Page 1
UNI-T
Manual
UTD2000E Series Programmable Digital Oscilloscope
June 2017
Uni-Trend Technology (China) Co., Ltd.
Page 2
UNI-T
Warranty and Statement
Copyright
2017 U n i - T r e n d T e c h n o l o g y (Ch i n a ) C o . , L td .
Brand Information
UNI-T is the registered trademark of Uni-Trend Technology (China) Co., Ltd.
Software Version
00.00.01
Software upgrade may have some change and add more function, please subscribe
UNI-T website to get the new version or contact UNI-T.
Statement
UNI-T products are protected by patents (including obtained and pending) in China and
other countries and regions.
UNI-T reserves the right to change specifications and prices.
The information provided in this manual supersedes all previous publications.
Information provided in this manual is subject to change without prior notice.
UNI-T shall not be liable for any errors that may be contained in this manual. For any
incidental or consequential damages, arising out of the use or the information and
deductive functions provided in this manual.
Without the written permission of UNI-T, this manual cannot photocopied, reproduced
or adapted.
Product Certification
UNI-T has certified that the product conforms to China national product standard and
industry product standard as well as ISO9001:2008 standard and ISO14001:2004
standard. UNI-T will go further to certificate product to meet the standard of other
member of the international standards organization.
Contact Us
If you have any question or problem, you can contact us,
Website：https://www.uni-trend.com
UTD2000E Series Osilloscope Programming Manual
Page 3
UNI-T
e format, symbols, parameters, and abbreviations of the SCPI command.
Instruction Format
The SCPI command is a tree-like hierarchy consisting of multiple subsystems, each
consisting of a root keyword and one or more hierarchical key words. The command
line usually begins with a colon ":"; Keywords are separated by the colon ":",
followed by optional parameter settings. The command keyword is separated by
spaces from the first parameter. The command string must end with a newline
<NL> character. Add the question mark "? " after the command line. It is
usually indicated that this feature is being queried.
Symbol Description
The following four symbols are not part of SCPI command, it cannot send with the
command. It usually used as supplementary description of command parameter.
Brace { } usually contains multiple optional parameters, it should select one
parameter when send command.
Such as DISPlay:GRID:MODE { FULL | GRID | CROSS | NONE} command
Vertical Bar | used to separated multiple parameters, it should select one parameter
when send command.
Such as DISPlay:GRID:MODE { FULL | GRID | CROSS | NONE} command
Square Brackets [ ] the contents in square brackets (command keywords) can
omissible. If the parameter is ignoret, the instrument will set the parameter as the
default value.
Such as MEASure:NDUTy? [<source>] command, it presents current channel
Triangular Brackets < > The parameter in the brackets must be replaced with a
valid value.
Such as use DISPlay:GRID:BRIGhtness 30 form to send DISPlay:GRID:BRIGhtness
<count> command.
UTD2000E Series Osilloscope Programming Manual
Page 4
Parameter Description
The parameter in this manual can divide into five types: Boolean, Integer, Real,
Discrete, ASCII string
Boolean
Parameter value can set “ON” (1) or “OFF” (0)
Such as SYSTem:LOCK {{1 | ON} | {0 | OFF}}
Integer
Parameter can take any valid integer value unless there have some other
descriptions.
Such as command: DISPlay:GRID:BRIGhtness <count> , parameter of
<count> can take integer from 0~100
Note: Do not set decimal as parameter, otherwise it may occur error.
UNI-T
Real
Parameter can take any valid integer value unless there have some other
descriptions.
Such as for command CH1, CHANnell: OFFSet <offset> , parameter of <offset>
can take integer value.
Discrete
Parameter can only take some specified numbers or characters.
Such as command DISPlay:GRID:MODE { FULL | GRID | CROSS | NONE}
parameter can only take FULL, GRID, CROSS, NONE
ASCII Character String
String parameter contain all ASCII string sets. Strings must begin and end
with paired quotes; it can use single or double quotation marks. The quotation
and delimiter can also be part of a string by typing it twice and not adding any
characters.
Such as set IP SYST:COMM:LAN:IPAD "192.168.1.10".
UTD2000E Series Osilloscope Programming Manual
Page 5
UNI-T
Shorthand Rule
All command can identify capital and small letter, if command need enter shorthand,
it should be all capital letter.
Data Return
Data return is divided into single data and batch data. The single data return is the
corresponding parameter type, in which the real return type is presents by the
scientific notation method. The part before e retains three figure behind the decimal
point, and the e part retains three figure; the batch return must be obey IEEE
488.2# string data format, ‘#’+ the length of character bits[fixed to one character]+
ASCII valid value+ valid data+ end string[‘\n’]
Such as #3123xxxxxxxxxxxxxxxxxxx\n presents 123 strings batch data return format, ‘3’
presents “123” occupies three character bits.
Notes：* presents return valid data.
UTD2000E Series Osilloscope Programming Manual
Page 6
SCPI Command
IEEE488.2 Common Command
*IDN?
Command format：
*IDN?
Functional description：
For query manufacture name, model, product serial number and software version.
Return format：
Manufacture name, model, product serial number, software version separated by dot
mark.
For example：
UNI-T Technologies, UPO2000CS, UPO1000, 00.00.01
*RST
UNI-T
Command format：
*RST
Functional description：
Restore factory settings and clear the entire error message, send and receive queue buffers.
SYSTem Command
The command used for the oscilloscope basic operation, including operating control,
full qwerty lock, error queue and system setup.
:RUN
Command format：
:RUN
Functional description：
Oscilloscope start to sampling, execute :STOP command to stop it.
:STOP
Command format：
:STOP
Functional description：
Stop sampling function, execute :RUN command to start it.
UTD2000E Series Osilloscope Programming Manual
Page 7
:AUTO
Command format：
:AUTO
Functional description：
Set control parameter automatically, use auto function to achieve the best display effect.
:SYSTem:LOCK
Command format：
:SYSTem:LOCK {{1 | ON} | {0 | OFF}}
:SYSTem:LOCK?
Functional description：
For lock/unlock full qwerty.
Return format：
Query return full qwerty lock status, 0 presents unlock，1 presents lock.
For example：
:SYSTem:LOCK ON/:SYST:LOCK 1 full qwerty lock
:SYSTem:LOCK OFF/:SYST:LOCK 0 unlock full qwerty
:SYSTem:LOCK? query return 1，it presents locked
UNI-T
:SYSTem:ERRor
Command format：
:SYSTem:ERRor
:SYSTem:ERRor?
Functional description：
Empty error message queue.
Return format：
Query return the last time error message, return error message by query format <message
number>,<message content>, <message number> is a integer，<message content> is ASCII
character string with double quotation marks.
like-113,"Undefined header; command cannot be found"
For example：
:SYSTem:ERR empty error message queue
:SYSTem:ERR? query return：
-113,"Undefined header; command cannot be found"
presents undefined command head
UTD2000E Series Osilloscope Programming Manual
Page 8
:SYSTem:SETup
Command format：
:SYSTem:SETup <setup_data>
:SYSTem:SETup?
Functional description：
Set system configuration data, <setup_data> is conform to IEEE 488.2 # format of binary data.
In sending，data flow is followed command character and complete send in time.
In reading, make sure there has enough buffer to receive data flow, otherwise it may occurred
abnormal.
Return format：
Query return system setup data, return format is conform to IEEE 488.2 # format of binary data.
:SYSTem:LANGuage
Command format：
:SYSTem:LANGuage {
:SYSTem:LANGuage?
Functional description：
Set system language.
Return format：
Query return{ ENGLish | SIMPlifiedchinese | TRADitionalchinese }.
For example：
:SYSTem:LANGuage ENGL set system language as English
:SYSTem:LANGuage? query returnENGLish
ENGLish | SIMPlifiedchinese | TRADitionalchinese }
UNI-T
:SYSTem:CAL
Command format：
:SYSTem:
Functional description：
Set system self-calibration, during self-calibration, oscilloscope can not communication.
CAL
:SYSTem:CLEAr
Command format：
:SYSTem:
Functional description：
Empty system saved waveform and setup data.
UTD2000E Series Osilloscope Programming Manual
CLEAr
Page 9
:SYSTem:CYMOmeter
Command format：
:SYSTem:CYMOmeter {1 | ON} | {0 | OFF}
:SYSTem:CYMOmeter?
Functional description：
The switch of frequency meter.
Return format：
Query return frequency meter status，1 presents on, 0 presents off.。
For example：
:SYSTem:CYMOmeter ON open frequency meter
:SYSTem:CYMOmeter? query return 1
:SYSTem:CYMOmeter:FREQuency?
Command format：
:SYSTem:CYMOmeter:FREQuency?
Functional description：
Acquire measured frequency value of frequency meter.
Return format：
Query return measured frequency value of frequency meter, invalid value return *.
For example：
:SYSTem:CYMOmeter:FREQuency? query return 1.20000E+3
UNI-T
:SYSTem:SQUare:SELect
Command format：
:SYSTem:SQUare:SELect { 10Hz | 100Hz | 1KHz | 10KHz }
:SYSTem:SQUare:SELect?
Functional description：
Select square wave output.
