupunkt 20717 Blue Parade 20571 Broksonic 20695, 20868 Cinea 20831

www.urcsupport.com

Helix 5 Device.fm Page 42 Tuesday, June 5, 2007 5:24 PM

CineVision 20876, 20833, 20869 Citizen 20695, 21277 Coby 20778, 21086, 21107, 21177 Craig 20831 Curtis Mathes 21087 CyberHome 20816, 20874, 21023,

21024, 21117, 21129, 21502 Daewoo 20784, 20705, 20833,

20869, 21169, 21172,

21234, 21242 Denon 20490, 20634 Desay 21407 DigitalMax 21738 Disney 20675, 21270 Dual 21068, 21085 Durabrand 21127 DVD2000 20521 Emerson 20591, 20675, 20821, 21268 Enterprise 20591 ESA 20821, 21268 Fisher 20670 Funai 20675, 21268, 21334 Gateway 21073, 21077, 21158, 21194 GE 20522, 20815, 20717 Go Video 20744, 20715, 20741,

20783, 20833, 20869,

21044, 21075, 21099,

21158, 21304, 21730 Go Vision 21071, 21072 GoldStar 20741 Greenhill 20717 Harman/Kardon 20582, 20702 Hitachi 20573, 20664, 21247 Hiteker 20672 Humax 21588 iLo 21348 Initial 20717 Insignia 21268 Integra 20627 JBL 20702 Jensen 21016

www.urcsupport.com

Helix 5 Device.fm Page 43 Tuesday, June 5, 2007 5:24 PM

JVC 20558, 20623, 20867,

21164, 21275, 21602, 21863 Kawasaki 20790 Kenwood 20490, 20534 KLH 20717, 20790, 21020, 21149 Koss 20651 Lasonic 20798 Lenoxx 21127 LG 20591, 20741, 20801, 20869 LiteOn 21058, 21158, 21416,

21440, 21738 Loewe 20511 Magnavox 20503, 20539, 20646,

20675, 20821, 21268, 21506 Malata 20782 Marantz 20539 McIntosh 21273 Memorex 20695, 20831, 21270 Microsoft 20522, 21708 Mintek 20839, 20717 Mitsubishi 21521, 20521 NAD 20741 Nakamichi 21222 NEC 20785 Nesa 20717 NexxTech 21402 Norcent 21003, 20872, 21107, 21265 Onkyo 20503, 20627, 20792 Oritron 20651 Panasonic 20490, 20632, 20703,

21362, 21462, 21490, 21762 Philips 20503, 20539, 20646,

20675, 20854, 21260,

21267, 21354 Pioneer 20525, 20571, 20631, 20632 Polaroid 21020, 21061, 21086 Polk Audio 20539 Portland 20770 Presidian 20675, 21072, 21738 Prima 21016 Proscan 20522 ProVision 20778

www.urcsupport.com

Helix 5 Device.fm Page 44 Tuesday, June 5, 2007 5:24 PM

Qwestar 20651 RCA 20522, 20571, 20717,

20790, 20822, 21022,

21132, 21769 Rio 20869 Rotel 20623, 21178 Rowa 20823 Sampo 20698, 20752 Samsung 20490, 20573, 20199,

20820, 20899, 21044, 21075 Sansui 20695 Sanyo 20670, 20695, 20873 Sensory Science 21158 Sharp 20630, 20675, 20752, 21256 Sharper Image 21117 Sherwood 20633, 20770, 21043, 21077 Shinsonic 20533, 20839 Sonic Blue 20869, 21099 Sony 20533, 21533, 20864,

21033, 21070, 21431, 21892 Sova 21122 Superscan 20821 Sylvania 20675, 20821, 21268 Symphonic 20675, 20821 TAG McLaren 20894 Teac 20790 Technics 20490, 20703 Theta Digital 20571 Tivo 21503 Toshiba 20503, 20695, 21045,

21154, 21503, 21588, 21769 Tredex 20800 Urban Concepts 20503 US Logic 20839 Venturer 20790 Vizio 21064, 21226 Xbox 20522, 21708 Yamaha 20490, 20539, 20545 Zenith 20503, 20591, 20741, 20869 Zoece 21265

Setup Codes for DVD/PVR Combos

www.urcsupport.com

Helix 5 Device.fm Page 45 Tuesday, June 5, 2007 5:24 PM

Controlled by the DVD

Go Video 21730 Humax 21588 Panasonic 20490 Pioneer 20631 RCA 20522 Sharp 21256 Sylvania 20675 Toshiba 21503, 21588

