Unify OpenStage 20 E, OpenScape Business, OpenScape Office, HiPath 3000 Operating Instructions Manual

OpenStage 20 E, OpenStage 20, OpenStage 20 G HiPath 3000, OpenScape Business, OpenScape Office

Operating Instructions

A31003-S2000-U106-13-7619

Unser Qualitäts- und Umweltmanagementsystem ist entsprechend den Vorgaben der ISO9001 und ISO14001 implementiert und durch ein externes Zertifizierungsunternehmen zertifiziert.

7619

Die Informationen in diesem Dokument enthalten lediglich allgemeine Beschreibungen bzw. Leistungsmerkmale, die je nach Anwendungsfall nicht immer in der beschriebenen Form zutreffen oder sich durch Weiterentwicklung der Produkte ändern können. Eine Verpflichtung, die jeweiligen Merkmale zu gewährleisten besteht nur, sofern diese ausdrücklich vertraglich zugesichert wurden.

Liefermöglichkeiten und technische Änderungen vorbehalten. Unify, OpenScape, OpenStage und HiPath sind eingetragene Warenzeichen der

Unify GmbH & Co. KG. Alle anderen Marken-, Produkt- und Servicenamen sind Warenzeichen oder eingetragene Warenzeichen ihrer jeweiligen Inhaber.

unify.com

Important information 3

Important information

Trademarks

For safety reasons, the telephone should only be supplied with power:

• using the original power supply unit. Part number: L30250-F600-C14x (x: 1=EU, 2=UK, 3=US) or

• in a LAN with PoE (Power over Ethernet), which complies with the IEEE 802.3af standard.

Never open the telephone or a key module. Should you encounter any problems, consult your administrator.

Use only original accessories. The use of other accessories may be hazardous and will render the warranty, extended manufacturer's liability and the CE marking invalid.

The device conforms to the EU Directive 1999/5/EC as attested by the CE marking.

All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

The correct disposal and separate collection of your old appliance will help prevent potential negative consequences for the environment and human health. It is a precondition for reuse and recycling of used electrical and electronic equipment.

For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service, the shop where you purchased the product or your sales representative.

The statements quoted above are only fully valid for equipment that is installed and sold in the countries of the European Union and is covered by the European Directive 2002/96/EC. Countries outside the European Union may have other regulations regarding the disposal of electrical and electronic equipment.

7 7

4 Important information

Location of the telephone

• The telephone should be operated in a controlled environment with an ambient temperature between 5°C and 40°C.

• To ensure good speakerphone quality, the area in front of the microphone (front right) should be kept clear. The optimum speakerphone distance is 50 cm.

• Do not install the telephone in a room where large quantities of dust accumulate; this can considerably reduce the service life of the telephone.

• Do not expose the telephone to direct sunlight or any other source of heat, as this is liable to damage the electronic components and the plastic casing.

• Do not operate the telephone in damp environments, such as bathrooms.

Software update

Product support on the Internet

Information and support for our products can be found on the Internet at:

http://www.unify.com

Technical notes, current information about firmware updates, frequently asked questions and lots more can be found on the Internet at:

http://wiki.unify.com/

During a software update, the phone must not be disconnected from the power supply unit, the LAN line or the phone line. An update action is indicated by messages on the display and/or by flashing LEDs.

Contents 5

Contents

Important information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Location of the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Software update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Product support on the Internet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

About this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Telephone type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Speakerphone quality and display legibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Voice encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Getting to know the OpenStage. . . . . . . . . . . . . . . . . . . . . . . . 12

The user interface of your OpenStage 20 E/20/20 G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Ports on the underside of the phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Using network ports more efficiently . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Function keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Mailbox key and Menu key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Audio keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3-way navigator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Dialpad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Idle mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Mailbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Caller list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Control and monitoring function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Basic functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Accepting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Accepting a call via the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Accepting a call via the loudspeaker (speakerphone mode) . . . . . . . . . . . . . . . . . . . . . . . . . 22

Switching to speakerphone mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Switching to the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Open listening in the room during a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Off-hook dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

On-hook dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Redialing a number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Rejecting calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Turning the microphone on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Calling a second party (consultation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Switching to the held party (alternating). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Transferring a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