Return format：
Query return{ 10Hz | 100Hz | 1KHz | 10KHz }。
For example：
:SYSTem:SQUare:SELect 10Hz select 10Hz of saquare wave output
:SYSTem:SQUare:SELect? query return 10Hz
:SYSTem:MNUDisplay
Command format：
:SYSTem:MNUDisplay { 5S | 10S | 20S | INFinite}
UTD2000E Series Osilloscope Programming Manual
Page 10
:SYSTem:MNUDisplay?
Functional description：
Set menu display time, INFinite presents menu is display all time.
Return format：
Query return{ 5S | 10S | 20S | INFinite }。
For example：
:SYSTem:MNUDisplay 5S set menu display base as 5s, automatic fold.
:SYSTem:MNUDisplay? query return 5S
:SYSTem:BRIGhtness
Command format：
:SYSTem:BRIGhtness <count>
:SYSTem:BRIGhtness?
Functional description：
Set screen luminance, <count> take value from 1~100，the bigger the number, the brighter the
screen.
Return format：
Query return the current screen luminance.
For example：
:SYSTem:BRIGhtness 50 screen luminance as 50
:SYSTem:BRIGhtness? query return 50
UNI-T
:SYSTem:VERSion?
Command format：
:SYSTem:VERSion?
Return format：
Query return version information, 128 bytes character string.
HW is hardware version number, SW is software version numer，PD is created date, ICV is
protocol version number.
For example：
:SYST:VERS? query return HW:1.0;SW:1.0;PD:2014-11-20;ICV:1.4.0
:SYSTem:COMMunicate:LAN:APPLy
Command format：
:SYSTem:COMMunicate:LAN:APPLy
Functional description：
The current internet parameter take effect immediately.
UTD2000E Series Osilloscope Programming Manual
Page 11
:SYSTem:COMMunicate:LAN:GATEway
Command format：
:SYSTem:COMMunicate:LAN:GATEway <gateway>
:SYSTem:COMMunicate:LAN:GATEway?
Functional description：
For the default gateway, <gateway> is belong to ASCII character string parameter，format is
xxx.xxx.xxx.xxx.
Return format：
Query return the default gateway.
For example：
:SYST:COMM:LAN:GATE "192.168.1.1" set default gateway as 192.168.1.1
:SYST:COMM:LAN:GATE? query return 192.168.1.1
:SYSTem:COMMunicate:LAN:SMASK
UNI-T
Command format：
:SYSTem:COMMunicate:LAN:SMASK <submask>
:SYSTem:COMMunicate:LAN:SMASK?
Functional description：
Set subnet mask, <submask> is belong to ASCII character string parameter， format is
xxx.xxx.xxx.xxx.
Return format：
Query return subnet mask.
For example：
:SYST:COMM:LAN:SMASK "255.255.255.0" set subnet mask as 255.255.255.0
:SYST:COMM:LAN:SMASK? query return 255.255.255.0
:SYSTem:COMMunicate:LAN:IPADdress
Command format：
:SYSTem:COMMunicate:LAN:IPADdress <ip>
:SYSTem:COMMunicate:LAN:IPADdress?
Functional description：
Set IP address, <ip> is belong to ASCII character string parameter，format is xxx.xxx.xxx.xxx。
Return format：
Query return IP address
For example：
UTD2000E Series Osilloscope Programming Manual
Page 12
:SYST:COMM:LAN:IPAD "192.168.1.10" set IP address as 192.168.1.10
:SYST:COMM:LAN:IPAD? query return192.168.1.10
:SYSTem:COMMunicate:LAN:DHCP
Command format：
:SYSTem:COMMunicate:LAN:DHCP {{1 | ON} | {0 | OFF}}
:SYSTem:COMMunicate:LAN:DHCP?
Functional description：
For switch configuration mode（auto IP）and（manual IP）.
Return format：
Query return dynamic configuration mode, 0 presents（manual IP），1 presents（auto IP）.
For example：
:SYST:COMM:LAN:DHCP ON turn on IP dynamic configurarion mode
:SYST:COMM:LAN:DHCP? query return 1
:SYSTem:COMMunicate:LAN:MAC?
UNI-T
Command format：
:SYSTem:COMMunicate:LAN:MAC?
Return format：
Query return MAC physical address.
For example：
:SYST:COMM:LAN:MAC? query return 00-2A-A0-AA-E0-56
KEY Command
This command is to control button and knob on the oscilloscope panel.
:KEY:<key>
Command format：
:KEY:<key>
:KEY:<key>:LOCK { {1 | ON} | {0 | OFF} }
:KEY:<key>:LOCK?
:KEY:<key>:LED?
Functional description：
Set button function and button lock status, <key> definition and description, see
Key Table.
Return format：
Query return key lock status or LED status.
Lock status：0 presents unlock, 1 presents lock；
Appendix 1：
UTD2000E Series Osilloscope Programming Manual
Page 13
LED light staus：0 presents light off, 1 presents light on.
For example：
:KEY:AUTO set oscilloscope control parameter automatically
:KEY:AUTO:LOCK ON/OFF lock/unlock button
:KEY:AUTO:LOCK? query return this key lock status, 1 presents locked
:KEY:AUTO:LED? query return LED status，0 presents light off
UNI-T
CHANnel Command
This command is to set channel independently. <n> take value as 1/2/3/4/5/6/7/8/9, it
presents {CH1/CH2/ CH3/ CH4/ MATH/ REF-A/ REF-B/ REF-C/ REF-D}.
Notes: this command in instruction set is not only valid for physical channel, but also
valid for MATH and reference channel parameter.
:CHANnel<n>:BWLimit
Command format：
:CHANnel<n>:BWLimit {{1|ON}|{0|OFF}}
:CHANnel<n>:BWLimit?
Functional description：
Set bandwidth limit function is ON (turn on bandwidth to 20MHz，to reduce display noise) or
OFF (turn off bandwidth to full display）
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:BWL ON turn on channel 1 bandwidth limit
:CHAN1:BWL? query return 1，it presents channel 1 bandwidth limit is turn on
:CHANnel<n>:COUPling
Command format：
:CHANnel<n>:COUPling {DC|AC|GND}
:CHANnel<n>:COUPling?
Functional description：
Set channel coupling mode, DC presents AC and DC component of input signal; AC presents DC
component of blocking input signal; GND (grounding) presents break input signal.
Return format：
Query AC, DC or GND.
For example：
:CHAN1:COUP DC set channel 1 coupling mode as DC
:CHAN1:COUP? query return DC
UTD2000E Series Osilloscope Programming Manual
Page 14
:CHANnel<n>:DISPlay
Command format：
:CHANnel<n>:DISPlay { {1|ON} | {0|OFF} }
:CHANnel<n>:DISPlay?
Functional description：
The switch of the specified channel.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:DISP ON turn on channel 1
:CHAN1:DISP? query return 1，it presents channel 1 is turn on
:CHANnel<n>:INVert
Command format：
:CHANnel<n>:INVert { {1|ON} | {0|OFF} }
:CHANnel<n>:INVert?
Functional description：
Set wave inversion function is ON (turn on) or OFF (back to normal display）.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:INV OFF turn off channel 1 inversion function
:CHAN1:INV? query return 0，it presents channel 1 inversion function is off
UNI-T
:CHANnel<n>:PROBe
Command format：
:CHANnel<n>:PROBe { 0.01X | 0.02X | 0.05X | 0.1X | 0.2X | 0.5X | 1X | 2X | 5X | 10X |20X
|50X |100X |200X |500X |1000X }
:CHANnel<n>:PROBe?
Functional description：
Set the probe attenuation factor corresponding to the probe.
Return format：
Query return { 0.01X | 0.02X | 0.05X | 0.1X | 0.2X | 0.5X | 1X | 2X | 5X | 10X |20X |50X |100X
|200X |500X |1000X }.
For example：
:CHAN1:PROB 10X set channel 1 probe attenuation factor as 10
:CHAN1:PROB? query return 10X
UTD2000E Series Osilloscope Programming Manual
Page 15
:CHANnel<n>:OFFSet
Command format：
:CHANnel<n>:OFFSet <offset>
:CHANnel<n>:OFFSet?
Functional description：
Set wave offset in vertical position, <n> take value as 1/2/3/4/5, it presents {CH1/CH2/CH3/
CH4/ MATH }.
Return format：
Query return offset value by scientific notation method, unit is related with the current channel
unit.
For example：
:CHAN1:OFFS 20V set channel 1 vertival offset as 20V
:CHAN1:OFFS? query return 2.000e001
:CHANnel<n>:SCALe
UNI-T
Command format：
:CHANnel<n>:SCALe {<scale> | UP | DOWN}
:CHANnel<n>:SCALe?
Functional description：
Set voltage base in vertical position.
<scale>：voltage base value；
UP：plus one position based on the current position；
DOWN ：minus one position based on the current position.
Return format：
Query return the current voltage position value by scientific notation method, unit is V.
For example：
:CHAN1:SCAL 20V set channel 1 voltage base as 20V
:CHAN1:SCAL? query return 2.000e001。
:CHAN1:SCAL UP plus one position based on 20V voltage base
:CHANnel<n>:UNITs
Command format：
:CHANnel<n>:UNITs {VOLTs|AMPeres }
:CHANnel<n>:UNITs?
Functional description：
Set channel unit as VOLTs and AMPeres.