Controlled by the VCR

RCA 20880 Sylvania 20000 Toshiba 21008, 21996

www.urcsupport.com

Helix 5 Device.fm Page 46 Tuesday, June 5, 2007 5:24 PM

Setup Codes for Home Automation

Accutek 31215 Amana 31716 Audio Access 30154 Bionaire 30846, 31215 Comfortex 30400 Da-Lite 30780 Frigidaire 31333, 31845 GE 30240 GoldStar 31537 Holmes 31215 Hunter Douglas 30433 Kenmore 31537 Lasko 30846 LG 31537 Lightolier 30184 LiteTouch 30084 Lutron 30597, 30318, 31239, 31597 One For All 30167 PCS 30184 RadioShack 30240 Royal Sovereign 31651 Russound 31232, 31233 Security System 30167 Sharper Image 30846 SmartLinc 30184 Somfy 30780 Universal X10 30167 Whirlpool 31332 Windmere 31215 X10 30167

Setup Codes for Satellite Receivers

AlphaStar 00772 Bell ExpressVu 00775, 01170 Chaparral 00216 Coolsat 01806 Crossdigital 01109

www.urcsupport.com

Helix 5 Device.fm Page 47 Tuesday, June 5, 2007 5:24 PM

DirecTV 01377, 00392, 00566,

00639, 01639, 01142,

00247, 00749, 01749,

00724, 00819, 01856,

01076, 01108, 00099,

01109, 01392, 01414,

01442, 01443, 01444,

01609, 01640 Dish Network System 01505, 01005, 00775,

01170, 01775 Dishpro 01505, 01005, 00775, 01775 Echostar 01505, 01005, 00775,

01170, 01775 Expressvu 00775, 01775 GE 00566 General Instrument 00869 GOI 00775, 01775 Hisense 01535 Hitachi 00819, 01250 HTS 00775, 01775 Hughes Network Systems 01142, 00749, 01749,

01442, 01443, 01444 Humax 01790 iLo 01535 JVC 00775, 01170, 01775 LG 01226, 01414 Magnavox 00724, 00722 Memorex 00724 Mitsubishi 00749 Motorola 00869 Next Level 00869 Panasonic 00247, 00701 Pansat 01807 Paysat 00724 Philips 01142, 00749, 01749,

00724, 01076, 00722,

00099, 01442, 00856 Proscan 00392, 00566 Proton 01535 RadioShack 00869 RCA 00566, 00855, 00143, 01392 Samsung 01377, 01276, 01108,

01109, 01442, 01609 Sony 00639, 01639, 01640

www.urcsupport.com

Helix 5 Device.fm Page 48 Tuesday, June 5, 2007 5:24 PM

Star Choice 00869 Tivo 01142, 01442, 01443, 01444 Toshiba 00749, 01749, 00790, 01285 UltimateTV 01392, 01640 Ultrasat 01806 Uniden 00724, 00722 US Digital 01535 USDTV 01535 Voom 00869 Zenith 01856, 00856

www.urcsupport.com

Helix 5 Device.fm Page 49 Tuesday, June 5, 2007 5:24 PM

Setup Codes for DVR/PVR Systems

ABS 21972 Alienware 21972 CyberPower 21972 Dell 21972 DirecTV 20739 Gateway 21972 Go Video 20614 Hewlett Packard 21972 Howard Computers 21972 HP 21972 Hughes Network Systems 20739 Humax 20739 Hush 21972 iBUYPOWER 21972 Linksys 21972 Media Center PC 21972 Microsoft 21972 Mind 21972 Niveus Media 21972 Northgate 21972 Panasonic 20614, 20616 Philips 20618, 20739 RCA 20880 ReplayTV 20614, 20616 Samsung 20739 Sonic Blue 20614, 20616 Sony 20636, 21972 Stack 9 21972 Systemax 21972 Tagar Systems 21972 Tivo 20618, 20636, 20739 Toshiba 21008, 21972, 21996 Touch 21972 Viewsonic 21972 Voodoo 21972 ZT Group 21972

Setup Codes for TVs

A-Mark 10003

www.urcsupport.com

Helix 5 Device.fm Page 50 Tuesday, June 5, 2007 5:24 PM

Abex 10032 Accurian 11803 Action 10873 Admiral 10093, 10463 Advent 10761, 10783, 10815,