6 Contents

Forwarding calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using variable call forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using call forwarding no reply (CFNR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Call forwarding in the event of telephone failure (CFSS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Call forwarding in the carrier network and

forwarding multiple subscriber numbers (MSN) (not for U.S.) . . . . . . . . . . . . . . . . . . . . . . . . 30

Using callback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Saving a callback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Accepting a callback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Viewing and deleting a saved callback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Enhanced phone functions . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Accepting calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Accepting a specific call for your colleague . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using the speakerphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Answering calls from the entrance telephone and opening the door. . . . . . . . . . . . . . . . . . . 34

Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

En-bloc sending/correcting numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Using the caller list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Calling a subscriber from the personal phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Calling a subscriber from the corporate directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Calling a subscriber from the internal system phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Using the LDAP directory from the system phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Making calls using system speed-dial numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Dialing with speed-dial keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Talking to your colleague with a speaker call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Talking to your colleague with discreet calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Automatic connection setup (hotline) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Assigning a station number (not for U.S.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Associated dialing/dialing aid. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

During a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Using call waiting (second call) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Preventing and allowing call waiting (automatic camp-on) . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Turning the call waiting tone on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Saving a number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Parking a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Conducting a conference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Activating tone dialing/DTMF suffix dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Transferring a call after a speaker call announcement in a group . . . . . . . . . . . . . . . . . . . . . 50

Sending a trunk flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

If you cannot reach a destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Call waiting (camp-on) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Busy override - joining a call in progress . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Using night answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Displaying and assigning call charges . . . . . . . . . . . . . . . . . . . 53

Displaying call charges (not for U.S.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Dialing with call charge assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Contents 7

Privacy/security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Voice encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Displaying status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Notes on voice encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Turning ringer cutoff on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Activating/deactivating "Do not disturb" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Caller ID suppression . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Monitoring a room . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Trace call – identifying anonymous callers (not for U.S.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Locking the telephone to prevent unauthorized use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Locking another telephone to prevent unauthorized use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Saving your PIN code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

More functions/services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Appointment reminder function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

Saving a timed reminder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Using timed reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

Sending a message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Creating and sending a message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Viewing and editing incoming messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Leaving an advisory message. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

Deleting advisory messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Using another telephone like your own for a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Using a mobile phone number at a random phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Logging on to the "guest telephone" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Moving the connection to the next telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Logging off from the "guest telephone" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Resetting services and functions

(system-wide cancelation for a telephone) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Activating functions for another telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Using system functions from outside

DISA (Direct Inward System Access) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Using functions in ISDN via code dialing (keypad dialing) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Controlling connected computers/programs/telephone data service . . . . . . . . . . . . . . . . . . . . . 70

Communicating with PC applications over a CSTA interface . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Controlling relays (only for HiPath 3000 and OpenScape Business) . . . . . . . . . . . . . . . . . . . . . 72

Sensors (HiPath 33x0/35x0 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Paging persons (not for U.S.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Phonebooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Personal phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Creating a new contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

Editing a contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Deleting a contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Deleting all contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Searching for a contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

Corporate directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Searching for a contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Advanced phonebook editing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Quick search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

8 Contents

Using team functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Activating/deactivating a group call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79

Picking up a call for another member of your team. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Ringing group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Uniform Call Distribution (UCD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82

Special functions in the LAN . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Leaving hunt group/group call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Setting up "follow me" call forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Using night answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Ringing group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Controlling relays (only for HiPath 3000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Opening a door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Individual phone configuration . . . . . . . . . . . . . . . . . . . . . . . . 89

Adjusting display properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Adjusting the display to a comfortable reading angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Setting contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Setting the ring tone mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Adjusting audio settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

Adjusting the receiving volume during a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Adjusting the ring volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

Adjusting the ringer pitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

Adjusting the speakerphone to the room acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Language for system functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Setting local ring tones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Changing the user password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

Network information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Testing the phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Testing the phone's functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Differing display views in a HiPath 4000 environment . . . . . . 97

Web interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Launching the web interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Administrator Pages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

User Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

User menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Fixing problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Responding to error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Contents 9

Contact partner in case of problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Care and cleaning instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Local user menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Opening the user menu on the phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

User menu display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Overview of functions and codes (alphabetical) . . . . . . . . . . 109

10 General information

General information

About this manual

This document contains general descriptions of the technical options, which may not always be available in individual cases. The required features must therefore be individually defined in the terms of the contract.