Return format：
Query return VOLTs, AMPeres.
UTD2000E Series Osilloscope Programming Manual
Page 16
For example：
:CHAN1:UNIT VOLT set channel 1 unit as VOLTs
:CHAN1:UNIT? query return VOLTs
:CHANnel<n>:VERNier
Command format：
:CHANnel<n>:VERNier { {1|ON} | {0|OFF} }
:CHANnel<n>:VERNier?
Functional description：
Set position accommodation mode, ON presents Fine tuning，to further
tuning settings to improve vertical resolution; OFF presents Coarse tuning， based on 1-2-5
system to set vertical sensitivity.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:VERN ON turn on channel 1 fine tuning function
:CHAN1:VERN? query return 1
subdivides between coarse
UNI-T
:CHANnel<n>:SELect
Command format：
:CHANnel<n>:
:CHANnel<n>:
Functional description：
For channel selection.
Return format：
Query return 1 or 0，it presents ON or OFF.
For example：
:CHAN1:
:CHAN1:
SELect
SELect?
SELect select channel 1
SELect? query return 1，it presents channel 1 has been selected
UTD2000E Series Osilloscope Programming Manual
Page 17
UNI-T
TIMebase Command
This command is to change the current channel horizontal scale (time base) and
horizontal position of trigger in memory (trigger offset). Horizontal scale change will
make waveform expand or shrink relative to screen center. Horizontal position change
will make wave shift relative to screen center.
:TIMebase:MODE
Command format：
:TIMebase:MODE {MAIN | WINDow}
:TIMebase:MODE?
Functional description：
Set timebase mode, MAIN or WINDow (zoom timebase <Zoomed>）
Return format：
Query return MAIN or WINDow.
For example：
:TIM:MODE MAIN set timebase mode as MAIN
:TIM:MODE? query return MAIN
:TIMebase:OFFSet
Command format：
:TIMebase:OFFSet <offset>
:TIMebase:OFFSet?
Functional description：
For adjust MAIN offset value,
Return format：
Query return <offset> value by scientific notation，unit is S.
For example：
:TIM:OFFS 1s set MAIN offset value as 1s
:TIM:OFFS? query return 1.000e000
wave shift relative to screen center.
UTD2000E Series Osilloscope Programming Manual
Page 18
:TIMebase:WINDow:OFFSet
Command format：
:TIMebase:WINDow:OFFSet <offset>
:TIMebase:WINDow:OFFSet?
Functional description：
For adjust WINDow offset value（zoom timebase <Zoomed>）,wave shift relative to screen center.
Return format：
Query return<offset> value by scientific notation method unit is S.
For example：
:TIM:WIND:OFFS 1 set WINDow offset value as 1s
:TIM:WIND:OFFS? query return 1.000e000
:TIMebase:SCALe
Command format：
:TIMebase:SCALe {<scale> | UP | DOWN}
:TIMebase:SCALe?
Functional description：
Set timebase position of MAIN, s/div.
<scale>：timebase value；
UP：plus one position based on the current position；
DOWN ：minus one position based on the current position.
Return format：
Query return< scale> value by scientific notation method, unit is s/div.
For example：
:TIM:SCAL 2 set MAIN offset value as 2s/div
:TIM:SCAL? query return 2.000e000
UNI-T
:TIMebase:WINDow:SCALe
Command format：
:TIMebase:WINDow:SCALe {<scale> | UP | DOWN}
:TIMebase:WINDow:SCALe?
Functional description：
For adjust WINDow timebase（zoom timebase <Zoomed>）, that is s/div.
Return format：
query return < scale> value by scientific notation method, in s/div.
For example：
:TIM:WIND:SCAL 2 set WINDow timebase offset value as 2s/div
:TIM:WIND:SCAL? query return 2.000e000
UTD2000E Series Osilloscope Programming Manual
Page 19
UNI-T
FUNCtion Command
Display the operational result plus, minus, multiply, divide, AND, OR, negation,
exclusive OR and FFT of CH1,CH2,CH3,CH4 waveform, set filter to use expression
operation.
:FUNCtion:MATH:MODE
Command format：
FUNCtion:MATH:MODE {MATH | FFT | FILTer}
FUNCtion:MATH:MODE?
Functional description：
Select MATH function mode.
Return format：
Query return {MATH | FFT | FILTer }
For example：
FUNC:MATH:MODE FFT select MATH mode as FFT mode
FUNC:MATH:MODE? query return FFT
:FUNCtion:OPERation
Command format：
:FUNCtion:OPERation {ADD | SUBTract | MULTiply | DIVide }
:FUNCtion:OPERation?
Functional description：
Set functional operator, including basic operation and logic operation, they are plus, minus,
multiply, divide, AND, OR, negation, exclusive OR.
Return format：
query return {ADD | SUBTract | MULTiply | DIVide }
For example：
:FUNCtion:OPERation ADD use puls operator：src1+src2
:FUNCtion:OPERation? query return ADD
:FUNCtion:SOURce<m>
Command format：
:FUNCtion:SOURce<m> <
:FUNCtion:SOURce<m>?
Functional description：
SOURce <m> presents source 1 or source 2, <m> take value as 1, 2.
SOURce1 is to select the first source of operator and math function or it can be single source of
Filter and FFT.
SOURce2
is to select the second source of operator and math function. Single source of Filter,
value>
UTD2000E Series Osilloscope Programming Manual
Page 20
and FFT is not applicable.
<value> presents CHANnel<n>， <n> take vaule as 1/2/3/4{CH1/ CH2/ CH3/ CH4}.
Return format：
Query return <n> take valu as 1/2/3/4/5/6/7/8/9.
For example：
:FUNCtion:SOUR1 CHAN1 choose channel 1 as source 1
:FUNCtion:SOUR1? query return1
:FUNCtion:SOUR2 CHAN2 choose channel 2 as source 2
:FUNCtion:SOUR2? query return 2
:FUNCtion:OPERation ADD add source 1 and source 2
:FUNCtion:FFT:WINDow
Command format：
:FUNCtion:FFT:WINDow {RECTangular|HANNing|HAMMing|BMAN}
:FUNCtion:FFT:WINDow?
Functional description：
FFT windowing to intercept signal. RECT, HANN, HAMM, BMAN
Hanning window, Hamming window and Blacman window respectively.
Return format：
Query return {RECTangular|HANNing|HAMMing|BMAN}.
For example：
:FUNCtion:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FFT:WIND HAMM windowing Hamming window
:FUNC:FFT:WIND? query return HAMMing
is rectangular window,
UNI-T
:FUNCtion:FFT:VTYPe
Command format：
:FUNCtion:FFT:VTYPe {VRMS|DBRMS}
:FUNCtion:FFT:VTYPe?
Functional description：
Set unit of FFT vertical diection as dbrms or VRMS. dbrms presents root mean square of power;
VRMS presents root mean square of voltage.
Return format：
Query return VRMS, DBRMS
For example：
:FUNCtion:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FFT:VTYP VRMS set unit of FFT vertical diection as root mean square of voltage
:FUNC:FFT:VTYP? query return VRMS
UTD2000E Series Osilloscope Programming Manual
Page 21
:FUNCtion:FFT:FREQuency
Command format：
:FUNCtion:FFT:FREQuency?
Functional description：
The center frequency of spectrum and waveform after obtaining FFT.
Return format：
Query return1.000e003，unit is Hz.
For example：
:FUNCtion:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FFT:FREQ? query return 1.000e003
:FUNCtion:FILTer:TYPE
Command format：
:FUNCtion:FILTer:TYPE {LP|HP|BP|BS}
:FUNCtion:FILTer:TYPE?
Functional description：
Filter type setting. LP, HP, BP, BS is low-pass filter, high-pass filter, band-pass filter and
band-stop filer respectively.
Return format：
Query return LP, HP, BP, BS.
For example：
:FUNCtion:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FILT:TYPE BP set to band-pass filter
:FUNC:FILT:TYPE? query return BP
UNI-T
:FUNCtion:FILTer:FREQuency:HIGH
Command format：
:FUNCtion:FILTer:FREQuency:HIGH < freq>
:FUNCtion:FILTer:FREQuency:HIGH?
Functional description：
The setting of the upper frequency limit of filter. It is applicable for high-pass filter, band-pass
filer and band-stop filter.
Return format：
Query return 1.000e003，unit is Hz.
For example：
:FUNCtion:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FILT:FREQ:HIGH 1KHz set the upper frequency limit of filter as 1kHz
UTD2000E Series Osilloscope Programming Manual
Page 22
:FUNC:FILT:FREQ:HIGH? query return 1.000e003
:FUNCtion:FILTer:FREQuency:LOW
Command format：
:FUNCtion:FILTer:FREQuency:LOW <freq>
:FUNCtion:FILTer:FREQuency:LOW?
Functional description：
The setting of the lower frequency limit of filter. It is applicable for high-pass filter, band-pass
filer and band-stop filter.
Return format：
Query return 6.000e001，unit is Hz.
For example：
:FUNC:SOUR1 CHAN1 set channel 1 as source 1
:FUNC:FILT:FREQ:LOW 60Hz set the upper frequency limit of filter as 60Hz
:FUNC:FILT:FREQ:LOW? query return 6.000e001
UNI-T
MEASure Command
This command is for oscilloscope basic measurement, auto turn on parameter
measurement and get test result, return test result by scientific notation method.