10817, 10842, 11933 Adventura 10046 Aiko 10092 Akai 10812, 10702, 10030,

10672, 11207, 11675,

11676, 11903, 11935 Alaron 10179 Albatron 10700, 10843 Ambassador 10177 America Action 10180 Ampro 10751 Anam 10180 AOC 10030, 10003, 10052, 11365 Apex Digital 10748, 10879, 10765,

10767, 10890, 11217, 11943 Archer 10003 Astar 11531, 11548 Audiovox 10451, 10180, 10092,

10003, 10623, 10710,

10802, 10846, 10875,

11284, 11937, 11951, 11952 Aventura 10171 Axion 11937 Bell & Howell 10154, 10016 BenQ 11032, 11315 Bradford 10180 Broksonic 10236, 10463, 10003,

11911, 11929, 11935, 11938 Byd:sign 11309, 11311 Cadia 11283 Candle 10030, 10046, 10056 Carnivale 10030 Carver 10054 Celebrity 10000 Celera 10765 Champion 11362 Changhong 10765

www.urcsupport.com

Helix 5 Device.fm Page 51 Tuesday, June 5, 2007 5:24 PM

Cinego 11986 Citizen 10060, 10030, 10092,

10039, 10046, 10056,

10280, 11928, 11935 Clarion 10180 Commercial Solutions 11447, 10047 Concerto 10056 Contec 10180 Craig 10180 Crosley 10054 Crown 10180, 10039 Curtis Mathes 10047, 10054, 10154,

10451, 10093, 10060,

10702, 10030, 10145,

10166, 11919, 11347,

11147, 10466, 10056,

10039, 10016 CXC 10180 CyberHome 10794 Cytron 11326 Daewoo 10451, 10092, 11661,

10039, 10623, 10661,

10672, 11928 Dell 11080, 11178, 11264, 11403 Denon 10145, 10511 Denstar 10628 Diamond Vision 11996, 11997 Dumont 10017 Durabrand 10463, 10180, 10178,

10171, 11034, 10003 Dwin 10720, 10774 Electroband 10000 Electrograph 11623, 11755 Electrohome 10463 Emerson 10154, 10236, 10463,

10180, 10178, 10171,

11963, 11944, 11929,

11928, 11911, 11394,

10623, 10280, 10179,

10177, 10039, 10038 Emprex 11422, 11546 Envision 10030, 10813, 11365 Epson 10833, 10840, 11290 ESA 10812, 10171, 11944, 11963

www.urcsupport.com

Helix 5 Device.fm Page 52 Tuesday, June 5, 2007 5:24 PM

Fisher 10154 FlexVision 10710 Fujitsu 10179, 10683, 10809, 10853 Funai 10180, 10171, 10179,

11271, 11904, 11963 Futuretech 10180 Gateway 11001, 11002, 11003,

11004, 11755, 11756 GE 11447, 10047, 10051,

10451, 10178, 10021,

10027, 11347, 11917,

11919, 11922 Gibralter 10017, 10030 Go Video 10886 GoldStar 10178, 10030, 10032, 11926 Grunpy 10180, 10179 Haier 11034, 10768 Hallmark 10178 Hannspree 11348, 11351, 11352 Harley Davidson 10179, 11904 Harman/Kardon 10054 Harvard 10180 Havermy 10093 Helios 10865 Hello Kitty 10451 Hewlett Packard 11088, 11089, 11101,

11494, 11502, 11642 Hisense 10748 Hitachi 11145, 10145, 10016,

10032, 10038, 10056,

10797, 11904, 11960 HP 11088, 11089, 11101,

11494, 11502, 11642 Hyundai 10849, 11219, 11294 iLo 11286, 11603, 11990 Infinity 10054 Initial 11603, 11990 Insignia 10171, 11204, 11326,

11517, 11564, 11963, 12002 Inteq 10017 Janeil 10046 JBL 10054 JCB 10000

www.urcsupport.com

Helix 5 Device.fm Page 53 Tuesday, June 5, 2007 5:24 PM

Jensen 10761, 10815, 10817,

11299, 11933 JVC 10053, 10731, 11253, 11923 Kaypani 10052 KDS 11498 KEC 10180 Kenwood 10030 KLH 10765, 10767, 11962 Kloss 10024, 10046 Konka 10628, 10632, 10638,

10703, 10707 Kost 11262, 11483 KTV 10180, 10030, 10039, 10280 LG 11265, 10178, 10700,