If a particular function on your phone is not available to you as described, this may be due to one of the following reasons:

• The function is not configured for you and your telephone. Please contact your system

administrator.

• Your communication platform does not feature this function. Please contact your Unify sales

partner for information on how to upgrade.

This user guide is intended to help you familiarize yourself with the OpenStage phone and all of its functions. It contains important information on the safe and proper operation of the OpenStage phone. These instructions should be strictly complied with to avoid operating errors and ensure optimum use of your multifunctional telephone in the network.

These instructions should be read and followed by every person installing, operating or programming the OpenStage phone.

These operating instructions are designed to be simple and easy to understand, providing clear step-by-step instructions for operating the OpenStage phone.

Administrative tasks are dealt with in a separate manual. The Quick Reference Guide contains quick and reliable explanations of frequently used functions.

Service

If you experience problems or defects with the phone, please dial the service number for your country.

Intended use

The OpenStage phone is a desktop or wall-mounted unit designed for voice transmission and for connection to a LAN. Any other use is regarded as unintended.

For your own protection, please read the section dealing with safety in detail. Follow the safety instructions carefully in order to avoid endangering yourself or other persons and to prevent damage to the unit.

The Unify service department can only help you if you experience problems or defects with the phone itself. Should you have any questions regarding operation, your specialist retailer or network administrator will gladly help you. For queries regarding connection of the telephone, please contact your network provider.

General information 11

Telephone type

The OpenStage 20 comes in three product variants, which can be differentiated as follows:

OpenStage 20 E

The suffix "E" stands for "economy". The OpenStage 20 E offers open listening as a feature Æ Page 23 but not speakerphone mode

Æ Page 22 and it has a 10/100 Mbps Ethernet switch Æ Page 13.

OpenStage 20

The OpenStage 20 offers speakerphone mode Æ Page 22 and has a 10/100 Mbps Ethernet switch Æ Page 13.

OpenStage 20 G

The suffix "G" stands for "Gigabit". The OpenStage 20 G offers speakerphone mode Æ Page 22 and has a 1000 Mbps Ethernet switch Æ Page 13.

The identification details (exact product designation and serial number) of your telephone can be found on the nameplate on the underside of the base unit. Specific details concerning your communication platform can be obtained from your administrator. Please always have this information to hand when you contact our service department regarding faults or problems with the product.

Speakerphone quality and display legibility

• To ensure good speakerphone quality (OpenStage 20/20 G only), the area in front of the

microphone (front right) should be kept clear. The optimum speakerphone distance is 50 cm.

• Proceed as follows to optimize display legibility:

– Turn the phone and tilt the display so that you have a frontal view of the display while

eliminating light reflexes.

– Adjust the contrast as required

Æ Page 89.

Voice encryption

On HiPath 3000/

OpenScape Business

(from R 4), HiPath Open Scape Office (V1), your

OpenStage

20 E/20/20 G supports voice encryption from software release 2 (V1 R2.xxxx). This

allows you to use your OpenStage to conduct calls without the risk of eavesdropping. Voice transmission is encrypted and then decrypted again on the call partner's phone and vice versa.

If "Secure Mode" is enabled on your phone and a connection is established to a phone that does not support voice encryption, the call is not encrypted and is

thus not secure.

Your administrator can define in the communication system whether and how you are notified of unencrypted calls. You can check in idle mode which security mode is activated on your

OpenStage

Æ Page 56.

12 Getting to know the OpenStage

Getting to know the OpenStage

The following sections describe the most frequently used controls and displays.

The user interface of your OpenStage 20 E/20/20 G

Note the description of the different product variants

Æ Page 11.

1 You can make and receive calls as normal using the handset. 2 The display permits intuitive operation of the phone Æ Page 17.

The function keys allow you to call up the most frequently used functions during a call (e.g.

Disconnect/Release) Æ Page 14.

4 O mailbox key and N menu key.

Audio keys are also available, allowing you to optimally configure the audio features of your telephone

Æ Page 14.

6 The 3-way navigator is a convenient navigation tool Æ Page 15. 7 The dialpad is provided for entering phone numbers/codes.