:MEASure:ALL
Command format：
:MEASure:ALL {{1 | ON} | {0 | OFF}}
:MEASure:ALL?
Functional description：
The switch setting of all measurement function.
Return format：
Query return turn on all measurement function whether is turn on
For example：
:MEASure:ALL ON turn on all measurement function
:MEASure:ALL? query return 1
:MEASure:CLEar
Command format：
:MEASure:CLEar
Functional description：
Empty the current measured parameter.
For example：
:MEAS:CLE delete the current measured parameter
UTD2000E Series Osilloscope Programming Manual
Page 23
:MEASure:SOURce
Command format：
:MEASure:SOURce <source>
:MEASure:SOURce?
Functional description：
For select the main measure source, <source> is CHANnel<n>， n take value as 1, 2, 3, 4.
Return format：
Query return{CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4 | MATH}.
For example：
:MEAS:SOUR CHAN1 select channel 1 as measure source
:MEAS:SOUR? return CHANnel1
:MEASure:SLAVe:SOURce
UNI-T
Command format：
:MEASure:SLAVe:SOURce <source>
:MEASure:SLAVe:SOURce?
Functional description：
For select slave information source, <source> is CHANnel<n>， n take value as 1, 2, 3, 4.
Return format：
query return{CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4 | MATH}.
For example：
:MEAS:SLAV:SOUR CHAN1 select channel 1 as slave information source
:MEAS:SLAV:SOUR? return CHANnel1
:MEASure:PDUTy?
Command format：
:MEASure:PDUTy? [<source>]
Functional description：
Measuring positive duty ratio of the specified channel waveform, <source> take vaule as
CHANnel1, CHANnel2, CHANnel3 or CHANnel4. Ignore measns the current channel.
Return format：
Query return 5.000e001，i unit is %.
:MEASure:NDUTy?
Command format：
:MEASure:NDUTy? [<source>]
Functional description：
UTD2000E Series Osilloscope Programming Manual
Page 24
Measuring positive duty ratio of the specified channel waveform, <source> take vaule as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH，Ignore measns the current channel.
Return format：
Query return 5.000e001，unit is %.
:MEASure:PDELay?
Command format：
:MEASure:PDELay? [<source1>,<source2>]
Functional description：
Measuring <source1> and <source2> relative to time delay of rise edge, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH，Ignore measns the current channel.
Return format：
query return-1.000e-004，unit is S.
For example：
Measuring the relative to time delay of rise edge.
:MEASure:PDEL? CHAN1,CHAN2
UNI-T
:MEASure:NDELay?
Command format：
:MEASure:NDELay? [<source1>,<source2>]
Functional description：
Measuring <source1> and <source2> relative to time delay of fall edge, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH，Ignore measns the current channel.
Return format：
Query return -1.000e-004，unit is S.
For example：
Measuring the relative to time delay of fall edge.
:MEASure:NDEL? CHAN1,CHAN2
:MEASure:PHASe?
Command format：
:MEASure:PHASe? [<source1>,<source2>]
Functional description：
Timing measuring <source1> relative to <source2> the advance or hysteretic of time quantum, it
presents by degree, 360°as a period, source take value as CHANnel1, CHANnel2, CHANnel3,
CHANnel4 and MATH. Ingore means the current channel.
Return format：
query return 1.000e001，unit is degree.
For example：
UTD2000E Series Osilloscope Programming Manual
Page 25
Measuring <source1> relative to <source2> the advance or hysteretic of time quantum.
:MEASure:PHAS? CHAN1,CHAN2
:MEASure:VPP?
Command format：
:MEASure:VPP? [<source>]
Functional description：
Measuring peak-to-peak value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH. Ingore means the current channel.
Return format：
Query return 3.120e000，unit is V.
:MEASure:VMAX?
Command format：
:MEASure:VMAX? [<source>]
Functional description：
Measuring the maximum value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH，Ingore means the current channel.
Return format：
Query return 2.120e000，unit is V.
UNI-T
:MEASure:VMIN?
Command format：
:MEASure:VMIN? [<source>]
Functional description：
Measuring the minimum value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH，Ingore means the current channel.
Return format：
Query return -2.120e000，unit is V.
:MEASure:VAMPlitude?
Command format：
:MEASure:VAMPlitude? [<source>]
Functional description：
Measuring the amplitude value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH，Ingore means the current channel.
Return format：
Query return 3.120e000，unit is V.
UTD2000E Series Osilloscope Programming Manual
Page 26
:MEASure:VTOP?
Command format：
:MEASure:VTOP? [<source>]
Functional description：
Measuring the top value of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3, CHANnel4 and MATH，Ingore means the current channel.
Return format：
Query return 3.120e000，unit is V.
:MEASure:VBASe?
Command format：
:MEASure:VBASe? [<source>]
Functional description：
Measuring the bottom value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH，Ingore means the current channel.
Return format：
query return-3.120e000，unit is V.
UNI-T
:MEASure:VMIDdle?
Command format：
:MEASure:VMIDdle? [<source>]
Functional description：
Measuring the middle value of the specified channel waveform,<source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH，Ingore means the current channel.
Return format：
Query return0.120e000，unit is V.
UTD2000E Series Osilloscope Programming Manual
Page 27
:MEASure:VAVerage?
Command format：
:MEASure:VAVerage? [<interval>][,<source>]
Functional description：
Measuring the average value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH. If there has no designated <source>,
the current channel as <source> by default; <interval> appoint the measurement separation, take
value as CYCLe and DISPlay, CYCLe presents integer cycle period, DISPlay presents full screen.
If there has no designated <interval>, take DISPlay by default.
Return format：
Query return1.120e000，unit is V.
:MEASure:VRMS?
Command format：
:MEASure:VRMS? [<interval>][,<source>]
Functional description：
Measuring the root mean square value of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3, CHANnel4 and MATH. If there has no designated <source>,
the current channel as <source> by default; <interval> appoint the measurement separation, take
value as CYCLe and DISPlay, CYCLe presents integer cycle period, DISPlay presents full screen.
If there has no designated <interval>, take DISPlay by default.
Return format：
Query return 1.230e000，unit is V.
UNI-T
:MEASure:AREa?
Command format：
:MEASure:AREa? [<interval>][,<source>]
Functional description：
Measuring the area of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3, CHANnel4 and MATH. If there has no designated <source>, the current
channel as <source> by default; <interval> appoint the measurement separation, take value as
CYCLe and DISPlay, CYCLe presents integer cycle period, DISPlay presents full screen. If there
has no designated <interval>, take DISPlay by default.
Return format：
Query return 3.456e002，unit is V.s.
UTD2000E Series Osilloscope Programming Manual
Page 28
:MEASure:OVERshoot?
Command format：
:MEASure:OVERshoot? [<source>]
Functional description：
Measuring overshoot of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3, CHANnel4 and MATH. Ignore means the current channel.
Return format：
query return1.230e002，unit is V.
:MEASure:PREShoot?
Command format：
:MEASure:PREShoot? [<source>]
Functional description：
Measuring prshoot of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3, CHANnel4 and MATH. Ignore means the current channel.
Return format：
Query return 1.230e-002，unit is V.
UNI-T
:MEASure:FREQuency?
Command format：
:MEASure:FREQuency? [<source>]
Functional description：
Measuring frequency of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and MATH. Ignore means the current channel.
Return format：
Query return 2.000e003，unit is Hz.
:MEASure:RISetime?
Command format：
:MEASure:RISetime? [<source>]
Functional description：
Measuring rise time of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and MATH. Ignore means the current channel.
Return format：
Query return5.000e-005，unit is s.
UTD2000E Series Osilloscope Programming Manual
Page 29
:MEASure:FALLtime?
Command format：
:MEASure:FALLtime? [<source>]
Functional description：
Measuring fall time of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and MATH. Ignore means the current channel.
Return format：
Query return 5.000e-005，unit is s.
:MEASure:PERiod?
Command format：
:MEASure:PERiod? [<source>]
Functional description：
Measuring period of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and MATH. Ignore means the current channel.
Return format：
Query return 5.000e-003，unit is s.
UNI-T
:MEASure:PWIDth?
Command format：
:MEASure:PWIDth? [<source>]
Functional description：
Measuring period of the specified channel waveform, <source> take value as CHANnel1,
CHANnel2, CHANnel3 and MATH. Ignore means the current channel.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:NWIDth?
Command format：
:MEASure:NWIDth? [<source>]
Functional description：
Measuring negative pulse width of the specified channel waveform, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and MATH. Ignore means the current channel.
Return format：
Query return 5.000e-003，unit is s.
UTD2000E Series Osilloscope Programming Manual
Page 30
:MEASure:FRR?
Command format：
:MEASure:FRR? [<source1>,<source2>]
Functional description：
Measuring time of the first rise edge between <source1> and <source2>, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and MATH. Ignore means the current channel.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:FRF?
Command format：
:MEASure:FRF? [<source1>,<source2>]
Functional description：
Measuring time between the first rise edge of <source1> and the first fall edge of <source2>,
<source> take value as CHANnel1, CHANnel2, CHANnel3 and MATH. Ignore means the current
channel.