10823, 10829, 10856,

11178, 11325, 11423,

11758, 11993 Lloyd's 11904 Logik 10016 Luxman 10056 LXI 10047, 10054, 10154,

10156, 10178 MAG 11498 Magnasonic 11928 Magnavox 11454, 10054, 10030,

10706, 11990, 11963,

11944, 11931, 11904,

11525, 11365, 11254,

11198, 10802, 10386,

10187, 10179, 10096,

10024, 10020 Majestic 10016 Marantz 10054, 10030, 10704,

10854, 10855, 11154, 11398 Matsushita 10250, 10650 Maxent 10762, 11211, 11755 Megapower 10700 Megatron 10178, 10145, 10003 Memorex 10154, 10463, 10150,

10178, 10016, 10179,

11911, 11926 MGA 10150, 10178, 10030 Midland 10047, 10017, 10051,

10032, 10039

www.urcsupport.com

Helix 5 Device.fm Page 54 Tuesday, June 5, 2007 5:24 PM

Mintek 11603, 11990 Minutz 10021 Mitsubishi 10093, 11250, 10150,

10178, 10836, 10868,

11550, 11917 Monivision 10700, 10843 Motorola 10093, 10835 Moxell 10835 MTC 10060, 10030, 10056 Multitech 10180 NAD 10156, 10178, 10056,

10866, 11156 NEC 10030, 10056, 10497,

10882, 11398, 11704 NetTV 10762, 11755 Nikko 10178, 10030, 10092 Norcent 10748, 10824, 11089,

11365, 11589, 11590, 11591 Norwood Micro 11286, 11296, 11303 Noshi 10018 NTC 10092 Olevia 11144, 11240, 11331, 11610 Olympus 11342 Onwa 10180 Optimus 10154, 10250, 10166, 10650 Optoma 10887 Optonica 10093 Orion 10236, 10463, 11463,

10179, 11911, 11929 Panasonic 10250, 10051, 10650,

11291, 11410, 11480,

11919, 11941, 11946, 11947 Penney 10047, 10156, 10051,

10060, 10178, 10030,

10003, 10018, 10021,

10027, 10032, 10039,

11347, 11919, 11926 Petters 11523 Philco 10054, 10030, 10020, 10096 Philips 11454, 10054, 10690,

11154, 11483, 11961 Pilot 10030, 10039 Pioneer 10166, 10038, 10679,

10866, 11260, 11398

www.urcsupport.com

Helix 5 Device.fm Page 55 Tuesday, June 5, 2007 5:24 PM

Polaroid 10765, 10865, 11262,

11276, 11314, 11316,

11326, 11327, 11328,

11341, 11498, 11523,

11962, 11991, 11992 Portland 10092, 10039 Prima 10761, 10783, 10815,

10817, 11933 Princeton 10700, 10717 Prism 10051 Proscan 11447, 10047, 11347, 11922 Proton 10178, 10003, 10052, 10466 Protron 11320, 11323 Proview 10835, 11401, 11498 Pulsar 10017 Quasar 10250, 10051, 10650, 11919 RadioShack 10047, 10154, 10180,

10178, 10030, 10032,

10039, 10056, 11904 RCA 11447, 10047, 12002,

11958, 11953, 11948,

11922, 11919, 11917,

11547, 11347, 11247,

11147, 11047, 10679,

10090, 10038, 10018 Realistic 10154, 10180, 10178,

10030, 10032, 10039, 10056 Runco 10017, 10030, 10497,

10603, 11398 Sampo 10030, 10032, 10039,

10052, 10762, 11755 Samsung 10060, 10812, 10702,

10178, 10030, 10032,

10056, 10766, 10814,

11060, 11312, 11395,

11575, 11903, 11959 Samsux 10039 Sansui 10463, 11409, 11904,

11911, 11929, 11935 Sanyo 10154, 10088, 10146,

10799, 10893, 11142 Sceptre 10878, 11217, 11360, 11599 Scotch 10178 Scott 10236, 10180, 10178, 10179

www.urcsupport.com

Helix 5 Device.fm Page 56 Tuesday, June 5, 2007 5:24 PM

Sears 10047, 10054, 10154,

10156, 10178, 10171,

10056, 10146, 10179,

11904, 11926 Sharp 10093, 10039, 10386,

10491, 10688, 10689,

10818, 10851, 11602,

11917, 11393 Sheng Chia 10093 Sherwood 11399 Signature 10016 Signet 11262 SIM2 Multimedia 11297 Simpson 10187 Sony 11100, 10000, 10834,