Getting to know the OpenStage 13

Ports on the underside of the phone

Properties of your OpenStage 20 E/20/20 G

Using network ports more efficiently

OpenStage 20 E/20 has a built-in 10/100 Mbps Ethernet switch. The OpenStage 20 G has a

1000

Mbps Ethernet switch. This means that you can connect a PC to the LAN directly via the phone. The option for connecting the telephone and PC must first be activated on the telephone by your administrator.

Using this connection option saves one network port for each switch used and requires fewer or shorter network cables when arranged correctly.

OpenStage 20 E 20 20 G

LCD display, 24 x 2 characters ; ; ; Full-duplex speakerphone function - ; ; 10/100 Mbps Ethernet switch Æ Page 13 ; ; - 1000 Mbps Ethernet switch Æ Page 13 - - ; Wall mounting ; ; ;

Network

Power supply unit

Earpi ece

Local cable type

OpenStage 20 E/20/20 G

Network switch PC

14 Getting to know the OpenStage

Keys

Function keys

Mailbox key and Menu key

Audio keys

Key Function when key is pressed

s End (disconnect) call Æ Page 25. , Saved number redial (last number dialed) Æ Page 25. r Button for call forwarding (with red key LED)

Æ Page 27.

1 If the key LED on your phone is flashing, your station has been set up as a forwarding destination.

Activate/deactivate the microphone (OpenStage 20/20 G only: also in speakerphone mode)

Æ Page 25.

Key Function when key is pressed

O Open mailbox (with red key LED) Æ Page 18. N Open menu (with red key LED) Æ Page 20.

Key Function when key is pressed

- Reduce volume and set contrast brighter Æ Page 89. n Turn speaker on/off (with red key LED) Æ Page 23. + Increase volume and set contrast darker Æ Page 89.

Getting to know the OpenStage 15

3-way navigator

This control allows you to manage most of your phone's functions as well as its displays.

Dialpad

In cases where text input is possible, you can use the dialpad to input text, punctuation and special characters in addition to the digits 0 to 9 and the hash and asterisk symbols. To do this, press the numerical keys repeatedly.

Example: To enter the letter "h", press the number 4 key on the keypad twice.

Alphabetic labeling of dial keys is also useful when entering vanity numbers (letters associated with the phone number's digits as indicated on the telephone spell a name, e.g.

0700 - PATTERN

= 0700 - 687837).

Multi-function keys

Remove the protective film from the ring around the 3-way navigator before using the phone.

Operation Functions when key is pressed

Press the $ key.

In idle mode:

• Open the idle menu Æ Page 17

In lists and menus:

• Scroll down

Press the % key.

In idle mode:

• Open the idle menu Æ Page 17

In lists and menus:

• Scroll up

Press the i key.

Entry selected:

• Perform action

Function ) (

Press and hold Turn phone lock on/off Æ Page 59

Text input Æ Page 16 Next letter in uppercase Delete character.

16 Getting to know the OpenStage

Character overview

Text input

Enter the required characters using the dialpad.

Choose the functions using the % and $ keys. Confirm your input with i.

Key 1x 2x 3x 4x 5x

1 Space

a b c 2

d e f 3

g h i 4

j k l 5

m n o 6

p q r s 7

t u v 8

w x y z 9

+ . - 0

)

2 Next letter in uppercase

(

3 Delete character

Getting to know the OpenStage 17

Display

Your OpenStage 20 E/20/20 G comes with a tilt-and-swivel black-and-white LCD display. Adjust the tilt and contrast to suit your needs

Æ Page 89ff.

Idle mode

Your phone is in idle mode when there are no calls taking place or settings being made.

Example:

Idle menu

When in idle mode, press the $ key on the 3-way navigator Æ Page 15 to display the idle menu.

You can call up various functions here. The idle menu includes selected functions from the Program/Service menu

Æ Page 20.

The idle menu may contain the following entries:

• Caller list

• Forwarding on

• Lock phone

• DND on

• Advisory msg. on

• Ringer cutoff on

• Send message

• View sent message

• View callbacks

• Phonebook (system phonebook)

• HF answerback on

• Suppress call ID

• Waiting tone off

• DISA internal

1. Must be activated by the administrator.

2. Only appears when there are messages that the recipient has not yet viewed.

3. Only appears if callback requests are saved.

220870 HiPath 4000 f

Time

Date

Open the idle menu

Own phone number

10:59 Wed 08 01.14

18 Getting to know the OpenStage

Mailbox

Depending on the type and configuration of your communication platform (consult the relevant administrator), messages from services, such

as HiPath Xpressions, are displayed in this

application in addition to messages received.