Return format：
Query return 5.000e-003，unit is s.
UNI-T
:MEASure:FFR?
Command format：
:MEASure:FFR? [<source1>,<source2>]
Functional description：
Measuring time between the first fall edge of <source1> and the first fall edge of <source2>,
<source> take value as CHANnel1, CHANnel2, CHANnel3 and MATH. Ignore means the current
channel.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:FFF?
Command format：
:MEASure:FFF? [<source1>,<source2>]
Functional description：
Measuring time of the first fall edge between <source1> and <source2>, <source> take value as
CHANnel1, CHANnel2, CHANnel3 and MATH. Ignore means the current channel.
Return format：
Query return 5.000e-003，unit is s.
UTD2000E Series Osilloscope Programming Manual
Page 31
:MEASure:LRR?
Command format：
:MEASure:LRR? [<source1>,<source2>]
Functional description：
Measuring time between the first rise edge of <source1> and the last rise edge of <source2>,
<source> take value as CHANnel1, CHANnel2, CHANnel3 and MATH. Ignore means the current
channel.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:LRF?
Command format：
:MEASure:LRF? [<source1>,<source2>]
Functional description：
Measuring time between the first rise edge of <source1> and the last fall edge of <source2>,
<source> take value as CHANnel1, CHANnel2, CHANnel3 and MATH. Ignore means the current
channel.
Return format：
Query return 5.000e-003，unit is s.
UNI-T
:MEASure:LFR?
Command format：
:MEASure:LFR? [<source1>,<source2>]
Functional description：
Measuring time between the first fall edge of <source1> and the last rise edge of <source2>,
<source> take value as CHANnel1, CHANnel2, CHANnel3 and MATH. Ignore means the current
channel.
Return format：
Query return 5.000e-003，unit is s.
:MEASure:LFF?
Command format：
:MEASure:LFF? [<source1>,<source2>]
Functional description：
Measuring time between the first fall edge of <source1> and the last fall edge of <source2>,
<source> take value as CHANnel1, CHANnel2, CHANnel3 and MATH. Ignore means the current
channel.
Return format：
UTD2000E Series Osilloscope Programming Manual
Page 32
Query return 5.000e-003，unit is s.
UNI-T
TRIGger Command
This command is to control trigger sweep mode and trigger standard, trigger decide
when oscilloscope start to collect data and display waveform.
Trigger Control
:TRIGger:MODE
Command format：
:TRIGger:MODE <mode>
:TRIGger:MODE?
Functional description：
Set trigger mode.
<mode> divided into EDGE（edge trigger）, PULSe（pulse width trigger）, VIDeo（video trigger）,
SLOPe（slope trigger）, ALTernat（alternative trigger）.
Return format：
Query return trigger mode
For example：
:TRIGger:MODE EDGE edge trigger
:TRIGger:MODE? query return EDGE
:TRIGger:SWEep
Command format：
:TRIGger:SWEep {AUTO|NORMal|SINGle}
:TRIGger:SWEep?
Functional description：
Set trigger sweep mode.
AUTO：If there has no trigger term, internal will produce trigger signal to force trigger.
NORMal：Trigger only when in trigger term.
SINGle：In trigger term, trigger one time and stop.
Return format：
Query return trigger sweep mode {AUTO|NORMal|SINGle}.
For example：
:TRIGger:SWEep AUTO set channel 1 as AUTO mode
:TRIGger:SWEep? query return AUTO
UTD2000E Series Osilloscope Programming Manual
Page 33
:TRIGger:LEVel:ASETup
Command format：
:TRIGger:LEVel:ASETup
Functional description：
Set trigger level on the vertical center point of signal amplitude.
For example：
:TRIG:LEVel:ASETup set trigger level on the center point
:TRIGger:STATus?
Command format：
:TRIGger:STATus?
Functional description：
Query the current the oscilloscope running status.
Return format：
Query return STOP/ARMED/READY/TRIGED/AUTO/SCAN /RESET /
For example：
:TRIGger:STATus? query return AUTO
UNI-T
REPLAY/ WAIT.
:TRIGger:LEVel
Command format：
:TRIGger:LEVel <level>
:TRIGger:LEVel?
Functional description：
Set the trigger level value of NORMal mode. <level> value must set based on voltage base and
the conversion of screen information.
Return format：
Query return<level> value，unit is V.
For example：
:TRIG:LEV 2 set the trigger leve as 2V
:TRIG:LEV? query return 2.000e000
:TRIGger:LEVel:LOW
Command format：
:TRIGger:LEVel:LOW <level>
UTD2000E Series Osilloscope Programming Manual
Page 34
:TRIGger:LEVel:LOW?
Functional description：
Set the low-level value of slope trigger, <level> value must set based on voltage base and the
conversion of screen information.
Return format：
query return <level> value，unit is V.
For example：
:TRIG:LEV:LOW 2 set the trigger leve as 2V
:TRIG:LEV:LOW? query return 2.000e000
:TRIGger:LEVel:HIGH
Command format：
:TRIGger:LEVel:HIGH <level>
:TRIGger:LEVel:HIGH?
Functional description：
Set the high-level value of slope trigger, <level> value must set based on voltage base and the
conversion of screen information.
Return format：
Query return <level> value，unit is V.
For example：
:TRIG:LEV:HIGH 2 set the trigger leve as 2V
:TRIG:LEV:HIGH? query return 2.000e000
UNI-T
:TRIGger:SOURce
Command format：
:TRIGger:SOURce <source>
:TRIGger:SOURce?
Functional description：
Set single information source trigger, input channel(CHANnel1, CHANnel 2, CHANnel 3,
CHANnel 4）, external trigger( EXT, EXT5), AC Line. Only EDGE/ PULSe / VIDeo support AC
Line, EXT and EXT5.
<source> presents information source trigger,
CHANnel<n>|EXT|EXT5|ACLine，<n> take value as 1, 2, 3, 4.
Return format：
Query return information source trigger { CHANnel1| CHANnel2| CHANnel3|
CHANnel4|EXT|EXT5|ACLINE}.
For example：
:TRIGger:SOUR CHAN1 set channel 1 as edge tigger
:TRIGger:SOUR? query return CHANnel1
UTD2000E Series Osilloscope Programming Manual
Page 35
:TRIGger:COUPling
Command format：
:TRIGger:COUPling {DC|AC|LF|HF|NOISE}
:TRIGger:COUPling?
Functional description：
For coupling mode, DC, AC, LF, HF and NOISE, except VIDeo.
Return format：
Query return coupling mode {DC|AC|LF|HF|NOISE}.
For example：
:TRIGger:COUPling AC set edge trigger as AC
:TRIGger:COUPling? query return AC
Edge Trigger
UNI-T
:TRIGger:EDGE:SLOPe
Command format：
:TRIGger:EDGE:SLOPe {POSitive|NEGative|ALTernation}
:TRIGger:EDGE:SLOPe?
Functional description：
Set the type of edge trigger, POSitive, NEGative and ALTernation.
Return format：
Query return edge trigger { POSitive | NEGative | ALTernation }.
For example：
:TRIGger:EDGE:SLOP POS set the edge trigger as POSitive
:TRIGger:EDGE:SLOP? query return POSitive
Pulse Width Trigger
:TRIGger:PULSe:QUALifier
Command format：
:TRIGger:PULSe:QUALifier {GREaterthan | LESSthan | EQUal| RANG}
:TRIGger:PULSe:QUALifier?
Functional description：
UTD2000E Series Osilloscope Programming Manual
Page 36
Set the term of pulse time, GREaterthan, LESSthan and EQUal.
Return format：
Query return{ GREaterthan | LESSthan | EQUal }.
For example：
:TRIGger:PULSe:QUALifier GRE set the pulse term as GREaterthan
:TRIGger:PULSe:QUALifier? query return GREaterthan
:TRIGger:PULSe:POLarity
Command format：
:TRIGger:PULSe:POLarity {POSitive | NEGative}
:TRIGger:PULSe:POLarity?
Functional description：
Set pulse polarity, POSitive and NEGative.
Return format：
Query return{ POSitive | NEGative }.
For example：
:TRIGger:PULSe:POL POS set pulse polarity as POSitive
:TRIGger:PULSe:POL? query return POSitive
UNI-T
:TRIGger:PULSe:TIME
Command format：
:TRIGger:PULSe:TIME <time>
:TRIGger:PULSe:TIME?
Functional description：
Set the time interval of pulse width trigger.
Return format：
Query return
For example：
:TRIGger:PULSe:TIME 1 set the pulse width as 1s
:TRIGger:PULSe:TIME? query return 1.000e000
the current time interval, unit is s.
:TRIGger:PULSe:TIME:UPPer
Command format：
:TRIGger:PULSe:TIME <time>
:TRIGger:PULSe:TIME?
UTD2000E Series Osilloscope Programming Manual
Page 37
Functional description：
Set the time interval of pulse width trigger.
Return format：
Query return the current time interval, unit is s.
For example：
:TRIGger:PULSe:TIME 1 set the pulse width as 1s
:TRIGger:PULSe:TIME? query return 1.000e000
:TRIGger:PULSe:TIME:LOWer
Command format：
:TRIGger:PULSe:TIME <time>
:TRIGger:PULSe:TIME?