11317, 11685, 11904, 11925 Soundesign 10180, 10178, 10179 Sova 11320, 11952 Soyo 11520 Spectricon 10003 Spectroniq 11498 Squareview 10171 SSS 10180 Starlite 10180 Studio Experience 10843 Superscan 10093, 10864 Supre-Macy 10046 Supreme 10000 SVA 10748, 10587, 10768,

10865, 10870, 10871, 10872 Sylvania 10054, 10030, 10171,

10020, 10096, 11271,

11314, 11394, 11931,

11944, 11963 Symphonic 10180, 10171, 11904, 11944 Syntax 11144, 11240, 11331 Tandy 10093 Tatung 10003, 11101, 11285,

11286, 11287, 11288,

11361, 11756 Technics 10250, 10051 Technol Ace 10179 Techview 10847 Techwood 10051, 10003, 10056

www.urcsupport.com

Helix 5 Device.fm Page 57 Tuesday, June 5, 2007 5:24 PM

Teknika 10054, 10180, 10150,

10060, 10092, 10016,

10039, 10056, 10179 Telefunken 10702, 10056 Thomas 11904 TMK 10178, 10056, 10177 TNCi 10017 Toshiba 10154, 11256, 10156,

11265, 10060, 11945,

11936, 11935, 11918,

11704, 11656, 11635,

11524, 11356, 11343,

11325, 11306, 11156,

10845, 10832, 10650, 11971 Totevision 10039 TVS 10463 Ultra 11323 Universal 10027 US Logic 11286, 11303 Vector Research 10030 Victor 10053 Vidikron 10054, 11398 Vidtech 10178 Viewsonic 10797, 10857, 10864,

10885, 11330, 11342,

11578, 11627, 11640, 11755 Viking 10046 Viore 11207 Visart 11336 Vizio 10864, 10885, 11499,

11756, 11758 Wards 10054, 10178, 10030,

10016, 10020, 10021,

10027, 10056, 10096,

10179, 10866, 11156 Waycon 10156 Westinghouse 10885, 10889, 10890,

11282, 11577 White Westinghouse 10463, 10623 Wyse 11365 Yamaha 10030, 10769, 10797,

10833, 10839 Zenith 10017, 10463, 11265,

10178, 10092, 10016,

11904, 11911, 11929

www.urcsupport.com

Helix 5 Device.fm Page 58 Tuesday, June 5, 2007 5:24 PM

Zonda 10003

Setup Codes for TVs (DLP)

Hewlett Packard 11494 HP 11494 LG 11265 Magnavox 11525 Mitsubishi 11250 Optoma 10887 Panasonic 11291 RCA 11447 Samsung 10812, 11060, 11312 SVA 10872 Toshiba 11265, 11306 Vizio 11499

Setup Codes for TVs (LCD)

Accurian 11803 Action 10873 Akai 11675, 11676, 11935 AOC 11365 Apex Digital 10890, 11217 Astar 11531, 11548 Audiovox 10180, 10710, 10802,

10846, 10875, 11284,

11937, 11951, 11952 BenQ 11315 Byd:sign 11309, 11311 Cadia 11283 Citizen 11935 CyberHome 10794 Dell 11080, 11178, 11264 Emprex 11422, 11546 Envision 10813, 11365 FlexVision 10710 Funai 10171 Go Video 10886 Hannspree 11348, 11351 Hewlett Packard 11088, 11642

www.urcsupport.com

Helix 5 Device.fm Page 59 Tuesday, June 5, 2007 5:24 PM

HP 11088, 11642 Hyundai 10849, 11219, 11294 iLo 11286, 11603, 11990 Initial 11603, 11990 Insignia 11204, 11517, 11564, 12002 Jensen 11299 Kost 11262 LG 10856, 11178, 11993 Magnavox 10802, 11198, 11365, 11990 Marantz 10855 Maxent 10762, 11211, 11755 Mintek 11603, 11990 Mitsubishi 11250 NetTV 10762 Norcent 11365, 11589, 11591 Norwood Micro 11286, 11296 Olevia 11144, 11240, 11331, 11610 Panasonic 10650, 11941 Petters 11523 Philips 11454, 11483 Polaroid 11262, 11276, 11316,

11341, 11498, 11523 Protron 11320, 11323 Proview 11401 RCA 10047, 11958 Sampo 10762, 11755 Samsung 10812, 10766, 10814,