Messages

You can send short text messages to individual internal stations or groups.

In idle mode (Æ Page 17) the following signals alert you to the presence of new messages:

• O key LED lights up

• "Messages received" is displayed.

Press the mailbox key O.

Example:

Voicemail

If your telephone is connected to a voicemail system (such as Entry Voice Mail), the Mailbox key will also light up to alert you to any messages that have arrived. An appropriate message also appears on the display (for instance, in Entry Voice Mail: „X new messages").

To listen to your voicemail, follow the instructions on the display.

For a description of how to edit the entries Æ Page 63.

Text? f

Msg. from: Coco, Chanel

Display message

Caller ID

Function menu

Getting to know the OpenStage 19

Caller list

If you are unable to accept an external or internal call, the call attempt is stored in the caller list. External answered calls can also be saved in the caller list (consult your administrator).

Your telephone stores up to ten calls in chronological order. Each call is assigned a time stamp. The oldest entry not yet deleted in the list is displayed first. Multiple calls from the same caller do not automatically generate new entries in the caller list. Instead, only the most recent time stamp for this caller is updated and its number incremented.

The caller list is automatically displayed Æ Page 37 in the idle menu Æ Page 17.

Information is displayed regarding the caller and the time at which the call was placed.

Example:

Callers with suppressed numbers cannot be saved in the call list.

For a description of how to edit the call lists Æ Page 37.

Busy 21.02. 16:25 f

10168 PETER

Date

Telephone status during a call attempt

Time

Caller ID

Function menu

20 Getting to know the OpenStage

Use the menu key N to access the following options:

• Program/Service menu for your communication system

• Personal (local phonebook)

• Corporate (corporate directory)

• User (local telephone settings for users)

• Administrator (local telephone settings for administrators)

The menu key LED remains red as long as you are in this menu.

A double arrow next to an entry indicates the availability of additional options for this entry. The menu structure comprises several levels. The first line in this structure shows the menu currently selected while the second line shows an option from this menu.

Accessing the Program/Service menu

The Program/Service menu on your communication system can be accessed in three ways:

1. Press the menu key N, choose the Program/Service? option using the $ or % key and select the

i key to confirm.

2. Press the

$ or % key and choose a function from the idle menu Æ Page 17.

3. Press

( or ) in idle mode and select the code for the relevant function.

Control and monitoring function

A control or monitoring function can be activated on your phone for service purposes by remote maintenance.

Control function

Your administrator has the option to activate and deactivate features of the phone via remote maintenance. During maintenance, the handset, microphone, loudspeaker and headset are deactivated. You are additionally informed on the display that the control function is active.

Monitoring function

In order to detect malfunctioning of a phone, for example, your administrator can install a monitoring function. You can use your phone as normal during monitoring. However you will first be informed about the operation with a message on the display and prompted to allow monitoring.

You will find an overview of the available functions as well as the corresponding codes on

Æ Page 109.

Menu title

Further entries are available

D Next feature? l

Program/Service? f Changeover? f Follow-me? f

! Call forw. - follow me? f ! Administrator (Admin) m

Basic functions 21

Basic functions

Accepting a call

Special default ring signaling is set for your telephone:

• When you receive an internal call, your telephone rings once every four seconds (single-tone sequence).

• When you receive an external call, your telephone rings twice in rapid succession every four seconds (dual-tone sequence).

• When you receive a call from the entrance telephone, your telephone rings three times in rapid succession every four seconds (triple-tone sequence).

• If a call is waiting, you hear a short tone (beep) every six seconds.

The number or the name of the caller appears on the display.

Accepting a call via the handset

The phone rings. The caller appears on the screen. Pay attention to the notes on voice encryption Æ Page 56.

^ Lift the handset.

+ or - Raise or lower the volume. Keep pressing the key until the desired volume is set.

Please read the introductory chapter "Getting to know the OpenStage"

Æ Page 12 carefully before performing any of the steps described here on

your phone.