Functional description：
Set the time interval of pulse width trigger.
Return format：
the current time interval, unit is s.
For example：
:TRIGger:PULSe:TIME 1 set the pulse width as 1s
:TRIGger:PULSe:TIME? query return 1.000e000
UNI-T
Video Trigger
:TRIGger:VIDeo:MODE
Command format：
:TRIGger:VIDeo:MODE {
:TRIGger:VIDeo:MODE?
Functional description：
Set the syc mode of video trigger, ODD, EVEN, LINE and ALINes.
Return format：
Query return{
For example：
:TRIGger:VIDeo:MODE ODD set the sync mode as ODD
:TRIGger:VIDeo:MODE? query return ODD
ODD | EVEN | LINE| ALIN}.
:TRIGger:VIDeo:STANdard
ODD | EVEN | LINE| ALINes}
Command format：
UTD2000E Series Osilloscope Programming Manual
Page 38
:TRIGger:VIDeo:STANdard {
:TRIGger:VIDeo:STANdard?
Functional description：
Set the video standard.
Return format：
Query return {
For example：
:TRIGger:VIDeo:STANdard NTSC set the video standard as NTSC
:TRIGger:VIDeo:STANdard? query return NTSC
NTSC | PAL | SECam }.
NTSC | PAL | SECam }
:TRIGger:VIDEO:LINE
Command format：
:TRIGger:VIDEO:LINE <value>
:TRIGger:VIDEO:LINE?
Functional description：
Set the specified line of video sync, <value> presents the specified line, the range is related to the
video standard.
Return format：
Query return the current specified line.
For example：
:TRIG:VIDEO:LINE 50 set the specified line of video sync as 50
:TRIG:VIDEO:LINE? query return 50
UNI-T
:TRIGger:VIDEO:SRATe?
Command format：
:TRIGger:VIDEO:SRATe?
Functional description：
Acquire the slew rate of video.
Return format：
Query return the current slew rate, return format is conform to the format of binary data IEEE
488.2#.
Slope Trigger
:TRIGger:SLOPe:QUALifier
Command format：
UTD2000E Series Osilloscope Programming Manual
Page 39
:TRIGger:SLOPe:QUALifier {GREaterthan | LESSthan | EQUal}
:TRIGger:SLOPe:QUALifier?
Functional description：
Set the term of slope time, GREaterthan, LESSthan and EQUal.
Return format：
Query return {GREaterthan | LESSthan | EQUal}.
For example：
:TRIGger:SLOPe:QUALifier GRE set the slope term as GREaterthan
:TRIGger:SLOPe:QUALifier? query return GREaterthan
:TRIGger:SLOPe:SLOPe
Command format：
:TRIGger:SLOPe:SLOPe {POSitive|NEGative}
:TRIGger:SLOPe:SLOPe?
Functional description：
Set the type of slope trigger, POSitive and NEGative.
Return format：
Query return{POSitive|NEGative}.
For example：
:TRIGger:SLOPe:SLOPe POS set the slope trigger as POSitive
:TRIGger:SLOPe:SLOPe? query return POSitive
UNI-T
:TRIGger:SLOPe:TIME
Command format：
:TRIGger:SLOPe:TIME <time>
:TRIGger:SLOPe:TIME?
Functional description：
Set the time interval of slope trigger.
Return format：
Query return the current time interval, unit is s.
For example：
:TRIGger:SLOPe:TIME 1 set the time interval of slope trigger as 1s
:TRIGger:SLOPe:TIME? query return 1.000e000
UTD2000E Series Osilloscope Programming Manual
Page 40
:TRIGger:SLOPe:THReshold
Command format：
:TRIGger:SLOPe:THReshold {LOW|HIGH|LH}
:TRIGger:SLOPe:THReshold?
Functional description：
Set the threshold mode of slope trigger.
Return format：
Query return{LOW|HIGH|LH}.
For example：
:TRIGger:SLOPe:THR HIGH set the threshold mode of slope trigger as HIGH
:TRIGger:SLOPe:THR? query return HIGH
Alternate Trigger
UNI-T
:TRIGger:ALTernat:TYPE
Command format：
:TRIGger:ALTernat:TYPE {
:TRIGger:ALTernat:TYPE?
Functional description：
Set alternate trigger mode, edge, pulse width and slope.
Return format：
Query return{
For example：
:TRIGger:ALTernat:TYPE
:TRIGger:ALTernat:TYPE? query return
EDGE | PULSe | SLOPe}.
EDGE | PULSe | SLOPe}
EDGE set alternate trigger mode as edge trigger
EDGE
CURSor Command
This command is to set cursor parameter, measure waveform data on the screen.
:CURSor:MODE
Command format：
:CURSor:MODE {
:CURSor:MODE?
Functional description：
UTD2000E Series Osilloscope Programming Manual
TRACK | INDependent }
Page 41
Set cursor mode, TRACK or INDependent.
Return format：
Query return{
For example：
:CURSor:MODE TRACK set cursor mode as TRACK
:CURSor:MODE? query return TRACK
TRACK | INDependent }.
:CURSor:TYPE
Command format：
:CURSor:TYPE {AMPlitude | TIME | CLOSe }
:CURSor:TYPE?
Functional description：
Set cursor mode , AMPlitude, TIME and CLOSe.
Return format：
Query return{AMPlitude | TIME | CLOSe }.
For example：
:CURSor:TYPE AMP set cursor mode as AMPlitude
:CURSor:TYPE? query return AMPlitude
UNI-T
:CURSor:SOURce
Command format：
:CURSor:SOURce <source>
:CURSor:SOURce?
Functional description：
Set cursor measurement source.
<source> take value as { CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4 | MATH}.
Return format：
Query return{ CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4 | MATH}.
For example：
:CURSor:SOURce CHAN1 set channel 1 as cursor source
:CURSor:SOURce? query return CHANnel1
:CURSor:CURA
Command format：
:CURSor:CURA <value>
UTD2000E Series Osilloscope Programming Manual
Page 42
:CURSor:CURA?
Functional description：
Set the horizontal or vertical position of A cursor line. It is related with command CURSor:TYPE，
amplitude presents the vertical position, time presents the horizontal position. Vertical line range
[0,699]，horizontal line range [28,227].
Return format：
Query return the position of A cursor line.
For example：
:CURSor:CURA 50 set manual A cursor line position as 50
:CURSor:CURA? query return 50
:CURSor:CURB
Command format：
:CURSor:CURB <value>
:CURSor:CURB?
Functional description：
Set the horizontal or vertical position of B cursor line. It is related with directive CURSor:TYPE.
Return format：
Query return the position of B cursor line.
For example：
:CURSor:CURB 50 set manual B cursor line position as 50
:CURSor:CURB? query return 50
UNI-T
:CURSor:AXValue?
Command format：
:CURSor:AXValue?
Functional description：
Query X value of A cursor point, unit is select by the amplitude unit of the current channel.
Return format：
Query returns X value of A cursor point by scientific notation method.
For example：
:CURSor:AXV? query return 2.000000E+02
:CURSor:AYValue?
Command format：
:CURSor:AYValue?
Functional description：
UTD2000E Series Osilloscope Programming Manual
Page 43
Query Y value of A cursor point, unit is select by the amplitude unit of the current channel.
Return format：
Query returns Y value of A cursor point by scientific notation method.
For example：
:CURSor:AYV? query return 2.000000E+02
:CURSor:BXValue?
Command format：
:CURSor:BXValue?
Functional description：
Query X value of B cursor point, unit is select by the amplitude unit of the current channel.
Return format：
Query returns X value of B cursor point by scientific notation method.
For example：
:CURSor:BXV? query return2.000000E+02
UNI-T
:CURSor:BYValue?
Command format：
:CURSor:BYValue?
Functional description：
Query Y value of B cursor point, unit is select by the amplitude unit of the current channel.
Return format：
Query returns Y value of B cursor point by scientific notation method.
For example：
:CURSor:BYV? query return 2.000000E+02
:CURSor:XDELta?
Command format：
:CURSor:XDELta?
Functional description：
In cursor track measuring, the difference value △X between cursor A point and cursor B point.
Return format：
Query return
scientific notation method.
For example：
:CURSor:XDEL? query return 2.000000E+02
the actual difference value △X between cursor A point and cursor B point by
UTD2000E Series Osilloscope Programming Manual
Page 44
:CURSor:YDELta?
Command format：
:CURSor:YDELta?
Functional description：
In cursor track measuring, the difference value △Y between cursor A point and cursor B
point.Unit is the same as the current chnnel unit.
Return format：
Query return the actual difference value △Y between cursor A point and cursor B point by
scientific notation method.
For example：
:CURSor:YDEL? query return 2.000000E+02
ACQuire Command
This command is to set sampling mode of oscilloscope.
UNI-T
:ACQuire:TYPE
Command format：
:ACQuire:TYPE {NORMal | AVERage | PEAKdetect | HRESolution }
:ACQuire:TYPE?
Functional description：
sampling mode of oscilloscope.
Set
NORMal, AVERage, PEAKdetect and HRESolution.
Return format：
Query return {NORMal | AVERage | PEAKdetect | ENVelope | HRESolution }.