11395, 11575 Sansui 11409 Sanyo 11142 Sceptre 10878, 11217, 11360, 11599 Sharp 10093, 10818, 11602 Sherwood 11399 Signet 11262 Sony 11685 Sova 11320 Soyo 11520 Superscan 10864 SVA 10587, 10870, 10871 Sylvania 10171, 11271, 11314, 11394 Symphonic 10171

www.urcsupport.com

Helix 5 Device.fm Page 60 Tuesday, June 5, 2007 5:24 PM

Syntax 11144, 11240, 11331 Tatung 11286 Techview 10847 Toshiba 10845, 11343, 11524,

11635, 11656 Ultra 11323 US Logic 11286 Vidikron 11398 Viewsonic 10857, 10864, 10885,

11330, 11578, 11627, 11640 Visart 11336 Vizio 10864, 10885, 11756, 11758 Westinghouse 10885, 10889, 10890,

11282, 11577 Wyse 11365 Zenith 11265

Setup Codes for TVs (Plasma)

Akai 10812, 11207, 11675 Albatron 10843 BenQ 11032 Byd:sign 11311 Daewoo 10661 Dell 11264 Electrograph 11623, 11755 ESA 10812 Fujitsu 10683, 10809, 10853 Funai 11271 Gateway 11001, 11002, 11003,

11004, 11755, 11756 Helios 10865 Hewlett Packard 11089, 11502 Hitachi 10797 HP 11089, 11502 Insignia 11564 JVC 10731 LG 10178, 10829, 10856,

11423, 11758 Marantz 10704, 11398 Maxent 11755 Mitsubishi 10836

www.urcsupport.com

Helix 5 Device.fm Page 61 Tuesday, June 5, 2007 5:24 PM

Monivision 10843 Motorola 10835 Moxell 10835 NEC 11398, 11704 NetTV 11755 Norcent 10824, 11089, 11590 Norwood Micro 11303 Panasonic 10250, 10650, 11480 Philips 10690 Pioneer 10679, 11260, 11398 Polaroid 10865, 11276, 11327, 11328 Proview 10835 Runco 11398 Sampo 11755 Samsung 10812, 11312 Sony 10000, 11317 Studio Experience 10843 SVA 10865 Sylvania 11271, 11394 Tatung 11101, 11285, 11287,

11288, 11756 Toshiba 10650, 11704 US Logic 11303 Viewsonic 10797, 11755 Viore 11207 Vizio 11756, 11758 Yamaha 10797 Zenith 10178

www.urcsupport.com

Helix 5 Device.fm Page 62 Tuesday, June 5, 2007 5:24 PM

Setup Codes for TV/DVD Combos

Controlled by the TV

Accurian 11803 Advent 11933 Akai 11675, 11935 Apex Digital 11943 Audiovox 11937, 11951, 11952 Axion 11937 Broksonic 11935 Cinego 11986 Citizen 11935 Diamond Vision 11997 Emerson 11394, 11963 ESA 11963 Funai 11963 Hitachi 11960 iLo 11990 Initial 11990 Insignia 11963, 12002 Jensen 11933 KLH 11962 LG 11993 Magnavox 11963, 11990 Mintek 11990 Panasonic 11941 Philips 11961 Polaroid 11962, 11991 Prima 11933 RCA 11948, 11958, 12002 Samsung 11903 Sansui 11935 Sova 11952 Sylvania 11394, 11963 Toshiba 11635, 11935

Controlled by the DVD

Advent 21016 Akai 20695 Apex Digital 20830 Audiovox 21071, 21121, 21122

www.urcsupport.com

Helix 5 Device.fm Page 63 Tuesday, June 5, 2007 5:24 PM

Axion 21071 Broksonic 20695 Citizen 20695 Emerson 20675, 21268 ESA 21268 Funai 21268 Go Vision 21071 Hitachi 21247 Insignia 21268 Jensen 21016 Magnavox 21268 Panasonic 21490 Philips 20854, 21260 Prima 21016 RCA 21022 Samsung 20899 Sansui 20695 Sova 21122 Sylvania 20675, 21268 Toshiba 20695

www.urcsupport.com

Helix 5 Device.fm Page 64 Tuesday, June 5, 2007 5:24 PM

Setup Codes for TV/VCR Combos

Controlled by the TV

America Action 10180 Audiovox 10180 Broksonic 11911, 11929 Citizen 11928 Curtis Mathes 11919 Daewoo 11928 Emerson 10236, 11911, 11928, 11929 Funai 11904 GE 11917, 11919, 11922 GoldStar 11926 Harley Davidson 11904 Hitachi 11904 JVC 11923 Lloyd's 11904 Magnasonic 11928 Magnavox 11904, 11931 Memorex 11926 Mitsubishi 11917 Orion 11911, 11929 Panasonic 11919 Penney 11919, 11926 Quasar 11919 RadioShack 11904 RCA 11917, 11919, 11922 Samsung 11959 Sansui 11904, 11911, 11929 Sears 11904, 11926 Sony 11904, 11925 Sylvania 11931 Symphonic 11904 Thomas 11904 Toshiba 11918, 11936 Zenith 11904, 11911, 11929