Your administrator can adjust the ring cadence for external and internal calls for you. In

other words, different ring cadences can be set for

different internal callers.

22 Basic functions

Accepting a call via the loudspeaker (speakerphone mode)

Notes on using speakerphone mode:

• Tell the other party that you are using speakerphone mode.

• The speakerphone works best at a low receiving volume.

• The ideal distance between the user and the telephone in speakerphone mode is about 50 cm (approx. 20 inches).

The phone rings. The caller appears on the screen. Pay attention to the notes on voice encryption Æ Page 56.

n Press the key shown. The LED lights up.

if nec + or - Raise or lower the volume. Keep pressing the key until the desired volume is set.

Ending the call

n Press the key shown. The LED goes out.

s Press the key shown.

Speakerphone mode is only available on the OpenStage 20/20 G.

Basic functions 23

Switching to speakerphone mode

Prerequisite: You are conducting a call via the handset.

n \ Hold down the key and replace the handset. Then release the key and continue

the call.

if nec. + or - Adjust the call volume. Keep pressing the key until the desired volume is set.

U.S. mode

If the country setting is set to U.S. (consult your administrator), you do not have to hold down the loudspeaker key when replacing the handset to switch to speakerphone mode.

n Press the key shown.

] Replace the handset. Proceed with your call.

if nec + or - Adjust the call volume. Keep pressing the key until the desired volume is set.

Switching to the handset

Prerequisite: You are conducting a call in speakerphone mode.

^ and [ Lift the handset. Proceed with your call.

Open listening in the room during a call

You can let other people in the room join in on the call. Let the other party know that you have turned on the speaker.

Prerequisite: You are conducting a call via the handset.

Activating

n Press the key shown. The LED lights up.

Deactivating

n Press the key shown. The LED goes out.

Speakerphone mode is only available on the OpenStage 20/20 G.

24 Basic functions

Making calls

Off-hook dialing

^ Lift the handset.

j Internal calls: Enter the phone number.

External calls: Enter the external code and the station number.

Pay attention to the notes on voice encryption Æ Page 56.

The called party does not answer or is busy:

\ Replace the handset.

On-hook dialing

j Internal calls: Enter the phone number.

External calls: Enter the external code and the phone number.

The other party answers with speaker:

^ Lift the handset.

or On-hook dialing (OpenStage 20/20 G only): Speakerphone mode.

Pay attention to the notes on voice encryption Æ Page 56.

The called party does not answer or is busy:

n Press the key shown. The LED goes out.

Basic functions 25

Redialing a number

The last three external phone numbers dialed are stored automatically.

You can redial them simply by pressing a key.

Displaying and dialing saved station numbers

, Press the key shown.

Keep confirming until the phone number you want appears.

Select and confirm the option shown.

Pay attention to the notes on voice encryption Æ Page 56.

Ending a call

\ Replace the handset.

s Press the key shown.

Rejecting calls

You can reject calls you do not wish to take. The call is then signaled on another definable telephone (consult your administrator).

The phone rings. The caller appears on the screen.

s Press the key shown.

If a call cannot be rejected, your telephone will continue to ring. The message "currently not possible" is displayed (e.g.

in the case of recalls).

Turning the microphone on and off

To prevent the other party from listening in while you consult with someone in your office, you can temporarily switch off the handset microphone or the handsfree microphone (OpenStage

20/20 G only). You can also switch on the

handsfree microphone to answer an announcement via the telephone speaker (speaker call

Æ Page 33).

Prerequisite: A connection is set up, the microphone is activated.

p Press the key shown. The LED lights up.

p Press the illuminated key. The LED goes out.

If this feature is configured (consult your administrator), account codes entered are also saved

Æ Page 54.

Next?

Call?

26 Basic functions

Calling a second party (consultation)

You can call a second party while a call is in progress. The first party is placed on hold.

Confirm the option shown.

j Call the second party.

Pay attention to the notes on voice encryption Æ Page 56.

Return to the first party, the second party does not answer:

Confirm the option shown.

or End the consultation:

Select and confirm the option shown.

Switching to the held party (alternating)

Select and confirm the option shown.

Pay attention to the notes on voice encryption Æ Page 56.

Combining the call parties in a three-party conference

Select and confirm the option shown.

Leaving a conference

Select and confirm the option shown.