For example：
:ACQ:TYPE AVER set sampling mode as AVERage
:ACQ:TYPE? query return AVERage
:ACQuire:AVERages:COUNt
Command format：
:ACQuire:AVERages:COUNt <count>
:ACQuire:AVERages:COUNt?
Functional description：
Set the average sampling time during average sampling mode, <count> stepped by 2 of Nth
power, Nth take value from 2~8192, 1≤N≤30.
Return format：
Query return the current sampling time.
For example：
UTD2000E Series Osilloscope Programming Manual
Page 45
:ACQ:AVER:COUN 32 set the average sampling time as 32
:ACQ:AVER:COUN? query return 32
:ACQuire:MODE
Command format：
:ACQuire:MODE { EQUivalent | REALtime}
:ACQuire:MODE?
Functional description：
Set samplimg mode, it divided into equivalent sampling and real-time sampling.
Return format：
Query return{ EQUivalent | REALtime}.
For example：
:ACQ:MODE EQU set sampling mode as EQUivalent
:ACQ:MODE? query return EQUivalent
:ACQuire:FAST
UNI-T
Command format：
:ACQuire:FAST {{1 | ON} | {0 | OFF}}
:ACQuire:FAST?
Functional description：
Set the switch of quick sampling.
Return format：
Query return quick sampling status, 0 presents turn on quick sampling, 1 presents turn off quick
sampling.
For example：
:ACQuire:FAST ON turn on quick sampling
:ACQuire:FAST? query return 1，it presents quick sampling is turn on
DISPlay Command
This command is to set or query oscilloscope display function or data.
:DISPlay:DATA?
Command format：
:DISPlay:DATA?
Functional description：
For query the current screen image data.
Return format：
Query return BMP image data，return data conform to binary data format IEEE 488.2 #.
UTD2000E Series Osilloscope Programming Manual
Page 46
For example：
:DISPlay:DATA? query return image data
data format：#800012345+bitmap data
:DISPlay:FORMat
Command format：
:DISPlay:
:DISPlay:FORMat?
Functional description：
Set display format of sampling point ,VECTors and DOTS.
Return format：
Query return { VECTors | DOTS }.
For example：
:DISPlay:FORMat VECT set sampling point as VECTors
:DISPlay:FORMat? query return VECTors
FORMat { VECTors | DOTS }
UNI-T
:DISPlay:GRADing:TIME
Command format：
:DISPlay:GRADing:TIME {CLOSe|SHORt|LONG|INFinite}
:DISPlay:GRADing:TIME?
Functional description：
For set or query afterglow time.
Return format：
Query return{CLOSe|SHORt|LONG|INFinite}.
For example：
:DISPlay:GRADing:TIME SHORt set afterglow time as SHORt
:DISPlay:GRADing:TIME? query return SHORt
:DISPlay:GRID
Command format：
:DISPlay:GRID {FULL|HALF|CORSS|NONE }
:DISPlay:GRID?
Functional description：
For set or query grid type display on screen.
Return format：
Query return{FULL|HALF|CORSS|NONE }.
For example：
:DISPlay:GRID HALF set grind type as HALF, only display grid not coordinate
:DISPlay:GRID? query return HALF
UTD2000E Series Osilloscope Programming Manual
Page 47
:DISPlay:GRID:BRIGhtness
Command format：
:DISPlay:GRID:BRIGhtness <count>
:DISPlay:GRID:BRIGhtness?
Functional description：
Set grid brightness, <count> take value from 1~100，the larger the number, the brighter the grid.
Return format：
Query return the current grid brightness.
For example：
:DISPlay:GRID:BRIGhtness 50 set grid brightness as 50
:DISPlay:GRID:BRIGhtness? query return 50
:DISPlay:WAVE:BRIGhtness
UNI-T
Command format：
:DISPlay:WAVE:BRIGhtness <count>
:DISPlay:WAVE:BRIGhtness?
Functional description：
Set waveform brightness, <count>take value from 1~100，the larger the number, the brighter the
waveform.
Return format：
Query return the current brightness.
For example：
:DISPlay:WAVE:BRIGhtness 50 set waveform brightness as 50
:DISPlay:WAVE:BRIGhtness? query return 50
:DISPlay:CLEar
Command format：
:DISPlay:CLEar
Functional description：
For empty waveform displayed on the screen, if oscilloscope is on RUN status, empty displayed
waveform then display new waveform.
:DISPlay:TYPE
Command format：
:DISPlay:TYPE {XY12 |YT}
:DISPlay:TYPE?
Functional description：
UTD2000E Series Osilloscope Programming Manual
Page 48
Set timebase display mode as XY12（X-Y mode：display amplitude of channel 1 on the horizontal
axis, display amplitude of channel 2 on the vertical axis）; YT（Y-T mode：display the relative
relationship of vertical voltage and horiziontal time）。
Return format：
Query return XY12, YT.
For example：
:DISP:TYPE YT set timebase format as YT mode
:DISP:TYPE? query return YT
WAVeform Command
This command is to read waveform data on the screen and set parameter.
:WAVeform:MODE
Command format：
:WAVeform:MODE {NORMal | RAW}
:WAVeform:MODE?
Functional description：
NORMal：read the display waveform data on the screen, the waveform data points is fixed points.
RAW：read the waveform data in memory storage, the waveform data points is related to the
storage depth. Notes: Read the data of memory storage is valid only when oscilloscope stops, this
command is invalid when in MATH channel.
Return format：
query return {NORMal | RAW}.
For example：
:WAVeform:MODE RAW set the read mode as RAW
:WAVeform:MODE? query return RAW
UNI-T
:WAVeform:FORMat
Command format：
:WAVeform:FORMat { WORD |
:WAVeform:FORMat?
Functional description：
The default format of waveform data is AD waveform point
BYTE：return AD data, one waveform point takes one byte（8 bits）
WORD：return AD data, one waveform point takes two bytes（16 bits），low 8 bits is valid, high
8 bits is 0
ASCII：return the actual voltage value of each waveform point by scientific notation method,
each voltage value separate by comma mark.
Conform to binary data IEEE488.2 fomat
UTD2000E Series Osilloscope Programming Manual
BYTE | ASCII }
Page 49
For example: #412342.00000E+01,2.20000E+01, 2.30000E+01..........\n
Return format：
Query return{ WORD |
For example：
:WAVeform:FORMat BYTE return format of AD waveform data is single byte mode
:WAVeform:FORMat? query return BYT
BYTE | ASCII }.
:WAVeform:STARt
Command format：
:WAVeform:STARt <start>
:WAVeform:STARt?
Functional description：
Set or query the initial position of waveform data read, < start> integer data type.
NORMal：1 ~1400
RAW：1 ~ the maximum current storage depth point
Return format：
Query return the initial position.
For example：
:WAVeform:STARt 200 set the initial position as 200
:WAVeform:STARt? query return 200
UNI-T
:WAVeform:STOP
Command format：
:WAVeform:STOP <stop>
:WAVeform:STOP?
Functional description：
Set or query the stop position of waveform data read, < start> integer data type.
NORMal：< stop> range1 ~1400
RAW：< stop> range: the maximum current storage depth point
Return format：
Query return stop position.
For example：
:WAVeform:STOP 400 set the stop position as 400
:WAVeform:STOP? query return 400
:WAVeform:SOURce
Command format：
:WAVeform:SOURce {CHANnel<n>| MATH}
UTD2000E Series Osilloscope Programming Manual
Page 50
:WAVeform:SOURce?
Functional description：
Set or query signal source of the current waveform data, if not send this command, it presents
query waveform data of the current channel.
Return format：
Query return
{ CHANnel1 |
CHANnel2 | CHANnel3 | CHANnel4 | MATH }.
For example：
:WAVeform:SOURce CHAN1
set signal source of the current waveform data as channel 1
:WAVeform:SOURce? query return CHANnel1
:WAVeform:POINts
Command format：
:WAVeform:POINts <points>
:WAVeform:POINts?
Functional description：
Set return waveform data, the default value is 0.
Return format：
Query return waveform point.
For example：
:WAVeform:POINts 120 set return waveform point as 120
:WAVeform:POINts? query return 120
UNI-T
:WAVeform:DATA?
Command format：
:WAVeform:DATA?
Functional description：
Read waveform data of the specified data source。
Return format：
WAVeform:POINts the specified quantity of waveform data, waveform data source is related
with :WAVeform:SOURc, data format is related with WAVeform:FORMat, returns data is
conform to binary data IEEE 488.2 # format.
For example：
The execute order to obtain the specified data source the waveform data as following：
The flow to obtain the waveform data of screen
:WAVeform:SOURce CHAN1
Set channel 1 as singal source of query waveform data
:WAVeform:MODE NORMal
Set to read the display waveform data
UTD2000E Series Osilloscope Programming Manual
Page 51
:WAVeform:FORMat BYTE
The return format of waveform data is AD single byte mode
:WAVeform:DATA?
Obtain the waveform data
The flow to obtain the internal waveform data, this flow is only valid when the oscilloscope
stops
:WAVeform:SOURce CHAN1
Set channel 1 as singal source of query waveform data
Set to read the internal waveform data
:WAVeform:FORMat BYTE
The return format of waveform data is AD single byte mode
:WAVeform:POINts 5000
Internal waveform point are 5000
:WAVeform:DATA?