Controlled by the VCR

America Action 20278 Audiovox 20278 Broksonic 20002, 20479, 21479

www.urcsupport.com

Helix 5 Device.fm Page 65 Tuesday, June 5, 2007 5:24 PM

Citizen 21278 Colt 20072 Curtis Mathes 21035 Daewoo 21278 Emerson 20002, 20479, 20593,

21278, 21479 Funai 20000 GE 20240, 20807, 21035, 21060 GoldStar 21237 Harley Davidson 20000 Hitachi 20000 LG 21037 Lloyd's 20000 Magnasonic 20593, 21278 Magnavox 20000, 20593, 21781 Magnin 20240 Memorex 20162, 21037, 21162,

21237, 21262 MGA 20240 Mitsubishi 20807 Optimus 20162, 20593, 21162, 21262 Orion 20002, 20479, 21479 Panasonic 20162, 21035, 21162, 21262 Penney 20240, 21035, 21237 Quasar 20162, 21035, 21162 RadioShack 20000, 21037 RCA 20240, 20807, 21035, 21060 Samsung 21014 Sansui 20000, 20479, 21479 Sanyo 20240 Sears 20000, 21237 Sony 20000, 21232 Sylvania 21781 Symphonic 20000, 20593 Thomas 20000 Toshiba 20845, 21145 Zenith 20000, 20479, 21479

www.urcsupport.com

Helix 5 Device.fm Page 66 Tuesday, June 5, 2007 5:24 PM

Setup Codes for VCRs

ABS 21972 Admiral 20048, 20209 Adventura 20000 Aiko 20278 Aiwa 20037, 20000, 20124 Alienware 21972 America Action 20278 American High 20035 Asha 20240 Audiovox 20037, 20278 Beaumark 20240 Bell & Howell 20104 Broksonic 20184, 20121, 20209,

20002, 20479, 21479 Calix 20037 Canon 20035 Carver 20081 CCE 20072, 20278 Citizen 20037, 20278, 21278 Colt 20072 Craig 20037, 20047, 20240, 20072 Curtis Mathes 20060, 20035, 20162, 21035 Cybernex 20240 CyberPower 21972 Daewoo 20045, 20278, 21278 Dell 21972 Denon 20042 DirecTV 20739 Durabrand 20039, 20038 Dynatech 20000 Electrohome 20037 Electrophonic 20037 Emerex 20032 Emerson 20037, 20184, 20000,

20121, 20043, 20209,

20002, 20278, 20479,

20593, 21278, 21479, 21593 Fisher 20047, 20104 Fuji 20035, 20033 Funai 20000, 20593, 21593

www.urcsupport.com

Helix 5 Device.fm Page 67 Tuesday, June 5, 2007 5:24 PM

Garrard 20000 Gateway 21972 GE 20060, 20035, 20240,

20807, 21035, 21060 Go Video 20432, 20614 GoldStar 20037, 20038, 21237 Gradiente 20000 Harley Davidson 20000 Harman/Kardon 20081, 20038 Harwood 20072 Hewlett Packard 21972 HI-Q 20047 Hitachi 20000, 20042, 20089 Howard Computers 21972 HP 21972 Hughes Network Systems 20042, 20739 Humax 20739 Hush 21972 iBUYPOWER 21972 JVC 20067 KEC 20037, 20278 Kenwood 20067, 20038 KLH 20072 Kodak 20035, 20037 LG 21037 Linksys 21972 Lloyd's 20000 Logik 20072 LXI 20037 Magnasonic 20593, 21278 Magnavox 20035, 20039, 20081,