Transferring a call

If the person you are speaking to wants to speak to another colleague of yours, you can transfer the call to that colleague.

Confirm the option shown.

j Enter the number of the party to whom you want to transfer the call. [ Announce the call, if necessary. \ Replace the handset.

Select and confirm the option shown1.

Consultation?

Return to held call?

Quit and return?

Toggle/Connect?

Conference?

If voice encryption is not activated or not available on a conference party's phone, the entire conference is not secure. It may be indicated that the call is not secure

Æ Page 56.

Leave conference?

For more information on conferences, see Æ Page 48.

Consultation?

Transfer?

1. ”Differing display views in a HiPath 4000 environment” Æ Seite 97

Basic functions 27

Forwarding calls

Using variable call forwarding

You can immediately forward internal or external calls to different internal or external telephones (destinations). (External destinations require special configuration in the system.)

r Press the key shown.

$ Open the idle menu Æ Page 17.

Select and confirm the option shown.

Confirm the option shown.

Select and confirm the option shown.

j Enter the destination number.

Confirm the option shown.

The call forwarding symbol as well as the phone number and possibly also the forwarding destination name are displayed.

Deactivating call forwarding

r Press the key shown.

c Open the idle menu Æ Page 17.

Select and confirm the option shown.

When call forwarding is active, a special dial tone sounds when you lift the handset. If DID DTMF is active (consult your administrator), you can also forward calls to this destination. Destinations: Fax = 870, DID =

871, Fax-DID =

872. If you are a call forwarding destination, the call forwarding key will flash

Æ Page 14.

Special features must be taken into consideration if your telephone operates with system networking via the PC network

Æ Page 85!

Forwarding on?

1=all calls?

2=external calls only?

3=internal calls only?

Save?

K 100168

Forwarding off

28 Basic functions

Using call forwarding no reply (CFNR)

Calls that are not answered after three rings (=default, can be adjusted by administrator) or that are received while another call is ongoing can be automatically forwarded to a specified telephone.

N Open the menu Æ Page 20.

Select and confirm the option shown.

j Enter the destination number.

• Enter the internal station number for internal destinations

• Enter the external code and the external station number for external destinations

Confirm the option shown.

Deactivating call forwarding no reply

N Open the menu Æ Page 20.

Select and confirm the option shown.

Confirm to deactivate and delete the forwarding destination.

Select and confirm to return to idle mode and not deactivate call forwarding.

Program/Service?

*495=CFNR on?

Save?

Program/Service?

#495=CFNR off?

Delete?

Exit

If CFNR is activated, "CFNR on" appears briefly on the display after you hang up.

Basic functions 29

Call forwarding in the event of telephone failure (CFSS)

If configured (consult your administrator), you can define an internal or external call forwarding destination that activates in the event of telephone failure.

N Open the menu Æ Page 20.

Select and confirm the option shown.

j Enter the destination number.

Confirm the option shown.

Deactivating call forwarding/deleting a destination:

N Open the menu Æ Page 20.

Select and confirm the option shown.

Confirm to deactivate and delete the forwarding destination.

Select and confirm to return to idle mode and not deactivate call forwarding.

Changing the forwarding destination (if call forwarding is active):

N Open the menu Æ Page 20.

Select and confirm the option shown.

)9411 Enter the code.

Confirm the option shown.

j Change the destination phone number.

Confirm the option shown.

Program/Service?

*9411= CFSS on?

Save?

Program/Service?

#9411= CFSS off?

Delete?

Exit?

Program/Service?

Change?

Save?

30 Basic functions

Call forwarding in the carrier network and forwarding multiple subscriber numbers (MSN) (not for U.S.)

If this function has been configured (consult your administrator), you can forward calls to your assigned multiple subscriber number (MSN) (DID number) directly within the carrier network. For example, you can forward your phone line to your home phone after business hours.

N Open the menu Æ Page 20.

Select and confirm the option shown.

Select and confirm the required type of call forwarding.

Select and confirm the option shown.

j Enter your DID number. j Enter the destination number (without the external code).

Confirm the option shown.

Deactivating call forwarding

Select and confirm the option shown.

Confirm the displayed call forwarding type.

j Enter your DID number.

Program/Service?

Trunk FWD on?

1=immediate?

2=on no answer?

3= on busy?

Save?

Trunk FWD off?