Obtain an area of internal waveform data
Description: when read internal data in batch, returns data is only an area of internal data,
waveform data is continuous between in two adjacent area and each area data is conform to binary
data IEEE 488.2 # format.
UNI-T
:WAVeform:PREamble?
Command format：
:WAVeform:PREamble?
Functional description：
Query return the current system waveform setup parameter.
Return format：
Query return use comma mark to separate.
Return data format: Format,Type,Points,Count,Xinc,Xor,Xref,Yinc,Yor,Yref.
Format：BYTE (0), WORD (1), ASCII(2).
Type：NORMAL(0), PEAK(1), AVER(2), ENVelope(3), HRESolution(4).
Points：return the waveform data points.
Count：in average sampling mode as average time, other mode as 1.
Xinc：the time difference between in two point of X direction of waveform data source.
Xor：the relative time of trigger point.
Xref：X reference
Yinc：unit voltage of Y direction
Yor：the relative position of Y direction and YREF zero position
Yref：the reference value of Y direction, the center point of screen
For example：
:WAVeform:PREamble?
return 1,0,0,1,8.000e-009,-6.000e-006,0,4.000e-002,0.000e000,100
UTD2000E Series Osilloscope Programming Manual
Page 52
:WAVeform:XINCrement?
Command format：
:WAVeform:XINCrement?
Functional description：
Query the time interval between two adjacent points in X direction of the selected source.
The returns value is related to data read mode:
NORMal mode，XINCrement=TimeScale/
base
RAW mode，XINCrement=1/SampleRate
Return format：
Query return
For example：
:WAV:XINC? query return 3.000e-003
time base count，unit is s.
waveform points in the horizontal direction of time
UNI-T
:WAVeform:XORigin?
Command format：
:WAVeform:XORigin?
Functional description：
Query the selected channel initial time of waveform data in the X direction, trigger point time is
zero, before trigger point is negative number.
Return value is related with the current data read mode：
NORMal mode，return initial time of waveform data display on the screen.
RAW mode，return initial time of waveform data storage in memory.
Return format：
Query return time value，unit is s.
For example：
:WAV:XOR? query return 3.000e-002
:WAVeform:XREFerence?
Command format：
:WAVeform:XREFerence?
Functional description：
Query the time reference of waveform points in X direction of the selected channel source, always
be zero.
Return format：
Query time reference，query return 0.
For example：
UTD2000E Series Osilloscope Programming Manual
Page 53
:WAV:XREF? query return 0
:WAVeform:YINCrement?
Command format：
:WAVeform:YINCrement?
Functional description：
Query unit voltage value of the current channel source in Y direction, unit is accord with
amplitude value.
Return value is related with the current data read mode:
NORMal mode，YINCrement = VerticalScale/waveform point of voltage base in vertical position
RAW mode，YINCrement is related with memory waveform VerticalScale and the current selected
VerticalScale.
Return format：
Query return unit voltage value of Y direction.
For example：
:WAV:YINC? query return 2.000e000
UNI-T
:WAVeform:YORigin?
Command format：
:WAVeform:YORigin?
Functional description：
Query the vertical shift in the Y direction of the current selected channel source relative to the
vertical reference position.
Return value is related with the current data read mode：
NORMal mode，YORigin = VerticalOffset/YINCrement
RAW mode，YORigin is related with memory waveform VerticalScale and the current selected
VerticalScale.
Return format：
Query return vertical offset, integer type.
For example：
:WAV:YOR? query return 0
:WAVeform:YREFerence?
Command format：
:WAVeform:YREFerence?
Functional description：
Query the reference position in the Y direction of the current selected channel source, ADC of
channel zero level channel.
UTD2000E Series Osilloscope Programming Manual
Page 54
Return value is related with the current data read mode:
NORMal mode，YREFerence is fixed as 128（the bottom of screen as 0, top as 255）
RAW mode，YREFerence is related with memory waveform VerticalScale and the current selected
VerticalScale.
Return format：
Query return referece position, integer type.
For example：
:WAV:YREF? query return 100
FILE Command
This command is for reference waveform and storage function.
:FILE:LOAD
Command format：
:FILE:LOAD <filename>[,<source>][,<disk>]
Functional description：
For loading waveform to the related channel or data setting.
<filename> file name must be character string data with double quotation mark, for
example “test.bsv”
The file name of *.bsv or *.csv presents load waveform data of the file into the reference
channel.
The file name of *.set presents load the setting data of the file into oscilloscope.
<source > presents reference channel{REFA | REFB | REFC | REFD}，optional parameter
only valid when load waveform data.
REFA presents reference channel A
REFB presents reference channel B
REFC presents reference channel C
REFD presents reference channel D
<disk> presents memory medium { FLASH | UDISK }，optional parameter，ignore presents
internal data of FLASH.
FLASH presents internal data
UDISK presents U disk data
UNI-T
For example：
FILE:LOAD "test.bsv",REFA,UISK
Load test.bsv waveform data into reference channel A from U disk
FILE:LOAD "system-set-up01.set"
Load No .1 configuration data into a oscilloscope from internal medium .
Notes：
The file name of internal storage setting must be"system-set-up01.set"~ "system-set-up255.set",
UTD2000E Series Osilloscope Programming Manual
Page 55
UNI-T
maximum limit 255 files.
The file name of internal storage bsv must be"wave01.bsv"~” wave255.bsv", maximum limit 255
files.
:FILE:SAVE
Command format：
:FILE:SAVE <filename>[,<source>][,<disk>]
Functional description：
For save channel waveform or setting data into file.
<filename> file name must be character string data with double quotation mark, for
example “test.bsv”
The file name of *.bsv or *.csv presents save channel waveform with the suffix name format
into file.
The file name of *.set presents save the setting data into file.
<source > presents physical channel {CHANnel1 | CHANnel2| CHANnel3| CHANnel4}，
optional parameter only valid when load waveform data.
CHANnel1 presents Channel 1
CHANnel2 presents Channel 2
CHANnel3 presents Channel 3
CHANnel4 presents Channel 4
<disk> presents memory medium { FLASH | UDISK }，optional parameter，ignore presents
internal data of FLASH.
FLASH presents internal data
UDISK presents U disk data
For example：
FILE:SAVE "test.bsv",CHANnel1,UDISK
Save waveform data of channel 1 as test.bsv format into U disk.
FILE:SAVE "system-set-up01.set"
The configuration data of oscilloscope save as No.1 position of internal medium.
FILE:SAVE "wave01.bsv",CHANnel1,FLASH
Save waveform data of channel 1 into internal medium.
FILE:SAVE "wave01.bsv",CHANnel1
Save waveform data of channel 1 into internal medium.
FILE:SAVE "system-set-up01.set",FLASH
The configuration data of oscilloscope save as internal medium.
FILE:SAVE "system-set-up01.set"
The configuration data of oscilloscope save as No.1 position of internal medium.
UTD2000E Series Osilloscope Programming Manual
Page 56
UNI-T
Notes：
The file name of internal storage setting must be"system-set-up01.set"~ "system-set-up255.set",
maximum limit 255 files.
The file name of internal storage bsv must be"wave01.bsv"~” wave255.bsv", maximum limit 255
files.
UTD2000E Series Osilloscope Programming Manual
Page 57
Appendix 1：Key Table
Key Functional Description LED
CH1 Channel 1 switch √
CH2 Channel 2 switch √
MATH Mathematical operation and menu √
AUTO Set control parameter automatically to display waveform
RS Control oscilloscope operating status, send this command
continuously, oscilloscope will step through stop and running
status
TMENu Trigger menu
DEFault Recovery default setting
HELP Help system
HMENu Horizontal system meue
DISPlay Display menu
F1 Select the first item of the current menu
F2 Select the second item of the current menu
F3 Select the third item of the current menu
F4 Select the fourth item of the current menu
F5 Select the fifth item of the current menu
MENu Menu display switch
PSCReen One key to print or one key save screen image
MEASure Measurement
CURSor Cursor measurement and menu
ACQuire Sampling menu
STORage Storage menu
UTILity Subsystem menu
FKNob Multifunction knob
FKNLeft Multifunction left knob
FKNRight Multifunction right knob
VPKNob Vertical position knob
VPKNLeft Vertical position left knob
VPKNRight Vertical position right knob
UNI-T
√
UTD2000E Series Osilloscope Programming Manual
Page 58
HPKNob Horizontal position knob
HPKNLeft Horizontal position left knob
HPKNRight Horizontal position right knob
TPKNob Trigger position knob
TPKNLeft Trigger position left knob
TPKNRight Trigger position right knob
VBKNob Voltage reference knob
VBKNLeft Voltage reference left knob
VBKNRight Voltage reference right knob
TBKNob Time reference knob
TBKNLeft Time reference left knob
TBKNRight Time reference right knob
SETZERO Zero setting
UNI-T
Appendix 2：Binary Data Format IEEE 488.2
DATA is data flow, other is ASCII character，as shown in the table below：
<#812345678 + DATA + \n>
Start mark
（1Byte）
# x x x x x x x x x
Length of bit wide
（1Byte）
Data total length（bit
wide Byte）
DATA（n Byte）
…………………
End mark
（1Byte）
\n
UTD2000E Series Osilloscope Programming Manual
Loading...