20000, 20149, 20563,

20593, 21593, 21781 Magnin 20240 Marantz 20035, 20081 Marta 20037 Matsushita 20035, 20162, 21162 Media Center PC 21972 MEI 20035

www.urcsupport.com

Helix 5 Device.fm Page 68 Tuesday, June 5, 2007 5:24 PM

Memorex 20035, 20162, 20037,

20048, 20039, 20047,

20240, 20000, 20104,

20209, 20479, 21037,

21162, 21237, 21262 MGA 20240, 20043 MGN Technology 20240 Microsoft 21972 Mind 21972 Minolta 20042 Mitsubishi 20067, 20043, 20807 Motorola 20035, 20048 MTC 20240, 20000 Multitech 20000, 20072 NEC 20104, 20067, 20038 Nikko 20037 Niveus Media 21972 Noblex 20240 Northgate 21972 Olympus 20035 Optimus 21062, 20162, 20037,

20048, 20104, 20432,

20593, 21162, 21262 Orion 20184, 20209, 20002,

20479, 21479 Panasonic 21062, 20035, 20162,

20225, 20614, 20616,

21035, 21162, 21262 Penney 20035, 20037, 20240,

20042, 20038, 21035, 21237 Pentax 20042 Philco 20035 Philips 20035, 20081, 20618,

20739, 21081, 21181 Pilot 20037 Pioneer 20067 Polk Audio 20081 Presidian 21593 Profitronic 20240 Proscan 20060, 21060 Protec 20072 Pulsar 20039 Quasar 20035, 20162, 21035, 21162

www.urcsupport.com

Helix 5 Device.fm Page 69 Tuesday, June 5, 2007 5:24 PM

RadioShack 20000, 21037 Radix 20037 Randex 20037 RCA 20060, 20240, 20042,

20149, 20807, 20880,

21035, 21060 Realistic 20035, 20037, 20048,

20047, 20000, 20104 ReplayTV 20614, 20616 Ricavision 21972 Runco 20039 Samsung 20240, 20045, 20739, 21014 Sanky 20048, 20039 Sansui 20000, 20067, 20209,

20479, 21479 Sanyo 20047, 20240, 20104 Scott 20184, 20045, 20121, 20043 Sears 20035, 20037, 20047,

20000, 20042, 20104, 21237 Sharp 20048, 20807, 20848 Shintom 20072 Shogun 20240 Singer 20072 Sonic Blue 20614, 20616 Sony 20035, 20032, 20033,

20000, 20636, 21032,

21232, 21972 Stack 9 21972 STS 20042 Sylvania 20035, 20081, 20000,

20043, 20593, 21593, 21781 Symphonic 20000, 20593, 21593 Systemax 21972 Tagar Systems 21972 Teac 20000 Technics 20035, 20162 Teknika 20035, 20037, 20000 Thomas 20000 Tivo 20618, 20636, 20739, 21996 TMK 20240 Toshiba 20045, 20043, 20845,

21008, 21145, 21972, 21996 Totevision 20037, 20240

www.urcsupport.com

Helix 5 Device.fm Page 70 Tuesday, June 5, 2007 5:24 PM

Touch 21972 Unitech 20240 Vector 20045 Vector Research 20038 Video Concepts 20045 Videomagic 20037 Videosonic 20240 Viewsonic 21972 Villain 20000 Voodoo 21972 Wards 20060, 20035, 20048,

20047, 20081, 20240,

20000, 20042, 20072, 20149 White Westinghouse 20209, 20072 XR-1000 20035, 20000, 20072 Yamaha 20038 Zenith 20039, 20033, 20000,

20209, 20479, 21479 ZT Group 21972

Setup Codes for Video Accessories

ABS 01272 Accurian 01653 Alienware 01272 CyberPower 01272 D-Link 01554, 01731 Epson 01563 Escient 01151, 01370, 01371 Gateway 01272 Hewlett Packard 01272, 01267 Howard Computers 01272 HP 01272 Hush 01272 iBUYPOWER 01272 JVC 01384 LG 01415 Linksys 01272, 01365 Media Center PC 01272 Microsoft 01272 Mind 01272 Motorola 01363

www.urcsupport.com

Helix 5 Device.fm Page 71 Tuesday, June 5, 2007 5:24 PM

Niveus Media 01272 Northgate 01272 Panasonic 01120 Pioneer 01010 Ricavision 01272 Roku 01486 Samsung 01190, 01490 Sensory Science 01126 Sharp 01010 Sony 01272, 01324, 01364 Stack 9 01272 Sylvania 01563 Systemax 01272 Tagar Systems 01272 Toshiba 01272 Touch 01272 Viewsonic 01272, 01329 Vizio 01126 Voodoo 01272 ZT Group 01272

www.urcsupport.com

Helix 5 Device.fm Page 72 Tuesday, June 5, 2007 5:24 PM

URC-5300

Revision 1.0

Universal Electronics Helix Z-wave User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
